Mitsubishi AA175TA03 Specification

TENTATIVE

All information in this technical data sheet is tentative

and subject to change without notice.

17.5” XGA - Wide

TECHNICAL SPECIFICATION

AA175TA03

MITSUBISHI / ADI

MITSUBISHI / ADI Confidential

(1/22)

Date: Jul.4,’03

AA175TA03_02_00

CONTENTS





No. Item Page

-- COVER 1

-- CONTENTS 2
1 OVERVIEW 3
2 ABSOLUTE MAXIMUM RATINGS 4
3 ELECTRICAL CHARACTERISTICS 4, 5, 6
4 INTERFACE PIN CONNECTION 7, 8
5 INTERFACE TIMING 9, 10, 11, 12, 13
6 BLOCK DIAGRAM 14
7 MECHANICAL SPECIFICATION 15, 16,
8 OPTICAL CHARACTERISTICS 17, 18
9 RELIABILITY TEST CONDITION 19

10 HANDLING PRECAUTIONS FOR TFT-LCD MODULE 20, 21, 22

MITSUBISHI / ADI Confidential

(2/22)

AA175TA03_02_00

1. OVERVIEW

AA175TA03 is 17.5” color TFT-LCD (Thin Film Transistor Liquid Crystal Display) modules
composed of LCD panel, driver ICs, control circuit, and backlight unit.

By applying 8 bit digital data, 1280 × 768, 16.7M-color images are displayed on the 17.5” diagonal
screen. Input power voltages are 5.0 V for LCD driving.

The type of data and control signals are digital, and 1 pixel data are transmitted per Typ. 65.0
MHz clock cycle.
General specifications are summarized in the following table:

ITEM SPECIFICATION

Display Area (mm)
Number of Dots

Pixel Pitch (mm)
Color Pixel Arrangement RGB vertical stripe
Display Mode Normally white TN
Number of Color
Brightness 400 cd/m2
Viewing Angle -75 ~ 75° (H), -60~50° (V)
Surface Treatment Anti-glare and hard-coating 3H
Electrical Interface LVDS 1ch
Optimum Viewing Angle(Contrast ratio) 6 o’clock
Module Size (mm)
Module Mass (g) 1700
Backlight Unit CCFL, 4-tubes, edge-light

380.2 (H) × 228.1 (V)
(17.5-inch diagonal)

1280 × 3 (H) × 768 (V)

0.297 (H) × 0.297 (V)

16.7 M(8 bits/color）

404.0 (W) × 258.0 (H) × 16.2 (D)

Sign"( )" is preliminary value. Characteristic value without any note is typical value.

The LCD product described in this specification is designed and manufactured for the standard
use in OA equipment and consumer products, such as computers, communication equipment,
industrial robots, AV equipment and so on.
Do not use the LCD product for the equipment that require the extreme high level of reliability,
such as aerospace applications, submarine cables, nuclear power control systems and medical or
other equipment for life support.
ADI assumes no responsibility for any damage resulting from the use of the LCD product in
disregard of the conditions and handling precautions in this specification.
If customers intend to use the LCD product for the above items or other no standard items,
please contact our sales persons in advance.

MITSUBISHI / ADI Confidential

(3/22)

AA175TA03_02_00

2. ABSOLUTE MAXIMUM RATINGS

Logic Signal

Data: RGB DATA, DCLK, HD, VD, DENA

ITEM SYMBOL MIN. MAX. UNIT

Power Supply Voltage for LCD VCC 0 7.0 V
Logic Input Voltage VI -0.3 6.0 V
Lamp Voltage VL 0 2500 Vrms
Lamp Current IL 0 10.0 mArms
Lamp Frequency FL 0 100 kHz
Operation Temperature *) T
Storage Temperature *) T

op

stg

0 50 °C

-20 60 °C

[Note]

*) Top,Tstg ≤ 40°C : 90% RH max. without condensation

Top,Tstg > 40°C : Absolute humidity shall be less than the value of 90% RH at 40°C without

condensation.

