Towel Ring
posts are die cast from
2860PB
–
Towel Ring
Cleaning Instructions:
Stock Number:
______________________Towel Ring
Materials:
Installation Instructions:
Dimensions:
Contemporary Technical Specification
Towel Ring
Stock Numbers:
q
Polished Brass Finish
Concealed Screw Mounting
Metal Ring
q 2500 – Towel Ring
Polished Chrome Finish
Concealed Screw Mounting
Clear Ring
q 2860 – Towel Ring
Polished Chrome Finish
Concealed Screw Mounting
Metal Ring
2500, 2860
highest quality zinc alloy (zamac).
Castings are triple plated with a
polished brass or polished chrome
finish. 2500 ring is clear acrylic.
2860 ring is aluminum with polished
brass or polished chrome finish.
1. Remove mounting bracket from back of fixture by loosening the set
screw.
2. Position unit on wall in desired location.
3. Lightly mark the outline of the base of the unit.
4. Center mounting bracket inside the outline.
5. Mark hole locations. Attach bracket to wall using 1 3/8” screws
(provided).
6. Mount base on bracket. Tighten set screw on the bottom.
Note: Wood blocking is preferable behind all wall surfaces.
If wood blocking is not available, the following optional fasteners are
suggested: Tile/Masonry – Plastic or Lead Anchors; Plaster/Drywall –
Toggle Bolts.
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
By Creative Specialties
25300 AL MOEN DRIVE •NORTH OLMSTED, OH 44070
CORPORATE HEADQUARTERS: (800) 321-8809 • FAX: (800) 848-6636
INTERNATIONAL: (440) 962-2000 • FAX: (440) 962-2726
CUSTOMER SERVICE (USA): 800-882-0116 • FAX: (888) 379-2720
WWW.CSI.MOEN.COM
Copyright Creative Specialties International 2006
Literature #BA0991
