Vocal Multi-Effects Processor
Contents
Precautions
Main Features
Battery Operation
Panel Instruction
Connections
Operation
Patch Selecting
Expression Pedal
Patch Editing
Patch Storing/Copying
Patch Pre-Select Recall Function
Vocoder Function
Loop Function
Factory Reset
Effects Explanation
Specification
...........................................................02
.................................................03Items Explanation
........................................................04
.................................................04
...................................................05
..........................................................07
.............................................................08
.............................................08
...........................................09
..................................................11
....................................13
..................14
.....................
...............................................16
...............................................18
..............................................19
.........................................................24
.....................15
Troubleshooting
Appendix
Patch List
...............................................................25
.......................................................26
...................................................25
01
Precautions
* PLEASE READ CAREFULLY BEFORE PROCEEDING *
Power Supply
Please connect the designated AC adapter to an AC outlet of the correct
voltage.
Please be sure to use only an AC adapter which supplies 9V DC, 300
mA, center minus.
Unplug the AC power adapter when not using or during electrical storms.
Connections
Always turn off the power of this and all other equipments before
connecting or disconnecting, this will help prevent malfunction and / or
damage to other devices. Also make sure to disconnect all connection
cables and the power cord before moving this unit.
Location
To avoid deformation, discoloration, or other serious damage, do not
expose this unit to the following conditions:
Direct sunlight
Heat sources
Magnetic fields
Extreme temperature or humidity
Excessive dusty or dirty location
High humidity or moisture
Strong vibration or shock
Interference with other electrical devices
Radios and televisions placed nearby may experience reception
interference. Operate this unit at a suitable distance from radios and
televisions.
Cleaning
Clean only with a soft, dry cloth. If necessary, slightly moisten the cloth.
Do not use abrasive cleanser, cleaning alcohol, paint thinners, wax,
solvents, cleaning fluids, or chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into this unit.
Take care not to drop the unit, and do not subject it to shock or excessive
pressure.
02
Items Explanation
Patch
A patch is comprised of information about the on/off status and effect
parameter settings used in each module.
Bank
A bank is a group of ten patches. VEM Box has 7 banks, labelled with
numbers 0 to 3 (unchangeable preset banks) and letters A to d
(editable user banks).
Effect module
A patch can be thought of as a combination of up to 8 single effects.
Each such effect is referred to as an effect module.
Effect type
Some effect modules have several different effects which are referred
to as effect types. Only one of these can be selected at a time.
Effect parameter
All effect modules have various parameters that can be adjusted.
These are called effect parameters or simply parameters. When
thinking of an effect module as a compact effect, the parameters
change the tone and effect intensity similar to the knobs on the device.
Mode
Mode is the status of different function of keys and controls, VEM Box
has Patch Mode for selecting and using patches, Loop Mode for
recording loop phrase, Edit Mode for modifying effects, and Store
Mode for saving patches.
03
Main Features
8 Effect Modules & 54 Effect Types
40 Preset Patches & 40 User Patches
Phrase Looper with 16 seconds of recording time
Vocoder Function
Assignable Expression Pedal
Patch Pre-Select function
Compact operation interface
Lightweight and tiny for easy transportation
AC adapter 9V DC power supply
AA/LR6 battery (x4) power supply
Battery Operation
1. Turn off the VEM Box and open the battery holder on the bottom.
2. Insert 4 AA/LR6 batteries and close the battery holder.
Press latch to release and then lift cover.
Latch
Note: When the batteries are getting low, the display will show to indicate this
situation.
Note: When using batteries, it is suggested to disconnect the microphone cable plug
from the [MIC IN] jack when not using the device, to conserve battery power.
Four batteries (size AA/LR6)
04
Panel Instruction
1 23 7
TR
PR
BANK PATCH
DATA EDIT
PATCH
BYPASS
HOLD FOR LOOP
4 5
VALUE
MODULE BYPASS
6
EXP. PEDAL
Press
05
DC9V INST.IN
13
INST.THRU
MIC IN
89 10
OUTPUT
[PHONES]
1112
Panel Instruction
01
Module Selector: Switches between every function module. In
patch edit mode, this knob selects the module/parameter for operation.
