Receptacle for

Click!

Click!

Variants/Accessories

+

Mx-p26A/B* camera body

and lenses; B036 to B237

for self-mounting

Mx-p26A/B* camera,

lens B016-B237

for MxBus modules* and

signal inputs/outputs

*Variant Mx-p26B supports MOBOTIX MxBus modules

Mx-A-IOA-IC

p26 Indoor PT

Quick Install

32.857-004_EN_05/2018

Variants of the p26

p26 camera body and lenses B036-B237

for self-mounting

p26 camera,

lens B016 to B237

+

Mx-p26A-6Day Mx-p26A-6Night

(3072x2048)
Color

Mx-p26A/B-6D

Mx-p26A/B-AU-6D

Mx-p26A/B-6D016

Mx-p26A/B-AU-6D016

Mx-p26A/B-6D036

Mx-p26A/B-AU-6D036

Mx-p26A/B-6D061 self-mounting only

Mx-p26A/B-6D079 self-mounting only

Mx-p26A/B-6D119 self-mounting only

Mx-p26A/B-6D237 self-mounting only

(3072x2048)
Black&White

Mx-p26A/B-6N

Mx-p26A/B-AU-6N

Mx-p26A/B-6N016

Mx-p26A/B-AU-6N016

Mx-p26A/B-6N036

Mx-p26A/B-AU-6N036

Variant

p26 camera module with/without audio package, for lenses
MX-B036 to MX-B237 (f/1.8, 103° bis 15°) for self-mounting

p26 with/without audio package with Fisheye lens MX-B016
(f/2.0, 180° horiz. angle of view)

p26 with/without audio package with ultra-wide-angle lens
MX-B036 (f/1.8, 103° horiz. angle of view)

p26without audio package with wide-angle lens MX-B061 (f/1.8,
60° horiz. angle of view)

p26 without audio package with standard lens MX-B079 (f/1.8, 45°
horiz. angle of view)

p26 without audio package with tele lens MX-B119
(f/1.8, 31° horiz. angle of view)

p26 without audio package with distance tele lens MX-B237 (f/1.8,
15° horiz. angle of view)

Standard Delivery

1.10

1.9

1.8

1.7

1.6

1.1

1.5

1.4

1.2

1.3

Item Count Part Name

1.1 1

1.2 1 Back cover (installed)

1.3 1 Main board with lens mount (installed)

1.4 1

1.5 1 Blind cover (only when self-mounting the lens)

1.6 1 Ethernet patch cable, 50 cm/19.7 in, black (installed)

1.7 1 MicroSD card pre-installed (SDHC installed, SDXC supported)

1.8 1 Flat-head screwdriver, blue

1.9 1

1.10 1 Allen wrench 1.5 mm

Housing with spring clips and tiltable camera receptacle
(installed)

Lens (only installed in camera models listed in «Variants of
the p26»)

Lens wrench gray (not with hemispheric variants with lens
B016)

Connecting the p26

You can nd detailed information on the installation and connections of

Power/Status

Microphone

Recording

adjusting the
camera tilt

Screw for
locking the
camera tilt

the p26 in the M25 Camera Manual (PDF, available on www.mobotix.com >
Support > Download Center > Documentation > Manuals).

Regarding the initial operation of the p26, please see the M25 Camera Manual
in Chapter 3, «Initial Operation».

Installing the Lens (Not for Hemispheric Variants with Lens B016)

The steps listed below are only required if the p26 has been ordered with separate lens for self-mounting (see «Variants of the p26»).

1. Remove the blind cover

Remove the blind cover that protects the image
sensor during shipping from the lens mount.
This should be done in a relatively dust-free
environment.

2. Install the lens

Screw the lens into the lens mount. Depending
on the physical length of the lens, you can
use your hand and then the gray lens wrench

(item 1.9). Aer initial operation of the camera,

remember to adjust the focus of the lens (see
«Initial Operation of the p26» on page 2).

