MK-2000P Hand held Wet Core Drill
OWNER’S MANUAL &
OPERATING INSTRUCTIONS
Revision 100
Manual Part# 158490
Caution: Read all safety and operating instructions
before using this equipment. This parts list MUST
accompany the equipment at all times.
08.2012
INTRODUCTION
Congratulations on your purchase of a MK-2000P Handheld Drill. We are certain that you will
be pleased with your purchase. MK Diamond takes pride in producing the nest construction
power tools and diamond blades in the industry.
Operated correctly, your MK-2000P Handheld Drill should provide you with years of service. In
order to help you, we have included this manual. This owner’s manual contains information
necessary to operate and maintain your MK-2000P Handheld Drill safely and correctly. Please
take the time to familiarize yourself with the MK-2000P Handheld Drill by reading and reviewing
this manual before operating it.
Read and follow all safety, operating and maintenance instructions.
If you should have questions concerning your MK-2000P Handheld Drill, please feel free to call
our friendly customer service department at (800) 421-5830.
Regards,
MK Diamond
NOTE THIS INFORMATION FOR FUTURE USE:
MODEL NUMBER:
SERIAL NUMBER:
PURCHASE PLACE:
PURCHASE DATE:
NOTE: For your (1) one year warranty to be effective, complete the warranty card
(including the Serial Number) and mail it in as soon as possible.
2
TABLE OF CONTENTS
SAFETY
Safety Messages 4
Damage Prevention Message 4
General Safety Precautions 4-5
Hazard Symbols 5
California Proposition 65 Message 6
Safety Label Locations 7
Product Features 8
UNPACKING, CONTENTS and ASSEMBLY
Unpacking 9
Contents 9
Assembly 9
OPERATION
Operation 10-15
MAINTENANCE, ACCESSORIES, & TROUBLESHOOTING
Maintenance 16
Cleanup 16
Troubleshooting 17-18
Accessories 19
EXPLODED VIEW AND PARTS LIST
Exploded View & Parts List 20-29
ORDERING and RETURN INSTRUCTIONS
Ordering Information 30
Return Material Policy 30
Packaging Instructions 30
Authorized Service Centers 30
CONTACT and LIMITED WARRANTY
Contact 31
Limited Warranty 31
3
MK-2000P SAFETY
RULES FOR SAFE OPERATION
DANGER
Failure to follow instructions in this manual may lead to serious injury or even death! This equipment
is to be operated by trained and qualied personnel only! This equipment is for industrial use only.
The following guidelines should always be used when operating the core drill.
GENERAL SAFETY
• DO NOT operate or service this equipment before reading this entire manual.
Read and understand all warnings, instructions and controls on the machine.
• This equipment should not be operated by persons under 18 years of age.
• NEVER operate this equipment without proper protective clothing, shatterproof
glasses, steel-toed boots and other protective devices required by the job.
• NEVER operate this equipment when not feeling well due to fatigue, illness or taking medicine.
• NEVER operate this equipment under the inuence of drugs or alcohol.
• Whenever necessary, replace nameplate, operation and safety decals when they be come difcult
to read.
• ALWAYS check the machine for loose bolts before starting.
• ALWAYS wear proper respiratory, head, ear and eye protection
equipment when operating this machine.
• Use the right tool. Do not use a tool or attachment to do a job for which it is not recommended.
Do not alter the tool. Maintain all tools with care for the safest and best performance.
• ALWAYS store equipment properly when it is not being used. Equipment should be stored in a
clean, dry location out of the reach of children.
• ALWAYS insure that the switch is off before plugging unit into electrical power.
• NEVER leave the drill running unattended. Turn power off.
• DO NOT over reach, maintain control. Keep proper footing and balance at all times. Maintain a
rm grip.
• Should any part of this drill become missing or damaged, or any component fail to perform
properly, shut off the drill and unplug the power source. Replace the missing, damaged, and/ or
failed part before resuming operations.
4
MK-2000P SAFETY
on
CAUTION
Always keep alert. Do not allow familiarity (gained from frequent use) to cause a careless mistake. Always
remember that a careless fraction of a second is sufcient to inict serious injury.
SAFETY MESSAGE / ALERT SYMBOLS
A safety message alerts you to potential hazards that could hurt you or others. Each safety message is
preceded by a safety alert symbol ( ) and one of three words: DANGER, WARNING, or CAUTION.
DANGER
You WILL be KILLED or SERIOUSLY INJURED if you do not follow directions.
WARNING
You CAN be KILLED or SERIOUSLY INJURED if you do not follow directions.
CAUTION
You CAN be INJURED if you do not follow directions. It may also be used to alert against
unsafe practices.
Each message tells you what the hazard is, what can happen, and what you can do to avoid or
reduce injury. Other important messages are preceded by the word NOTICE.
NOTICE
You can cause PROPERTY DAMAGE to your machine if you don’t follow directions.
The safety labels should be periodically inspected and cleaned by the user to maintain good legibility
at a safe viewing distance. If the label is worn, damaged or illegible, it should be replaced. Contact
MK Diamond or your dealer for replacement.
HAzARD SYMBOLS
ELECTRICAL SHOCK
NEVER touch electrical wires or components while the engine is running. They can be
sources of electrical shock which could cause severe injury or burns.
ACCIDENTAL STARTS
Before starting the equipment, be sure the ON/OFF switch is in the “OFF” position to prevent accidental starting. Place the ON/OFF switch in the OFF position before performing
any service operation.
ROTATING PARTS
Keep hands, feet, hair, and clothing away from all moving parts to prevent injury. Never
operate the motor with covers, shrouds, or guards removed.
5
