Morphy Richards PERFORMAIR ENDURANCE BAGLESS CYLINDER VACUUM CLEANER - REV 2, PerformAir Endurance 71068 Instructions Manual
PPeerrffoorrmmAAiirr EEnndduurraannccee bbaagglleessss
ccyylliinnddeerr vvaaccuuuumm cclleeaanneerr
Please read and keep these instructions
Getting the best from your new cleaner...
If your cleaner is not picking up as well as it should, please check
FFiilltteerrss
It is important to rotate the filter dial prior to emptying.
This action shakes clean the dust canister pleated filter. See page 6.
BBlloocckkaaggeess
Check the nozzle, tubes and hose for blockages.
TTuurrbboo nnoozzzzllee
((cceerrttaaiinn mmooddeellss oonnllyy))
Remove hair and dirt caught around the brush bar regularly.
SSaaffeettyy ccuutt oouutt
If the product switches itself off during use, refer to page 7 for instructions.
VC71067 MUK Rev 2
For replacement parts, help with using your Morphy Richards, problems and lots
more, contact us by phone or through our website.
UK Helpline: 0845 077 7700
Ireland 1800 409 119
To register for your 3 year guarantee, ring the Helpline numbers below
within 28 days of purchase. This offer is only available in the UK.
Please have the following information available:
Serial number: Model number:
(see page 8 for guarantee details).
71067 Rev2 29/10/07 15:24 Page 1
22
IMPORTANT
SAFETY
INSTRUCTIONS
The use of any electrical
appliance requires the
following common sense
safety rules.
Primarily there is danger of
injury or death and
secondly the danger of
damage to the appliance.
These are indicated in the
text by the following two
conventions:
WARNING: Danger to
the person!
IMPORTANT: Damage to
the appliance!
In addition we offer the
following safety advice.
Please read before using
the appliance
Location
• Do not use or keep this
product outside.
• Do not store the appliance
near hot surfaces eg.
ovens or heating
appliances.
Mains lead
• Do not allow the mains
lead to become strained or
run this appliance over it.
• If the electrical cable
becomes damaged the
cable assembly must be
replaced. Do not attempt
this task yourself, contact
the helpline number that is
found at the bottom of the
page.
Personal safety
• The plug must be removed
from the wall socket before
cleaning or maintaining the
appliance.
• Never modify the cleaner in
any way.
• Never use in the presence
of explosive liquids or
vapours.
• Never pick up inflammable
or poisonous liquids such
as petrol, copier toner or
other volatile substances.
Never pick up acids,
asbestos or asbestos dust.
• Repairs to electrical
appliances are only to be
undertaken by trained
personnel. Unprofessional
repairs can be dangerous
for users.
• Use only genuine Morphy
Richards spare parts and
accessories.
• The appliance must never
be left running when
unsupervised.
• This vacuum cleaner is
intended for domestic use
only. Misuse or use for
commercial or any other
purpose will render the
guarantee invalid.
• This appliance is not
intended for use of persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they
have been given
supervision or instruction
concerning use of the
application by a person
responsible for their safety.
Product safety
• Never use the appliance
without the filters being
installed.
• Never use the appliance to
vacuum hot ashes, broken
glass, sharp objects or
liquids.
Children
• Children do not understand
the dangers associated
with operating electrical
appliances. Never allow
children to use this
appliance.
• Children should be
supervised to ensure that
they do not play with the
appliance, or stumble over
the power cord.
ELECTRICAL
REQUIREMENTS
Check that the voltage on
the rating plate of your
appliance corresponds with
your house electricity
supply which must be A.C.
(Alternating current).
If the socket outlets in your
home are not suitable for
the plug supplied with this
appliance the plug should
be removed and the
appropriate one fitted.
If you cut off the plug and
let go of the cable it will
rewind into the machine
therefore you must pull out
a length of cable and
secure it before cutting the
plug off and re-fitting a new
one.
WARNING: The plug
removed from the mains
lead, if severed, must be
destroyed as a plug with
a bared flexible cord is
hazardous if engaged
into a live socket outlet.
Should the fuse in the 13
amp plug require changing
a 13 amp BS1362 fuse
must be fitted.