02
VALUE Knob with Enter Button: Dial the knob for setting master
level, or changing parameter values. Press the button to switch effect
type, ensure storing, etc.
03
LED Display: Shows bank and patch numbers, setting values, and
other information for operating.
04
PATCH [REC/OVERDUB] Footswitch: Selects patches
(backwards), start loop recording/overdubbing, and other functions.
05
PATCH + [MODULE BYPASS] Footswitch: Selects patches
(forwards), play/stop loop, bypass effect module, and other functions.
Expression Pedal: Adjusts volume or some effect parameters.
06
07
EXP. PEDAL LED: Indicates the status of the expression pedal.
08
MIC IN Jack: XLR + 1/4” TRS audio jack, for connecting
microphone. When operating VEM Box on batteries, plugging Mic
cable into this jack will turn on the unit.
09
INST. IN Jack: 1/4” mono audio jack, for connecting guitar or other
instruments.
OUTPUT [PHONES] Jack: 1/4” stereo audio jack, for connecting
10
headphone or amplifier. Using a mono cable can output the signal to
an amplifier, or use a Y cable to output the signal to two amplifiers.
Also can plug a stereo headphone into this jack.
11
INST. THRU Jack: 1/4” mono audio jack, output the signal directly
from INST.IN jack.
12
DC 9V Jack: For power supply, use a 9-volt DC regulated by AC
adapter, 300mA (plug polarity is positive on the barrel and negative
in the center).
13
Battery Holder: For installing batteries (AA/LR6 x 4).
11
06
AC adapter
Connections
Microphone
Amplifiers
INST.THRUDC9V INST.IN
OUTPUT
Microphone
07
MIC IN
Guitar amplifier
[PHONES]
Headphones
Operation
Patch Selecting
01
Power On
Plug the cable of AC Adapter
(9V, 300mA, center minus) into
MIC IN
the [DC 9V] Jack, when using
batteries, plug the Mic cable
into [MIC IN] this jack will turn
the device on.
02
Selecting Patches
Set the Module Selector to [PATCH],
the LED display will show the information
Bank
name
BANK
PATCH
Patch
name
of bank and patch number, step on
EDITDATA
[PATCH +/-] footswitch to change patches
(Hold one footswitch to switch patches
quickly).
Pressing [PATCH +] footswitch time and again (or holding [PATCH +]
footswitch) cycles through patches in the order ~ ... ~ , ~ ...
~ , Pressing or holding [PATCH -] footswitch will switch patches in
the opposite order.
Adjusting the master volume
03
Set the Module Selector to [PATCH], rotate [VALUE] knob to adjust
the setting up the master volume, master volume of VEM Box (when
LED display will show the current level). The range of
master volume is ~ , 70 is the default value.
INST.THRUDC9V INST.IN
OUTPUT
[PHONES]
BANK PATCH
Entering Bypass Mode
04
When in PATCH mode, press both [PATCH –] and [PATCH +]
footswitches together to enter bypass mode. LED will display ,
and all of the effects will be turned off.
08
EDIT
DATA
BANK PATCH
EDIT
DATA
Expression Pedal
Volume Control
01
If the [EXP. PEDAL] LED is not lighted up, the expression pedal
will be a volume pedal for controlling the master level of VEM Box.
02
Effect Control
If the [EXP. PEDAL] LED is lighted up, the expression pedal will be
an expression pedal for controlling the effect’s parameter which
was set up in PEDAL setting.
Control Assign
03
Set the Module Selector to [PEDAL], the LED display will show the
controlling object of the expression pedal.
There are 9 kinds of parameter can be controlled by the pedal,
LED will show the type of parameter in control:
Control Target
Wah
Transducer
Modulation Rate
Modulation Depth Depth
Harmony Range
Delay Time
Delay Feedback
Reverb Level Reverb Level
Vocoder Gender Gender
LED Display
Control Parameter
Central Frequency
Gain / Cutoff
Rate / Frequency
Pitch
Time
Feedback
Rotate [VALUE] knob to choose one kind of controlling target, then
the expression pedal will work with the corresponding parameter.
