MICROWAVE
OVEN
Installation & User Instructions –
Please keep for future reference
D90D23EL-B8(E17)
Version 3 3/6/2019
Contents
Safety Information…………………………………………….. 3
Installation……………………………………………………… 7
Parts and assembly…………………………………………… 8
Control panel…………………………………………………….. 9
Setting the clock………………………………………………. 10
Stop cooking / cancel………………………………………… 10
Control panel lock…..………………………………………… 11
Selecting microwave power level…………………………… 11
Microwave express mode……………………………………. 12
Microwave cooking…………………………………………… 13
Defrosting………………………………………………………… 14
Grill cooking……………………………………………………. 15
Combination cooking…………………………………………. 16
Auto cook…………………………………………………………. 17
Cleaning your oven…………………………………………… 20
Materials suitable for use in the oven……………………. 21
General microwave cooking advice………………………… 22
Troubleshooting…………………………………………….…… 23
Technical Specification………………………………………. 24
Recycling electrical products……………………………… 24
Plug rewiring…………………………………………………… 25
Guarantee……………………………………………………….. 26
Version 3 3/6/2019
2
Safety information
Important – Please read these instructions fully before
installation
• WARNING: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover that gives
protection against exposure to microwave energy. Servicing
of this appliance must only be carried out by a qualified
electrician.
• WARNING: If the door or door seals are damaged, the oven
must not be operated until it has been repaired by a
competent person. Do not operate this appliance if
damaged or modified in any way.
• Keep the appliance and its cord out of reach of children less
than 8 years.
• When operating in combination or grill modes, the oven
becomes extremely hot. Do not allow children to use the
appliance without adult supervision
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children unless they are aged from 8 years and above and
supervised.
• Switch off and unplug before cleaning or servicing the
appliance.
• Keep microwave, cable and plug dry and away from areas
where it is likely to get splashed. Never immerse in water.
Never clean with a steam cleaner.
• Do not pull on the cable to disconnect from the mains supply.
Version 3 3/6/2019
3
• This oven must be positioned so that the plug is accessible
and the plug socket is within easy reach of the power cord.
• Do not operate the microwave if damaged or after it
malfunctions. In the event the supply cord is damaged, it
must only be replaced by a qualified service engineer, with a
suitably approved part.
• Do not place items with naked flames or containers with
liquids on this appliance.
• The mains plug shall be connected into a mains socket outlet
with a protective earth connection.
• All microwaves are tested and approved in accordance with
current electromagnetic safety and compatibility regulations
and standards. As a precautionary measure, pacemaker
manufacturers recommend wearers to keep a minimum
distance of 20-30 cm between an operating microwave oven
and the pacemaker in order to avoid possible interference
with the pacemaker. If you suspect there may be interference,
turn the microwave off immediately and contact the
manufacturer of the pacemaker.
WARNING!
• This appliance is not intended to be used in: staff kitchen
areas in shops, offices and other working environments; farm
houses; by clients in hotels, motels and other residential
type environments; bed and breakfast type environments.
• This appliance must not be operated by a timer or a separate
remote control system.
• Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
• Microwave heating of beverages can result in delayed
eruptive boiling; therefore care must be taken when handling
the container.
• If you are preparing food or liquid for a baby stir or shake
the contents and check the temperature before consumption
in order to avoid burns.
Version 3 3/6/2019
4
WARNING! (continued)
• Never cook or heat eggs in their shell or whole hard boiled
eggs, as they may explode even after cooking in the
microwave has been completed.
• The oven should be cleaned regularly and any food deposits
removed – see page 20 for details. Failure to maintain the
oven and seals in a clean condition could lead to
deterioration of the surface or seals, adversely affect the life
of the oven and possibly result in a hazardous situation.
• Never operate the oven when empty and avoid leaving
unattended during use.
• Do not cover and allow adequate ventilation – see page 7 for
clearance required.
• The surfaces of the oven and the containers inside
will become hot during and immediately after use;
wear oven gloves when handling.