FFoorr AAddvviiccee,, SSppaarreess oorr AAcccceessssoorriieess,, tteell:: 00884455 007777 77770000 ((UUKK)) oorr 11880000 440099 111199 ((IIrreellaanndd))
71067 Rev2 29/10/07 15:24 Page 2
FEATURES
⁄ Hose inlet
¤ Dust canister
‹ Dust canister release
button
› Carrying handle
fi On/off power switch
fl Eco Switch
‡ Parking slot
· Tool storage drawer
‚ Plug recess
„ Cable rewind switch
‰ Exhaust filter grille
 Exhaust filter
Ê Dust canister lid
Á Pleated, washable dust
canister filter
Ë Mesh filter cover
È Hose
Í Hose handle with airflow
regulator
Î Tube(s): 2 separate
attachable tubes, or 1
single telescopic tube
(length adjustable),
dependant on model.
Ï Combination floor nozzle
Ì Hard floor nozzle
(certain models only)
Ó Turbo nozzle
(certain models only)
Ô Hair and Stair tool
(certain models only)
Upholstery nozzle
Ò Clip on brush
(attached to )
Ú Crevice tool
Note: ,Ò,Ú are stored
in the tool storage drawer
·
Û Filter cleaning brush
Ù Dust canister lid release
33
⁄
¤
‹
›
fi
fl
‡
‚
Ê
‰
¤
„
Â
Ë
È
·
Í
Î
Ï
Ì
Ô
Ó
Á
Ò
Ú
Û
Ù
71067 Rev2 29/10/07 15:24 Page 3
44
FFoorr AAddvviiccee,, SSppaarreess oorr AAcccceessssoorriieess,, tteell:: 00884455 007777 77770000 ((UUKK)) oorr 11880000 440099 111199 ((IIrreellaanndd))
OPERATING THE
APPLIANCE
TOOLS AND
ACCESSORIES
1 Fit the hose to the cleaner by
inserting the hose end into the
hose inlet ⁄. When removing,
squeeze the clips either side
and pull.
2 Attach the tube(s): either the 2
separate attachable tubes, or
the single telescopic tube
(dependant on model).
• For the telescopic tube, extend
to the required length by
pushing up the slider release
and pulling out the tube A.
• The hose handle features an
airflow regulator which allows
suction to be reduced as
required.
3 Attach your choice of floor
nozzle to the end of the tube Î.
Combination floor
nozzle
The combination floor nozzle
can be adjusted to suit different
floor surfaces. Retract the
brushes for use on carpet. The
brushes should be down for use
on hardfloors or damage may
occur.
Hand tools
The crevice tool Ú (for awkward
places, behind radiators etc)
and the upholstery nozzle
with clip on brush Ò (for
curtains and upholstery) are
stored in the tool drawer · B.
Using the turbo
nozzle
(certain models only)
Attach the turbo nozzle Ó to
the telescopic tubes.
This nozzle is ideal for carpet
and especially effective at
removing pet hair.
Cleaning the turbo
nozzle
The turbo nozzle should be
regularly cleaned and any hairs
or fibres wrapped around the
brush bar removed to maintain
optimum performance.
Hardfloor nozzle
(certain models only)
Attach the hardfloor nozzle Ì
to the telescopic tubes. This
nozzle is ideal for use on wood,
laminate, tile and vinyl flooring.
Hair and Stair tool
(certain models only)
This tool Ô is suitable for
cleaning the stairs, and when
the additional attachment is
added, it is ideal for picking up
human and pet hair.
B
A
Ú
Ò
71067 Rev2 29/10/07 15:24 Page 4
55
Quick guide to
accessories:
CONTROLS
Power
1 Assemble with the required
hose, tube and accessory
2 Pull out the mains cable to it’s
full length and plug into the
mains supply.
3 Switch on by pressing the on/off
power switch fi.
Eco Switch
The Eco Switch fl allows you to
turn down the power when
cleaning more delicate items
such as curtains and upholstery,
saving energy and reducing
running costs.
Suction can also be controlled
using the airflow regulator on
the hose handle. Closed for
maximum suction, open for
reduced suction.
Automatic cable
rewind
After use, unplug and press the
cable rewind switch to retract
the cable.
WARNING: When using the
cable rewind, always hold
the plug as the cable will
rewind quickly.
Combination
floor nozzle
Turbo nozzle Hair and
Stair tool
Hard floor
nozzle
Crevice tool
Upholstery
nozzle with
clip on-brush
Carpet
!!
With brushes
retracted
!!
Rugs
!!
With brushes
retracted
!!
Wood/
laminate
!!
With brushes
down
!!
Tile
!!
With brushes
down
!!
Vinyl
!!
