Minuteman UPS UPS User Manual

User's Manual

SmartSine

User's Manual

1. Introduction 2

2. Controls and Indicators 4

3. Installation 6

4. Operation 9

5. Troubleshooting 11

6. Replacing the Battery 12

English

7. Obtaining Service 15

8. Specifications 16

9. Configurable Parameters & Settings 17

10. Limited Product Warranty 19

11. Declaration of Conformity 21

© Copyright Para Systems, Inc., 2002

1

English

Thank you for purchasing a MINUTEMAN power protection product. It has been
designed and manufactured to provide many years of trouble free service.

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS !

Please read the manual before installing your SmartSine UPS. It provides the
information that should be followed during installation and maintenance of the
UPS and the batteries allowing you to correctly set up your system for the
maximum safety and performance. Included is information on customer
support and factory service if it is required. If you experience a problem with the
UPS please refer to the Troubleshooting guide in this manual to correct the
problem or collect enough information so that the MINUTEMAN Technical
Support Department can rapidly assist you.

This symbol indicates "ATTENTION"

This symbol indicates "Risk of Electrical Shock"

NOTICE: This equipment has been tested and found to comply

with the limits for a Class B computing device in accordance with the
specifications in Subpart J of Part 15 of FCC Rules and the Class B
limits for radio noise emissions from digital apparatus set out in the

Radio Interference of the Canadian Department of Communications.
These limits are designed to provide reasonable protection against such
interference in a residential installation. This equipment generates and uses
radio frequency and if not installed and used properly, that is, in strict
accordance with the manufacturer's instructions, this equipment may cause
interference to radio and television reception. If this equipment does cause
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

2

! Re-orient the receiving antenna
! Relocate the computer with respect to the receiver
! Move the computer away from the receiver
! Plug the computer into a different outlet so that the computer and receiver

are on different branch circuits.

! Shielded communications interface cables must be used with this product.

WARNING: Changes or modifications to this unit not expressly

approved by the party responsible for compliance could void the user's
authority to operate the equipment.

Receiving Inspection

After removing your MINUTEMAN UPS from its carton, it should be inspected
for damage that may have occurred in shipping. Immediately notify the carrier
and place of purchase if any damage is found. Warranty claims for damage
caused by the carrier will not be honored. The packing materials that your UPS
was shipped in, are carefully designed to minimize any shipping damage. In the
unlikely case that the UPS needs to be returned to MINUTEMAN, please use
the original packing material. Since MINUTEMAN is not responsible for
shipping damage incurred when the system is returned, the original packing
material is inexpensive insurance. PLEASE SAVE THE PACKING

MATERIALS!

WARNING: Risk of electrical shock. Hazardous live parts inside

this power supply are energized from the battery even when the AC
input power is disconnected.

English

To de-energize the outputs of the UPS:

1. If the UPS is on press and release the on/off button.

2. Disconnect the UPS from the AC power outlet.

3. To de-energize the UPS completely, disconnect the battery.
This Uninterruptible Power Supply contains potentially hazardous voltages.
DO NOT attempt to disassemble the unit. This UPS contains no user
serviceable parts. Repairs and battery replacement must be performed by

AUTHORIZED SERVICE PERSONNEL ONLY.

CAUTION! To reduce the risk of electrical shock in conditions where

load equipment grounding cannot be verified, disconnect the UPS from
the AC power outlet before installing a computer interface cable.
Reconnect the power cord only after all signaling connections are made.

CAUTION! Connect the UPS to a two pole, three wire grounding

AC power outlet. The receptacle must be connected to appropriate
branch protection (circuit breaker or fuse). Connection to any other
type of receptacle may result in a shock hazard and violate local
electrical codes.

3

Para Systems Life Support Policy

English

As a general policy, Para Systems Inc. (Para Systems) does not recommend
the use of any of its products in life support applications where failure or
malfunction of the Para Systems product can be reasonably expected to cause
failure of the life support device or to significantly affect its safety or
effectiveness. Para Systems does not recommend the use of any of its
products in direct patient care. Para Systems will not knowingly sell its
products for use in such applications unless it receives in writing assurances
satisfactory to Para Systems that (a) the risks of injury or damage have been
minimized, (b) the customer assumes all such risks, and (c) the liability of
Para Systems Inc. is adequately protected under the circumstances.

Examples of devices considered to be life support devices are neonatal oxygen
analyzers, nerve stimulators (whether used for anesthesia, pain relief, or other
purposes), auto transfusion devices, blood pumps, defibrillators, arrhythmia
detectors and alarms, pacemakers, hemodialysis systems, peritoneal dialysis
systems, neonatal ventilator incubators, ventilators for both adults and infants,
anesthesia ventilators, and infusion pumps as well as any other devices
designated as “critical” by the United States FDA.

Hospital grade wiring and low leakage current devices may be ordered as
options on many Para Systems UPS systems. Para Systems does not claim
that units with this modification are certified or listed as Hospital Grade by Para
Systems or any other organization. Therefore, these units do not meet the
requirements for use in direct patient care.

FRONT PANEL

4

FRONT PANEL INDICATORS

Press and release the ON/OFF/Test Button after 1 beep to turn the
UPS ON or OFF (see section 4).