• Check regularly during cooking cycle especially when using
plastic or paper containers to ensure food and containers do
not ignite.
• If smoke is emitted, switch off or unplug the appliance and
keep the door closed in order to stifle any flames.
• Do not use oven on, near or under flammable or heat
sensitive items.
• Do not place foil wrapped food, metal containers or
containers with metal parts or trim when using the
microwave or combination oven.
• Do not use with a cracked or missing turntable or without
the turntable ring.
• The microwave oven is intended for heating food and
beverages. Drying of clothing and heating of warming
buttons, slippers, sponges, damp cloth and similar may lead
to risk of injury, ignition or fire.
• Always check for container and utensil suitability before
using in the microwave oven - see page 21 for advice.
Version 3 3/6/2019
5
FOOD SAFETY
• Do not cook raw meat or raw shellfish in a microwave, due
to the possibility for uneven heating.
• Do not use microwave for home canning or bottling.
Improperly canned or bottled foods may spoil and be
dangerous to eat.
• Always check the temperature of food before serving.
• Food cooking times will vary with microwave wattage (MAFF
rating). When following recipes and on pack cooking
instructions always check the MAFF rating / wattage of the
appliance being used (marked on the front of the microwave)
and follow the corresponding cooking advice.
Version 3 3/6/2019
6
Installation
• This microwave is designed to be free standing and is not
intended to be used ‘built in’ or in a cabinet.
• Select a level surface away from televisions, cookers and
other heat producing appliances.
• Ensure adequate ventilation and allow a clearance of
➢ 5cm at each side of the oven
➢ 20cm clearance above the oven
➢ 10cm at the rear of the oven
➢ The minimum installation height is 85cm
• Ensure that the cable is not close to any sharp or hot
surfaces, or where it is likely to cause a trip hazard.
Version 3 3/6/2019
7
Parts and assembly
1. Interlocking catches
2. Door with viewing panel
3. Turntable shaft
4. Turntable roller
5. Control panel
• Ensure all packaging materials, protective film and
adhesive tape are removed and check the oven and door for
any damage. Do not remove the waveguide cover.
• Assemble as shown above and ensure that the glass
turntable is correctly positioned on the shaft and roller.
• When using the microwave do not fit the grill rack.
• The grill rack may be used in grill and combination cooking
modes as required.
6. Waveguide cover
7. Glass turntable
8. Grill element
9. Grill rack
Version 3 3/6/2019
8
Control panel
Display
•
Display
Description
Symbol
Cooking
(High power
modes)
Cooking
(Low power
modes)
Control panel
locked
Function
knob
Defrost
Clock
Microwave
COMB1
COMB2
Time increments
Cooking time Increments
0 – 5 min 10 sec
5 – 10 min 30 sec
10 – 30 min 1 min
30 – 60 min 5 min
Grill
Combination
mode 1
Combination
mode 2
Data entry
required
Weight gram
Percentage
power
Fan only
operation
Version 3 3/6/2019
9
Setting the clock
1. Fully unwind the cable, plug in and switch on. The
microwave will emit a single bleep and the display will show
1:01.
2. Press the CLOCK button to select 12 hour time format.
Press the button again to select the 24 hour format.
3. When the time format of choice is displayed, turn the
FUNCTION knob until the correct hour is displayed.
4. Press the CLOCK button to save the setting and turn the
FUNCTION knob until the correct minute is displayed.
5. Press the CLOCK button again to save the setting and exit
the set up feature.
Notes:
• If the oven is unplugged or turned off at the mains the clock
setting will be lost.
• To check the time during oven operation, press the CLOCK
button and the time will display briefly before returning to
the countdown timer.
Stop cooking / Cancel
2.
• The oven can be stopped at any time by pressing the
STOP/CANCEL button or by opening the door.
• If the oven door is OPEN, press the STOP/CANCEL button
ONCE to clear all settings.
• If the oven door is CLOSED, press the STOP/CANCEL button
TWICE to clear all settings.
