OWNER’S MANUAL

SHOGUN

Foreword

Mitsubishi Motors Europe B.V.

E09200101932

Thank you for selecting a SHOGUN as your new vehicle.
This owner’s manual will add to your understanding and full
enjoyment of the many fine features of this vehicle.
It contains information prepared to acquaint you with the
proper way to operate and maintain your vehicle for the utmost
in driving pleasure.

MITSUBISHI MOTORS Europe B.V. reserves the right to
make changes in design and specifications and/or to make
additions to or improvements in this product without obligation
to install them on products previously manufactured.
It is an absolute requirement for the driver to strictly observe
all laws and regulations concerning vehicles.

This owner’s manual has been written in compliance with
such laws and regulations, but some of the contents may
become contradictory with later amendment of the laws and
regulations.

Please leave this owner’s manual in this vehicle at time of
resale. The next owner will appreciate having access to the
information contained in this owner’s manual.

Repairs to your vehicle:
Vehicles in the warranty period:
All warranty repairs must be carried out by a MITSUBISHI
MOTORS Authorized Service Point.

Throughout this owner’s manual the words WARNING and
CAUTION appear.
These serve as reminders to be especially careful. Failure to follow
instructions could result in personal injury or damage to your vehicle.

WARNING

indicates a strong possibility of severe personal injury or
death if instructions are not followed.

CAUTION

means hazards or unsafe practices that could cause minor
personal injury or damage to your vehicle.

You will see another important symbol:

NOTE: gives helpful information.

*: indicates optional equipment.

It may differ according to the sales classification; refer to
the sales catalogue.

Abbreviations used in this owner’s manual:

LHD: Left-Hand Drive
RHD:Right-Hand Drive
M/T: Manual Transmission
A/T: Automatic Transmission

Information for station service

E09300100486

Fuel tank capacity

Fuel

Fuel requirements

Engine oil Refer to the “Maintenance” section of this owner’s manual for the SAE viscosity.
Tyre inflation pressure Refer to the “Maintenance” section for the tyre inflation pressure.

3-door models 69 litres
5-door models 88 litres

Petrol-powered vehicles

Unleaded petrol octane number (EN228)

95 RON or higher

Diesel-powered vehicles

Vehicles to comply with the Euro 4 regulation

Cetane number (EN590)

51 or higher

Vehicles to comply with the Euro 3 regulation

Cetane number

45 or higher

Refer to the “Fuel selection” for details.

Vehicles outside the warranty period:
Where the vehicle is repaired is at the discretion of the owner.

© 2007 Mitsubishi Motors Corporation

OBKX08E1

BL071501

8

Table of contents

Overview

General information

Locking and unlocking

Seat and seat belts

Instruments and controls

Starting and driving

For pleasant driving

For emergencies

Vehicle care

Maintenance

Specifications

1

2

3

4

5

6

7

8

9

Overview

LHD

Supplemental restraint system-airbag
(for driver’s seat) p. 2-58

Horn switch p. 3-78
Daytime dipper button
(meter illumination control)
p. 3-9

Instruments and Controls (Driver’s area)

Instruments p. 3-2

E00100102052

Hazard warning flasher switch
p. 3-66

Combination headlamps
and dipper switch p. 3-58
Turn-signal lever p. 3-65
Headlamp washer switch*
p. 3-76

Audio switch* p. 5-70

Front fog lamp switch*
p. 3-66
Rear fog lamp switch
p. 3-67

Electric remote-controlled
outside rear-view mirror
switch p. 4-11

Headlamp levelling switch*
p. 3-62

Sonar cancel switch*
p. 4-78

Bonnet release lever
p. 8-3

Fuse box lid p. 8-29

Fuel tank filler door release
lever p. 3

Steering wheel height adjustment p. 4-8

Windscreen wiper and washer
switch p. 3-68
Rear window wiper and
washer switch p. 3-75

Cruise control switch*
p. 4-70

Ignition switch p. 4-14

Active stability control
switch p. 4-63

Overview

RHD

Daytime dipper button
(meter illumination control)
p. 3-9

Hazard warning flasher
switch p. 3-66

Combination headlamps and
dipper switch p. 3-58
Turn-signal lever p. 3-65
Headlamp washer switch*
p. 3-76

Audio switch* p. 5-70

Active stability control
switch p. 4-63

Sonar cancel switch*
p. 4-78

Headlamp levelling switch* p. 3-62

Fuel tank filler door release lever
p. 3

Instruments p. 3-2

Supplemental restraint system-airbag
(for driver’s seat) p. 2-58
Horn switch p. 3-78

Bonnet release lever
p. 8-3

Steering wheel height adjustment p. 4-8

Windscreen wiper and washer
switch p. 3-68
Rear window wiper and
washer switch p. 3-75

Cruise control switch* p. 4-70

Ignition switch p. 4-14

Front fog lamp switch*
p. 3-66
Rear fog lamp switch p. 3-67

Electric remote-controlled
outside rear-view mirror
switch p. 4-11

Fuse box lid p. 8-29

Overview

Instruments and Controls (Instrument panel)

E00100102788

LHD

Audio* p. 5-20, 5-43
Mitsubishi Multi Communication System*

Refer to the separate “Mitsubishi Multi Communication System owner’s manual”
Front automatic air conditioning
p. 5-4

Rear window demister switch
p. 3-77

Centre accessory box* p. 5-96

Gearshift lever p. 4-23
Selector lever p. 4-25

Parking brake lever p. 4-6

Armrest (for front seats) p. 2-10
Centre console box p. 5-94
Accessory socket p. 5-83

Rear heater*/Rear air conditioning*
p. 5-15

Floor ventilators* p. 5-2

Centre information

Front passenger’s airbag OFF indication lamp p. 2-63

display p. 3-17

Transfer shift lever
p. 4-34

Cup holder (for front seats)
p. 5-99

Centre ventilators p. 5-2

Supplemental restraint system-airbag
(for front passenger’s seat) p. 2-58

Side ventilators p. 5-2

Front passenger’s airbag
ON-OFF switch p. 2-63

Glove box p. 5-93

Rear differential lock
switch* p. 4-42

Cigarette lighter*
p. 5-82
Accessory socket*
p. 5-83

Heated seat switch* p. 2-12

Overview

RHD

Front passenger’s airbag OFF indication lamp p. 2-63

Centre ventilators p. 5-2

Supplemental restraint system - airbag
(for front passenger’s seat) p. 2-58

Rear window demister switch
p. 3-77

Side ventilators p. 5-2

Front passenger’s airbag
ON-OFF switch p. 2-63

Glove box p. 5-93

Rear differential lock
switch* p. 4-42

Cigarette lighter*
p. 5-82
Accessory socket*
p. 5-83

Heated seat switch* p. 2-12

Centre information
display p. 3-17

Transfer shift lever
p. 4-34

Cup holder (for front seats)
p.5-99

Audio* p. 5-20, 5-43
Mitsubishi Multi Communication System*
Refer to the separate “Mitsubishi Multi
Communication System owner’s manual”

Front automatic air conditioning
p. 5-4

Centre accessory box* p. 5-96

Gearshift lever p. 4-23
Selector lever p. 4-25

Parking brake lever p. 4-6

Armrest (for front seats) p.2-10
Centre console box p. 5-94
Accessory socket p. 5-83

Rear heater*/Rear air
conditioning* p. 5-15

Floor ventilators* p. 5-2

Overview

LHD

Luggage compartment lamp
p. 5-88, 8-38, 8-52

Interior

Electric window control
p. 1-16

Rear personal lamps p. 5-87, 8-38, 8-51

Roof ventilators

(5-door models)* p. 5-2

Electric win­dow lock switch
p. 1-18

Central door
lock switch
p. 1-9

E00100202415

Sunglasses holder* p. 5-98

Sunroof switch*
p. 1-21

Room & map lamp p. 5-87, 8-38, 8-50
Interior lamp switch p. 5-85

Sun visors p. 5-77

Vanity mirror p. 5-78

Supplemental restraint system

- curtain airbag* p. 2-58

Seat belts p. 2-38
Adjustable seat belt anchor
(for front seats) p. 2-41

Luggage floor box p. 5-97

Cup holder (for third seat)*
p. 5-101

Head restraints p. 2-16

Inside rear-view mirror p. 4-9

Video entertainment system*
Refer to the separate “Video
entertainment system owner’s
manual”

Seat p. 2-2

Supplemental restraint system - side airbag
(for front seats)* p. 2-58

Armrest (for rear/second seat) p. 2-14
Cup holder (for rear/second seat) p. 5-99

RHD

Sunglasses holder* p. 5-98

Sunroof switch*
p.1-21

Room & map lamp p. 5-87, 8-38, 8-50
Interior lamp switch p. 5-85

Central door lock
switch p. 1-9

Electric window
lock switch
p. 1-18

Rear personal lamps p. 5-87, 8-38, 8-51

Electric window control
p. 1-16

Overview

Luggage compartment lamp
p. 5-88, 8-38, 8-52

Sun visors p. 5-77

Vanity mirror p. 5-78

Inside rear-view mirror p. 4-9

Video entertainment system*
Refer to the separate “Video
entertainment system owner’s
manual”