3. ELECTRICAL CHARACTERISTICS

(1) TFT- LCD Ambient Temperature : Ta =

25°C

ITEM SYMBOL MIN. TYP. MAX. UNIT Remarks

Power Supply Voltages for LCD VCC 4.5 5.0 5.5 V *1)
Power Supply Currents for LCD ICC -- 450 960 mA *2)
Permissive Input Ripple Voltage VRP -- -- 100 mVp-p VCC = +5.0 V

*1) Power and signals sequence:

t1 ≤ 10 ms 1 s ≤ t5
100 ms < t2 200 ms ≤ t6
0 < t3 ≤ 1 s 0 ≤ t7
0 < t4 ≤ 50 ms

LCD Power Supply

0.5V

Backlight Power Supply

4.5V

t1

t2

t6 t7

VCC

data

VL

t3

t4

4.5V

2.2V

0.5V

t5

MITSUBISHI / ADI Confidential

(4/22)

AA175TA03_02_00

VCC-dip conditions:

td

VCC

1) When VCCMIN ≥ 3.6 V, td ≤ 10 ms

2) When VCCMIN < 3.6 V
VCC-dip conditions should also follow the power and signals sequence.

4.5V

VCCMIN

*2) Typical current condition:

256- gray- bar-pattern
768 line mode
VCC = 5.0 V, fH = 46.8 kHz, fV = 60 Hz, f

= 15.3 MHz

CLK

(2) Backlight Ta = 25°C

ITEM SYMBOL MIN. TYP. MAX. UNIT Remarks

Lamp Voltage VL -- 750 -- Vrms IL = 7.0 mArms
Lamp Current IL 5.0 7.0 8.0 mArms *1),*5)
Lamp Frequency FL 40 -- 70 kHz *2)

1700 -- -- Vrms Ta = 0°C

Starting Lamp Voltage VS

1500 --

--

Vrms Ta = 25°C

*3), *4)

Lamp Life Time LT -- 35000 -- h

IL = 7.0 mArms,

Continuous

Operation

*1) Lamp Current measurement method (The current meter is inserted in low voltage line.)

A

A

Power

A

A

Inverter

Supply

LCD

Module

CTL
CTL

CTH

CTH

CTL

CTL
CTH

CTH

*2) Lamp frequency of inverter may produce interference with horizontal synchronous frequency,

and this may cause horizontal beat on the display. Therefore, please adjust lamp frequency,
and keep inverter as far from module as possible or use electronic shielding between inverter
and module to avoid the interference.

*3) Lamp life time is defined as the time either when the brightness becomes 50% of the initial

value, or when the starting lamp voltage does not meet the value specified in this table.

*4) The life time of the backlight depends on the ambient temperature. The life time will decrease

under low/high temperature.

MITSUBISHI / ADI Confidential

(5/22)

AA175TA03_02_00

*5) Please use the inverter which has symmetrical current wave form as follows,

I
I

The degree of unbalance: less than 10%
The ratio of wave height: less than 2±10%

PH

PL

IPH: High side peak

IPL: Low side peak

The degree of unbalance = |IPH - IPL| / Irms
The ratio of wave height = IPH(or IPL) / Irms

100(%)

×

CURRENT WAVE FORM

MITSUBISHI / ADI Confidential

(6/22)

AA175TA03_02_00

4. INTERFACE PIN CONNECTION

(1) CN 1(Data Signal and Power Supply)

Used Connector: DF14H -20P -1.25H (HIROSE)

Pin No. Symbol Function

1 VDD Power supply
2 VDD Power supply
3 VSS Ground
4 VSS Ground
5 RA- Negative LVDS, R0-R5, G0
6 RA+ Positive LVDS, R0-R5, G0
7 VSS Ground
8 RB- Negative LVDS, G1-G5, B0-B1

9 RB+ Positive LVDS, G1-G5, B0-B1
10 VSS Ground
11 RC- Negative LVDS, B2-B5, HD, VD, DE
12 RC+ Positive LVDS, B2-B5, HD, VD, DE
13 VSS Ground
14 RCLK- Negative LVDS, CLK
15 RCLK+ Positive LVDS, CLK
16 VSS Ground
17 RD- Negative LVDS, R6-R7, G6-G7, B6-B7
18 RD+ Positive LVDS, R6-R7, G6-G7, B6-B7
19 GND Ground
20 CMMD1a NCM Mode *) (See: Page 8)

MITSUBISHI / ADI Confidential

(7/22)

AA175TA03_02_00

(2) CN 2

CN1

CN2

MODE

LLL

native

LHnative

HLnative

HHnative

HLL

native

LHnative

HLsRGB

HHTV

Ω

Used Connector: IL-FHR-B10S-HF (JAE)

Pin No. Symbol Function

1 CMMD1b NCM Mode *)
2 CMMD2 NCM Mode *)
3 OVMD FFD ON/OFF (H or Open:ON / L:OFF)
4 SCMD
5 GND
6 TEST This pin should be open. (For our internal use only.)
7 TEST This pin should be open. (For our internal use only.)
8 TEST This pin should be open. (For our internal use only.)
9 TEST This pin should be open. (For our internal use only.)

