Contents

Why Choose
Mitsubishi Electric?

4

Product Line-up 6

Wall-Mounted

MSZ-LN Series 8
MSZ-EF Series 10
MSZ-AP Series 12

Floor Standing

MFZ-KJ Series 14

Ceiling-Cassette

SLZ Series 16

Ceiling-Concealed

SEZ Series 17

Controls 18

Wi-Fi Control 19

Functions 20

Specifications 22

03

Why Choose
Mitsubishi Electric?

As a leading company in the industry, Mitsubishi Electric has a proud history in the
manufacturing and supply of leading edge electrical and electronic equipment for both
domestic and commercial use. Our efforts to make indoor life more comfortable began in 1921,
with the introduction of our first electric fan which became an instant hit. Some 10 years later
we began to manufacture coolers, which were just as popular.

Our commitment to quality service, research and development has helped us gain a leading
position in today’s marketplace in a wide variety of areas including heating, cooling and air
conditioning. Mitsubishi Electric’s ‘today technology’ provides controlled comfort wherever you
live, work and relax.

Whether it’s consistent heating and cooling for the home or office, Mitsubishi Electric offers you
state-of-the-art technology that is quiet, simple to use, energy efficient and above all, reliable.

04

3D i-See Sensor

Rated Capacity

Measured Capacity

Setting Temperature

Indoor Temperature

Mitsubishi Electric strive for the perfect balance of performance,
reliability, low power consumption and a long operational life
span for all of our products. The 3D i-See Sensor is an infrared
sensor that measures the temperature at distant positions, while
moving from left to right. The airflow speed and temperature are
adjusted to prevent over-heating/cooling, thereby helping reduce
consumption of excessive electricity. (LN Model only)

30°C

Low High

22°C

Cooling

Floor-level temperature
is monitored to prevent
excessive cooling.

Heating

Floor-level temperature
is monitored to determine
if heating is needed.

Inverter Technology

Mitsubishi Electric inverter technologies ensure superior performance
including the optimum control of operation frequency. Optimum power
is applied in all heating/cooling ranges and maximum comfort is
achieved while reducing energy consumption.

Flexible Choice

Mitsubishi Electric air conditioners range from wall-mounted,
floor-standing, ceiling-concealed, ceiling-cassette to ceiling-suspended
units, which are suitable for your application.

Economic Operation

Impressively low operating cost is a key advantage of inverter air
cutting-edge electronics and mechanical technologies to achieve
a synergistic effect that enables improvements in heating/cooling
efficiency.

Quiet Operation

We recognise that noise affects comfort, so we constantly work to
make our air conditioners as quiet as possible. With improvements
to our fan blades combined with grille shape to our outdoor unit,
it’s even quieter when in low noise mode. We want you to feel the
comfort, not hear it.

Noise Level

Train

Interior

Quiet

Passenger

Car Interior

(40km/h)

Library
Interior

Sound

of Rustling

Leaves

MSZ-AP (25&35)

Human

Hearing Limits

(Extremely Quiet)

Ultimate Comfort and Modern Design

Mitsubishi Electric provide attractive air conditioners which range in
a variety of designs to suit diversified needs; with stylish lines for the
living room and quiet operation for the bedroom, our air conditioners
provide advanced air control which is smart and sophisticated.

Peace of Mind

Mitsubishi Electric’s air conditioners range used in residential
applications are covered by a full 5 year parts and labour warranty.
Delivering quality performance year in year out.

See website for terms and conditions.

80dB 60dB 40dB 20dB 10dB

19dB

05

Product Line up

WALL-MOUNTED

MSZ-LN Series

2.5kW 3.5kW 5.0kW 6.0kW 7.1kW 8.0kW

   

» Heating & Cooling
» Inverter Technology
» Double Vane
» 24 Hour Timer

» Natural Flow
» Quiet Operation
» Plasma Quad

Plus Filter

MSZ-EF Series

2.5kW 3.5kW 4.2kW 5.0kW 6.0kW 7.1kW 8.0kW

   

» Heating & Cooling
» Inverter Technology
» Auto Vane
» 24 Hour Timer

» 3 Colours Available

White, Silver & Black

» Nano Platinum Filter
» Weekly Timer

MSZ-AP Series

2.5kW 3.5kW 4.2kW 5.0kW 6.0kW 7.1kW 7.8kW

      

» Heating & Cooling
» Inverter Technology
» R32 Refrigerant
» Quiet Operation
» i-Save Mode

» Blue Fin Condenser
» Vertical & Horizontal

Vanes

» Wi-Fi Connectable*
» Auto Change Over

- -

» 3D i-See Sensor
» Dual Barrier Coating
» Built-in Wi-Fi
» Weekly Timer

- - -

» Wi-Fi Connectable*
» Flat Panel
» Auto Restart
» Auto Change Over

» Demand Response

Capable

» Weekly Timer
» 24 Hour Timer
» Dual Barrier Coating

» Auto Change Over
» 3 Colours Available

Red, Black & Pearl
White

» Anti-Allergy

Enzyme Filter
(Optional)

MSZ-LN Series

MSZ-EF Series

MSZ-AP Series

FLOOR-STANDING

MFZ-KJ Series

2.5kW 3.5kW 5.0kW 6.0kW 7.1kW 8.0kW

   

» Heating & Cooling
» Pure White
» Quiet Operation

» Wi-Fi Connectable*
» Anti-Allergy

Enzyme Filter

» i-Save Mode

- -

» 24 Hour Timer
» Auto Change Over

» Multi-Vane Flow

CEILING-CASSETTE

SLZ-KF Series

2.5kW 3.5kW 5.0kW 6.0kW 7.1kW 8.0kW

   

» Heating & Cooling
» Quiet Operation
» 2x2 Compact Size
» Long-Life Filter

» Fresh-Air Intake
» Weekly Timer
» Auto Change Over
» Auto Restart

- -

» Wi-Fi Connectable*
» Auto Vane
» Pure White

CEILING-CONCEALED

SEZ Series

» Auto Restart

MFZ-KJ Series

SLZ Series

06

2.5kW 3.7kW 5.1kW 5.6 kW 6.5kW 8.0kW

    

» Auto Restart
» Heating & Cooling
» Quiet Operation

» 200mm Compact Size
» Air Cleaning Filter
» Weekly Timer

» Auto Change Over
» Wi-Fi Connectable*

-

SEZ Series

*Optional upgrade adapter required per unit.

07

LN Series

The LN range is a wall mounted system that blends energy efficiency with a sleek and ultra
modern design. The new stylish design is available with a range of deep, rich colours Ruby
Red, Onyx Black and Pearl White, resulting in a premium quality feel. With a wide range of
features including Built-In Wi-Fi, Plasma Quad Plus Filtration System, 3D i-See Sensor and low
GWP R32 refrigerant, the MSZ-LN is the pinnacle of luxury air conditioning.

Small Rooms

Unit Dimension: (w) 890 x (d) 233 x (h) 307 mm

MSZ-LN25VGV/B/R-A1

Cooling Capacity: 2.5kW (min 1.0kW~max 3.5kW)
Cooling Efficiency-EER: 5.10/AEER: 5.07

Heating Capacity: 3.2kW (min 0.8kW~max 5.4kW
Heating Efficiency-COP: 5.42/ACOP: 5.39

Medium Rooms

Unit Dimension: (w) 890 x (d) 233 x (h) 307 mm

MSZ-LN50VGV/B/R-A1

Cooling Capacity: 5.0kW (min 1.0kW~max 6.0kW)
Cooling Efficiency-EER: 3.62/AEER: 3.61

Heating Capacity: 6.0kW (min 1.0kW~max 8.2kW)
Heating Efficiency-COP: 4.05/ACOP: 4.04

LN Series units are available in:

MSZ-LN35VGV/B/R-A1

Cooling Capacity: 3.5kW (min 0.8kW~max 4.0kW)
Cooling Efficiency-EER: 4.07/AEER: 4.05

)

Heating Capacity: 4.0kW (min 1.0kW~max 6.3kW)
Heating Efficiency-COP: 4.88/ACOP: 4.86

MSZ-LN60VGV/B/R-A1

Cooling Capacity: 6.1kW (min 1.4kW~max 6.9kW)
Cooling Efficiency-EER: 3.53/AEER: 3.52

Heating Capacity: 6.8kW (min 1.8kW~max 9.8kW)
Heating Efficiency-COP: 3.78/ACOP: 3.77

08

Ruby Red

Onyx Black Pearl White

This setting can be used to directly target
airflow at people such as for immediate
comfort when coming indoors on a hot
(cold) day.

Direct Airow

CONTROL

FEATURES

30°C

Plasma Quad Plus Filter

The Plasma Filter System is an
advanced, multi-stage filtration
system designed to effectively
reduce airborne contaminants
such as allergens, viruses
and bacteria, ensuring the
circulation of fresh, clean air
back into the room.

3D i-See Sensor

The LN Series is equipped with
3D i-See Sensor, an infared-ray
sensor that measures the
temperature at distant positions.
While moving to the left and right,
eight vertically arranged sensor
elements analyse the room
temperature.

Natural Flow

To create comfortable airflow,
the most important aspect is
that the flow of air feels natural.
Mitsubishi Electric has created
this solution using technology
that freely and flexibly controls
to mimic natural airflow.

