Installation and Operation Instructions
Before attempting to connect or operate this product, please
read these instructions completely.
RM7CF2N
Fixed Vandal Resistant, Recessed Ceiling Mounted Dome Camera Enclosure
RM7CF2.................... Outdoor 24Vac clear Vandal Resistant recessed housing for xed camera with heater / blower
RM7CF2N.................. Outdoor 24Vac clear Vandal Resistant recessed housing for xed network (12Vdc) camera with heater / blower
IRM7CF...................... Indoor clear Vandal Resistant recessed housing for xed camera
IRM7CF2N................. Indoor 24Vac clear Vandal Resistant recessed housing for xed network (12Vdc) camera with heater / blower
IRM7TF...................... Indoor tinted Vandal Resistant recessed housing for xed camera
RM7TF2N.................. Outdoor 24Vac tinted Vandal Resistant recessed housing for xed network (12Vdc) camera with heater / blower
IRM7CF2....................Indoor 24Vac clear Vandal Resistant recessed housing for xed camera with heater / blower
Substitute “C” (Clear dome) for “T” (Tinted dome) version
