TECHNICAL SPECIFICATION

AA121TB01

MITSUBIS HI ELECTRI C Corp.

Date: Dec.3,’07

MITSUBISHI

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Confidential (1/25) AA121TB01_02_00

www.panelook.com

Global LCD Panel Exchange Center



CONTENTS



No. Item Page

-- COVER 1

-- CONTENTS 2
1 APPLICATION 3

www.panelook.com

2 OVERVIEW 4
3 ABSOLUTE MAXIMUM RATINGS 5
4 ELECTRICAL CHARACTERIST ICS 5, 6, 7
5 INTERFACE PIN CONNECTIO N 8, 9
6 INTERFACE TIMING 10, 11, 12, 13, 14
7 BLOCK DIAGRAM 15
8 MECHANICAL SPECIFICATION 16, 17
9 OPTICAL CHARACT ERISTICS 18, 19, 20

10 RELIABILITY TEST CO NDITION 21
11 OTHER FEATURE 22
12 HANDLING PRECAUTIONS FOR TFT-LCD MODULE 23, 24, 25

MITSUBISHI

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Confidential (2/25) AA121TB01_02_00

www.panelook.com

Global LCD Panel Exchange Center





1. APPLICATION

This specification applies to color TFT-LCD module, AA121TB01.

These specification papers are the proprietary product of Mitsubishi Electric Corporation
(“MITSUBISHI) and include materials protected under copyright of MITSUBISHI. No part of this
document may be reproduced in any form or by any means without the express written per mission
of MITSUBISHI.

MITSUBISHI does not assume any liability for infringement of patents, copyrights or other
intellectual property rights of third parties by or arising from use of a product specified in this
document. No license, express, implied or otherwise, is granted under any patents, copyrights or
other intellectual property rights of MITSUBISHI or of others.

MITSUBISHI classifies the usage of the TFT-LCD module as follows. Please confirm the usage
before using the product.

(1) Standard Usage

Computers, office equipment, factory automation equipment, test and measurement
equipment, communications, transportation equipment(automobiles, ships, trains, etc.),
provided, however, that operation is not influenced by TFT-LCD directly.

(2) Special Usage

Medical equipment, safety equipment, transportation equipment, p rovided, however, that
TFT-LCD is necessary to its operation.

(3) Specific Usage

Cockpit Equipment, military systems, aerospace equipment, nuclear reactor control
systems, life support systems and any other equipment. MITSUBISHI should make a
contract that stipulate apportionment of responsibilities between MITSUBISHI and our
customer.

www.panelook.com

The product specified in this document is designed for “Standard Usage” unless otherwise specified
in this document. If customers intend to use the product for applications other than those specified
for “Standard Usage”, they should first contact MITSUBIS HI sales representative for it's intended
use in writing.

MITSUBISHI has been making continuous effort to improve the reliability of its products.
Customers should implement sufficient reliability design of their application equipments such as
redundant system design, fail-safe functions, anti-failure features.

MITSUBISHI assumes no responsibility for any damage resulting from the use of the product that
does not comply with the instructions and the precautions specified in this document.

Please contact and consult a MITSUBISHI sales representative for any questions regarding this
product.

MITSUBISHI

Confidential (3/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



2. OVERVIEW

AA121TB01 is 12.1” color TFT-LCD (Thin Film Transistor Liquid Crystal Display) module
composed of LCD panel, driver ICs, control circuit, and backlight unit.

By applyi ng 6 bi t or 8 bit dig ital data, 1280 × 800, 262k -colo r or 16.7M -col or imag es are di splayed
on the 12.1” diagonal screen. Input power voltage is 3.3V for LCD driving.
The type of data and control sig nals are digital an d transmitted via LVDS i nterface per Ty p. 71
MHz clock cycle.

Inverter for backlight is not included in this module. General specifications are summarized in the
following table:

ITEM SPECIFICATION
Display Area (mm)
Number of Dots 1280 × 3 (H) × 800 (V)

www.panelook.com

261.12 (H) × 163.2 (V)
(12.1-inch diagonal)

Pixel Pitch (mm) 0.204 (H) × 0.204 (V)
Colo r Pixel Arrangem e n t RGB vertical stripe
Disp lay Mode Normally white TN
Number of Color 262k(6 bit/color), 16.7M(8 bit/color)
Luminance (cd/m2) (400)
Wide View ing Angle Technology Optical Compensation F ilm
Viewing Angle (CR ≥ 10) −80∼80°(H), −60∼80°(V)
Surface Treatment Anti-glare and hard-coating 3H
Electrical Interface LVDS (6 bit/8 bit)
Optimum Viewing Angle (Contrast ratio) 6 o’clock
Module Size (mm) 283.0 (W) × 185.1 (H) × 11.5 (D)
Module Mass (g) (800)
Backlight Unit CCFL, 2-tube s, edge-light, replaceab le

Sign “( )”represents preliminary value. Characteristic value without any note is typical value.