Indirect / Direct
Airflow

The indirect airflow setting can
be used when the flow of air
feels too strong or direct. For
example, it can be used during
cooling to avert airflow and
prevent body temperature from
being excessively cool.

Dual Split Vane
Technology

The unique dual split vane
design allows airflow to be
customised to suit different areas
of the room, by independently
directing air upwards, downwards
or to the side.

Quiet Operation

We recognise that noise affects
comfort, so we constantly work to
make our air conditioners as quiet
as possible. With improvements
to our fan blades combined with
grille shape to our outdoor unit,
it’s even quieter when in low noise
mode. We want you to feel the
comfort, not hear it.

Energy Efficient

Impressively low power
consumption and quiet, yet
powerful performance. Ensuring
quality room comfort and energy
savings, thereby reducing
the consumption of excessive
electricity.

*1 To use Amazon Alexa to control your air conditioner, you will need an Amazon Echo device.

* 2 To use Google Assistant to control your air conditioner, you will need a Google Home smart speaker.

Large windows and room volume are some of the factors that may effect the performance of the air conditioning unit.

LN SERIES FEATURES

» Heating & Cooling

» Inverter Technology

» Absence Detection

» Econo Cool

» Auto/Double Vane

» Dual Barrier Coating

» Colour Selection

» Compact

» 24 Hour Timer

» Auto Restart

» Built-In Wi-Fi

» Weekly Timer

» Guaranteed Operating Range

Cooling at -10°C ~ 46°C

Heating at -15°C ~ 24°C

» Vertical & Horizontal Swing

» Auto Change Over

» 3D i-See Sensor

Built-In Wi-Fi Control

Unlock the door to smarter
cooling and heating for total
home comfort. You can control
and monitor your air conditioner
from anywhere anytime via your
smartphone, tablet or online
account.

» Direct/Indirect Airflow

» Natural Flow

» Plasma Quad Plus Filter

» DC Inverter

» Dual Split Vane Technology

*1

*2

09

EF Series

The streamlined wall-mounted indoor units have eloquent clean lines, expressing
sophistication and quality. Available in 3 stylish colours classic white, matte silver and glossy
black to provide the best match scenario for diverse interior designs while simultaneously
ensuring quality room comfort.

Small Rooms

Unit Dimension: (w) 885 x (d) 195 x (h) 299 mm

MSZ-EF25VE2W/B/S

Cooling Capacity: 2.5kW (min 1.2kW~max 3.4kW)
Cooling Efficiency-EER: 4.59/AEER:4.56

Heating Capacity: 3.2kW (min 1.1kW~max 4.2kW)
Heating Efficiency-COP: 4.57/ACOP: 4.55

Medium Rooms

Unit Dimension: (w) 885 x (d) 195 x (h) 299 mm

MSZ-EF42VE2W/B/S

Cooling Capacity: 4.2kW (min 0.9kW~max 4.6kW)
Cooling Efficiency-EER: 3.28/AEER: 3.27

Heating Capacity: 5.4kW (min 1.4kW~max 6.3kW)
Heating Efficiency-COP:

3.70/ACOP: 3.69

MSZ-EF35VE2W/B/S

Cooling Capacity: 3.5kW (min 1.4kW~max 4.0kW)
Cooling Efficiency-EER: 3.85/AEER:3.83

Heating Capacity: 4.0kW (min 1.8kW~max 5.5kW)
Heating Efficiency-COP: 4.19/ACOP: 4.17

MSZ-EF50VE2W/B/S

Cooling Capacity: 5.0kW (min 1.4kW~max 5.4kW)
Cooling Efficiency-EER: 3.21/AEER: 3.20

Heating Capacity: 5.8kW (min 1.6kW~max 7.5kW)
Heating Efficiency-COP: 3.71/ACOP: 3.70

10

Large windows and room volume are some of the factors that may effect the performance of the air conditioning unit.

CONTROL

FEATURES

without

“Low standby power”

with

“Low standby power”

below

1W

around

10W

around

around

90%

90%

reduction

reduction

Stylish Design

Developed to complement
modern interior room decor,
MSZ-EF Series is available in
three colours glossy black, matte
silver and classic white. Specially
chosen to blend in naturally
wherever installed.

Energy Efficient

Impressively low power
consumption and quiet, yet
powerful performance. Ensuring
quality room comfort and energy
savings, thereby reducing
the consumption of excessive
electricity.

Low Stand-By Power

Electrical devices consume
electric power even when they are
switched off or in standby mode.
The EF Series units have a Low
Standby Power of below 1 watt
reducing the wasted power by
around 90%.

Platinum Filter

The Nano Platinum Deodorising
Filter reduces airborne bacteria
while improving air quality.

The optional Electrostatic Anti­Allergy Enzyme Filter effectively
combats common allergens.

Quiet Comfort All Day

Mitsubishi Electric’s advanced

“Quiet Mode” fan speed setting
provides peaceful operation as low
as 21dB for 25/35 models.
This unique feature makes the
MSZ-EF series ideal for use in
any situation.

Wi-Fi Control*

Unlock the door to smarter
cooling and heating for total
home comfort. You can control
and monitor your air conditioner
from anywhere anytime via your
smartphone, tablet or online
account.

1

* 1 Optional upgrade adapter required per unit.

Requires an Internet connection and the App downloaded from the App Store or GooglePlay Store on your
smartphone or tablet with the latest Operating System available.

*2 To use Amazon Alexa to control your air conditioner, you will need an Amazon Echo device.

* 3 To use Google Assistant to control your air conditioner, you will need a Google Home smart speaker.

EF Series units are available in:

Glossy Black

Matte Silver Classic White

EF SERIES FEATURES

*2

*3

» Heating & Cooling

» Inverter Technology

» Econo Cool

» Nano Platinum Filter

» Auto Restart

» 24 Hour Timer

» Weekly Timer

» Guaranteed Operating Range

Cooling at -10°C ~ 46°C
Heating at -15°C ~ 24°C

» Auto Change Over

» Electrostatic Anti-Allergy

Enzyme Filter (Optional)

» Self Diagnosis

11

AP Series

Mitsubishi Electric MSZ-AP series wall mounted split system is engineered for high
performance and utilises a low GWP R32 refrigerant. Models range from 2.5 to 7.8kW so there
is a capacity to suit most cooling and heating requirements around the home. It also features a
new streamlined design to blend in with any decor.

Small & Medium Rooms

Unit Dimension: (w) 798 x (d) 219 x (h) 299 mm

MSZ-AP25VG(D*)

Cooling Capacity: 2.5 (min 1.1kW~max 3.6kW)

Cooling Efficiency-EER: 5.00/AEER: 4.97

Heating Capacity: 3.2kW (min 1.3kW~max 5.0kW)
Heating Efficiency-COP: 4.78kW/ACOP: 4.75

MSZ-AP42VG(D*)

Cooling Capacity: 4.2 (min 0.9~max 4.8kW)
Cooling Efficiency-EER: 3.53/AEER: 3.52

Heating Capacity: 5.4 (min 1.3~max 6.0kW)
Heating Efficiency-COP: 3.78/ACOP: 3.77

Large Rooms

Unit Dimension: (w)1100 x (d) 257 x (h) 325 mm

MSZ-AP60VG(D*)

Cooling Capacity: 6.0 (min 1.4kW~max 7.3kW)
Cooling Efficiency-EER: 3.77/AEER: 3.77

Heating Capacity: 6.8 (min 2.0kW~max 8.6kW)
Heating Efficiency-COP: 4.07/ACOP: 4.06

MSZ-AP35VG(D*)

Cooling Capacity: 3.5 (min 1.1kW~max 4.1kW)

Cooling Efficiency-EER: 4.02/AEER: 4.01

Heating Capacity: 3.7 (min 1.3kW~max 5.1kW)

Heating Efficiency-COP: 4.57/ACOP: 4.55

MSZ-AP50VG(D*)

Cooling Capacity: 5.0 (min 1.4kW~max 6.2kW)
Cooling Efficiency-EER: 3.79/AEER: 3.78

Heating Capacity: 6.0 (min 1.4kW~max 8.0kW)
Heating Efficiency-COP: 4.57/ACOP: 4.55

MSZ-AP71VG(D*)

Cooling Capacity: 7.1 (min 2.0kW~max 8.7kW)
Cooling Efficiency-EER: 3.53/AEER: 3.53

Heating Capacity: 8.0 (min 2.2kW~max 9.9kW)

Heating Efficiency-COP: 3.83/ACOP: 3.82

12

MSZ-AP80VG(D*)

Cooling Capacity: 7.8 (min 2.0kW~max 9.2kW)
Cooling Efficiency-EER: 3.31/AEER: 3.30

Heating Capacity: 9.0 (min 2.2kW~max 11.0kW)
Heating Efficiency-COP: 3.53/ACOP: 3.53

(D*) represents DRED enabled model. This is only available in QLD.

Large windows and room volume are some of the factors that may effect the performance of the air conditioning unit.

FEATURES

CONTROL

NEW Award Winning Design

The MSZ-AP Series has a uniform,
streamlined design regardless of
the size and model of the unit. The
simple yet high-quality appearance is
designed to blend in with any interior.
When mounted, the units appear
smaller due to the tapered
bottom end.

