Morphy Richards Compact breadmaker User Manual

TTwwoo yyeeaarr gguuaarraanntteeee

This guarantee is valid in the UK and Ireland only. It is in your interest to retain the retailers receipt as proof of purchase. Please quote the following information if the product develops a fault. These numbers can be found on the base of the product.

Model No. Serial No.

All Morphy Richards Products are individually tested before leaving the factory. In the unlikely event of any appliance proving to be faulty within 28 days of purchase it should be returned to the place of purchase for it to be replaced.

If the fault develops after 28 days and within 24 months of original purchase, you should contact the helpline number quoting Model number and Serial number on the product, or write to the address below. You will be asked to return the product (in secure, adequate packaging) to the address below along with a copy of proof of purchase. Subject to the exclusions set out below (see ‘Exclusions’) the faulty appliance will then be repaired or replaced and dispatched usually within 7 working days of receipt.

If for any reason this item is replaced during the 2 year guarantee period, the guarantee on the new item will be calculated from original purchase date. Therefore it is vital to retain your original till receipt or invoice to indicate the date of initial purchase.

To qualify for the 2 year guarantee the appliance must have been used according to the manufacturers instructions. For example kettles should have been regularly descaled or an iron cord should have been stored as recommended by the instructions.

EExxcclluussiioonnss

Morphy Richards shall not be liable to replace or repair the goods under the terms of the Guarantee where: 1 The fault has been caused or is attributable to accidental use,

mis-use, negligent use or used contrary to the manufacturers

recommendations or where the fault has been caused by power

surges or damage caused in transit. 2 The appliance has been used on a voltage supply other than

that stamped on the products. 3 Repairs have been attempted by persons other than our service

staff (or authorised dealer). 4 Where the appliance has been used for hire purposes or non-

domestic use. 5 Morphy Richards are not liable to carry out any type of servicing

work, under the guarantee. 6 Plastic filters for all Morphy Richards kettles and coffee makers

are not covered by the guarantee.

This guarantee does not confer any rights other than those expressly set out above and does not cover any claims for consequential loss or damage. This guarantee is offered as an additional beneﬁt and does not affect your statutory rights as a consumer.

The After Sales Division, Morphy Richards Ltd, Mexborough, South Yorkshire, England, S64 8AJ Helpline (office hours): UK (local rate) 08450 777700, Republic of Ireland 1800 409119

CCoommppaacctt

bbrreeaaddmmaakkeerr

Please read and save these instructions

IIMMPPOORRTTAANNTT SSAAFFEEGGUUAARRDDSS

WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED,

INCLUDING THE FOLLOWING:

Read all instructions carefully.

Do not touch hot surfaces. Use oven mitts or oven gloves when removing the hot bread pan. Do not cover the steam vent openings under any circumstances.

To protect against electrical shock, do not immerse cord or plug in water or other liquid.

Close supervision is necessary when any appliance is used near children.

Unplug the power supply cord when the appliance is not in use, or before cleaning. Allow to cool before putting on or taking off any parts, and before cleaning the appliance.

If the mains lead of this appliance is damaged do not use it. The lead may only be replaced by Morphy Richards Ltd or an agent of the company, since special purpose tools are required. Telephone Morphy Richards helpline for advice.

The use of accessory attachments not recommended by the manufacturer may cause damage to the breadmaker.

Do not use outdoors.

Do not let the power supply cord hang over the edge of table or counter, or touch hot surfaces.

Do not place the appliance on or near heat sources such as gas or electric stove ovens, or burners.

Extreme caution must be given when moving an appliance containing hot contents or liquids.

To disconnect, press and hold STOP, then switch socket off and remove plug from wall socket. Never pull on the cord.

Do not use the breadmaker for other than intended use.

Avoid contact with moving parts.

Put ingredients into the baking pan, then fit the baking pan into the breadmaker. The baking pan must be in place prior to switching on the appliance.

Do not operate this appliance in the presence of explosive and/or flammable fumes.

