Mitsubishi Electronics WD-62528, WD-62527, WD-52528 User Manual

Owner’s Guide

Projection Television Models

WD-52527, WD-62527

WD-52528, WD-62528

Visit our website site at

www.mitsubishi-tv.com

TV Information:

Use this space to record the model and serial numbers of your television. This information is on the back of your TV.

Model number

Serial number

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user of

the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be sufficient magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the literature accompanying the appliance.

Exercise extreme care when lifting or moving this TV. A minimum of two adults should lift or move the TV.

Portions of the advanced circuitry of this TV will sometimes operate while the TV is turned off. This allows the TV to download guide information and CableCARD™ updates. A cooling fan may switch on during these standby periods and may be heard in a quiet environment. This is normal operation. Also, the main cooling fan will operate at all times while the TV is turned on and during the lamp cool-down period just after turning off the TV (approximately one minute). This is also normal operation.

Custom cabinet installation must allow for proper air circulation around the television.

STAND REQUIREMENT

CAUTION: Mitsubishi TV models WD-52527 and WD-52528 are for use only with Mitsubishi stand models MB-52527 or MB-52528. Mitsubishi TV models WD-62527 and WD-62528 are for use only with Mitsubishi stand models MB-62527 or MB-62528. Use with other stands is capable of resulting in instability causing possible injury.

LAMP REPLACEMENT

The image on this TV is produced by a high-brightness lamp that will operate for many hours. Eventually, however, this lamp will need to be replaced. It is designed to be easily replaced by the TV owner. Front panel indicators and/or onscreen messages will assist you in determining when the lamp needs to be replaced. Please see Appendix H for details on lamp replacement.

To order a new lamp:

While Under Warranty After Warranty

Call (800) 332-2119. Please have model number, serial number, and TV purchase date available.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Call (800) 553-7278. Order lamp part number 915P028010.

NOTE TO CATV SYSTEM INSTALLER: THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM INSTALLER’S ATTENTION TO ARTICLE 820-40 OF THE NEC THAT PROVIDES GUIDELINES FOR THE PROPER GROUNDING AND, IN PARTICULAR, SPECIFIES THAT THE CABLE GROUND SHALL BE CONNECTED TO THE GROUNDING SYSTEM OF THE BUILDING, AS CLOSE TO THE POINT OF CABLE ENTRY AS PRACTICAL.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION: To assure continued FCC compliance, the user must use a shielded video interface cable with bonded ferrite cores at both ends, when using the HDMI connections.

Changes or modifications not expressly approved by Mitsubishi could cause harmful interference and would void the user’s authority to operate this equipment.

Note: The digital television is capable of receiving analog basic, digital basic and digital premium cable television

programming by direct connection to a cable system providing such programming. A security card (CableCARD) provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator’s enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

WARNING: This product contains chemicals known to the State of California to cause cancer and/or birth defects or other reproductive harm.

IMPORTANT SAFEGUARDS

Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television.

1. Read, Retain and Follow All Instructions

Read all safety and operating instructions before operating the TV. Retain the safety and operating instructions for future reference. Follow all operating and use instructions.

2. Heed Warnings

Adhere to all warnings on the appliance and in the operating instructions.

3. Cleaning

Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive or aerosol cleaners. Cleaners can permanently damage the cabinet and screen. Use a lightly dampened cloth for cleaning.

4. Attachments and Equipment

Never add any attachments and/or equipment without approval of the manufacturer as such additions may result in the risk of fire, electric shock or other personal injury.

5. Water and Moisture

Do not use the TV where contact with or immersion in water is possible. Do not use near bath tubs, wash bowls, kitchen sinks, laundry tubs, swimming pools, etc.

6. Accessories

Do not place the TV on an unstable cart, stand, tripod, or table. The TV may fall, causing serious injury to a child or adult and serious damage to the TV. Use only with a cart, stand, tripod, bracket or table recommended by the manufacturer, or sold with the TV. Any mounting of the TV should follow the manufacturer’s instructions, and should use mounting accessories recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV and to protect it from overheating. Do not block these openings or allow them to be obstructed by placing the TV on a bed, sofa, rug, or other similar surface. Nor should it be placed over a radiator or heat register. If the TV is to be placed in a rack or bookcase, ensure that there is adequate ventilation and that the manufacturer’s instructions have been adhered to.

8. Power Source

This TV should be operated only from the type of power source indicated on the marking label. If you are not sure

of the type of power supplied to your home, consult your appliance dealer or local power company.

9. Grounding or Polarization

This TV is equipped with a polarized alternating current line plug having one blade wider than the other. This plug

will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

10. Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the TV.

11. Lightning

For added protection for this TV during a lightning storm, or when it is left unattended and unused for long period of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV due to lightning and power-line surges.

IMPORTANT SAFEGUARDS, continued

ANT E N NA LE A D IN W IR E

ANT E N NA DIS C H AR GE U NIT (NE C A R T IC LE 8 10-2 0)

G R OU ND IN G C ON DU C TO R S (NE C A R T IC LE 8 10-2 1)

G R OU ND CL AM PS

P OW E R S E R VIC E G R O U NDI NG E LE CT R ODE S Y S T E M (NE C A R T 2 50, PA R T H)

G R OU ND CL AM P

E LE CT R IC S E R V IC E E QU IP ME NT

NE C — NAT IO N AL E L E C T R I C AL C O DE

E X A MP L E O F A NT E N NA G R OU N DIN G

12. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or

power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

13. Overloading

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

14. Object and Liquid Entry

Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or shortout parts that could result in fire or electric shock. Never spill liquid of any kind on or into the TV.

15. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.

Article 810 of the National Electric Code, ANSI/NFPA No. 70-2002,

provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

16. Servicing

Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17. Damage Requiring Service

Unplug the TV from the wall outlet and refer servicing to qualified service personnel under the following conditions:

(a) When the power-supply cord or plug is damaged. (b) If liquid has been spilled, or objects have fallen into the TV. (c) If the TV has been exposed to rain or water. (d) If the TV does not operate normally by following the operating instructions, adjust only those controls that are

covered by the operating instructions as an improper adjustment of other controls may result in damage and

will often require extensive work by a qualified technician to restore the TV to its normal operation. (e) If the TV has been dropped or the cabinet has been damaged. (f) When the TV exhibits a distinct change in performance - this indicates a need for service.

18. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the

manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire,

electric shock or other hazards.

19. Safety Check

Upon completion of any service or repair to the TV, ask the service technician to perform safety checks to determine that the TV is in safe operating condition.

20. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves or other products (including amplifiers) that produce heat.

Contents

Chapter 1: Television Overview

Special Features ........................................................................................................... 10

TV Accessories ............................................................................................................. 11

Remote Control Functions: Overview ........................................................................... 12

Remote Control Functions:

Operation ................................................................................................................. 13

Care ......................................................................................................................... 14

Sleep Timer ............................................................................................................. 14

Front Control Panel ...................................................................................................... 15

Front Panel Indicator Lights .......................................................................................... 16

Back Panel ................................................................................................................... 18

Chapter 2: Connecting

External Devices & NetCommand® Setup ................................................................... 22

Wall Outlet Cable or Cable Box .................................................................................... 23

CableCARD™ Technology ........................................................................................... 24

Antenna with Single Lead ............................................................................................. 25

Antennas with Separate UHF and VHF Leads ............................................................. 25

VCR to an Antenna or Wall Outlet Cable ...................................................................... 26

VCR Video and Audio to TV ......................................................................................... 26

VCR Video and Audio to a Cable Box .......................................................................... 27

A/V Receiver ................................................................................................................ 28

Satellite Receiver or Other Device with S-Video .......................................................... 28

DVD Player with Component Video .............................................................................. 29

HDTV Cable Box or Satellite Receiver with Component Video .................................... 29

HDMI Device................................................................................................................. 30

DVI Device .................................................................................................................... 30