Quiet Operation

A “Quiet Mode” setting has been
added to the fan speed settings,
ensuring super quiet operation
as low as 18dB*. Perfect for the
bedroom; it’s so quiet you’ll check
to see if it’s on.

*Model 25 in heating mode only.

NEW Vertical & Horizontal

Vanes

New vertical and horizontal
vanes are double the size of the
previous model, allowing the
airflow direction to be adjusted and
improving airflow control effectively.
These functions can be activated
at the touch of a button on your
remote controller.

Heat Exchanger

Fan

Air Duct

Without With

NEW Dual Barrier

Coating

Dual Barrier Coating reduces
dust and greasy dirt from getting
into the air conditioner. Image
shows a simulated comparison
of dirt over 10 years, without and
with Dual Barrier Coating.

Energy Efficient

Impressively low power
consumption and quiet, yet
powerful performance. Ensuring
quality room comfort and energy
savings, thereby reducing
the consumption of excessive
electricity.

Blue Fin Condenser

Anti-corrosion treatment has been
applied to the heat exchanger
of the outdoor unit. This coating
inhibits corrosion of the aluminum
fins; salt in the air causes this
especially in coastal areas.

(Corrosion of the heat exchanger will

affect the efficiency and performance

of the AC).

R32 Refrigerant

R32 is a refrigerant with just one­third the global warming potential
of R410A, meaning reduced
risk of harm to the environment.

R32

* 1 Optional upgrade adapter required per unit.

Requires an Internet connection and the App downloaded from the App Store or GooglePlay Store on your
smartphone or tablet with the latest Operating System available.

*2 To use Amazon Alexa to control your air conditioner, you will need an Amazon Echo device.

* 3 To use Google Assistant to control your air conditioner, you will need a Google Home smart speaker.

R32 enables increased energy
efficiency and is said to be the
next generation in refrigerants.

AP SERIES FEATURES

» Heating & Cooling

» Inverter Technology

» Econo Cool

» Auto Vane

» Natural White

» Demand Response Capable

» Low Temperature Cooling

» Weekly Timer

» Auto Restart

» Dual Barrier Coating

» Auto Fan Speed

» 24 Hour Timer

» Auto Change Over

» Vertical & Horizontal Vanes

» Anti-Allergy Enzyme Filter (Optional)

Wi-Fi Control*

Unlock the door to smarter
cooling and heating for total
home comfort. You can control
and monitor your air conditioner
from anywhere anytime via
your smartphone, tablet or
online account.

» Guaranteed Operating Range

Cooling at -10°C ~ 46°C

Heating at -15°C ~ 24°C

1

*2

*3

13

KJ Series

FLOOR STANDING UNIT

High capacity, simple, flat design in harmony with living spaces raises the value of your room
to the next level.

Small Rooms

Unit Dimension: (w) 750 x (d) 215 x (h) 600 mm

MFZ-KJ25VE

Cooling Capacity: 2.5kW (min 0.5kW~max 3.4kW)
Cooling Efficiency-EER: 4.63/AEER: 4.62

Heating Capacity: 3.4kW (min 1.2kW~max 4.6kW)
Heating Efficiency-COP: 4.42/ACOP: 4.41

Medium Rooms

Unit Dimension: (w) 750 x (d) 215 x (h) 600 mm

MFZ-KJ50VE

Cooling Capacity: 5.0kW (min 1.6kW~max 5.7kW)
Cooling Efficiency-EER: 3.57/AEER: 3.56

Heating Capacity: 5.8kW (min 2.2kW~max 8.2kW)
Heating Efficiency-COP: 3.87/ACOP: 3.86

MFZ-KJ35VE

Cooling Capacity: 3.5kW (min 0.5kW~max 3.7kW)
Cooling Efficiency-EER: 3.89/AEER:3.88

Heating Capacity: 4.3kW (min 1.2kW~max 5.8kW)
Heating Efficiency-COP: 3.91/ACOP: 3.90

MFZ-KJ60VE

Cooling Capacity: 6.0kW (min 1.6kW-max 6.8kW)

Cooling Efficiency-EER: 3.42/AEER: 3.43

Heating Capacity: 6.8kW (min 2.2kW-max 9.1kW)

Heating Efficiency-COP: 3.60/ACOP: 3.59

14

Large windows and room volume are some of the factors that may effect the performance of the air conditioning unit.

CONTROL

FEATURES

Rapid Heating
Technology

MFZ Series ensures a comfortable
room temperature is reached
faster with Rapid Heating
Technology. Warm air is blown
out in a downward direction and
then sucked back into the unit to
quickly raise the temperature of
the air being blown out.

Multi Flow Vane

A powerful blower allows distribution
of air from the upper and lower air
outlets. The result is a comfortable
environment with an even
temperature throughout the room.
Three uniquely shaped vanes control
the airflow and allow the freedom
to customise comfort according to
preferences.

Wi-Fi Control*

Unlock the door to smarter
cooling and heating for total
home comfort. You can control
and monitor your air conditioner
from anywhere anytime via
your smartphone, tablet or
online account.

1

Slim, Sophisticated
Design

Floor consoles feature a new
contemporary sleek design
that harmonises with interiors.

i-Save mode

“i-Save” is a setting function that
recalls the preferred (preset)
temperature by pressing the
i-Save button on the remote
controller.

*2

*3

* 1 Optional upgrade adapter required per unit.

Requires an Internet connection and the App downloaded from the App Store or GooglePlay Store on your
smartphone or tablet with the latest Operating System available.

*2 To use Amazon Alexa to control your air conditioner, you will need an Amazon Echo device.

* 3 To use Google Assistant to control your air conditioner, you will need a Google Home smart speaker.

MFZ SERIES FEATURES

» Heating & Cooling

» Inverter Technology

» Only 19dB (KJ 25/35)

» Econo Cool

» Nano Platinum Filter

» Horizontal Auto Vane

» Horizontal Swing

» Pure White

» Built-In Weekly Timer

» 24 Hour Timer

» Auto Restart

» Guaranteed Operating Range

Cooling at -10°C ~ 46°C

Heating at -15°C ~ 24°C

» Error Logs

» Vertical Airflow

» Easy Installation (with leveling plate)

» Emergency Operation Switch

» Anti-Allergy Enzyme Filter

1515

SLZ Series

CEILING CASSETTE

Our compact, lightweight ceiling cassette units with 4-way airflow provide improved comfort by
evenly distributing airflow throughout the entire room.

Small Rooms

Unit Dimension: (w) 570 x (d) 570 x (h) 208 mm
Panel Dimension: (w) 650 x (d) 650 x (h) 20 mm

SLZ-KF25VA3

Cooling Capacity: 2.5kW (min 1.5kW~max 3.2kW)
Cooling Efficiency-EER: 3.85/AEER: 3.73

Heating Capacity: 3.0kW (min 1.3kW~max 4.5kW)
Heating Efficiency-COP: 3.85/ACOP: 3.75

SLZ-KF50VA3

Cooling Capacity: 5.0kW (min 2.3kW~max 5.2kW)
Cooling Efficiency-EER: 3.27/AEER: 3.21

Heating Capacity: 4.5kW (min 1.7kW~max 6.5kW)
Heating Efficiency-COP: 3.16/ACOP: 3.22

FEATURES

Air Cleaning Filter

This built-in filter reduces dust
and other particulates, keeping
the air purified and deodorised.
The long-life filter in SLZ Series
air conditioners can be used
for approximately 2,500 hours
with simple maintenance.

Medium Rooms

Unit Dimension: (w) 570 x (d) 570 x (h) 208 mm
Panel Dimension: (w) 650 x (d) 650 x (h) 20 mm

SLZ-KF35VA3

Cooling Capacity: 3.5kW (min 1.4kW~max 3.9kW)
Cooling Efficiency-EER: 3.68/AEER: 3.61

Heating Capacity: 4.0kW (min 1.7kW~max 5.0kW)
Heating Efficiency-COP: 3.70/ACOP: 3.36

SLZ-KF60VA3

Cooling Capacity: 5.6kW (min 2.3kW~max 6.5kW)
Cooling Efficiency-EER: 3.20/AEER: 3.16

Heating Capacity: 6.0kW (min 2.5kW~max 7.4kW)
Heating Efficiency-COP: 3.19/ACOP: 3.15

New Design

The straight-line form introduced
has resulted in a beautiful square
design. Its high affinity ensures
the ability to blend in seamlessly
with any interior. The indoor unit
is an ideal match for office and
retail.

16

SLZ SERIES FEATURES

» Heating & Cooling

» PAM Control

» Long Life (2,500 Hour Filter)

» Fresh Air Intake

» Pure White

» Auto Vane

» Vertical Swing

» 12 Hour Timer

» Auto Restart

» Weekly Timer (PAR-40MAA)

» Guaranteed Operating Range

Cooling at -10°C ~ 46°C
Heating at -15°C ~ 24°C

» Optional M-NET Connection

» 3D i-See Sensor (Optional)

» Wi-Fi Control

(Optional upgrade adapter
required per unit)

» Self Diagnosis

(with wired R/C check code)

» Error Logs

SEZ Series

CEILING-CONCEALED

Our concealed-ceiling unit has a reduced installation space height with impressively
quiet operation. Comfort for the living room, bedroom and other living spaces.