10 TEST This pin should be open. (For our internal use only.)

*) NCM Setting Table

CMMD1a CMMD1b CMMD2

(3) CN 3, 4(Backlight)

Backlight-side connector: BHSR-02VS-1 (JST)
Inverter-side connector: SM02B-BHSS-1-TB (JST)

Pin No. Symbol Function

Scan Direction setting (H or Open :Normal / L :Reverse）

CN1-CMMD1a

0

CN2-CMMD1b

CN2-CMMD2

Pull-up Resistor
(Inside of ASIC)

CMMD1

CMMD2

(4) CN 5, 6(Backlight)

Backlight-side connector: BHR-02VS-1 (JST)
Inverter-side connector: SM02(4.0)B-BHS-1-TB (JST)

Pin No. Symbol Function

[Note] VBLH-VBLL = VL

MITSUBISHI / ADI Confidential

1, 2 CTH

1, 2 CTL

VBLH（High Voltage）

VBLL（Low Voltage）

(8/22)

AA175TA03_02_00

5. INTERFACE TIMING

(1) Timing Specifications

ITEM SYMBOL MIN. TYP. MAX. UNIT

Frequency f

DCLK 
*1) *4)

Period t
Low Width t
High Width t
Horizontal Period(Low)
Horizontal Front Porch

DENA

*3)

Horizontal Back Porch t
Vertical Period(Low) tVA
Vertical Front Porch t
Vertical Back Porch t

Frequency f

HD

*2)*4)

Period t
Low Width t
Frequency f

VD *2)

Period t
Low Width t

CLK

CLK

WCL

WCH

t

HA

t

HFP

HBP

VFP

VBP

H

H

WHL

V

V

WVL

-- 65 72

13.9 15.3 -­5 -- -­5 -- --

1280 1280 1280

32 48 -­56 66 --

768 768 768

2 4 -­4 8 --

-- 46.8 52.6

19.0 21.4 -­4 8 --

55 60 68

14.9 16.7 18.2
2 4 --

[Note]

*1) DATA is latched at fall edge of DCLK in this specification.
*2) Polarities of HD and VD are negative in this specification.
*3) DENA (Data Enable) should always be positive polarity as shown in the timing

specification.

*4) DCLK should appear during all invalid period, and HD should appear during invalid period

of frame cycle.

*5) HD low width , DENA horizontal front poach, and DENA horizontal back poach should be

even value.

*6) LVDS timing follows the timing specifications of LVDS receiver IC:THC63LVD824 (THine).

MHz

ns
ns
ns

t

CLK

t

CLK

t

CLK

tH
t

H

t

H

kHz

µs

t

CLK

Hz
ms

t

H

MITSUBISHI / ADI Confidential

(9/22)

AA175TA03_02_00

(2) Timing Chart

12767

768

3

t

VD

DENA

HD

t

DCLK

1

2

1280

3

t

t

t

t

tH=1/f
First Data

Last Data

DENA

HD

a. Horizontal Timing Chart

DATA

Invalid Data Invalid Data

(R,G,B)

HFP

b. Vertical Timing Chart

LINE DATA

Invalid Data Invalid Data

WHL

HBP

1279

HA

H

t

VFP

t

WVL

VBP

VA

tV=1/f

V

MITSUBISHI / ADI Confidential

(10/22)

AA175TA03_02_00

previous cycle(2nd data : EVEN data)

current cycle(1st data : ODD data)

LVDS-Rx CMOS output pin

LVDS-Rx input DATA

(3) LVDS Mapping

RCLK1

RA1+/- R13 R12 G22 R27 R26 R25 R24 R23 R22 G12 R17 R16 R15 R14 R13 R12 G12

DATA R1 R0 G0 R5 R4 R3 R2 R1 R0 G0 R5 R4 R3 R2 R1 R0 G0

RB1+/- G14 G13 B23 B22 G27 G26 G25 G24 G23 B13 B12 G17 G16 G15 G14 G13 B13

DATA G2 G1 B1 B0 G5 G4 G3 G2 G1 B1 B0 G5 G4 G3 G2 G1 B1

RC1+/- B15 B14 DE

DATA B3 B2 DE VD HD B5 B4 B3 B2 DENA VD HD B5 B4 B3 B2 DE

Vsync Hsync

B27 B26 B25 B24 DE

Vsync Hsync

B17 B16 B15 B14 DE

RD1+/- R11 R10 x B21 B20 G21 G20 R21 R20 x B11 B10 G11 G10 R11 R10 x

DATA R7 R6 reserveB7 B6 G7 G6 R7 R6 reserveB7 B6 G7 G6 R7 R6 reserve

MITSUBISHI / ADI Confidential

(11/22)