Version 3 3/6/2019
10
Control panel lock
Up
This function helps prevent accidental or unsupervised
operation of the oven by young children. The lock function is
activated automatically 1 minute after last user operation; the
padlock symbol will be shown in the display and the control
panel will now be inactive.
To deactivate the lock, simply open or close the door and the
padlock icon will extinguish in the display.
Selecting microwave oven power
The default on the microwave oven is set to cook at full power
unless otherwise changed. To select a lower power setting,
press the POWER button repeatedly before setting the cooking
time. The power selected will be shown in the display.
Display Power (%) Display Power (%)
100 % 100 (Full) 40% 40
80% 80 20% 20
60% 60 00% 00 (for timer use)
Version 3 3/6/2019
11
Express microwave mode
This function allows the microwave to be set quickly at set
increments.
1. Place the item to be cooked in a suitable microwave safe
container. Open the door and position the container in the
centre of the glass turntable. Securely close the microwave
door.
2. Press the START/ QUICK START button to cook on full power
for 30 seconds. Each successive press will increase the
cooking time by 30 or 60 seconds which depending on the
length of cooking time required.
3. The microwave will automatically start a few seconds after
the last button press and the timer will start to count down.
Version 3 3/6/2019
12
Microwave cooking
1. Place the food to be cooked in a suitable microwave safe
container and cover.
2. Pull open the door, place the container in the centre of the
glass turntable and securely close the oven door.
3. Press the POWER button and turn the FUNCTION knob until
the required cooking time is displayed (10 seconds to 60
minutes). Please note that the increments that the timer
increases varies depending on the length of cooking time
required (see ‘Time increment’ table) For example, when
choosing a cooking time between 0 and 5 minutes the timer
will increase in increments of 10 seconds.
4. Press the START / QUICK START button to select.
5. The microwave will start to cook and the timer will start to
count down
6. Cooking can be interrupted to stir contents or check
cooking progress by opening the door. Settings will be
retained and cooking will restart when the door is closed
and the START / QUICK START button is pressed.
7. After the cooking time has finished, the display will show
‘End’, the microwave will turn off automatically and three
bleeps will sound every two minutes until the oven door is
opened or any
8. Allow food to stand for 30 seconds to one minute before
stirring or serving.
9. The oven can be stopped at any time by pressing the
STOP/CANCEL button or by opening the door.
STOP/CANCEL
button is pressed.
Version 3 3/6/2019
13
Defrosting
1.
1. Weigh the item to be defrosted, place in a suitable
microwave safe container and position in the centre of the
glass turntable. Securely close the microwave door.
2. Turn the FUNCTION knob until 100g and the defrost symbol
is shown in the display.
3. Continue to turn the FUNCTION knob until the weight (100 -
1800g) of the item to be defrosted is shown.
4. Press the START / QUICK START button, the defrost time
will be calculated automatically and the microwave will start
to defrost and the timer will count down.
5. Two thirds through the defrost program a two bleeps will be
heard, defrosting will pause and food should rearranged or
turned over. Settings will be retained and defrosting will
restart when the door is closed and the START / QUICK
START button is pressed.
6. After the defrosting time has finished, the display will show
‘End’, the microwave will turn off automatically and three
bleeps will sound every two minutes until the oven door is
opened or the STOP/CANCEL button is pressed.
Version 3 3/6/2019
14
Grill cooking
1. Place the food to be cooked in a suitable grill safe container.
Pull open the door and place the container in the centre of
the glass turntable or alternatively place the food directly on
the grill rack with a grill safe collecting tray beneath.
2. Securely close the oven door.
3. Press the GRILL button and turn the FUNCTION knob until
the required cooking time is displayed (10 seconds to 60
minutes). Please note that the increments that the timer
increases varies depending on the length of cooking time
required (see ‘Time increment’ table) For example, when
choosing a cooking time between 1 and 5 minutes the timer
will increase in increments of 10 seconds.
4. Press the START / QUICK START button to select.
5. The grill will start to cook and the timer will start to count
down.
6. Grilling can be interrupted to turn the food over or to check
on progress by opening the door. Close the door and press
START/ QUICK START button to resume grilling.