Removing/Installing the Back Cover

The steps listed below are only required if you need to access the inside of the camera housing. Make sure the power supply to the camera is discon-

nected before opening the housing!

Caution: In order to avoid damage from electrostatic discharge, you should touch a grounded device before opening the housing of the camera (e.g., the

blank metal at the back of a computer). This will remove any static electricity that may have built up.

1. Remove the cover

Insert a small screwdriver into one of the holes

at the side as shown in the gure and gently

press inward to release the lock. Repeat the

process for the two other locks and li the

back cover from the housing.

2. Follow the procedures

Follow the procedures for the work inside the
housing as described in the sections listed
below:

•

➔

Inserting/Exchanging the SD Card

•

➔

Installing the Mx-A-IOA-IC

3. If required, enlarge the cable guide

If the cable guide is not large enough for addi­tional cables, enlarge the guide accordingly.
Depending on the size required, break out either
one or two elements of the cable guide using

pliers (see blue markings in the gure).

4. Attach back cover

Insert the back cover, so that the large arrow

(highlighted blue in the gure) is positioned

in the viewing direction of the camera. Make
sure the cables and wires are guided properly
thought the cable guide, then carefully press
the back cover into the housing until it clicks
into place.

Inserting/Exchanging the SD Card

All camera models can use the integrated MicroSD card to record video data. In order to exchange the MicroSD card, please proceed as outlined in the
following instruction. For information on reliable SD cards, please see the MOBOTIX website www.mobotix.com > Support > Download Center > Docu-
mentation > White Lists in the document MicroSD Card Whitelist for MOBOTIX Cameras.

When replacing the SD card, make sure that recording has been deactivated in the browser (Admin Menu > Storage > Storage on External File Server /
Flash Device; activate recording again in the same dialog). Follow the instructions in section «Removing/Installing the Back Cover» to access the inside

of the camera and to close it again aer inserting the SD card.

1. Remove the SD card

If a MicroSD card has been installed, gently

press with your nger as indicated by the arrow

until you hear a click. Then release the SD
card. The card is protruding slightly and can

2. Insert the SD card

Insert the MicroSD card and gently press with

your nger as indicated by the arrow until you

hear another click.

Make sure that the SD card is fully inserted.

be easily removed.

Installing the Mx-A-IOA-IC

For the Mx-p26A/B, you can use the optionally available Mx-A-IOA-IC to attach external sensors using the signal inputs and
to switch other devices via the signal outputs. When used with the the Mx-p26B, you can also attach MxBus devices (e.g., an
MX-GPS-Box). To facilitate the installation of the module, you should attach the connection wires before inserting the module.

Follow the instructions in section «Removing/Installing the Back Cover» to access the inside of the camera and to close it again

aer inserting the module.

1. Attach the connection cables

Attach the connection cables as shown in the terminal connector overview.

2. Insert the Mx-A-IOA-IC

Hold the Mx-A-IOA-IC with attached connection
wires over the receptacle on the main board

Terminal Connectors

MxBus connectors

MxBus functionality is only supported

by the camera variant Mx-p26B.

(red arrow in gure).

Use one nger to carefully press the board of

the module onto the receptacle. Make sure that
the green terminal connector block is pointing

Output 1 A

Output 1 B/GND

Output 1 12 V –

Output 2 A

Output 2 B/GND

Output 2 12 V –

Input 1 –

Input 1 +

Input 2 –

Relay

pot.-

free

Relay

pot.-

free

–

Output 1

12 V

–

Output 2

12 V

Inputs

Outputs

upward (towards the SD card, see red arrow

in gure below).

Make sure that the Mx-A-IOA-IC is fully inserted.

Please also make sure that the connection
wires are guided through the housing without
tension and in a loop so that the cables do

not li the module out of its receptacle when
adjusting the camera tilt (see gure).