AA175TA03_02_00




(4) Color Data Assignment

COLOR R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0




BASIC

COLOR









RED








GREEN








BLUE





INPUT

DATA

BLACK
RED(255)
GREEN(255)
BLUE(255)
CYAN
MAGENTA
YELLOW
WHITE
RED(0)
RED(1)
RED(2)

RED(254)
RED(255)
GREEN(0)
GREEN(1)
GREEN(2)

GREEN(254)
GREEN(255)
BLUE(0)
BLUE(1)
BLUE(2)

BLUE(254)
BLUE(255)

MSB

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1

R DATA G DATA B DATA

LSB MSB

LSB MSB

LSB

[Note]

*1) Definition of gray scale

Color (n) --- n indicates gray scale level.

Higher n means brighter level.

*2) Data

1:High, 0: Low

MITSUBISHI / ADI Confidential

(12/22)

AA175TA03_02_00

(5) Data Mapping

D( 1, 1) D( 2, 1) --- D( X, 1) --- D(1279, 1) D(1280, 1)
D( 1, 2) D( 2, 2) --- D( X, 2) --- D(1279, 2) D(1280, 2)

¦ ¦ + ¦ + ¦ ¦

D( 1, Y) D( 2, Y) --- D( X, Y) --- D(1279, Y) D(1280, Y)

¦ ¦ + ¦ + ¦ ¦
D( 1,767) D( 2,767) --- D( X,767) --- D(1279,767) D(1280,767)
D( 1,768) D( 2,768) --- D( X,768) --- D(1279,768) D(1280,768)

MITSUBISHI / ADI Confidential

(13/22)

AA175TA03_02_00

6. BLOCK DIAGRAM

TFT-LCD Module

ｃ

CN2
CN1

LVDS

Receiver

Timing

Controller

CN3

Backlight

Source Driver

CN5

Voltage Supply
for Gray Levels

and Vcom

DC/DC

Converter

BACKLIGHT

Gate Driver

CCFL

LCD Panel

1280 X 3 X 768

Backlight

CN3, 4

1
2

1
2

CN4
CN6

MITSUBISHI / ADI Confidential

(14/22)

CN5, 6

AA175TA03_02_00

7. MECHANICAL SPECIFICATIONS

(1) Front side

MITSUBISHI / ADI Confidential

(15/22)

AA175TA03_02_00

(2) Rearside

[Note]
We recommend you referring to the detailed drawing for your design.
Please contact our company sales representative when you need the detailed drawing.

MITSUBISHI / ADI Confidential

(16/22)

AA175TA03_02_00

8. OPTICAL CHARACTERISTICS











Ta = 25°C, VCC = 5.0 V, Input Signals: Typ. Values shown in Section 5

ITEM SYMBOL CONDITION MIN. TYP. MAX. UNIT Remarks

Contrast Ratio CR
Luminance Normal Lw
Uniformity

∆Lw θ = φ = 0°

Response Time tr

(White/Black) tf

Response Time (Gray) trg,tfg

Viewing Horizontal

Angle Vertical

φ CR ≥ 10
θ

θ = φ = 0°
θ = φ = 0°

θ = φ = 0°
θ = φ = 0°

θ = φ = 0°

--

350 500 -­320 400 --

-- -- 30

-- 6 --

-- 19 --

-- 10 15 ms *3)*5)

--

-75∼75

-60∼50

--

--

Image Sticking tis 2 h -- -- 2 s

Red Rx (0.611) (0.641) (0.671)

Color Green Gx
Coordinates

[Note]

Blue Bx (0.113) (0.143) (0.173)

White Wx (0.283) (0.313) (0.343)

Ry (0.305) (0.335) (0.365)

(0.253) (0.283) (0.313)

Gy

θ = φ = 0°

(0.558) (0.588) (0.618)

By (0.028) (0.058) (0.088)

Wy

(0.299) (0.329) (0.359)

These items are measured using CS1000(MINOLTA) for color coordinates, EZContrast(ELDIM) for
viewing angle, and CS1000 or BM-5A(TOPCON) for others under the dark room condition (no
ambient light) after more than 45 minutes from turning on the lamp unless noted.

