Essentials bagless vacuum cleaner
Please read and keep these instructions
VC73206 MUK Rev 2
For replacement parts, help with using your Morphy Richards product,
problems and lots more, contact us by phone or through our website.
UUKK HHeellpplliinnee:: 00884444 887711 00994499
RReeppllaacceemmeenntt PPaarrttss:: 00884444 887733 00771155
IIrreellaanndd HHeellpplliinnee:: 11880000 440099 111199
Getting the best from your new cleaner...
If your cleaner is not picking up as well as it should, please check
Filters
To maintain performance, it is very important to clean the pleated filter at
every emptying. The filter may also be washed but must be fully dry before
re-fitting. See page 5 for more details.
Blockages
Check nozzles, tubes and hose for blockages.
Safety cut-out
If the cleaner overheats, a motor protection thermostat will automatically
switch the cleaner off. If this happens, switch the cleaner off, unplug from
power supply and leave the cleaner to cool for at least 60 minutes. Check
the airways for blockages, empty dust canister and clean the filters before
restarting.
73206 rev2 11/6/08 09:53 Page 1
22
IMPORTANT
SAFETY
INSTRUCTIONS
The use of any electrical
appliance requires the
following common sense
safety rules.
Primarily there is danger of
injury or death and secondly
the danger of damage to the
appliance.
Please read these
instructions carefully before
using the appliance.
Location
• Do not use or keep this
product outside.
• Do not store the appliance
near hot surfaces eg. ovens
or heating appliances.
Mains lead
• Do not allow the mains lead
to become strained or run
this appliance over it.
• If the electrical cable
becomes damaged, the
cable assembly must be
replaced. Do not attempt this
task yourself, contact the
helpline number that is found
at the bottom of the page.
Personal safety
• WARNING: Keep loose
clothing, hair, fingers
etc. away from the
nozzle whenever the
cleaner is connected to
the mains.
• WARNING: Only lift and
carry the product by the
handle ›.
• Always disconnect from the
mains supply before
attempting to clear any
blockages.
• The plug must be removed
from the wall socket before
cleaning or maintaining the
appliance.
• Never use in the presence of
explosive liquid or vapours.
• Never pick up inflammable or
poisonous liquids such as
petrol, copier toner or other
volatile substances. Never
pick up acids, asbestos or
asbestos dust.
• Never touch the plug or
cable with wet hands.
• Unprofessional repairs can
be dangerous for users.
• The appliance must never be
left running unsupervised.
• This appliance is intended for
domestic use only. Misuse or
use for commercial or any
other purpose will render the
guarantee invalid.
• Always disconnect the
appliance from the mains
supply after use or prior to
emptying or cleaning.
• To protect against fire,
electric shock and personal
injury do not immerse cord,
plug or cleaner in water or
other liquid.
• This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
Product safety
• Never use the appliance
without the filters being
installed.
• Never use the appliance to
vacuum hot ashes, broken
glass, sharp objects or
liquids.
• Use only Morphy Richards
spare parts and accessories.
• Repairs to electrical
appliances are only to be
undertaken by trained
personnel. Unprofessional
repairs can be dangerous for
users.
• Never modify the cleaner in
any way.
Children
• Children do not understand
the dangers associated with
operating electrical
appliances. Never allow
children to use this
appliance.
• Children should be
supervised to ensure that
they do not play with the
appliance, or stumble over
the power cord.
ELECTRICAL
REQUIREMENTS
Check that the voltage on
the rating plate of your
appliance corresponds with
your house electricity supply
which must be A.C.
(Alternating Current).
If the socket outlets in your
home are not suitable for the
plug supplied with this
appliance, the plug should
be removed and the
appropriate one fitted.
If you cut off the plug and let
go of the cable, it will rewind
into the machine, therefore
you must pull out a length of
cable and secure it before
cutting the plug off and refitting a new one.
WARNING: The plug
removed from the mains
lead, if severed, must be
destroyed, as a plug with
a bared flexible cord is
hazardous if engaged
into a live socket outlet.
Should the fuse in the 13
amp plug require changing, a
13 amp BS1362 fuse must
be fitted.
UUKK HHeellpplliinnee 00884444 887711 00994499 RReeppllaacceemmeenntt PPaarrttss 00884444 887733 00771155 IIrreellaanndd HHeellpplliinnee 11880000 440099 111199
73206 rev2 11/6/08 09:53 Page 2
FEATURES
⁄ Dust canister release latch
¤ Eco Switch
‹ Cable rewind button
› Handle
fi Power on/off switch
fl Wheels
‡ Dust canister
· Hose inlet
‚ Hose connector with
release button
„ Storage hook
‰ Exhaust filter and cover
 Tube storage slot
(underneath product)
Ê Floor nozzle
Á Hose/handle with airflow
control
Ë Upholstery nozzle
È Crevice tool
Í Crevice tool brush
attachment
Î Tool storage clip
Ï Telescopic metal tube
Ì Filter assembly
Ó Pleated filter
Ô Mesh filter
Small cleaning brush
Ò Motor inlet filter
Ú Turbo nozzle
(certain models only)
Û Stair and hair tool
(certain models only)
‡
‰
Ê
33
Ó
Á
‚
⁄ ‹
›
fi
fl
·
Ë
Â
Ï
Î
Ì
Ô
Ò
„
Ú
¤
Û
È
Í
73206 rev2 11/6/08 09:53 Page 3