MITSUBISHI

Confidential (4/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



3. ABSOLUTE MAXIMUM RATINGS

ITEM SYMBOL MIN. MAX UNIT
Power Supply Volta ge fo r LCD VCC 0 4.0 V
Logic Input Voltage VI −0.3 VCC+0.3 V
Lamp Voltage VL 0 2000 Vrms
Lamp Current IL 0 18 mArms
Lamp Frequency FL -- 80 kHz

Operation Temperature(Panel)
Operation Temperature(Ambient)

Storage Temperature

[Note]

1) Measured at the center of active area and at the center of panel back surface

2) Top,Tstg ≤ 40°C : 90%RH max. without condensation
Top,Tstg > 40°C : Absolute humidity shall be less than t he value of 90%RH at 40°C without

condensation.

www.panelook.com

Note 1,2)

Note 2)

Note 2)

T

T

op(Panel)

op(Ambient)

T

stg

−20 70 °C

−20 70 °C

−20 80 °C

4. ELECTRICAL CHARACTERISTICS

(1) TFT-LCD

Ambient temperature: Ta = 25℃

ITEM SYMBOL MIN. TYP. MAX. UNIT Remarks

Power Supp l y Vo ltages for LCD VCC 3.0 3.3 3.6 V *1)
Power Supply Currents for LCD ICC -- (550) (950) mA *2)
Permissive Input Ripple Voltage VRP -- -- 100 mVp-p VCC = +3.3V

Logic Input Voltage

*1) Power and signals sequence:

t1 ≤ 10 ms 200 ms ≤ t4
0 < t2 ≤ 50 ms 200 ms ≤ t5
0 < t3 ≤ 50 ms 0 ≤ t6

LCD Power Supply

Logic Signal

㩷

High VIH 2.0 -- VCC+0.3 V MODE, SC

Low VIL 0 -- 0.8 V MODE, SC

VCC

0.9VCC

data

0.1VCC

0.9VCC

0.1VCC

0.1VCC

t2

Backlight Power Supply

MITSUBISHI

Confidential (5/25) AA121TB01_02_00

t1

VL

t5 t6

data: RGB DATA, DCLK, DENA, MODE, SC

t3

t4

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



VCC-dip conditions:

1) When 2.6 V

≤ VCC < 3.0 V, t d ≤ 10 ms

2) When VCC < 2. 6 V
VCC-dip conditions should also follow the power and signals sequence.

*2) Typical current condition:

64-gray-bar pattern(6 bit)
256-gray-bar pattern(8 bit)

800 line mode

VCC = +3.3 V , f

=49.4 kHz, fV=60 Hz, f

H

www.panelook.com

2.6 V

td

=71 MHz

CLK

VCC

3.0 V

(2) Backlight
Ta = 25℃

ITEM SYMBOL MIN. TYP. MAX. UNIT Remarks

Lamp Voltage VL -- 540 -- Vrms IL = 13.0 mArms
Lamp Current IL 6.0 (13.0) 15.0 mArms *2),*6)
Lamp Frequency FL 35 -- 80 kHz *3)

Ta = 25°C

Ta = 0°C

Ta = −20°C

Continuous operation

Starting Lamp Voltage VS

975 -­1150 -­1240 --

--

--

Vrms

--

Lamp Life Time LT 50000 -- -- h

*4),*5), IL = 13.0 mArms

[Note]

*1) Please use synchronous inverter.

*2) Lamp Current measurement method (The current meter is inserted in low voltage line.)

LCD

Module

CTH
CTH

CTL

Inverter

A

Power

Supply

*3) Lamp frequency of inverter may produce interferenc e with horizontal synchronous frequency,

and this may cause horizontal beat on the display. Therefore, please adjust lamp frequency, and
keep inverter as far from module as possible or use electronic shielding between inverter and
module to avoid the interference.