Seat p. 2-2

Supplemental restraint system

- side airbag (for front seats)* p. 2-58

Armrest (for rear/second seat) p. 2-14
Cup holder (for rear/second seat) p. 5-99

Cup holder (for third seat)*
p. 5-101

Head restraints p. 2-16

Roof ventilators
(5-door models)*
p. 5-2

Supplemental restraint system ­curtain airbag* p. 2-58

Seat belts p. 2-38
Adjustable seat belt anchor
(for front seats) p. 2-41

Luggage floor box p. 5-97

Overview

3-door models

Rear shelf* p. 5-101

Accessory socket p. 5-83

Luggage area

E00100400963

Jack p. 6-11
Jack handle p. 6-11
Tools p. 6-11

Securing bands of warning triangle
p. 5-107

Luggage hooks p. 5-105

5-door models

Cargo area cover* p. 5-103

Video jack*
Refer to the separate
“Video entertainment
system owner’s manual”

Side box* p. 5-97

Luggage hooks p. 5-105

Jack handle p. 6-11

Jack p. 6-11

Accessory socket
p. 5-83

Rear window washer
fluid container p. 8-12

Securing bolts of spare
wheel garnish p. 6-18

Luggage hooks p. 5-105

Tools p. 6-11

Rain sensor* p. 3-71

Windscreen wiper and washer p. 3-68

Outside (Front)

Sunroof* p. 1-21

Overview

E00100502434

Electric window control
p. 1-16

Rear side/quarter window p. 1-20
Antenna p. 5-77

Engine compartment p. 9-16
Bonnet p. 8-3

Headlamp washer*
p. 3-76

Front fog lamps*
p. 3-66, 8-36, 8-42

Locking and unlocking p. 1-7
Keyless entry system* p. 1-5

Outside rear-view mirrors p. 4-11
Approach lamps* p. 1-12

Side turn-signal lamps* p. 3-65

Front turn-signal lamps
p. 3-65, 8-36, 8-41

Position lamps p. 3-58, 8-36, 8-41

Headlamps p. 3-58, 8-36, 8-38

Overview

Outside (Rear)

E00100502564

Spare wheel p. 6-17

Rear-view camera* p. 4-84

Spare wheel garnish p. 6-18

Licence plate lamps
p. 3-58, 8-36, 8-49

Tail lamps*
p. 3-58, 8-36, 8-44

Rear turn-signal lamps*
p. 3-65, 8-36, 8-44

Rear fog lamp
p. 3-67, 8-36, 8-47

High-mounted stop lamp p. 8-36, 8-48

Rear window wiper and washer p. 3-75

Corner and back sensor* p. 4-78

3-door models 5-door models

Rear turn-signal lamps* p. 3-65, 8-36, 8-44

Stop and tail lamps*
p. 3-58, 8-36, 8-44
Stop lamps*
p. 8-36, 8-44

Reversing lamps
p. 8-36, 8-44

Backdoor p. 1-13

Fuel tank filler p. 3

Tyre inflation pressure p. 8-19
Changing tyres p. 6-16
Tyre rotation p. 8-21
Tyre chains p. 8-23

Rear turn-signal lamps* p. 3-65, 8-36, 8-44

Reversing lamps
p. 8-36, 8-44

Stop and tail lamps* p. 3-58, 8-36, 8-44
Stop lamps* p. 8-36, 8-44

General information

Fuel selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Filling the fuel tank . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installation of accessories . . . . . . . . . . . . . . . . . . . . 6

Modification/alterations to the electrical or

fuel systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Genuine parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Used engine oils safety instructions and

disposal information . . . . . . . . . . . . . . . . . . . . . . . 8

General information

N

Fuel selection

Petrol-powered vehicles

Unleaded petrol octane number (EN228)
95 RON or higher

Recommended

fuel

!

CAUTION

● For petrol-powered vehicles, the use of leaded fuel

can result in serious damage to the engine and cata­lytic converter.

● Diesel-powered vehicles to comply with the Euro 4

regulation are designed to use only diesel fuel that
meets the EN 590 standard.
Use of any other type of diesel fuel can adversely
affect the engine.

Diesel-powered vehicles

Vehicles to comply with the Euro 4 regulation
Cetane number (EN590)
51 or higher
Vehicles to comply with the Euro 3 regulation
Cetane number
45 or higher

E00200101362

OTE

● Petrol-powered vehicles have the knock control system so

that you can use unleaded petrol 91 RON as an emergent
measure in case unleaded petrol 95 RON or higher is not
available on journey, etc. In such a case, you don’t need to
adjust the engine specially.
In case of using unleaded petrol 91 RON, the engine per­formance level is reduced.

● In petrol-powered vehicles, repeatedly driving short dis-

tance at low speeds can cause deposits to form in the fuel
system and engine, resulting in poor starting and poor
acceleration.
If these problems occur, you are advised to add a deter­gent additive to the gasoline when you refuel the vehicle.
The additive will remove the deposits, thereby returning
the engine to a normal condition. Be sure to use a genuine
MITSUBISHI FUEL SYSTEM CLEANER. Using an
unsuitable additive could make the engine malfunction.
For details, please contact your MITSUBISHI MOTORS
Authorized Service Point.

● Poor quality petrol can cause problems such as hard start-

ing, stalling, engine noise and hesitation. If your experi­ence these problems, try another brand and/or grade of
petrol.
If the check engine warning lamp flashes, have the system
checked as soon as possible at a MITSUBISHI MOTORS
Authorized Service Point.

2

General information

● In diesel-powered vehicles, poor-quality diesel fuel can

cause deposits form in the injector, resulting in black
smoke and rough idling.
If these problems occur, you are advised to add a cleaning
additive to the diesel fuel when you refuel the vehicle.
The additive will break up and remove the deposits,
thereby returning the engine to a normal condition.
Be sure to use a genuine MITSUBISHI DIESEL FUEL
SYSTEM CLEANER. Using an unsuitable additive could
make the engine malfunction. For details, please contact
your MITSUBISHI MOTORS Authorized Service Point.

Filling the fuel tank

!

WARNING

● When handling fuel, comply with the safety regula-

tions displayed by garages and filling stations.

● Before removing the fuel cap, be sure to get rid of

your body’s static electricity by touching a metal
part of the car or fuel pump. Any static electricity on
your body could create a spark that ignites fuel
vapor.

● Perform the whole refuelling process (opening the

fuel tank filler door, removing the fuel cap, etc.) by
yourself. Do not let any other person come near the
fuel tank filler. If you allowed a person to help you
and that person was carrying static electricity, fuel
vapor could be ignited.

● Do not move away from the fuel tank filler until

refueling is finished. If you moved away and did
something else (for example, cleaning your wind­screen) partway through the refueling process, you
could pick up a fresh charge of static electricity.

● If the tank cap must be replaced, use only a MIT-

SUBISHI MOTORS original part.

Fuel tank capacity

3-door models: 69 litres
5-door models: 88 litres

E00200201578

3

General information

Refueling

1. Before filling with fuel, stop the engine.

2. The fuel tank filler is located on the rear right side of your
vehicle.
Open the fuel tank filler door with the release lever
located below the instrument panel.

LHD

RHD

4

General information

3. Open the fuel tank filler tube by slowly turning the cap
anticlockwise.

A- Remove

B- Close

!

CAUTION

● Since the fuel system may be under pressure,

remove the fuel tank filler tube cap slowly. This
relieves any pressure or vacuum that might have
built up in the fuel tank. If you hear a hissing sound,
wait until it stops before removing the cap. Other­wise, fuel may spray out, injuring you or others.

4. Insert the gun in the tank port as far as it goes.

!

CAUTION

● Do not tilt the gun.

5. When the gun stops automatically, do not fill with fuel
any more.

6. To close, turn the fuel tank filler tube cap slowly clock­wise until you hear clicking sounds, then gently push the
fuel tank filler door closed.

5

General information

Installation of accessories

E00200300774

We recommend you to consult your MITSUBISHI MOTORS
Authorized Service Point.

● The installation of accessories, optional parts, should only

be carried out within the limits prescribed by law in your
country, and in accordance with the guidelines fitting
instructions and warnings contained within the documents
accompanying the parts or accessories.

● Improper installation of electrical components may cause

an electrical fire if incorrectly fitted. Please refer to Modi­fication/alteration to the electrical or fuel systems section
within this owner’s manual.

● Using a cellular phone or radio set inside the vehicle with-

out an external antenna may cause electrical system inter­ference, which could lead to unsafe vehicle operation.

● Tyres and wheels which do not meet specifications must

not be used.
Refer to the “Specifications” section for information
regarding wheel and tyre sizes.

● When fitting accessories, ensure that maximum gross

vehicle weight and maximum axle weight are not
exceeded.

Important points!

Due to large number of accessory and replacement parts of dif­ferent manufactures available in the market, it is not possible,
not only for MITSUBISHI MOTORS, but also for a MIT­SUBISHI MOTORS Authorized Service Point, to check
whether the attachment or installation of such parts affects the
overall safety of your MITSUBISHI-vehicle.

Even when such parts are officially authorized, for example by
a “general operators permit” (an appraisal for the part) or
through the execution of the part in an officially approved man­ner of construction, or when a single operation permit follow­ing the attachment or installation of such parts, it cannot be
deduced from that alone, that the driving safety of your vehicle
has not been affected.

Consider also that there basically exists no liability on the part
of the appraiser or the official. Only in the case of parts (MIT­SUBISHI MOTORS original replacement or exchange parts as
well as MITSUBISHI MOTORS genuine accessories) that are
recommended and released by a MITSUBISHI MOTORS
Authorized Service Point and that are attached or installed by a
MITSUBISHI MOTORS Authorized Service Point can you
assume, that optimal safety has been provided. The same also
pertains to modifications of MITSUBISHI vehicle with respect
to the production specifications. For your own safety, in such
cases, you should only undertake modifications according to
the recommendations of a MITSUBISHI MOTORS Author­ized Service Point.

