Q Series Large Type

Base Unit/Blank Cover

(AnS Series Size)

User's Manual

Q35BLS Q35BLS-D QG69LS Q38BLS Q38BLS-D Q65BLS Q65BLS-D Q68BLS Q68BLS-D Q55BLS Q55BLS-D

Thank you for purchasing the Mitsubishi Electric programmable controller MELSEC-Q series.

Prior to use, please read this and relevant manuals thoroughly to fully understand the product.

MODEL ANS-Q-LARGE-U MODEL

CODE

IB(NA)-0800495-E(1806)MEE

13J290

CONDITIONS OF USE FOR THE PRODUCT

(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in

conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; and ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.

(2) The PRODUCT has been designed and manufactured for the purpose of

being used in general industries. MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR the PRODUCT. ("Prohibited Application") Prohibited Applications include, but not limited to, the use of the PRODUCT in;

• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the public could be affected if any problem or fault occurs in the PRODUCT.

• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality assurance system is required by the Purchaser or End User.

• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other applications where there is a significant risk of injury to the public or property.

A-1

Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required. For details, please contact the Mitsubishi representative in your region.

A-2

REVISIONS

*The manual number is given on the bottom right of the cover.

Print date *Manual number Revision

January 2013 IB(NA)-0800495-A First edition

February 2013 IB(NA)-0800495-B Change of the external dimension diagram

November 2015 IB(NA)-0800495-C Descriptions regarding the Q series large type

December 2016 IB(NA)-0800495-D Descriptions are revised due to compliance with

June 2018 IB(NA)-0800495-E Descriptions are revised due to compliance with

base unit are added.

the new China RoHS.

the Chinese standardized law.

This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

A-3

1. OVERVIEW .................................................................................................... 1

1.1 Overview ............................................................................................... 1

1.2 Features ................................................................................................ 1

1.3 Supplied Parts....................................................................................... 3

2. SYSTEM CONFIGURATION.......................................................................... 5

2.1 System Configuration ............................................................................ 5

2.2 Precautions for System Configuration................................................. 10

2.3 Modules That Cannot be Mounted on the Q Series Large Type

Base Unit (AnS Series Size) ............................................................... 11

3. SPECIFICATIONS........................................................................................ 12

3.1 Specifications of the Q Series Large Type Base Unit

(AnS Series Size) ................................................................................ 12

3.2 Specifications of the Q Series Large Type Blank Cover

(AnS Series Size) ................................................................................ 14

4. PARTS NAMES ............................................................................................ 15

4.1 Parts Names ....................................................................................... 15

5. MOUNTING AND INSTALLATION ............................................................... 18

5.1 Handling Precautions .......................................................................... 18

5.2 Precautions for Installing the Q Series Large Type Base Unit

(AnS Series Size) ................................................................................ 19

5.3 Mounting and Installation of the Q Series Large Type Base Unit

(AnS Series Size) ................................................................................ 21

5.4 Mounting/Removing the Q Series Module .......................................... 23

6. EXTERNAL DIMENSIONS ........................................................................... 25

6.1 Q Series Large Type Base Unit (AnS Series Size) ............................. 25

6.2 Q Series Large Type Blank Cover (AnS Series Size) ......................... 29

A-4

TERMS

Unless otherwise specified, this manual uses the following generic terms and abbreviations to explain the Q series large type base units (AnS series size) and Q series large type blank cover (AnS series size).

Term Description

Q series large type base unit (AnS series size)

Q series large type main base unit (AnS series size)

Q series large type extension base unit (AnS series size)

Q series large type blank cover (AnS series size)

Q series

AnS series

High Performance model QCPU

Universal model QCPU

MELSECNET/H remote I/O module

Q3B

Q3DB

Q5B A generic term for the Q52B and Q55B extension base units

Q6B

QA1S5B Another term for the QA1S51B extension base unit

QA1S6B

QA6B

A generic term for the Q series large type main base unit (AnS series size) and Q series large type extension base units (AnS series size)

A generic term for the Q35BLS, Q38BLS, Q35BLS-D, and Q38BLS-D MELSEC-Q series main base units

A generic term for the Q65BLS, Q68BLS, Q55BLS, Q65BLS-D, Q68BLS-D, and Q55BLS-D MELSEC-Q series extension base units

The abbreviation for the QG69LS MELSEC-Q series blank cover

The abbreviation for Mitsubishi MELSEC-Q series programmable controller

The abbreviation for compact types of Mitsubishi MELSECA series programmable controller

A generic term for the Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU, and Q25HCPU

