LCD
Projector
User Manual
ENGLISH
FRANÇAIS
DEUTSCH
X400B
ITALIANO
ESPAÑOL
X390
MODEL LVP-X400BU / LVP-X390U
EN – 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO
PREVENT BLADE EXPOSURE.
NOTE:
SINCE THIS PROJECTOR IS PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET MUST BE INSTALLED NEAR THE EQUIPMENT AND SHOULD BE EASILY ACCESSIBLE.
WARNING
Use the attached specified power supply cord. If you
use another power-supply cord, it may cause interference with radio and television reception.
Use the attached RGB cable, RS-232C cable with this
equipment so as to keep interference within the limit
of a FCC Class A device.
This apparatus must be grounded.
The projector automatically shuts off when the
lamp is used up in about 2,000 hours and cannot
be used until the lamp is replaced and the
internal timer is reset. See page 23.
DO NOT LOOK DIRECTLY INTO THE LENS
WHEN PROJECTOR IS IN THE POWER ON
MODE.
When using the projector in Europe
COMPLIANCE NOTICE
This LCD - Video Projector complies with the
requirements of the EC Directive 89/336/EEC “EMC
Directive” as amended by Directive 93/68/EEC and
73/23/EEC “Low Voltage Directive” as amended by
Directive 93/68/EEC.
The electro-magnetic susceptibility has been chosen
at a level that gains proper operation in residential
areas, on business and light industrial premises and
on small-scale enterprises, inside as well as outside
of the buildings. All places of operation are
characterised by their connection to the public low
voltage power supply system.
WARNING
Use the attached RGB cable or RS-232C cable with
this equipment so as to keep interference within the
limits of a EN55022 Class B and EN55013. Please
follow WARNINGS instructions.
EN – 2
Contents
Important safeguards.......................................................................... 4
Overview ................................................................................................ 6
Using the remote control ..................................................................... 8
Battery installation ......................................................................................................... 8
Installation ........................................................................................... 9
Basic connections ............................................................................... 10
Projector + AV equipment............................................................................................. 10
Projector + DVD player or HDTV decoder ................................................................... 10
Projector + personal computer ...................................................................................... 11
Preparing the projector for operation ............................................... 12
To operate projector power ON.......................................................... 13
Menu operation .................................................................................. 15
Picture adjustment............................................................................. 18
Specification of RGB signals in each computer mode of the projector ....................... 20
Advanced feature for presentation ................................................... 21
Expand ........................................................................................................................... 21
PinP (Picture in Picture) ............................................................................................... 21
Still ................................................................................................................................. 21
Mouse remote control .................................................................................................... 22
Lamp replacement ............................................................................. 23
Maintenance ....................................................................................... 24
ENGLISH
Troubleshooting .................................................................................. 25
Indicators ............................................................................................ 26
Specifications ...................................................................................... 27
Kensington Lock ............................................................................................................ 27
Connectors ..................................................................................................................... 28
Dimensional drawings .................................................................................................. 28
What’s included in the box............................................................................................ 28
Replacement part .......................................................................................................... 28
Trademark, Registered trademark
Macintosh is trademark or registered trademark of Apple Computer Inc.
IBM and PS/2 are trademarks or registered trademarks of International Business Machines Corporation.
Windows is trademark or registered trademark of Microsoft Corporation.
MicroSaver and Kensington are registered trademarks of Kensington Technology Group.
Other brand or product names are trademarks or registered trademarks of their respective holders.
EN – 3
Important safeguards
Please read all these instructions regarding your LCD
projector and retain them for future reference. Follow
all warnings and instructions marked on the LCD projector.
1. Read instructions
All the safety and operating instructions should
be read before the appliance is operated.
2. Retain instructions
The safety and operating instructions should be
retained for future reference.
3. Warnings
All warnings on the appliance and in the operating instructions should be adhered to.
4. Instructions
All operating instructions must be followed.
5. Cleaning
Unplug this projector from the wall outlet before cleaning it. Do not use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
6. Attachments and equipment
Never add any attachments and/or equipment
without the approval of the manufacturer as
such additions may result in the risk of fire, electric shock or other personal injury.
7. Water and moisture
Do not use this projector near water or in contact with water.
8. Accessories
Do not place this projector on an unstable cart,
stand, tripod, bracket or table. Use only with a
cart, stand, tripod bracket, or table recommended by the manufacturer or sold with the
projector. Any mounting of the appliance should
follow the manufacturer's instructions and
should use a mounting accessory recommended
by the manufacturer.
An appliance and cart combination should be
moved with care. Quick stops, excessive force and
uneven surfaces may cause the appliance and
cart combination to overturn.
9. Ventilation
Slots and openings in the cabinet are provided
for ventilation, ensuring reliable operation of the
projector and to protect it from overheating. Do
not block these openings or allow them to be
blocked by placing the projector on a bed, sofa,
rug, or bookcase. Ensure that there is adequate
ventilation and that the manufacturer's instructions have been adhered to.
10. Power sources
This projector should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power,
please consult your appliance dealer or local
power company.
11. Power-cord protection
Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items
placed upon or against them. Pay particular attention to cords at plugs, convenience receptacles,
and points where they exit from the appliance. Do
not put the power cord under a carpet.
12. Overloading
Do not overload wall outlets and extension cords
as this can result in a fire or electric shock.
13. Objects and liquids
Never push objects of any kind through openings of this projector as they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the projector.
14. Servicing
Do not attempt to service this projector yourself. Refer all servicing to qualified service personnel.
15. Damage requiring service
Unplug this projector from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
(a) If the power-supply cord or plug is dam-
aged.
(b) If liquid has been spilled, or objects have
fallen into the projector.
(c) If the projector does not operate normally
after you follow the operating instructions.
Adjust only those controls that are covered
by the operating instructions. An improper
adjustment of other controls may result
in damage and may often require extensive work by a qualified technician to restore the projector to its normal operation.
(d) If the projector has been exposed to rain
or water.
(e) If the projector has been dropped or the
cabinet has been damaged.
(f) If the projector exhibits a distinct change
in performance - this indicates a need for
service.
16. Replacement parts
When replacement parts are required, be sure
that the service technician has used replacement
parts specified by the manufacturer or parts
having the same characteristics as the original
part. Unauthorized substitutions may result in
fire, electric shock or other hazards.
17. Safety check
Upon completion of any service or repair to this
projector, ask the service technician to perform
safety checks determining that the projector is
in a safe operating condition.
EN – 4
WARNING:
Unplug immediately if there is something
wrong with your projector.
Do not operate if smoke, strange noise or odor comes
out of your projector. It might cause fire or electric
shock. In this case, unplug immediately and contact
your dealer.
Never remove the cabinet.
This projector contains high voltage circuitry. An
inadvertent contact may result in an electric shock.
Except as specifically explained in the Owner's
Guide, do not attempt to service this product
yourself. Please contact your dealer when you want
to fix, adjust or inspect the projector.
Do not modify this equipment.
It can lead to fire or electric shock.
If you break or drop the cabinet.
Do not keep using this equipment if you break or
drop it. Unplug the projector and contact your dealer
for inspection. It may lead to fire if you keep using
the equipment.
Do not face the projector lens to the sun.
It can lead to fire.
Use correct voltage.
If you use incorrect voltage, it can lead to fire.
Do not place the projector on uneven
surface.
Place the projection on a leveled and stable surface
only. Please do not place equipment on unstable
surfaces.
Do not look into the lens when it is
operating.
It may hurt your eyes.Never let children look into
the lens when it is on.
Do not turn off the main power abruptly or
unplug the projector during operation.
It can lead to lamp breakage, fire, electric shock or
other trouble. It is best to wait for the fan to turn off
before turning main power off.
Do not touch Air outlet grill and Bottom
plate which becomes hot.
Do not touch them or put other equipment in front of
Air outlet grill. The heated Air outlet grill and Bottom plate may cause injury or damage to other equipment. Also, do not set the projector on the desk which
is easily affected by heat.
Clean the air-filter once a month.
Clean the air-filter frequently. If the filter or ventilation slots become clogged with dirt or dust, the temperature inside of the projector may rise and cause
some troubles, such as damage of inside parts, and
shortening the life of panel.
Place of installation
For safety’s sake, refrain from setting the projector at
any place subjected to high temperature and high
humidity. Please maintain an operating temperature,
humidity, and altitude as specified below.
• Operating temperature: between +41°F (+5°C) and
+104°F (+40°C)
• Operating humidity: between 30 and 90%
• Never put any heat-producing device under the pro-
jector so that the projector does not overheat.
• Do not attach the projector to a place that is unstable or subject to vibration.
• Do not install the projector near any equipment that
produces a strong magnetic field. Also refrain from
installing near the projector any cable carrying a
large current.
• Place the projector on a solid, vibration free surface: otherwise it may fall, causing serious injury
to a child or adult, and serious damage to the product.
• Do not stand the projector: it may fall, causing serious injury and damage to the projector.
• Place the projector within a slope of ±15˚. Slanting
the projector more than ±15˚ may cause trouble or
explosion of the lamp.
• Do not place the projector near air-conditioning unit
or heater to avoid hot air to the exhaust and ventilation hole of the projector.
ENGLISH
COMPLIANCE NOTICE OF FCC
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set
out in the interference-causing equipment standard entitled “Digital Apparatus”, ICES-003 of the Department of
Communications.
Changes or modifications not expressly approved by Mitsubishi could void the user's authority to operate this equipment.
COMPLIANCE NOTICE OF INDUSTRY CANADA
This Class A digital apparatus complies with Canadian ICES-003.
EN – 5
Overview
65
7
1 Air inlet grill (Front)
2 Terminal board
3 Air outlet grill
4 Speaker (Left/Right)
5 Control panel
6 Remote control sensor (Front)
7 Lens
8 Remote control sensor (Rear)
4
3
2
9 Kensington Security Lock Standard
connector
10 Easy-carry handle
1
Control panel
14 13 12
1
2
COMPUTER
3
MENU
4
AUTO
POSITION
5
Terminal board
16
15
INPUT SELECT
REMOTE
DIGITAL
ANALOG
MAIN
1
2
OI
AC IN
3
89 10
LAMP
ZOOM/
FOCUS
VOLUME
TEMP
VIDEO
ENTER
MUTE
11
10
1011121314
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
RS-232C
L
R
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
4
56 7
9
8
7
6
VIDEO 1
IN
S-VIDEO
VIDEO
AUDIO
89
USB
VIDEO 2
IN
1 Power button
2 – (VOLUME) button
3 COMPUTER button
4 MENU button
5 AUTO POSITION button
6 MUTE button
7 Direction buttons
8 ENTER button
9 VIDEO button
10 + (VOLUME) button
11
ZOOM/FOCUS button
12 TEMP (temperature) indicator
13 LAMP indicator
14 Power indicator
1 Main power
I : ON
O : OFF
2 Ground terminal
3 Power jack
4 COMPUTER 2 IN terminal (D-SUB mini 15P)
5 COMPUTER OUT terminal (D-SUB mini 15P)
6 AUDIO OUT jack
7 Video/audio input terminals
8 USB Terminal
9 RS-232C (DIN 8P) terminal
10 COMPUTER 2 AUDIO IN jack
11 COMPUTER 1 AUDIO IN jack
12 COMPUTER 1 IN terminal (DVI-D24P)(For
LVP-X400BU only)
13 COMPUTER 1 IN terminal (D-SUB mini 15P)
14 INPUT SELECT switch (For LVP-X400BU only)
15 Reset button
16 Wired remote control (REMOTE) jack
EN – 6
Bottom side
1
2
3
1 Release buttons (Left/Right)
2 Adjustment foot (Left/Right)
3 Air inlet cover
4 Lamp cover
ENGLISH
Caution:
Do not replace the lamp right after using the projector. The
lamp will be very hot.