6

General information

Modification/alterations to the electrical or

fuel systems

E00200400254

MITSUBISHI MOTORS has always manufactured safe, high
quality vehicles. In order to maintain this safety and quality, it
is important that any accessory that is to be fitted, or any modi­fications carried out which involve the electrical or fuel sys­tems, should be carried out in accordance with MITSUBISHI
MOTORS guidelines.

!

CAUTION

● If the wiring interferes with any part of the vehicle

bodywork or improper installation methods are
used, i.e. protective fuses not installed, etc.), elec­tronic devices may be adversely affected, possibly
resulting in an electrical fire or other failures that
may cause an accident.

Genuine parts

E00200500330

MITSUBISHI MOTORS has gone to great lengths to bring you
a superbly crafted automobile offering the highest quality and
dependability.
Use MITSUBISHI MOTORS genuine parts, designed and
manufactured to maintain your MITSUBISHI MOTORS auto­mobile at top performance. MITSUBISHI MOTORS genuine
parts are identified by this mark and are available at all MIT­SUBISHI MOTORS Authorized Service Points.

7

General information

Used engine oils safety instructions and dis-

posal information

E00200600025

!

WARNING

● Prolonged and repeated contact may cause serious

skin disorders, including dermatitis and cancer.

● Avoid contact with the skin as far as possible and

wash thoroughly after any contact.

● Keep used engine oils out of reach of children.

Protect the environment

It is illegal to pollute drains, water courses and soil. Use
authorized waste collection facilities, including civic amenity
sites and garages providing facilities for disposal of used oil
and used oil filters. If in doubt, contact your local authority for
advice on disposal.

8

Locking and unlocking

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1- 2

Electronic immobilizer

(Anti-theft starting system). . . . . . . . . . . . . . . . .1- 3

Keyless entry system* . . . . . . . . . . . . . . . . . . . . . .1- 5

Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1- 7

Central door locks . . . . . . . . . . . . . . . . . . . . . . . . .1- 9

“Child-protection” rear doors (5-door models) . . .1- 11

Approach lamp*. . . . . . . . . . . . . . . . . . . . . . . . . . .1- 12

Backdoor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1- 13

Electric window control. . . . . . . . . . . . . . . . . . . . .1- 16

Rear side/quarter window . . . . . . . . . . . . . . . . . . .1- 20

Sunroof*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1- 21

1

Locking and unlocking

N

The keys fit all locks.

Type 1

1

Keys

E00300101161

Type 2

OTE

● The key number is stamped on the tag as indicated in the

illustration.
Make a record of the key number and store the key and
key number tag in separate places, so that you can order a
key in the event the original keys are lost.

1-2

Locking and unlocking

● The key is a precision electronic device with a built-in sig-

nal transmitter. Please observe the following in order to
prevent damage.

• Do not leave where it may be exposed to heat caused by
direct sunlight, such as on top of the dashboard.

• Do not take the remote control transmitter apart.

• Do not excessively bend the key or subject it to strong
impacts.

• Keep the remote control transmitter dry.

• Keep away from magnetic objects such as key holders.

• Keep away from devices that produce magnetism, such
as audio systems, computers and televisions.

• Do not clean with ultrasonic cleaners.

• Do not leave the key where it may be exposed to high
temperature or high humidity.

● The engine is designed so that it will not start if the ID

code registered in the immobilizer computer and the key’s
ID code do not match. Refer to the section entitled “Elec­tronic immobilizer” for details and key usage.

Electronic immobilizer

(Anti-theft starting system)

E00300201087

The electronic immobilizer is designed to reduce significantly
the possibility of vehicle theft. The purpose of the system is to
immobilize the vehicle if an invalid start is attempted. A valid
start attempt can only be achieved using a key “registered” to
the immobilizer system.

1

1-3

Locking and unlocking

N

OTE

● In the following cases, the vehicle may not be able to

receive the registered ID code from the registered key and
the engine may not start.

• When the key contacts a key ring or other metallic or
magnetic object (Type A)

• When the key grip contacts metal of another key

1

(Type B)

• When the key contacts or is close to other immobilizing
keys (including keys of other vehicles) (Type C)

In cases like these, remove the object or additional key
from the vehicle key. Then try again to start the engine.
If the engine does not start, we recommend you to con­tact your MITSUBISHI MOTORS Authorized Service
Point.

1-4

Locking and unlocking

● Electronic immobilizer is not compatible with remote

starting systems. Use of these systems may result in vehi­cle starting problems and a loss of security protection.

● If you lose your key, order a key from your MITSUBISHI

MOTORS Authorized Service Point as soon as possible.
To obtain a replacement or extra spare key, take your vehi­cle and all remaining keys to your MITSUBISHI
MOTORS Authorized Service Point. All the keys have to
be re-registered in the immobilizer computer unit. The
immobilizer can register up to 8 different keys.

!

CAUTION

● Don’t make any alterations or additions to the

immobilizer system; alterations or additions could
cause failure of the immobilizer.

Keyless entry system*

E00300301394

Press the remote control switch, and all doors (including the
backdoor) will be locked or unlocked as desired. It is also pos­sible to operate the door mirrors.

1

1- LOCK switch
2- UNLOCK switch
3- Indication lamp

To lock

Press the LOCK switch (1), and all doors (including the back­door) will be locked. When they are locked with the room lamp
switch at the middle position (DOOR), the room lamp and the
turn-signal lamps blink once.

1-5

Locking and unlocking

N

N

To unlock

Press the UNLOCK switch (2), and all doors (including the
backdoor) will be unlocked. When they are unlocked with the
room lamp switch at the middle position (DOOR), the room
lamp will be turned on for approximately 15 seconds and the
turn-signal lamps will blink twice.

1

OTE

● The indication lamp (3) comes on each time a switch is

pressed.

● If the UNLOCK switch (2) is pressed and no door (includ-

ing the backdoor) is opened within approximately 30 sec­onds: relocking will automatically occur.

● It is possible to modify functions as follows:

For further information, contact your MITSUBISHI
MOTORS Authorized Service Point.

• The time for automatic relocking can be changed.

• The confirmation function (flashing of the turn-signal
lamps) can be set to operate only when the doors and
backdoor are locked or only when the doors and back­door are unlocked.

• The confirmation function (this indicates locking or
unlocking of the doors and backdoor with the flash of
the turn-signal lamps) can be deactivated.

• The number of times the turn-signal lamps are flashed
by the confirmation function can be changed.

Operation of the outside rear-view mirrors

To fol d

Within 30 seconds of locking the doors and backdoor using the
LOCK switch (1), press the LOCK switch twice rapidly to fold
the door mirrors.

To ext end

Within 30 seconds of unlocking the doors and backdoor using
the UNLOCK switch (2), press the UNLOCK switch twice
rapidly to return the door mirrors to their extended positions.

OTE

● The keyless entry system does not operate in the follow-

ing conditions:

• The key is left in the key cylinder.

• The door (including the backdoor) is open.

● The remote control switch will operate within about 4 m

from the vehicle. However, the operating range of the
remote control switch may change if the vehicle is located
near a power station, or radio/TV broadcasting station.

● If either of the following problems occurs, the battery may

be exhausted. We recommend you to have the battery
replaced.

• The remote control switch is operated at the correct dis­tance from the vehicle, but the doors (including the
backdoor) are not locked/unlocked in response.

• The indication lamp (3) is dim or does not come on.

● If your remote control switch is lost or damaged, please

contact your MITSUBISHI MOTORS Authorized Service
Point for a replacement remote control switch.

1-6

Locking and unlocking

● If you wish to add a remote control switch, we recom-

mend you to contact your MITSUBISHI MOTORS
Authorized Service Point.
A maximum of 4 remote control switches are available for
your vehicle.

Doors

!

CAUTION

● Make sure the doors are closed: driving with doors

not completely closed is dangerous.

● Never leave children in the vehicle unattended.

● Be careful not to lock the doors while the key is

inside the vehicle.

To lock or unlock with the key

E00300401177

1

1- Lock
2- Unlock

1-7

Locking and unlocking

To lock or unlock from inside the vehicle

1

1- Lock
2- Unlock

Pull the inside door handle towards you to open the door.

To lock without using the key

Front door

Set the inside lock knob (1) to the locked position, and while
pulling the outside handle up (2), close the door (3).

1-8

Locking and unlocking

N

Rear door (5-door models)

Set the inside lock knob (1) to the locked position, and close
the door (2).

“Forgotten-key-prevention” mechanism

E00300600273

If the key is in the ignition switch when you push the lock knob
forward with the driver’s door open, the lock knob will auto­matically return to the unlocked position.

Central door locks

E00300800969

OTE

● Each of the doors can be locked or unlocked independ-

ently by using the inside lock knob.

● Repeated continuous operation between lock and unlock

could activate the central door locking systems built-in
protection circuit and prevent the system from operating.
If this occurs, wait about 1 minute before operating the
central door lock switch or the key.

1

1-9

Locking and unlocking

Driver’s door with key

Using the key on the driver’s door locks or unlocks all doors
(including the backdoor).

1

1- Lock
2- Unlock

Driver’s door with central door lock switch

Using the central door lock switch locks or unlocks all doors
(including the backdoor).

1- Lock
2- Unlock

1-10

Locking and unlocking

“Child-protection” rear doors

(5-door models)

E00300900263

1- Lock
2- Unlock

Child protection helps prevent the rear doors from being
opened accidentally from the inside.
If the lever is set to the locked position, the rear doors cannot
be opened using the inside handle, but only with the outside
handle.
If the lever is set to the “Unlock” position, the child protection
mechanism does not function.

!

CAUTION

● When driving with a child in the rear seat, please

use the child protection to prevent accidental door
opening which may cause an accident.