A generic term for the Q00UJCPU, Q00UCPU, Q01UCPU, Q02UCPU, Q03UDCPU, Q03UDVCPU, Q03UDECPU, Q04UDHCPU, Q04UDVCPU, Q04UDEHCPU, Q06UDHCPU, Q06UDVCPU, Q06UDEHCPU, Q10UDHCPU, Q10UDEHCPU, Q13UDHCPU, Q13UDVCPU, Q13UDEHCPU, Q20UDHCPU, Q20UDEHCPU, Q26UDHCPU, Q26UDVCPU, Q26UDEHCPU, Q50UDEHCPU, and Q100UDEHCPU

A general term for the QJ72LP25-25, QJ72LP25G, and QJ72BR15

A generic term for the Q33B, Q35B, Q38B, and Q312B main base units

A generic term for the Q35DB, Q38DB, and Q312DB multiple CPU high speed main base units

A generic term for the Q63B, Q65B, Q68B, and Q612B extension base units

A generic term for the QA1S65B and QA1S68B extension base units

A generic term for the QA65B and QA68B extension base units

A-5

B

QA6ADP

QA6ADP+A5

Term Description

A generic term for the A52B, A55B, and A58B extension base units

A generic term for the A62B, A65B, and A68B extension base units

The abbreviation for the QA6ADP QA conversion adapter module

B/A6B

The abbreviation for the A large type extension base unit on which QA6ADP is mounted

A-6

1. OVERVIEW

1.1 Overview

The products are used to replace the AnS series with the Q series when the existing installation site and cables are utilized.

This manual explains specifications, component devices, part names, settings, mounting, and installation of the Q series large type base unit (AnS series size) and Q series large type blank cover (AnS series size). For contents not explained in this manual such as SAFETY PRECAUTIONS, EMC and Low Voltage Directives, and general specifications, refer to the following manual:

QCPU User's Manual (Hardware Design, Maintenance and Inspection)

1.2 Features

This section explains features of the Q series large type base unit (AnS series size) and Q series large type blank cover (AnS series size).

(1) The Q series large type base unit (AnS series size) is available in

two types; DIN rail mounting type and panel mounting type. Select the suitable type of a base unit for the operating environment.

Mounting type Main base unit Extension base unit

Panel mounting type

DIN rail mounting type

Q35BLS Q38BLS

Q35BLS-D Q38BLS-D

Q65BLS Q68BLS Q55BLS

Q65BLS-D Q68BLS-D Q55BLS-D

(2) Since the Q series large type base unit (AnS series size) has the

QX40

Q12HCPU

MODE

ERR. USER

AT.

BOOT

PULL

USB

RS-232

MELSEC

Q62P

PULL

Q series module

Q series large type base unit (AnS series size)

Q series large type blank cover (AnS series size)

(3) Mount the Q series module on the Q series large type base unit

same mounting dimensions with the AnS series base unit, the same mounting holes can be utilized. The following table shows the corresponding models for replacement.

AnS series base unit

A1S35B Q35BLS

A1S38B Q38BLS

A1S65B Q65BLS

A1S68B Q68BLS

A1S55B Q55BLS

Q series large type base unit

(AnS series size)

(AnS series size).

The renewal tool manufactured by MITSUBISHI ELECTRIC ENGINEERING COMPANY LIMITED (hereafter, abbreviated as renewal tool) can be mounted on the module, and a connector and terminal block used with the AnS series can be used without wiring change.

*1 To mount the Q series module on the I/O slot of the Q series large type base unit (AnS

series size), always attach the Q series large type blank cover (AnS series size).

1.3 Supplied Parts

(1) Q series large type main base unit (AnS series size)

(panel mounting type)

Product Model Quantity Remarks

Q35BLS

Q series large type main base unit (AnS series size)

Base unit mounting screw - 4 M5 × 25 screw

This manual IB-0800495 1 -

Safety Guidelines

*1 The Q series large type extension base unit (AnS series size) does not include with the

guidelines.

(2) Q series large type main base unit (AnS series size)

(DIN rail mounting type)

Product Model Quantity Remarks

Q series large type main base unit (AnS series size)

DIN rail mounting adapter

End fitting L - 1 -

End fitting R - 1 -

Fixing bracket for terminal block conversion adapter

Bracket fixing screw - 6 M4×8 screw

*1*2

Q38BLS

Q65BLS

Q68BLS

Q55BLS

IB-0800423 1 -

Q35BLS-D

Q38BLS-D

Q65BLS-D

Q68BLS-D

Q55BLS-D

Q6DIN1 or Q6DIN2 1

-1 -

1 -

Q6DIN1 (Includes 2 adapters (large), 4 adapters (small),

3 square washers,

and 3 mounting screws

Q6DIN2 (Includes 2 adapters (large), 3 adapters (small),

2 square washers,

and 2 mounting screws

(M5×10))

Product Model Quantity Remarks

This manual IB-0800495 1 -

Safety Guidelines

*1 For a combination of the DIN rail mounting adapter, refer to the following:

Q6DIN1: Q38BLS-D and Q68BLS-D Q6DIN2: Q35BLS-D, Q65BLS-D, and Q55BLS-D

*2 The stopper for DIN rail mounting adapter is not included with this base unit since the end

fitting is substitutable.

