DESCRIPTION
• Available in various finishes identified by suffix
• Fixed mount showerhead only
• Nonmetallic spray face and shell
• Brass swivel ball assembly
FLOW
• Showerhead is limited to 2.5 gpm (9.5 L/min) at 80 psi
• EP suffix models are limited to 1.75 gpm (6.6 L/min) at 80 psi
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B125.1 and all applicable
requirements referenced therein
• EP suffix models are IAPMO Green listed and third party certified to
WaterSense®
WARRANTY
• Lifetime limited warranty against leaks, drips and finish defects to the
original homeowner
• 10 year limited warranty when used in a multifamily installation
• 5 year limited warranty when used in a commercial installation
Visit www.moen.com/support for complete details and limitations
Specifications
Moenflo® XL
Single Function Showerhead
Models: 6322 series
3-1/4"
(82mm)
EP Suffix
Models Only
3-3/4"
(95mm)
Rev. 6/17
CRITICAL DIMENSIONS
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