IR Emitter NetCommand® ........................................................................................... 31

Compatible IEEE 1394 Devices .................................................................................... 32

Helpful Hints ................................................................................................................. 34

Chapter 3: NetCommand® Setup and Editing

NetCommand® Introduction ....................................................................................... 36

Using the Remote Control with NetCommand® ......................................................... 37

NetCommand® Setup On-Screen Buttons .................................................................. 38

3D Graphical Viewpoint® Menu System ...................................................................... 39

NetCommand® Initial Setup ........................................................................................ 40

Edit NetCommand®

Add an A/V Receiver .............................................................................................. 43

Add Devices ........................................................................................................... 46

Change Devices ..................................................................................................... 50

Delete Devices ........................................................................................................ 50

Finish Screen .......................................................................................................... 50

Chapter 4 : IEEE 1394 Devices and NetCommand® Controlled Recordings

IEEE 1394 Devices and NetCommand® Control ......................................................... 52

Adding IEEE 1394 Devices Automatically ..................................................................... 53

Device Selection Menu ................................................................................................. 55

Using the Device Menu Button to Display Menus ........................................................ 56

Using the GUIDE Button to Display ChannelViewTM and Menus .................................. 57

NetCommand® Controlled Peer-to-Peer Connections ................................................ 58

Direct VCR Recording from an Antenna or Cable Source ............................................ 59

A/V Disc Search ........................................................................................................... 59

Track List Screen ......................................................................................................... 59

Chapter 5: TV Menu Screen Operations

Main Menu Choices...................................................................................................... 62

Setup Menu .................................................................................................................. 63

NetCommand® Menu .................................................................................................. 65

Record Menu ................................................................................................................ 66

Channel Menu .............................................................................................................. 68

SuperQuickView™ ........................................................................................................ 69

Captions Menu ............................................................................................................. 70

V-Chip Lock Menu ........................................................................................................ 72

Audio/Video Menu ........................................................................................................ 75

A/V Settings Descriptions ............................................................................................ 76

Operation of PIP and POP ............................................................................................ 78

Chapter 6: Special Features

TV Display Formats ..................................................................................................... 80

Display Formats ........................................................................................................... 81

Device Control with NetCommand® ............................................................................ 82

Appendix A: Bypassing the V-Chip Lock ..................................................................... 85

Appendix B: Specifications .......................................................................................... 87

Appendix C: Remote Control Programming Codes ..................................................... 89

Appendix D: On-Screen Information Displays .............................................................. 92

Appendix E: NetCommand® Specialized Device Keys ............................................... 93

Appendix F: Cleaning and Service ............................................................................... 94

Appendix G: Filter Cleaning .......................................................................................... 95

Appendix H: Lamp Cartridge Replacement ................................................................. 96

Troubleshooting ............................................................................................................ 98

Trademark and License Information ............................................................................. 103

Index ............................................................................................................................. 104

Warranty ....................................................................................................................... 107

Our Thanks...

Thank you for choosing Mitsubishi as your premier Home Entertainment provider.

This Owner’s Guide describes the features and functions of your Mitsubishi

widescreen, high definition TV. We urge you to examine this Owner’s Guide to become familiar with the innovative features and operations this unique television offers.

The very core of our corporate philosophy is to provide our customers with the

very best. Our development team at Mitsubishi has worked to provide you with

a television that defines “state-of-the-art,” with the capability to meet your needs

now and in the future.

Whether this is your first Mitsubishi electronic product or an addition to your Mitsubishi collection, we believe you and your family will continue to enjoy your Mitsubishi home theater for many years.

Thank you,

Mitsubishi Digital Electronics America, Inc.

Chapter . . .

Television Overview

Special Features ...................................................................................... 10

TV Accessories ........................................................................................ 11

Remote Control Functions: Overview ................................................... 12

Remote Control Functions:

Operation ............................................................................................ 13

Care ..................................................................................................... 14

Sleep Timer ......................................................................................... 14

Front Control Panel ................................................................................. 15

Front Panel Indicator Lights ................................................................... 16

Back Panel ............................................................................................... 18

Special Features

Your new High Definition widescreen television has many special features that make it the perfect center of your home entertainment system, including:

Digital Cable Ready (CableCARD™)

Your widescreen Mitsubishi HDTV is “Plug-and-Play” ready. It can descramble a cable provider’s one-way digital signals with the use of a CableCARD security module. The CableCARD is used in place of a traditional cable box to access digital cable programming (including high definition). Contact your local cable provider for availability information and service details.

NetCommand® Home Network Control System

Your widescreen Mitsubishi HDTV offers a new level of networking to combine selected older products with new and future digital products. NetCommand supports IEEE 1394 connections, Audio Video Control system (AV/C), 5C copy protection and IR control of selected older products such as VCRs, DVD players, cable boxes or satellite receivers. NetCommand includes the ability to learn remote control signals directly from many devices, allowing you to customize the NetCommand system in a way that works best for your viewing.

16:9 Widescreen Picture Format

Enjoy a full theatrical experience in the comfort of your home. View pictures as film directors intended them. Digital TV broadcasts, DVDs and newer video game consoles support this widescreen format.

TV Guide On Screen® Interactive Program Guide

An eight-day on-screen program guide that can be used with cable, over-the-air and CableCARD™ reception. The subscription-free guide system lists regular, digital and high-def inti on programming. This system allows multiple sorting options and easy program recording. Program listings are downloaded while your TV is turned off, so that you have current program information available every day. Note that when the system is first set up, it may take up to 24 hours to begin to receive TV program listings. It may take one week to receive all eight days of TV program listings.

Chapter 1. Television Overview

TV Accessories

108&3

)0.&

1"64&

3&$

'''8%3&83&7 1-":

4501







70-6.&

*/'0

&9$)

&/5&3

57.&/6

%&7*$&

.&/6

7$)*1

'03."5

1*1$)





427



%&7*$&

4-&&1

7*%&0

"6%*0

.65&









$)"//&-

"%+645

1*1

1*1%&7*$&

$"/$&-

"6%*0

$"#-&%#4%57 %7%

7$3

(6*%&

46#

$0//&$5

1"(&

AA A

108&3

1"64&

3&$







%&7*$&

.&/6

)0.&





427



46#$"/$&-









57.&/6

(6*%&

.65&

$)

70-

3&83&7

'''8%

1-":

4501

4-&&1

*/'0

7$)*1

"6%*0

7*%&0

$0//&$5

"6%*0

$"#-&%#4%57

%7%

7$3

'03."5

1*1$)

1*1101

&9$)

1*1%&7*$&

1"(&

%&7*$&

Please take a moment to review the following list of items to ensure that you have received everything including:

For the WD-52527 or WD-62527

1. Remote Control

2. Two AAA Batteries

For the WD-52528 or WD-62528

1. Remote Control

2. Two AA Batteries

3. One Double IR Emitter Cable (allows NetCommand to control other devices)

4. Product Registration Card (not pictured)

5. Owner’s Guide (not pictured)

6. TV Guide On Screen® User’s Manual (not pictured)

7. Quick Reference Card (not pictured)

3. One Quadruple IR Emitter Cable (allows NetCommand to control other devices)

4. Product Registration Card (not pictured)

5. Owner’s Guide (not pictured)

6. TV Guide On Screen User’s Manual (not pictured)

7. Quick Reference Card (not pictured)

Chapter 1. Television Overview

Remote Control Functions: Overview

Overview

Figures on the following page

Slide Switch: Selects A/V product to be controlled by

the remote control. Select TV for NetCommand® device control.

In alphabetical order:

ADJUST: Press , , and to navigate TV Guide

On Screen®, menus, change settings, and move the PIP on-screen location. Operates many NetCommand functions.

AUDIO: Selects and adjusts individual audio settings.

CANCEL/SUB: Clears SQV and some menu entries and

cancel recordings. For digital channels, adds separator between major and sub channel numbers.