*3 The Q series large type extension base unit (AnS series size) does not include with the

guidelines.

IB-0800423 1 -

(3) Q series large type blank cover (AnS series size)

Product Model Quantity Remarks

Q series large type blank cover (AnS series size)

QG69LS 1 -

2. SYSTEM CONFIGURATION

CPU01234567

Power supply module

CPU module

Q series large type main base unit (AnS series size) (Q3BLS, Q3BLS-D), Q series main base unit (Q3B, Q3DB), or Q series large type main base unit (Q3BL)

Q series extension base unit (Q5B, Q6B), Q series large type extension base unit (AnS series size) (Q6BLS, Q6BLS-D, Q55BLS, Q55BLS-D), or Q series large type extension base unit (Q6BL, Q55BL)

Q series extension base unit on which AnS series module can be mounted (QA1S5B, QA1S6B)

Q series extension base unit on which A series module can be mounted (QA6B)

QA conversion adapter + A/QnA series extension base unit (QA6ADP + A5B/A6B)

Main base unit

Extension base unit

Slot number

8 9 10 11 12 13 14 15

16 17 18 19 20 21 22 23

24 25 26 27 28 29 30 31

32 33 34 35 36 37 38 39

2.1 System Configuration

This section explains system configuration when using the Q series large type base unit (AnS series size). The following modules can be mounted on the CPU slot of the Q series large type base unit (AnS series size).

• High Performance model QCPU

• Universal model QCPU (except Q00UJCPU)

• MELSECNET/H remote I/O module

(1) System configuration using the High Performance model QCPU

and Universal model QCPU

For a combination of the CPU modules and base units, refer to the "Precautions" section. The following table shows restrictions on system configuration.

Maximum number of extension stages of extension base units

Maximum number of mountable I/O modules

Applicable main base unit model

Applicable extension base unit model

Extension cable model QC05B, QC06B, QC12B, QC30B, QC50B, and QC100B

Q series power supply module model

AnS series power supply module model

A series power supply module model

Q00UCPU, Q01UCPU, and Q02UCPU: 4 extension stages Modules other than the above: 7 extension stages

• Q00UCPU and Q01UCPU: 24 modules

• Q02UCPU: 36 modules

Modules other than the above: 64 modules

Q33B, Q35B, Q38B, Q312B, Q35DB, Q38DB, Q312DB, Q35BLS, Q38BLS, Q35BLS-D, Q38BLS-D, Q35BL, and Q38BL

Model requiring no power supply module

Model requiring Q series power supply module

Model requiring no AnS series power supply module

Model requiring AnS series power supply module

Model requiring A series power supply module

Q61P-A1, Q61P-A2, Q61P, Q61P-D, Q62P, Q63P, Q64P, and Q64PN

A1S61PN, A1S62PN, and A1S63P

A61P, A61PN, A62P, A63P, A61PEU, and A62PEU

Q52B, Q55B, Q55BLS, Q55BLS-D, Q55BL, and QA6ADP+A5

Q63B, Q65B, Q68B, Q612B, Q65BLS, Q68BLS, Q65BLS-D, Q68BLS-D, Q65BL, and Q68BL

QA1S51B

QA1S65B and QA1S68B

QA65B, QA68B, and QA6ADP+A6

B

Precautions

• Use extension cable so that the overall extension length can be within 13.2m.

• Do not install the extension cable together with the main circuit (high voltage and high current) line or bring them close to each other. Keep a distance of 100mm or more between them.

• Set the number of extension stages so that the number is not duplicated with another.

• When using extension base units on which AnS/A series modules can be mounted together with the other units, follow the instructions described below.

• Connect the units in order of Q5 Q5

BLS(-D)/Q6BLS(-D)/Q5BL/Q6BLQA1S5B/

QA1S6

BQA6BQA6ADP+A5B/A6B from the

nearest position of the main base unit.

• The QA1S6 used together.

• Since the QA1S51B does not have an extension cable connector (OUT), it cannot be used with the QA6 QA6ADP+A5

• Assign module I/O number with putting each series in block so that the order can be "from Q series to A series" or "from A series to Q series". Failure to do so causes an error "SP.UNIT LAY ERR." (error code: 2120). In addition, do not duplicate the I/O number.

• Connect the extension cable from OUT of the extension cable connector on the base unit to IN of the extension base unit on the next stage.

• If the number of mounted modules exceeds the maximum number of mountable I/O modules, an error "SP.UNIT LAY ERR." (error code: 2124) occurs.

