Replacing the micro
filters
The micro-filters must be cleaned everytime
the bag is changed to remove the fine dust
particles collected. This can be done by
shaking them.
However, after approximately 5 dustbag
changes, the filters should be replaced.
The motor protection filter is found in the
dustbag compartment. With the dustbag
removed, release the filter from the securing
flap and clean or replace.
The exhaust filter is located behind the
exhaust filter outlet cover
fi. To remove,
unclip the cover, remove the filter and clean or
replace.
IMPORTANT: Do not operate without a
micro filter fitted.
Care and
maintenance
Your cleaner is manufactured to withstand
normal day-to-day use, but an occasional wipe
over with a damp cloth will help maintain its
good looks. Abrasive cleaners should not be
used.
Purchasing new dust
bags and filters
Use original Goblin bags and filters.
Replacement packs can be purchased from
specialist retailers. If you have difficulty, call the
number on the front of this booklet.
Helpline
If you have any difficulty with your
appliance, do not hesitate to call us. We’re
more likely able to help than the store from
where you bought it.
Please have the following information ready
to enable our staff to deal with your query
quickly:
•Name of the product
• Model number as shown on the underside
of the appliance
• Serial number.
5
7831 Compact ib 06/02/2002 2:20 PM Page 1
Your two-year
guarantee
• It is important to retain the retailers receipt
as proof of purchase. Staple your receipt to
this back cover for future reference.
Please quote the following information if the
product develops a fault. These numbers can
be found on the base of the product.
Model no. Serial no.
All Goblin products are individually tested
before leaving the factory. In the unlikely event
of any appliance proving to be faulty within 28
days of purchase it should be returned to the
place of purchase for it to be replaced.
If the fault develops after 28 days and within
24 months of original purchase, you should
contact the helpline number quoting model
number and serial number on the product, or
write to Morphy Richards at the address shown.
You will be asked to return the product (in
secure, adequate packaging) along with a copy
of proof of purchase. Subject to the exclusions
set out below (1-5), the faulty appliance will
then be repaired or replaced and dispatched
usually within seven working days of receipt.
If you suspect a fault, follow the simple
checks detailed below before returning the
appliance or calling the helpline.
• Check the dust bag and filters for
blockages.
• Check the hose and tubes for blockages.
• Check the plug is firmly in the socket and
the supply is switched on.
• Make sure the socket is working by trying
another appliance.
If for any reason this item is replaced during
the two-year guarantee period, the guarantee
on the new item will be calculated from original
purchase date. Therefore it is vital to retain your
original receipt or invoice to indicate the date of
initial purchase.
To qualify for the two year guarantee the
appliance must have been used according to
the manufacturers instructions. For example
bags and filters should be changed or cleaned
regularly.
Goblin shall not be liable to replace or repair
the goods under the terms of the Guarantee
where:
1 The fault has been caused or is attributable
to accidental use, mis-use, negligent use or
used contrary to the manufacturers
recommendations or where the fault has
been caused by power surges or damage
caused in transit.
2 The appliance has been used on a voltage
supply other than that marked on the
products.
3 Repairs have been attempted by persons
other than our service staff (or authorised
dealer).
4 Where the appliance has been used for hire
purposes or non-domestic use.
5 The guarantee excludes consumables such
as bags and filters.
This guarantee does not confer any rights
other than those expressly set out above and
does not cover any claims for consequential
loss or damage. This guarantee is
offered as an additional benefit
and does not affect your
statutory rights as a consumer.
• This guarantee is valid in
the UK and Ireland only.
442/8673/09 Rev 2 2/02
The After Sales Division,
Goblin, Mexborough,
South Yorkshire, England, S64 8AJ
Helpline (office hours)
UK (local rate) 08450 777700
Republic of Ireland 1800 409119
Goblin products are intended for
household use only
Goblin has a policy of continuous
improvement in product quality and
design. The Company, therefore,
reserves the right to change the
specification of its models at any time.
For additional information on Goblin products www.morphyrichards.co.uk
7831 Compact ib 06/02/2002 2:20 PM Page 2
Compact vacuum cleaner
Please read and keep these instructions
getting the best from
your new cleaner...
If your cleaner isn’t picking up as
well as it should, please check
• Dustbags
It is important to replace them when full, otherwise the
performance of the cleaner will be impaired
• Filters
It is important that the filters are cleaned and replaced
regularly to allow air through the appliance
• Blockages
Check the nozzle, tubes and hose for blockages
www .morphyrichards.co.uk
7831 Compact ib 06/02/2002 2:20 PM Page 3
2
Important safety
instructions
The use of any electrical appliance requires
the following of common sense safety rules.