4
Remote control
VIDEO
VOLME
RIGHT CLICK
ENTER
P in P
MUTE
KEYSTONE
ZOOM/
FOCUS
LASER
20
1
2
COMPUTER
AUTO
POSITION
3
4
MENU
5
6
7
EXPAND STILL
19
18
17
16
15
14
13
12
11
10
9
8
1 Power button
2 COMPUTER button
3 AUTO POSITION button
4 MENU button
5 Right click button (For mouse)
6 EXPAND button
7 PinP button
8 Wired remote control jack
9 MUTE (Audio/Video) button
10 STILL button
11
Direction buttons
1
2 ENTER button
13 Mouse pointer
14 LASER button
15 + , – (VOLUME) buttons
16 ZOOM/FOCUS button
17 VIDEO button
18 KEYSTONE button
19 Remote control transmitter
20 Laser aperture
21 Left click button (For mouse)
• Pressing LASER button emits the laser beam about
1 minute. Release LASER button and press it again
if you wish to emits the laser beam.
AVOID EXPOSURE -LASER
RADIATION IS EMITTED
FROM THIS APERTURE.
21
About laser beam
This remote control is class 2 (max. output 1 mW laser diode
640 - 660 nm) laser equipment.
Beam Divergence : 6m distance about 10.0mm x 10.0mm (±6.0mm)
CAUTION
LASER RADIATION
DO NOT STARE INTO BEAM
WAVE LENGTH : 640 - 660 nm
MAX OUTPUT : 1 mW
CLASS 2 LASER PRODUCT
IEC 60825-1:1993+A1:1997
CAUTION :
• Pressing the LASER button provided remote control emits
laser beam. Do not look into the beam light directly. Do not
point the laser beam at people. Looking the laser beam directly
may damage eyesight.
• Use of controls or adjustments or procedures other than those
specified herein may result in hazardous radiation exposure.
EN – 7
Using the remote control
Battery installation
Use two AA size batteries.
1. Remove the back cover of the remote control by pushing the battery compartment door in the direction of the
arrow.
2. Load the batteries making sure that they are positioned correctly (+ to +, and - to -).
3. Replace the back cover.
12 3
Important:
• Do not use a new battery with an old one.
• Load batteries in the correct position.
• Do not heat, take apart, or throw batteries into fire.
• Do not try to recharge batteries. Do not use rechargeable batteries.
• If the solution of batteries comes in contact with your skin or clothes, rinse with water. If the solution comes
in contact with your eyes, rinse them with water and then consult your doctor.
Operation area (for wireless control system)
The range for operation is about 10 m (about 32 feet) when the remote control points to the projector. The distance to the screen back to the projector must be less than 7 m (about 23 feet). Depending on the type of the
screen, the distance will be different.
20˚
15˚
30˚30˚
20˚
15˚
20˚ 20˚
Important:
Avoid the direct sunlight or fluorescent light to the remote control sensor. Also keep the distance of more than 2 m
(6.5") between the remote control sensor and fluorescent lamp on the remote control may not work correctly.
Using the wired remote control
Attached remote control for this projector can be used as a wired remote control with remote control cable. Wired
remote control is useful for operating in a distance or outside of the operating area.
REMOTE
MAIN
OI
INPUT SELECT
DIGITAL
ANALOG
AC IN
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
RS-232C
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
VIDEO
L
AUDIO
R
• When the remote control is connected with remote
control cable, it does not work as a wireless
remote control.
USB
• When you need a longer cable, use a pin-pin cable.
• When using the wired remote control, the laser beam may be darker. It is normal.
EN – 8
Installation
Orientation of the projector
Picture size can be set by changing the distance between the screen and the projector.
Front projection
Height
(between the screen and the
L
head of the projector)
Screen
Screen
Width
A
B
To find the approximate distance
between the projector and screen:
Multiply the width of the screen
x 1.9 (min.) , Multiply the width of
A=B
the screen x 2.4 (max.).
• Refer to the chart for recommended distances in maximum
zoom and minimum zoom.
ENGLISH
Distance from screen (L) / (approximate)
Maximum
zoom (min.)
(cm)
155
235
315
394
474
554
634
714
794
1194
(inch)
61 "
92 "
124 "
155 "
187 "
218 "
250 "
281 "
312 "
470 "
Minimum
zoom (max.)
(cm)
195
296
396
496
597
697
797
898
998
–
(inch)
77 "
116 "
156 "
195 "
235 "
274 "
314 "
353 "
393 "
–
Diagonal size
(inch)
40 "
60 "
80 "
100 "
120 "
140 "
160 "
180"
200 "
300 "
Screen
Height
(inch)
24 "
36 "
48 "
60 "
72 "
84 "
96 "
108 "
120 "
180 "
Width
(inch)
32 "
48 "
64 "
80 "
96 "
112 "
128 "
144 "
160 "
240 "
• The above numbers are approximate, and may be slightly different from the actual measurements.
Front projection, ceiling mount
For ceiling mount, you need the ceiling mount kit.
• For rear projection, set IMAGE REVERSE in the
INSTALLATION menu to MIRROR. See Page 16.
Ask a specialist for installation. For more details,
consult your dealer.
Caution:
• Placing the projector on a carpet reduces ventilation from the fan at the bottom and might cause
problems. Place a hard board or similar item
under the projector to facilitate ventilation of the
unit.
• Place the projector more than 20 in. from the wall
SCREEN
to prevent blocking the intake, exhaust slots and
ventilation of this projector because hot air comes
• When using the ceiling mount, set IMAGE REVERSE in the INSTALLATION menu to MIRROR INVERT. See Page 16.
• Projected images may appear darker when the
unit is used as a ceiling installation than when it
is used in the tabletop position. This does not
signify a product malfunction.
Rear projection
Ask a specialist for installation. For more details,
consult your dealer.
out of it.
• Do not use the projector under the following
circumstances, which may cause fire or electric
shock.
• in a dusty or humid place
• while the projector is lying sideways or upside
down
• near a heater
• in a kitchen or oily, smoky or damp place
• in direct sunlight
• with high temperature, such as a closed car
• where the temperature is lower than 41°F or
higher than 104°F
SCREEN
Important:
• Do not put stress on the lens, as this may cause
damage.
´ EN – 9
Basic connections
L
R
S-VIDEO
VIDEO
AUDIO
MAIN
REMOTE
AC IN
AUDIO OUT
VIDEO 1
IN
VIDEO 2
IN
COMPUTER OUT
OI
AUDIO 2 IN
COMPUTER 2 IN
AUDIO 1 IN
USB
DIGITAL
ANALOG
INPUT SELECT
COMPUTER 1 IN
RS-232C
B G R
C
B(PB
)Y CR(PR)
HD/CS VD
DVD player or HDTV decoder
No connection
BNC - RCA connector
(optional)
Mini D-SUB 15 pin-BNC
conversion cable (optional)
to COMPUTER
AUDIO IN
to AUDIO OUT
AUDIO cable
to COMPUTER
IN (Mini D-SUB
15P)
This projector can be connected to equipment such as VCRs, video cameras, videodisc players, and personal computers having analog RGB output.
Important:
• Make sure that your equipment is turned off before connection.
• Plug in firmly and unplug by holding the plug, not by pulling the main power cable.
• If connected units are set too close to one another, the image may be affected.
• Refer to the owner's guide of each component for details of connections.
Projector + AV equipment
Important:
• Match the color of video and audio plugs on the AV cable with the connections.
• S-video signals take priority over video signals. If you input both S-video signals and normal video signals at
the same time, the normal video input automatically is inhibited.
Connect either one of these.
REMOTE
MAIN
OI
INPUT SELECT
DIGITAL
ANALOG
AC IN
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
USB
RS-232C
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
VIDEO
L
AUDIO
R
to S-video input
to video input
to audio input
to video output
to audio output
VCR etc.
to S-video output
Projector + DVD player or HDTV decoder
Some DVD players have output terminal for 3 line fitting (Y, CB, CR). When connecting them to the projector,
connect to COMPUTER 1 IN or COMPUTER 2 IN of the projector. In this case, set “ Y, CB , CR” for COMPUTER
INPUT setting in SIGNAL menu.
DVD player generally has SDTV system component
video output (Y, CB, CR) terminals. HDTV decoder has
HDTV system component video output (Y, PB, PR) terminals. When connecting the projector with DVD
player or HDTV decoder, the signal cuircuit
automaticaly applied to either of them. In this case,
the COMPUTER INPUT in the SIGNAL menu becomes [Y, CB, CR/Y, PB, PR].
• Y, PB, PR is an example of the terminal names for a HDTV decoder.
• The terminal name is different depending on the connected equipment.
• Use mini D-SUB 15 pin-BNC conversion cable for connection.
• Some DVD players may not project the image correctly.
• When connecting with HDTV equipment which has R, G, B output, set RGB for the COMPUTER INPUT in
the SIGNAL setting menu.
• Change the setting in the SIGNAL menu, when 525p signal is inputted. (Refer to page 20).
• Set the INPUT SELECT switch on the terminal board to ANALOG. (For LVP-X400BU only)
EN – 10
Projector + Personal computer
For computer with Mini D-SUB 15P terminal (IBM PC or IBM PC compatibles etc.)
RGB cable for PC
to COMPUTER IN (Mini D-SUB 15P)
USB
INPUT SELECT
REMOTE
DIGITAL
ANALOG
MAIN
OI
AC IN
to COMPUTER
OUT
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
RS-232C
AUDIO 1 IN
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
AUDIO 2 IN
VIDEO
AUDIO OUT
L
AUDIO
R
to COMPUTER AUDIO IN
PC audio cable (option)
to PC audio
output
to monitor
port
AUDIO OUT
MONITOR OUTPUT
RGB cable for PC (option)
When outputting to both a PC monitor and the projector.