MITSUBISHI

Confidential (6/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



*4) Lamp life time is defined as the time either when the brightness becomes 50% of the initial

value, or when the starting lamp voltage does not meet the value specified in this ta ble.

*5) The life time of the backlight depends on the ambient temperature. The life time will decrease

under low/high temperature.

*6) Please use the inverter which has symmetrical current wave form as follows,

The degree of unbalance: less than 10%

www.panelook.com

The ratio of wave height: less than

I

PH

I

PL

CURRENT WAVE FORM

±10%

2

IPH: High side peak

I

: Low side peak

PL

The degree of unbalance = |IPH - IPL| / Irms
The ratio of wave height =

I

(or IPL) / Irms

PH

100(%)

×

MITSUBISHI

Confidential (7/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



V

5. INTERFACE PIN CONNECTION

(1) CN 1(Inte rface Signal)

Used connecto r: FI-SE20P-HF E (JAE)

Corresponding connector: FI-S20S[fo r discrete Wi re], FI-SE20 ME[fo r FPC] (JAE)

Pin

No.

Symbol

1 VCC +3.3 V Power supply ←
2 VCC +3.3 V Power supply ←
3 GND GND ←
4 GND GND ←
5 Link 0− R0, R1, R2, R3, R4, R5, G0 R2, R3, R4, R5, R6, R7, G2 R0, R1, R2, R3, R4, R5, G0
6 Link 0+ R0, R1, R2, R3, R4, R5, G0 R2, R3, R4, R5, R6, R7, G2 R0, R1, R2, R3, R4, R5, G0
7 GND GND ←
8 Link 1− G1, G2, G3, G4, G5, B0, B1 G3 , G4 , G5, G6, G7, B2, B3 G1, G2, G3, G4, G5, B0, B1

9 Link 1+ G1, G2, G3, G4, G5, B0, B1 G3 , G4 , G5, G6, G7, B2, B3 G1, G2, G3, G4, G5, B0, B1
10 GND GND ←
11 Link 2− B2, B3, B4, B5, DENA B4, B5, B6, B7, DENA B2, B3, B4, B5, DENA
12 Link 2+ B2, B3, B4, B5, DENA B4, B5, B6, B7, DENA B2, B3, B4, B5, DENA
13 GND GND ←
14 CLKIN− Clock −←
15 CLKIN+ Clock + ←
16 GND GND ←
17 Link3− See: *2) R0, R1, G0, G1, B0, B1 R6, R7, G6, G7, B6, B7
18 Link3+ See: *2) R0, R1, G0, G1, B0, B1 R6, R7, G6, G7, B6, B7

19 MODE Low=ISP 6 bit compa tibility mode
20 SC

Scan direct i on control (Lo w=Normal, Hi gh =Reverse)

*1) The shielding case is connected with GND.
*2) Recommended wiring of Pin 17,18 (6 bit input)

Function (ISP 6 bit com patibility mode )

6 bit input 8 bit input

www.panelook.com

Function (ISP 8 bit

compatibilit y m o de)

High=ISP
8 bit compatibility mode

←

LVDS
transmitter

(2) CN 2(Backlight)

Backlight-side connecto r: BHR-04VS-1 (JST)
Inverter-side connector: SM02(4.0)B-BHS(LF)(SN) (JST)

[Note]

CC

680

620

Ω

Ω

LOW data

Pin 17
Pin 18

or

Pin No. Symbol Function

1, 2 CTH

VBLH

4 CTL

（High Voltage）

VBLL

（Low Voltage）

VBLH-VBLL = VL

Pin 17
Pin 18

MITSUBISHI

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Confidential (8/25) AA121TB01_02_00

www.panelook.com

Global LCD Panel Exchange Center



(3) ISP data mapping

a. ISP 6 bit compatibility mode(6 bit input)

CLKIN+/-

www.panelook.com

1CLK

Link0+/-

Link1+/-

Link2+/-

b. ISP 6 bit compatibility mode(8 bit input)

