Mitsubishi Electronics LCD1920NX User Manual

MultiSync LCD1920NX

User’s Manual

Index

Warning, Caution ........................ English-2

Declaration .................................. English-2

Getting Started ............................ English-3

Adjusting the Monitor ..................English-3

Quick Installation.........................English-4

Operations .................................. English-6

OSD Main Menu ......................... English-7

Recommended Use .................... English-9

Specifications ............................ English-11

Features .................................... English-12

Troubleshooting.........................English-13

TCO’95......................................English-14

TCO’99......................................English-15

Canadian Department of Communications Compliance Statement

DOC: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CAN/CSA C22.2 No. 950.

FCC Information

1. Use the attached specified cables with the MultiSync LCD1920NX colour monitor so as not to interfere with radio and television
reception.
(1) Please use the supplied power cord or equivalent to ensure FCC compliance.
(2) Please use the supplied AC Adapter.
(3) Please use the supplied shielded video signal cable.

Use of other cables and adapters may cause interference with radio and television reception.

2.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult your dealer or an experienced radio/TV technician for help.

If necessary, the user should contact the dealer or an experienced radio/television technician for additional suggestions. The user
may find the following booklet, prepared by the Federal Communications Commission, helpful: “How to Identify and Resolve Radio­TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington, D.C., 20402, Stock No.
004-000-00345-4.

English

DECLARATION OF CONFORMITY

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

U.S. Responsible Party: NEC-Mitsubishi Electronics Display of America, Inc.
Address: 1250 North Arlington Heights Road, Suite 500

Itasca, Illinois 60143-1248

Tel. No.: [phone]

Type of Product: Computer Monitor
Equipment Classification: Class B Peripheral
Model: MultiSync LCD1920NX

We hereby declare that the equipment specified above

conforms to the technical standards as specified in the FCC Rules.

Windows is a registered trademark of Microsoft Corporation. NEC is a registered trademark of NEC Corporation. ENERGY STAR
is a U.S. registered trademark. All other brands and product names are trademarks or registered trademarks of their
respective owners.

As an ENERGY STAR® Partner, NEC-Mitsubishi Electronics Display of America has determined that this product meets the
Energy Star guidelenes for energy efficiency. The ENERGY STAR emblem does not represent EPA endorsement of any product
or service.

English-1

WARNING

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE
THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE
PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

CA UTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM

WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE
POWER CORD FROM THE AC OUTLET. DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the operation and maintenance of
this unit has been included. Therefore, it should be read carefully in order to avoid any problems.

Declaration

Declaration of the Manufacturer

We hereby certify that the colour monitor
MultiSync LCD1920NX
is in compliance with

Council Directive 73/23/EEC:

– EN 60950

Council Directive 89/336/EEC:

– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024

and marked with

NEC-Mitsubishi Electric Visual

Systems Corporation

4-13-23, Shibaura,

Minato-Ku

Tokyo 108-0023, Japan

English-2

Getting Started

Congratulations on your purchase of this TFT LCD Monitor.
Please read this section carefully to get instant understanding of this product and its correct operations.

Important! Please keep the original carton and all packing materials for future shipping needs.

Package Contents

Your TFT LCD Monitor package includes the following items:

• 19” TFT LCD Colour Monitor

• Signal cable with 15 pin D-Sub connector

• AC Adapter

• Power cord

• User’s Manual

• CD-ROM

Unique Features

• 8-bit panel, supporting 16.7M true colours.

• High brightness & high contrast, providing more vivid images.

• Built-in both analog and digital interfaces.

• TCO’99 and TCO’95 approved.

• Composite sync and compatibility.

• Five languages in OSD (On Screen Display).

• 9-stage smoothing function.

• Supports 19 sets of factory preset modes and 32 sets of user’s automatically saved modes.

• Wide Viewing Angle.

English

Adjusting the Monitor

Press down on the stand and gently adjust the monitor to a suitable viewing angle (see Figure below). Please note that this
monitor can only be tilted forward to 5 degrees, backward to 20 degrees, and swiveled 90 degrees left/right. To prevent
damage to the monitor, do not press the screen over its tolerant angles.

English-3

Quick Installation

• Make sure the computer is turned off.

• Attach the female end of the power cord (Indication E) to the AC adapter (Indication D), then plug the AC adapter
connector to the power “DC-IN (Indication A)” jack of the LCD monitor.

• When using a power cord, plug the male end into the wall socket.

• Plug one end of the 15 pin D-Sub signal cable (Indication F) in the “D-SUB” video signal connector (Indication B) of

LCD monitor. If you use digital signal, plug one end of the 24 pin DVI-D signal cable (Indication G) in the “DVI-D” video
signal connector (Indication C) of LCD monitor.

• Turn on the computer.

• Turn on the LCD monitor.

• Before your operations of the monitor, please refer to P.6 “Operations” first.

Connector cover

A

B

E

D

A. DC In
B. D-SUB
C. DVI-D

NOTE : When operating this LCD monitor with an AC125-240V power source, please refer to “Recommended Use”

for proper power code selection. Use supplied AC Adapter.

D. AC Adapter
E. Power Cord
F. D-Sub Signal Cable

C

F

English-4