Note: There will be a symbol behind the effect parameter which can be
controlled by the pedal (refer to Effect Explanation for detail).
Note: If the effect module of the chosen target was not turned on, the pedal
will be of no effect.
Note: Pedal setting can be stored in patch.
Note: The expression pedal will be effective in EDIT mode.
09
Expression Pedal
Switch Control Mode
04
(Volume-Effect)
Push down the expression pedal at full
tilt to switch the control mode from
volume control to effect control, and
[EXP.PEDAL] LED will shift from
Push strongly, so that pedal
touches here
extinguish to light. It also can switch the
control mode from effect control to
volume control, [EXP.PEDAL] LED will
shift from light to extinguish.
05
Pedal Reset
The responsivity of the expression pedal on VEM Box can be reset
as necessary. If the effect change seems insufficient when pushing
the pedal down, or if the volume or tone changes excessively even
when the pedal is only lightly pushed, or if it’s hard to switch the
pedal mode, adjust the pedal as follows:
a. Set the Module Selector to [PEDAL] and hold down [VALUE]
button and then power on, the indication will appear on the LED
display, and then release the [VALUE] button.
b. Fully raise the expression pedal and press [VALUE] button once,
the indication will appear on the LED display.
c. Push the expression pedal fully down and press [VALUE] button
again, the indication will appear on the LED display.
d. Push strongly down the expression pedal at full tilt and press
[VALUE] button once more. The Pedal Reset adjustment is
completed, and VEM Box will return to the play mode. If the
indication is shown, press [VALUE] button and repeat the
procedure from step b.
Fully raise
Fully down
Push strongly, so that pedal
touches here
10
Patch Editing
Select Effect Module
01
Set the Module Selector to the effect module which you want to
edit, the available setting options are listed below:
01.MIC LEVEL (Para)
02.PEDAL (Para)
03.PREAMP (Type & Para)
04.TRANS (Type & Para)
05.EQ (Type & Para)
06.MOD (Type & Para)
07.RATE (Para)
08.HARMONY (Type)
09.RANGE (Para)
1100..DELAY (Type & Para)
11.D.TIME (Para)
12.REVERB (Type & Para)
13.DECAY (Para)
14.VOCODER (Type & Para)
BANK
DATA
EDIT
PATCH
Parameters
value
Effect
type
05
04
03
02
TRAN S
PREA MP
01
Type & Para: The effect type (left
side of the display) and parameter’s
value (right side of the display) are
adjusted simultaneously.
06
07
08
14
09
10
11
12
13
Para: Only adjust the
Type: Only select the effect type.
BANK
Effect
type
PATCH
EDIT
parameter’s value.
BANK
value
DATADATA
PATCH
EDIT
In fact, the RATE module is a part of MOD module, the RANGE module
is a part of HARMONY module, the D.TIME module is a part of DELAY
module, and the DECAY module is a part of REVERB module.
They are all parameter’s value setting module which belongs to the
previous effect module.
11
Patch Editing
Change Setting
02
Press [VALUE] knob to change effect/parameter type ahead, hold
and rotate [VALUE] knob to change effect/parameter type ahead
(clockwise) or backwards (anticlockwise), rotate [VALUE] knob to
set a new value of the effect type or parameter. As long as the
selected item’s value changes, a dot ( ) will appear in the bottom
right of the display. This indicates that a setting has been changed
from the currently stored value.
BANK
PATCH
TRA NS
PRE AMP
03
Bypass an Effect Module
Dot indicates that setting
has been changed
DATA
EDIT
When adjusting an effect in EDIT mode, press [MODULE
BYPASS] / [PATCH +] footswitch to bypass this effect module, the
indication will appears on the display and the module will be
turned off. Pressing [MODULE BYPASS] / [PATCH +] switches
once more will return the setting to the previous condition.