• Set the INPUT SELECT switch on the terminal board to ANALOG. (For LVP-X400BU only)
For computer with DVI terminal (For LVP-X400BU only)
DVI cable (option)
ENGLISH
computer
to COMPUTER IN (DVI-D24P)
REMOTE
MAIN
OI
INPUT SELECT
DIGITAL
ANALOG
AC IN
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
USB
RS-232C
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
VIDEO
L
AUDIO
R
computer
to DVI port
to COMPUTER AUDIO IN
PC audio cable (option)
to PC audio
output
AUDIO OUT
DVI
• Set the INPUT SELECT switch on the terminal board to DIGITAL.
• The signal inputted to the COMPUTER 1 IN (DVI) terminal is not outputted from the COMPUTER OUT terminal.
• Make sure to connect computer with DVI cable before starting computer. If connecting computer with DVI cable after
starting the computer, the image signal may not be outputted from DVI terminal of computer
Important:
• Connectors or analog RGB output adapters may be necessary depending on the PC connected to this projector.
Please contact your dealer.
• The audio input for this projector is a stereo pin jack. Please check the available cable for the audio input
terminal of the computer. Some personal computer may not have the audio output terminal.
For using Macintosh
• A monitor output adapter is necessary for a Macintosh if it has no video port. Please contact your dealer.
• A MAC adapter for RGB cable may be necessary depending on the personal computer connected to this projec-
tor. Please contact your dealer.
About DDC™ (For DVI connection)
The projector complies with VESA™ DDC™ 2B (EDID) specification. If your computer provides DDC™2B (EDID)
function, setup will be done automatically. If your system is Windows® 98 or higher, your computer supported in
standard. If your system is Windows® 95 or lower, you must down load the driver from our Internet Home Page for use
this function. Please contact your dealer or Mitsubishi sales office for more details.
´ EN – 11
Preparing the projector for operation
Getting ready for projection
1. Connect the power cord provided to the projector.
2. Connect the power cord to the wall power outlet.
3. Remove the lens cap.
Warning:
• Do not look directly into the lens when projector is
“ON”.
• The lens cap is for protecting the lens. If you leave
the power on with the cap on, the cap may be warped.
Please remove the lens cap when you turn the power
on.
• This projector is equipped with the power cords for
both U.S. and Europe. Use the appropriate power
cord for your country.
• A three-pin grounding type power plug is used with
the projector. Do not remove the grounding pin on
the power plug. If you are unable to insert the plug
into the outlet, contact your electrician to replace
your A/C outlet.
• The supplied power cord for U.S. is used for 120V
only. Never connect to any outlet or power supply
having a different voltage or frequency. If you
connect to the power supply having a different
voltage, please use the appropriate power cord.
• Use 100-240V AC 50/60Hz correct voltage otherwise it may lead to fire or electric shock.
• Do not place any objects on the power cord, and keep
the projector away from heat sources to avoid damaging the power cord. A damaged power cord can
cause fire or electric shock.
• Do not modify or alter the power cord otherwise it
may cause fire or electric shock.
Contact your dealer if the cord is damaged.
Caution:
• Plug in firmly and unplug by holding the plug, not
by pulling the cable out.
• Do not plug in or out with wet hands. It may cause
an electric shock.
Adjusting the angle of projection
For the best result, project onto a flat screen with a 90
degree angle to the floor. If necessary, tilt the projector
by adjusting two foot adjustments on the bottom of the
projector.
screen
1. Lift the projector to the appropriate angle.
2. Press the buttons by the projector’s adjustable front
feet, this will allow the feet to slide out to the approximate position.
3. Release the foot adjustment buttons to lock the feet
in that position.
4. Rotate the projector feet for fine adjustment.
After using the projector
5. Return the adjustable feet into the projector.
Important:
• The image becomes trapezoid shape when the
screen or project is not level. Use KEYSTONE
button and + or - buttons on the remote control to
adjust, however, the circumference of the image
may not be focused.
• Screen on a flat wall with a 90˚ angle to the floor.
• Align projector to produce a full screen display as
illustrated on page 9.
• The distance from the projector to the screen must
be compatible with screen size chart on page 9.
Note the distance from the screen chart.
Adjustment foot
EN – 12
To operate projector power ON
USB
L
R
RS-232C
VIDEO 1
IN
S-VIDEO
VIDEO
AUDIO
VIDEO 2
IN
REMOTE
MAIN
OI
INPUT SELECT
DIGITAL
ANALOG
AC IN
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
3 , 9 , 10
4
AUTO POSITION
button
COMPUTER
AUTO
POSITION
VIDEO
VOLUME
KEYSTONE
ZOOM/
FOCUS
ENGLISH
5 , 7
2 , 11
TEMP
LAMP
COMPUTER
MENU
AUTO
POSITION
indicator
ZOOM/
FOCUS
VOLUME
VIDEO
ENTER
MUTE
LAMP POWER
-
green
-
5 , 7
4
MUTE button
red
green
red
3 , 9 , 10
6 , 8
4
AUTO POSITION
button
1. Turn on the equipment connected to the projector.
2. Put the projector into standby mode by pressing the
main power switch. The POWER indicator lights up
red.
3. Turn the projector on by pressing the POWER button.
The light source lamp starts warming up, eventually turning completely on.
• When the light source lamp does not light up,
wait until the LAMP indicator is turned off, then
press the POWER button again.
• If the main power switch to the unit is turned
off within two minutes of turning off the light
source lamp, power will not be applied to the
lamp for one minute when the next time the
main unit power switch is turned on. When
this happens, the indicator lamp will blink for
one minute.
condition
stand-by
when light source lamp is on
light source lamp held off temporarily
Important:
• A darkened image may be seen right after pressing
the POWER button due to warming up of this projector. While warming up, no other commands can
be accepted.
• When the lamp indicator is blinking red, the service life of the lamp is about to end. Replace the
lamp. See pages 23 and 26.
RIGHT CLICK
ENTER
P in P
MUTE
LASER
STILL button
MUTE button
6 , 8
MENU
EXPAND STILL
• The picture might not be of optimum performance
in extreme hot or cold conditions. (The projector is
not malfunctioning.)
4. Select the desired external input source by using
the COMPUTER or VIDEO button.
• The projector automatically selects the appropriate
signal format. The selected signal format is displayed on the screen.
• When selecting the COMPUTER input, the image
may flicker. Press the $ or % button to adjust the
image.
For LVP-X400BU only
• To view the digital input, select COMPUTER 1 input and set the INPUT SELECT switch on the terminal board to DIGITAL.
5. Press the ZOOM/FOCUS button to ZOOM. “ZOOM”
will appear on the display.
6. Adjust with the + or - button to get an approximate
size.
7. Press the ZOOM/FOCUS button to FOCUS. “FOCUS” will appear on the display.
8. Adjust with the + or - button to get a fine picture.
• Focus and zoom adjustment is possible in the normal
picture mode only. In PinP or EXPAND mode, the
adjustment is prohibited.
´ EN – 13
To operate projector power ON (Continue)
Turning off the projector
9. Press the POWER button.
The message “POWER OFF? YES : PRESS AGAIN”
appears on the screen.
• To exit from this mode, press any button except
POWER, LASER, mouse pointer, R/L-click,
STILL and VOLUME + and - buttons.
10.Press the POWER button again.
The light source lamp will be turned off.
Pressing the POWER button second time will shut
off the light source lamp, but the exhaust fan continues to operate for 120 seconds to cool down the
light source lamp and LCD panels. In this time, the
lamp indicator will be turned off.
11.Turn off the main power switch. When turning off
the main switch, the POWER indicator turns off.
• In cases where the main power switch is accidentally turned off when either the intake/exhaust
fan or the power source lamp is in operation, allow
the unit to cool down for 10 minutes with the
power turned off. Repeat step 3 when turning on
the power source lamp. If the lamp does not turn
on immediately, repeat this step two or three
times. Replace the lamp if it should still fail to
turn on.
AUTO POSITION button
When the source is selected to COMPUTER and the
image is not in the right place, follow as shown below.
1. Set screen to the brightest display as possible
(e.g., full-screen display of the “Trash” window).
2. If the screen saver is running, turn off the screen saver.
3. Press the AUTO POSITION button.
• If the image is still not in the right place, adjust
the image position by using the SIGNAL menu.
AV mute
Image and audio are temporarily muted by pressing
the MUTE button. To restore the image and audio to
the normal mode, press the MUTE button again.
• The audio from the AUDIO OUT jack is also muted
by pressing the MUTE button.
Caution:
• When you have finished using this equipment, wait
120 seconds for the exhaust fans to stop. Then turn
off the main switch and unplug the power cable from
the wall outlet, for safety purposes.
• After the lamp is turned off, the lamp cannot be
switched on again for 60 seconds as a precautionary measure. It will take another 60 seconds before
the lamp indicator goes off. If you wish to turn on
the projector again, wait until the indicator is off
then press the POWER button.
• The exhaust fan rotates faster when the temperature around the projector rises.
• When the temperature around the projector becomes
too high, the sign “TEMP!!” blinks red on the screen.
If the temperature stays too high, the lamp will be
shut off automatically .
The projector automatically shuts off when the
lamp is used up in about 2,000 hours and cannot
be used until the lamp is replaced and the
internal timer is reset. See page 23.
The volume from the speaker
Press the volume + or – button to change the volume
from the speaker.
The volume control bar will appear on the screen.
AUDIO 15
• The volume control bar will disappear about 10
seconds after releasing the volume buttons.
• The volume buttons do not work when MENU
selection bar or MENU is displayed.
• The volume from the AUDIO OUT jack is also changed
by pressing the volume + or – button. (Variable LINE
OUT)
• If the high level of audio signal, for example DVD
is supplied into COMPUTER AUDIO IN terminal,
the speaker out may be distorted.
EN – 14
Menu operation
IMAGE CONTRAST ± 30
BRIGHTNESS
COLOR MATRIX
USER
COLOR TEMP.
SHARPNESS ± 10
TINT ± 10
COLOR ± 10
INSTALLATION
FEATURE MENU POSITION 1 (Upper left), 2(Lower right)
SIGNAL MEMORY CALL AUTO, USER1, USER2
KEYSTONE
AUTO POWER ON
AUTO POWER OFF
SPLASH SCREEN
IMAGE REVERSE OFF, MIRROR, INVERT, MIRROR INVERT
EXPAND MODE 1 - 4
FRAME POSI. 1 - 5
VIDEO SIGNAL AUTO , NTSC , PAL , SECAM , 4.43NTSC , PAL-M , PAL-N , PAL-60
LANGUAGE , English , Español , Deutsch , Français , Italiano ,
RESET ALL OK
HORIZ.POSITION 0 - 999
VERT.POSITION 0 - 999
FINE SYNC. 0 - 39
TRACKING
COMPUTER INPUT RGB, YCBCR / YPBP
HOLD AUTO
USER
MEMORIZE
DELETE
DEFAULT
Basic operation
Several settings can be adjusted using Menu.
EXAMPLE: Auto power off time setting
1. Press the MENU button.
Opt
2. Press the $ or % button to select the INSTALLA-
TION menu.