Upholstery
!! !! !! !!
Stairs
!! !!
Small spaces
!!
71067 Rev2 29/10/07 15:24 Page 5
66
FFoorr AAddvviiccee,, SSppaarreess oorr AAcccceessssoorriieess,, tteell:: 00884455 007777 77770000 ((UUKK)) oorr 11880000 440099 111199 ((IIrreellaanndd))
DUST CANISTER
Emptying
To obtain the best results from
your cleaner empty the dust
canister regularly, otherwise the
airflow and cleaning power will
be reduced.
1 Every time the dust canister is
emptied, turn the yellow dial (a
minimum of 5 revolutions) prior
to pressing the dust canister
release button (this will agitate
the fine dust between the filter
pleats and restore the air flow)
2 Remove the dust canister from
the product by pressing the dust
canister release button ‹. Lift
up the lid and remove the
canister from the product,
pulling the dust canister away
from the product. C
3 Holding the dust canister over a
dustbin press the dust release
button as shown D, the bottom
of the dust container will drop
down to release the dirt.
4 Close the bottom of the dust
canister by pressing the base
upwards until it clicks into place.
5 Refit the dust canister back into
the product. Make certain the
dust canister feet are located in
place.
6 Close the lid securely.
ALLERGY
SUFFERERS
When emptying any vacuum
cleaner, it is difficult to avoid
exposure to dust. To minimise
this risk, please ensure that you
encase the dust canister in a
large bag to empty it. Close the
bag as tightly as possible round
the dust canister. Remove the
dust canister and close the bag
as tightly and quickly as
possible and dispose of this
immediately. It is advisable to
wear disposable gloves and a
face mask while emptying the
cleaner. If at all possible, ask a
non allergy sufferer to empty the
dust canister when required.
FILTERS
Cleaning canister
filter
1 Access the filter assembly by
removing the lid Ê. Press the lid
release button Ù down then
rotate the lid anti-clockwise E.
2 Use the filter cleaning brush to
remove any fluff from the
outside of the mesh filter.
3 Rotate mesh filter clockwise to
disassemble the filters.
4 Shake the pleated filter to
remove any dust.
5 Both the mesh and pleated
filters may be washed (in cool
water only) but must be
thoroughly air dried before
refitting.
IMPORTANT: Do not use
detergents to clean the filters.
• A spare pleated filter is
provided. This allows one to be
in use whilst the other is washed
and dried.
6 To re-assemble, locate the
pleated filter into the lid then
secure into place with the mesh
filter by rotating the mesh filter
anti-clockwise.
7 Fit the lid with filter assembly
onto the canister then rotate
clockwise until it locks into
place.
OPEN
D
E
C
Ù
71067 Rev2 29/10/07 15:24 Page 6
77
Exhaust filter
The exhaust filter  is located
at the rear of the cleaner. Press
the catch and pull the exhaust
grille ‰ away F. Pull the
bottom of the filter outwards so
the top of the filter unhooks
from the filter recess.
To maintain the high efficiency,
the exhaust filter should be
replaced every 6 months.
IMPORTANT: To re-fit the filters,
first hook the top of the filter
into the filter recess then push
the bottom of the filter into
location G.
Note: If the filter is not correctly
hooked in, the exhaust filter
grille will not close.
After fitting the filter, re-fit the
exhaust filter grille by hooking
the bottom of the grille in first
and then pushing the top close
until it clicks fully closed.
IMPORTANT: All filters should
be checked regularly for signs
of damage, preferably after each
cleaning task. The filters must
be replaced immediately if they
become damaged.
• Always disconnect the cleaner
from the mains when checking
filters.
• Always make sure all filters are
fitted before use. Failure to do
so may result in damage to your
product.
Storage position
When finished you can store the
tubes and accessories by
locating the tube storage clip
into the parking slot on the side
of the cleaner as shown H.
Safety cut-out
If the cleaner overheats a motor
protection thermostat will
automatically switch the motor
off. If this happens, switch the
cleaner off, unplug from the
power supply and leave the
cleaner to cool for at least 60
minutes. Check the airways for
blockages, empty dust canister
and clean the filters before
restarting.
Cleaning and
maintenance
Unplug from the mains before
cleaning. The vacuum cleaner,
especially the dust
compartment and all
accessories can be cleaned
using a damp cloth or a nonabrasive cleaner and wiped dry.