BANK PATCH
REC/OVERDUB
PATCH
BYPASS
HOLD FOR LOOP
MODULE BYPASS
VALUE
EDIT
DATA
Adjusting the MIC LEVEL
04
Set the Module Selector to [MIC LEVEL], rotate [VALUE] knob
to adjust the volume of a patch, LED display will show the current
level.
The range of patch level is ~ .
Note: If you return to [PATCH] module and select another patch, the
changes you have made in edit mode will be lost unless you store the
patch first.
12
Patch Storing/Copying
Enter Storing Mode
01
Set the Module Selector to [STORE] to enter storing mode, the
display will show the current editing patch’s number.
BANK PATCH
TRAN S
PRE AMP
EDITDATA
Storing/Copying Patch
02
When in [STORE] mode, press [VALUE]
button once to do the storing, the patch’s
number on the display will begin to flash, at
that time, rotate [VALUE] knob or press
[PATCH -] / [PATCH +] footswitch to
change patch number, when you got the
expectant position, press [VALUE] button
again to confirm the patch storing, the
patch’s number on the display will stop
flashing.
BANK PATCH
DATA
EDIT
Note: To cancel the store process, rotate the Module Selector to another
position, well then the patch will not be saved.
Note: An edited patch can be stored in a user bank ( ~ ), it can not be
stored in a preset patch ( ~ ).
Note: Storing an existing patch in another location can create a copy.
13
Patch Pre-Select Recall Function
Patch Pre-Select function can let you select the patch firs t but
not to activate it, and then perform an additional step to acti vate
the patc h.
To use this fu nction, conform to the following instructions:
Before p ower on, hold down the [PATCH +] footswi tch,
01
and then
power to the VEM Box, will appear on the display and last
flashing for 3 seconds, it indicates setting up to Patch Pre- Select
function successfully.
BANK PATCH
EDITDATA
In PATCH mode, select the patch to use
02
REC/OVERDUB
PATCH
BYPASS
HOLD FOR LOOP
MODULE BYPASS
BANK PATCH
next. The selected new ban k and patch’s
number flash on the display, but the sound
does not change yet.
EDITDATA
Press bo th [PATCH -] and [PATCH +]
03
footsw itches together,
the sele cted patch will be activated, the sound changes, and
the display will stop flashing.
REC/OVERDUB
HOLD FOR MUTE TUNING
BYPASS / TUNER
MODULE BYPASS
PATCH
BANK PATCH
BANK PATCH
EDITDATA
To return th e normal patch selecting method, turn the power
04
EDITDATA
off and then on again. The Patch Pre-Select fu nction will not
preser ve when power on again.
14
Vocoder Functions
Vocoder is a process of using real-time frequency spectrum of one sound
(Modulator) to modulate the frequency spectrum of another (Carrier).
it contains a series of bandpass filters that allow through only those
frequencies detected in the Modulator source. For example, when a
human voice is used to modulate a synthesizer voice, it will sound like
the synthesizer is talking, very interesting effects.
Selecting Vocoder Types
01
Set the Module Selector to [VOCODER] to enter Vocoder module, you
can select vocoder types by pressing [VALUE] button. There are 3 types
o f vocoder effects in VEM Box: Vocoder, Robot, Whisper.
Vocoder is a standard classical vocoder, you need to plug an instrument
into the INST. IN jack as a carrier source, and connect your microphone
to [MIC IN] jack, then play the instrument while speaking or singing, you
will enjoy the wonder sound.
Robot is a traditional vocoder effect often heard from many sci-fi movies,
to use this vocoder effect, just plug your mic and speak or sing.
Whisper is an alternative vocoder effect which can makes your voice
sound like devil speaking, to use this vocoder effect, just plug your mic
and speak or sing.
Adjusting Vocoder Effects
02
Each vocoder effect has the same parameter (Gender) to adjust, use
[VALUE] knob to change parameter range ( ~ ), gender can slew the
p itch of the vocoder down for a more masculine sound (smaller value) or
up for a more feminine sound (bigger value).
Note: When Vocoder module is working, other effects module will be invalid,
but the parameters of them will be unchanged.