Small Rooms

Unit Dimension: (w) 990 X (d) 700 X (h) 200mm - SEZ-KD35VA

SEZ-KD25VA

Cooling Capacity: 2.5kW (min 1.5kW~max 3.2kW)
Cooling Efficiency-EER: 3.33/AEER: 3.21

Heating Capacity: 3.0kW (min 1.3KW~max 4.5kW)
Heating Efficiency-COP: 3.61/ACOP: 3.49

SEZ-KD35VA

Cooling Capacity: 3.7kW (min 1.4kW~max 3.9kW)
Cooling Efficiency-EER: 3.39/AEER: 3.31

Heating Capacity: 4.2kW (min 1.7KW~max 5.0kW)
Heating Efficiency-COP: 3.72/ACOP: 3.62

FEATURES

Quiet Operation

Offering whisper-quiet operation
at a hushed noise level of 23dB
(SEZ-KD25/35), creating a calm
and comfortable environment.
So quiet you’ll check to see if
they’re on.

Medium Rooms Large Rooms

Unit Dimension: (w) 990 x (d) 700 x (h) 200 mm Unit Dimension: (w) 1190 x (d) 700 x (h) 200 mmUnit Dimension: (w) 790 X (d) 700 X (h) 200mm - SEZ-KD25VA

SEZ-KD50VA

Cooling Capacity: 5.1kW (min 2.3kW~max 5.6kW)
Cooling Efficiency-EER: 3.11/AEER: 3.05

Heating Capacity: 6.4kW (min 1.7KW~max 7.2kW)
Heating Efficiency-COP: 3.54/ACOP: 3.48

SEZ-KD60VA

Cooling Capacity: 5.6kW (min 2.3kW~max 6.3kW)
Cooling Efficiency-EER: 3.16/AEER: 3.11

Heating Capacity: 7.4kW (min 2.5KW~max 8.0kW)
Heating Efficiency-COP: 3.61/ACOP: 3.55

SEZ-KD71VA

Cooling Capacity: 6.5kW (min 2.8kW~max 8.3kW)
Cooling Efficiency-EER: 3.16/AEER: 3.10

Heating Capacity: 8.1kW (min 2.6KW~max 10.4kW)
Heating Efficiency-COP: 3.72/ACOP: 3.66

Compact Ceiling­Concealed Units

With a slim size of 200mm in
height the concealed unit fits
easily and discreetly into ceiling
spaces. Allowing you to create
a high class interior.

SEZ SERIES FEATURES

» Heating & Cooling

» Wi-Fi Control

(Optional upgrade adapter
required per unit)

» Weekly Timer (SEZ-VAQ)

(PAR-40MAA)

» Guaranteed Operating Range

Cooling at -10°C ~ 46°C (KA25)
Cooling at -15°C ~ 43°C (KA50)
Cooling at -15°C ~ 46°C (KA60/71)

Heating at -15°C ~ 24°C

» Optional M-NET Connection

» Flare Connection

» Error Logs

» Auto Restart

17

Controls

HANDHELD CONTROLLERS & WALL MOUNTED CONTROLS

Making the most out of your air conditioner all starts with the controls, these allow you to create
the comfort levels that match your demands.

As air conditioners are becoming more advanced, so are the controls, to allow accuracy and
ease of use to maximise the functionality of your air conditioner. The availability of handheld
controllers, wired wall mounted controller PAR-40MAA and Wi-Fi Control not only provide you
with a wide variety of choice, but also allow optimised programming efficiency.

PAC-YT52CRA Controller

To simplify operation of the system, the range of controls has been
limited to On/Off, mode, room temperature, fan speed and additional
vane control for high walls, cassettes, and under ceilings units.
The ability to sense the room ambient via the inbuilt thermostat.
This means you are sensing the actual space temperature where
the end user is.

PAR-SL100A-E Weekly Remote Controller

With an easy to read display and a variety of operating modes at the
touch of a button. This controller features a weekly and 24 hour timer, On/
Off timer to set operating times on a daily basis. The ‘i-Save’ mode recalls
the preset temperature. This remote is standard for the AP Series, EF
series and LN series.

PAR-40MAA 7 Day Wired Controller*

The wall mounted 7 day controller is an optional upgrade with the ability
to connect to all Mitsubishi Electric systems listed in this brochure.
The PAR-40MAA Controller allows you to program up to 8 stop/start
patterns per day for up to 7 days at a time.

*Optional upgrade adapter required per unit.

18

PAR-CT01MAA Bluetooth* Touch Screen Controller

The full colour touch controller PAR-CT01MAA enables the control of
both residential and commercial air conditioning applications. It has a
customisable 3.5 inch colour LCD touch panel that makes it easy to use.
Available in white or premium black finishes, suitable for almost any decor.
Operation panels are easier to see and simple to use with big visible-sized
icons. Logo images can also be displayed on the initial screen for more
customisation.

Available in White or Premium Black.

*Available for PAR-CT01MAA-SB and PAR-CT01MAA-PB.

Control Your Comfort

Anywhere, Anytime*

1

WI-FI CONTROL*

1

Wi-Fi Control unlocks the door to
smarter heating or cooling, for total
home comfort wherever you are.

This innovative technology connects
your domestic high wall, floor
mounted and ducted air conditioner
to your smartphone, tablet or online
account, giving you the freedom to
fully control each unit on-the-go via an
internet connection from anywhere
in the world.

*1 Optional upgrade adapter required per unit.

Requires an Internet connection and the App downloaded
from the App Store or GooglePlay Store on your smartphone
or tablet with the latest Operating System available.

* 2 To use Amazon Alexa to control your air conditioner, you will

need an Amazon Echo device.

* 3 To use Google Assistant to control your air conditioner, you will

need a Google Home smart speaker.

Wi-Fi FEATURES

» View & control from anywhere in the world

» Enhance energy savings

» Set up 7 day weekly schedule

» Wireless connection using WPS

CONTROL

*1

Superior Customisation

This innovative technology places
multiple functions of your
air conditioner at your fingertips.
Turning the unit On/Off, adjusting
set temperature, changing mode,
fan speed and airflow direction are
all possible.

Develop Operating Rules

Tailor your system to always
meet your needs. Unlock
the full potential of your air
conditioner, program your system
to automatically turn On/Off at
specific times, change settings,
and develop temperature rules to
ensure superior comfort
day after day.

NEW Wi-Fi Voice Control

with Amazon Alexa and
Google Assistant

Mitsubishi Electric air conditioning
systems connected with Wi-Fi
Control*1 are now also Amazon
Alexa*2 and Google Assistant*3
enabled! This means you can
enjoy hands-free control.

19

FUNCTIONS

Energy Saving

3D i-See Sensor

The “3D i-See Sensor” monitors the whole room in sections and
directs the airflow to areas of the room where the temperature does
not match the temperature setting. For example when cooling the
room, if the middle of the room is detected to be hotter, more airflow
is directed towards it. This eliminates unnecessary heating/cooling
and contributes to lower electricity costs.

DC Inverter

Inverter technology matches compressor speed to your indoor
heating or cooling requirements. PAM (Pulse Amplitude Modulation)
provides higher efficiency within the inverter by controlling the
amount
of power drawn.

Econo Cool Energy-Saving Feature

“Econo Cool” is an intelligent temperature control feature that adjusts
the amount of air directed towards the body based on the air-outlet
temperature. The setting temperature can be raised by as much as
2 degrees without any loss in comfort, thereby realising a 20% gain
in energy efficiency. (Function only available during manual
cooling operation.)

“i-Feel” Control

The “i-Feel” fuzzy-logic control memorises the most desirable
temperature setting. If the “TOO WARM” or “TOO COOL” button
on the remote controller is pressed, the system adds the choice to
the control memory and adjusts the temperature so that the most
comfortable temperature is provided. That temperature setting is
used the next time the unit is turned on.

PAM (Pulse Amplitude Modulation)

PAM is a technology that controls the current waveform so that it
resembles the supply voltage wave, thereby reducing loss and
realising more efficient use of electricity. Using PAM control, 98% of
the input power supply is used effectively.

Comfort

Auto Vane

The vane closes automatically when the air conditioner is not running,
concealing the air outlet and creating a flat surface that is
aesthetically appealing.

Swing (Vertical Vane)

The air outlet vane swings from side to side so that the airflow
reaches every part of the room.

Long Airflow

Use this function to ensure that the airflow circulates to areas far
across the room. Press the Long Airflow icon on the remote controller
to extend reach up to as far as 12 metres from the unit.

Dual Split Vane

The unique dual split vane design allows airflow to be customised
to suit different areas of the room, by independently directing air
upwards, downwards or to the side.

Air Quality

Air Cleaning Filter

The filter is charged with static electricity, enabling it to attract and
capture dust particulates that regular filters don’t.

Anti-Allergy Enzyme filter

The anti-allergy enzyme filter works to trap allergens such as molds
and bacteria and decompose them using enzymes retained in the filter.

Catechin Filter

Catechin is a bioflavonoid by-product of green tea with both antiviral
and antioxidant qualities. It also has an excellent deodorising
effect, which is why Mitsubishi Electric uses the compound in its
air conditioner filters. In addition to improving air quality, it prevents
the spreading of bacteria and viruses throughout the room. Easily
removed for cleaning and maintenance, when the filter is washed
regularly the deodorising action is rated to last more than 10 years.