Opt
INSTALLATION
3. Press the ENTER button (or } button).
Opt
INSTALLATION
KEYSTONE
AUTO POWER
ON
AUTO POWER
OFF
ON
SPLASH SCREEN ON
IMAGE REVERSE
XGA60
XGA60
XGA60
0˚
OFF
OFF
OFF
± 30
1
2
USER
OFF
STANDARD
HIGH
LOW
USER
-15˚, -12˚, -9˚, -6˚, -3˚, 0˚, +3˚, +6˚, +9˚, +12˚, +15˚
ON , OFF
OFF, 5, 10, 15, 30, 60 min
ON , OFF
ON , OFFANAMORPHIC
0 - 9999
ON
OFF
USER1, USER2
USER1, USER2
RED ± 30
YELLOW ± 30
GREEN ± 30
CYAN ± 30
BLUE ± 30
MAGENTA ± 30
SATURATION ± 5
CONTRAST R ± 30
CONTRAST B ± 30
BRIGHTNESS R ± 30
BRIGHTNESS B
(Displays only when the source is selected to VIDEO)
(Displays only when the source is selected to VIDEO)
(AUTO : When the source is selected to COMPUTER)
± 30
*
*
* : Setting range is different
according to the type of
*
the signal.
R
BEGIN -1 - -99
END 1 - 99
CLAMP POSITION 0 - +63
CLAMP WIDTH 1 - 63
HORIZ. PIXELS 0 - 9999
VERT LINES 0 - 9999
PLL
VERT. SYNC.
SHUTTER(U)
SHUTTER(L)
SHUTTER(LS)
SHUTTER(RS)
AUTO, 0 - 7
AUTO, ON, OFF
*
*
*
*
0 - 383
0 - 383
0 - 510
0 - 510
4. Press the { or } button to select AUTO POWER
OFF.
AUTO POWER
ON
AUTO POWER
OFF
ON
SPLASH SCREEN ON
OFF
OFF
5. Press the $ or % button to adjust auto power off
time.
AUTO POWER
ON
AUTO POWER
OFF
ON
SPLASH SCREEN ON
OFF
30 min
6. Exit the menu system by pressing the MENU button several times.
• If the menu operation is not working, press the
RESET button on the terminal board using a suitable sharp object, push gently.
• The settings with 2 mark, you should press the
ENTER button after selecting.
ENGLISH
EN – 15
Opt
INSTALLATION
XGA60
OFF
KEYSTONE
0˚
AUTO POWER
ON
OFF
SPLASH SCREEN ON
AUTO POWER
OFF
OFF
IMAGE REVERSE
ON
Opt
XGA60
MENU POSITION
VIDEO SIGNAL AUTO
LANGUAGE English
RESET ALL OK
ANAMORPHIC OFF
A
Ë
?
EXPAND MODE 1.
FRAME POSI.
A
A
A
A
1.
3.
FEATURE
Menu operation (continued)
1 IMAGE
CONTRAST ........ Adjusts the picture contrast. The contrast becomes higher
as the number increases.
BRIGHTNESS .... Adjusts image brightness. The image becomes brighter as
the number increases.
COLOR MATRIX. ......
Adjusts color balance in each color of the image. See page
18.
COLOR TEMP.. .. Adjusts color temperature. See page 18.
SHARPNESS ...... Adjusts the picture sharpness. The sharpness becomes
sharper as the number increases.
TINT .................... Adjusts the color balance in the image. The color balance
of the image shifts green as the number increases and
shifts to purple as the number decreases (displays only when the source is selected to
VIDEO).
• When the TV50 (PAL, SECAM) signal is inputted, you cannot adjust the TINT.
COLOR ................ Adjusts the color intensity of the image (displays only when the source is selected to VIDEO).
2 INSTALLATION
KEYSTONE ........ Adjusts keystone correction of the image. If the image has
keystone distortion, select the approximate setting.
AUTO POWER ON .....
To select whether to boot up automatically when the power is
turned on external to the projector. In this case, the main
power switch of the projector has to be ON. Set this when the
projector is hanging on the ceiling.
• The projector is in stand-by mode when the lamp is not
on. In this case, use the remote control to turn on the
lamp.
AUTO POWER OFF ..
Use to select the length of time before projector switches to stand-by when there is no input
signal selected source.
SPLASH SCREEN .
IMAGE REVERSE
Use to display the splash screen on the screen when the power is turned ON.
Use to reverse or invert the projected image. MIRROR is used to rear projection. MIRROR,
INVERT is for rear projection ceiling mount.
Opt
CONTRAST
BRIGHTNESS 0
COLOR MATRIX
COLOR TEMP. STANDARD
SHARPNESS 0
TINT 0
COLOR 0
XGA60
0
USER
3 FEATURE
MENU POSITION .
Use to select the position where the menu is displayed,
(upper left) or (lower right).
EXPAND MODE .. Selects the mode of enlarging screen. See page 21.
FRAME POSI. .... Sets the position of sub screen. See page 21.
VIDEO SIGNAL ... When AUTO is set, the appropriate video format is
automatically selected according to the input signal. If the
image does not appear correctly, select the desired video
format manually.
ANAMORPHIC... Set ON when displaying DVD discs which are recorded in
letter boxed images.
LANGUAGE ....... Use to select the language for the projector display such as
menu. ( / English / Español / Deutsch / Français / Italiano / )
RESET ALL ........ Use to reset the MENU setting (except LANGUAGE).
• When the LANGUAGE in FEATURE menu is set to English and NTSC video format is selected, the brightness is decreased 15 points by set-up cancel function for U.S. (The indicated value is not changed.) The image
becomes darker, but this is not a failure of the projector.
EN – 16
4 SIGNAL
CLAMP POSITION
SIGNAL-USER
0
CLAMP WIDTH 0
HORIZ. PIXELS 0
PLL AUTO
SHUTTER(RS) 0
VERT. LINES 0
VERT. SYNC. AUTO
SHUTTER(LS) 0
SHUTTER(L) 0
SHUTTER(U) 0
MEMORY CALL ........
HORIZ. POSITION ....
VERT. POSITION .....
FINE SYNC. ....... Use to synchronize the projector with PC input signals so
TRACKING ......... Use to avoid image noise such as wide stripes.
COMPUTER INPUT ....
Use to select AUTO, USER 1 or USER 2. See below.
Use to adjust the horizontal position of the image.
Use to adjust the vertical position of the image.
that the image is not blurred.
The unit adjusts itself automatically when connected to a
DVD player with a component video output (Y, CB, CR). In
the case ( Y, PB, PR). In the case the projector is connected to
equipment that includes RGB output terminal, adjust to
RGB mode.
SIGNAL
A
MEMORY CALL
U
HORIZ. POSITION 0
VERT. POSITION 0
FINE SYNC. 0
TRACKING 0
COMPUTER INPUT RGB
R G B
R G B
HOLD AUTO
USER MEMORIZE DELETE DEFAULT
HOLD .................. Adjusts the image when flagging occurs near the top of the
screen.
5 SIGNAL - USER (Normally, there is no need for adjustments.)
CLAMP POSITION/
CLAMP WIDTH .........
If you use something similar, the brighter colors of the
projected image may become blurred. In this case, adjust
CLAMP POSITION or CLAMP WIDTH.
HORIZ.PIXELS .. Use to adjust the width of the image. The image size grows
wider as the number increases. (Adjust to the horizontal
pixels of the input signal for normal setting.)
VERT.LINES ...... Use to adjust the height of the image. The image size grows
higher as the number increases. (Adjust to the vertical lines
of the input signal for normal setting.)
PLL ...................... Use to adjust the image when skewed on top. Select AUTO for
normal setting.
VERT.SYNC. ...... Use to adjust the image when its motion does not run
smoothly. Select AUTO for normal setting.
SHUTTER(U) .....Use to adjust the image when the noise etc. appears on top part of image.
SHUTTER(L) ...... Use to adjust the image when the noise etc. appears on bottom part of image.
SHUTTER(LS) .... Use to adjust the image when the noise etc. appears on left side of image.
SHUTTER(RS) ... Use to adjust the image when the noise etc. appears on right side of image.
Opt
XGA60
AUTO
ENGLISH
User memory for signal setting
This projector can memorize the maximum of 2 signal menu settings.
Memorizing the setting
1. Select MEMORIZE in the SIGNAL menu, and press the ENTER button.
2. Press the $ or % button to select the memory which you wish to record (USER 1 or USER 2).
3. Press the ENTER button.
Initialite the setting which has been changed (Default)
Select RESET in the SIGNAL menu, and press the ENTER button.
• When initializing, selection buttons will not work for about 2 - 18 seconds.
Select the user setting
Select MEMORY CALL in SIGNAL menu, and press the $ or % button to select the memory (USER 1 or USER 2).
Reset the recorded setting
1. Select DELETE in the SIGNAL menu, and press the ENTER button.
2. Press the $ or % button to select the memory which you wish to reset (USER 1 or USER 2).
3. Press the ENTER button.
The recorded setting will be reset.
EN – 17
Picture adjustment
Adjusting the image
You can adjust the picture by using the IMAGE menu.
Opt
CONTRAST
BRIGHTNESS 0
COLOR MATRIX
COLOR TEMP. STANDARD
SHARPNESS 0
TINT 0
COLOR 0
XGA60
0
USER
To control the level of white-to-black in the image :
Adjust CONTRAST in IMAGE menu. Press the %
button to increase the contrast and the $ button to
reduce it.
To control the light level of the image :
Adjust BRIGHTNESS in IMAGE menu. Press the %
button to lighten the image and the $ button to
darken the image.
To adjust the detail and clarity of the image :
Adjust SHARPNESS in IMAGE menu. Press the %
button to make the picture seem sharper and the $
button to make it softer.
To determine the intensity of the color :
Adjust COLOR in IMAGE menu. Press the %
button to increase the amount of color in the image
and the $ button to decrease it.
To adjust the red-green color balance of the image :
Adjust TINT in IMAGE menu. Press the % button
to increase the amount of red in the image and the $
button to increase the amount of green in the image.
Color matrix
This feature adjusts the color balance in each color of
RGB (Red, Green, Blue), and their neutral colors
(yellow, cyan, magenta) by using Color correction
adjustment. Use Color correct adjustment when
enphasizing a specific color, or when only a certain
color balance is not correctly adjusted.
1. Select COLOR MATRIX in IMAGE menu.
2. Press the ENTER button.
COLOR MATRIX
1 2
USER OFF
5. Press the $ or % button to adjust the color balance
of the color.
6. Repeat steps 4 and 5 for more adjustments.
7. Exit the menu system by pressing the MENU button several times.
• When using the setting which has been already
prepared, select desired position 1 or 2 in step 3.
When the source is selected to VIDEO, 1 will be
selected automatically. When the source is selected
to COMPUTER, 2 will be selected automatically.
• When not using Color matrix adjustment, select
OFF in step 3.
