Instruction
manual
Please read and keep these
instructions for future use
KT108001 MUK REV1
Health & Safety
The use of any electrical appliance requires the following common sense safety rules.
Please read these instructions carefully before using the product.
• This appliance can be used by children aged from 8 years
and above if they have been given supervision or instruction
concerning the use of the appliance in a safe way and
understand the hazards involved. Cleaning and user
maintenance shall not be made by children unl ess they are
older than 8 years and supervised. Keep the appliance and its
cord out of reach of children aged less than 8 years.
• Children shall not play with the appliance.
• Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved.
• If the mains cable is damaged, it must be replaced by the
manufacturer, it’s service agent or similarly qualified person in
order to avoid a hazard.
• WARNING: Do not open the lid whilst the water is boiling.
• This appliance is intended to be used in household and
similar applications such as: farm houses, by clients in hotels,
motels and other residential type environments, and bed
and breakfast type environments. It is not suitable for use
in staff kitchen areas in shops, offices and other working
environments.
2
Location
• Always locate your appliance away from the edge of the worktop.
• Ensure that the appliance is used on a firm, flat surface.
• Do not use the appliance outdoors or near water.
• WARNING: Do not place the appliance onto a metal tray or metal surface whilst in use.
Mains cable
• Do not let the mains cable hang over the edge of the worktop where a child could reach it.
• Do not let the mains cable run across an open space e.g. between a low socket and a table.
• Do not let the mains cable run across a cooker or other hot area which might damage the cable.
• The mains cable should reach from the socket to the base unit without straining the connections.
Personal safety
• Always keep the top of the cordless base dry, especially around the connection area, disconnect
the power supply before drying. Allow to dry thoroughly before reconnection to the power supply.
• Do not fill above the MAX mark, otherwise boiling water may be ejected.
• Always pour hot water slowly and carefully without tipping the appliance too fast to prevent
splashing and spillage.
• Do not hold the switch in the on position or tamper with the switch to fix it in the on position as this
may cause damage to the switch-off mechanism.
• Do not move the kettle while switched on.
• WARNING: Misuse of the appliance could cause personal injury.
Other safety considerations
• The use of attachments or tools not recommended or sold by Morphy Richards,
may cause fire, electric shock or injury.
• The kettle is only to be used with the stand provided.
• Do not use the appliance for any use other than to boil water.
• The appliance must not be on the base unit when being filled with water.
• Unplug from the outlet when not in use.
• WARNING: The appliance must not be immersed for cleaning.
• WARNING: When boiled, allow a few seconds before pouring.
Electrical requirements
• Check that the voltage on the rating plate of your appliance corresponds with your house electricity
supply which must be A.C. (Alternating Current). Should the fuse in the mains plug require
changing, a 13 amp BS1362 fuse must be fitted. WARNING: This appliance must be earthed.
4
... the premium, highly innovative Morphy Richards product group.
Driven by principles of innovation and providing exceptional quality, the
Redefine range is designed to fulfil the consumer need for brilliantly performing
products that have equal aesthetic consideration.
this is where the similarity ends
this is where the exceptional begins
6
1
1
2
2
3
5
6
7
8
9
10
4
11
12
13
14
15
1 Ring Pull
A soft touch ergonomic ring pull for easy removal of the lid when filling your glass Kettle.
2 Lid
A unique design that allows water to flow through for a perfect pour.
3 Limescale Filter
Catches any scale and ensures your drink looks as good as it tastes.
4 Spout
Sleek design for a perfect pour.
5 Handle
Ergonomically designed handle for easy grip.
6 Glass Body
Duran Schott® glass makes it easy to see how much water is inside the kettle
and illuminates when boiling water.
7 Cordless Base
Your kettle can be lifted away from the base for easy filling or pouring without any
leads getting in the way.
8 360º Connector
Your Kettle can easily be placed back on the connector on the base from any angle.
Ideal for the right or left handed use.
9 On/Off/Cancel Icon
Touch icon to activate or deactivate kettle from standby mode or cancel current boiling cycle.
10 Select 75ºC Temperature
Touch icon to heat water to 75ºC.