Electro Static Anti-Allergy Enzyme Filter

This function utilises both the air cleaning filter and anti-allergy
enzyme filter.

Fresh-Air Intake

Indoor air quality is enhanced by the direct intake of fresh exterior air.

Nano Platinum Filter

The filter has a large capture area and incorporates nanometre-sized
platinum-ceramic particles that work to kill bacteria and deodorise
the circulating air. Better dust collection than conventional filters is
also ensured.

Plasma Quad Plus Filter

Units are equipped with a pre-filter and two special filters that perform
plasma air cleaning and plasma purification functions (Plasma Duo).
The plasma system removes bad odors and bacterial particulates of
micron and nanometre-size from the air.

20

Swing (Horizontal Vane)

The air outlet vane swings up and down so that the airflow is spread
evenly throughout the room.

Wide and Long Airflow

The wide and long airflow function is especially beneficial for large
spaces, helping to ensure that air is well circulated and reaches
every corner of the room.

Wide Airflow

This unique airflow system distributes air horizontally over a
wide-ranging 150° in heating mode and 100° in cooling mode.
Simply press the Wide Swing icon on the remote controller to select
the desired airflow from seven different patterns.

Convenience

Ampere Limit Adjustment

Dipswitch settings can be used to adjust the maximum electrical
current for operation. This function is highly recommended for
managing energy costs.

*Maximum capacity is lowered with the use of this function.

Auto Changeover

The air conditioner automatically switches between heating and
cooling modes to maintain the desired temperature.

Auto Restart

Especially useful at the time of power outages, the unit turns back
on automatically when power is restored.

Auto Fan Speed Mode

The airflow speed mode adjusts the fan speed of the indoor unit
automatically according to the present room conditions.

“i-Save” Mode

“i-Save” is a simplified setting function that recalls the preferred
(preset) temperature by pressing a sinAPe button on the remote
controller. Press the same button twice in repetition to immediately
return to the previous temperature setting. Using this function
contributes to comfortable waste-free operation, realising the most
suitable air conditioning settings and saving on power consumption
when, for example, leaving the room or going to bed.

Low-Temperature Cooling

Intelligent fan speed control in the outdoor unit ensures optimum
performance even when the outside temperature is low.

On/Off Operation Timer

Use the remote controller to set the times for the air conditioner to
turn On/Off.

System Control

M-Net Connection

Units can be connected to MELANS system controllers (M-NET
controllers) such as the AE-200E.

MXZ Connection

Connection to the MXZ multi-split outdoor unit is possible.

PAR-40MAA Control

Units are compatible for use with the PAR-40MAA remote controller,
which has a variety of management functions including a weekly timer.

*Optional upgrade adapter required per unit.

System Group Control

The same remote controller is capable of controlling the operational
status of up to 16 refrigerant systems.

Wi-Fi Interface

Interface enabling users to control air conditioners and check operating
status via devices such as personal computers, tablets and smartphones.

Optional upgrade adapter required per unit. (Excludes LN Series).

Installation & Maintenance

Cleaning-Free Pipe Reuse*

The application of pipe reuse technology such as Mitsubishi Electric’s
original hard alkyl benzene oil makes it possible to reuse the same
piping, thereby allowing cleaning-free renewal of air conditioning
systems that use R22 refrigerant.

*Cleaning-Free Pipe Reuse Technology specifically applies to piping
which is contaminated with chlorine residue, iron particles and slime.
These contaminants are typically found in which the previous system
utilised R22 refrigerant. Cleaning-Free Pipe Reuse Technology cannot
be used to clean pipes which contain foreign matter other than what
can be generated from an operating air conditioner.

Operation Lock

To accommodate specific-use applications, cooling or heating
operation can be specified when setting the control board of the
outdoor unit. A convenient option when a system needs to be
configured for exclusive cooling or heating service.

Error Log Function

Operation errors are recorded, allowing confirmation when needed.

Flare Connection

Flare connection to cooling pipe work is possible.

Dual Barrier Coating

Dual Barrier Coating reduces dust and greasy dirt from getting into
the air conditioners, which can assist in creating a healthy and quiet
environment.

Self-Diagnostic Function (Check Code Display)

Check codes are displayed on the remote controller or the operation
indicator to inform the user of malfunctions detected.

21

SPECIFICATIONS

SERIES Deluxe Wall Mounted MSZ-LN Series

Model

Nominal Total Cooling *1

AEER/EER 5.07 / 5.10 4.05 / 4.07 3.61 / 3.61 3.52/3.53

Cooling

Heating

Airflow Airflow (Cooling/Heating) L/s 71-198 / 67-240 71-213 / 71-228 95-231 / 90-261 118-261 / 110-261

Indoor Unit

Outdoor Unit

Electrical Volt / Phase 240/1

Refrigerant

MCA A 9.6 10 14 16

Breaker Size A 10 10 16 16

Star Rating 5.5 3.5 2.5 2.5

Total Input [Min-Rated-Max] kW 0.180 - 0.490 - 0.900 0.160 - 0.860 - 1.180 0.190 - 1.380 - 2.330 0.270 - 1.730 - 2.730

Running Current [Rated] A 2.5 4.1 6.3 7.8

Nominal Heating Capacity *1

ACOP/COP 5.39 / 5.42 4.86 / 4.88 4.04 / 4.05 3.77 / 3.78

Star Rating 6.0 5.0 3.5 3.0

Total Input [Min-Rated-Max] kW

Running Current [Rated] A 3.0 4.0 6.8 7.9

Dimensions [HxWxD] mm 307 x 890 x 233 307 x 890 x 233 307 x 890 x 233 307 × 890 × 233

Unit Weight kg 15.5 15.5 15.5 15.5

Noise Level SPL (PWL)
in Cooling

Noise Level SPL (PWL)
in Heating

Dimensions [HxWxD] mm 550 x 800 x 285 550 × 800 × 285 714 x 800 x 285 880 × 840 × 330

Weight kg 35 35 40 55

Noise Level SPL (PWL)
in Cooling

Noise Level SPL (PWL)
in Heating

Pipe Size (Gas) OD mm 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 12.7 (1/2)

Pipe Size (LIquid) OD mm 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)

Max Pipe Run/Height m 20 / 12 20 / 12 20 / 12 30 / 15

Pre-Charged Refrigerant kg 0.8 (7m) 1.15 (7m) 1.15 (7m) 1.45 (7m)

Add. Charge g/m 30 30 30 20

Outdoor - Cooling °CDB -10 ~ 46

Outdoor - Heating °CDB -15 ~ 24

1

1

MSZ-LN25VGV/B/R

MUZ-LN25VG-A1

kW 2.5 (1.0-3.5) 3.5 (0.8-4.0) 5.0 (1.0-6.0) 6.1 (1.4-6.9)

kW 3.2 (0.8 - 5.4) 4.0 (1.0 - 6.3) 5.4 (1.0 - 8.2) 6.8 (1.8 - 9.8)

0.150 - 0.590 - 1.500 0.170 - 0.820 - 1.880 0.170 - 1.480 - 3.000 0.330 - 1.800 - 3.620

dB(A) 19 - 23 - 29 - 36 - 42 19 - 23 - 29 - 36 - 43 27 - 31 - 25 - 39 - 46 29 - 33 - 26 - 40 - 49

dB(A) 19 - 24 - 29 - 36 - 45 19 - 24 - 30 - 38 - 45 25 - 30 - 35 - 41 - 47 29 - 33 - 37 - 43 - 49

dB(A) 46 49 51 55

dB(A) 49 50 54 55

MSZ-LN35VGV/B/R

MUZ-LN35VG-A1

MSZ-LN50VGV/B/R

MUZ-LN50VG-A1

MSZ-LN60VGV/B/R

MUZ-LN60VG-A1

22

Notes:

*1 Nominal conditions cooling: EAT 27°CDB/19°CWB, Ambient 35°CDB. Rated conditions cooling: EAT.

24°CDB/17°CWB, ambient 35°CDB. Nominal conditions heating: EAT 20°CDB/15°CWB, Ambient 7°CDB/6°CWB.

*2 Rated Load Amps (RLA) is based on nominal conditions. Use Maximum Circuit Amps (MCA) for power supply infrastructure sizing etc.

MUZ-LN25/35 MUZ-LN50 MUZ-LN60

(Rating Conditons)

Cooling: Indoor 27°C, D.B./19°C, W.B.

Outdoor 35°C, D.B./24°C, W.B.

Heating: Indoor 20°C, D.B./15°C, W.B.

Outdoor 7°C, D.B./6°C, W.B.

Mitsubishi Electric is constantly

developing and improving its products.
The company reserves the right to
make any variation in the technical
specification to the equipment described,
or to withdraw or replace products
without prior notification.

This is a guide only, please refer to the
installation and service manuals to
confirm the latest specifications or
contact your local Mitsubishi Electric
office.