• To construct a multiple CPU system, use a main base unit, Q3

B or Q3DB.

• To use the Universal model QCPU with the extension base units QA1S5 use the Universal model QCPU whose serial number (first five digits) is "13102" or later.

B and QA6ADP+A5 B/A6B cannot be

B/A6B.

B, QA1S6B, QA6B, and QA6ADP+A5B/A6B,

B/Q6B/

B and

(2) System configuration using the MELSECNET/H remote I/O

module

Main base unit

Extension base unit

CPU01234567

MELSECNET/H remote I/O module

Power supply module

8 9 10 11 12 13 14 15

16 17 18 19 20 21 22 23

Slot number

Q series large type main base unit (AnS series size) (Q3BLS, Q3BLS-D), Q series main base unit (Q3B, Q3DB), or Q series large type main base unit (Q3BL)

Q series large type extension base unit (AnS series size) (Q6BLS, Q6BLS-D, Q55BLS, Q55BLS-D), Q series extension base unit (Q5B, Q6B), or Q series large type extension base unit (Q6BL, Q55BL)

24 25 26 27 28 29 30 31

The following table shows restrictions on system configuration.

Maximum number of extension stages of extension base units

Maximum number of mountable I/O modules

Applicable main base unit model

Applicable extension base unit model

Extension cable model QC05B, QC06B, QC12B, QC30B, QC50B, and QC100B

Q series power supply module model

7 extension stages

64 modules

Q33B, Q35B, Q38B, Q35BLS, Q38BLS, Q35BLS-D, Q38BLS-D, Q35BL, and Q38BL

Model requiring no power supply module

Model requiring Q series power supply module

Q61P-A1, Q61P-A2, Q61P, Q61P-D, Q62P, Q63P, Q64P, and Q64PN

Q52B, Q55B, Q55BLS, Q55BLS-D, and Q55BL

Q63B, Q65B, Q68B, Q612B, Q65BLS, Q68BLS, Q65BLS-D, Q68BLS-D, Q65BL, and Q68BL

Precautions

• Use extension cable so that the overall extension length can be within 13.2m.

• Do not install the extension cable together with the main circuit (high voltage and high current) line or bring them close to each other.

• Keep a distance of 100mm or more between them.

• Set the number of extension stages so that the number is not duplicated with another.

• Connect the extension cable from OUT of the extension cable connector on the base unit to IN of the extension base unit on the next stage.

• If the number of mounted modules exceeds the maximum number of mountable I/O modules, an error "SP.UNIT LAY ERR." (error code: 2124) occurs.

2.2 Precautions for System Configuration

This section explains precautions for using the products.

(1) A multiple CPU system cannot be constructed using the Q series

large type main base unit (AnS series size).

(2) To construct a multiple CPU system with the Q series large type

extension base unit (AnS series size), use a main base unit, Q3

B or Q3DB.

QCPU User's Manual (Multiple CPU System)

When read the manual, regard the descriptions for the Q5

B/Q6

B as the Q series large type extension base unit (AnS series

size) because the handing of the Q series large type extension base unit (AnS series size) is the same as that of the Q5

B/Q6B.

(3) To mount the Q series module on Q series large type base unit

(AnS series size), always attach the Q series large type blank cover (AnS series size). (The cover is not necessary for a module mounted on CPU slot and power supply.)

(4) In Q series large type (AnS series size), the extension cable

connector is not on the right side of the base unit. When the extension cable is used, make sure the cable lengths and the way to connect the cable.

2.3 Modules That Cannot be Mounted on the Q Series Large Type Base Unit (AnS Series Size)

This section explains modules that cannot be mounted on the Q series large type base unit (AnS series size).

(1) Two-slot module

Ex. Q64TCRTBW, Q64TCRTBWN, Q64TCTTBW,

Q64TCTTBWN, QD70D4, QD70D8, QJ71LP21S-25, and QJ71GP21S-SX

(2) Module on which the Q series large type blank cover (AnS series

size) cannot be attached

• Module whose height exceeds 98mm

• Module with a bracket on its top

• Module having a projection (such as a connector) on its bottom

• Module on which the Q7BAT-SET has been mounted

Ex. Q66AD-DG, Q66DA-G, Q68AD-G, Q68RD3-G, Q68TD-G-H02,

Q64AD2DA, QD75M1, QD75MH1, QD75M2, QD75MH2, QD75M4, QD75MH4, and the QJ71WS96 on which the Q7BAT-SET has been mounted

A module with a bracket cannot be mounted.

A module with the height exceeding 98mm cannot be mounted.

A two-slot module cannot be mounted.

A module having a projection (such as a connector) on its bottom cannot be mounted.