Note: When saving a patch with active vocoder effects, other module’s
parameter can be stored as well whereas they are invalid. When vocoder is set
to off in this patch, other effects modules will return to their corresponding
state.
15
Loop Functions
Enter Loop Mode
01
BANK PATCH
Hold down [PATCH –] and [PATCH +] footswitches
together longer than 2 seconds to enter Loop mode,
LED display will show .
Loop Recording
02
DATA
BANK PATCH
When in Loop mode, press [PATCH-] / [REC ] /OVERDUB
footswitch once to start recording, will appear
o n the LED display and last flashing.
DATA
During first time recording, press [PATCH-] / [REC ] footswitch /OVERDUB
again to set the loop end, recording will be stopped and turn to loop
playback; press [PATCH+] footswitch can also set the loop end but the
loop will be stopped.
Note: The maximuem recording time is 16 seconds, the loop end will be set
immediately once the first recording time go beyond 16 seconds.
Note: Only the MIC IN singal can be recorded.
Overdub
03
When a loop is already recorded, no matter it is stopped or in playback,
press [PATCH-] / [REC/OVERDUB] footswitch to start overdubbing,
will flashing on the LED display again.
BANK PATCH
During overdubbing, press [patch-] / [REC/OVERDUB]
footswitch will stop overdubbing and turn to playback,
then press [patch-] / [REC/OVERDUB] footswitch again
DATA
will do another overdubbing.
You can record a loop and overdub it again and again, there is no limit of
overdubbing times .
EDIT
EDIT
EDIT
Note: Once the overdubbing time go beyond the loop length, a new overdubbing
will begin automatically from the loop start.
Delete Loop
04
If VEM Box have a recorded loop data, a dot (.) will appear in the middle
bottom of LED display. Hold down VALUE button longer than 3 seconds
while the loop is in the stop status, the loop data will be deleted and the
dot (.) will disappear as well.
16
Loop Functions
Play/Stop loop
05
When loop is at stop status (LED display shows ), press [PATCH+]
footswitch to start loop playing (if there is no loop data, playback can not
be executed).
When the loop is playing ( is flashing on the LED display), press
[PATCH+] footswitch to stop playback,
When recording ( is flashing on the LED display), press [PATCH+]
footswitch to stop playing and recording, LED display will turn to show
, press [PATCH+] footswitch again to start playback.
Exit Loop mode
06
When in Loop mode, hold down [PATCH –] and [PATCH +] footswitches
together longer than 2 seconds to exit loop function.
Selecting effects and Patch in Loop mode
07
When in Loop mode, you can select patches and adjust effects as well.
Set the Module Selector to [PATCH] module, you can select patches by
rotating [VALUE] knob. When adjusting effects in loop mode, the
parameters's value shown in LED display will last flashing, moreover, the
LED will return to indicate loop function if there is no operation in 3
seconds.
LED display will show .
Note: The loop data will be remain even though you exit the loop mode, it will
be lost after power off or deleting operation.
Note: When selecting patches or adjusting effects in Loop mode, any operation
of Loop function will turned the LED display to indicate loop information at
once.
Note: In Loop mode, store function can not be operated.
17
Factory Reset
Factory Reset function will initialize all setting of VEM Box. All the user
patches will be erased and overwritten by the preset patches.
To do the factory reset, conform to the following instructions:
Before power on, set the Module Selector to [PATCH], hold down the
[PATCH -] and [PATCH +] footswitch and the [VALUE] button
simultaneously, and then power to the VEM Box, will appear on the
display and last flashing.
MODULE BYPASS
PATCH
BANK PATCH
EDIT
DATA
TRA NS
PRE AMP
HOLD
REC/OVERDUB
HOLD FOR MUTE TUNING
BYPASS / TUNER
At that time, press [VALUE] button to confirm, will be flashing in a
faster speed for 2 seconds, then turn to display at a steady status
for 3 second, then back to the normal state, the factory reset operation
have been done.
VALUE
PRESS
BANK PATCH
EDIT
FASTER FLASHING
2 SECONDS
BANK PATCH
EDIT
DATADATA
3 SECONDS
BANK PATCH
EDIT
DATA
Note: If you want to quit Factory Reset halfway, move the Module Selector to
another location, then the Factory Reset will be canceled.