Color temperature
1. Select COLOR TEMP in IMAGE menu.
2. Press the $ or % button to select USER 2.
3. Press the ENTER button.
COLOR TEMP.-USER
CONTRAST R
CONTRAST B 0
BRIGHTNESS R 0
BRIGHTNESS B 0
4. Press the { or } button to select the desired item.
5. Press the $ or % button to adjust the item.
6. Repeat steps 4 and 5 for more adjustments.
7. Exit the menu system by pressing the MENU button several times.
About color temperature
There are different kinds of white color. Color temperature is
a way to show the differences. The white, which temperature
is low, becomes reddish white. When the color temperature is
higher, the white becomes more bluish. This projector sets
this color temperature by changing the numbers of contrast
blue and red.
To set the color temperature high:
Set the contrast B (Blue) number high, and the contrast R
(Red) number low.
To set the color temperature low:
Set the contrast B (Blue) number low, and the contrast R
(Red) number high.
0
RED 0
YELLOW
GREEN
CYAN
BLUE
MAGENTA 0
SATURATION
0
0
0
0
0
3. Press the $ or % button to select USER }.
4. Press the { or } button to select the desired color.
• If you wish to adjust the color intensity of the
image, select SATURATION.
EN – 18
Adjustment from personal computer
Although this projector sets proper signal systems
automatically for the image signal from personal
computers, it cannot be applied to some of personal
computers. In this case, press the AUTO POSITION
button. If the images are still not projected correctly,
use the MENU display to adjust the projected images.
Opt
SIGNAL
A
MEMORY CALL
U
HORIZ. POSITION 0
VERT. POSITION 0
FINE SYNC. 0
TRACKING 0
COMPUTER INPUT RGB
R G B
R G B
HOLD AUTO
USER MEMORIZE DELETE DEFAULT
Image moved to right or left :
Adjust HORIZ. POSITION in SIGNAL menu. Press
the % button to move the image to left. Press the $
button to move the image to right.
Image moved to up or down :
Adjust VERT. POSITION in SIGNAL menu. Press
the % button to move the image to upward. Press
the $ button to move the image to down.
Image flickers / Image is out of focus :
Adjust FINE SYNC. in SIGNAL menu.
XGA60
AUTO
Top part of image curves :
Change the setting of HOLD in SIGNAL menu or
PLL in SIGNAL - USER menu.
HOLD ...Select ON, and adjust BEGIN or
END for image which top part is the
least curved.
PLL .......Select 0 - 7 for an image in which top
part is the least curved. Select AUTO for
normal setting.
Image does not move naturally :
Adjust VERT. SYNC. of the menu in SIGNAL USER menu. Select AUTO for normal setting.
curved. Select AUTO for normal setting.
• Do not change each menu setting in USER menu
for normal setting.
Simple adjustment method
1. Select HORIZ. POSITION in SIGNAL menu.
2. Press the$ or % button to adjust the horizontal
start position (the left side of image).
3. Select TRACKING in SIGNAL menu.
4. Press the$ or % button to adjust the horizontal
end position (the right side of image).
5. Repeat steps 1 to 4 for fine adjustment.
6. Select VERT. POSITION in SIGNAL menu.
7. Press the$ or % button to adjust the vertical
start position (the top end of image).
ENGLISH
SIGNAL-USER
CLAMP POSITION
CLAMP WIDTH 0
HORIZ. PIXELS 0
VERT. LINES 0
PLL AUTO
VERT. SYNC. AUTO
SHUTTER(U) 0
SHUTTER(L) 0
SHUTTER(LS) 0
SHUTTER(RS) 0
0
Wide strips appear :
Adjust CLAMP POSITION or CLAMP WIDTH of
each menu in SIGNAL - USER menu.
Noise appears on right or left side of image :
Adjust SHUTTER (LS), SHUTTER (RS) or HORIZ.
PIXELS of the menu in SIGNAL - USER menu.
Noise appears on top or bottom part of image :
Adjust SHUTTER (U), SHUTTER (L) or VERT.
LINES of the menu in SIGNAL - USER menu.
EN – 19
Picture adjustment (continued)
Specification of RGB signals in each computer mode of the projector
Signal mode resolution horizontal Vertical Normal mode Real mode
TV60 – 15.73 59.94 1024 x 768 –
TV50 – 15.63 50.00 1024 x 768 –
1080i – 33.75 60.00 1024 x 576 –
720p – 45.00 60.00 1024 x 576 –
PC98 640 x 400 24.82 56.42 1024 x 640 640 x 400
CGA70 640 x 400 31.47 70.09 1024 x 640 640 x 400
CGA85 640 x 400 37.86 85.08 1024 x 640 640 x 400
VGA60 640 x 480 31.47 59.94 1024 x 768 640 x 480
VGA72 640 x 480 37.86 72.81 1024 x 768 640 x 480
VGA75 640 x 480 37.50 75.00 1024 x 768 640 x 480
VGA85 640 x 480 43.27 85.01 1024 x 768 640 x 480
SVGA56 800 x 600 35.16 56.25 1024 x 768 800 x 600
SVGA60 800 x 600 37.88 60.32 1024 x 768 800 x 600
SVGA72 800 x 600 48.08 72.19 1024 x 768 800 x 600
SVGA75 800 x 600 46.88 75.00 1024 x 768 800 x 600
SVGA85 800 x 600 53.67 85.06 1024 x 768 800 x 600
XGA43i 1024 x 768 35.52 86.96 1024 x 768 1024 x 768
XGA60 1024 x 768 48.36 60.00 1024 x 768 1024 x 768
XGA70 1024 x 768 56.48 70.07 1024 x 768 1024 x 768
XGA75 1024 x 768 60.02 75.03 1024 x 768 1024 x 768
XGA85 1024 x 768 68.68 85.00 1024 x 768 1024 x 768
SXGA70a 1152 x 864 63.85 70.01 1024 x 768 1024 x 768
SXGA75a 1152 x 864 67.50 75.00 1024 x 768 1024 x 768
SXGA85a 1152 x 864 77.49 85.06 1024 x 768 1024 x 768
SXGA60b 1280 x 960 60.00 60.00 1024 x 768 1024 x 768
SXGA75b 1280 x 960 75.00 75.00 1024 x 768 1024 x 768
SXGA43i 1280 x 1024 46.43 86.87 1024 x 768 1024 x 768
SXGA60 1280 x 1024 63.98 60.02 1024 x 768 1024 x 768
SXGA75 1280 x 1024 79.98 75.03 1024 x 768 1024 x 768
SXGA85 1280 x 1024 91.15 85.02 1024 x 768 1024 x 768
MAC13 640 x 480 35.00 66.67 1024 x 768 640 x 480
MAC16 832 x 624 49.72 74.55 1024 x 768 832 x 624
MAC19 1024 x 768 60.24 75.02 1024 x 768 1024 x 768
MAC21 1152 x 870 68.59 74.96 1024 x 768 1024 x 768
HP75 1024 x 768 62.94 74.92 1024 x 768 1024 x 768
HP72 1280 x 1024 78.13 72.00 1024 x 768 1024 x 768
SUN66a 1152 x 900 61.85 66.00 1024 x 768 1024 x 768
SUN76a 1152 x 900 71.81 76.63 1024 x 768 1024 x 768
SUN66 1280 x 1024 71.68 66.68 1024 x 768 1024 x 768
SUN76 1280 x 1024 81.13 76.11 1024 x 768 1024 x 768
SGI72 1280 x 1024 76.92 72.30 1024 x 768 1024 x 768
SGI76 1280 x 1024 82.00 76.00 1024 x 768 1024 x 768
IBM60 1280 x 1024 63.42 60.00 1024 x 768 1024 x 768
• When the EXPAND MODE of FEATURES menu is set
to real screen display, by pressing the EXPAND button
on the remote control, it will switch to the screen displaying the picture as its original size (real screen display). In the real screen display, pictures will be blackframed when picture resolution is lower than 1,024 x
768.
Important:
• Some computers may not be compatible with the
projector.
• The projector's maximum resolution is 1,024 x 768
pixels. It may not display correctly for the pictures
of higher resolutions than 1,024 x 768.
• The picture with a SYNC on G (Green) signal
may jitter.
• The picture with a SYNC on G (Green) signal may
be tinged with green.
(H x V) frequency (kHz) frequency (Hz) (H x V) (H x V)
• Set the COMPUTER INPUT in SIGNAL menu to RGB,
when inputting the HDTV signal as RGB signal.
• In case of the SXGA, the right side of the image may
not appear. In this case, adjust the TRACKING in the
SIGNAL menu.
• Set the SIGNAL menu and USER menu as shown
below, when 525p signal is inputted. Set TRACKING first.
HORIZ. POSITION .............................
VERT. POSITION................................
TRACKING ............................. 800
COMPUTER INPUT ............... YC
CLAMP POSITION .............................
CLAMP WIDTH ..................................
HORIZ.PIXELS ....................... 624
VERT.LINES ........................... 456
VERT.SYNC. ........................... ON
HOLD ...................................... ON2 BEGIN -1
139
48
BCR/YPBPR
+9
+3
• If the resolution and frequency of your computer are
not shown on the table, change the resolution of your
computer. You may find the compatible resolution
and frequency.
END 8
EN – 20
Advanced features for presentation
Expand
By pressing the EXPAND button on the remote control, you can magnify the detailed image of the picture.
You can also view the screen displaying the picture as
its original size (native resolution display).
Setting the Expand mode
1. Press the MENU button.
2. Press the $ or % to select the FEATURE menu.
3. Press the ENTER button.
4. Press the { or } button to select EXPAND MODE
or FRAME POSI.
5. Press the $ or % to set the EXPAND MODE or
FRAME POSI.
6. Press the MENU button twice to exit the menu system.
EXPAND MODE
(EXPAND MODE 1)
Normal
FRAME POSI.
(FRAME POSI.
1~4)
12
(EXPAND MODE 2)
Zooming
Zooming
(FRAME POSI. 5)
(EXPAND MODE 3) (EXPAND MODE 4)
Normal
Zooming
Native resolution
display
REAL screen display
• During REAL mode, Press the $ or % buttons
for fine adjustment. The { and } buttons are
not working at this time.
• The expanding rate cannot be changed by pressing either the + or - button.
Picture in Picture (PinP)
One of the special features of this unit is the picturein-picture (PinP) mode. PinP allows you to view different sources at the same time.
Using the PinP mode
1. Press the PinP button on the remote control.
• When the image from VIDEO IN or S-VIDEO
IN terminal is displayed on the screen, the image from COMPUTER IN terminal is displayed
as sub-image.
• When the image from COMPUTER IN terminal
is displayed on the screen, the image from VIDEO
IN or S-VIDEO IN terminal is displayed as subimage.
2. If necessary, select the desired external input source
of the image by using the VIDEO or COMPUTER
button.
