Page 1
www.morphyrichards.com.au
Microwave Oven
INSTRUCTION MANUAL
Model: MRMWO20WTE
Read these instructions carefully before
using your microwave oven.
STORE THESE INSTRUCTIONS CAREFULLY
Page 2
TO EXCESSIVE MICROWAVE ENERGY
• Do not attempt to operate this oven with the door open since this
can result in harmful exposure to microwave energy. It is important
not to break or tamper with the safety interlocks.
• Do not place any object between the oven front face and the door
or allow spatter/matter or cleaner residue to accumulate on sealing
surfaces.
IMPORTANT SAFETY INSTRUCTIONSPRECAUTIONS TO AVOID POSSIBLE EXPOSURE
WARNING
To reduce the risk of fire, electric shock, injury to persons or exposure
to excessive microwave oven energy when using your appliance, follow
basic precautions, including the following:
• Read and follow the specific: “PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY”.
• WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its
surface could be degraded and affect the lifespan of the apparatus and
lead to a dangerous situation.
SPECIFICATIONS
Model: MRMWO20WTE
Rated Voltage: 230-240V~50Hz
Rated Input Power: 1050W
Rated Output Power: 700W
Oven Capacity: 20L
Turntable Diameter: 255mm
External Dimensions (L x W x H): 439.5 x 334.2 x 258.2mm
Net Weight: Approx. 9.17kg
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with
the appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard. (For appliance with type Y attachment)
• WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
• WARNING: It is hazardous for anyone other than an authorised
repairer/technician to carry out any service or repair operation that
involves the removal of a cover which gives protection against
exposure to microwave energy.
• WARNING: Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
• Do not heat food in plastic or paper containers, due to the possibility
of ignition.
• Only use utensils that are suitable for use in microwave ovens.
2 3
Page 3
• If smoke is emitted, switch off or unplug the appliance and keep the
door closed in order to stifle any flames.
• Metallic containers for food and beverages are not allowed during
microwave cooking.
• Microwave heating of beverages can result in delayed eruptive
boiling, therefore care must be taken when handling the container.
• The contents of feeding bottles and baby food jars shall be stirred or
shaken and the temperature checked before consumption, in order
to avoid burns.
• Eggs in their shell and whole hard-boiled eggs should not be heated
in microwave ovens since they may explode, even after microwave
heating has ended.
• The oven should be cleaned regularly and any food deposits
removed.
• Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
• Only use the temperature probe recommended for this oven. (For
ovens provided with a facility to use a temperature-sensing probe.)
• The microwave oven shall not be operated in a closed cabinet.
• The appliance shall not be cleaned with a steam cleaner.
• The appliance is intended to be used freestanding.
• The rear surface of appliances shall be placed against a wall.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential environments;
- bed and breakfast type environments
It is not suitable for commercial or laboratory use.
• The microwave oven is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads, slippers,
sponges, damp cloth and similar may lead to risk of injury, ignition
or fire.
4 5
Page 4
To Reduce the Risk of Injury to Persons Grounding Installation
DANGER
ELECTRIC SHOCK HAZARD
Touching some of the internal components can cause serious personal injury
or death. Do not disassemble this appliance.
WARNING
ELECTRIC SHOCK HAZARD
Improper use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for
the electric current.
This appliance is equipped with a cord having a grounding wire with a
grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are
not completely understood or if doubt exists as to whether the appliance is
properly grounded.
CLEANING
BE SURE TO UNPLUG THE APPLIANCE FROM THE POWER SUPPLY.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be cleaned carefully
with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
shattering of the glass.
5. Cleaning Tip: For easier cleaning of the cavity walls that the food cooked
can touch: Place half a lemon in a bowl, add 300ml (1/2 pint) water and
heat on 100% microwave power for 10 minutes. Wipe the oven clean using
a soft, dry cloth.
