Y3208BN – Pivoting Paper
Holder
Brushed Nickel Finish
Y3208CH – Pivoting Paper
Holder
Chrome Finish
25300 AL MO EN DRIVE NORTH OLMS T E D , O H 44070
CORPORATE HEAD QUARTERS: (800 ) 321-8809 FAX: (800) 8 4 8 - 6 6 3 6
INTERNATIONA L: (440) 962-2000 FAX: (440) 9 6 2 -2726
CUSTOMER SERV ICE (USA): 800-882-0116 FAX: (888) 3 7 9 -2720
WWW.CSI.MOE N.COM
Copyright Creative Specialties International Literature # BA1597
Pivoting Paper Holder post is die
cast from highest quality zinc alloy
(Zamac). Casting is plated Chrome
or Brushed Nickel. The Pivoting
Paper Holder arm is stainless steel.
Cleaning Instructions:
1. Position the mounting template on the wall in the desired location.
2. Using a level, align the template and tape it to the wall.
3. Drill two 5/16” holes at each mounting plate location that
corresponds to your product.
4. Remove the template from the wall.
5. Fold ends of the plastic toggle together and insert into each hole
in the wall.
6. Lightly tap anchors until flush with the wall.
7. One at a time, insert plastic pin into each of the anchors and
lightly tap to activate anchor. Remove pin and repeat on all
anchors.
8. Remove mounting plates from the posts by loosening each
setscrew.
9. Place the mounting plate on the wall over the installed wall
anchors with “UP” facing you.
10. Insert screws through the mounting plate into the anchors.
Tighten the screws.
11. Place each post over the mounting posts with setscrews facing
down. Pivoting post with bar should be on the left side. Tighten
both setscrews.
Stock Number:______________________Pivoting
Paper Holder By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Pivoting Paper Holder
Y3208
Boardwalk Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