SPECIFICATIONS

SERIES

Model

Nominal Total Cooling*1

AEER/EER 4.56 / 4.59 3.83 / 3.85 3.27 / 3.28 3.20 / 3.21

Cooling
Performance

Heating
Performance

Airflow

Indoor Unit

Outdoor Unit

Electrical Volt / Phase 240/1

Refrigerant

MCA A 7.3 8.5 9.5 12.4

Breaker Size A 10 10 10 16

Star Rating 4.5 3 2 1.5

Total Input
[Min-Rated-Max]

Running Current [Rated] A 2.9 4.2 5.7 6.9

Nominal Heating
Capacity* 1

ACOP/COP 4.55 / 4.57 4.17 / 4.19 3.69 / 3.70 3.70 / 3.71

Star Rating 4.5 4.0 3.0 2.5

Total Input
[Min-Rated-Max]

Running Current [Rated] A 3.5 4.4 6.5 7.0

Airflow
(Cooling/Heating)

Dimensions
(H x W x D)

Unit Weight kg 11.5 11.5 11.5 11.5

Noise Level (SPL) ­in Cooling

Noise Level (SPL) ­in Heating

Dimensions
(H x W x D)

Weight kg 30 35 35 54

Noise Level (SPL/PWL) ­in Cooling

Noise Level (SPL/PWL) ­in Heating

Pipe Size (Gas) OD

Pipe Size (Liquid) OD

Max Pipe Run/Height m 20 / 12 20 / 12 20 / 12 30 / 15

Pre-Charged Refrigerant kg 0.8 (7m) 1.15 (7m) 1.15 (7m) 1.45 (7m)

Add. Charge g/m 30 30 30 20

Outdoor - Cooling °CDB -10 ~ 46

Outdoor - Heating °CDB -15 ~ 24

1

MSZ-EF25VE2W/B/S

MUZ-EF25VE

kW 2.5 (1.2-3.4) 3.5 (1.4-4.0) 4.2 (0.9-4.6) 5.0 (1.4-5.4)

kW 0.240 - 0.545 - 1.150 0.210 - 0.910 - 1.500 0.160 - 1.280 - 1.930 0.300 - 1.580 - 1.980

kW 3.2 (1.1 - 4.2) 4.0 (1.8 - 5.5) 5.4 (1.4 - 6.3) 5.8 (1.6 - 7.5)

0.250 - 0.700 - 1.170 0.280 - 0.955 - 1.530 0.260 - 1.460 - 2.050 0.310 - 1.565 - 2.640

kW

L/s 67 - 175 / 67 - 198 67 - 175 / 67 - 212 97 - 172 / 92 - 212 97 - 183 / 107 - 220

mm 299 x 885 x 195 299 x 885 x 195 299 x 885 x 195 299 x 885 x 195

dB(A) 21 - 23 - 29 - 36 - 42 21 - 24 - 29 - 36 - 42 28 - 31 - 35 - 39 - 42 30 - 33 - 36 - 40 - 43

dB(A) 21 - 24 - 29 - 37 - 45 21 - 24 - 30 - 38 - 46 28 - 30 - 35 - 41 - 48 30 - 33 - 37 - 43 - 49

mm 550 x 800 x 285 550 x 800 x 285 550 x 800 x 285 880 x 840 x 330

dB(A) 47 / 58 49 / 61 50 / 62 52 / 65

dB(A) 48 / 60 50 / 63 51 / 64 52 / 66

mm
(inch)

mm
(inch)

9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 12.7 (1/2)

6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)

Signature Wall Mounted

MSZ-EF Series

MSZ-EF35VE2W/B/S

MUZ-EF35EVE

MSZ-EF42VE2W/B/S

MUZ-EF42VE

MSZ-EF50VE2W/B/S

MUZ-EF50VE

Notes:

*1 Nominal conditions cooling: EAT 27°CDB/19°CWB, Ambient 35°CDB. Rated conditions cooling: EAT.

24°CDB/17°CWB, ambient 35°CDB. Nominal conditions heating: EAT 20°CDB/15°CWB, Ambient 7°CDB/6°CWB.

*2 Rated Load Amps (RLA) is based on nominal conditions. Use Maximum Circuit Amps (MCA) for power supply infrastructure sizing etc.

Mitsubishi Electric is constantly developing and improving its products.
The company reserves the right to make any variation in the technical
specification to the equipment described, or to withdraw or replace products
without prior notification.

This is a guide only, please refer to the installation and service manuals to
confirm the latest specifications or contact your local Mitsubishi Electric
office.

MUZ-EF25/35/42 MUZ-EF50

(Rating Conditons)

Cooling: Indoor 27°C, D.B./19°C, W.B.

Outdoor 35°C, D.B./24°C, W.B.

Heating: Indoor 20°C, D.B./15°C, W.B.

Outdoor 7°C, D.B./6°C, W.B.

23

SPECIFICATIONS

SERIES MSZ-AP Series

Model

Nominal Total Cooling*1

AEER/EER 4.97 / 5.00 4.01 / 4.02 3.52 / 3.53 3.78 / 3.79 3.77 / 3.77 3.53 / 3.53 3.30 / 3.31

Cooling
Performance

Heating
Performance

Airflow

Indoor Unit

Outdoor Unit

Electrical Volt / Phase 230/1

Refrigerant

MCA A 7.0 7.1 9.9 14.0 14.0 16.4 16.5

Breaker Size A 10 10 10 16 16 20 20

Star Rating 5.5 3.5 2.5 3.0 3.0 2.5 2.0

Total Input
[Min-Rated-Max]

Running Current [Rated] A 2.6 4.1 5.3 5.9 7.1 8.8 10.8

Nominal Heating
Capacity* 1

ACOP/COP 4.75 / 4.75 4.55 / 4.57 3.77 / 3.78 3.70 / 3.70 4.06 / 4.07 3.82 / 3.83 3.53 / 3.53

Star Rating 5.0 4.5 3.0 3.0 3.5 3.0 2.5

Total Input
[Min-Rated-Max]

Running Current [Rated] A 3.3 3.8 6.3 7.1 7.4 9.1 11.3

Airflow
(Cooling/Heating)

Dimensions
(H x W x D)

Unit Weight kg 10.5 10.5 10.5 10.5 16 17 17

Noise Level (SPL) ­in Cooling

Noise Level (SPL) ­in Heating

Dimensions
(H x W x D)

Weight kg 34/35 34/35 35/36 40/41 40/41 55 55

Noise Level (SPL/PWL) ­in Cooling

Noise Level (SPL/PWL) ­in Heating

Pipe Size (Gas) OD

Pipe Size (Liquid) OD

Max Pipe Run/Height m 20 / 12 20 / 12 20 / 12 20 / 12 30 / 15 30 / 15 30 / 15

Pre-Charged Refrigerant kg 0.7 (10m) 0.7 (10m) 0.7 (10m) 1.0 (15m) 1.0 (15m) 1.0 (15m) 1.5 (15m)

Add. Charge g/m 20 20 20 20 20 20 20

Outdoor - Cooling °CDB -10 ~ 46

Outdoor - Heating °CDB -15 ~ 24

1

MSZ-AP25VG(D*)
MUZ-AP25VG(D*)

kW 2.5 (1-1 - 3.6) 3.5 (1.1 - 4.1) 4.2 (0.9 - 4.8) 5.0 (1.4 - 6.2) 6.0 (1.4 - 7.3) 7.1 (2.0 - 8.7) 7.8 (2.0 - 9.2)

kW 0.21 - 0.50 - 0.99 0.21 - 0.87 - 1.18 0.15 - 1.19 - 1.90 0.30 - 1.32 - 2.23 0.24 - 1.59 - 2.35 0.43 - 2.01 - 3.03 0.43 - 2.36 - 3.20

kW 3.2 (1.3 - 5.0) 3.7 (1.3 - 5.1) 5.4 (1.3- 6.0) 6.0 (1.4 - 8.0) 6.8 (2.0 - 8.6) 8.0 (2.2 - 9.9) 9.0 (2.2 - 11.0)

kW 0.35 - 0.67 - 1.4 0.35 - 0.81 - 1.42 0.26 - 1.43 - 1.90 0.30 - 1.62 - 3.00 0.30 - 1.67 - 2.60 0.42 - 2.09 - 3.25 0.42 - 2.55 - 3.65

L/s 82 - 205 / 82 - 190 82 - 223 / 82 - 215 90 - 223 / 88 - 233 100 - 258 / 93 - 268 156 - 315 / 180 - 338 160 - 310 / 133 - 320 160 - 343 / 133 - 320

mm 299 x 798 x 219 299 x 798 x 219 299 x 798 x 219 299 x 798 x 219 325 x 1100 x 257 325 x 1100 x 257 325 x 1100 x 257

19 - 24 - 31 - 38 - 44 19 - 24 - 31 - 38 - 45 26 - 29 - 35 - 40 - 46 28 - 33 - 39 - 44 - 49 29 - 37 - 41 - 45 - 48 30 - 37 - 41 - 45 - 49 30 - 37 - 41 - 45 - 53

dB(A)

18 - 25 - 31 - 38 - 42 19 - 25 - 31 - 38 - 45 26 - 29 - 35 - 40 - 46 28 - 33 - 38 - 43 - 48 29 - 37 - 41 - 45 - 48 30 - 37 - 41 - 45 - 51 30 - 37 - 41 - 45 - 51

dB(A)

mm 550 x 800 x 285 550 x 800 x 285 550 x 800 x 285 714 x 800 x 285 714 x 800 x 285 880 x 840 x 330 880 x 840 x 330

dB(A) 46 / 59 50 / 64 51 / 65 54 / 69 55 / 69 56 / 69 56 / 69

dB(A) 49 / 59 50 / 64 52 / 65 56 / 69 57 / 69 55 / 69 55 / 69

mm
(inch)

mm
(inch)

9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 12.7(1/2) 12.7(1/2) 12.7(1/2)

6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)

MSZ-AP35VG(D*)
MUZ-AP35VG(D*)

MSZ-AP42VG(D*)

MUS-AP42VG(D*)

MSZ-AP50VG(D*)
MSZ-AP50VG(D*)

MSZ-AP60VG(D*)
MSZ-AP60VG(D*)

MSZ-G71VG(D*)

MSZ-AP71VG(D*)

MSZ-AP80VG(D*)
MSZ-AP80VG(D*)

24

Notes:

*1 Nominal conditions cooling: EAT 27°CDB/19°CWB, Ambient 35°CDB. Rated conditions cooling: EAT 24°CDB/17°CWB, ambient 35°CDB.

