25300 AL MOEN D RI VE NOR TH OLMSTED , OH 44070
COR PORATE H EADQU ARTERS: (800) 321-8809 F AX: (800) 848-6636
IN TER NATION AL: (440) 962-2000 FAX: (440) 962-2726
CU STOMER SERVI CE (USA): 800 -882-0116 FAX: (888) 379-2720
WW W. MOEN .C OM
Copyright Creative Specialties International Literature #BA1629
Shower Rods are 20-gauge stainless
steel with a polished finish.
See Technical Specification for 58-F for
information on the adjustable flanges.
58-5 – 5’ Stainless Steel Shower Rod
Set
Polished Finish
1” Diameter Smooth Rod
Exposed Screw Mounting
Flanges (58-F)
1. Place flanges on both ends of shower rod.
2. Position rod assembly in desired location.
3. Mark location of mounting holes for both flanges.
4. Drill starter holes.
5. Attach left bracket to wall using 2” screws (pr ovided).
6. Insert rod and right bracket assembly into left bracket.
7. Slide right bracket against wall and attach with 2” screws
(provided).
Note: Wood blocking is preferable behind all wall surfaces.
If wood blocking is not available, the following optional fasteners are
suggested: Tile/Masonry – Plastic or Lead Anchors; Plaster/Drywall –
Toggle Bolts
Stock Number:______________________Shower Rod
By Creative Specialties
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Shower Rod Sets – Exposed Screw
58
Shower Rods Technical Specification