To switch Main image and Sub image
3. Press the $ or % buttons on the remote control.
To change frame position
4. Press the { or } buttons on the remote control.
ENGLISH
34
Main
Sub
Using the Expand mode
1. Press the EXPAND button.
• You can magnify different areas of the active pic-
ture by pressing the {, }, $, % button.
• You can change the magnification of the zoomed area
by pressing the + or - button.
2. Press the EXPAND button twice on the remote control.
The normal screen display will appear on the screen.
• Display enlargement does not work with
video input or S-video input.
• In EXPAND mode, you cannot adjust the zoom/focus and the volume.
FRAME POSI.
(FRAME POSI.
1~4)
12
(FRAME POSI. 5)
34
Main
Sub
5. Press the PinP button on the remote control.
The sub image will be disappear.
• Adjusting contrast, brightness, tint or color is not
available in PinP mode.
• In PinP mode, both Main image and Sub image
are displayed with their frames skipped.
• In PinP mode, the audio of the Main image is
outputted.
• In PinP mode, the images may not move smoothly.
Still
How to stop the picture temporarily (still picture).
1. Press the STILL button on the remote control.
The picture will freeze temporarily.
To resume picture activity.
2. Press the STILL button on the remote control
again.
EN – 21
left click
This operates in the same
way as the left button on
the computer mouse.
Advanced features for presentation (continued)
Mouse remote control
By connecting to personal computer through the USB or PS/2 port, you can operate your computer with the
projector remote control.
Projector + computer with USB connector
to USB
REMOTE
MAIN
OI
INPUT SELECT
DIGITAL
ANALOG
AC IN
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
RS-232C
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
VIDEO
L
AUDIO
R
USB 4P
(type B)
USB cable
USB 4P
(type A)
USB
• You can use the mouse remote control function with a computer supporting USB only. If your system is
Windows® 98 or higher, your computer supports USB in standard. If your system is Windows® 95 or lower,
please contact your dealer. If your computer is Macintosh® with USB port, you can use this function.
• When the lamp is turned ON, the computer connected with the USB cable may not work correctly. In this
case, restart the projector and the computer. If possible, you should disconnect the USB cable when the lamp
is turned ON.
to USB port
Projector + computer with PS/2 connector
to RS-232C
terminal
to mouse
(PS/2) port
REMOTE
MAIN
OI
INPUT SELECT
DIGITAL
ANALOG
AC IN
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
USB
RS-232C
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
VIDEO
L
AUDIO
R
RS-232C cable
PS/2 adaptor
D-SUB 9PMini DIN 8P D-SUB 9P Mini DIN 6P
• Turn off computer and the projector before connecting with PS/2 port. When connecting the computer with the
projector when the personal computer is on, the remote control does not work as a mouse. In that case, restart
the personal computer.
• When the projector is connected with USB terminal and RS-232C terminal at the same time, only the terminal which the projector recognizes first will work.
Operation
KEYSTONE
VIDEO
VOLME
ZOOM/
FOCUS
COMPUTER
AUTO
POSITION
mouse pointer
Use to move the cursor on the image,
instead of the computer mouse.
EN – 22
MENU
RIGHT CLICK
LASER
right click
This operates in the same way as the right
button on the computer mouse.
Lamp replacement
The lamp is designed to project the image on the LCD
panels. When the lamp no longer functions, replace it
with a new one.
Caution:
• Do not remove the lamp immediately after using
the projector, you may get burned because of the
high temperature of the lamp.
• When you replace the lamp, press the power button
to power off, then wait for 120 seconds in stand-by
mode to allow the lamp and LCD panels to cool. Turn
off the main switch, unplug the power cord from
the outlet, and wait one hour so that the lamp is
cooled to the touch.
• Do not remove the lamp except for replacement.
Careless treatment can cause injury or fire.
• Do not touch the lamp element directly. It may break
and cause you to injure or burn yourself.
• Be sure not to drop the lamp lid screw into the projector. Also be sure not to insert metal or any flammable objects, it may cause fire or electric shock. If
any objects are inserted, please unplug and contact
your dealer.
• Install the lamp securely, failure may cause a fire.
• If the light bulb part breaks, some small glass frag-
ments may fall out through the small cooling grill,
and sticks to the inside of projector or the lamp box.
When taking the lamp out, make sure to turn over
the projector and hold the handle of the lamp box to
avoid injury from the glass fragments.
• Never shake the lamp or hold it in front of your face
after removing the lamp box. The glass fragments may
fall out and cause injuries to your
eyes and so on.
1. Reverse the projector gently.
(a)
2. Loosen the screws of the lamp lid
(a) using a phillips screwdriver (+).
3. Remove the lamp cover in the
direction of the arrow as indicated.
4. Loosen screws (b) using a phillips
screwdriver (+), and remove them.
(b)
5. Pull up the handle.
6. Hold onto the projector by the
handle as you pull out the lamp.
• Pull the lamp out of the projector
slowly. Should the light bulb be broken, glass fragments will spill out if
the lamp is pulled out too quickly.
• Once the lamp has been removed,
do not spill liquid on it, place it near
flammable objects or where children can touch it. Otherwise, it will cause injury or
fire.
7. Insert the new lamp securely into the projector body
in the right direction.
8. Put the handle back to the holding point.
• Make sure that the handle is locked.
9. Tighten up the screws (b) using a phillips screwdriver (+).
10.
Tighten up the screws of the lamp lid using a phillips
screwdriver (+).
How to reset the operation time meter
Plug in the power cord, switch on the projector, and
reset lamp time by pressing the $, % and POWER
buttons on the contro panel simultaneously.
Important:
• If the 3 buttons was not pressed at the same time,
the lamp time may not be reset.
• Please confirm the TEMP indicator illuminates
about 2 seconds and the lamp time has been
reset.
• The projector will not turn on if you do not secure
the lamp lid.
• You must reset the operation time meter after you
replace the lamp.
• Do not reset the operation time meter unless the
lamp has been replaced.
Caution:
• Do not spill liquid on the lamp or place it near flammable objects or where children can touch it. Otherwise, it could cause injury or fire.
• Be sure that the projector guide is firmly inserted
between the right and left lamp guides.
Interval of the lamp replacement
The interval of the lamp replacement about 2,000 hours
of consecutive use. Replacement span may differ according to operating environment, and may be shorter
than 2,000 hours. Decreases in luminescence and/or
color brightness will indicate that the light source lamp
needs to be replaced. When lamp operation time exceeds 1,500 hours, the indicator will flash alternately
between green and red (while the lamp is in operation;
when the lamp is not in operation, the indicator will
appear red only). When the lamp has been used for
about 1,900 hours, the message “LAMP!!.” will appear
on the screen for one minute everytime the power is
turned on. When the lamp has been used for about 2,000
hours, the projector will automatically shut off for safety
and the power indicator light will be red. The projector
cannot be used until the lamp has been replaced and
operation timer has been reset.
Caution:
• The lamp is fragile. If broken, be careful not to cut
yourself with glass fragments.
• The replacement span of the lamp depends on the
environment. For replacement lamps, please contact your dealer.
The projector automatically shuts off when the
lamp is used up in about 2,000 hours and cannot
be used until the lamp is replaced and the
internal timer is reset.
EN – 23
ENGLISH
Maintenance
Caution:
Be sure to turn off the projector and unplug the power
cord from the wall outlet before you perform any maintenance on the projector.
Cleaning the air-filter
Clean the air-filter frequently (about once a month). If
the filter or ventilation slots become clogged with dirt
or dust, the temperature inside of the projector may
rise and cause some troubles, such as damage of inside parts, and shortening the life of panel.
• When the temperature inside of the projector
rises, the TEMP indicator blinks in red, and the
power will be shut off to be stand-by which LAMP
indicator is turned off.
Filter cover
Cleaning the projector and the ventilation
slots
Use a soft cloth to clean the projector and the ventilation slots. When the slots become dirty, wipe them with
a soft cloth dampened with a diluted mild detergent,
and then wipe them with a dry cloth.
To protect the surface of the projector from fading or
deteriorating:
• Do not spray insecticide on or inside the projector.
• Do not use benzine or thinner to clean it.
• Do not let rubber or plastic materials come into
contact with the projector.
Cleaning the lens
Use a standard lens-cleaning brush or a piece of lens
tissue dampened with lens cleaning fluid. The lens surface is fragile. Use only recommended, nonabrasive
lens-cleaning materials. Do not touch the lens with your
fingers.
1. To remove the filter cover, press the ridged
area gently, push the cover in the direction
of the arrow and lift.
2. Remove the air-filter from the filter cover.
3. Wash the air-filter.
• Use water or a mild
detergent diluted with
water to clean the filter.
Rinse the filter
thoroughly and let it dry
completely.
4. Attach the filter to the cover.
5. Reinstall the filter cover.
Important:
• If the filter is damaged or becomes extremely
dirty, contact your dealer for replacement.
• The power will not turn on if the air-filter cover is
improperly installed.
Filter cover
Filter
Caution:
Be sure to use the projector with an air-filter. If not,
dust may get inside the projector, causing a fire or a
breakdown.
EN – 24
Troubleshooting
The following offers solutions to some of the common problems you may encounter. We suggest that you consult
this chart before contacting your dealer.
PROBLEMS
The power is off.
No picture appears
on the screen.
The image is
turned off.
The image is
distorted.
The image is dark.
The image is
blurred.
The image remains
blurred.
Red, blue or green dots are
viewed on the text of image.
CAUSE
• The air inlet slots, outlet slots or air filter is
clogged with dust or some objects.
POWER indicator does not light up.
• Power cord is unplugged from the outlet.
• Power cord is disconnected from the projector.
• The main switch is turned off.
• The lamp lid is open.
POWER indicator blinks red.
• The projector has been turned on again too soon
after having been turned off.
• When the power switch was turned off while
the fan was running, during or after lamp
operation.
• The room temperature is too high.
(Does the LAMP indicator show an unusual
condition?)
Lamp is no longer working.
•
POWER indicator blinks between red and green.
• The filter cover is not closed.
• When the LAMP indicator or the TEMP
indicator is either on or blinking, the main unit
requires repairs.
Lens is covered by lens cap.
•
• When the LAMP indicator or the TEMP
indicator is either on or blinking, the main unit
requires repairs.
The equipment connected to this projector is not turned on.
•
Hookup is not made correctly with other equipment.
•
The input source is not selected correctly.
•
The INPUT SELECT switch is not selected correctly.
•
(For LVP-X400BU only)
• The air inlet slots, outlet slots or air filter is
clogged with dust or some objects.
(In this case, the TEMP indicator does not light up.)
The projector is not at a right angle to the screen.
•
Brightness, tint and color are not adjusted correctly.
•
The projecting distance is beyond the focused area.
•
Lens is dirty.
•
Screen size exceeds screen size specifications.
•
Brightness and contrast are not adjusted correctly.
•
FINE adjustment is not made correctly.
•
• Tracking is not adjusted.
The projector is not at a right angle to the screen.