CH(ANNEL)/PAGE: Scans up or down through

memorized channels. When used with TV Guide On Screen®, cable box, ChannelView, or satellite, moves up or down one screen at a time.

CONNECT (WD-52528, WD-62528): Initiates IEEE 1394

peer-to-peer connections.

DEVICE: Displays the Device Selection menu to

select the device to view (Ant-1 and Ant-2, or devices connected to the TV’s inputs).

DEVICE MENU: Displays or removes the options menu

for TV Guide On Screen and devices connected to TV including CableCARD™, display. For VCR or DVDs the first press displays the transport menu.

ENTER(WD-52528, WD-62528): Selects a channel

number or menu item.

ENTER/EXCH (WD-52527, WD-62527): Selects a

channel number or menu item. Exchanges PIP or POP and main TV picture.

EXCH (WD-52528, WD-62528): Exchanges PIP or POP

and main TV picture.

FF/FWD: Fast forward or forward search with a VCR or

fast play a DVD.

FORMAT: Changes the shape and size of the main TV

picture.

GUIDE: Displays or removes TV Guide On Screen or

ChannelView for Ant-1 and 2. Displays Track List for A/V Disc. Displays program guide for satellite receiver, or DVD Disc menu.

HOME: Exits TV on-screen menus and the TV Guide On

Screen system and returns to TV viewing.

INFO: Displays an on-screen summary of the current

device used and any broadcast or V-Chip information available. Cycles through available Info Box Sizes in the

TV Guide On Screen system. See Appendix D for details.

Light: Located on the left side for WD-52527 and

WD-62527 and on the right side for WD-52528 and WD-62528 of the remote control, this feature illuminates buttons or labels.

MUTE: Turns sound on or off.

Numbers: Individually selects channels or enters

information into menus.

PAUSE: Freeze a live TV picture when no PIP or POP

image is displayed. When PIP or POP image is visible, pauses that image. Pauses a VCR, DVD or A/V Disc.

PIP CH: Scrolls up or down through memorized

channels for PIP source.

PIP DEVICE: Displays PIP Selection menu to select the

PIP or POP image source device.

PIP (WD-52527, WD-62527): Cycles through PIP choices.

PIP/POP (WD-52528, WD-62528): Cycles through PIP

and POP choices.

PLAY: Plays the VCR, DVD or A/V Disc.

POWER: Turns power on and off for TV and other A/ V

products.

QV (QuickView™): Switches between the current

channel and last channel viewed.

REC (Record for WD-52528, WD-62528): Records

with a VCR, sets up recordings for DVCR, IEEE 1394 devices, or while in ChannelView. When Listings screen for TV Guide On Screen is displayed, will start a recording.

REC/CONNECT (WD-52527, WD-62527): Records

with a VCR, sets up recordings for DVCR, IEEE 1394 devices, or while in ChannelView. Also initiates IEEE

1394 peer-to-peer connections. When Listings screen

for TV Guide On Screen is displayed, will start a recording.

REW/REV: Rewinds or reverses search with a VCR.

Reverses scan with a DVD or A/V Disc.

SLEEP: Sets the TV to turn off within 2 hours. See page

14 for setup instructions.

SQV (SuperQuickView™): Scans through memorized

lists of favorite channels.

STOP: Stops a VCR, DVD or A/V Disc.

TV MENU: Displays on-screen menu system.

V-CHIP: Turns On or Off the V-Chip Lock.

VIDEO: Selects and adjusts individual video settings.

VOLUME: Changes sound level.

Chapter 1. Television Overview

Remote Control Functions: Operation

"MLBMJOF CBUUFSJFT

108&3

)0.&

1"64&

3&$

'''8%3&83&7 1-":

4501







70-6.&

*/'0

&9$)

&/5&3

57.&/6

%&7*$&

.&/6

7$)*1

'03."5

1*1$)





427



%&7*$&

4-&&1

7*%&0

"6%*0

.65&









$)"//&-

"%+645

1*1

1*1%&7*$&

$"/$&-

"6%*0

$"#-&%#4%57 %7%

7$3

(6*%&

46#

$0//&$5

1"(&

108&3

1"64&

3&$







%&7*$&

.&/6

)0.&





427



46#$"/$&-









57.&/6

(6*%&

.65&

$)

70-

3&83&7

'''8%

1-":

4501

4-&&1

*/'0

7$)*1

"6%*0

7*%&0

$0//&$5

"6%*0

$"#-&%#4%57

%7%

7$3

'03."5

1*1$)

1*1101

&9$)

1*1%&7*$&

1"(&

%&7*$&

33 22

Operation

Installing the Batteries:

WD-52527 & WD-62527 Remote

13 26

8 7

15 34

21 27

2 35

5 12

19 24

WD-52528 & WD-62528 Remote

1. Remove the remote control’s back cover by gently pressing the ribbed tab in the direction of the arrow and sliding off the cover.

2. Load the batteries, making sure the polarities (+) and (-) are correct. For best results, insert the negative (-) side first. AAA batteries are used with the WD-52527 and WD-62527. AA batteries are used with WD-52528 and WD-62528.

Operation: Installing the Batteries

Chapter 1. Television Overview

Remote Control Functions: Care and Sleep Timer

Sleep Timer

Setting the Sleep Timer:

1. Press SLEEP on the remote control.

2. Each press of SLEEP increases the time displayed by

30 minutes, until the maximum value of 120 minutes is reached.

3. After 5 seconds of inactivity, the message will

disappear.

4. Press SLEEP to view the remaining time before the

timer turns the TV off.

Canceling the Sleep Timer:

1. Press SLEEP to display the on-screen message.

2. Press SLEEP repeatedly until OFF is displayed.

Note: After 5 seconds of inactivity, the message

box disappears.

Hint: If the remote is in the TV layer and the TV will not

function, press POWER and 935 to reset the remote.

Care

For Best Results from the Remote Control:

• Be within 20 feet of the equipment.

• Do not press two or more buttons at the same time unless instructed.

• Do not allow unit to get wet or become heated.

• Avoid dropping on hard surfaces.

• Do not use harsh chemicals to clean. Use only a soft, lightly moistened cloth.

• Do not mix new and old batteries.

• Do not heat, take apart or throw batteries into fire.

• Use only alkaline batteries.

Chapter 1. Television Overview

Front Control Panel

*/165

47*%&07*%&0-  "6%*0 3

 

DEVICEGUIDE

CANCEL

ENTER

MENUFORMAT

– CH –

ADJUST

– VOL –

< >

POWER

SYSTEM

RESET

LAMP STATUS TIMER

ENTER

– CH –

ADJUST

– VOL –

< >

POWER

SYSTEM

RESET

LAMP STATUS TIMER

The buttons on the Front Control Panel highlighted are duplicated on the remote control. The top row of labels shows

the control functions when there are no TV menus displayed on the screen. The bottom row of labels shows the control functions when the TV menus are displayed on the screen or when a special function has been activated. See “Remote Control Overview” for further details on the functions of these buttons.

System Reset

If the TV will not respond to either the remote control or the front panel controls and/or will not power Off, press the SYSTEM RESET button with a pointed item like the end point of a paperclip. The TV will turn Off and the TIMER light will flash quickly for about one minute. When the TIMER light stops flashing, you may again turn on the TV. The changes you made the last time the TV was on before you used the SYSTEM RESET button may be lost, however, the changes that were previously saved are not lost.

A/V Reset

There may be times when you wish to reset the A/V (Audio and Video) settings back to the factory defaults. To return all of the settings at once, press GUIDE and FORMAT on the front panel at the same time. To reset the defaults for individual devices, use the A/V Memory Reset selection on the Audio/Video menu.

Input 3

This input can be used for convenient connection of a camcorder or other video device to the TV. Please note that if you connect to the S-VIDEO terminal, the VIDEO terminal is deactivated. The VIDEO terminal is active when there is no S-Video connection.