11 Select 85ºC Temperature
Touch icon to heat water to 85ºC.
12 Select 95ºC Temperature
Touch icon to heat water to 95ºC.
13 Select 100ºC Temperature
Touch icon to heat water to 100ºC.
14 Indicator Lights
Flash when water is heating and remain illuminated when desired temperature is reached.
15 Cord Storage
Helps to keep your kitchen worktop neat and tidy.
8
1
Remove the Lid (2), by pulling the ring pull to one
side and lifting upwards. Fill your kettle with the
desired amount of water.
2
Replace the Lid. The bevelled arrow on the Lid
points forward towards the Spout (4). Ensure the
Lid is secured correctly into place before use.
Using your
kettle
Before using your kettle, or if it has not been used for over a week,
follow these instructions to boil the maximum amount of water, then
discard to ensure the system is clean and ready for use.
The following instructions detail the steps to follow to use your kettle. For cancelling/changing
the selected temperature function, switching the kettle off and cleaning instructions,
see the following pages.
When plugging your kettle in at the socket for the first time, it will beep twice and the indicator lights
(14) will all flash briefly. The lights will then dim indicating that the kettle is in standby mode and
ready to use.
5
Select the desired temperature by placing your
finger across one of the temperature icons for 2
seconds. All indicator lights (14) will dim except the
temperature selected. The selected icon will begin
to flash until the temperature is reached. The
kettle glass body (6) will also illuminate.
6
Whe the desired temperature is reached, the
indicator light (14) will stop flashing and remain
illuminated and the glass body (6) will dim. Allow
a few seconds before pouring into a vessel.
CAUTION: HOT.
3
Place your Kettle onto the 360º Connector (8) on
the Cordless Base (7). 4
Tap the on/off Icon (9) to exit standby mode. All
indicator lights (14) will illuminate.
1
To switch the kettle on, follow steps 1-5 on page 8.
3
All temperature icons are now available for
reselection. Touch the new temperature icon that
you would like to select and boiling will begin as
normal.
2
If you decide to cancel the current cycle, touch the
same temperature icon again for 2 seconds, or
tap the on/off/cancel icon (9). All indicator lights
(14) will illuminate and the current cycle will be
cancelled.
4
If you do not reselect a new temperature after
30 seconds all indicator lights (14) will
automatically dim indicating stand by mode.
Cancelling/changing selected
temperature function
Switching your kettle off/into standby
• When all indicator lights (14) on your kettle base are dim, your kettle is in standby mode.
• When all indicator lights (14) on your kettle base are illuminated, your kettle is on. You can switch your kettle
into standby mode by touching the on/off/cancel icon (9). All lights will then dim, indicating standby mode.
• To switch the kettle off completely, turn off at the socket.
10
Care & Cleaning
WARNING: Always disconnect the plug from the mains
and allow your kettle to cool before cleaning.
Wipe the outside with a damp cloth.
IMPORTANT: Do not use abrasive cleaners on the
outside of the kettle as this may scratch the surface.
Descaling
IMPORTANT: As this appliance is fitted with a concealed
element it must be descaled regularly. The frequency
of descaling depends on usage and the hardness of
the water in your area.
Excessive scale can cause the appliance to switch off
before boiling and may damage the element
invalidating the warranty. It is essential that regular
descaling takes place. We recommend descaling your
kettle every month.
Use a proprietary descaling product suitable for
stainless steel, glass or plastic. Please follow the
instructions on the packet carefully.
Cleaning the Filter
1 Boil 750ml of water in the kettle, empty into a
suitable container then slowly add the descaler
sachet as instructed.
2 Place the lid into the solution so the filter is fully
submerged.
3 Leave for 10 minutes then remove and thoroughly
swill the filter under a running tap.
4 Dry and re-fit to the kettle body.
4 Re-boil the kettle and pour the water away through
the lid/filter.
5 Your kettle is now ready for use.
Contact Us
Helpline
If you are having a problem with your appliance,
please call our Helpline, as we are more likely to be
able to help than the store you purchased the item
from. Please have the product name, model number
and serial number to hand when you call to help us
deal with your enquiry quicker.