CLKIN+/-

Link0+/-

Link1+/-

Link2+/-

R1G0 R5 R4 R3 R2 R0

G2B1 B0 G5 G4 G3 G1

B3DENA B5 B4 B2

1CLK

R3G2 R7 R6 R5 R4 R2

G4B3 B2 G7 G6 G5 G3

B5DENA B7 B6 B4

Link3+/-

c. ISP 8 bit compatibility mode

CLKIN+/-

Link0+/-

Link1+/-

Link2+/-

Link3+/-

R1B1 B0 G1 G0 R0

1CLK

R1G0 R5 R4 R3 R2 R0

G2B1 B0 G5 G4 G3 G1

B3DENA B5 B4 B2

R7B7 B6 G7 G6 R6

MITSUBISHI

Confidential (9/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



6. INTERFACE TIMING

LVDS transmitter input signal

(1) Timing Specifications

ITEM SYMBOL MIN TYP MAX UNIT

www.panelook.com

DCLK

Frequency f
Period t

Active Time t
Blanking Time t

CLK

CLK

HA

HB

50 71 80 MHz

12.5 14.1 20 ns

1280 1280 1280 t

20 160 -- t

CLK

CLK

Horizontal

DENA

Frequency f
Period t

Active Time t

Blanking Time t

H

H

VA

VB

42.4 49.4 60 kHz

16.6 20.3 23.6 μs
800 800 800 t

3 23 -- t

Vertical

Frequency f
Period t

V

V

55 60 75 Hz

13.3 16.7 18.2 ms

[Note]

1) DENA (Data Enable) should always be positive polarity as shown in the timing specification.

2) DCLK should a p pear during all invalid period.

3) LVDS timing follows the timing specifications of LVDS receiver IC: THC63LVDF84B(Thine).

4) In case of blanking time fluctuation, please satisfy following condition.
t

VBn

> t

VBn-1

− 3(tH)

H

H

MITSUBISHI

Confidential (10/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



V

V

(2) Timing Chart

a. Horizont al T imi ng Chart

DCLK

www.panelook.com

First Data Last Data

DATA
(R,G,B)

t

HB

DENA

b. Vertical Timing Chart

LINE DATA

1 2

1 2 799 800 3Invalid Data Invalid Data

t

VB

3Invalid Data Invalid Data

t

HA

tH=1/f

t

A

1279 1280

H

DENA

tV=1/f

MITSUBISHI

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Confidential (11/25) AA121TB01_02_00

www.panelook.com

Global LCD Panel Exchange Center



(3) Color Dat a Assignment

a. 6 bit input

COLOR

R5 R4 R3 R2 R1 R0 G5 G4 G3 G2 G1 G0 B5 B4 B3 B2 B1 B0

MSB LSB MSB LSB MSB LSB

BLACK 00 0 0 000000000 0 0 000
RED(63) 11 1 1 110000000 0 0 000
GREEN(63) 0 0 0 0 0 0 1 1 11110 0 0 000

BASIC BLUE(63) 00 0 0 000000001 1 1 111

COLOR CYAN 00 0 0 001111111 1 1 111

MAGENTA 11 1 1 110000001 1 1 111
YELLOW 11 1 1 111111110 0 0 000
WHITE 11 1 1 111111111 1 1 111

www.panelook.com

INPUT DATA

R DATA G DATA B DATA

RED(1) 00 0 0 010000000 0 0 000
RED(2) 00 0 0 100000000 0 0 000

RED

RED(62) 11 1 1 100000000 0 0 000
RED(63) 11 1 1 110000000 0 0 000
GREEN(1) 0 0 0 0 0 0 0 0 00010 0 0 000
GREEN(2) 0 0 0 0 0 0 0 0 00100 0 0 000

GREEN

GREEN(62) 0 0 0 0 0 0 1 1 11100 0 0 000
GREEN(63) 0 0 0 0 0 0 1 1 11110 0 0 000
BLUE(1) 00 0 0 000000000 0 0 001
BLUE(2) 00 0 0 000000000 0 0 010

BLUE

BLUE(62) 00 0 0 000000001 1 1 110
BLUE(63) 00 0 0 000000001 1 1 111

[Note]

1) Definition of gray scale
Color (n) --- n indicates gray scale level.

Higher n means brighter level.

2) Data
1:High, 0: Low

MITSUBISHI

Confidential (12/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



b. 8 bit input

www.panelook.com

INPUT DATA

COLOR





BASIC

COLOR













RED











GREEN











BLUE







BLACK
RED(255)
GREEN(255)
BLUE(255)
CYAN
MAGENTA
YELLOW
WHITE
RED(1)
RED(2)

RED(255)
GREEN(1)
GREEN(2)

GREEN(255)
BLUE(1)
BLUE(2)

BLUE(255)

R DATA G DATA B DATA

R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0

MSB LSB MSB LSB MSB LSB

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

1 1 1 1 1 1 11 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0





0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1

[Note]

1) Definition of gray scale
Color (n) --- n indicates gray scale level.