--

cd/m2

%
ms
ms

°
°

--

*1)*2)*3)

*2)*3)
*2)*3)
*3)*4)
*3)*4)

*3)
*3)

*6)

*3),*7)

Condition: IL = 7.0 mArms, Inverter frequency: 45 kHz
*1) Definition of Contrast Ratio

CR=ON (White) Luminance / OFF(Black) Luminance

*2) Definition of Contrast ratio, Luminance and Luminance Uniformity

∆Lw=[Lw(MAX)/Lw(MIN)-1] × 100
Measure Contrast ratio and White Luminance on the below 5 points

(1,1)

192

384

576

326 640 960

1

5

3

2

4

(1280,768)

MEASUREMENT POINT

MITSUBISHI / ADI Confidential

(17/22)

AA175TA03_02_00

*3) Definition of Viewing Angle( θ , φ)

tfg

trg

Gray Level)

Cols 638-642

*4) Definition of Response Time (Black/White)

White

Luminance

90%90%

10%10% Black

tr

tf

*5) Definition of Response Time (Gray)

Luminance

(64〜224th Gray Level)

10%

90% 90%

(32~192th

10%

*6) Image Sticking

Continuously display the test pattern shown in the figure below for two-hours. Then display a
completely white screen. The previous image shall not persist more than two seconds at 25°C.

White

Area

Rows 382-386

*7) NCM Mode is native.

MITSUBISHI / ADI Confidential

Black

Lines

TEST PATTERN FOR IMAGE STICKING TEST

(18/22)

AA175TA03_02_00

9. RELIABILITY TEST CONDITION

(1) Temperature and Humidity

TEST ITEM CONDITIONS

HIGH TEMPERATURE 40°C, 90% RH, 240h

HIGH HUMIDITY OPERATION (No condensation)

HIGH TEMPERATURE OPERATION 50°C, 240 h

LOW TEMPERATURE OPERATION 0°C, 240 h

THERMAL SHOCK

(Non-Operation)

HIGH TEMPERATURE STORAGE 60°C, 240 h

LOW TEMPERATURE STORAGE -20°C, 240 h

(2) Shock & Vibration

ITEM CONDITIONS



BETWEEN -20°C (1h) and 60°C(1h),

5 CYCLES

SHOCK Waveform: half sinusoidal wave, 2 ms

(NON-OPERATION) Number of shocks: one shock input in each direction of three mutually

Perpendicular axes for a total of six shock inputs

Waveform: sinusoidal

VIBRATION Frequency range: 5 to 500 Hz

(NON-OPERATION) Frequency sweep rate: 1.0 octave /min

Duration: one sweep from 5 to 500 Hz in each of three mutually
Perpendicular axis(each x,y,z axis: 1 hour, total 3 hours)

Shock level: 980 m/s2 (100 G）

Vibration level: 9.8 m/s2 (1.0 G）zero to peak

(3) Judgment standard

The judgment of the above tests should be made as follow:

Pass: Normal display image with no obvious non-uniformity and no line defect.

Partial transformation of the module parts should be ignored.

Fail: No display image, obvious non-uniformity, or line defects.



MITSUBISHI / ADI Confidential

(19/22)

AA175TA03_02_00

10. HANDLING PRECAUTIONS FOR TFT-LCD MODULE

Please pay attention to the followings in handling TFT-LCD products;

(1) ASSEMBLY PRECAUTION

a. Please mount the LCD module by using mounting hole with a screw clamping torque less than

0.5 Nm. Please do not bend or wrench the LCD module in assembling. Please do not drop, bend
or twist the LCD module in handling. Please mount the invertor circuit board by using



mounting hole of rear side with a screw clamping torque less than 0.5 Nm.

b. Please design display housing in accordance with the following guide lines.

(a) Housing case must be designed carefully so as not to put stresses on LCD all sides and not to

wrench module. The stresses may cause non-uniformity even if there is no non-uniformity
statically.

(b) Keep sufficient clearance between LCD module back surface and housing when the LCD

module is mounted. Approximately 1.0mm of the clearance in the design is recommended
taking into account the tolerance of LCD module thickness and mounting structure height on
the housing.

(c) When some parts, such as, FPC cable and ferrite plate, are installed underneath the LCD

module, still sufficient clearance is required, such as 0.5mm. This clearance is, especially, to
be reconsidered when the additional parts are implemented for EMI countermeasure.