•
When you see the stationary image for a long time, it may remain on the screen if you change the
•
image. It is not a breakdown. The blurred image will disappear in a few minutes.
It is normal.
•
•
•
• Insert the power cord into the projector.
•
• Close the lamp lid.
•
• Turn the power switch on and off several times.
•
•
•
•
•
•
•
• Confirm the hookup.
•
•
•
•
•
•
•
•
•
•
• Adjust tracking.
•
POSSIBLE SOLUTIONS
Remove the object.
Plug the power cord into the outlet.
Turn the main switch on.
Wait for the lighting sequence.
Refer to "Indicators" on page 26.
Replace the lamp with a new one.
Close the cover correctly.
Contact your dealer.
Take the lens cap off.
Replace the lamp with a new one.
Turn on the connected equipment.
Select the correct source according to the equipment connected to this projector.
Select the correct position.
Remove the object and turn off the main power
switch. After about 10 minutes, Turn the projector on.
Adjust the angle of the projector to make a right
angle to the screen. See page 12.
Adjust brightness, tint and color correctly.
Adjust the projecting distance. See page 9.
Clean lens.
Reduce screen size to within 40" to 300".
Adjust brightness, contrast.
Make FINE adjustment.
Adjust the angle of the projector to make a
right angle to the screen. See page 12.
ENGLISH
The image is distorted on the screen
and noise is heard.
No sound is heard.
Nothing is displayed on
the PC monitor.
Warm air comes out of
the exhaust vents.
Adjustments cannot be
made.
The cable for connection with other equipment
•
is not plugged securely into the terminal.
The projector is installed too close to other
•
equipment.
Volume is not turned up.
•
Connection to other equipment is not made correctly.
•
The PC monitor is not turned on.
•
This is typical of the LCD projector.
•
The operation is incorrectly made due to noise or
•
interference.
Plug the connecting cable securely into the
•
terminal. See pages 10-11.
Install the projector far away from other equipment.
•
Turn up the volume.
•
• Check connections. See pages 10-11.
Turn on the monitor.
•
Press the reset button on the Terminal board.
•
See page 15.
EN – 25
Indicators
The projector has three indicators each of which shows the working condition of the projector.
The following offers solutions to possible problems. If a problem persists, turn the projector off and consult your
dealer.
Power indicator
LAMP indicator
TEMP indicator
LAMP
TEMP
ZOOM/
FOCUS
VOLUME
COMPUTER
MENU
VIDEO
ENTER
Normal condition
POWER LAMP TEMP
Steady
red
Steady
green
Steady
green
Blinking
green
Steady
green
OffOff
Off
Off
CONDITION Notes
Stand-by
Lamp stand-by (about for 1 minute) The power button cannot be used to switch
The POWER is ON. (Normal condition)
Abnormal condition
POWER LAMP TEMP
Steady
green
Steady
red
Steady
green
Off
Blinking
Blinking
CONDITION POSSIBLE SOLUTIONS
Unusual temperature
• The ventilation slits or air filter is clogged with
red
• The room temperature is too high.
• The filter is dirty.
red
dust or debris.
AUTO
POSITION
MUTE
ON and OFF
• Remove the object from the ventilation
slits.
• Relocate the projector to a cooler place.
• Clean the filter.
Steady
red
Steady
green
green/red
Steady
red
Steady
red
Blinking
green/red
Blinking
green/red
Blinking Blinking
EN – 26
Blinking
green
Blinking
Blinking
red
Steady
red
Steady
or or
Off
Off
Off
Off
OffOff
Steady
The protection circuit is working or the lamp is in an
abnormal condition.
• Wait until the LAMP indicator is turned
off, then press the POWER button.
• If the above operation is not effective,
replace the lamp.
Lamp duration warning. (Lightning duration total
about 1, 500 hours.When the POWER is ON.)
Lamp duration warning. (Lightning duration total
Replace the lamp.
Exchange with a new lamp if the same
problem recurs.
about 1, 500 hours.When the POWER is OFF.)
Lamp duration warning. (Lightning duration total
about 2,000 hours.)
The lamp or filter cover is not closed.
Close the cover correctly.
Abnormal. Contact your dealer.
Specifications
Type
Model
Rated power supply
Rated input
LCD panels
Colors
Projection lens
Light source lamp
Picture size
PC compatibility
Video compatibility
Audio output
Speaker
S-video input
Video input
Audio inputs
Analog RGB input
(mini D-SUB 15P)
Digital RGB input
(DVI-D24P)
PC audio input
Control connector
Outside dimensions
Weight
Length of power cord
Temperature, humidity
(performance guarantee)
LCD projector
LVP-X400BU | LVP-X390U
AC100 ~ 240V, 50 / 60Hz
3.7 A
1.3-inch LCD panel: 3 pieces (for R, G, B)
Pixels 1,024 × 768 = 786,432 pixels
Total 2,359,296 pixels
Active pixel rate: 99.99 % or more (each panel)
16,770,000 colors
F 1.8~2.2 f = 52 ~ 66 mm
250 W NSH
40 ~ 300 inch (aspect ratio 4:3)
Resolution : 640 x 400 - 1024 x 768 + Compressed 1280 x 1024
Sync on Green available
NTSC / NTSC 4.43 / PAL (including PAL-M, N) / SECAM, PAL-60
DVD (Component) / HDTV (1080i) / 720p / (525p)
2 W stereo
6 cm square type (8Ω 2W) × 2
Luminance signal: 1.0 Vp-p 75Ω (negative sync.)
Chroma signal: 0.286 Vp-p 75Ω (burst signal)
1.0 Vp-p 75Ω (negative sync.)
350 mVrms, 10kΩ or more
RGB: 0.7Vp-p 75Ω (negative sync.)
YCBCR: Y:1.0Vp-p (negative sync.) CBCR:0.7Vp-p
HD/CS : TTL level (positive or negative)
VD : TTL level (positive or negative)
DVI Interface (TMDS Single link)
(For LVP-X400BU only)
350 mVrms, 10kΩ or more ø3.5mm stereo mini jack
Serial (Mini DIN 8 pin female connector) RS-232C standards
PS/2 (Mouse function), USB terminal for Mouse, Wired remote terminal
299 × 133 × 367 mm
(width × height × depth)
Approx. 6.7kg
114 inch (2.9m)
+41°F (+5°C) ~ +104°F (+40°C), 30~90%
ENGLISH
Kensington Lock
This projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security
System. Refer to the information that came with the Kensington System for instructions on how to use it to
secure the projector. Please contact to Kensington Technology Group as shown below.
Kensington Technology Group
2855 Campus Drive
San Mateo, CA 94403, U.S.A.
Phone : (650)572-2700 Fax : (650)572-9675
EN – 27
Specifications (continued)
Connectors
RS-232C (Mini DIN 8P)
PIN No. NAME I/O
1 TXD IN
2 RTS IN
3 DTR IN
4 GND –
5 CTS / 5V IN/OUT
6 DCD / CLOCK OUT
7 RXD OUT
8 RI / DATA OUT
Dimensional drawings
(mm)
COMPUTER IN
(DVI-D24P)
(For LVP-X400BU only)
PIN No.
1 DATA 2- 13 –
2 DATA 2+ 14 +5V Power
3 DATA 2 Shield 15 Ground
4 – 16 Hot Plug Detect
5 – 17 DATA 0-
6 DDC Clock 18 DATA 0+
7 DDC Data 19 DATA 0 Shield
8 –
9 DATA 1- 21 –
10 DATA 1+ 22 Clock Shield
11 DATA 1 Shield 23 Clock+
12 – 24 Clock-
SPEC
16 9
8
PIN No.
2
0 –
SPEC
1724
1
COMPUTER IN/OUT
(Mini D-SUB 15P)
PIN No. SPEC
1 R(RED)/CR
2
G(GREEN)/Y
3
B(BLUE)/CB
4 GND
5 GND
6 GND
7 GND
8 GND
9 –
10 GND
11 GND
12 –
13 HD/CS
14 VD
15 –
10
15
6
11
15
98.5
92
25
247
299
What’s included in the box
2 AC power cable 246C383-10
246C383-20
1 Audio/Video cable 246C381-10
1 RGB cable for PC 246C394-10
1 RS-232C cable 246C366-10
1 PS/2 adapter 246C367-10
1
USB cable (For LVP-X400BU only)
246C376-10
367
133
81
87.5
21
51.5
330
1 Remote control 939P843-10
1 Remote control cable 246C393-10
1 User’s manual 871D317-10
1 Quick reference card 857B051-10
2 Battery for remote –
Replacement part
(Option / Not included in the box)
Spare marcury lamp 499B023-10
(VLT-X400LP)
EN – 28
Manufactured by Mitsubishi Electric Corporation
1 Zusho Baba, Nagaokakyo-City, Kyoto Japan
Printed in Japan871D317A10
to RS-232C
terminal
RS-232C cable
D-SUB 9P
L
R
S-VIDEO
VIDEO
AUDIO
MAIN
REMOTE
AC IN
AUDIO OUT
VIDEO 1
IN
VIDEO 2
IN
COMPUTER OUT
OI
AUDIO 2 IN
COMPUTER 2 IN
AUDIO 1 IN
USB
COMPUTER 1 IN
RS-232C
RS-232C adaptor
for Macintosh (optional)
to modem port
or printer port
D-SUB 9PMini DIN 8P
LCD Projector
LVP-X390U
Control projector by using a personal computer
This projector can be controlled by connecting a personal computer with RS-232C terminal.
Functions can be controlled by a personal computer:
• Turn ON or OFF
• Changing input signal
• Menu setting
Connection
Projector + IBM PC or IBM PC compatibles
RS-232C cable
to RS-232C
Projector + Macintosh
terminal
to Com1
Comport
D-SUB 9P
REMOTE
MAIN
OI
COMPUTER 1 IN
COMPUTER 2 IN
COMPUTER OUT
AC IN
AUDIO 1 IN
AUDIO 2 IN
AUDIO OUT
RS-232C
VIDEO 1
VIDEO 2
IN
IN
S-VIDEO
VIDEO
L
AUDIO
R
USB
Important:
• Make sure that your computer and projector are turned off before connection.
• Turn on the projector after the computer is started up.
(If you do not follow this order, the Comport may not function.)
• If your PC (IBM or IBM compatible) is equipped only with a 25-pin serial port connector, a 25-pin serial port
adapter is required. Contact your dealer for details.
1) Interface
PROTOCOL RS-232C
BAUD RATE 9600 [bps]
DATA LENGTH 8 [bits]
PARITY BIT NONE
STOP BIT 1 [bits]
FLOW CONTROL NONE
This projector uses RXD, TXD and GND lines for RS-232C control.
For RS-232C cable,the reverse type cable should be used.
2) Control command diagram
The command is structured by the address code, function code, data code and end code. The length of the
command is different by each function.
Address code Function code Data code End code
HEX 30h 30h Function Data 0Dh
ASCII '0' '0' Function Data
[Address code] 30h 30h (In ASCII code, '0' '0') fixed.