Higher n means brighter level.

2) Data
1:High, 0: Low

MITSUBISHI

Confidential (13/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



(4) Display Position and Scan Direction

D(X,Y) shows the data number of input signal for LCD panel signal processing PCB.

www.panelook.com

SC: Low

   SC: High

D(1,1) D(1280,1)

D(1,800)

D(1280,800)

CN2

D(1280,800) D(1,800)

CN2

D(1280,1) D(1,1)

MITSUBISHI

Confidential (14/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



r

7. BLOCK DIAGRAM

CN1

Timing signal
Display data

Timing

Controller

www.panelook.com

G1

G2

TFT-LCD

Powe

Drivers(gate)

I/F Connector

Power

Supply

Circu it

G800

S1

Drivers(source)

CCFL

S2

S3839

S3840

CN2

1

2

4

MITSUBISHI

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Confidential (15/25) AA121TB01_02_00

www.panelook.com

Global LCD Panel Exchange Center



8. MECHANICAL SPECIFICATIONS

(1) Front Side

www.panelook.com

MITSUBISHI

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

Confidential (16/25) AA121TB01_02_00

(Unit: mm)

www.panelook.com

Global LCD Panel Exchange Center



(2) Rear Side

www.panelook.com

MITSUBISHI

Confidential (17/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

(Unit:mm)

www.panelook.com

Global LCD Panel Exchange Center



9. OPTICAL CHARACTERISTICS

ITEM SYMBOL CONDITION MIN TYP MAX UNIT Remarks

www.panelook.com

Ta=25°C, VCC=3.3V, Input Signals: Typ. Values shown in Section 6

Contrast Ratio CR θ

Luminance Lw θ
Luminance Uniformity ΔLw θ

tr θ

Response Time

tf θ

=0°, θ

V

=0°, θ

V

=0°, θ

V

=0°, θ

V

=0°, θ

V

=0° 390 600 -- -- *1)*2)*5)

H

=0° 300 (400) -- cd/m

H

=0° -- -- 30 % *1)*3)*5)

H

=0° -- 4 -- ms *1)*4)*5)

H

=0° -- 12 -- ms *1)*4)*5)

H

2

*1)*5)

Horizontal θH −70∼70 −80∼80 -- ° *1)*5)

Viewing
Angle

Vertical θ

V

Horizontal θH −70∼70 −80∼80 -- ° *1)*5)
Vertical θ

V

CR ≥ 10

−50∼70 −60∼80 -- ° *1)*5)

CR ≥ 5

−70∼70 −80∼80 -- ° *1)*5)

Image sticking tis 2 h -- -- 2 s *6)



Red



Color Gx (0.298) (0.328) (0.358)

Green

Coordinates



Blue




White



Rx (0.543) (0.573) (0.603)
Ry (0.299) (0.329) (0.359)

Gy θ

=0°, θ

V

=0° (0.506) (0.536) (0.566) --

H

*1)*5)

Bx (0.131) (0.161) (0.191)

By (0.127) (0.157) (0.187)
Wx (0.283) (0.313) (0.343)
Wy (0.299) (0.329) (0.359)

[Note]
These items ar e me asur e d usi n g CS 1000( M I NO LTA) f o r c o lo r c o or di n ates, EZCont r ast( ELDI M ) f o r
viewing angle and CS1000 or BM-5A(TOPCON) for others under the dark room condition (no
ambient light) after more than 30 minutes from turning on the lamp unless noted.

Condition: IL = (13.0) mArms, FL= 55 kHz
Measurement method for luminance and color coordinates is as follows.

Photodetector
Luminance : θ=2° (BM-5A)
Color coordinates : θ=1° (CS1000)

TFT-LCD module

θ

(Field)

500 mm

The luminance is measu red ac cor ding to FLAT PANE L DISPLA Y MEA SUR EME NTS STA NDAR D

(VESA Standard).