18
Effects Explanation
01
General Instruction
Effect Chain
Modules
PREAMP EQTRANSDUCER
Compressor
Types
Limiter
Boost
Noise Reduce
Auto Wah
Sense Wah
Manual Wah
VOCODER
Vocoder
Robot
Whisper
Distortion
Grunge
Low Cut
High Cut
Telephone
Tube
LoFi
Overdrive
Fuzz
Beast
Mid Cut
Radio
Megaphone
Low
Mid
High
Presence
MOD
Chorus
Flanger
Talk Flanger
Phaser
Step Phaser
Tremolo
Vibrato
Filter
Ring
Stutter
VEM Box has 8 effect modules, 54 types of effect in total, can offer up
to 7 simultaneous effects (VOCODER module can not work with any
other module at one time).
Each effect module has several different effect types, only one type can
be selected at a time. All effect types have various parameters that can
be adjusted, the parameters change the tone and effect intensity similar
to the knobs on the device.
02
Explain the Effects Modules/Types/Parameters
HARMONY
1 Voice Harmony
2 Voices Harmony
3 Voices Harmony
Double
Pitch Shift
Detune
DELAY
Digital
Analog
Mod
Tape Echo
Echo
REVERB
Room
Chamber
Hall
Church
Plate
Mod
PREAMP Module
Type Name Display Effect Explanation
This effect is used for controlling dynamics of the signal, it limits
Compressor
Limiter
Boost
NR
Auto Wah
high-level signals and boosts low-level signals.
The parameter's value controls the Depth.
This effect limits high-level signals to avoid
The parameter's value controls the Depth.
This effect can enhance the gain and dynamic of the signal.
The parameter's value controls the Gain.
Noise Reduction, it will reduce the noise of input signal.
The parameter's value controls the NR's Intensity.
This effect creates a recurrent wah-wah sound.
The parameter's value controls the Rate.
19
overload.
Effects Explanation
Sense Wah
Manual Wah
This effect varies wah sound according to input intensity.
The parameter's value controls the Sensitivity.
This effect varies wah sound by turning the knob or controlling
the expression pedal.
The parameter's value controls the Central Frequency.
This mark means the parameter can be controlled by the expression pedal if corresponding
type was chosen in PEDAL module.
TRANS (Transducer) Module
Type Name Display Effect Explanation
This effect simulates a warm tube drive tone of classical tube
Tube
Overdrive
Distortion
Fuzz
Grunge
Beast
Low Cut
Mid Cut
High Cut
Radio
Telephone
Megaphone
LoFi
preamplifier.
The parameter's value controls the Gain.
This effect produces a natural overdrive sound.
The parameter's value controls the Gain.
This effect creates a smooth distortion sound.
The parameter's value controls the Gain.
This effect creates a classic fuzz sound.
The parameter's value controls the Gain.
This effect creates a dirty but powerful distortion sound.
The parameter's value controls the Gain.
This effect makes your voice offensive like a beast.
The parameter's value controls the Gain.
This effect cuts the low frequency.
The parameter's value controls the Cutoff.
This effect cuts the mid frequency.
The parameter's value controls the Cutoff.
This effect cuts the high frequency.
The parameter's value controls the Cutoff.
This effect sounds like coming from an old radio.
The parameter's value controls the Cutoff.
This effect sounds like coming from a telephone.
The parameter's value controls the Cutoff.
This effect sounds like coming from a megaphone
The parameter's value controls the Cutoff.
This effect creates a rough lofi sound.
The parameter's value controls the Cutoff.
20
Effects Explanation
EQ (Equalizer) Module
Type Name Display Effect Explanation
Low
Mid
High
Presence
This controls the bottom band of the equalizer, the central frequency
is 200Hz. The parameters value controls the Gain.
This controls the middle band of the equalizer, the central frequency
is 500Hz. The parameters value controls the Gain.
This controls the high band of the equalizer, the central frequency is
1kHz. The parameters value controls the Gain.