IMPORTANT

Portions of the advanced circuitry of this TV must continue to operate even when the TV is turned off. Some of these circuits therefore may need to be cooled at times during standby. A low power standby fan may switch on and be heard in a quiet environment. This is normal operation.

Chapter 1. Television Overview

Front-Panel Indicator Lights

DEVICEGUIDE

CANCEL

ENTER

MENUFORMAT

– CH –

ADJUST

– VOL –

< >

POWER

SYSTEM

RESET

LAMP STATUS TIMER

Indicators

Refer to the following tables for explanations of the front-panel indicator lights.

Power/Timer Indicator

Indicator Color TV Condition Additional Information

None (indicator off) TV is powered OFF. Normal operation.

Green, steady TV is powered ON. Normal operation.

Green, rapid blinking 1. TV just plugged into AC outlet. Wait until blinking stops before turning on

(approximately 1 minute). Normal operation.

2. AC just restored after power failure. Wait until blinking stops before turning on (approximately 1 minute). Normal operation.

3. TV Rebooting after System Reset

used.

4. TV Rebooting after power

fluctuation or receiving abnormal digital signals from digital channel, CableCARD™, or digital device.

5. You have begun the procedure to

update software from an authorized flash memory device.

Green, slow blinking TV powered off and automatic on-

timer is set.

Wait until blinking stops before turning on (approximately 1-2 minutes). Normal operation.

Wait until blinking stops before turning on (approximately 1 minute). Normal operation.

For detailed information, see the instructions that accompany the authorized software update. Important: Do not use non-authorized software at any time.

Normal operation. TV can be turned on at any time.

Lamp Indicator

Indicator Color TV Condition Additional Information

None (indicator off) Normal TV on or standby condition. Normal operation.

Green, rapid blinking TV just powered off and lamp is

cooling.

Yellow, steady Lamp nearing end of useful life. This is a recommendation to have a new lamp ready

Yellow, blinking 1. Lamp access door is open or not

secure.

2. No lamp installed. TV will not operate without a lamp. See Appendix H

Red, steady Lamp no longer illuminates and has

reached the end of the lamp life.

Chapter 1. Television Overview

Begins to blink 30 seconds after turning off TV. TV can be turned on before it begins to blink or after the blinking stops, but not while the indicator is blinking. Normal operation.

before the current lamp stops illuminating. See Appendix H for ordering information.

TV will not operate until lamp access door is secure. See Appendix H for installation information.

for installation information.

Replace the lamp. The TV will not operate when the lamp no longer illuminates. See Appendix H for installation information.

Front-Panel Indicator Lights, continued

Status Indicator

Indicator Color TV Condition Additional Information

None (indicator off) Normal TV on or standby condition. Normal operation.

Yellow, steady 1. Operating temperature is too high,

dust filter may need cleaning.

2. Room temperature is too high. TV will not operate when the ambient room

Yellow, blinking Dust filter cover is not in place or not

secure.

Red, either steady or blinking

TV may require service. Turn off the TV and unplug the set from the AC power

See appendix G concerning dust filter cleaning. TV will not operate when the dust filter is clogged and internal temperature rises too high.

temperature is too high. Turn off the TV and wait until the room temperature drops.

TV will not operate until the dust filter cover is securely in place.

source. Wait one minute and then plug the set back in.

If the LED is still on, contact your dealer or a Mitsubishi Authorized Service Center. See www. mitsubishi-tv.com or call 1-800-332-2119 to receive Authorized Service Center information.

Chapter 1. Television Overview

COMPONENT

YPbPr (480i/480p/720p/1080i)

INPUT

S-VIDEO

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIORIGHT

DTV/CABLE/

VHF/UHF

/ANT1 MAIN

ANT 2 / AUX

DIGITAL

AUDIO

OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

AUDIO-

LEFT/

(MONO)

AUDIORIGHT

OUTPUT

AUDIO

OUTPUT

RECORD OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIORIGHT

SER

VICE

POR

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

IEEE 1394

INPUT/

OUTPUT

Net Command

IR EMITTER

',INK

INPUT





 

 











USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

Back Panel

WD-52527 WS-62527

1. Antenna (ANT-1 MAIN, ANT-2 AUX)

ANT-1 MAIN and ANT-2 AUX can each receive both digital and analog over-the-air channels from a VHF/UHF antenna or non-scrambled digital/analog cable channels.

Your primary viewing signal source should be connected to ANT-1 MAIN. ANT-1 MAIN must be used to view premium subscription cable TV service authorized by the CableCARD™ access card. The CableCARD access card is provided by your local cable company. ANT-2 AUX can continue to receive over-the-air or non-scrambled cable signals.

2. IR Emitter-NetCommand

Two jacks are provided for connecting IR emitters. IR Emitters connected to these jacks are used by the NetCommand system of the TV to control external analog devices such as VCRs, DVDs, cable boxes, satellite receivers and audio receivers.

3. Input-1, -2

Input 1 and 2 can be used for the connection of a VCR, Super VHS (S-VHS) VCR, DVD player, standard satellite receiver or other A/V device to the TV. Please note that if S-VIDEO and VIDEO are available for the video input, you must choose to connect only one. They cannot both be connected at the same time.

4. Component-1, -2 Inputs YPbPr (480i/480p/720p/1080i)

Component-3 is available on WD-52528 and WD-62628.

receiver or compatible video game system. Please see Appendix B for signal compatibility.

These inputs can be used for the connection of devices with component video outputs, such as a DVD player, external HDTV

5. HDMI™

The HDMI™ (High Definition Multimedia Interface) supports uncompressed standard and high definition digital video formats and existing digital PCM audio formats. If using a cable box, the HDMI input supports both video and audio using a single cable.

Chapter 1. Television Overview

Back Panel, continued

COMPONENT

YPbPr (480i/480p/720p/1080i)

INPUT

S-VIDEO

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIORIGHT

DIGITAL

AUDIO

OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

AUDIO-

LEFT/

(MONO)

AUDIO-

RIGHT

OUTPUT

AUDIO

OUTPUT

RECORD OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIO-

RIGHT

SERVICE

PORT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

IEEE 1394

INPUT/

OUTPUT

Net Command

IR EMITTER

',INK

INPUT





 

 











DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

WD-52528 WD-62528

Use this input to connect to EIA/CEA-861 compliant devices such as a high definition satellite receiver, cable box, or DVD player. This input supports 480i, 480p, 720p and 1080i video formats. It is not intended for use with personal computers or devices outputting video signals at computer resolutions, such as SVGA or XGA.

This input can also be used as a DVI connection with separate analog audio inputs. An optional HDMI-to-DVI adaptor or cable will be necessary to make this connection and may be available from your local electronics retailer. When using the optional HDMI-to-DVI adapter, the DVI analog audio inputs on your TV allow you to receive left and right audio from your DVI device.

This input is High-Bandwidth Digital Copy Protection compliant (HDCP).

6. Output: Audio Output, Record Output

AUDIO OUTPUT sends analog audio of the program currently shown on the screen to an A/V surround sound receiver or stereo system. Digital audio from digital channels, FireWire® (DTV Link/IEEE 1394) devices and HDMI devices is converted to analog audio by the TV. If you do not have a digital A/V receiver, this should be the only audio connection between the TV and your analog A/V receiver or stereo system.

RECORD OUTPUT sends analog audio and video to a VCR for recording purposes. These signals may not be the same as those of the program that is currently being shown on screen. Signals from digital channels and FireWire (IEEE 1394) devices are converted to analog signals. There is no video signal when copy restrictions are in effect. Audio alone is output when Component 1, 2, or 3, or the HDMI input is selected for recording.

7. Service Port

This input is for use by Authorized Mitsubishi Servicers only or for authorized software updates.