7. After the grilling time has finished, the display will show
‘End’, the grill will turn off automatically and three bleeps
will sound every two minutes until the oven door is opened
or STOP/CANCEL button is pressed.
8. The oven can be stopped at any time by pressing the
STOP/CANCEL button or by opening the door.
Version 3 3/6/2019
15
Combination cooking
This function combines both cooking methods and two preset
programmes are available. Approximate cooking times for each
programs are as follows.
• Combi. 1 – 30% of cooking time is by microwave and 70% by
grill
• Combi. 2 – 55% of cooking time is by microwave and 45% by
grill
1. Place the food to be cooked in a suitable microwave and grill
safe container. Pull open the door and place the container
in the centre of the oven or alternatively place the food
directly on the grill rack with a microwave and grill safe
collecting tray beneath.
2. Press the COMBI button of choice (see above) and turn the
FUNCTION knob until the required cooking time is displayed
(10 seconds to 60 mins). Please note that the increments
that the timer increases varies depending on the length of
cooking time required (see ‘Time increment’ table) For
example, when choosing a cooking time between 1 and 5
minutes the timer will increase in increments of 10 seconds.
3. Press the START / QUICK START button to select.
4. The oven will start to cook and the timer will start to count
down.
5. After the cooking time has finished, the display will show
‘End’, the oven will turn off automatically and three bleeps
will sound every two minutes until the oven door is opened or
STOP/CANCEL button is pressed.
6. Cooking can be interrupted to turn the food over or to check
on progress by opening the door. Close the door and press
START/ QUICK START button to resume cooking.
7. The oven can be stopped at any time by pressing the
STOP/CANCEL button or by opening the door.
Version 3 3/6/2019
16
Auto cook function
The oven has a pre-programmed cooking menu that can be
used immediately from start up just by turning the FUNCTION
knob clockwise.
1. After checking the cooking method used in the table
following, place the item to be cooked in a suitable
container.
2. Open the door and place the container in the centre of the
glass turntable and securely close the oven door.
3. Turn the FUNCTION knob and select the required auto
cooking programme of choice (see table below).
4. Press the WEI.ADJ. button repeatedly until the
corresponding food weight / quantity is displayed and press
the START / QUICK START button.
5. The oven will start to cook and the timer will start to count
down from the preset time.
6. Cooking can be interrupted to stir contents or check
cooking progress by opening the door. Settings will be
retained and cooking will restart when the door is closed
and the START / QUICK START button is pressed.
7. After the cooking time has finished, four bleeps will sound.
8. Allow food to stand for 30 seconds to one minute before
stirring or serving.
9. The oven can be stopped at any time by pressing the
STOP/CANCEL button or by opening the door. Pressing the
STOP/CANCEL button once (with the door closed) will stop
the cooking, pressing the button twice will clear the
settings.
Note:
• Auto cook programs 7, 8 & 9 pause part way through cooking
as a reminder to turn food over. Open the door, turn the
food over and press the START / QUICK START button to
continue cooking.
Version 3 3/6/2019
17
Display Food
1 Milk /
coffee
Weight /
quantity
1 (200ml)
2 (400ml)
3 (600ml)
2 Rice 150g
3 Spaghetti 100g
4 Potato 1 (230g)
2 (460g)
3 (690g)
5 Auto
Reheat
6 Fish 200g
300g
450g
600g
200g
300g
200g
300g
400g
500g
600g
700g
800g
300g
400g
500g
600g
Instructions
Heating liquid from 5-10°C.
Use wide neck cup / mug
and do not cover.
Place rice in a bowl with five
times the quantity (unless
another quantity specified by
food packaging) of boiling
water and cover.
Place pasta in a bowl with
eight times the quantity of
water and cover.
If using pasta with longer
cooking times (e.g. fusilli)
additional cooking may be
required.
For best result, use potatoes
at room temperature and
once the potatoes are
cooked, wrap them in tin foil
for at least 5 minutes to cook
through. Larger or cold
potatoes may need
additional cooking.