Input 2 +

Installing the p26

Screw for

locking

the cam-

era tilt

1

2

1

2

Output 1

Output 2

§

§

Use the drilling template on the back for this purpose (red circle) or draw a circle with 105 mm/4.13 in diameter for the cut­out. Cut out the hole for the camera, then guide the cables (network cable, USB cable, MxBus* and signal input/output wires)
through the hole. (*Variant Mx-p26B only.)

1. Install the p26

Press the spring clips back and insert the p26
into the hole for the camera. The spring clips

will snap outwards, thus rmly holding the

camera in place.

2. Roughly align the p26

Turn the camera until it roughly points into the
intended direction; once it is running, you will
adjust the camera according to the live image
(see «Initial Operation of the p26»).

Make sure that you only press back the spring
clips as shown in the image. Do not press them
back any further as the springs may snap out

of their xtures otherwise.

Removing the p26

1. Pull out the camera

Pull the camera from its position by gently pulling the camera downward
on one side, then the other side. Take care to NOT let the spring clips

snap forward (risk of injury!).

2. Remove the cables

Remove the cables coming from the building (network cable, USB cable
and signal input/output wires). Pull out the camera.

Initial Operation of the p26

The initial operation starts with connecting the power supply (see section «Network and Power Connection, Additional

Cables» in the M25 Camera Manual). The rst access follows the procedure described in the same manual in the section

«Initial Operation of the Camera». All other tasks require access to the camera’s user interface in the browser. Enter the
camera’s IP address into the address bar of the browser (user "admin", password "meinsm"; password must be changed

upon rst login – camera soware V5.1.x and higher).

1. Set installed lens (only when self-mounting)

Open Admin Menu > Hardware Conguration >
Lens Conguration dialog and select the installed
lens. This step is required to select the proper
special functions of the installed lens (e.g., for
wide-angle lenses).

2. Adjust lens focus (if required)

This step is only necessary if the lens has been

installed for the rst time or exchanged. In cameras

with an MX-B016 ("Hemispheric") lens, the lens
has been focused at the factory.

Check the live image from the camera in the browser.
Activate the focusing aid in the browser (Focusing
Aid quick control, Activated value).

Carefully turn the lens in clockwise or counter-clockwise direction using
the gray lens wrench until the red area of the focusing aid is as small as
possible. Remove the lens wrench every time you changed the lens focus.

Once the focus is adjusted properly, deactivate the focusing aid again
(Focusing Aid quick control, Disabled value).

3. Adjust viewing direction

Turn the image in the ceiling until the live image
shows the desired viewing direction

1

.

Stick the Allen wrench (item 1.10) into the hole
of the lock screw and loosen the screw a bit

2

.

Stick the blue screwdriver (item 1.8) into
the receptacle for adjusting the camera
tilt. Adjust the camera tilt as needed while
watching the live image of the camera 1 .

Lock the camera tilt by slightly tightening

2

the lock screw

.

4. Conguring and Using the Mx-A-IOA-IC

The camera will automatically detect an installed
Mx-A-IOA-IC (see Camera Status, System section
in browser).

The signal inputs can be used right away in the signal
input proles in the Setup Menu > Event Overview.
Likewise, the signal outputs can be used in the signal

output proles in Admin Menu > Hardware Con-
guration > Signal Out Proles.

In addition, the signal inputs/outputs have been
entered automatically in the Admin Menu > Assign Wires dialog and can
be used to control doors and lights.

To use one or both signal outputs not as potential-free outputs (for relays),
but as 12 V outputs, open the Admin Menu > Hardware Conguration >

Manage Hardware Expansions dialog. In the IO Board section, click on
Connect for each output you want to use as output.

5. Save the conguration

In the live image of the browser, select the Manage Settings quick con­trol and set Store Entire Conguration as value. The camera stores the

conguration in the permanent camera memory so that the settings will

be applied at the next camera reboot.