8. DVI Analog Audio

Unlike HDMI, DVI does not carry audio information on the same cable. Use these analog stereo audio inputs when using the HDMI input with a device that outputs DVI instead of HDMI.

Chapter 1. Television Overview

Back Panel, continued

9. DTV Link/IEEE 1394

These jacks allow the TV to connect to external IEEE 1394 digital products by means of a single cable. Two jacks are provided for this purpose, allowing for a high degree of flexibility in connecting your NetCommand®-controlled system. Detailed information regarding IEEE 1394 connection requirements are in Chapter 4.

10. CableCARD™ Slot

The CableCARD access card provided by your cable TV service provider is inserted into this slot. The top of the card should face up as indicated by the direction of the CARD TOP arrow. When you use the CableCARD Slot, you must connect the cable to ANT-1.

CableCARD is a nationwide standard system that allows your local cable TV provider to supply you with an access card customized to your account. This card allows the TV to receive, decode and unscramble the premium digital channels included in your cable TV subscription without the use of a cable box. See page 22 for additional CableCARD information and activation instructions.

If your cable company is not currently offering CableCARD access cards, you will need to use a cable box provided and authorized by your local cable company to view scrambled channels.

11. Digital Audio Output

This output sends Dolby® Digital or PCM digital audio to your digital A/V surround sound receiver. Analog audio from analog channels and devices is converted by the TV to PCM digital audio. In most cases, this should be the only audio connection between the TV and your A/V receiver. If you have MP3 audio sources, however, you need to connect the TV’s analog AUDIO OUTPUT (left and right) to your A/V receiver.

A Note About Temporary Residual Images

Prolonged display of stationary images on your TV may cause faint, residual “ghost” images to be visible when viewing other programs. THIS EFFECT IS TEMPORARY. The residual images will disappear within days or weeks. Most TV and DVD programming is of generally uniform brightness and will not produce this effect.

To prevent the appearance of residual images:

• Avoid display of stationary images for extended periods on this or any other LCD projection TV. Examples of such images include:

∙ Stationary images that may be part of video games and web pages ∙ Bright, stationary icons overlaid on moving video ∙ Side bars displayed with narrow-format video (see definition on page 80) ∙ Top and bottom bars displayed with letter-box video (see definition on page 80)

• Mix regular TV and video programming with uses that display stationary images.

Chapter 1. Television Overview

Chapter . . .

Connecting

External Devices & NetCommand® Setup ........................................... 22

Wall Outlet Cable or Cable Box ............................................................. 23

CableCARD™ Technology ...................................................................... 24

Antenna with Single Lead ...................................................................... 25

Antennas with Separate UHF and VHF Leads ..................................... 25

VCR to an Antenna or Wall Outlet Cable............................................... 26

VCR Video and Audio to TV .................................................................... 26

VCR Video and Audio to a Cable Box .................................................... 27

A/V Receiver or Stereo System ............................................................. 28

Satellite Receiver or Other Device with S-Video ................................. 28

DVD Player with Component Video ....................................................... 29

HDTV Cable Box or Satellite Receiver with Component Video .......... 29

HDMI Device ............................................................................................ 30

DVI Device ................................................................................................ 30

IR Emitter NetCommand® ..................................................................... 31

Compatible IEEE 1394 Devices .............................................................. 32

Helpful Hints ............................................................................................ 34

Connecting External Devices and NetCommand® Setup

Model

M-VR800 &

M-VR1000

Model

M-VR900 &

M-VR700

Model

Lifestyle®28

Model

AVR-2700

Model

DTR-9.1

Model

VR-2080

Model

SR8200

Model

VSX-D557

Model

VSX-49TX

Model

RSX-1065

Model

STR-DE825

Model

RV-X2095

Model

RX-V2200

Device Audio Output to AV Receiver Inputs by Name

VCR

VCR 1 VCR VCR VCR-1 Video 1 Video 1 VCR1

VCR/Tape

VCR 1/DVR Video 2 Video 1 VCR 1 VCR 1

Satellite Receiver Aux

Cable/DBS AUX CD Video 3 Video 3 DSS CD SAT Video 4 TV/DBS TV/DBS D-TV/LD

DVD Player

DVD DVD (built-in) DVDVDP DVD Video 4 DVD LD/SAT DVD/LD Video 5 TAPE/MD CD DVD

TV Monitor Output (& Digital Audio)

TV TV TV TV/DBS Video 4 Video 4 TV DVD/TV TV Video 1 DVD/LD DVD/LD CBL/SAT

Chart 2

Mitsubishi 1 Mitsubishi 2 Bose Denon Integra Kenwood Marantz Pioneer 1 Pioneer 2 Rotel Sony Yamaha 1 Yamaha 2

FJUIFSBOBMPHTUFSFPPS EJHJUBMDPBYJBMBVEJPDBCMFT

"7

SFDFJWFS

*3&NJUUFST

WJEFPBOETUFSFP

BVEJPDBCMFT

EFWJDFUPCF

DPOOFDUFE

TUFSFPBOEPS

EJHJUBMBVEJPDBCMFT

NetCommand is able to control many current audio and video devices by sending remote control signals from the TV to each device through IR emitters. Additionally, it is also able to learn the remote control signals used by most audio

video devices not already in the TV’s memory. NetCommand can automatically switch the TV and compatible or

learned Audio/Video (A/V) Receivers to the correct input used with each device. It is important that the inputs on the

TV and A/V receiver back panels match the NetCommand setup that is displayed on-screen.

To simplify the installation of NetCommand, there is a step-by-step on-screen NetCommand Setup procedure in this chapter, which details the type and brands of devices you are connecting to the TV. The NetCommand Setup also

assigns preset TV and A/V receiver inputs for each device. You should connect each device to the TV input (both audio and video) and to the A/V receiver (audio) as shown in the figure below.

The following charts show which preset inputs you should use on the TV and A/V receiver. Chart 1 shows TV inputs. Chart 2 shows the A/V receiver inputs used by A/V receiver models already known by NetCommand. Only audio

should be connected to the A/V receiver.

Chart 1

Default Device Audio and Video Outputs to TV Inputs

Cable for CableCARD™ Service ANT-1

Antenna/Cable (digital/analog) ANT-1 if primary viewing source,

ANT-2 if secondary viewing source

Cable box Component-1

VCR Input-1

Satellite Receiver Input-2

Camcorder Input-3 (on front panel)

DVD Player Component-2

After using NetCommand Setup, you may go to the NetCommand menu at any time to change the inputs you used for connecting each device, custom name devices, add devices not included in the presets above or delete devices no longer used. See Edit NetCommand. See Helpful Hints, at the end of this chapter for additional information on device setup.

Chapter 2. Connecting

Connecting a Wall Outlet Cable or Cable Box

$BCMF$"3%5.4-05

DPWFSSFNPWFE

DIGITAL

AUDIO

OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

57CBDLQBOFMTFDUJPO

1SJNBSZ 8BMM0VUMFU $BCMF



0QUJPOBM4FDPOEBSZ "OUFOOBPS$BCMF

DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

DTV/C BLE/

VHF/UHF

ANT 1 / MAIN

ANT 2 / A

*ODPNJOH

$BCMF

065

5808":41-*55&3



$BCMF#PY

CBDLQBOFMTFDUJPO

065











57CBDLQBOFMTFDUJPO

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

Wall Outlet Cable

(can be used with a CableCARD™)

Figure 1

It is very important to connect the incoming cable for your primary viewing source to ANT-1, especially for CableCARD™ use.

1. Connect the primary incoming coaxial lead cable to ANT-1 MAIN on the TV back panel.

2. For an optional secondary antenna source, connect an antenna (or cable) to ANT-2 AUX.

3. If you have subscribed to a CableCARD™ service, the

CableCARD can now be inserted into the CableCARD SLOT. Using a Phillips screwdriver, remove the CableCARD cover screws. Insert the CableCARD, then replace the cover and screws. Additional CableCARD information is on page 20.