UTENSILS CAUTION
It is hazardous for anyone other than an authorised repairer/technician to carry
out any service or repair operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
See the instructions on “Materials you can use in microwave oven or to be
avoided in microwave oven.” There may be certain non-metallic utensil/
container that are not safe to use for microwaving. If in doubt, you can test the
utensil/container in question following the procedure below.
UTENSILS TEST
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with
the utensil/container in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil/container is warm, do not use
it for microwave cooking.
4. Do not exceed 1 minute cooking time.
6 7
Page 5
MATERIALS YOU CAN USE IN MICROWAVE OVEN MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Utensils Remarks
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must
be at least 3/16 inch (5mm) above the turntable. Incorrect usage may
cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer's instructions.
Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Paper plates and cups Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with
metal handle
Metal or metal
trimmed utensils
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed
Wood Wood will dry out when used in the microwave oven and may split or
May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy.
Metal trim may cause arcing.
to high temperature.
crack.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should
be labeled "Microwave Safe". Some plastic containers soften, as the
food inside gets hot. "Boiling bags" and tightly closed plastic bags
should be slit, pierced or vented as directed by package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
8 9
Page 6
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
F
C BE D
G
a. Control panel
b. Turntable shaft
c. Turntable ring assembly
d. Glass tray
e. Observation window
f. Door assembly
g. Safety interlock system
TURNTABLE INSTALLATION
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
a. Never place the glass tray upside
down. The glass tray should never be
restricted.
b. Both glass tray and turntable ring
assembly must always be used during
cooking.
c. All food and containers of food are
always placed on the glass tray for
cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
COUNTERTOP INSTALLATION
Remove all packing material and
accessories. Examine the oven for any
damage such as dents or broken door. Do
not install if oven is damaged.
A
Cabinet: Remove any protective film
found on the microwave oven cabinet
surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
INSTALLATION
1. Select a level surface that provides
enough open space for the intake
and/or outlet vents.
30cm
0cm
20cm
min85cm
20cm
• The minimum installation height
is 85cm.
• The rear surface of appliance
should be placed against a
wall.
• Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm is
required between the oven and
any adjacent walls.
• Do not remove the legs from
the bottom of the oven.
• Blocking the intake and/ or
outlet openings can damage
the oven.
• Place the oven as far away
from radios and TV as possible.
Operation of microwave oven
may cause interference to your
radio or TV reception.
2. Plug your oven into a standard
household outlet. Be sure the
voltage and the frequency is
the same as the voltage and the
frequency on the rating label.
WARNING:
Do not install oven over a range
cooktop or other heat-producing
appliance. If installed near or over
a heat source, the oven could be
damaged and the warranty would be
void.
THE ACCESSIBLE
SURFACE MAY BE HOT
DURING OPERATION.
10 11
Page 7
OPERATION INSTRUCTIONS
CLOCK SETTING
1. In standby state, press “CLOCK” to display “00:00”, hour high flashing, “:” and other “0”
always bright.
2. Press the number keys and enter the current time. For example, time is 12:10 now, please
press “1,2,1,0” in turn.
3. Press “CLOCK” to finish clock setting. “:” will flash and the clock will be lit.
If the input numbers are not within the range of 1:00–12:59, the setting will be invalid.
4. If the clock needs to be reset, please repeat step 1 to step 3. If step 3 is not confirmed by
pressing the “CLOCK” key, the originally set clock is restored after 1 minute or after pressing
the “STOP/CANCEL” key.
Note:
• If the clock is not set immediately after initial power-up, the screen will display “0:00” until
the time has been manually set.
• During the process of clock setting, if the “STOP/CANCEL” key is pressed or if there is no
operation within 1 minute, the oven will exit the setting state and the setting is invalid.
KITCHEN TIMER
1. Press “KITCHEN TIMER” once, LED will display “00:00”.
2. Press the number buttons and enter the correct time (the maximum cooking time is 99
minutes and 99 seconds).