Important Notes

Safety Warnings

Notes on Installing:

• This product must not be used in locations exposed to
the dangers of explosion.

•

Make sure that you install this product as outlined in the instructions
of this Quick Install document. A faulty installation can damage the
camera!

• When installing this product, make sure that you are only using gen­uine MOBOTIX parts and MOBOTIX connection cables.

• Only install this product on suitable, solid materials that provide for

a sturdy installation of the xing elements used.

Electrical installation: Electrical systems and equipment may

only be installed, modied and maintained by a qualied

electrician or under the direction and supervision of a qual-

ied electrician in accordance with the applicable electrical guidelines.

Make sure to properly set up all electrical connections.

Electrical surges: MOBOTIX cameras are protected against

the eects of small electrical surges by numerous measures.

These measures, however, cannot prevent the camera from
being damaged when stronger electrical surges occur. Special care should
be taken when installing the camera outside of buildings to ensure proper
protection against lightning, since this also protects the building and the
whole network infrastructure.

Max. power consumption of attached extension modules:
The power consumption of all attached MxBus modules must
not exceed 2,5 W. When attaching modules to the MxBus
connector and the USB socket, the power consumption of all attached
modules must not exceed 3 W, if the camera is powered by PoE class 3.
If PoE class 2 is used, the power consumption of all attached modules

must not exceed 1 W!

Never touch the lens: Due to the high performance of the
p26, the area of the image sensor can get quite hot, especially
when the ambient temperature is also high. This does not

aect the proper functioning of the camera in any way. For this reason,

the product must not be installed within the reach of persons.

Power o before opening the camera: Make sure the power
supply to the camera is disconnected before opening the
camera housing (e.g., when exchanging the SD card or when
opening the body to attach wires).

Network security: MOBOTIX products include all of the nec­essary conguration options for operation in Ethernet net­works in compliance with data protection laws. The operator
is responsible for the data protection concept across the entire system.

The basic settings required to prevent misuse can be congured in the
soware and are password-protected. This prevents unauthorized parties

from accessing these settings.

Legal Notes

Legal aspects of video and sound recording: You must com­ply with all data protection regulations for video and sound
monitoring when using MOBOTIX products. Depending on
national laws and the installation location of the p26, the recording of
video and sound data may be subject to special documentation or it may
be prohibited. All users of MOBOTIX products are therefore required to
familiarize themselves with all applicable regulations and to comply with
these laws. MOBOTIX AG is not liable for any illegal use of its products.

Disposal

Electrical and electronic products contain many valuable
materials. For this reason, we recommend that you dispose of
MOBOTIX products at the end of their service life in accordance
with all legal requirements and regulations (or deposit these
products at a municipal collection center). MOBOTIX products must not be
disposed of in household waste! If the product contains a battery, please
dispose of the battery separately (the corresponding product manuals

contain specic directions if the product contains a battery).

Disclaimer

MOBOTIX AG does not assume any responsibility for damages,
which are the result of improper use or failure to comply to the
manuals or the applicable rules and regulations. Our General
Terms and Conditions apply. You can download the current version of the
General Terms and Conditions from our website at www.mobotix.com
by clicking on the COS link at the bottom of every page.

Technical Specications

Mx-p26A/B*-6Dxxx (daylight image sensor, color)

Mx-p26A/B*-6Nxxx (night image sensor, Black&White)

Model Variants

Lens Options B016 – B237 (180° to 15° hor. angle of view)

Sensitivity

Image Sensor 1/1,8“ CMOS, 6MP (), progressive scan

Max. Image Size 6MP (3072x2048)

Image Formats

Max. Frame Rate

Video Codec

ONVIF ONVIF-S (camera soware V5.0.2.x and higher)

DVR

Mx-p26A/B*-AU-6D016/036 (audio package, daylight image sensor,
color)

Mx-p26A/B*-AU-6N016/036 (audio package, night image sensor,
Black&White)