Purchasing
replacement filters
Use only original Morphy
Richards filters. These can be
purchased from Morphy
Richards on Replacement parts
line.
HELPLINE
If you have any difficulty with
your appliance, do not hesitate
to call us.
We are more likely to be able
to help than the store from
where you bought it.
Please have the following
information ready to enable our
staff to deal with your query
quickly.
• Name of the product
• Model number as shown on the
underside of the appliance.
• Serial number as shown on
underside of the appliance.
UK Helpline 0845 077 7700
Ireland Helpline 1800 409 119
H
F
G
For electrical products sold
within the European
Community. At the end of
the electrical products
useful life it should not be
disposed of with
household waste.
Please recycle where
facilities exist. Check with
your Local Authority or
retailer for recycling advice
in your country.
71067 Rev2 29/10/07 15:24 Page 7
8
88
Morphy Richards products are intended for household use only.
Morphy Richards has a policy of continuous improvement in product quality and
design. The company, therefore reserves the right to change the specification of
its models at any time.
The After Sales Division
Morphy Richards Ltd
Mexborough, South Yorkshire,
England, S64 8AJ
Helpline (office hours)
UK 0845 077 7700
Republic of Ireland 1800 409 119
FFoorr ddeettaaiillss ooff ootthheerr pprroodduuccttss iinn tthhee MMoorrpphhyy RRiicchhaarrddss rraannggee pplleeaassee sseeee oouurr wweebbssiittee .. .. ..
VC71067 MUK Rev 2 10/07
YOUR THREE
YEAR
GUARANTEE
Available on registration
in the UK only
This 3 year guarantee is only
valid when registered directly
with Morphy Richards within
28 days of purchase. If you do
not register your product within
28 days, it is guaranteed for 2
years. To validate your 3 year
guarantee, telephone our
consumer helpline. Once you
have registered your product,
you will receive written
confirmation from Morphy
Richards, please retain this
information. Please note that
the 3 year guarantee is only
available in the UK. Please
refer to your 2 year guarantee
for more information.
YOUR TWO
YEAR
GUARANTEE
It is important to retain the
retailer’s receipt as proof of
purchase. Staple your receipt
to this back cover for future
reference.
Please quote the following
information if the product
develops a fault. These
numbers can be found on the
base of the product.
Model no.
Serial no.
All Morphy Richards products
are individually tested before
leaving the factory. In the
unlikely event of any appliance
proving to be faulty within 28
days of purchase, it should be
returned to the place of
purchase for it to be replaced.
If the fault develops after 28
days and within 24 months of
original purchase, you should
contact the Helpline number
quoting Model number and
Serial number on the product,
or write to Morphy Richards at
the address shown.
You may be asked to return a
copy of proof of purchase.
Subject to the exclusions set
out below (see Exclusions) the
faulty appliance will then be
repaired or replaced and
dispatched usually within 7
working days of receipt.
If you suspect a fault, follow
the simple checks detailed
below before retrying the
appliance or calling the
helpline.
• Check the filters for blockages.
• Check the tools / tubes for
blockages.
• Check the plug is firmly in the
socket.
• Check the socket is working by
trying another appliance.
• Check the fuse in the plug.
If for any reason this item is
replaced during the 2 year
guarantee period, the
guarantee on the new item will
be calculated from original
purchase date. Therefore it is
vital to retain your original till
receipt or invoice to indicate
the date of initial purchase.
To qualify for the 2 year
guarantee, the appliance must
have been used according to
the instructions supplied.
Exclusions
Morphy Richards shall not be
liable to replace or repair the
goods under the terms of the
guarantee where:
1 The fault has been caused or is
attributable to accidental use,
misuse, negligent use or used
contrary to the manufacturer’s
recommendations
or where the fault has been
caused by power surges or
damage caused in transit.
2 The appliance has been used
on a voltage supply other than
that stamped on the products.
3 Repairs have been attempted
by persons other than our
service staff (or authorised
dealer).
4 Where the appliance has been
used for hire purposes or non
domestic use.
5 Morphy Richards are not liable
to carry out any type of
servicing work, under the
guarantee.
6 The guarantee excludes
consumables such as some
filters.
• This guarantee does not confer
any rights other than those
expressly set out above and
does not cover any claims for
consequential loss or damage.
This guarantee is offered as an
additional benefit and does not
affect your statutory rights as a
consumer.
• This guarantee is valid in the
UK and Ireland only.
71067 Rev2 29/10/07 15:24 Page 8
Loading...