1

1-11

Locking and unlocking

N

Approach lamp

The lamps (A) in the bottom of each mirror illuminate the road
surface while people are entering or exiting the vehicle.

*

1

These lamps turn on/off as follows:

● The lamp illuminates for about 15 seconds when all the

doors (including the backdoor) are unlocked by means of
the key in the driver’s door, the keyless entry system (if so
equipped) or the central door lock switch.

● When any door or the backdoor is opened, the lamp illu-

minates for about 2 minutes.
If all the doors (including the backdoor) are closed while
the lamps are on, the lamps go off 30 seconds later.

E00306100023

OTE

● The lamps go off immediately if:

• All the doors (including the backdoor) are locked by
means of the key in the driver’s door, the keyless entry
system (if so equipped) or the central door lock switch.

• The ignition switch is turned to the “ON” position.

1-12

Locking and unlocking

N

Backdoor

E00301300336

!

WARNING

● It is dangerous to drive with the backdoor open

since carbon monoxide (CO) gas can enter the cabin.
You cannot see or smell CO. It can cause uncon­sciousness and even death.

!

CAUTION

● When the backdoor is open, the rear-right combina-

tion lamp is obscured by the spare wheel.
If the backdoor is opened while the vehicle is parked
on the road, alert other road users to the vehicle’s
presence using a warning triangle or other device as
required by local legislation.

● When closing the backdoor, always ensure your or

other person’s fingers cannot be caught by the back­door.

OTE

● The backdoor is equipped with an oil damper type back-

door stopper, enabling you to hold the backdoor at a
desired position.

● While opening or closing the backdoor, you may feel

slight resistance. This is a structural feature of the back­door stopper that supports the backdoor and does not indi­cate any abnormality.

To lock or unlock from outside the vehicle
(Except for vehicles with keyless entry system)

1

1- Lock
2- Unlock

1-13

Locking and unlocking

N

To lock or unlock from inside the vehicle

The backdoor can be locked or unlocked by using the central
door lock switch.

1

1- Lock
2- Unlock

Vehicles without keyless entry system, if the backdoor is
locked or unlocked by using the central door lock switch, it can
still be locked or unlocked with the key.

OTE

● Repeated continuous operating between lock and unlock

could cause the central door lock’s built-in protection cir­cuit to prevent the system from operating. If this occurs,
wait about 1 minute before operating the central door lock
switch.

● When the luggage compartment lamp is set to the [•] posi-

tion, the luggage compartment lamp illuminates when the
backdoor is opened and turns off when it is closed.

1-14

Locking and unlocking

To open

Pull the outside handle towards you to open the backdoor.

Backdoor stopper

Open the backdoor fully and then move the locking tube (A) to
the LOCK position (B); this will ensure that the backdoor
remains in the fully opened position. To subsequently release
the stopper, move the locking tube back to the UNLOCK posi­tion (C).

!

CAUTION

● When closing the backdoor, be careful not to trap

your hands.

1

1-15

Locking and unlocking

Electric window control

The electric windows can only be operated with the ignition
switch in the “ON” position.

Electric window control switch

Each door window opens or closes while the corresponding

1

switch is operated.

Driver’s switch (LHD)

E00302200185

E00302300766

Driver’s switch (RHD)

1- Driver’s door window
2- Front passenger’s door window
3- Rear left door window (5-door models)
4- Rear right door window (5-door models)
5- Lock switch

!

WARNING

● Before operating the electric window control, make

sure that nothing is capable of being trapped (head,
hand, finger, etc.).

● Never leave the vehicle without removing the key.

● Never leave a child (or other person who might not

be capable of safe operation of the electric window
control) in the vehicle alone.

1-16

Locking and unlocking

N

N

OTE

● Repeated operation with the engine stopped will run down

the battery. Operate the window switches only while the
engine is running.

Driver’s switches

The driver’s switches can be used to operate all door windows.
A window can be opened or closed by operating the corre­sponding switch.
Press the switch down to open the window, and pull up the
switch to close it.
If the switch is fully pressed down/pulled up, the door window
automatically opens/closes completely.
If you want to stop the window movement, operate the switch
lightly.

Passenger’s switches

The passenger’s switches can be used to operate the corre­sponding passenger’s door windows.
Press the switch down for opening the window, and pull up the
switch for closing.

Passenger’s switch

1

OTE

● The rear door windows only open halfway.

1-17

Locking and unlocking

N

N

Lock switch

When this switch is operated, the passenger’s switches cannot
be used to open or close the door windows.
To unlock, press it once again.

1

1- Lock
2- Unlock

OTE

● The driver’s switch always can open or close any door

windows.

E00303100501

!

WARNING

● A child may tamper with the switch at the risk of its

hands or head being trapped in the window. When
driving with a child in the vehicle, please press the
window lock switch to disable the passenger’s
switches.

OTE

● It is possible to prevent the driver’s door switches from

being used to open and close the front passenger’s door
window and rear door windows (5-door models) while the
lock switch is pressed in the “LOCK” position.
For details, we recommend you to consult a MITSU­BISHI MOTORS Authorized Service Point.

Timer function

E00302400086

The door windows can be opened or closed for 30 seconds
after the ignition switch is turned off. If the driver’s door is
opened during this period, the door window can be opened or
closed for another 30 seconds.
However, once the driver’s door is closed, the windows cannot
be operated.

1-18

Locking and unlocking

N

Safety mechanism

E00302500218

If a hand or head is trapped in the closing window, it will lower
automatically.
Nonetheless, make sure that nobody puts their head or hand out
of the window when closing a window.
The lowered window will become operational after a few sec­onds.

!

WARNING

● If the safety mechanism is activated three or more

times successively, the safety mechanism will be tem­porarily cancelled.
If a hand or head got trapped, a serious injury could
result.

!

CAUTION

● The safety mechanism is cancelled just before the

window is fully closed. This allows the window to
close completely. Therefore be especially careful that
no fingers are trapped in the window.

OTE

● The safety mechanism can be activated if the driving con-

ditions or other circumstances cause the door windows to
be subjected to a physical shock similar to that caused by
a trapped hand or head.

● If the safety mechanism is activated three or more times in

a row, the safety mechanism will be cancelled and the
door window will not close correctly.
In such a case, the following procedure should be imple­mented to rectify this situation. If the window is open,
repeatedly raise the appropriate window switch until that
window has been fully closed. Following this, release the
switch, raise the switch once again and hold it in this con­dition for at least 1 second, then release it. You should
now be able to operate all windows in the normal fashion.

1

1-19

Locking and unlocking

1

Rear side/quarter window

To open

1. Pull the lever towards you.

E00302600091

2. Push the lever towards the outside of the vehicle.

3. Push the lever towards the rear of the vehicle to secure it
in place.

To close

Pull the lever, returning it to its original position and securing it
in place.

1-20

Locking and unlocking

N

N

Sunroof

The sunroof can only be operated with the ignition switch in
the “ON” position.

1- Tilt up
2- Close, Tilt down
3- Open

To open, press the switch (3).
To stop the moving sunroof, press the switch (1) or (2).

*

E00302700832

OTE

● The sunroof automatically stops just before reaching the

fully open position.
Press the switch again to fully open it.

To tilt up, press switch (1).
The rear sunroof raises for ventilation.

OTE

● When the sunroof is tilted up, the sunshade is automati-

cally opened slightly.

To tilt down, press switch (2).

Timer function

The sunroof can be opened or closed for 30 seconds after the
ignition switch is turned off. If the driver’s door is opened dur­ing this period, the sunroof can be opened or closed for another
30 seconds.
However, once the driver’s door is closed, the sunroof cannot
be operated.

1

To close, press switch (2).
To stop the moving sunroof, press switch (1) or (3).

1-21

Locking and unlocking

N

Lock switch

When this switch is operated, the sunroof switch cannot be
used to open or close the sunroof.
To unlock, press it once again.

1

1- Lock
2- Unlock

OTE

● If the sunroof switch is operated with the lock switch

pressed, a buzzer sounds to indicate the sunroof cannot be
opened or closed.

● With the lock switch pressed, operation of the electric

window control with switches other than the driver’s door
switches is also prevented.

Safety mechanism

If a hand or head is trapped in the closing sunroof, it will re­open automatically.
Nonetheless, make sure that nobody puts their head or hand out
of the sunroof when opening or closing.
The opened sunroof will become operational after a few sec­onds.

If the safety mechanism should be activated 5 or more times
consecutively, normal closing of the sunroof will be aborted. In
such an event, the following steps should be taken:

1. Press switch (2) repeatedly, setting the sunroof in the tilt
up condition.

2. Once the tilt up condition has been reached, press and
hold switch (2) for a period of at least 3 seconds.

3. Press switch (2) once again to fully close the sunroof.

1-22

Locking and unlocking

N

4. After pressing switch (3) to perform full opening, press
switch (2) to fully close the sunroof.

OTE

● The safety mechanism can be activated if the driving con-

ditions or other circumstances cause the sunroof to be sub­jected to a physical shock similar to that caused by a
trapped hand or head.

● Avoiding stopping the sunroof before it reaches the open-

ing or closing end during operations in steps 3 and 4
above. If this should accidentally happen, repeat the proc­ess from step 1.

!

CAUTION

● The safety mechanism is cancelled just before the

sunroof is fully closed. This allows the sunroof to
close completely.
Therefore be especially careful that no fingers are
trapped in the sunroof.

5. Following this action, it should be possible to operate the
sunroof in the normal manner.

Sunshade

Slide the sunshade manually to open and close it.

!

CAUTION

● Be careful that hands are not trapped when closing

the sunshade.