Place food in a bowl and
cover. Check that food is
heated throughout before
serving.
Place food in a bowl and
cover.
Check that fish is cooked
through before consuming.
Version 3 3/6/2019
18
7 Chicken 800g
1000g
1200g
1400g
8
Beef/
Mutton
200g
300g
400g
500g
600g
9 Skewered
meat
100g
200g
300g
400g
500g
Cooks by combination mode
Turn chicken over two thirds of
the way through the cooking
cycle when the bleep is heard.
The cooking times are guidelines
only – check that chicken is
cooked through before
consuming.
Cooks by combination mode
For even cooking, cut meat into
small equally sized pieces and
place onto a microwave safe
plate. Turn meat over two thirds
of the way through the cooking
cycle when the bleep is heard.
The cooking times are guidelines
only – check that meat is cooked
through before consuming.
Cooks by combination mode
For even cooking, cut meat into
small equally sized pieces and
place on a non-metallic skewer
and a microwave and grill safe
plate. Turn meat over two thirds
of the way through the cooking
cycle when the bleep is heard.
The cooking times are guidelines
only – check that meat is cooked
through before consuming.
Version 3 3/6/2019
19
Cleaning
Clean the oven and seals to remove food debris on a weekly
basis and more often if required. Failure to maintain the oven
and seals in a clean condition could lead to deterioration of the
surface or seals, adversely affect the life of the oven and
possibly result in a hazardous situation (possible release of
microwave energy).
Clean the oven after each use, if food is cooked uncovered and
especially if fatty foods are cooked and the grill function is used.
1. Switch off, unplug the oven and allow the oven to cool
completely.
2. Wipe surfaces and seals with a soft damp cloth (not wet).
Do not use abrasive cleaning products or metal scrapers to
clean the glass door of the oven as this could damage the
surface and cause breakage. Do not immerse in water. Do
not use a steam cleaner.
3. The grill rack, glass turntable and turntable roller can be
washed in hot water with a little washing up liquid. NOT
SUITABLE FOR DISHWASHERS.
4. Always allow surfaces to fully dry before using the oven
again.
Version 3 3/6/2019
20
Materials suitable for use in the oven
5.
Material Suitability for use in
Microwave Grill Combination
Glassware Heat resistant
only
Ceramic ware Heat resistant
only
Plastic
containers
Not melamine
Microwave safe
only
Avoid using
Heat resistant
only
Heat resistant
only
No No
Heat resistant
only
Heat resistant
only
with food with
high fat or
sugar contents
Plastic film Microwave safe
No No
only
Kitchen paper Only for
No No
reheating do
not leave
unattended
Metal tray or
No Yes Yes
rack
Aluminium
No No No
foil & foil
containers
Browning
dishes
Place upturned
plate on the
No No
glass turntable
(to prevent
heat stress)
before using
DO NOT use metallic containers for food and beverages,
aluminium foil, or any other metal trimmed packaging when
operating in microwave or combination modes. The metal rack
is suitable for use in grill and combination modes.
Version 3 3/6/2019
21
General microwave cooking advice
• Food cooking times will vary with microwave wattage (MAFF
rating). When following recipes and on pack cooking
instructions always check the MAFF rating / wattage of the
appliance being used (marked on the front of the microwave)
and follow the corresponding cooking advice.
• Beverages can result in delayed eruptive boiling; therefore
care must be taken when handling the container.
• Remove lids from containers before placing in the microwave,
pierce plastic films and do not use vessels with sealed or
restricted openings since they are liable to explode.
• Pierce the skin or membranes of food (e.g. potatoes, apples,
fish, chicken, eggs) in several places before cooking. Never
cook or heat eggs in their shell or whole hard boiled eggs, as
they may explode even after cooking has been completed.
• Ensure food is similar size and density. Large dense items
take longer to cook than small ones e.g. potatoes take longer
to cook than peas.
• Food quantity will affect the cooking time, e.g. two potatoes
take longer than one.