3. Press “START/+30SEC.” to confirm setting.
4. When the kitchen timer has completed the countdown, the buzzer will ring before returning to
the standby state.
Note:
• The kitchen timer is different from the 12-hour clock, the kitchen timer is a timer.
• When the kitchen timer is in use, no additional program can be set.
MICROWAVE COOKING
Select different microwave power levels and cooking times as you wish. There are multiple power
levels available. Press the number buttons to choose the power. The default power level is 100%
power. The maximum cooking time is 99 minutes and 99 seconds.
Example: If you want to use 50% microwave power to cook for 15 minutes, you can operate the
oven as the following steps:
1. Press “TIME COOK” once, the oven will display “00:00”.
2. Press “1”, “5”, “0”, “0” in order.
3. Press “POWER” once, then press “5” to select 50% microwave power.
4. Press “START/+30SEC.” to start cooking. During cooking or when cooking is paused, the
screen will display the remaining cooking time.
Note:
• When setting the power level and cooking time, if you press “STOP/CANCEL” or if no
operation in 1 minute, the oven will go back to the previous status automatically.
• If “PL0” is selected, the fan will work using 0% microwave energy.
• During cooking, press “POWER” to change the microwave power level. The current power
will flash for 3 seconds and you can change the microwave power level. The selected
power level will be set for the remainder of the cooking time.
Microwave Power Chart
Level 10 9 8 7 6 5 4 3 2 1 0
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1 PL0
12 13
Page 8
SPEEDY COOKING
AUTO MENU COOKING
1. In the standby state, cook on 100% microwave power by pressing the number buttons 1 to 6
to set a cooking time between 1 to 6 minutes, then press “START/+30SEC.” to start cooking.
Press “START/+30SEC.” to increase the cooking time; the maximum cooking time is 99
minutes and 99 seconds.
2. When the oven is in the standby state, press the “START/+30SEC.” button to start cooking
on full microwave power for 30 seconds. Keep pressing “START/+30SEC.” to increase the
cooking time by 30 second increments (the maximum setting is 99 minutes and 99 seconds).
Note: During microwave cooking and time defrost, the cooking time can be increased in 30
second increments by pressing the “START/+30SEC.” button.
DEFROST BY WEIGHT
1. Press “ WEIGHT DEFROST” once, the oven will display “dEF1”.
2. Input the weight of the food (weight should be within 100–2000g).
3. Press the “START/+30SEC.” button to start defrosting.
DEFROST BY TIME
1. Press “TIME DEFROST” once, the oven will display “dEF2”.
2. Input the cooking time (the maximum cooking time is 99 minutes and 99 seconds).
3. The default microwave power for defrosting by time is “PL3” To change the power level,
press “POWER” once, the oven will display “PL3”, then press a number button to select the
microwave power.
4. Press the “START/+30SEC.” button to start defrosting.
Example: Cooking 350g of frozen vegetables:
1. Press “FROZEN VEGETABLE” twice, the oven will display “350”.
2. Press the “START/+30SEC.” button to start cooking.
AUTO MENU CHART
Menu Weight Press Times Display
50g Once 50
POPCORN
100g Twice 100
1 (approximately 230g) Once 1
POTATO
PIZZA
FROZEN VEGETABLE
BEVERAGE
2 (approximately 460g) Twice 2
3 (approximately 690g) 3 times 3
100g Once 100
200g Twice 200
400g 3 times 400
150g Once 150
350g Twice 350
500g 3 times 500
1 cup (approximately 120ml) Once 1
2 cups Twice 2
3 cups 3 times 3
250g Once 250
DINNER PLATE
14 15
350g Twice 350
500g 3 times 500
Page 9
MEMORY FUNCTION
INQUIRING FUNCTION
1. Press the “0/MEMORY” button to choose the memory “1”, “2” or “3” program, and the oven
will display “1”, “2” or “3”.
2. If the program has been set, press “START/+30SEC.” to start cooking. If no program has been
set, continue to set the program.
