Mitsubishi Electronics LCD1720M User Manual
Index
Warning .................................................................................................................... 1
Contents ................................................................................................................. 2
Quick Start ............................................................................................................. 3
Controls .................................................................................................................. 8
Recommended Use............................................................................................... 11
Specifications ....................................................................................................... 13
Features ................................................................................................................ 14
Troubleshooting ................................................................................................... 15
References............................................................................................................. 17
Limited Warranty .................................................................................................18
TCO’95 .....................................................................................................................19
TCO’99.....................................................................................................................21
Avertissement ..................................................................................................... 24
Contenu ................................................................................................................. 25
Mise en marche rapide ...................................................................................... 26
Commandes ........................................................................................................... 31
Usage recommandé ............................................................................................ 34
Fiche technique ................................................................................................... 36
Fonctions .............................................................................................................. 37
Dépannage ............................................................................................................ 38
Références ........................................................................................................... 40
Garantie limitée .................................................................................................. 41
TCO’95 ....................................................................................................................42
TCO’99....................................................................................................................44
WARNING
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. ALSO, DO NOT USE
THIS UNIT'S POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS UNLESS THE PRONGS
CAN BE FULLY INSERTED.
REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE COMPONENTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE POWER CORD IS UNPLUGGED FROM
WALL SOCKET. TO FULLY DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT THE POWER
CORD FROM THE AC OUTLET.DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This
symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause
electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit.
This symbol alerts the user that important literature concerning the operation and maintenance of this
unit has been included. Therefore, it should be read carefully in order to avoid any problems.
Canadian Department of Communications Compliance Statement
DOC: This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations
according to
CAN/CSA C22.2 No. 950.
FCC Information
1.
Use the attached specified cables with the
LA-17S02-BK) color monitor so as not to interfere with radio and television reception.
(1)
Please use the supplied power cord or equivalent to ensure FCC compliance.
(2) Please use the supplied shielded video signal cable.
(3) Please use supplied audio cable.
MultiSync LCD1720M™
(LA-17S02 and
2.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy, and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult your dealer or an experienced radio/TV technician for help.
If necessary, the user should contact the dealer or an experienced radio/television technician
for additional suggestions. The user may find the following booklet, prepared by the Federal
Communications Commission, helpful: ”How to Identify and Resolve Radio-TV Interference
Problems.“ This booklet is available from the U.S. Government Printing Office, Washington,
D.C., 20402, Stock No. 004-000-00345-4.
1
Contents
Your new NEC MultiSync® LCD monitor box* should contain the
following:
• MultiSync LCD1720M™ monitor with tilt / swivel base
• Power Cord
• Video Signal Cable
• Audio Cable
• User’s Manual
Power Cord
Video Signal Cable
User’s Manual
* Remember to save your original box and packing material to transport or ship the monitor.
Audio Cable
2
Quick Start
To attach the MultiSync® LCD monitor to your system, follow these instructions:
1. Turn off the power to your computer.
2. For the PC: Connect the 15-pin mini D-SUB of the appropriate signal cable to the
connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync LCD1720M
computer (Figure B.1). Attach the 15-pin mini D-SUB end of the appropriate signal
cable to the MultiSync LCD1720M Macintosh cable adapter (Figure B.1). Tighten all
screws.
NOTE:
To obtain the MultiSync LCD1720M Macintosh cable adapter, call NEC-Mitsubishi
Electronics Display of America, Inc. at (800) 632-4662.
3. Connect the 15-pin mini D-SUB of the video signal cable to the appropriate connector
on the back of the monitor. (Figure C.1).
4. Connect the audio cable to “AUDIO INPUT” on the back of the monitor and the other
end to the “Audio out” terminal of the computer (Figure D.1).
5. Headphones may be connected to the “Headphones” output on the front of the
monitor’s bezel marked “ ” (Figure E.1). While the headphones are connected, the
sound from the speakers will be disabled. Headphones can be purchased from your
local electronics store.
6. Connect one end of the power cord to the MultiSync LCD Series monitor and the other
end to the power outlet (Figure C.1).
NOTE: If you use this monitor at AC126-240V, please refer to Recommended Use
section of this manual for proper selection of AC power cord.
7. Turn on the monitor with the front power switch (Figure F.1) and the computer.
8. To complete the setup of your MultiSync LCD monitor, use the following OSM
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User ’s Manual for a full description of these OSM
controls.
NOTE: For download information on the Windows® 95/98/Me/2000/XP INF file for your MultiSync
LCD1720M monitor, refer to the References section of this User’s Manual.
NOTE: If you have any problems, please refer to the Troubleshooting section of this User’s Manual.
™
Macintosh cable adapter to the
™
controls:
3
Quick Start –
Figure A.1
continuedcontinued
continued
continuedcontinued
Macintosh
Cable
Adapter
(not included)
Note:
Some Macintosh systems do not
require a Macintosh Cable Adapter.
Figure B.1
Figure C.1
Figure D.1
4
Quick Start –continued
Figure E.1
Figure F.1
5
Power Switch
Quick Start –continued
Tilt and swivel
Grasp both sides of the monitor screen with
your hands and adjust the tilt and swivel as
desired (Figure TS.1).
Remove Monitor Stand for Mounting
To prepare the monitor for alternate mounting
purposes:
1.Disconnect all cables.
2.Place monitor face down on a
non-abrasive surface. Insert a
screw driver (or similar object)
into the hole on the bottom of
stand. As shown in the picture,
hold the stand cover in hand and
lift up gradually by the stick and
then remove (Figure R.1).
3.Remove the 4 screws
connecting the monitor to the
stand and lift off the stand
assembly (Figure R.2).
The monitor is now ready for mounting in an alternate manner.
4.Connect the AC cord, signal cable and Audio cable to the back of the
monitor (Figure R.3).
5. Reverse this process to reattach stand.
NOTE: Use only VESA-compatible alternative mounting method.
Figure R.1
Figure TS.1
Figure R.2
Non-abrasive surface
Figure R.3
