Direct Input Box
1. Status LED
Instructs the workin g st at us o f
MICRO DI, when lit up, the uni t is
at work, GREEN light indic at es
CABINET SIM ULATOR is off,
RED light indicates th e CA BI NE T
SIMULATO R is o n.
2. DC IN Power Jack:
For power supply, use a 9-volt
DC regulated AC adapter (p lu g
polarity is positive o n th e ba rr el
and negative in the cent er ).
3. INPUT Jack:
”
1/4 mono audio jack, for
connecting guitar or b as s.
4. BALANCED OUTPUT Jac k:
XLR BALANCED output ja ck ,
outputs the signal.
5. UNBALANCED OUTPUT J ac k:
1/4” mono audio jack, ou tp ut s
the signal.
6. GAIN Switch:
Switches the gain valu e be tw ee n -2 0d B, 0 dB a nd + 20 dB .
7. CABINET SIMULATOR S wi tc h:
The v ir tu al 4x12” cabinet simulation can be switched on and off by
the OFF/ON switch.
8. GND LIFT Switch:
When pushed down, it bre ak s th e gr ou nd c on ne ct io n be tw ee n in pu t
and output. This can eliminate hum or ground loops depending on
the grounding of the con ne ct ed e qu ip me nt .
:
Smart direct input box wit h ul tr a lo w di st or ti on , it q ui et ly t ra ns fe rs
the sound of guitar or bas s di re ct ly t o th e au di o sy st em
Balanced/unbalan ce d ou tp ut , ga in s wi tc h, c ab in et s im ul at or a nd
ground lift function i nc lu de d
Full metal shell
Very small and exquis it e DC 9 V Ada pt er p ow er s up pl y
Main Features
Input: 1/4” monaural j ac k (i mp ed an ce : 1M )
Output: 1/4” monaura l ja ck ( im pe da nc e: 1 k Oh ms )
Power Requirements : AC a da pt er 9 V DC ( ce nt er m in us p lu g)
Current Draw: 12 mA
Dimensions: 93.5mm ( D) × 4 2m m (W ) × 52 mm ( H)
Wei gh t: 140g
Accessories: Own er ’s M an ua l
* Dis claim er: Any s pecif icati on’s up date wo n't be am ended i n this ma nual.