Primarily there is danger of personal injury
and secondly danger of damage to the
appliance and property. These are indicated in
the text by the following two conventions:
WARNING: Danger of personal injury
IMPORTANT: Damage to the appliance
In addition we offer the following essential
safety advice.
Location
• Do not use or keep this product outside
when it is raining.
• Do not store the appliance near hot ovens
or heating appliances.
Mains lead
• Do not allow the mains lead to become
strained or run this appliance over it.
• If the electrical cable becomes damaged
the complete cable assembly must be
replaced. Do not attempt this task yourself,
contact Goblin using the helpline number.
Children
• Children do not understand the dangers
associated with operating electrical
appliances. Never allow children to use this
appliance.
Other safety considerations
• Never use the appliance without the filter
installed.
• Never use the appliance to vacuum hot
ashes, broken glass, sharp objects or
liquids.
• Never use in the presence of explosive
liquids or vapours.
• Never pick up inflammable or poisonous
liquids such as petrol, copier toner, or other
volatile substances. Never pick up acids,
asbestos or asbestos dust.
• Always disconnect the appliance from the
mains supply after use or prior to cleaning
or replacing dust bags.
• The appliance should never be left running
unsupervised.
• Never modify the cleaner in any way.
• Repairs to electrical appliances are only to
be undertaken by trained personnel.
Unprofessional repairs can be dangerous
for users.
• Use only genuine Goblin spare parts and
accessories
Electrical
requirements
Check that the voltage on the rating plate
of your appliance corresponds with your house
electricity supply which must be A.C.
(Alternating Current).
If the socket outlets in your home are not
suitable for the plug supplied with this
appliance, the plug should be removed and the
appropriate one fitted.
If you cut off the plug and let go of the
cable it will rewind into the machine. Therefore
you must pull out a length of cable and secure
it before cutting off the plug and refitting a new
one.
WARNING: The plug removed from the
mains lead, if severed, must be destroyed
as a plug with bared flexible cord is
hazardous if engaged into a live socket
outlet.
Should the fuse in the 13 amp plug require
replacement, a BS1362 13 amp fuse must be
fitted.
7831 Compact ib 06/02/2002 2:20 PM Page 4
⁄
¤
›
‰
„
‚
‡
3
⁄
Dust compartment cover
¤ Hose inlet
‹ Cable rewind pedal
› Dustbag compartment lid release
fi Exhaust filter outlet
fl On/off power foot pedal
‡ Dustbag condition indicator
· Carrying handle
‚ Hose with handle and airflow control
„ Extension tubes
‰ Combination floor nozzle
 Crevice tool
Ê Brush head for crevice tool
·
ÂÊ
fl
fi
A
‹
7831 Compact ib 06/02/2002 2:20 PM Page 5
4
Quick start
1 Assemble the nozzle, tubes and hose as
shown
A.
2 Pull out the cable to it’s full length and plug
in to the mains supply.
3 Switch on by pressing the foot pedal
fl.
Accessories
A range of accessories is provided with
some stored within the machine for added
convenience.
1 Fit the hose to the cleaner by inserting the
hose end into the hose inlet
¤ and twist.
2 Attach the extension tubes to the handle
end of the hose. The hose handle features a
regulator which allows the suction to be
reduced as required.
3 Attach the combination floor nozzle to the
extension tubes. The floor nozzle has two
levers for two positions:
• brush up for carpets, rugs etc.
•brush down for hard floors, tiles etc.
Other accessories are stored at the back of
the cleaner and include:
•crevice tool
 for awkward places, behind
radiators etc.
• brush attachment
Ê for pelmets, delicate
objects etc which attaches to the crevice
tool
Controls
Power
The on/off control is operated by the foot
pedal
fl.
The suction power can be adjusted using
the fingertip control ‚ on the handle.
Closed: full suction
Open: low suction
Automatic cable rewind
After use, unplug and press the cable
rewind button to retract the cable.
WARNING: When using the cable
rewind, always hold the plug as the cable
will rewind quickly.
Replacing the
dustbag
To obtain the best results from your cleaner
be sure to check and change the dustbag
regularly, otherwise the airflow and cleaning
power of your cleaner will be reduced.
When the dustbag condition indicator
‡
has changed to red, it is necessary to replace
the dustbag.
1 Press the dust compartment lid release
›
and lift the cover.
2 Remove the dustbag holder, unclip the
dustbag and dispose.
3 Insert the new dustbag into the dustbag
holder ensuring it is firmly secured and the
folds of the bag are opened out.
4 Replace the holder and dustbag within the
dustbag compartment and close the lid.
IMPORTANT: Do not operate your cleaner
without a dustbag fitted.
7831 Compact ib 06/02/2002 2:20 PM Page 6