1

1-23

Locking and unlocking

N

1

To ope n

When switch (2) is pressed, the sunshade and the sunroof open
together.

To clo se

When switch (1) is pressed, the sunshade and the sunroof close
together.

OTE

● If the sunroof is stopped midway, the sunshade will no

longer be able to close together with the sunroof. In such a
situation, press switch (2) to fully open the sunroof and
then press switch (1).

● When the sunroof is tilted up, the sunshade is automati-

cally opened slightly.

● Be sure to tilt down the sunroof before closing the sun-

shade.

● The sunshade cannot be closed with the sunroof opened.

Do not attempt to close the sunshade when the sunroof is
opened.

!

WARNING

● Do not put head, hands or anything else out of the

sunroof opening while driving the vehicle.

● Never leave a child (or other person who might not

be capable of safe operation of the sunroof switch) in
the vehicle alone.

● Before operating the sunroof, make sure that noth-

ing can get trapped (head, hand, finger, etc.).

1-24

N

OTE

● The sunroof stops just before reaching the fully open posi-

tion.
If the vehicle is driven with the sunroof in this position,
wind throb is lower than with the sunroof fully open.

● When leaving the vehicle unattended, make sure you

close the sunroof and remove the ignition key.

● Do not try to operate the sunroof if it is frozen closed

(after snow fall or during extreme cold).

● Do not sit or place heavy luggage on the sunroof or roof

opening edge.

● Release the switch as soon as the sunroof reaches the fully

open or fully closed position.

● If the sunroof does not operate when the sunroof switch is

operated, release the switch and check whether something
is trapped by the sunroof. If nothing is trapped, we recom­mend you to have the sunroof checked.

● Depending on the model of ski carriers or roof carriers,

the sunroof may make contact with the carrier when the
sunroof is tilted up. Be careful when tilting up the sunroof
if such a ski carrier or a roof carrier is installed.

● Be sure to close the sunroof completely when washing the

vehicle or when leaving the vehicle.

● Be careful, not to put any wax on the weatherstrip (black

rubber) around the sunroof opening. If stained with wax,
the weatherstrip cannot maintain a weatherproof seal with
the sunroof.

● After washing the vehicle or after it has rained, wipe off

any water that is on the sunroof before operating it.

● Operating the sunroof repeatedly with the engine station-

ary will run down the battery. Operate the sunroof while
the engine is running.

Locking and unlocking

1

1-25

Seat and seat belts

Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 2

Seat arrangement . . . . . . . . . . . . . . . . . . . . . . . . . .2- 3

Seat adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 5

Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 6

Rear seats (3-door models)*/Second seats

(5-door models)* . . . . . . . . . . . . . . . . . . . . . . . .2- 13

Third seat (5-door models)*. . . . . . . . . . . . . . . . . .2- 16

Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 16

Making a luggage area . . . . . . . . . . . . . . . . . . . . . .2- 19

Making a flat seat*. . . . . . . . . . . . . . . . . . . . . . . . .2- 35

Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 38

Pregnant women restraint . . . . . . . . . . . . . . . . . . .2- 43

Seat belt pre-tensioner system and force

limiter system . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 43

Child restraint. . . . . . . . . . . . . . . . . . . . . . . . . . . . .2- 44

Seat belt inspection . . . . . . . . . . . . . . . . . . . . . . . .2- 58

Supplemental restraint system (SRS) - airbag . . . .2- 58

2

Seat and seat belts

2

Seats

E00400100820

1- Front seats

● To adjust forward or backward → p. 2-6

● To recline the seatback → p. 2-7

● To adjust seat cushion height → p. 2-8

● Lumbar support adjustment (Power type, driver’s seat)

→ p. 2-10

● Armrest → p. 2-10

● To get in and out of the rear seat

(3-door models, passenger’s seat) → p. 2-11

● Heated seats* → p. 2-12

2-2

2- Rear seats (3-door models)* / Second seats
(5-door models)*

● To recline the seatback → p. 2-13

● Armrest → p. 2-14

● To get in and out of the third seat (5-door models)

→ p. 2-15

3- Third seat (5-door models)*

● To recline the seatback → p. 2-16

Seat arrangement

By operating the front, rear/second or third seat select the desired seat arrangement.

3-door models 5-door models

Normal usage

Flat seat* → p. 2-35

Seat and seat belts

E00400200515

2

2-3

Seat and seat belts

Folding the rear seatbacks forward (3­door models)/folding the second seat­backs forward (5-door models)
→ p. 2-20

3-door models 5-door models

2

Folding the rear seats (3-door models)/
folding the second seats (5-door
models) → p. 2-22

How to stow
large articles

Storage of the third seat → p. 2-25 —

Removing the third seat → p. 2-29 —

2-4

Seat and seat belts

Seat adjustment

E00400300314

Adjust the driver’s seat so that you are comfortable and that
you can reach the pedals, steering wheel, switches etc. while
retaining a clear field of vision.

!

WARNING

● Do not attempt to adjust the seat while driving. This

can cause loss of vehicle control and result in an
accident. After adjustments are made, ensure the
seating is locked in position by attempting to move
the seat forward and rearward without using the
adjusting mechanism.

● Do not allow people or children to ride in any area of

your vehicle that is not equipped with seats and seat
belts, and make sure that everyone travelling in
your vehicle is in a seat and wearing a seat belt, or in
the case of a child is strapped in a child restraint.

● To minimize the risk of personal injury in the event

of a collision or sudden braking, the seatbacks
should always be in the almost upright position
while the vehicle is in motion. The protection pro­vided by the seat belts may be reduced significantly
when the seatback is reclined. There is greater risk
that the passenger will slide under the seat belt,
resulting in serious injury, when the seatback is
reclined.

!

CAUTION

● Make sure the seat is adjusted by an adult or with

adult supervision for correct and safe operation.

● Do not place a cushion or the like between your back

and the seatback while driving. The effectiveness of
the head restraints will be reduced in the event of an
accident.

● When sliding the seats, be careful not to catch your

hand or foot.

2

2-5

Seat and seat belts

N

Front seats

To adjust forward or backward

Manual type

Pull the seat adjusting lever and adjust the seat forward or
backward to the desired position, and release the adjusting
lever.

2

!

WARNING

● To ensure the seat is locked securely, try to move the

seat forward or backward without using the adjust­ing lever.

E00400400100

E00400500055

Power type

Adjust the seat by operating the switch as indicated by the
arrows.

1- Adjustment forward
2- Adjustment backward

OTE

● To prevent the battery from running down, operate the

power seat with the engine running.

2-6

Seat and seat belts

N

To recline the seatback

E00400600056

Manual type

In order to recline the seatback, lean forward slightly, pull the
seatback lock lever up, and then lean backward to the desired
position and release the lever. The seatback will lock in that
position.

!

CAUTION

● The reclining mechanism of the seatback is spring

loaded, causing it to return to the vertical position
when the lock lever is operated. When using the
lever, sit close to the seatback or hold it with your
hand to control its return motion.

Power type

Adjust the seatback angle by operating the switch as indicated
by the arrows.

2

1- To move to forward direction
2- To recline rearward

OTE

● To prevent the battery from running down, operate the

power seat with the engine running.

2-7

Seat and seat belts

To adjust seat cushion height

Manual type

To adjust the seat cushion height, turn the dial as shown in the
illustration.

2

1- To move the front of the seat cushion up
2- To move the front of the seat cushion down

E00400700451

3- To move the rear of the seat cushion up
4- To move the rear of the seat cushion down

2-8

Power type

N

To adjust the seat cushion height, operate the switch as indi­cated by arrows.

OTE

● To prevent the battery from running down, operate the

power seat with the engine running.

1- To move the front of the seat cushion up and down

Seat and seat belts

2

2- To move the rear of the seat cushion up and down

3- To move the whole seat cushion up and down

2-9

Seat and seat belts

N

Lumbar support adjustment (Power type,
driver’s seat)

A lumbar support adjustment is located in the seatback of the
driver’s seat. To adjust the lumbar support, operate the switch
as indicated by arrows.

2

1- Strong
2- Weak

OTE

● To prevent the battery from running down, operate the

power seat with the engine running.

E00400800032

Armrest

E00400900118

Slide forward the centre console lid while pressing the right
upper lever (A).

2-10

Seat and seat belts

To get in and out of the rear seat
(3-door models, passenger’s seat)

E00401000044

The lever can be used to make getting in and out easier.
Pull up the lever (A) or depress the pedal (B), tilt the seatback
forward. Then slide the entire seat forward. To return the seat,
raise the seatback, then slide the entire seat backward until
there is a “click” in a locked position. Adjust the seat position.

!

WARNING

● Do not drive the vehicle with the seatback folded

forward. The seat is not retained with the seatback
in this position, so serious injuries could be suffered
in the event of hard braking or a collision.

!

CAUTION

● The reclining mechanism of the seatback is spring

loaded, causing it to return to the vertical position
when the lock lever is operated. When using the
lever, sit close to the seatback or hold it with your
hand to control its return motion.

2

2-11

Seat and seat belts

Heated seats*

The heated seats can be operated with the ignition switch in the
“ON” position. Operate the switch as indicated by arrows.
The indication lamp (A) will illuminate while the heater is on.

2

1- Heater high (for quick heating).
2- Heater off.
3- Heater low (to keep the seat warm).

!

CAUTION

● Switch off seat heaters when not in use.

E00401100289

!

CAUTION

● Operate in the high position for quick heating. Once

the seat is warm, set the heater to low to keep it
warm. Slight variations in seat temperature may be
felt while using the heated seats. This is caused by
the operation of the heater’s internal thermostat and
does not indicate a malfunction.