• The shape of food will affect the cooking time; place the
thickest part of food on the outside of the plate.
• Leave food to stand for a short period after cooking or
defrosting to allow the temperature to become uniform.
Version 3 3/6/2019
22
Troubleshooting
Observation Potential cause / solution
Oven will not
start
Arcing or
sparking
Unevenly
cooked food
Overcooked
food
Undercooked
food
Incomplete
defrosting
Noisy
turntable
Oven light
does not
illuminate
Plug not fully inserted into the mains socket or
not switched on
Door is open
Incorrect operation
Do you have a power cut?
Unsuitable materials used when using
microwave function.
Oven is operated when empty
Spilled food remains in oven cavity
Unsuitable materials used when using
microwave.
Food not fully defrosted before cooking
Power setting for cooking time is incorrect
Food was not turned or stirred during cooking
Uneven sized food
Power setting for cooking time is incorrect
Cooking period set too long
Food not fully defrosted before cooking
Unsuitable materials used when using microwave
Ventilation ports restricted
Power setting for cooking time is incorrect
Unsuitable materials used when defrosting
Defrost time too short
Food was not turned or stirred during defrosting
Uneven sized food
Food residue between turntable roller and base
of cavity
Glass turntable not correctly positioned on roller
Bulb has burnt out
Start button not been pressed
Version 3 3/6/2019
23
Technical specification
Morphy Richards 23 Litre 900W Microwave With Grill
Model D90D23EL-B8(E17)
Rated Voltage & Frequency 230 - 240V AC 50Hz
Rated Power Output 900W
Rated Power
Input
MAFF rating E
Rated Microwave Frequency 2450MHz
Capacity Overall 23 litre
Class rating 1 (earthed)
BS 1362 fuse 13A
Diameter of glass turntable 270mm
Product dimensions (external) 281 x 483 x 395 mm
Product weight (net) 14.1 kg approx.
This appliance complies with European regulation no. 1935/2004 of 27/10/2004 on food
contact materials. The product is classified as a Group 2, Class B, ISM appliance.
Group 2 includes all ISM (Industrial, Scientific or Medical) appliances in which radio
frequencies are generated intentionally and/or used in the form of electromagnetic
radiation to treat materials, together with electroerosion equipment. Class B includes
equipment for domestic use or on premises directly connected to low voltage electricity
supply for supplying buildings for residential use.
Microwave 1400W
Grill 1000W
Useable 16 litre
Recycling electrical products
You should now recycle your waste electrical goods and
in doing so help the environment.
This symbol means an electrical product should not be
disposed of with normal household waste. Please
ensure it is taken to a suitable facility for disposal when
finished with.
Visit www.recycle-more.co.uk, click on “bank locator”
and enter your postcode to find your nearest recycling
site.
Version 3 3/6/2019
24
Plug rewiring advice
The wires in this mains lead are coloured in accordance with the
following UK electrical code: BLUE = NEUTRAL
BROWN = LIVE
GREEN + YELLOW = EARTH
Non-rewireable plug
This appliance may be fitted with a “non‐rewireable” plug. If you
need to change the fuse in a “non‐rewireable” plug, the fuse
cover must be refitted. If the fuse cover is lost or damaged, the
appliance must not be used.
Rewireable plug
The colours of the wires in the mains lead of this appliance may
not correspond with the coloured markings identifying the
terminals in a rewireable plug. Rewireable plugs should only
be replaced by a suitably competent person. If in doubt,
consult a qualified electrician.
The BLUE wire must be connected to the
terminal marked with the letter N
The BROWN wire must be connected to
the terminal marked with the letter L
The GREEN & YELLOW wire must be
connecting to the terminal marked with
the letter E or the earth symbol .
Imported by Argos Ltd, MK9 2NW
If you require assistance, please call the Sainsbury’s Argos helpline
on 0345 604 0105
Your statutory rights are not affected.
Made in China. All brand names are registered trademarks of their
respective owners.
Version 3 3/6/2019
25
Version 3 3/6/2019
26
Loading...