3. SPECIFICATIONS

3.1 Specifications of the Q Series Large Type Base Unit (AnS Series Size)

The following tables show performance specifications of the Q series large type base unit (AnS series size).

(1) Q series large type main base unit (AnS series size)

Item

Number of mountable I/O

modules

Extendability Extendable

Applicable module Q series module

5 VDC internal current

consumption

Size of mounting hole 6 hole (for M5 screw) -

External dimensions

Weight 0.82kg 1.32kg 0.59kg 0.72kg

Accessory Section 1.3 (1) Section 1.3 (2)

DIN rail installation Not installable Installable

Q35BLS Q38BLS Q35BLS-D Q38BLS-D

5858

0.11A 0.12A 0.11A 0.12A

H 130mm 118mm

W 325mm 430mm 311mm 416mm

D 53mm 48.5mm

Model

(2) Q series large type extension base unit (AnS series size)

Item

Number of mountable I/O

modules

Extendability Extendable

Applicable module Q series module

5 VDC internal current

consumption

Size of m ounting hole 6hole (for M5 screw) -

External dimensions

Weight 0.98kg 1.32kg 0.57kg 0.74kg

Accessory Section 1.3 (1) Section 1.3 (2)

DIN rail installation Not installable Installable

Q65BLS Q68BLS Q65BLS-D Q68BLS-D

5858

0.11A 0.12A 0.11A 0.12A

H 130mm 118mm

W 315mm 420mm 304mm 409mm

D 53mm 48.5mm

Model

(3) Q series large type extension base unit (Ans series size)

(without power supply)

Item

Number of mountable I/O

modules

Extendability Extendable

Applicable module Q series module

5 VDC internal current

consumption

Size of mounting hole 6hole (for M5 screw) -

External dimensions

Weight 0.82kg 0.51kg

Accessory Section 1.3 (1) Section 1.3 (2)

DIN rail installation Not installable Installable

Q55BLS Q55BLS-D

H 130mm 118mm

W 260mm 248mm

D 53mm 48.5mm

Model

0.1A

3.2 Specifications of the Q Series Large Type Blank Cover (AnS Series Size)

The following tables show performance specifications of the Q series large type blank cover (AnS series size).

Item

External dimensions

Weight 0.03kg

H 108mm

W 34.5mm

D 54mm

Model

QG69LS

4. PARTS NAMES

4.1 Parts Names

This section explains the part names of the Q series large type base unit (AnS series size) and Q series large type blank cover (AnS series size).

(1) Q series large type base unit (AnS series size)

(panel mounting type)

5)6)1) 4)

No. Name Description

1) Extension cable connector

2) Base cover Protective cover of extension cable connector

3) Module connector

4) Module fixing screw hole

5) Base mounting hole

Terminal block conversion

6) adapter fixing hole

Connector for connecting an extension cable (for signal communications with the extension base unit)

Connector for mounting power supply module, CPU module, Q series large type I/O module, and MELSEC-Q series module

Screw hole for fixing a module to the base unit (screw size: M3×12)

Hole for installing the base unit on a panel such as control panel (for M5 screw)

Screw hole for fixing a terminal block conversion adapter (screw size: M3×8)

(2) Q series large type base unit (AnS series size)

(DIN rail mounting type)

1) 4) 6)

7) 8)

No. Name Description

1) Extension cable

2) Base cover Protective cover of extension cable connector

3) Module connector

4) Module fixing screw hole

5) End fitting L End stop bracket for fixing a module to the base unit.

6) End fitting R

Fixing bracket for terminal

7) block conversion adapter

Terminal block conversion

8) adapter fixing hole

DIN rail adapter installation

9) hole

Connector for connecting an extension cable (for signal communications with the extension base unit)

Connector for mounting power supply module, CPU module, Q series large type I/O module, and MELSEC-Q series module

Screw hole for fixing a module to the base unit (screw size: M3

End fitting L is engraved with "L" and end fitting R is engraved with "R".

Bracket for fixing a terminal block conversion adapter

Screw hole for fixing a terminal block conversion adapter (screw size: M3

Hole for installing a DIN rail adapter

×12)

×8)

(3) Part names of the Q series large type blank cover (AnS series

size)

No. Name Description

1) Top fixing hook

2) Bottom fixing hook

3) Module fixing screw

Hook for fixing the Q series large type blank cover (AnS series size) to the Q series module top

Hook for fixing the Q series large type blank cover (AnS series size) to the Q series module bottom

Screw for fixing a module to the Q series large type base unit (AnS series size). (screw size: M3×12)

5. MOUNTING AND INSTALLATION

5.1 Handling Precautions

This section explains handling precautions for the Q series large type base unit (AnS series size) and Q series large type blank cover (AnS series size).

(1) Do not disassemble the Q series large type base unit (AnS series

size) since it is precision apparatus.