(d) Design the inverter location and connector position carefully so as not to give stress to lamp

cable, or not to interface the LCD module by the lamp cable.

(e) Keep sufficient clearance between LCD module and the others parts, such as inverter and

speaker so as not to interface the LCD module. Approximately 1.0mm of the clearance in the
design is recommended.

c. Please do not push or scratch LCD panel surface with anything hard. And do not soil LCD panel

surface by touching with bare hands. (Polarizer film, surface of LCD panel is easy to be flawed.)

d. Please do not press any parts on the rear side such as source TCP, gate TCP, control circuit

board and FPCs during handling LCD module. If pressing rear part is unavoidable, handle the

LCD module with care not to damage them.
e. Please wipe off LCD panel surface with absorbent cotton or soft cloth in case of it being soiled.
f. Please wipe off drops of adhesives like saliva and water on LCD panel surface immediately. They

might damage to cause panel surface variation and color change.
g. Please do not take a LCD module to pieces and reconstruct it. Resolving and reconstructing

modules may cause them not to work well.
h. Please do not touch metal frames with bare hands and soiled gloves. A color change of the metal

frames can happen during a long preservation of soiled LCD modules.
i. Please pay attention to handling lead wire of backlight so that it is not tugged in connecting with

inverter.

MITSUBISHI / ADI Confidential

(20/22)

AA175TA03_02_00

j. Please connect the metal frame of LCD module to GND in order to minimize the effect of external

noise and EMI.
k. Be sure to connect the cables and the connectors correctly.

(2) OPERATING PRECAUTIONS

a. Please be sure to turn off the power supply before connecting and disconnecting signal input

cable.
b. Please do not change variable resistance settings in LCD module. They are adjusted to the most

suitable value. If they are changed, it might happen LCD does not satisfy the characteristics

specification.
c. LCD backlight takes longer time to become stable of radiation characteristics in low temperature

than in room temperature.
d. The interface signal speed is very high. Please pay attention to transmission line design and

other high speed signal precautions to satisfy signal specification.
e. A condensation might happen on the surface and inside of LCD module in case of sudden change

of ambient temperature.
f. Please pay attention not to display the same pattern for very long time. Image might stick on

LCD. Even if image sticking happens, it may disappear as the operation time proceeds.
g. Please obey the same safe instructions as ones being prepared for ordinary electronic products.

(3) PRECAUTIONS WITH ELECTROSTATICS

a. This LCD module use CMOS-IC on circuit board and TFT-LCD panel, and so it is easy to be

affected by electrostatics. Please be careful with electrostatics by the way of your body

connecting to the ground and so on.
b. Please remove protection film very slowly from the surface of LCD module to prevent from

electrostatics occurrence.

(4) STORAGE PRECAUTIONS

a. Please do not leave the LCDs in the environment of high humidity and high temperature such

as 60°C90% RH.
b. Please do not leave the LCDs in the environment of low temperature; below -20°C.

(5) SAFETY PRECAUTIONS

a. When you waste damaged or unnecessary LCDs, it is recommended to crush LCDs into pieces

MITSUBISHI / ADI Confidential

(21/22)

AA175TA03_02_00

and wash them off with solvents such as acetone and ethanol, which should later be burned.
b. If any liquid leaks out of a damaged glass cell and comes in contact with the hands, wash off

thoroughly with soap and water.
c. Be sure to turn off the power supply when inserting or disconnecting the cable.
d. Inverter should be designed carefully so as not to keep working in case of detecting over current

or open circuit on the lamp.

(6) OTHERS

a. A strong incident light into LCD panel might cause display characteristics changing inferior

because of polarizer film, color filter, and other materials becoming inferior. Please do not

expose LCD module direct sunlight and strong UV rays.
b. Please pay attention to a panel side of LCD module not to contact with other materials in

preserving it alone.
c. For the packaging box, please pay attention to the followings;

(a) Packaging box and inner case for LCD are designed to protect the LCDs from the damage or

scratching during transportation. Please do not open except picking LCDs up from the box.

(b) Please do not pile them up more than 6 boxes. (They are not designed so.) And please do not

turn over.

(c) Please handle packaging box with care not to give them sudden shock and vibrations. And

also please do not throw them up.

(d) Packaging box and inner case for LCDs are made of cardboard. So please pay attention not

to get them wet. (Such like keeping them in high humidity or wet place can occur getting
them wet.)

MITSUBISHI / ADI Confidential

(22/22)

AA175TA03_02_00