● If the following types of persons use the heated seats,

they might become too hot or receive minor burns
(red skin, heat blisters, etc.):

• Children, elderly or ill people

• People with sensitive skin

• Excessively tired people

• People under the influence of alcohol or sleep
inducing medication (cold medicine, etc.)

● Do not place heavy objects on the seat or stick pins,

needles, or other pointed objects into it.

● Do not use a blanket, cushion, or other material with

high heat insulation properties on the seat while
using the heater; this might cause the heater element
to overheat.

● When cleaning the seat, do not use benzene, gaso-

line, alcohol, or other organic solvents; this might
damage the surface of the seat and also the heater
element.

● If water or any other liquid is spilled on the seat,

allow it to dry thoroughly before attempting to use
the heater.

● Turn the heater off immediately if it appears to be

malfunctioning during use.

2-12

Seat and seat belts

Rear seats (3-door models)*/

Second seats (5-door models)*

E00402000184

!

WARNING

● When a person is sitting in the middle seating posi-

tion of the rear seats (3-door models)/second seats
(5-door models), pull up the head restraint to a
height at which it locks in position. Be sure to make
this adjustment before starting to drive. Serious
injuries could otherwise be suffered as the result of
an impact. Refer to “Head restraints” on page 2-16.

To recline the seatback

E00402200157

In order to recline the seatback, lean forward slightly, pull the
seatback lock lever up, and then lean backward to the desired
position and release the lever. The seatback will lock in that
position.

3-door models

2

5-door models

2-13

Seat and seat belts

N

!

CAUTION

● The reclining mechanism of the seatback is spring

loaded, causing it to return to the vertical position
when the lock lever is operated. When using the
lever, sit close to the seatback or hold it with your
hand to control its return motion.

Armrest

E00402400218

For rear seats (3-door models)

Press the button (A) at the top of the armrest and allow the
armrest to drop down.

OTE

2

● Each seatback can be adjusted by the lever on its side.

● On 5-door models, each of the second seat’s sidebacks (A)

is foldable. When either side of the seatback is reclined to
a new position, its sideback automatically folds inward
accordingly.

2-14

Seat and seat belts

N

For second seats (5-door models)

Lift the centre head restraint and then tilt the armrest for use as
illustrated.

!

CAUTION

● When storing the armrest, push the armrest

securely to prevent it from falling down while driv­ing the vehicle.

OTE

● Do not stand or sit on the armrest. It could break.

To get in and out of the third seat (5-door models)

E00402500163

Getting in and out of the third seat can be made easily by fold­ing the second seat.
Refer to “Folding the rear seats (3-door models) / Folding the
second seats (5-door models)” on page 2-22.

2

2-15

Seat and seat belts

Third seat (5-door models)

To recline the seatback

In order to recline the seatback, lean forward slightly, pull the
seatback lock lever as shown in the illustration, and then lean
backward to the desired position and release the lever. The
seatback will lock in that position.

2

!

CAUTION

● The reclining mechanism of the seatback is spring

loaded, causing it to return to the vertical position
when the lock lever is operated. When using the
lever, sit close to the seatback or hold it with your
hand to control its return motion.

*

E00402700149

E00402800124

Head restraints

E00403300474

!

WARNING

● Driving without the head restraints in place can

cause you and your passengers serious injury or
death in an accident. To reduce the risk of injury in
an accident, always make sure the head restraints
are installed and properly positioned when the seat
is occupied.

● Never place a cushion or similar device on the seat-

back. This can adversely affect head restraint per­formance by increasing the distance between your
head and the restraint.

2-16

Seat and seat belts

To adjust height

Adjust the head restraint height so that the centre of the
restraint is as close as possible to eye level to reduce the
chances of injury in the event of collision. Any person too tall
for the restraint to reach their seated eye level, should adjust
the restraint as high as possible.
To raise the head restraint, move it upward. To lower the
restraint, move it downward while pushing the height adjusting
knob (A) in the direction of the arrow. After adjustment, push
the head restraint downward and make sure that it is locked.

To adjust forward or backward

Tilt the head restraint towards you to adjust it forward. To
adjust it backward, tilt the head restraint backward.

2

2-17

Seat and seat belts

To remove

Lift the head restraint with the height adjusting knob (A)
pushed in.

To install

Confirm that the head restraint is facing the correct direction,
and then insert it into the seatback while pressing the height
adjusting knob (A) in the direction indicated by the arrow.

2

!

CAUTION

● Confirm that the height adjusting knob (A) is cor-

rectly adjusted as shown in the illustration, and also
lift the head restraints to ensure that they do not
come out of the seatback.

2-18

Seat and seat belts

!

CAUTION

● The head restraints for the seats differ in shape and

size. When installing head restraints, make sure the
head restraints are fitted in their respective seats.

AA0059237

Making a luggage area

E00403400013

!

CAUTION

● Do not stack luggage above the seatback height.

Secure the luggage firmly.
Serious accidents could result due to unrestrained
objects entering the passenger compartment during
sudden braking.

● When folding, storing or removing the seat, be sure

not to catch your hand or leg.

2

2-19

Seat and seat belts

N

Folding the rear seatbacks forward (3-door mod­els) / Folding the second seatbacks forward
(5-door models)

The passenger and luggage compartments can be joined by
folding the rear (3-door models) / second (5-door models) seat­back forward. This is useful for carrying long objects.

To fol d

1. If your vehicle is equipped with a rear shelf (3-door mod-

2

els) / cargo area cover (5-door models), remove it before
performing the following steps.
Refer to “Rear shelf (3-door models)” on page 5-101 and
“Cargo area cover (5-door models)” on page 5-103.

2. Lift up the knob (A) behind the seatback, then tilt the seat­back forward.

E00403500232

OTE

● Each seatback can be folded forward using the knob on its
side.

2-20

Seat and seat belts

3. Push the seat until you hear a “click” and the seat locks
securely.

To replace

Raise the seatback until it locks securely into place.
Push lightly on the seatback to confirm that it has actually been
secured.

2

2-21

Seat and seat belts

Folding the rear seats (3-door models) / Folding
the second seats (5-door models)

To create luggage space, you can fold the rear (3-door models)/
second (5-door models) seats.
If your vehicle is equipped with the third seat, by folding the
second seat, you can get in and out easier.

!

WARNING

2

● When driving the vehicle, do not allow anyone to sit

on the third seat if the second seat is in the folded­down position. The second seat could tip rearward
in the event of hard braking or a collision, resulting
in serious injuries.

E00403700221

To fol d

1. If your vehicle is equipped with a rear shelf (3-door mod­els) / cargo area cover (5-door models), remove it before
performing the following steps.
Refer to “Rear shelf (3-door models)” on page 5-101 and
“Cargo area cover (5-door models)” on page 5-103.

2. Lift up the knob (A) behind the seatback, then tilt the seat­back forward.

2-22

Seat and seat belts

3. Lift the seat until you hear a “click”.

To replace

1. Hold the seat with your hand, then return the seat to its
original position while pushing the stopper (A).

2

2-23

Seat and seat belts

2. Push the seat until you hear a “click” and the seat locks
securely.

3. Raise the seatback until it locks securely into place.
Push lightly on the seatback to confirm that it has actually
been secured.

2

2-24

Seat and seat belts

N

Storage of the third seat

E00404100206

By folding the third seat into the luggage floor box, large arti­cles can be stored in the vehicle.

To sto re

1. Remove the luggage floor board (A) and the head
restraints (B).
Refer to “Luggage floor box” on page 5-97 and “Head
restraints” on page 2-16.

2. Stow the removed head restraints in the luggage floor box
with their front faces facing upward.

2

OTE

● Stowing the head restraints with their front faces facing
downward would prevent the third seat from being
stowed.

2-25

Seat and seat belts

3. Pull up knob (C) on the side of the seatback, then tilt the
seatback forward.

4. Push lever (D) forward, then tilt the seatback forward
until the seatback touches the seat cushion.

2

!

CAUTION

● Do not drive with luggage placed on the forward-

folded seatback.

2-26

Seat and seat belts

5. Pull lever (E), fold the seat backward, and store it into the
luggage floor box.

!

CAUTION

● Ensure that lever (E) is not operated while the seat is

occupied. The folding action of the seat in such a sit­uation could result in an unexpected accident.

● When folding the seat, be sure not to catch your

hands between seat and luggage floor box.

!

CAUTION

● When folding the seat away into the luggage floor

box, hold the seat by hand and fold it slowly. If the
seat is not held properly, it might fall under its own
weight during folding and pinch your hand.

2

2-27

Seat and seat belts

6. Fold down the stand (F).

To rep lace

1. Remove the luggage floor board. And then raise the stand.

2. Raise the seat forward until you hear a “click” and the seat
locks securely.

2

7. Refit the luggage floor board.

2-28

Seat and seat belts

3. Push knob (A) forward, and raise the seatback until it
locks securely into place.
After the operation, push lightly on the seatback to con­firm that it has actually been secured.

4. Refit the luggage floor board and head restraints.

Removing the third seat

E00404200122

To create more luggage space, you can remove the third seat.

!

CAUTION

● For safety, do not allow children to remove or refit

the seat.

● Be careful not to trap your hands or feet when

removing or refitting the seat. Also, be careful not to
drop or trip over the seat. If necessary, have some­one help you remove it.

2

2-29

Seat and seat belts

2

To remove

1. Remove the head restraints.
Refer to “Head restraints” on page 2-16.

2. Pull up the knob (A) on the side of the seatback, then tilt
the seatback forward.

3. Push the lever (B) forward, then tilt the seatback forward
until the seatback touches the seat cushion.

2-30

Seat and seat belts

4. Pull the seat lock lever (C). 5. Fold the stands (D) towards you from the seat side, while
lifting the front end of the seat.