(2) Always mount the power supply module on the Q series large type

extension base unit (AnS series size) excluding the Q55BLS and Q55BLS-D. When the load of a module used is light, the module may operate without power supply module; however, the operation cannot be guaranteed because of its instability.

(3) Tighten the module fixing screws and other screws within the

following range.

Location of screw

Module fixing screw (M3×12 screws) 0.36 to 0.48N•m Base cover fixing screw 0.36 to 0.48N•m Bracket fixing screw (M4×8 screws) 1.00 to 1.35N•m End fitting stopper screw (M4×8 screws) 1.00 to 1.35N•m

(4) Do not install the extension cable together with the main circuit

(high voltage and high current) line or bring them close to each other. Keep a distance of 100mm or more between them.

Tightening torque

range

5.2 Precautions for Installing the Q Series Large Type Base Unit (AnS Series Size)

(1) Module installation position

Provide the following distances between the top and bottom of the module and other structure or components to ensure ventilation for heat dissipation and to change the module easily.

Indicates the control panel top, wiring duct, or any part position.

*5, *6

5mm or more *2, *6

*1 30mm or more is required when writing duct is 50mm or less in height. Otherwise, at least

40mm is required.

*2 20mm or more is required when the extension cable is connected without removing

adjacent modules.

*3 80mm or more is required when the connector type is used. For Q8BAT, 80mm or more is

required when the connection cable for Q8BAT is used. *4 For Q7BAT, 45mm or more is required. *5 For Q8BAT, 30mm or more is required from both top and bottom sides of the module. *6 For Q8BAT, 5mm or more is required from both left and right sides of the module.

30mm or more

*1, *5 Control panel

30mm

or more

*4, *5

5mm or more *6

Programmable controller

20mm or more *3

Door

(2) Module installation direction

(a) Install the programmable controller in the direction shown

below to ensure ventilation for heat dissipation.

(b) Do not install it in the directions shown below.

Vertical mounting

Horizontal installation

(3) Install the base unit on a flat surface.

When the base unit is installed on an uneven surface, the printedcircuit board may be strained, resulting in a malfunction.

(4) Do not install the programmable controller together with a vibration

source such as a large electromagnetic contactor or non-fuse breaker. Install the programmable controller to the separate panel or isolate it as far as possible.

(5) Provide the following distances between the programmable

controller and devices (contactor and relay) to avoid the influence of radiated noise or heat.

• Device installed in front of the programmable controller: 100mm or more

• Device installed on either side of the programmable controller: 50mm or more

At least 50mm

At least 100mm

Contactor, relay, etc.

At least 50mm

5.3 Mounting and Installation of the Q Series Large Type Base Unit (AnS Series Size)

The following explains how to mount or install the Q series large type base unit (AnS series size).

(1) Installing a base unit on a panel

To install a base unit on a panel such as a control panel, tighten the base unit mounting screws.

(2) Mounting a base unit on a DIN rail

The following shows a procedure to mount the base unit on a DIN rail.

(a) Installing DIN rail mounting adapter

The following figures show how to install the DIN rail mounting adapters on the base unit rear.

Base unit rear

Place the hook of the adapter (small) in the lower hole.

Insert the adapter (large) into the grooves of the base unit from below.

(b) Mounting on a DIN rail

Remove the base cover and mount the base unit on a DIN rail. Put the base cover on after the completion of the next step, (c). When extension bases are used, determine the number of extension stages in this step.

Base cover

DIN rail

Push the top of the adapter (small) far enough until it "clicks".

Push the bottom of the adapter (large) far enough until it "clicks".

End fitting L

Stopper screw

Attach the end fitting L and R on the both ends of a DIN rail. Slide them to the position of the end fitting mounting holes on the base unit. Loosen the stopper screws and hitch the hooks of the stopper to the DIN rail. Tighten the bracket fixing screws on each corner to firmly lock the end fitting in place.

M4 8 screw

Stopper screw

M4 8 screw

End fitting R

Stopper

Stopper screw

End fitting

DIN rail

Hitch both hooks of the stopper to the DIN rail. Tilt the stopper slightly downward if the hook does not come out from the stopper.

(d) Fixing bracket for terminal block conversion adapter

installation Hook the fixing bracket for terminal block conversion adapter to the bottom side of a DIN rail. Place the bracket to the mounting hole for the end fitting L and R, then tighten the bracket fixing screws on each side to fix the bracket.

M4 8 screw

Fixing bracket for terminal block conversion adapter

5.4 Mounting/Removing the Q Series Module

The following shows procedures for mounting the Q series module on the Q series large type base unit (AnS series size).

(1) Attaching the Q series large type blank cover

The following shows a procedure for attaching the Q series large type blank cover (AnS series size) to the Q series module.