Standard Cable Box

(analog cable box, other than an HDTV cable box, compatible with PIP/POP)

Figure 2 3 coaxial cables and one two-way RF splitter are required.

These are not included with the TV.

Note: See page 29 to connect an HDTV cable box.

1. Connect the incoming cable to IN on an RF splitter.

2. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the TV back panel.

3. Connect one coaxial cable from OUT on the RF splitter to IN on the analog cable box.

4. Connect one coaxial cable from OUT on the cable box to ANT-2 AUX on the TV back panel.

5. After the cable box is connected to ANT-2 AUX as shown, open NetCommand and go to the RF Connection for Cable screen and do the following:

a. Check the RF check box.

b. For antenna, select ANT-2.

c. For Channel, select the channel to which the

TV must be tuned for your cable box. The

default channel is 3.

Figure 1. Wall Outlet Cable

Additional connection cables are

not provided with the TV. They are available at most electronic stores.

IMPORTANT

When this setup is complete, you can use the TV remote control to change channels on the cable box.

RF split ter

Figure 2. Connecting a Cable Box

Note: To use a cable box connected to ANT-2 as shown above, you must make the noted NetCommand changes. The changes are required to change the NetCommand cable-box default connection (Component-1) to the actual connection (ANT-2).

Chapter 2. Connecting

Please call XYZ Cable at xxx-xxx-xxxx to activate cable service.

They will need these numbers: Host ID X-XXX-XXX-XXX-XXX CableCARDTMID: X-XXX-XXX-XXX-XXX

See owner's manual for further information

CableCARD™ Technology

CableCARD Technology

CableCARD is a nationwide system standard that allows your local cable TV provider to supply you with an access card customized to your account. This card allows your TV to receive, decode and unscramble the premium digital channels included in your cable TV subscription, without the use of a cable box. It also allows your cable provider to automatically update and change your subscription. When you move to a new cable provider’s area, you simply return the CableCARD to the original cable provider and get a new card from your new cable provider.

Please note that CableCARD is a new technology and your local cable provider may not currently be offering this service. As time passes, this system will become broadly supported by most cable providers.

The CableCARD system is “unidirectional” which means your cable provider can send updates to the access card and TV, however, the TV cannot send back signals such as requests for Video-On-Demand or Pay-per-View request by remote control.

Digital cable channels authorized by the CableCARD will be available on the FireWire® IEEE 1394 network and can be shared by other products on the network. Some digital channels or programs may not be copied or recorded because of copy restriction limits set by the content owners or copyright holders.

Using a CableCARD

After inserting a CableCARD into the TV back panel CableCARD slot and powering On the TV, the initialization process begins. An initial screen will automatically display for a few minutes, with information that your Cable Provider will need in order to start service. Please write down this information before calling your cable provider.

An example of an initial screen is shown here. Your screen will display specific information from your cable provider and may not look exactly like this screen.

If you were unable to write down the information, you can press TV MENU on the remote and then enter the number 999 and the screen will re-display. You can also press DEVICE MENU when the CableCARD is the selected source and you will be able to select the startup application.

The digital television is capable of receiving analog basic, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card (CableCARD) provided by your cable operator is required to view encrypted digital programming. Certain advanced and interactive digital cable services such as video-on-demand, a cable operator’s enhanced program guide and data-enhanced television services may require the use of a set-top box. For more information call your local cable operator.

Please see page 20 for instructions on how to insert the CableCARD.

Chapter 2. Connecting

IMPORTANT

To use a CableCARD, the primary incoming

cable must be connected to ANT-1 MAIN.

0IN 'MBU5XJO

-FBE

0QUJPOBM0IN

UP0IN

.BUDIJOH5SBOTGPSNFS

0IN $PBYJBM

$BCMF







57CBDLQBOFMTFDUJPO

DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

&YUFSOBM "OUFOOB PS$BCMF

#BDL

4JEF

'MBU5XJO-FBE

6)'"OUFOOB

$IBOOFMT

7)'"OUFOOB

$IBOOFMT

0INUP

0IN

$PNCJOFS

'MBU5XJO-FBE

6)'

7)'





57CBDLQBOFMTFDUJPO

DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

Connecting an Antenna with a Single Lead or Antennas with Separate UHF and VHF Leads

Antenna with Single Lead

(not for use with CableCARD™)

Figure 3 A 300-Ohm to 75-Ohm transformer is required. This is not

included with the TV, but is available at most electronics stores.

For antennas with flat twin leads

1. For an antenna with flat twin leads, connect the 300-Ohm twin leads to the 300-Ohm to 75-Ohm transformer.

2. Push the 75-Ohm side of the transformer onto ANT-1 MAIN on the TV back panel.

For cable or antenna with coaxial lead

3. Connect the coaxial lead directly to ANT-1 MAIN on the TV back panel.

Antennas with Separate UHF and VHF Leads

Figure 4

A UHF/VHF combiner is required. This is not included with

the TV.

1. Connect the UHF and VHF antenna leads to the UHF/VHF combiner.

2. Push the combiner onto ANT-1 MAIN on the TV back panel.

Figure 3. Connecting a Single Antenna

Mitsubishi strongly recommends you avoid using antennas with flat twin leads. Flat twin lead antenna wires are subject to interference which may adversely affect the performance of the TV. We recommend using coaxial antenna cable.

Figure 4. Connecting separate UHF and VHF Antennas

Chapter 2. Connecting

Connecting a VCR to Antenna or Wall Outlet Cable





57CBDLQBOFM

"UUBDIPOMZPOFDBCMFUZQF

47JEFPSFDPNNFOEFEJGBWBJMBCMF

)46





7$3CBDLQBOFM

*GZPVS7$3IBTBWJEFPDIBOOFM PS3'0/0''TXJUDITFUJUUP0''









065

5808":41-*55&3

*ODPNJOH$BCMF









COMPONENT

YPbPr (480i/480p/720p/1080i)

INPUT

S-VIDEO

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIO-

RIGHT

DIGITAL

AUDIO

OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

AUDIO-

LEFT/

(MONO)

AUDIO- RIGHT

OUTPUT

AUDIO

OUTPUT

RECORD OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIO-

RIGHT

SERVICE

PORT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

IEEE 1394

INPUT/ OUTPUT

Net Command

IR EMITTER

(-JOL

INPUT

DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

Connecting VCR Video and Audio to the TV

Connecting VCR to an Antenna or Wall Outlet Cable and Connecting VCR

Video and Audio to the TV

Figure 5 A two-way RF splitter, 3 coaxial cables, right and left audio cables and an S-Video or Video cables are required. These are not included with the TV.

1. Connect the incoming cable or Antenna to IN on the RF splitter.

2. Connect one coaxial cable from OUT on the RF splitter to ANTENNA IN on the VCR back panel.

3. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the TV back panel.

4. To use the TV speakers with the VCR, connect a set of audio cables from AUDIO OUT on the VCR back panel to INPUT-1 AUDIO-LEFT (MONO) and AUDIO-RIGHT on the TV back panel. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel. If your VCR is mono (non-stereo), connect only the white (left) cable.

5. Connect either an S-Video or Video cable from VIDEO OUT on the VCR back panel to INPUT-1 VIDEO on the

TV back panel. Only one type of video cable should

be connected. S-Video is recommended, if available.

6. For NetCommand® controlled recordings, connect a set of audio cables from AUDIO IN on the VCR back panel to RECORD OUTPUT AUDIO-LEFT (MONO) and AUDIO-RIGHT on the TV back panel. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel.

7. Complete the NetCommand controlled recordings connections by connecting a Video cable from VIDEO IN on the VCR back panel to RECORD OUTPUT

VIDEO on the TV back panel.

Figure 5. Connecting a VCR to an Antenna or Wall Outlet Cable

Note: NetCommand® will assume your VCR is connected to inputs as shown on this page. If you use any other inputs for your VCR or add a second VCR, this change must match in the NetCommand system. See Edit NetCommand... in Chapter 3 for more information.