2

2-31

Seat and seat belts

6. Put down the front end of the seat to the floor. In this situ­ation, the seat locking system is unlocked automatically.

7. Remove the covers (E) by turning the knob (F) anticlock­wise.

2

G- Unlock
H- Lock

2-32

Seat and seat belts

N

8. Hold the seat as shown in the illustration, remove the seat
by sliding it backward.

!

CAUTION

● Do not sit or place luggage on the removed seat. Any

weight placed on the folded seat could deform the
seat mountings, preventing the seat from being
locked securely onto the floor.

OTE

● During the removal procedure, ensure that both ends of

the seat are moved evenly while the seat is being pulled
out. If this procedure is not followed, the seat could catch
on its securing fixtures, making it difficult to remove.

2

2-33

Seat and seat belts

2

To refit

1. Push the seat’s mounting arms into the luggage compart­ment’s fixtures.

2. Confirm that the seat’s mounting arms are secured by the
hooks (A).

3. Fold the stands forward from the seat side, while lifting
the front end of the seat.

4. Refit the covers on both sides of the luggage room.

2-34

Seat and seat belts

5. Push the knob (B) forward, raise the seatback until it locks
securely into place.
After the operation, push the seatback lightly to confirm
that it has actually been secured.

6. Refit the head restraints.

Making a flat seat*

E00404300048

By removing the head restraints and fully reclining the seat­backs of the seats, one large flat seat is achieved.

!

WARNING

● Never drive with passengers on the flat seat. This is

highly dangerous.

!

CAUTION

● To make a flat seat, stop the vehicle in a safe place.

● Make sure the seat is adjusted by an adult or with

adult supervision for correct and safe operation.

● When sliding the seat, be sure not to catch your

hand or leg.

● Do not walk around on top of the seats after they

have been laid flat.

● To ensure the seats are locked securely, attempt to

move them back and forth.

● Do not jump on, or impact the seatbacks heavily.

● To raise the seatback, put a hand on the seatback

and raise slowly. Never have a child do this opera­tion, or an unexpected accident may result.

2

2-35

Seat and seat belts

1. If your vehicle is equipped with a rear shelf (3-door mod­els) / cargo area cover (5-door models), remove it before
performing the following steps.
Refer to “Rear shelf (3-door models)” on page 5-101 and
“Cargo area cover (5-door models)” on page 5-103.

2. Remove the head restraints from the front seats.
If your vehicle is equipped with the third seat (5-door
models), store the third seat into the luggage floor box.
Refer to “Head restraints” on page 2-16 and “Storage of
the third seat” on page 2-25.

3. Slide the front seats fully forward, then tip their seatbacks
backward.
On 5-door models, slide the front seats backward until
their seatbacks touch the second seat.
Refer to “To adjust forward or backward” on page 2-6 and
“To recline the seatback” on page 2-7.

2

2-36

Seat and seat belts

N

4. On 3-door models, remove the head restraints from the
rear seat.
Recline the rear (3-door models) / second (5-door models)
seatback backward.
Refer to “To recline the seatback” on page 2-13.

OTE

● On 5-door models, each of the second seat’s sidebacks (A)

is foldable. When either side of the seatback is reclined to
a new position, its sideback automatically folds inward
accordingly.

2

2-37

Seat and seat belts

2

5. On 3-door models, store the front head restraints and rear
centre head restraint between the front seats.
And store the rear outboard head restraints on the side of
the rear seat.
On 5-door models, store the front head restraints between
the front seats.
The flat seat configuration is now complete.
Reverse the above procedure when returning the seat to
the normal position.

3-door models

5-door models

Seat belts

E00404800072

To protect you and your passengers in the event of an accident,
it is most important that the seat belts be worn correctly while
driving.
The front seat belts have a pre-tensioner system. These belts
are used the same way as a conventional seat belt.
Refer to “Seat belt pre-tensioner system and force limiter sys­tem” on page 2-43.

!

WARNING

● Always place the shoulder belt over your shoulder

and across your chest. Never put it behind you or
under your arm.

● One seat belt should be used by only one person.

Doing otherwise can be dangerous.

● The seat belt will provide its wearer with maximum

protection if the recliner seatback is placed in fully
upright position. When the seatback is reclined,
there is greater risk that the passenger will slide
under the belt, especially in a forward impact acci­dent, and may be injured by the belt or by striking
the instrument panel or seatbacks.

● Seat belts should always be worn by every adult who

drives or rides in this vehicle, and by all children
who are large enough to wear seat belts properly.
Other children should always use proper child
restraint systems.

● Remove any twists when using the belt.

2-38

Seat and seat belts

N

!

WARNING

● No modifications or additions should be made by the

user which will either prevent the seat belt adjusting
devices from operating to remove slack, or prevent
the seat belt assembly from being adjusted to
remove slack.

● Never hold a child in your arms or on your lap when

riding in this vehicle, even if you are wearing your
seat belt. To do so risks severe or fatal injury to your
child in a collision or sudden stop.

● Always adjust the belt to a snug fit.

● Always wear the lap portion of the belt over your

hips.

3-point type seat belt (with emergency locking
mechanism)

E00404900871

This type of belt requires no length adjustment. Once worn, the
belt adjusts itself to the movement of wearer, but in the event of
a sudden or strong shock, the belt automatically locks to hold
the wearer’s body.

To fasten

1. Pull the seat belt out slowly while holding the latch plate.

OTE

● When the seat belts cannot be pulled out in a locked con-

dition, pull the belts once forcefully and then return them.
After that, pull the belts out slowly once again.

2. Insert the latch plate into the buckle until a “click” is
heard.

2

2-39

Seat and seat belts

N

!

WARNING

● Never wear the lap portion of the belt across your

abdomen. During accidents it can press sharply
against abdomen and increase the risk of injury.

● The seat belts must not be twisted when worn.

3. Pull the belt slightly to adjust slackness as desired.

To unfasten

2

Hold the latch plate and push the button on the buckle.

OTE

● As the belt retracts automatically, keep the latch plate held

while retracting so that the belt stows slowly. Failure to do
this could damage the vehicle.

Seat belt reminder/warning lamp

E00409800338

The seat belt warning lamp is located on the instrument panel.
A tone and warning lamp are used to remind the driver to fas­ten the seat belt.

When the ignition key is turned to the “ON” position, the warn­ing lamp will illuminate and a tone will sound for about 6 sec­onds. If the driver’s seat belt remains unfastened for
approximately 1 minute later, the warning lamp will flash and
the tone sound intermittently (each 12 times) when the vehicle
is driven. If the driver subsequently unfastens the seat belt
while driving, the warning lamp and tone will issue further
warnings. And if the seat belt remains unfastened, the warning
lamp and tone will issue further warnings each time the vehicle
starts moving from a stop. When the seat belt is fastened, the
warnings will stop.

2-40

Seat and seat belts

Adjustable seat belt anchor (front seats)

E00405000286

The seat belt anchor height can be adjusted.
Move the seat belt anchor down with the lock knob (A)
depressed. To move the anchor up, slide it without depressing
the lock knob (A).

Anchor down Anchor up

!

WARNING

● When adjusting the seat belt anchor, set it at a posi-

tion that is sufficiently high so that the belt will
make full contact with your shoulder but will not
touch your neck.

Rear / second, third seat belt storage*

E00405300029

When the seat belt is not in use, store it as shown in the illustra­tion.

3-door models

2

5-door models

2-41

Seat and seat belts

Seat belt plate storage

After passing the belt through the rear notch (A), insert the
plate into the front notch (B).

2

Seat belt buckle storage

Store the seat belt buckle in the storage pocket.

Rear/Second seat

Third seat (5-door models)

2-42

Seat and seat belts

Pregnant women restraint

E00405600064

!

WARNING

● Seat belts work for everyone, including pregnant

women. Pregnant women should use the available
seat belts. This will reduce the likelihood of injury to
both the woman and the unborn child. The lap belt
should be worn across the thighs and as snug against
the hips as possible, but not across the waist. Consult
your doctor if you have any additional questions or
concerns.

Seat belt pre-tensioner system and force

limiter system

E00405700081

The driver’s seat and front passenger’s seat each have a seat
belt equipped with a pre-tensioner system.

Pre-tensioner system

The pre-tensioner system will retract their respective seat belts
instantaneously, thus maximizing the seat belt’s effectiveness,
if there is a frontal impact severe enough to injure the driver
and/or front passenger and the ignition switch is in the “ON” or
“START” position.

!

WARNING

● To obtain the best results from your pre-tensioner

seat belt, make sure you have adjusted your seat
correctly and wear your seat belt properly.

!

CAUTION

● Installation of audio equipment or repairs in the

vicinity of the pre-tensioner seat belts or floor con­sole must be performed in line with MITSUBISHI
MOTORS guidelines. It is important to do so
because the work could affect the pre-tensioner sys­tems.

E00405800747

2

2-43

Seat and seat belts

N

!

CAUTION

● If you need to scrap the vehicle, please consult a

MITSUBISHI MOTORS Authorized Service Point.
It is important to do so because unexpected activa­tion of the pre-tensioner seat belts could cause inju­ries.

OTE

2

● The pre-tensioner seat belts will be activated if the vehicle

suffers a severe frontal impact, even if the seat belts are
not worn.

● The pre-tensioner seat belts are designed to work only

once. After the pre-tensioner seat belts have been acti­vated, we recommend you have it replaced by a MIT­SUBISHI MOTORS Authorized Service Point.