3. After you have set a memory program, press “START/+30SEC.” once to save the program and
the display will return to the standby state. Press “START/+30SEC.” again to start cooking.
Example: To set the memory 2 program to cook the food for 3 minutes and 20 seconds on 80%
microwave power, the steps are as follows:
1. In the standby state, press “0/MEMORY” twice, the oven will display “2”.
2. Press “TIME COOK” once, then press “3”, “2”, “0” in order.
3. Press “POWER” once, then press “8” and the oven will display “PL8”.
4. Press “START/+30SEC.” twice to save the program and start cooking.
5. To start the program from the standby state, press “0/MEMORY” twice, then press
“START/+30SEC.” to start cooking.
Note:
• Only one or two stages can be set as a memory program.
• After interruption to the electricity supply, all Memory programs will need to be re-entered.
MULTI-STAGE COOKING
Two stages of cooking can be set. If one of the stages is defrosting, it should be put in the first
stage automatically.
Example: If you want to cook food for 5 minutes on 80% microwave power + 10 minutes on 60%
microwave power, do it as the following:
1. Press “TIME COOK” one, then press “5”, “0”, “0”, to set the cooking time.
2. Press “POWER” once, then press “8” to select 80% microwave power.
3. Press “TIME COOK” once, then press “1”, “0”, “0”, “0” to set the cooking time.
4. Press “POWER” once, then press “6” to select 60% microwave power.
5. Press “START/+30SEC.” to start cooking.
1. To check the time during cooking, press “CLOCK”, the clock time will flash for three seconds.
2. To check the microwave power during cooking, press “POWER”, the current microwave power
will be displayed for three seconds before return to the previous state.
CHILD LOCK
LOCK:
In the standby state, press “STOP/CANCEL” for 3 seconds, there will be a long beep and the oven
will display “ ”.
UNLOCK:
In the locked state, press “STOP/CANCEL” for 3 seconds, there will be a long beep when the
oven returns to the standby state.
SPECIFICATIONS
• The oven will beep 5 times to let you know that cooking is complete.
• In the standby state, if the clock is set, the screen will display the time and “:” will flash.
If the clock is not set, the screen will display “0:00”.
• In the function setting state, the screen will display the corresponding setting.
• During cooking or when cooking has been paused, the screen will display the remaining
cooking time.
Note: Auto cooking menus cannot be set as one stage of multi-stage cooking.
16 17
Page 10
TROUBLE SHOOTING
Normal
NOTES
Microwave oven
interfering with TV
reception
Dim oven light In low power microwave cooking, the oven light may become
Steam accumulating on
door, hot air out of vents
Oven started accidentally
with no food in
Radio and TV reception may be interfered with when the
microwave oven is operating. It is similar to the interference of
small electrical appliances, like a mixer, vacuum cleaner, and
electric fan. It is normal.
dim. It is normal.
In cooking, food can release steam. Most escape from vents,
but some may accumulate on a cool place like the oven door.
It is normal.
Do not run the unit without any food inside.
Trouble Possible Cause Remedy
Oven cannot be started 1. Power cord not
plugged in tightly
2. Fuse blowing or circuit
breaker works
Unplug. Then plug in again
after 10 seconds
Replace fuse or reset
circuit (repaired by
professional personnel of
our company)
3. Trouble with outlet Test outlet with other
appliances
Oven does not heat 4. Door not fully closed Close door
18 19
Page 11
Recycling: Do not dispose of electrical appliances
as unsorted municipal waste. Use separate
collection facilities. Contact your local government
for information regarding the collection systems
available. If electrical appliances are disposed
of in landfills or dumps, hazardous substances
can leak into the ground water, polluting the food
chain and damaging health and wellbeing.
Glen Dimplex Australia Pty Ltd
1340 Ferntree Gully Road
Scoresby VIC 3179
Phone: 1300 556 816
Email: sales@glendimplex.com.au
Web: www.morphyrichards.com.au
Loading...