Nominal conditions heating: EAT 20°CDB/15°CWB, Ambient 7°CDB/6°CWB.

*2 Rated Load Amps (RLA) is based on nominal conditions. Use Maximum Circuit Amps (MCA) for power supply infrastructure sizing, etc.

(D*) represents DRED enabled model. This is only available in QLD.

Multi-split system compatibility with model numbers MXZ-*E**VAD2-A1 only.

MUZ-AP25/35/42 MUZ-AP50/60 MUZ-AP71/80

(Rating Conditons)

Cooling: Indoor 27°C, D.B./19°C, W.B.

Outdoor 35°C, D.B./24°C, W.B.

Heating: Indoor 20°C, D.B./15°C, W.B.

Outdoor 7°C, D.B./6°C, W.B.

Mitsubishi Electric is constantly

developing and improving its products.
The company reserves the right to
make any variation in the technical
specification to the equipment described,
or to withdraw or replace products
without prior notification.

This is a guide only, please refer to the
installation and service manuals to
confirm the latest specifications or
contact your local Mitsubishi Electric
office.

SPECIFICATIONS

SERIES MFZ-KJ Series

Model

1

Nominal Total Cooling*1

AEER/EER 4.62 / 4.63 3.88 / 3.89 3.56 / 3.57 3.42 / 3.43

Cooling
Performance

Heating
Performance

Airflow

Indoor Unit

Outdoor Unit

Electrical Volt / Phase 230/1

Refrigerant

MCA A 9.4 9.4 14.0 16.5

Breaker Size A 10 10 16 20

Star Rating 5.0 3.0 2.5 2.0

Total Input
[Min-Rated-Max]

Running Current [Rated] A 2.7 4.2 6.2 7.8

Nominal Heating
Capacity* 1

ACOP/COP 4.41 / 4.42 3.90 / 3.91 3.86 / 3.87 3.59 / 3.60

Star Rating 4.0 3.0 3.0 2.5

Total Input
[Min-Rated-Max]

Running Current [Rated] A 3.7 5.0 6.7 8.4

Airflow
(Cooling/Heating)

Dimensions
(H x W x D)

Unit Weight kg 15 15 15 15

Noise Level (SPL) ­in Cooling

Noise Level (SPL) ­in Heating

Dimensions
(H x W x D)

Weight kg 37 37 55 55

Noise Level (SPL/PWL) ­in Cooling

Noise Level (SPL/PWL) ­in Heating

Pipe Size (Gas) OD

Pipe Size (Liquid) OD

Max Pipe Run/Height m 20 / 12 20 / 12 30 / 15 30 / 15

Pre-Charged Refrigerant kg 1.1 (7m) 1.1 (7m) 1.5 (7m) 1.5 (7m)

Add. Charge g/m 30 30 20 20

Outdoor - Cooling °CDB -10 ~ 46 -10 ~ 46 -10 ~ 46 -10 ~ 46

Outdoor - Heating °CDB -15 ~ 24 -15 ~ 24 -15 ~ 24 -15 ~ 24

kW 2.5 (0.5-3.4) 3.5 (0.5-3.7) 5.0 (1.6-5.7) 6.0 (1.6-6.8)

kW

kW 3.4 (1.2 - 4.6) 4.3 (1.2 - 5.8) 5.8 (2.2 - 8.2) 6.8 (2.2 - 9.1)

kW

L/s

mm

dB(A) 20 - 39 20 - 39 27 - 44 27 - 53

dB(A) 19 - 41 19 - 41 29 - 50 29 - 51

mm

dB(A) 46 / 59 47 / 60 49 / 63 52 / 65

dB(A) 51 / 62 51 / 63 52 / 63 53 / 65

mm
(inch)

mm
(inch)

MFZ-KJ25VE

MUFZ-KJ25VE

0.15 - 0.54 - 0.91 0.15 - 0.90 - 1.14 0.43 - 1.40 - 1.97 0.43 - 1.75 - 2.40

0.36 - 0.77 - 1.40 0.36 - 1.10 - 2.20 0.58 - 1.50 - 3.06 0.58 - 1.89 - 3.70

65-137 / 65-162 65-137 / 65-162 93-177 / 100-233 93-250 / 100-243

600 x 750 x 215 600 x 750 x 215 600 x 750 x 215 600 x 750 x 215

550 x 800 x 285 550 x 800 x 285 880 x 840 x330 880 x 840 x330

9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 12.7 (1/2)

6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)

MFZ-KJ35VE

MUFZ-KJ35VE

MFZ-KJ50VE

MUFZ-KJ50VE

MFZ-KJ60VE

MUFZ-KJ60VE

Notes:

*1 Nominal conditions cooling: EAT 27°CDB/19°CWB, Ambient 35°CDB. Rated conditions cooling: EAT 24°CDB/17°CWB, ambient 35°CDB.

Nominal conditions heating: EAT 20°CDB/15°CWB, Ambient 7°CDB/6°CWB.

*2 Rated Load Amps (RLA) is based on nominal conditions. Use Maximum Circuit Amps (MCA) for power supply infrastructure sizing, etc.

Mitsubishi Electric is constantly developing and improving its products.
The company reserves the right to make any variation in the technical
specification to the equipment described, or to withdraw or replace products
without prior notification.

This is a guide only, please refer to the installation and service manuals to
confirm the latest specifications or contact your local Mitsubishi Electric
office.

MUFZ-KJ-25/35 MUFZ-KJ-50/60

(Rating Conditons)

Cooling: Indoor 27°C, D.B./19°C, W.B.

Outdoor 35°C, D.B./24°C, W.B.

Heating: Indoor 20°C, D.B./15°C, W.B.

Outdoor 7°C, D.B./6°C, W.B.

25

SPECIFICATIONS

Cooling
Performance

Heating
Performance

Airflow

Indoor Unit

Outdoor Unit

Electrical

Guaranteed
Operating
Range

SERIES Compact Ceiling Cassette SLZ Series

Model

Nominal Total

1

Cooling*

AEER/EER 3.73 / 3.85 3.61 / 3.68 3.21 / 3.27 3.16 / 3.20

Total Input (Rated) kW 0.65 0.95 1.53 1.75

Nominal Heating

1

Capacity*

ACOP/COP 3.75 / 3.85 3.63 / 3.7 3.11 / 3.16 3.15 / 3.19

Total Input (Rated) kW 0.78 1.08 1.58 1.88

Airflow
(Cooling/Heating)

Ext. Static Pressure Pa - - - -

Dimensions
(H x W x D)

Panel Dimensions
(H x W x D)

Supply Spigot Size
(H x W x D)

Return Spigot Size
(H x W x D)

Unit Weight

Noise Level (SPL) ­in Cooling/Heating

Dimensions
(H x W x D)

Weight kg 31 35 51 51

Noise Level (SPL/
PWL) - in Cooling

Noise Level (SPL/
PWL) - in Cooling

Volt / Phase SinAPe-Phase, 50Hz, 230V

MCA A 8.16 9.18 16 14

MCB A 10 10 20 20

RLA
(Cooling/Heating)*2

Outdoor - Cooling °CDB -10 ~ 46 -10 ~ 46 -15 ~ 43 -15 ~ 46

Outdoor - Heating °CDB -15 ~ 24 -15 ~ 24 -15 ~ 24 -15 ~ 24

SLZ-KF25VA3

SUZ-KA25VAD2

kW 2.5 (1.5 -3.2) 3.5 (1.4 - 3.9) 5.0 (2.3 - 5.2) 5.6 (2.3 - 6.5)

kW 3.0 (1.3 - 4.5) 4.0 (1.7 - 5.0) 5.0 (1.7 - 6.5) 6.0 (2. 5 - 7.4)

L/s 108 - 125 - 142 108 - 150 - 192 117 - 150 - 192 125 - 192 - 217

mm 245 x 570 x 570 245 x 570 x 570 245 x 570 x 570 245 x 570 x 570

mm 10 x 625 x 625 10 x 625 x 625 10 x 625 x 625 10 x 625 x 625

mm - - - -

mm - - - -

kg
(Panel)

dB(A) 25 - 28 - 31 25 - 33 - 39 27 - 34 - 39 32 - 40 - 43

mm 550 x 800 x 285 550 x 800 x 285 880 x 840 x 330 880 x 840 x 330

dB(A) 46 (59) 47 (61) 53 (68) 55 (69)

dB(A) 46 (59) 48 (62) 55 (69) 55 (69)

A 3.5 / 3.9 5.0 / 5.2 7.4 / 8.2 7.9 / 8.7

15 (3) 15 (3) 15 (3) 15 (3)

SLZ-KF35VA3

SUZ-KA35VAD2

SLZ-KF50VA3

SUZ-KA50VAD2

SLZKF-60VA3

SUZ-KA60VAD2

Optional Parts

System Control Interface MAC-33IF-E

Wi-Fi Interface MAC-568IF-E

Remote Sensor PAC-SE41TS-E

Remote On/Off Adapter PAC-SE55RA-E

Connector Cable for Remote Display PAC-SA88HA-E

Controller

PAR-40MAA

Wired Remote Controller

Wireless Remote Controller

Mitsubishi Electric is constantly developing and improving

its products. The company reserves the right to make any
variation in the technical specification to the equipment
described, or to withdraw or replace products without prior
notification.

