Kyvos™ Technical Specication

1-5/16
(33mm)

3"

(458mm)

(610mm)

18" & 24" Towel Bar BP3718 & BP3724

Stock Numbers:

BP3718CH – Towel Bar

Chrome Finish

BP3724CH – Towel Bar

Chrome Finish

BP3718BN – Towel Bar

Brushed Nickel

BP3724BN – Towel Bar

Brushed Nickel

Materials:

Dimensions:

18" Towel Bar

24" Towel Bar

18"

24"

Installation Instructions:

(76mm)

"

Towel bar posts are constructed of
zinc. Bar is constructed of stainless steel.

1. Position the mounting template on the wall in the desired location. Using a
level, align the template and tape it to the wall.

2. Remove each mounting post from the body by loosening the set screw.

3. Place each mounting post on the template with notch facing down.

4. Mark the 2 large hole locations of each mounting bracket.

5. Attach each mounting bracket to the wall, using the wall anchors provided

6. Mount each base on the corresponding mounting bracket. Check and make
sure that the base set screw hole(s) are facing down. Assemble a set screw
to each base. Use the allen wrench included in hardware kit to tighten each
set screw and secure the assembly to the mounting bracket(s).

7. Tighten all 4 screws. Do not over tighten.

8. With pre-assembled towel bar and posts, position each end post with the
set screw down and place over mounting post. Tighten the set screw at the
bottom of each base.

Cleaning Instructions:

To preserve the ne nish of this product, clean only with a soft damp cloth. Dry

well. Do not use commercial or abrasive cleaners.

Stock Number: ______________________ Towel Bar
By Moen Incorporated

25300 AL MOEN DRIVE • NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: [phone] • FAX: [phone]
INTERNATIONAL: (440 ) 962-2000 • FAX: [phone]
CUSTOMER SERVICE (USA): 800-882-0116 • FAX: [phone]
WWW.MOEN.COM

©

2016 Moen Incorporated. Moen is a registered trademark and Kyvos is a trademark of

Moen Incorporated. All rights reserved.