Chapter 2. Connecting



57CBDLQBOFM

"UUBDIPOMZPOFDBCMFUZQF

47JEFPSFDPNNFOEFEJGBWBJMBCMF

)46





7$3CBDLQBOFM

*GZPVS7$3IBTBWJEFPDIBOOFM PS3'0/0''TXJUDITFUJUUP0''





065

5808":41-*55&3

*ODPNJOH$BCMF









COMPONENT

YPbPr (480i/480p/720p/1080i)

INPUT

S-VIDEO

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIORIGHT

DTV/CABLE/

DIGITAL AUDIO

OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

AUDIO-

LEFT/

(MONO)

AUDIO-

RIGHT

OUTPUT

AUDIO

OUTPUT

RECORD OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIOLEFT/

(MONO)

AUDIORIGHT

SERVICE

PORT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

IEEE 1394

INPUT/

OUTPUT

Net Command

IR EMITTER

(-JOL

INPUT

$BCMF#PY

CBDLQBOFMTFDUJPO

065











DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

Connecting VCR Video and Audio to a Cable Box

VCR Video and Audio to a Cable Box

Figure 6 A two-way RF splitter, 4 coaxial cables, right and left audio cables and an S-Video or Video cable are required. These are not included with the TV.

1. Connect the incoming cable to IN on the RF splitter.

2. Connect one coaxial cable from OUT on the RF splitter to ANTENNA IN on the cable box back panel.

3. Connect one coaxial cable from OUT on the RF splitter to ANT-1 MAIN on the TV back panel.

4. Connect one coaxial cable from OUT on the cable box to ANTENNA IN on the VCR back panel.

5. Connect one coaxial cable from ANTENNA OUT on the VCR back panel to ANT-2 AUX on the TV back panel.

6. To use the TV speakers with the VCR, connect a set of audio cables from AUDIO OUT on the VCR back panel to INPUT-1 AUDIO-LEFT (MONO) and AUDIO-RIGHT on the TV back panel. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel. If your VCR is mono (non-stereo), connect only the white (left) cable.

7. Connect either an S-Video or Video cable from VIDEO OUT on the VCR back panel to INPUT 1 VIDEO on the

TV back panel. Only one type of video cable should

be connected. S-Video is recommended, if available.

8. For NetCommand® controlled recordings, connect a set of audio cables from AUDIO IN on the VCR back panel to RECORD OUTPUT AUDIO-LEFT (MONO) and

AUDIO-RIGHT on the TV back panel. The red cable

connects to the R (right) channel and the white cable connects to the L (left) channel.

9. Complete the NetCommand controlled recordings connections by connecting a Video cable from VIDEO IN on the VCR back panel to RECORD OUTPUT

VIDEO on the TV back panel.

Note: With this connection configuration, it is possible to view live cable programs through the VCR. For best picture quality, however, always view live cable programs directly from the cable box instead of the VCR.

Figure 6. Connecting a VCR to a Cable Box

Chapter 2. Connecting

*/ */ */ */ */ */ */ */065 065 065 065

"69 $% 5"1& 5"1& 7$3 7$3 57 %7%

.0/*5037$37$357%7%

.0/*5037$37$357%7%

065

*/*/*/*/*/*/*/*/065 065

065 065

$&/5&3

46# 800'&3

'30/5463

3&$

4063$&

-*/&065

13&065

463306/%

41&",&347 .*/

'30/5

41&",&34"7 .*/

'30/5

41&",&34#7 .*/

$&/5&3 7.*/

5)*4%&7*$&$0.1-*&48*5)1"350'5)& '$$36-&401&3"5*0/*446#+&$5505)& '0--08*/(580$0/%*5*0/45)*4%&7*$& .":/05$"64&)"3.'6-*/5&3'&3&/$&"/% 5)*4%&7*$&.645"$$&15"/:*/5&3'&3&/$& 3&$&*7&%*/$-6%*/(*/5&3'&3&/$&5)"5.": $"64&6/%&4*3&%01&3"5*0/

."/6'"$563&%6/%&3-*$&/4&'30.%0-#:-"#03"503*&4-*$&/4*/( $03103"5*0/%0-#:130-0(*$"/%5)&%06#-&%4:.#0-"3& 53"%&."3,40'%0-#:-"#03"503*&4$03103"5*0/ $01:3*()5%0-#:-"#03"503*&4*/$"--3*()54 3&4&37&%

*/165

015*$"-

*/165

$0"9*"-

*/165

$0"9*"-

%*(*5"-"6%*0

48*5$)&%

6/48*5$)&%

"$7)[

505"-8"."9

"$065-&54

.*546#*4)*

"6%*07*%&03&$&*7&3

.0%&-.73

108&34611-: 108&3$0/46.15*0/

7)[ 87"

%*453*#65&%#: .*546#*4)*$0/46.&3&-&$530/*$4".&3*$" */$

"5-"/5*$#-7%."%&*/ +"1"/ /03$3044("'"#3*26&&/ +"1"/



"7*4

3*426&%&$)0$&-&$530/26&

/&1"4&/-&7&3

3*4,0'&-&$53*$4)0$,

%0/0501&/

"/5&//"

7

7

(/%

"560

45"/%#:

0''

S T

47*%&0

7*%&0

"6%*0

8"3/*/(

"73FDFJWFS3FBS1BOFM



57CBDLQBOFM

*/165

$0"9*"-



3FE

8IJUF



COMPONENT

YPbPr (480i/480p/720p/1080i)

INPUT

S-VIDEO

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIO- RIGHT

DIGITAL AUDIO OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

AUDIO-

LEFT/

(MONO)

AUDIO- RIGHT

OUTPUT

AUDIO

OUTPUT

RECORD

OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIOLEFT/ (MONO)

AUDIORIGHT

SERVICE

PORT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

IEEE 1394

INPUT/

OUTPUT

Net Command

IR EMITTER

',INK

INPUT

DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

3FE

8IJUF



6TFJG DPOOFDUJOH BOBOBMPH "7SFDFJWFS

6TFJG DPOOFDUJOHB %PMCZEJHJUBM "7SFDFJWFS

Connecting an A/V Receiver (Stereo System)



57CBDLQBOFMTFDUJPO



:$





7*%&0065

"6%*0065

"6%*0*/

8IJUF

3FE





3FE

8IJUF

BOZ4WJEFPEFWJDF

INPUT

S-VIDEO

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIORIGHT

Connecting a Satellite Receiver or Other Device with S -Video

A/V Receiver (Stereo System)

Figure 7 A coaxial digital audio cable or stereo audio cables are required.

These cables are not provided with the TV.

• To connect an analog A/V receiver:

Connect a set of stereo audio cables from OUTPUT AUDIO 2 on the TV back panel to the TV AUDIO INPUT on the back of the A/V receiver. The red cable connects to the R (right) channel and the white cable connects to the L (left) channel.

• To connect a digital A/V receiver with Dolby® Digital surround sound:

Connect one end of a digital audio cable to DIGITAL AUDIO on the back of the TV. Connect the other end to the COAXIAL DIGITAL INPUT on the back of the A/V receiver.

Satellite Receiver or Other Device with S-Video

Figure 8

An S-Video cable and audio cables are required. These are not

included with the TV.

1. Connect an S-Video cable from VIDEO OUT on the satellite receiver back panel to INPUT-2 VIDEO on the

TV back panel.

2. Connect a set of audio cables from AUDIO OUT on the satellite receiver back panel to INPUT-2 AUDIO, on the

TV back panel. The red cable connects to the R (right)

channel and the white cable connects to the L (left) channel.

Note: Refer to the Satellite Receiver Owner’s Guide for Dish Antenna connections.

