Page 1

Robe Hook

is die cast from highest

P5030PB

–

Double Robe Hook

Cleaning Instructions:

Stock Number:

______________________Robe Hook

Materials:

Installation Instructi

ons:

Dimensions:

Contemporary Technical Specification



Literature #BA0990

Robe Hook

Stock Numbers:

Polished Brass Finish Concealed Screw Mounting

q P5030 – Double Robe Hook

Polished Chrome Finish Concealed Screw Mounting

“P” = Poly Bag Packaging

P5030

quality zinc alloy (zamac). Castings are triple plated with a polished brass or a polished chrome finish.

1. Remove mounting bracket from back of fixture by loosening the set screw.

2. Position unit on wall in desired location.

3. Lightly mark the outline of the base of the unit.

4. Center mounting bracket inside the outline.

5. Mark hole locations. Attach bracket to wall using 1 3/8” screws (provided).

6. Mount base on bracket. Tighten set screw on the bottom.

Note: Wood blocking is preferable behind all wall surfaces. If wood blocking is not available, the following optional fasteners are suggested: Tile/Masonry – Plastic or Lead Anchors; Plaster/Drywall – Toggle Bolts.

To preserve the fine finish of this product, clean only with a soft damp cloth. Dry well. Do not use commercial or abrasive cleaners.

By CSI Bath Furnishings

25300 AL MOEN DRIVE • NORTH OLMSTED, OH 44070 (800) 321-8809 • FAX: (800) 848-6636 • INTERNATIONAL: (440) 962-2000 •