MITSUBISHI

Confidential (18/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



*1) Measurement Point

Contrast Ratio, Lumina nce, Response Time, Viewing Angle, Color Coordinates : D isplay Center

Luminance Uniformity: point 1∼5 shown in a figure below

(1,1)

www.panelook.com

640

320

960

200

400

600

*2) Definition of Contrast Ratio

CR= Luminance with all white pixels / Luminance with all black pixels

*3) Definition of Luminance Uniformity

ΔLw=[Lw(MAX)/Lw(MIN)-1] × 100

*4) Definition of Response Time

White

Luminance

1

5

3

2

4

(1280,800)

90%90%

tr

*5) Definition of Viewing Angle (θ

Upper(+)

Left (-)

LCD panel

, θ

)

V

H

Normal Axis

10%10% Black

θ

V

θ

Η

tf

Right (+)

Lower(-)

MITSUBISHI

Confidential (19/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



*6) Image sticking:

Continuously display the test pattern shown in the figure below for two-hours. Then display a
completely white screen. The previous image shall not persist more tha n tw o seconds at 25°C.

Rows 398-402

TEST PATTERN FOR IMAGE STICKING TEST

www.panelook.com

Cols 638-642

White

Area

Black
Lines

MITSUBISHI

Confidential (20/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center





www.panelook.com

10. RELIABILITY TEST CONDITION

(1) Temp e rature and Humi dity

TEST ITEM CONDITIONS

HIGH TEMPERATURE

HIGH HUMIDITY OPERATIO N

HIGH TEMPERATURE OP ERATION 70°C, 240 h

LOW TEMPERATURE OPERATION −20°C, 240 h

HIGH TEMPERATURE ST ORAGE 80°C, 240 h

LOW TEMPERATURE STORAGE −20°C, 240 h

THERMAL SHOCK (NON-O PERATION)

(2) Shock & Vibrat ion

ITEM CONDITIONS

40°C, 90%RH, 240h

(No condensation)

BETWEEN −20°C (1h) and 80°C(1h),

100 CYCLES

Shock level: 1470 m/s

SHOCK

(NON-OPERATION)

VIBRATION

(NON-OPERATION)

(3) Judgment standard

The judgment of the above tests should be made as follow:

Pass: Normal display image, no damage of the display function. (ex. no line defect)

Partial transformation of the module parts should be ignored.

Fail: No display image, dam age of the display function. (ex. line defect)

Waveform: half sinusoidal wave, 2 ms
Number of shocks: one shock input in each direction of three mutually
perpendicular axes for a total of six shock inputs

Vibration level: 9.8 m/s
Waveform: sinusoidal
Frequency range: 5 to 500 Hz
Frequency sweep rate: 0.5 octave /min
Duration: one sweep from 5 to 500 Hz in each of three mutually

perpendicular axis(each x,y,z axis: 1 hour, total 3 hours)

2

(150G)

2

(1.0G)

MITSUBISHI

Confidential (21/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



11. OTHER FEATURE

This LCD module com plies with RoHS*) directive .

*)

RoHS: Restriction of the use of certain hazardous substances in electr ical and electr onic

equipment

www.panelook.com

MITSUBISHI

Confidential (22/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center





www.panelook.com

12. HANDLING PRECAUTIONS FOR TFT-LCD MODULE

Please pay attention to the followings in handling TFT-LCD products;

(1) ASSEMBLY PRECAUTION

a. Please mount the LCD module by using mounting hole with a screw clamping torque less than

0.5 Nm. Please do not bend or wrench the LCD module in assembling. Please do not drop, bend
or twist the LCD mod ule in handling.

b. Please design display hous ing in accordance with the following guide lines.

(a) Housing case must be designed carefully so as not to put stresses on LCD all sides and not

to wrench module. The stresses may cause non-uniformity even if there is no
non-uniformity statically.

(b) Keep sufficient clearance between LCD module back surface and housing when the LCD

module is mounted. Approximately 1.0mm of the clearance in the design is recommended
taking into account the tolerance of LCD module thickness and mounting structure height
on the housing.

(c) Whe n some parts, su ch as, FPC c able and fer rite pl ate, ar e instal led un derneath the LCD

module, still sufficient clearance is required, such a s 0.5mm. This clearance is, especially, to
be reconsidered when the additional parts are implemented for EMI countermeasure.

(d) Design the inverter location and connector position carefully so as not to give stress to

lamp cable, or not to interface the LCD module by the lamp cable.

(e) Keep sufficient clearance between LCD module and the others parts, such as inverter and

speaker so as not to interface the LCD module. Approximately 1.0mm of the clearance in
the design is recommended .