Figure 7. Connecting an A/V receiver

Note: On rare occasions, an HDMI signal may be copy-restricted and cannot be output from the TV as a digital signal. This is not anticipated to be a common situation. To hear these copy-protected signals through the A/V receiver, use connections for analog A/V receivers.

Chapter 2. Connecting

Figure 8. Connecting a Satellite Receiver with S-Video

Note: NetCommand® will assume you

connected your Satellite Receiver to Input-2. If you add a second Satellite Receiver or use any other inputs for your Satellite Receiver, this change must match in the NetCommand system. See Editing NetCommand Setup in Chapter 3 for more information.

Connecting a DVD Player with Component Video

COMPONENT

YPbPr (480i/480p/720p/1080i)

AUDIO-

LEFT/

(MONO)

AUDIO-

RIGHT

7*%&0

7*%&0065

#*5453&".1$.$)463306/% $)

$&/5&3

46#800'&3463306/% '30/5 $0"9*"- 015*$"-

"6%*0065

"$*/

.*546#*4)*

%7%1-":&3

.0%&-

%%

108&34611-:7_)[ 108&3$0/46.15*0/8

.*546#*4)*%*(*5"-&-&$530/*$4

%*453*#65&%#:

+&30/*.030"% *37*/&$"

."%&*/+"1"/

".&3*$"*/$

4&3*"-/0

."/6'"$563&%

3FE

%7%CBDLQBOFM

57CBDLQBOFMTFDUJPO

8IJUF

3FE





3FE





8IJUF

5P57$PNQPOFOU :131CJOQVUT

%573FDFJWFSXJUI:1S1CDPOOFDUJPOT

7*%&0

47*%&0

7$3

$0/530-

1)0/&+"$,

3&.05&

0655057

$) $)

$"65*0/

3*4,0'&-&$53*$"-4)0$,

%0/0501&/

%*(*5"-

"6%*0065

8IJUF

3FE

4"5&--*5&*/

*/'30."/5

"6%*0

7*%&0









57CBDLQBOFMTFDUJPO

COMPONENT

YPbPr (480i/480p/720p/1080i)

INPUT

S-VIDEO

VIDEO

AUDIO- LEFT/

(MONO)

AUDIO- RIGHT

ANT 2 / AUX

DIGITAL

AUDIO

OUTPUT

CableCARD™ USE WITH ANT 1 CARD TOP

AUDIOLEFT/

(MONO)

AUDIO-

RIGHT

OUTPUT

AUDIO

OUTPUT

RECORD OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIO-

LEFT/

(MONO)

AUDIO- RIGHT

SERVICE

PORT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

IEEE 1394

INPUT/ OUTPUT

Net Command

IR EMITTER

',INK

INPUT

*ODPNJOH"OUFOOB PS$BCMF



UPBOUFOOB

DBCMFPSTBUFMMJUF

DTV/CABLE/

VHF/UHF

USE WITH

CableCARD

ANT 1 / MAIN

ANT 2 / AUX

Connecting an HDTV Cable Box or Satellite Receiver with Component Video

DVD Player with Component Video

Figure 9 Component video cables and audio cables are required.

These are not included with the TV.

1. Connect the Component Video cables from Y/Pr/ Pb VIDEO OUT on the back of the DVD player to COMPONENT-2 on the TV back panel, matching the correct connection:

• Y to Y (Green)

• Pr to Pr (Red)

• Pb to Pb (Blue)

2. Connect a set of audio cables from AUDIO OUT on the back of the DVD player to COMPONENT-2

AUDIO Input on the TV back panel. The red cable

connects to the R (right) channel, and the white cable connects to the L (left) channel.

HDTV Cable Box or Satellite Receiver with Component Video

Figure 10 A coaxial splitter, RCA component video cables, and audio cables are required. These are not included with the TV.

1. Connect the outside antenna, cable, or satellite to ANT or SATELLITE IN on the cable box or satellite receiver. See your device’s owner’s guide for instructions and cable compatibility.

2. Connect the incoming terrestrial antenna or cable (not satellite) to ANT-1 on the TV back panel (a coaxial splitter, available at most electronic supply stores, may be required to complete this installation).

3. Connect RCA-type cables from the YPrPb outputs on the DTV receiver to Component-1 on the TV back panel, matching the correct connections:

DTV Receiver to TV Back panel

• Y to Y

• Pr to Pr

• Pb to Pb

4. Connect L (left) and R (right) audio cables from the DTV receiver to Component-1 AUDIO on the TV back panel.

5. If you are using a cable-box input other than Component-1 (the default), open the NetCommand RF Connection for Cable screen (see page 49) or the Connection for [device] screen (see page 48) to change the input.

Figure 9. Connecting a DVD Player with Component Video

Note: NetCommand® will assume you

connected your DVD player to Component-2. If you add a second DVD or use any other inputs for your DVD, this change must match in the

NetCommand system. See Edit NetCommand... in Chapter 3 for more information.

See Appendix B for component video signal compatibility information.

For digital audio connections to your A/V receiver , see your HDTV Receiver and A/V receiver Owner’s Guides.

IMPORTANT

Note: To use the benefits of a digital A/V receiver, connect your cable box or satellite receiver’s digital audio out to a digital input on your digital A/V receiver.

Figure 10. Connecting an HDTV cable box or Satellite Receiver with Component Video Connections

Chapter 2. Connecting

Connecting an HDMI or DVI Device

57CBDLQBOFMTFDUJPO

)%.*3FDJFWFS

AUDIO-

LEFT/

(MONO)

AUDIO- RIGHT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

!.4

#!",%

3!4%,,)4%

46/54

!5$)/

2

,

$6)/54

%7*%&7*$&

2'"/54

%7*50)%.*$"#-&





DVI

Analog Audio

1 2

AUDIO-

(MONO)

AUDIO- RIGHT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

INPUT

LEFT/



AUDIO-

LEFT/

(MONO)

AUDIO- RIGHT

OUTPUT

AUDIO

OUTPUT

RECORD OUTPUT

DVI

Analog Audio

1 2

VIDEO

AUDIO-

(MONO)

AUDIO- RIGHT

SERVICE

PORT

MONITORLINK™/HDMI

VIDEO 480i/480p/720p/1080i

AUDIO PCM LINEAR

INPUT

LEFT/



57CBDLQBOFMTFDUJPO

HDMI Device

Figure 11

An HDMI-to- HDMI cable is required. This is not included with

the TV. It may be available at your local electronics retailer.

You can connect two HDMI devices to the TV back panel

through the HDMI connections. HDMI devices provide

video and audio through this cable, so each device

requires only one HDMI cable, no other connection is required.

DVI Device

Figure 12 A DVI-to-HDMI cable or DVI/HDMI adaptor and HDMI cable and audio cables are required. These are not included with the TV. They may be available at your local electronics retailer.

1. Connect the DVI-to-HDMI cable (recommended) (or

DVI/HDMI adaptor with an HDMI cable) from the DVI device’s back panel to the HDMI 1 or 2 connection on the TV back panel.

NOTE: If you are using a DVI/HDMI adaptor, it is

important to connect the adaptor to the DVI side for best performance.

2. Connect a set of audio cables from AUDIO OUT on

the DVI device back panel to the DVI Analog Audio INPUT 1 or 2 on the TV back panel. The red cable connects to the R (right) channel, and the white cable connects to the L (left) channel.

NOTE: The HDMI connection supports copy protection

(HDCP). Some devices require connecting to an analog input first, in order to view on-screen menus and select HDMI/DVI as the ouput. Please review your equipment instructions for HDMI/DVI connectivity and compatibility.

Figure 11. Connecting an HDMI Device

Note: This connection supports digital stereo audio, but not multi-channel surround sound. To use the digital multi-channel surround sound feature of your HDMI device, connect the device’s digital audio output directly to your A/V receiver. Refer to the owner’s guides for these devices for detailed instructions.

Chapter 2. Connecting

Figure 12. Connecting a DVI Device