This controls the ultra high band of the equalizer, the central
frequency is 8kHz. The parameter 's value controls the Gain.
EQ Gain-Display Comparison:
Para-Display
Gain
1 2 3 4 5 6 7 8 9
-12dB -9dB -6dB -3dB 0dB +3dB +6dB +9dB +12dB
MOD (Modulation) Module
Type Name Display Effect Explanation
Chorus
Flanger
Talk Flanger
Phaser
Step Phaser
Tremolo
Vibrato
Filter
Ring
Stutter
Rate
This effect creates a shining dimensional sound. The parameter’s
value controls the Depth.
This effect produces an undulating and floating feeling sound. The
parameter’s value controls the Depth.
This effect produces another kind of flanger sound. The parameter’s
value controls the Depth.
This effect creates a pulsing-like sound. The parameter’s value
controls the Depth.
This effect produces a phaser sound with more pulsing feeling. The
parameter’s value controls the Depth.
This effect periodically influences the volume of the signal. The
parameter’s value controls the Depth.
This effect periodically influences the pitch of the signal. The
parameter’s value controls the Depth.
This effect produces a sweeping filter sound. The parameter's
value controls the Depth.
Produces sounds like ring bell. The parameter's value controls
the Effect's Level.
This effect makes your sound on and off.
The parameter's value controls the Depth.
Control the speed of effects, except Ring.
Frequency
Control the frequency when use Ring.
21
HARMONY Module
Type Name Dis play Effect Explanation
1 Voice Harmony
This effect transfers the pitch and blend with the original note.
Effects Explanation
2 Voices Harmony
3 Voices Harmony
Double
Pitch Shift
Detune
This effect creates 2 pitch shift sound blended with the original note.
This effect creates 3 pitch shift sound blended with the original note
This effect makes your voice thicker and wider.
This effect transfers the original note's pitch.
This effect slightly shifts the pitch and mixes it back with the
original signal to create a chorus-like effect.
HARMONY Range Comparison:
Type Name Dis play Effect Explanation
1 Voice Harmony
2 Voices Harmony
3 Voices Harmony
Double
Pitch Shift
Detune
2 Voices Har mony (sem itone)
-1 2, +12
-7 , -12
-7 , -4
-7 , +4
-7 , +7
-4 , +4
-4 , +7
+4, +7
+ 5, +1 2
+7, +12 +4, +7, +12
Control the harmony range from -12 semitones to +12 semitones.
Each parameter corresponds to a 2 Voices Harmony sound,
conform to the following list.
Each parameter corresponds to a 3 Voices Harmony
sound, conform to the following list.
Control the doubling effects' depth.
Control the pitch range from -12 semitones to +12 semitones.
Control the pitch range from 1 cent to 30 cents.
3 Voices Har mony (semitone)
-1 2, -7, -4
-1 2, -7, +12
-1 2, -5, +12
-1 2, +5, +12
-1 2, +7, +12
-7 , -4, + 4
-7 , -4, + 7
-7 , +4, +7
-4 , +4, +7
22
Effects Explanation
DELAY Module
Type Name Dis play Effect Explanation
Digital
Analog
Mod
Tape Echo
Echo
Delay Time
Repeat the signal with no special processing, creates the most
clean delay sound. The parameter's value controls the Feedback.
Simulates an analog delay equipment, produces a warm and vintage
delay sound. The parameter's value controls the Feedback.
Adds chorus effect to the delay sound, has more extensive spacy
feeling. The parameter's value controls the Feedback.
Simulates an Tape Echo machine, creates a tape-like delay sound.
The parameter's value controls the Feedback.
Simulates the real Echo, authentic and natural delay sound.
The parameter's value controls the Feedback.
The value indicates the delay time from 10ms~1500ms.
REVERB Module
Type Name Display Effect Explanation
Room
Chamber
Hall
Church
Plate
Mod
Decay Control the Decay of Reverb effect
Simulates the acoustics of a Room.
The parameter's value controls the Reverb's Level.
Simulates the acoustics of a Chamber.
The parameter's value controls the Reverb's Level.