Hitch the module fixing part at the bottom of the Q series large type blank cover (AnS series size) to the slit at the bottom of the Q series module so that the back faces of the blank cover and the module can contact.

Push the top of the Q series large type blank cover (AnS series size) toward the Q series module, and hitch the top fixing hook to the slit at the top of the Q series module.

End

Back face

Point

When mounting the Q series module with Q series large type blank cover (AnS series size) on the Q series large type base unit (AnS series size), always tighten the module fixing screws of the Q series large type blank cover (AnS series size).

Q series module

Q series large type blank cover (AnS series size)

Module fixing part

Q series large type blank cover (AnS series size)

Top fixing hook

Q series module

(Bottom view)

(2) Removing the Q series large type blank cover (AnS series size)

To remove the Q series large type blank cover (AnS series size) from the Q series module, remove the bottom fixing hook first.

(3) Mounting to/removal from the Q series large type base unit

For procedures of mounting/removing the Q series module on/from the Q series large type base unit, refer to the following manual.

QCPU User's Manual (Hardware Design, Maintenance and Inspection)

6. EXTERNAL DIMENSIONS

The following shows external dimensions diagrams of the Q series large type base unit (AnS series size) and Q series large type blank cover (AnS series size).

6.1 Q Series Large Type Base Unit (AnS Series Size)

(1) Q35BLS

4-Mounting screw (M5 25)

110

130

(2) Q35BLS-D

48.5

305 325

118

311

Unit: mm

(3) Q38BLS

4-Mounting screw (M5 25)

130

110

53 430

(4) Q38BLS-D

118

48.5

(5) Q65BLS

4-Mounting screw (M5 25)

110

130

410

416

Unit: mm

295

315

Unit: mm

(6) Q65BLS-D

118

48.5

(7) Q68BLS

4-Mounting screw (M5 25)

110

130

(8) Q68BLS-D

118

48.5

400 420

409

304

Unit: mm

(9) Q55BLS

4-Mounting screw

(M5 25)

(10) Q55BLS-D

130

110

240

260

118

Unit: mm

24848.5

Unit: mm

6.2 Q Series Large Type Blank Cover (AnS Series Size)

(1) QG69LS

(1.8)

108

(1.8)

34.5

Unit: mm

WARRANTY

Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi; damages to products other than Mitsubishi products; and to other duties.

Country/

Sales office/

Region

Tel

USA MITSUBISHI ELECTRIC AUTOMATION, INC.

500 Corporate Woods Parkway, Vernon Hills, IL 60061, U.S.A. Tel : +1-847-478-2100

Mexico MITSUBISHI ELECTRIC AUTOMATION, INC.

Mexico Branch Mariano Escobedo #69, Col. Zona Industrial, Tlalnepantla Edo. Mexico, C.P.54030 Tel : +52-55-3067-7500

Brazil MITSUBISHI ELECTRIC DO BRASIL COMÉRCIO

E SERVIÇOS LTDA. Avenida Adelino Cardana, 293, 21 andar, Bethaville, Barueri SP, Brazil Tel : +55-11-4689-3000

Germany MITSUBISHI ELECTRIC EUROPE B.V. German

Branch Mitsubishi-Electric-Platz 1, 40882 Ratingen, Germany Tel : +49-2102-486-0

UK MITSUBISHI ELECTRIC EUROPE B.V. UK Branch

Travellers Lane, Hatfield, Hertfordshire, AL10 8XB, U.K. Tel : +44-1707-28-8780

Ireland MITSUBISHI ELECTRIC EUROPE B.V. Irish

Branch Westgate Business Park, Ballymount, Dublin 24, Ireland Tel : +353-1-4198800

Italy MITSUBISHI ELECTRIC EUROPE B.V. Italian

Branch Centro Direzionale Colleoni-Palazzo Sirio Viale Colleoni 7, 20864 Agrate Brianza(Milano) Italy Tel : +39-039-60531

Spain MITSUBISHI ELECTRIC EUROPE, B.V. Spanish

Branch Carretera de Rubí, 76-80-Apdo. 420, 08190 Sant Cugat del Vallés (Barcelona), Spain Tel : +34-935-65-3131

France MITSUBISHI ELECTRIC EUROPE B.V. French

Branch 25, Boulevard des Bouvets, 92741 Nanterre Cedex, France Tel : +33-1-55-68-55-68

Czech

MITSUBISHI ELECTRIC EUROPE B.V. Czech

Republic

Branch Avenir Business Park, Radlicka 751/113e, 158 00 Praha5, Czech Republic Tel : +420-251-551-470

Poland MITSUBISHI ELECTRIC EUROPE B.V. Polish

Branch ul. Krakowska 50, 32-083 Balice, Poland Tel : +48-12-347-65-00

Sweden

MITSUBISHI ELECTRIC EUROPE B.V. (Scandinavia) Fjelievägen 8, SE-22736 Lund, Sweden Tel : +46-8-625-10-00

Russia MITSUBISHI ELECTRIC (RUSSIA) LLC St.