(f) To avoid local elevation/decrease of temperature, considering location of heating element,

heat release, thermal design should be done.

c. Please do not push or scratch LCD panel surface with anything hard. And do not soil LCD

panel surface by touching with bare hands. (Polarizer film, surface of LCD panel is easy to be
flawed.)

d. Please do not press any parts on the rear side such as source TCP, gate TCP, control circuit

board and FP Cs during handling LCD module. If pressing rear part is unavoidable, handle the

LCD module with care not to damage them.
e. Please wipe off LCD panel surface with absorbent cotton or soft cloth in case of it being soiled.
f. Please wipe off drops of adhesives like saliva and water on LCD panel surface immediately.

They might dama ge to cause panel surface variation an d color change .
g. Please do not take a LCD module to pieces and reconstruct it. Resolving and rec onstructing

modules may cause them not to work well.
h. Please do not touch metal frames with bare hands and soiled gloves. A color change of the

metal frames can happen during a long preservation of soiled LCD modules.

i. Please handle metal frame carefully beca use edge of metal frame is very sh arp.

MITSUBISHI

Confidential (23/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



j. Please pay attention to handling lead wire of backlight so that it is not tugged in c onnecting

with inverter.
k. Please connect the metal frame of LCD module to GND in order to minimize the effect of

external noise and EMI.
l. Be su re to connect the cab les and the connect ers correctly.

(2) OPERATING PRECAUTIONS

a. Please be sure to turn off the power supply before connecting and disconnecting signal input

cable.
b. Please do not change variable resistance settings in LCD module. They are adjusted to the

most suitable value. If they are changed, it might happen LCD does not satisfy the

characteristics specification.
c. LCD backlight takes longer time to become stable of radiation characteristics in low

www.panelook.com

temperature than in room temperature.
d. The interface signal speed is very high. Please pay attention to transmission line design and

other high speed signal precautions to satisfy signal specification.
e. A condensation might happen on the surface and inside of LCD module in case of sudden

change of ambient temperature.
f. Please pay attention not to display the same pattern for very long time. Image might stick on

LCD. Even if image sticking happens, it may disappear as the operation time proceeds.
g. Please obey the same safe instructions as ones being prepared for ordinary electronic products.

(3) PRECAUTIONS WITH ELECTROSTATICS

a. This LCD module use CMOS-I C on circ uit board and TFT- LCD panel, and so it i s easy to be

affected by electrostatics. Please be careful with electrostatics by the way of your body

connecting to the ground and so on.
b. Please remove protection film very slowly from the surface of LCD module to prevent from

electrostatics occurrence.

(4) STORAGE PRECAUTIONS

a. Please do not leave the LCDs in the environment of high humidity and high temperature such

as 60°C90%RH.

b. Please do not leave the LCDs in the environment of low temperature; below –20°C.

(5) SAFETY PRECAUTIONS

a. When you waste damaged or unnecessary LCDs, it is recommended to crush LCDs into pieces

and wash them off with solvents such as acetone and ethanol, which should later be burned.

MITSUBISHI

Confidential (24/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com

Global LCD Panel Exchange Center



b. If any liquid leaks out of a dam aged glass cel l and comes i n contact wi th the hands, wash off

thoroughly with soap and water.
c. Be sure to turn off the power supply when in serting or disconnecting t he cable.
d. Inverter should be designed carefully so as not to keep working in case of detecting over

current or open circuit o n the lam p.

(6) OTHERS

a. A strong incident light into LCD panel might cause display characteristics changing inferior

because of polarizer film, color filter, and other materials becoming inferior. Please do not

expose LCD module direct sunlight and st rong UV rays.
b. Please pay attention to a panel side of LCD module not to contact with other materials in

preserving it alone.
c. For the packaging box, please pay attention to the followings;

www.panelook.com

(a) Packaging box and inner case for LCD are designed to protect the LCDs from the damage

or scratching during transportation. Please do not open except picking LCDs up from the
box.

(b) Please do not pile them up more than (7) boxes. (The y are not desi gned so.) A nd please do

not turn over.

(c) Please handle packaging box with care not to give them sudden shock and vibrations. And

also please do not throw them up.

(d) Packaging box and inner case for LCDs are made of cardboard. So please pay attention not

to get them wet. (Such like keeping them in high humidity or wet place can occur getting
them wet.)

MITSUBISHI

Confidential (25/25) AA121TB01_02_00

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory!

www.panelook.com