Simulates the acoustics of a concert Hall.
The parameter's value controls the Reverb's Level.
Simulates the acoustics of a big church.
The parameter's value controls the Reverb's Level.
Simulates a Plate reverberation.
The parameter's value controls the Reverb's Level.
Add Chorus effect to a Hall reverb.
The parameter's value controls the Reverb's Level.
VOCODER Module
Type Name Display Effect Explanation
Offers a wonderful vocoder effect, like the guitar sound (keyboard,
synthesizer, or other instruments) is talking.
The parameter's value controls the Vocoder's Gender.
This effect can make your voice sound like a robot.
The parameter's value controls the Vocoder's Gender.
This effect can make your voice sound like devil speaking.
The parameter's value controls the Vocoder's Gender.
Vocoder
Robot
Whisper
Note: The Vocoder effect must work with instruments input, or else there is no
sound, the Robot effect and Whisper effect didn't have to.
23
Specification
No. of Effect Modules:
No. of Effect Types:
Preset Patch Memory:
User Patch Memory:
MIC IN Jack:
INST. IN Jack:
OUTPUT [PHONES] Jack:
INST. THRU Jack:
Power requirements:
Dimensions:
Weight:
Accessories:
* Disclaimer: Any specification’s update won't be amended in this manual.
8 Modules (Max. 7 simultaneous modules)
54 Types
40 Patches (4 Banks, each bank has 10 patches)
40 Patches (4 Banks, each bank has 10 patches)
XLR+1/4 TRS audio jack”
1/4” mono audio jack
1/4” stereo audio jack(doubles as line/headphone jack)
1/4” mono audio jack
AC adapter 9V DC, 300 mA (center minus plug)
or 4 AA/LR6 batteries
158mm (D) x 237mm (W) x 63mm (H)
750g (without batteries)
Owner’s Manual, AC adapter 9V DC
24
Troubleshooting
Can not power on
Check power connection.
------ Make sure the power is connected correctly.
Check the adapter.
------ Make sure the adapter’s type is DC9V/300mA/center minus.
When using battery, check whether the cable is inserted entirely to the
MIC IN jack.
When using battery, check the battery, is the battery low or dead?
------ Make sure the battery is at work and the MIC IN jack is connected
with an audio cable.
No sound or low volume
Check connection of cables.
------ Make sure all the cables are connected firmly.
Check the on/off switch of microphone and the volume setting of amplifier.
------ Make sure each equipment’s volume is set to an appropriate level.
High noise
Check the adapter.
------ Make sure the adapter’s type is DC9V/300mA/center minus.
Check the cables.
------ Make sure the cables are connected firmly and have no quality
problem.
25
Appendix
Patch List
Patch PatchPatch Name Reverb Level Pedal Assign
Simple Repeat
Bright Hall
FB Plate
Dirty Thing
4th Down
Radio
Choir
Ghost Vib
Evil Voice
Classic Vocoder
Beast Speak
Comp Echo
Nice 2-Voice
Chop Chop
Lofi Harmony
Top On Tower
Little Jet
Underwater
Infiniteness
Reform
Volume
Reverb Level Volume
Volume
Volume
Volume Volume
Volume
Volume
Vibrato Depth
Harmony Range
Volume
Volume
Volume
Volume
Stutter Rate
Volume
Volume
Flanger Rate
Flanger Rate
Volume
Vocoder Gender
Patch Name
Tape Echo
3-Voice Plate
Double
Telephone
Naughty Child
Holy Water
5th Up
Dark Hall
Breathe
Devil Inside
Chorus Echo
Detune
4th Wah
Spacy
Fuzzy Boy
Fast Echo
Broken Mirror
Scary Movie
Snow Man
Robot
Volume
Volume
Volume
Reverb Level
Volume
Reverb Level
Volume
Vocoder Gender
Volume
Volume
Volume
Reverb Level
Fuzz Gain
Delay Feedback
Volume
Reverb Level
Volume
Vocoder Gender
26
MOOER AUDIO CO.,LTD
Shenzhen, China
www.mooeraudio.com
Loading...