[Function code] A code of each fixed control move.
[Data code] A code of each fixed control data (number) and not always indicated.
[End code] 0Dh (In ASCII code, ' ') fixed.
1
3) Control sequence
(1) Send the command from a personal computer to the projector. (The commands must be sent at least
400ms apart.)
(2) The projector will send a return command 400ms* after it has received an end code. If the command is
not received correctly, the projector will not send the return command.
(3) The personal computer checks the command and confirms if the command which has been sent has been
executed or not.
(4) This projector sends various codes other than the return code. When having a control sequence by RS-
232C, reject other codes from personal computer side.
• * : The sending time of return command maybe delayed depending on the condition (during changing the
input signal, etc.).
[Example] Turn the power ON (' 'is for ASCII code)
Sending commands Status code from Meaning
from the PC etc. projector
30 30 21 0D Command for POWER ON
'0' '0' '!' ' '
30 30 21 0D Command received
'0' '0' '!' ' ' (Command echo back)
4) Operation commands
The operation commands execute the basic operation setting of this projector. It may not operate when changing the signal.
Operation
POWER ON ! 21h
POWER OFF " 22h
INPUT COMPUTER 1 _r1 5Fh 72h 31h
INPUT COMPUTER 2 _r2 5Fh 72h 32h
INPUT VIDEO 1 _v1 5Fh 76h 31h
INPUT VIDEO 2 _v2 5Fh 76h 32h
ASCII HEX
• POWER OFF command will not work for 1 minute after the power is turned on.
• POWER ON command will not work for 1 minute after the power is turned off.
[Example] Set the input signal to COMPUTER 1 (' 'is for ASCII code)
Sending commands Status code from Meaning
from the PC etc. projector
30 30 5F 72 31 0D Command for setting the input
'0' '0' '_' 'r' '1' ' ' signal to COMPUTER 1
30 30 5F 72 31 0D Command received
'0' '0' '_' 'r' '1' ' ' (Command echo back)
2
5) Volume commands
The volume commands execute the volume setting of this projector with the value.
ITEM ASCII HEX VALUE
VOLUME VL 56h 4Ch 00 - 31
How to set the grade
Use ASCII letters code to set the grade for setting data. Please refer to the table below for HEX code.
ASCII '0' '1' '2' '3' '4' '5' '6' '7' '8' '9'
HEX 30h 31h 32h 33h 34h 35h 36h 37h 38h 39h
[Example] Set the volume to 15 (Standard value) (' 'is for ASCII code)
Sending commands Status code from Meaning
from the PC etc. projector
30 30 56 4C 31 35 0D Command for setting the volume
'0' '0' 'V' 'L' '1' '5' ' '
30 30 56 4C 31 35 0D Command received
'0' '0' 'V' 'L' '1' '5' ' ' (Command echo back)
6) Remote commands
Some remote control operations can be done by remote command codes.
Button's name on remote
+ / VOLUME UP r06 72h 30h 36h
– / VOLUME DOWN r07 72h 30h 37h
FOCUS / ZOOM r0f 72h 30h 66h
KEYSTONE r43 72h 34h 33h
EXPAND r02 72h 30h 32h
PIP r04 72h 30h 34h
{ r53 72h 35h 33h
} r2b 72h 32h 62h
$ r4f 72h 34h 66h
% r59 72h 35h 39h
MENU r54 72h 35h 34h
ENTER r10 72h 31h 30h
AUTO POSITION r09 72h 30h 39h
STILL ra4 72h 61h 34h
ASCII HEX
[Example] Display MENU selection bar. (' 'is for ASCII code)
Sending commands Status code from Meaning
from the PC etc. projector
30 30 72 35 34 0D Command as same as MENU button
'0' '0' 'r' '5' '4' ' '
30 30 72 35 34 0D Command received
'0' '0' 'r' '5' '4' ' ' (Command echo back)
3
7) Menu setting commands
The menu setting commands execute the menu setting of this projector. If the personal computer doesn’t send
the commands without attaching the data code, the projector which has received the command replays the
setting data as data code.
ITEM ASCII HEX VALUE
CONTRAST P 50h ±30±30±30 (R from G+Main data+B from G)
BRIGHTNESS Q 51h ±30±30±30 (R from G+Main data+B from G)
COLOR MATRIX (MODE)
COLOR MATRIX (R, G, B)
COLOR MATRIX (Y, C, M)
COLOR MATRIX (SATURATION)
COLOR TEMP. A 41h 1 (Standard), 2 (High), 3 (Low), 4 (User)
SHARPNESS R 52h ±10
TINT S 53h ±10
COLOR T 54h ±10
KEYSTONE KS 4Bh 53h ±00, ±03, ±06, ±09, ±12, ±15
AUTO POWER ON APON 41h 50h 4Fh 4Eh 0 (OFF), 1 (ON)
AUTO POWER OFF APOF 41h 50h 4Fh 46h 00 (Off) , 05, 10, 15, 30, 60
SPLASH SCREEN SS 53h 53h 0 (OFF), 1 (ON)
IMAGE REVERSE IR 49h 52h 0 (OFF), 1 (Mirror), 2 (Invert), 3 (Mirror invert)
MENU POSITION MP 4Dh 50h 0 (Upper left), 1 (Lower right)
EXPAND MODE EX 45h 58h 1 - 4
FRAME POSITION FM 46h 4Dh 1 - 5
VIDEO SIGNAL VS 56h 53h 0 (AUTO), 1 (NTSC), 2 (PAL), 3 (SECAM) ,
ANAMORPHIC SC 53h 43h 0 (OFF), 1 (ON)
LANGUAGE LG 4Ch 47h 0 (
RESET ALL
MEMORY CALL MMC 4Dh 4Dh 43h 0 (AUTO), 1 (USER1), 2 (USER2)
HORIZ. POSITION HP 48h 50h + (increase), – (decrease)
VERT. POSITION VP 56h 50h + (increase), – (decrease)
FINE SYNC. FN 46h 4Eh 00 - 39
TRACKING TRK 54h 52h 4Bh + (increase), – (decrease)
COMPUTER INPUT CIN 67h 49h 4Eh 0 (RGB), 1 (YCBCR/YPBPR)
HOLD HLD 48h 4Ch 44h 0 (AUTO), 1 (ON), 2 (OFF)
HOLD BEGIN HLB 48h 4Ch 42h –01 - –99
HOLD END HLE 48h 4Ch 45h 01 - 99
CLAMP POSITION CLP 43h 4Ch 50h 00 - 63
CLAMP WIDTH CLW 43h 4Ch 57h 01 - 63
HORIZ. PIXELS HPL 48h 50h 4Ch 0000 - 9999
VERT LINES VLN 56h 4Ch 4Eh 0000 - 9999
PLL PLL 50h 4Ch 4Ch 0 (AUTO), 1 (0), 2 (1), 3 (2), 4 (3), 5 (4), 6 (5), 7 (6), 8 (7)
VERT.SYNC VSC 56h 53h 43h 0 (AUTO), 1 (ON), 2 (OFF)
SHUTTER (U) SHU 53h 48h 55h 000 - 383
SHUTTER (L) SHL 53h 48h 4Ch 000 - 383
SHUTTER (LS) SHLS 53h 48h 4Ch 53h 000 - 510
SHUTTER (RS) SHRS 53h 48h 52h 53h 000 - 510
MUTE MUTE 4Dh 55h 54h 45h 0 (MUTE OFF), 1 (MUTE ON)
CMT 43h 4Dh 54h 1, 2, 3 (USER), 4 (OFF)
MRGB 4Dh 52h 47h 42h ±30±30±30 (R+G+B)
MYCM 4Dh 59h 43h 4Dh ±30±30±30 (Y+C+M)
MSAT 4Dh 53h 41h 54h ±05
4 (4.43NTSC), 5 (PAL-M), 6 (PAL-N), 7 (PAL-60)
), 1 (English), 2 (Español), 3 (Deutsch) ,
4 (Frençais), 5 (Italiano), 6 ( )
RSTALL
52h 53h 54h 41h 4Ch 4Ch
How to set the grade
Use ASCII letters code to set the grade for setting data. Please refer to the table below for HEX code.
ASCII '+' '–' '0' '1' '2' '3' '4' '5' '6' '7' '8' '9'
HEX 2Bh 2Dh 30h 31h 32h 33h 34h 35h 36h 37h 38h 39h
[Example 1] Set the AUTO POWER ON to ON.
Sending commands Status code from Meaning
from the PC etc. projector
30 30 41 50 4F 4E 30 0D Command for setting the
'0' '0' 'A' 'P' 'O' 'N' '1' ' ' AUTO POWER ON to ON
30 30 41 50 4F 4E 30 0D Command received
'0' '0' 'A' 'P' 'O' 'N' '1' ' ' (Command echo back)
4
The data code of CONTRAST and BRIGHTNESS is structured by the difference data of R from G, the main data and the difference
data of B from G.
[Example 2] Set the difference data of R from G to +10, the setting main data to 0 and the difference data
of B from to -5.
Sending commands Status code from Meaning
from the PC etc. projector
30 30 50 2B 31 30 2B 30 30 2D 30 35 0D Command for setting the
'0' '0' 'P' '+' '1' '0' '+' '0' '0' '-' '0' '5' ' ' picture control
30 30 50 2B 31 30 2B 30 30 2D 30 35 0D Command received
'0' '0' 'P' '+' '1' '0' '+' '0' '0' '-' '0' '5' ' ' (Command echo back)
[Example 3] The TINT was set to +10 when the setting status was confirmed.
Sending commands Status code from Meaning
from the PC etc. projector
30 30 53 0D Command to confirm
'0' '0' 'S' ' ' setting of TINT
30 30 53 2B 31 30 0D Command (setting of TINT
'0' '0' 'S' '+' '1' '0' ' ' is +10) carried out
8) Reading command diagram
Monitor projector operation status. The power ON, OFF and input terminal settings can be monitored.
ASCII HEX
Function Data (Receive) Function Data (Receive)
POWER ON vP 1 76h 50h 31h
POWER OFF vP 0 76h 50h 30h
INPUT COMPUTER 1 vI r1 76h 49h 72h 31h
INPUT COMPUTER 2 vI r2 76h 49h 72h 32h
INPUT VIDEO 1 vI v1 76h 49h 76h 31h
INPUT VIDEO 2 vI v2 76h 49h 76h 32h
When a personal computer sends the command, data code will not be attached. However, the projector which has
received a command will attach the recent operating status and then send.
[Example ] Input was Video 1 when the operating status of the input terminal was confirmed.
Sending commands Status code from Meaning
from the PC etc. projector
30 30 76 49 OD Command to confirm input
'0' '0' 'v' 'I' ' '
30 30 76 49 76 31 0D Command (Input is Video 1)
'0' '0' 'v' 'I' 'v' '1' ' ' carrired out
5
Loading...