UK Helpline 0344 871 0945
EIRE Helpline 1800 409 119
Spares 0344 871 0945
Talk To Us
If you have any questions or comments, or want some
great tips or recipe ideas to help you get the most out
of your products, join us online:
Blog www.morphyrichards.co.uk/blog
Facebook facebook.com/morphyrichardsuk
Twitter @loveyourmorphy
Website www.morphyrichards.com
Registering your 2 year guarantee
Your standard one year guarantee is extended for an
additional 12 months when you register the product within 28
days of purchase with Morphy Richards. If you do not register
the product with Morphy Richards within 28 days, your product
is guaranteed for 1 year. To validate your 2 year guarantee
register with us online at
www.morphyrichards.co.uk
Or call our customer registration line quoting model
and serial number, these numbers can be found on
the base of your product.
UK 0344 871 0945
IRE 1800 409 119
N.B. Each qualifying product needs to be registered
with Morphy Richards individually. Please note that
the 2 year guarantee is only available in the UK and
Ireland. Please refer to the one year guarantee for
more information.
Your 1 year guarantee
It is important to retain the retailer’s receipt as proof of
purchase. Staple your receipt to this back cover for future
reference.
Please quote the following information if the product
develops a fault. These numbers can be found on the base of
the product.
Model no, Serial no.
All Morphy Richards products are individually tested before
leaving the factory. In the unlikely event of any appliance
proving to be faulty within 28 days of purchase, it should be
returned to the place of purchase for it to be replaced.
If the fault develops after 28 days and within 12 months of
original purchase, you should contact the Helpline number
quoting Model number and Serial number on the product, or
write to Morphy Richards at the address shown.
You may be asked to return a copy of proof of purchase.
Subject to the exclusions set out below (see Exclusions), the
faulty appliance will then be repaired or replaced as
appropriate and dispatched usually within 7 working days of
receipt.
If, for any reason, this item is replaced or repaired during the 1
year guarantee period, the guarantee on the new item will be
calculated from original purchase date.
Therefore it is vital to retain your original retailers receipt or
invoice to indicate the date of initial purchase. To qualify for the
1 year guarantee, the appliance must have been used
according to the instructions supplied. For example, crumb
trays should have been emptied regularly.
Exclusions
Morphy Richards shall not be liable to replace or repair the
goods under the terms of the guarantee where:
1 The fault has been caused or is attributable to accidental
use, misuse, negligent use or used contrary to the
manufacturer’s recommendations or where the fault has
been caused by power surges or damage caused in transit.
2 The appliance has been used on a voltage supply other
than that stamped on the products.
3 Repairs have been attempted by persons other than our
service staff (or authorised dealer).
4 The appliance has been used for hire purposes or non
domestic use.
5 The appliance is second hand.
6 Morphy Richards reserves the right not to carry out any type
of servicing under the guarantee at its discretion.
7 Plastic filters for all Morphy Richards kettles and coffee
makers are not covered by the guarantee.
8 Batteries and damage from leakage are not covered by the
guarantee.
This guarantee does not confer any rights other than those
expressly set out above and does not cover any claims for
consequential loss or damage. This guarantee is offered as an
additional benefit and does not affect your statutory rights
as a consumer. Morphy Richards products are intended for
household use only. See usage limitations within the location
safety instructions.
Disclaimer
Morphy Richards has a policy of continuous improvement in
product quality and design. The company, therefore reserves the
right to change the specification of its models at any time.
For electrical products sold within the European
Community. At the end of the electrical products useful life, it should
not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority
or retailer for recycling advice in your
country.
IF YOU ARE HAVING A PROBLEM
WITH ONE OF OUR PRODUCTS,
CALL OUR HELPLINE:
UK: 0344 871 0945
EIRE: 1800 409 119
SPARES: 0344 871 0945
12
The After Sales Division, Morphy Richards Ltd
Mexborough, South Yorkshire, S64 8AJ
UK: 0344 871 0945
EIRE: 1800 409 119
KT108001 MUK REV1 07/16
www.morphyrichards.co.uk/redefine
Loading...