This is a guide only, please refer to the installation and service
manuals to confirm the latest specifications or contact your
local Mitsubishi Electric office.

PAC-YT52CRA

PAR-CT01MAA

PAR-SL97A-E

PAR-SL00A

Refrigerant

Panel

Corner Panel

Pipe Size Gas (OD) mm 9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 15.88 (1/2)

Pipe Size
Liquid (OD)

Max Pipe Run m 20 20 30 30

Max Lift m 12 12 30 30

Pre-Charged R410a kg 0.8 (5.0m) 1.05 (5.0m) 1.6 (7.0m) 1.8 (7.0m)

Add. Charge g/m 30 30 20 20

SLP-2FA

SLP-2FAL

SLP-2FAE

SLP-2FALE

SLP-2FALM

SLP-2FALME

PAR-SF9FA-E

PAC-SF1ME-E

mm 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)

Panel & Corner Panel

With Signal Receiver With 3D i-See Sensor With NEW Wireless Remote Controller




 
 
  




26

SUZ-KA25/35VAD2 SUZ-KA50/60VAD2

SPECIFICATIONS

Cooling
Performance

Heating
Performance

Airflow

Indoor Unit

Outdoor Unit

Electrical

Refrigerant

Others

Guaranteed
Operating
Range

SERIES

Model

Nominal Total

1

Cooling*

SEZ-KD25VAQ/L

SUZ-KA25VAD

SEZ-KD35VAQ/L

SUZ-KA35VAD

kW 2.5 (1.5 - 3.2) 3.7 (1.4 - 3.9) 5.1 (2.3 - 5.6) 5.6 (2.3 - 6.3) 6.5 (2.8 - 6.3)

Compact Ceiling Concealed

SEZ Series

SEZ-KD50VAQ/L

SUZ-KA50VAD

SEZ-KD60VAQ/L

SUZ-KA60VAD

SEZ-KD71VAQ/L

SUZ-KA71VAD

AEER/EER 3.21 / 3.33 3.31 / 3.39 3.05 / 3.11 3.11 / 3.16 3.10 / 3.16

Star Rating - - - - -

Nominal
Heating
Capacity*

kW 3.0 (1.3 - 4.5) 4.2 (1.7 - 5.0) 6.4 (1.7 - 7.2) 7.4 (2.5 - 8.0) 8.1 (2.6 - 10.4)

1

ACOP/COP 3.49 / 3.61 3.62 / 3.72 3.48 / 3.54 3.55 / 3.61 3.66 / 3.72

Star Rating - - - - -

Airflow
(Cooling/
Heating)

Ext. Static
Pressure

Dimensions
(H x W x D)

Supply Spigot
Size (H x W)

Return Spigot
Size (H x W)

L/s 92 - 117 - 150 117 - 150 - 183 167 - 208 - 250 200 - 250 - 300 200 - 267 - 333

Pa 5 - 15 - 35 - 50 5 - 15 - 35 - 50 5 - 15 - 35 - 50 5 - 15 - 35 - 50 5 - 15 - 35 - 50

mm 200 x 790 x 700 200 x 990 x 700 200 x 990 x 700 200 x 1190 x 700 200 x 1190 x 700

mm 150 x 660 150 x 860 150 x 860 150 x 1060 150 x 1060

mm 157.5 x 660 157.5 x 860 157.5 x 860 157.5 x 1060 157.5 x 1060

Unit Weight kg 18 21 23 27 27

Noise Level
(SPL/PWL) ­in Cooling

Dimensions
(H x W x D)

dB(A) 23 - 26 - 30 23 - 28 - 33 30 - 34 - 37 30 - 34 - 38 30 - 35 - 40

mm 550 x 800 x 285 550 x 800 x 285 850 x 840 x 330 880 x 840 x 330 880 x 840 x 330

Weight kg 30 33 53 50 53

Noise Level
(SPL/PWL) ­in Cooling

dB(A) 46 (59) 47 (61) 53 (68) 55 (69) 55 (69)

Volt / Phase 240/1

MCA A 8.16 9.18 16 14 16.1

MCB A 10 10 20 20 20

RLA
(Cooling/
Heating)*

Power Supply to OU *

IU/OU Connecting
Wire

Pipe Size
(Gas) OD

Pipe Size
(Liquid) OD

A 3.5 / 3.9 5.0 / 5.2 7.4 / 8.2 7.9 / 8.7 9.1 / 9.7

2

3

3C 3C 3C 3C 3C

mm
(Inch)

mm
(Inch)

SDI + TPS

(2C+E)*

9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 15.88 (5/8) 15.88 (5/8)

6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 9.52 (3/8)

SDI + TPS

4

(2C+E)*

SDI + TPS

4

(2C+E)*

SDI + TPS

4

(2C+E)*

4

SDI + TPS

(2C+E)*

Max Pipe Run m 20 20 30 30 30

Max Lift m 12 12 30 30 30

Pre-Charged
R410A

kg 0.8 (5.0 m) 1.05 (5.0 m) 1.6 (7.0 m) 1.8 (7.0 m) 1.8 (7.0 m)

Add. Charge g/m 30 30 20 20 55

Drain Pumps Optional*

Standard Accessories

Indoor ­Cooling

Indoor ­Heating

Outdoor ­Cooling

Outdoor ­Heating

°CDB/
°CWB

°CDB 20 ~ 27

°CDB -10 ~ 46 -15 ~ 43 -15 ~ 46

°CDB -15 ~ 24 -15 ~ 24 -15 ~ 24

VAL includes

wireless control*

5

9

wireless control*

Optional*

VAL includes

5

9

5

Optional*

VAL includes

wireless control*

21/15 ~ 32/23

Optional*

VAL includes

9

wireless control*

5

9

Optional*

VAL includes

wireless control*

4

5

9

Notes:

*1 Nominal conditions cooling: EAT 27°CDB/19°CWB, Ambient 35°CDB. Rated conditions cooling: EAT 24°CDB/17°CWB, ambient

35°CDB.
Nominal conditions heating: EAT 20°CDB/15°CWB, Ambient 7°CDB/6°CWB.

*2 Rated Load Amps (RLA) is based on nominal conditions. Use Maximum Circuit Amps. (MCA) for power supply infrastructure sizing,

etc.

*3 Optional drain pump for SEZ series: PAC-KE07DM-E.
*4 Grille for SLZ-KA VAL series (wireless option): SLP-2ALW. Grille for SLZ-KA VAQ series (wired option): SLP-2AAW (add wired

controller PAR-40MAA or PAC-YT52CRA).

*5 For VAQ model, add wired controller PAR-40MAA or PAC-YT52CRA.

(Rating Conditons)

Cooling: Indoor 27°C, D.B./19°C, W.B.

Outdoor 35°C, D.B./24°C, W.B.

Heating: Indoor 20°C, D.B./15°C, W.B.

Outdoor 7°C, D.B./6°C, W.B.

27

For more information contact

www.mitsubishielectric.com.au
Call 1300 722 228

Distributed and guaranteed throughout Australia by

MITSUBISHI ELECTRIC AUSTRALIA PTY. LTD.

(Incorporated in New South Wales) A.B.N. 58 001 215 792

See website for full

Terms and Conditions

Products in this brochure contain refrigerant R32. Please refer to the specifications before installation and servicing of these products.
The purchaser must ensure that the person and/or companies are suitably licensed and experienced are permitted to install, service

Products in this brochure contain refrigerant R410A. Please refer to the specifications before installation and servicing of these products.

and repair the air conditioners. Suitable access for warranty and service is required. Specifications, designs and other content

The purchaser must ensure that the person and/or companies are suitably licensed and experienced are permitted to install, service and repair

appearing in this brochure is current at the time of printing, and is subject to change without notice. Images are representational for

the air conditioners. Suitable access for warranty and service is required. Specifications, designs and other content appearing in this brochure

illustration purposes. PRINTED: JULY 2019.

is current at the time of printing, and is subject to change without notice. Images are representational for illustration purposes. New publication,
effective April 2015. Superseding L-179-6-C7458-F SI 1204. PRINTED: DECEMBER 2018.

© Mitsubishi Electric Australia 2019
