3
OAH186
OUTLINES AND DIMENSIONS
MR-WX700C-A
(Display)
(Display)
(Cabinet)
(Display)
Unit: mm
378(Front)/407(Rear)
(Pitch between the rear wheels)
(Max.)
(Min.)
(Max.)
(Min.)
(Min.)
(Max.)
(Pitch between the adjust bolts)
(Pitch between the front wheels)
(Max.)
(Min.)
(Max.)
(Min.)
(Min.)
(Max.)
2,240
1,722
(Excluding the adjustable support cover)
(Including the adjustable support cover)
200
Distance between the
refrigerator body and
the wall to open the door
to 90 degrees
7.5
7.5
REQUIRED SPACE FOR INSTALLATION
50
1,821
949
Bottle pocket (Large)Bottle pocket (Small)
Adjustable Pocket (Small)
Adjustable Pocket (Large)
738
748
(Including the
adjustable support cover)
800
5 5
991
192
352
1,216
DOOR DIMENSION
R(L) R(R) I S F V
Height 865 865 207 207 324 367
Width 284 510 284 510 800 800
R(L) : Refrigerator compartment (Left)
R(R) : Refrigerator compartment (Right)
I : Ice making compartment
S : Supercool freezing compartment
F : Freezer compartment
V : Vegetable compartment