*Variant Mx-p26B supports MOBOTIX MxBus modules

Color sensor (day): 0,1 lx @ 1/60s; 0,005 lx @ 1s
BW sensor (night): 0,02 lx @ 1/60s; 0,001 lx @ 1s

Freely congurable format 4:3, 8:3, 16:9 or customized format (image

cropping), e.g., 2592x1944 (5MP), 2048x1536 (QXGA), 1920x1080
(Full-HD), 1280x960 (MEGA)

MxPEG (max.): 42@HD (1280x720), 34@Full-HD, 24@QXGA, 15@5MP,
12@6MP

M-JPEG (max.): 26@HD (1280x720), 13@Full-HD, 9@QXGA, 5@5MP,
4@6MP

H.264 (max.): 25@Full-HD, 20@QXGA

MxPEG, M-JPEG, JPEG (max. output fromat 6MP)

H.264 (max. output fromat QXGA; bandwidth limitation possible)

On internal MicroSD card (SDHC installed, SDXC supported)

External on USB device

External on NAS

Full image recording regardless of live image zoom

MxFFS

Pre-alarm and post-alarm images

DVR monitoring with error notication

Soware MxManagementCenter

Image Processing

PTZ Digital pan/tilt/zoom; max. zoom 8x (continuous)

Alarm/Events

Intelligent Video Analysis MxActivitySensor, video motion analysis, MxAnalytics

Audio
(only p26 with audio
package)

Interfaces

Security

Certications

Power Supply Power over Ethernet IEEE 802.3af

Power Consumption Typ. 5 W

Power Consumption of
External Devices

Protection Classes IP20, IK06

Ambient Temperature 0 to 40 °C/32 to 104°F

Dimensions/Weight Height x diameter: 89 x 120 mm/3.5 x 4.72 in; weight: approx. 270 g

Housing PBT-30GF, white

MxLEO, backlight compensation, automatic white balance, image
distortion correction

Temperature sensor, shock detector (with rmware version 5.0.1
and higher), other sensors/IO via MxMessageSystem, notication via

email, FTP, VoIP, SIP

Microphone and loudspeaker integrated, both 16bit/16kHz (HD
wideband audio)

Recording with audio

VoIP phone, remote controlling using key codes

Ethernet 100Base-T (MxRJ45), MiniUSB (MxMiniUSB) , MxBus*

*Only variant Mx-p26B

User/group management, HTTPS/SSL, IP address lter, IEEE 802.1x,

intrusion detection, digital image signature, MxFFS

EN55022:2010; EN55024:2010; EN50121-4:2006; EN61000-6-1:2007;
EN 61000-6-2:2005; EN61000-6-3:2007+A1:2011;
EN61000-6-4:2007+A1:2011; AS/ NZS CISPR22:2009+A1:2010;
CFR47 FCC part15B

At MxBus: max. 2,5 W, at USB: max. 2.5 W, total max. 3 W

The power consumption of the camera will increase accordingly!

Dimensions/Drilling Template

Outside diameter 120 mm/4.72 in

Max. thickness
for installation

28 mm/1.1 in

Recommended

min. instal-

lation depth

50 mm/1.97 in

39 mm/1.54 in

46 mm/

1.54 in

p26-main board

Mx-A-IOA-IC

25 mm/0.98 in

Cut-out diameter Ø 105 mm/4.13 in

Outside diameter 120 mm/4.72 in

Further information on www.mobotix.com:

• Products > Indoor Cameras > p26 Indoor PT

• Support > Download Center > Documentation > Certicates & Declarations of Conformity

MOBOTIX, the MX logo, MxPEG and MxActivitySensor sare trademarks of MOBOTIX AG registered in the Euro­pean Union, the U.S.A., and other countries • Information subject to change without notice • MOBOTIX does
not assume any liability for technical or editorial errors or omissions contained herein • All rights reserved •
© MOBOTIX AG 2017
