SYSTEM COMPONENTS
The Mojix STAR system is a single network element at the enterprise edge. Based on Mojix's innovative distributed architecture, a single system consists of one or more STAR units managing up to 512 low-cost Mojix eNode transmitters. Mojix eNodes provide energy to all passive RFID tags within their specified interrogation spaces, while the centralized, high-sensitivity Mojix STAR reads the resulting tag signals from across the system's potentially vast coverage area of more than 250,000 sq. feet (24,000 sq. meters).
Mojix eNodes: Distributed Transmitters
Mojix eNodes are reliable, autonomously operated RF repeaters designed to excite all EPC UHF Gen2 RFID tags within their designated interrogation spaces. Although excite ranges are dependent on tag sensitivity, they can range to over 100 feet. Each eNode antenna excites all passive RFID tags within its designated interrogation space and includes form factors to accommodate both fixed and mobile infrastructures. eNodes can be deployed as needed to shape discrete, overlapping or contiguous interrogation spaces, including configurations to create virtual fences for securing tagged items.
STAR Receiver: Centralized Read and Control point
The STAR Receiver functions as a single point of data collection, provisioning, control, and integration with enterprise systems. With the ability to detect extremely faint signals and the freedom from conventional RFID’s line of sight restrictions, the STAR receiver works in concert with its satellite eNodes to support one or many business processes across the entire coverage area. The STAR Receiver contains a 1 x 4 array assembly, and digital and RF processing assemblies. The STAR Receiver utilizes classical, fully active, phased array antennas for enabling the visibility into the space dimension. The smart array approach adopted by Mojix is based fully on digital processing techniques, thereby providing very high resolution for estimation of direction of arrival of the signal of interest (SOI), enabling the system to provide accurate location information on the tag position.
Master Controller
The STAR signal processing platform is linked to an edge appliance called a Master Controller (MCON), and communicates via a standard wired Ethernet interface. The MCON can drive an arbitrary number of STAR systems and includes interfaces to the enterprise middleware. In a larger enterprise deployment, multiple STAR domains exist in various locations and can require one or more Master Controllers in a clustered configuration.
www.mojix.com
Confidential and Proprietary
STAR 3000 Installation Manual
Mojix Incorporated
Page
9 of 45
STAR: Physical Interfaces
The following picture illustrates the STAR’s physical interfaces.
www.mojix.com
Figure 1: STAR Physical Interfaces
1. 1 TX Output TNC: Transmit RF Signal, 24 Volts DC, Forward Command Signal
2. 2 TX Output TNC for Wireless eNode Network: Up to two wireless forward command antenna(s)
3. 4 RX Input TNC from Antenna(s): Inputs from receive antenna array OR individual receive antenna(s)
4. 1 RX Input TNC Sync: Input synchronization signal from master STAR (for multiple simultaneous receiving)
5. 1 TX Output TNC Sync: Output synchronization signal to another STAR
6. 2 Ethernet Interfaces: Control from MCON, Status Monitoring and Tag Read Packets
7. 2 USB Interfaces (future use)
8. 1 DC Power Connector
Cabled System Topology
Confidential and Proprietary
STAR 3000 Installation Manual
Mojix Incorporated
Page
10 of 45
Error! Reference source not found. illustrates the components of the STAR system topology. These
items are as follows:
Figure 2: STAR System Topology
SYSTEM COMPONENTS
1. STAR
2. eMux: splitter and amplifier for the RF signal
3. eNode: controls up to 4 antennas to excite tags
4. Master Controller (MCON): application appliance
5. Optional Sensor network to detect activity in specific areas
Wireless STAR System Topology
Figure 3 illustrates Wireless STAR system topology, showing:
1. STAR and power supply, including the command link antenna
2. Wireless 4-port eNode, including the command link antenna
3. Sensor port
4. eNode transmit antennas
5. MCON
www.mojix.com
Confidential and Proprietary
STAR 3000 Installation Manual
Mojix Incorporated
Page
11 of 45
Com m and Link Transmit Only Antenna
Wireless TAR Reader
LAN line
LAN
Master Controller
Power Supply
Wireless
4 Port eNode
Com mand Link Receive Only Antenna
External Power Supply
Senso rs
Transmit Antenna
Coaxial Cable
Tag
Figure 3: Wireless STAR System Topology
www.mojix.com
Confidential and Proprietary
STAR 3000 Installation Manual
Mojix Incorporated
Page
12 of 45
STAR RECEIVER INSTALLATION
STAR Receiver Installation
The STAR is mechanically designed for post or wall mounting. Figure 4 illustrates the rear mounting bracket. This bracket is designed to be used with any standard VESA mounting bracket. As shown in the figure, the mounting bracket is installed directly on the STAR Receiver back plate.
Installation instructions:
1. Product installation shall be conducted by a qualified installer. The appropriate local engineer or architect shall be consulted to ensure the wall and/or pole mount is capable of safely supporting up to 4 times the weight of the product.
2. Should the customer elect to mount the STAR to a flat surface (e.g. wall), holes are provided in the main mounting bracket to accommodate a family of hardware (customer supplied).
3. When mounting STAR unit to a flat surface, a minimum of 4 fasteners are required, though the exact type is a function of the wall material and construction. Best industry practice is recommended.
a. For example: toggle bolts or Molly bolts would be the first choice on hollow walls. Lead lag
shields would be recommended on solid (cast) concrete or brick. Nails are not recommended, but could be used only if the wood material of the wall was at least 1.5" thick.
4. The STAR Receiver is first secured to the main bracket using the provided hardware. A standard VESA bracket designed to hold 4 times the weight of the STAR unit should separately be mounted to either a mast or a flat surface. The last step is to attach the STAR bracket to the VESA bracket.
www.mojix.com
Figure 4: STAR 3000 VESA Interface Mount Bracket
Confidential and Proprietary
STAR 3000 Installation Manual
Mojix Incorporated
Page
13 of 45
Figure 5: VESA Interface Mount Bracket Side View
Figure 6: VESA Interface Mount Bracket Rear View
Figure 7: VESA Interface Mount Bracket End Profile View
www.mojix.com
Confidential and Proprietary
STAR 3000 Installation Manual
Mojix Incorporated
Page
14 of 45
STAR POWER SUPPLY INSTALLATION
Recommended installation of the power supply is a wall mounted configuration within 20 feet from the STAR Receiver.
Wall Mount Power Supply
Figure 8 shows the power supply with integrated mounting brackets.
www.mojix.com
Figure 8: STAR Power Supply
The wall mounted power supply requires the following hardware (not included with shipment).
#6 Drywall (bugle head) or #6 wood screws if the unit is being fastened to a wooden surface
For a solid wood mount, box nails are a suitable option, provided that the head diameter is more
than .28” and less than .30” in diameter and the shank of the nail is at least 2” long.
For a metal surface mount that is at least .1875” thick, #6-32 pan head machine screws may be
used.
Confidential and Proprietary
Loading...
+ 31 hidden pages