This appliance is intended for household use only and not for commercial or industrial use.

To avoid damaging the machine, do not place the baking pan or any object on top of the unit.

Do not clean with scouring pads. Do not wash the baking pan, kneading blade measuring cup or spoon in a dishwasher. Refer to ‘Cleaning’ section of this book.

Do not use breadmaker for storage purposes nor insert any utensils, as they may create a fire or electric shock.

SAVE THESE INSTRUCTIONS

CCoonntteennttss

OOppeerraattiinngg iinnssttrruuccttiioonnss

Important safeguards 2 Electrical requirements 3 Before first use 3 Components 4 Control panels settings and functions 5 How to use your breadmaker 6 Slicing and storing bread 6 Care and cleaning 7 Knowing your ingredients 8 Measuring your ingredients 9 Other tips 10

RReecciippeess

Basic white bread 11 French bread 11 Standard brown bread 11 Granary malted wheat bread 11 Wholemeal with vitamin C bread 11 Italian herb bread 11 Sundried tomato bread 12 Sundried tomato with mixed herbs bread 12 Onion bread 12 Chocolate and walnut bread 12 Cinnamon and raisin bread 12 Mixed spice and raisin bread 12

Troubleshooting 13

EElleeccttrriiccaall rreeqquuiirreemmeennttss

Check that the voltage on the rating plate of your appliance corresponds with your house electricity supply which must be A.C. (Alternating Current).

If the socket outlets in your home are not suitable for the plug supplied with this appliance, the plug should be removed and the appropriate one fitted.

Note: The plug removed from the mains lead, if

severed, must be destroyed as a plug with bared flexible cord is hazardous if engaged into a live socket outlet.

WARNING: THIS APPLIANCE MUST BE EARTHED.

Should the fuse in the 13 amp plug require

changing a 13 amp BS1362 fuse must be fitted.

BBeeffoorree ffiirrsstt uussee

Enjoy using your Morphy Richards Breadmaker.

Before first use, please take a few minutes to read this instruction book and to find a place to keep it handy for reference.

Pay particular attention to the safety instructions we have provided for your protection.

Carefully unpack the breadmaker and remove all packaging materials. To remove any dust that may have accumulated during packing, wash inside of pan and kneading blade with hot soapy water and a soft cloth, rinse and dry. The kneading blade lifts off the shaft in the bottom of the pan and may be needed to be twisted slightly to remove.

Do not immerse bread pan in water or wash in automatic dishwasher as damage to bearing that turns the kneading blade can occur.

Wipe inside of chamber and outside surfaces of machine with a soft damp cloth if necessary, dry with a soft cloth.

Do not immerse bottom of bread pan in water.

Bar

CCoommppoonneennttss

Kneading blade

Wire handle

Baking pan

Rotating shaft

Start/stop button

Lid

Viewing window

Main body

Inner case

Select button

Control panel

Pan base

CCoonnttrrooll ppaanneell sseettttiinnggss && ffuunnccttiioonnss

BBrreeaadd sseelleecctt bbuuttttoonn

The bread select button lets you choose between two bread settings - brown and white. With each press of the bread select button, the light will alternate between the two bread settings.

The white setting can be used for almost any bread recipe containing mostly bread flour. If a recipe contains up to 50% whole wheat flour, use the brown setting.

SSttaarrtt//ssttoopp bbuuttttoonn

Use the start/stop button to turn the breadmaker on and off. Before starting the machine, you must program the bread select setting required. Then press start/stop button once to turn machine on.

When the machine in on, the green ‘operation’ light will glow. When baking is complete, light will change to red to let you know machine is in ‘keep warm‘ mode for one hour. An alert will also sound when baking is complete. Turn off by pressing and holding start/stop until the alert sounds and the ‘keep warm‘ light goes out. If the breadmaker is not turned off after completion of the one hour ‘keep warm’ period, the breadmaker will automatically turn itself off.