SRS warning lamp

This warning lamp is shared by the SRS airbags and the pre­tensioner seat belts.
Refer to “SRS warning lamp” on page 2-75.

Force limiter system

In the event of a collision, each force limiter system will effec­tively absorb the load applied to the seat belt to minimize the
impact to the passenger.

E00405900083

E00406000153

Child restraint

E00406401066

When transporting children in your vehicle, some type of child
restraint system should always be used according to the size of
the child. This is required by law in most countries.
The regulations concerning driving with children in the front
seat may differ from country to country. You are advised to
comply with the relevant regulations.

!

WARNING

● When possible, put children in the rear seat. Acci-

dent statistics indicate that children of all sizes and
ages are safer when properly restrained in the rear
seat rather than in the front seat.

● Holding a child in your arms is no substitute for a

restraint system. Failure to use a proper restraint
system can result in severe or fatal injury to your
child.

● Each child restraint device or fixing is to be used

only by one child.

● When attaching a child restraint to the rear seat,

place the front seatbacks in the upright position.
Otherwise, the child could be seriously injured in
the event of hard braking or a collision.

2-44

Seat and seat belts

Caution for installing the child restraint on vehi­cles with a front passenger airbag

The label shown here is attached on vehicles with a front pas­senger airbag.

!

WARNING

● Extreme Hazard!

Do not use a rearward facing child restraint on a
seat protected by an airbag in front of it!

Use rearward facing child restraints in the rear seat or turn off
the front passenger’s airbag ON-OFF switch. (Refer to “To turn
an airbag off” on page 2-64.)

Front passenger’s airbag ON

!

WARNING

● A REARWARD FACING CHILD RESTRAINT

must NOT be used in the front passenger seat if the
front passenger’s airbag has not been deactivated.
The force of an inflating airbag could kill or cause
serious injuries to the child. A rearward facing child
restraint must only be used in the rear seat.

2

2-45

Seat and seat belts

!

WARNING

● A FORWARD FACING CHILD RESTRAINT

should be used in the rear seat whenever possible; if
used in the front seat, adjust the seat to the most
rearward position.

Infants and small children

E00406600641

When transporting infants and small children in your vehicle,
follow the instruction given below.

2

Instruction:

● For small infants, an infant carrier should be used. For

small children whose height when seated allows the
shoulder belt to lie in contact with the face or the throat, a
child seat should be used.

● The child restraint system should be appropriate for your

child’s weight and height and properly fit in the vehicle.
For a higher degree of safety: THE CHILD RESTRAINT
SYSTEM SHOULD BE INSTALLED IN THE REAR
SEAT.

2-46

Seat and seat belts

N

● Before purchasing a child restraint system, try installing it

in the rear seat to make sure there is a good fit. Because of
the location of the seat belt buckles and the shape of the
seat cushion, it may be difficult to securely install some
manufacturer’s child restraint systems.
If the child restraint system can be pulled forward or to
either side easily on the seat cushion after the seat belt has
been tightened, choose another manufacturer’s child
restraint system.

!

WARNING

● When installing a child restraint system, refer to the

instructions provided by the manufacturer of the
restraint system. Failure to do so can result in severe
or fatal injury to your child.

● After installation, push and pull the child restraint

system back and forth, and side to side, to see that it
is positively secured. If the child restraint system is
not installed securely, it may cause injury to the
child or other occupants in the case of accident or
sudden stops.

● When the child restraint system is not in use, keep

your child restraint system secured with the seat belt
or remove it from the vehicle in order to prevent it
from being thrown around inside the vehicle during
an accident.

OTE

● Depending on the seating position in the vehicle and the
child restraint system that you have, the child restraint can
be attached using one of the following two locations:

• To the lower anchorage in the rear seat (3-door models)/
second seat (5-door models) ONLY if the child restraint
has ISOFIX mountings (See page 2-54).

• To the seat belt (See page 2-57).

Older children

E00406700147

Children who have outgrown the child restraint system should
be seated in the rear seat and wear combination lap shoulder
belt.
The lap portion of the belt should be snug and positioned low
on the abdomen so that it is below the top of the hip-bone. Oth­erwise, the belt could intrude into the child’s abdomen during
an accident and cause injury.

2

2-47

Seat and seat belts

Suitability for various ISOFIX positions

E00411400038

Vehicle ISOFIX positions

Mass Group Size class Fixture

Front Passenger

Carrycot F ISO/L1 X X IL X

GISO/L2X IL X X

2

XXXX

0 - Up to 10 kg E ISO/R1 X IL IL X

XXXX

0+ - Up to 13 kg

EISO/R1X IL

D ISO/R2 X IL IL X

C ISO/R3 X IL IL X

XXXX

I - 9 to 18 kg D ISO/R2 X IL IL X

C ISO/R3 X IL IL X

BISO/F2X IUF IUF X

B1 ISO/F2X X

AISO/F3X IUF IUF X

XXXX

II- 15 to 25 kg XXXX

III- 22 to 36 kg XXXX

Rear / second Outboard

Left side Right side

IL, IL*

IUF, IL*

1

IUF, IL*

Rear Centre

2

1

X

X

2-48

Seat and seat belts

N

Key of letters to be inserted in the table above:

● IUF- Suitable for ISOFIX forward child restraints systems of universal category approved for use in the mass group.

● IL- Suitable for particular ISOFIX child restraint systems (CRS) given in the attached list.

These ISOFIX CRS are those of the “specific vehicle”, “restricted” or “semiuniversal” categories.

● X- ISOFIX position not suitable for ISOFIX child restraint systems in this mass group and/or this size class.

IL (Genuine part information)

Genuine part No. ECE No.

1

*

2

*

MZ313045 E1-04301133

MZ313589 E1-04301146

OTE

● MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.

For detailed information, consult your MITSUBISHI MOTORS Authorized Service Point.

2

2-49

Seat and seat belts

Suitability for various seating positions

3-door models

Seating position

Mass Group

Activated Air-

2

0 - Up to 10 kg X X X X X

0+ - Up to 13 kg X

I - 9 to 18 kg

II & III - 15 to 36 kg

*1: With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch.

Key of letters to be inserted in the table above:

● U- Suitable for “universal” category restraints approved for use in this mass group.

● UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group.

● L- Suitable for particular child restraints (MITSUBISHI MOTORS genuine parts).

● B- Built-in restraint approved for this mass group.

● X- Seat position not suitable for children in this mass group.

Front Passenger Rear Outboard

bag

L*

L*

Deactivated Air-

1

bag*

2

L*

5

6

L*

L*

5

6

Left side Right side

3

L*2, L*

5

L*4, L*

6

L*

L*2, L*

L*4, L*

6

L*

3

5

E00406800034

Rear Centre

3

L*2, L*

5

L*4, L*

6

L*

2-50

L (Genuine part information)

N

Genuine parts No. ECE No.

2

*

3

*

4

*

5

*

6

*

MZ312807 E1-04301146

MZ313589 E1-04301146

MZ312745 E1-04301136

MZ313045 E1-04301133

MZ312808 E1-04301148

OTE

● There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0- Up to 10 kg”.

MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For detailed information, consult your MITSUBISHI MOTORS Authorized Service Point.

Seat and seat belts

2

2-51

Seat and seat belts

5-door models

Seating position

Mass Group

Front Passenger

Activated

Airbag

Deactivated

Airbag*

1

Rear Out-

board

0 - Up to 10 kg X X X

0+ - Up to 13 kg X

2

I - 9 to 18 kg

II & III - 15 to 36 kg

L*

L*

3

L*

6

7

L*

L*

6

7

3

L*

L*5, L*

7

L*

U*2, L*3, L*4U*2, L*3, L*

6

U*2, L*5, L*6U*2, L*5, L*

*1: With front passenger’s airbag deactivated by means of front passenger’s airbag ON-OFF switch.

2

: Adjust the angle of the seatback to the most upright position.

*

Key of letters to be inserted in the table above:

● U- Suitable for “universal” category restraints approved for use in this mass group.

● UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group.

● L- Suitable for particular child restraints (MITSUBISHI MOTORS genuine parts).

● B- Built-in restraint approved for this mass group.

● X- Seat position not suitable for children in this mass group.

Intermediate Outboard

Left side Right side

2

U*

U*2, L*

7

2

U*

U*2, L*

Intermediate

4

6

7

Centre

X

L*3, L*

L*5, L*

7

L*

4

6

2-52

L (Genuine part information)

N

Genuine parts No. ECE No.

3

*

4

*

5

*

6

*

7

*

MZ312807 E1-04301146

MZ313589 E1-04301146

MZ312745 E1-04301136

MZ313045 E1-04301133

MZ312808 E1-04301148

OTE

● There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0- Up to 10 kg”.

MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement.
For detailed information, consult your MITSUBISHI MOTORS Authorized Service Point.

Seat and seat belts

2

2-53

Seat and seat belts

Installing a child restraint system to the lower
anchorage (ISOFIX child restraint mountings)
and tether anchorage*

Lower anchorage location

Your vehicle’s rear seat (3-door models) / second seat (5-door
models) is fitted with lower anchorages for attaching a child
restraint system with ISOFIX mountings.

2

E00408900169

Tether anchorage locations

There are 2 attachment points on the floor, located behind the
rear seat (3-door models) / second seat (5-door models). These
are for securing a child restraint system tether strap to both of
the 2 rear (3-door models) / second (5-door models) seating
positions in your vehicle.

!

WARNING

● Child restraint anchorages are designed to with-

stand only those loads imposed by correctly fitted
child restraints. Under no circumstances are they to
be used for adult seat belts, or harnesses, or for
attaching other items or equipment to the vehicle.

2-54
