Modal MD-HPBT01 User Manual
MD-HPBT01
Before using your new product, please read these instructions to prevent any damage.
Bluetooth Stereo Headset
Modal MD-HPBT01 Bluetooth
Stereo Headset
Contents
Introduction ...................................................................... 2
Features............................................................................... 3
Setting up your stereo headphones......................... 6
Using your stereo headphones .................................. 6
Maintaining .....................................................................15
Troubleshooting ............................................................15
Specifications..................................................................18
Legal notices ...................................................................19
One-Year Limited Warranty........................................21
Introduction
Congratulations on your purchase of a high-quality Modal product.
Your MD-HPBT01 represents the state of the art in Bluetooth stereo
headset design and is designed for reliable and trouble-free
performance.
2
Features
Package contents
• Bluetooth stereo headset
•AC wall adapter
• USB charging cable
•Replacement ear pads
• Quick Setup Guide
3MD-HPBT01
Side view
# Item Description
Logo with
1
indicator LED
Volume Up/Down Press + or – to increase or decrease the volume.
2
(power/talk)
3
button
(play/pause)
4
button
5
Micro USB connector
(rewind)
6
(fast forward)
7
Microphone
8
Reflective strip
Indicator LED show current status of the headphones. See the LED
Indicators table on page 5.
Press to turn on your stereo headphones. If you receive a phone
call, press to talk. Press to turn off your stereo headphones.
Press to begin playback. During playback, press to pause
playback. Press again to resume playback.
Plug the micro USB connector from the AC adapter into this port
to charge your headphones.
• Press once to return to the beginning of a track.
• Press twice to go to the previous track.
• Press and hold to rewind.
• Press once to skip to the next track.
• Press and hold to fast-forward.
Allows you to talk on the telephone.
An attractive feature and provides extra safety in low-light
conditions.
4
LED indicators
Headphones status LED status
Power on
Tur ning off
Low battery
Recharging
Recharging complete
Pairing mode
Connection complete
Receiving a call
Talking on the phone
Blue LED flashes
Red LED dims and disappears
Red LED blinks continuously
Red LED stays on
Blue LED stays on
Blue and red LEDs flash rapidly
Blue LED blinks every five seconds
Blue LED flashes rapidly
Blue LED brightens and dims repeatedly
5MD-HPBT01
Setting up your stereo headphones
Charging your stereo headphones
When your stereo headphone’s battery is low, the red LED blinks.
To charge your stereo headphones:
• Connect the charging cable from the AC adapter to your Bluetooth
stereo headphones and plug the AC adapter into a wall outlet. The red
LED stays on while your stereo headphones are charging and turns blue
when they are fully charged.
Using your stereo headphones
Turning your stereo headphones on and off
To turn your stereo headphones on and off:
• Press and hold the (power/talk) button for two seconds. The LED
blinks blue (when turned on) or red (when turned off ), and the voice
prompt says “Hello”, or “Bye.”
6
Pairing your stereo headphones with a Bluetooth device
Your stereo headphones can store pairing information for up to 8
Bluetooth devices, such as phones and tablets.
Notes: Your stereo headphones:
- Range is 33 feet (10 meters).
- Support easy pairing.
- Prompt you by saying “Connected,” when connected.
- Support a battery indicator icon on an iOS device.
Make sure that your Bluetooth device supports the Bluetooth V 3.0
1
protocol and is not paired with another device. To determine what
Bluetooth protocol your device supports, see the documentation that
came with your device.
2
With the headphones turned off, press and hold (power/talk) for four
seconds. The LED blinks blue and red rapidly, then pairing mode is
activated
Make sure that your Bluetooth device is within 33 feet of your stereo
3
headphones.
4
Turn on your Bluetooth device, turn on Bluetooth, then set your device
to pairing mode. For more information, see the documentation that
came with your Bluetooth device.
5
On your Bluetooth device, select “MD-HPBT01”, then enter the password
0000 (four zeros), if required, to pair your headphones. Your stereo
headphones pair with the Bluetooth device and the LED on your stereo
headphones blinks blue every two seconds.
For more information on pairing Bluetooth devices to your cell phone or
MP3 player, see the device's documentation.
.
7MD-HPBT01