Petersburg Branch Piskarevsky pr. 2, bld 2, lit “Sch”, BC “Benua”, office 720; 195027 St. Petersburg, Russia Tel : +7-812-633-3497

HEAD OFFICE : TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN

NAGOYA WORKS : 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA, JAPAN

When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.

Sales office/

Country/

Tel

Region

MITSUBISHI ELECTRIC TURKEY A.Ş Ümraniye

Turkey

Branch Serifali Mahallesi Nutuk Sokak No:5, TR-34775 Umraniye/Istanbul, Turkey Tel : +90-216-526-3990 MITSUBISHI ELECTRIC EUROPE B.V. Dubai

UAE

Branch Dubai Silicon Oasis, P.O.BOX 341241, Dubai, U.A.E. Tel : +971-4-3724716 ADROIT TECHNOLOGIES

South

20 Waterford Office Park, 189 Witkoppen Road,

Africa

Fourways, South Africa Tel : +27-11-658-8100

MITSUBISHI ELECTRIC AUTOMATION (CHINA)

China

LTD. No.1386 Hongqiao Road, Mitsubishi Electric Automation Center, Shanghai, China Tel : +86-21-2322-3030 SETSUYO ENTERPRISE CO., LTD.

Taiwan

6F, No.105, Wugong 3rd Road, Wugu District, New Taipei City 24889, Taiwan Tel : +886-2-2299-2499 MITSUBISHI ELECTRIC AUTOMATION KOREA

Korea

CO., LTD. 7F-9F, Gangseo Hangang Xi-tower A, 401, Yangcheon-ro, Gangseo-Gu, Seoul 07528, Korea Tel : +82-2-3660-9530

Singapore

MITSUBISHI ELECTRIC ASIA PTE. LTD. 307, Alexandra Road, Mitsubishi Electric Building, Singapore 159943 Tel : +65-6473-2308

Thailand

MITSUBISHI ELECTRIC FACTORY AUTOMATION (THAILAND) CO., LTD. 12th Floor, SV.City Building, Office Tower 1, No. 896/19 and 20 Rama 3 Road, Kwaeng Bangpongpang, Khet Yannawa, Bangkok 10120, Thailand Tel : +66-2682-6522

Vietnam

MITSUBISHI ELECTRIC VIETNAM COMPANY LIMITED Hanoi Branch 6th Floor, Detech Tower, 8 Ton That Thuyet Street, My Dinh 2 Ward, Nam Tu Liem District, Hanoi, Vietnam Tel : +84-4-3937-8075

Indonesia

PT. MITSUBISHI ELECTRIC INDONESIA Gedung Jaya 11th Floor, JL. MH. Thamrin No.12, Jakarta Pusat 10340, Indonesia Tel : +62-21-3192-6461

India

MITSUBISHI ELECTRIC INDIA PVT. LTD. Pune Branch Emerald House, EL-3, J Block, M.I.D.C., Bhosari, Pune-411026, Maharashtra, India Tel : +91-20-2710-2000

Australia MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.

348 Victoria Road, P.O. Box 11, Rydalmere, N.S.W 2116, Australia Tel : +61-2-9684-7777

Specifications subject to change without notice.

Mitsubishi Electric ANS-Q-LARGE-U, Q35BLS, Q38BLS, Q38BLS-D, Q65BLS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

CONDITIONS OF USE FOR THE PRODUCT

REVISIONS

CONTENTS

TERMS

1. OVERVIEW

1.1 Overview

1.2 Features

1.3 Supplied Parts

2. SYSTEM CONFIGURATION

2.1 System Configuration

2.2 Precautions for System Configuration

2.3 Modules That Cannot be Mounted on the Q Series Large Type Base Unit (AnS Series Size)

3. SPECIFICATIONS

3.1 Specifications of the Q Series Large Type Base Unit (AnS Series Size)

3.2 Specifications of the Q Series Large Type Blank Cover (AnS Series Size)

4. PARTS NAMES

4.1 Parts Names

5. MOUNTING AND INSTALLATION

5.1 Handling Precautions

5.2 Precautions for Installing the Q Series Large Type Base Unit (AnS Series Size)

5.3 Mounting and Installation of the Q Series Large Type Base Unit (AnS Series Size)

5.4 Mounting/Removing the Q Series Module

6. EXTERNAL DIMENSIONS

6.1 Q Series Large Type Base Unit (AnS Series Size)

6.2 Q Series Large Type Blank Cover (AnS Series Size)

WARRANTY