On-Line/On-Battery/Boost/Buck LED
Fault LED
Overload LED

Weak/Bad Battery LED

Site Wiring Fault LED

On/Off/Test Button

English

On-Line On-Battery

Buck Boost

The On-Line/On-Battery/Boost and Buck (green) LED illuminates in a steady
state when the UPS is on and supplying AC power to the load. The LED blinks
and the audible alarm sounds, when supplying battery power to the load. The
LED blinks and no audible alarm when the UPS is in either the boost or the
buck mode.

The Fault (red) LED illuminates when the UPS has detected an internal
fault. (see section 5)

The Overload (yellow) LED illuminates when the loads connected to the
UPS exceeds the UPS power rating. (see section 5)

The Weak/Bad Battery (red) LED illuminates when the UPS has
detected that the batteries are Weak/Bad. Battery replacement might
be required. (see section 5)

SWF

The Site Wiring Fault (red) LED illuminates when the UPS detects a
improperly wired AC outlet. (see section 5)

5

REAR PANEL

English

4

5

3

2

1

9

8

1. The RJ-45/RJ-11 modular connectors are used for 10 Base-T network/single
line telephone surge protection. (see section 3)

2. The communications port is for UPS monitoring and control. (see section 4)

3. The output receptacles are NEMA 5-15R type.

4. Rating/Serial number label.

5. The Smart Slot is for MINUTEMAN option cards.

6. The output circuit breakers will trip in the event the individual banks of the
output receptacles exceed the rating of the circuit breaker (Not on all models).

7. The input power cord has a NEMA 5-15P or 5-20P (S 2000) connector.

8. The input circuit breaker will trip in the event the load exceeds the UPS's
power rating.

9. The DIP Switch setting may be changed by the user to set the desired
inverter (on battery) output voltage. (see section 4)

6

7

INSTALLATION PLACEMENT

6

Install the UPS in a temperature controlled environment that is free of
conductive contaminants. Select a location which will provide good air
circulation for the UPS at all times. Avoid locations near heating devices, water
or excessive humidity, or where the UPS is exposed to direct sunlight. Route
power cords so they cannot be walked on or damaged.

Operating Temperature: 0 to 40 degrees C (+32 to 104 degrees F)
Operating Elevation: 0 to 3,000m (0 to 10,000 ft)
Operating and Storage Relative Humidity: 95%, non-condensing
Storage Temperature: -15 to +45 degrees C (+5 to +113 degrees F)
Storage Elevation: 0 to 15,000m (0 to +50,000 ft)

INSTALLATION

Be sure to read the installation placement and all the cautions before installing
the UPS. Place the UPS in the final desired location and complete the rest of
the installation procedure. USE CAUTION: The UPS is heavy. Use the
appropriate number of personnel when installing the UPS.

English

NOTE:

CONNECTING YOUR EQUIPMENT

Plug the equipment into the output receptacles on the rear panel of the UPS.
Do not use extension cords, adapter plugs, power strips or surge strips on the
output of the UPS. Ensure that you do not exceed the maximum output rating
of the UPS (refer to the UPS's back panel or the Electrical Specifications in this
manual).

CAUTION!

If the UPS is going to be out of service or stored for a prolonged period
of time, the batteries must be recharged for at least twenty-four hours
every ninety days.

DO NOT connect a laser printer to the output receptacles on the
UPS, unless the UPS is rated 2000VA or greater. A laser printer
draws significantly more power when printing than at idle and
may overload the UPS.

7

CONNECTING THE UPS TO AN AC SOURCE

Plug the UPS into a two pole, three wire, grounded receptacle only. Do not use

English

extension cords, adapter plugs, power strips or surge strips.

CHECKING THE SITE WIRING FAULT

After plugging in the UPS, check the Site Wiring Fault (SWF) LED on the front
panel of the UPS. If the LED is illuminated, the UPS is plugged into an
improperly wired AC outlet.

CAUTION!

If the UPS indicates a Site Wiring Fault, have a Qualified
Electrician correct the problem.

CHARGING THE BATTERY

The SmartSine UPS will charge the internal batteries whenever the UPS is
connected to an AC source. It is recommended that the UPS's batteries be
charged for a minimum of 4 hours before use. The UPS may be used
immediately, however, the “ON Battery” runtime may be less than normally
expected.

NOTE: If the UPS is going to be out of service or stored for a prolonged period

of time, the batteries must be recharged for at least twenty-four hours
every ninety days.

COMMUNICATIONS PORT CONNECTION (OPTIONAL)
MINUTEMAN Power Management software and interface cables kits can be
used with the SmartSine UPS. Use only MINUTEMAN or MINUTEMAN
approved interface cables with these UPSs. Connect the interface cable to the
9 pin communications port on the rear panel of the UPS. Secure the connector
to the UPS via the screws on the connector housing. Connect the other end of
the cable to the device that will be monitoring/controlling the UPS.

NOTE:

Connecting to the Communications Port is optional. The UPS works
properly without a connection.

TELEPHONE/NETWORK SURGE PROTECTION CONNECTION (OPTIONAL)
Connect a single line telephone or a 10 Base-T network line to the protection
sockets on the rear panel of the UPS. This connection will require another
length of telephone or network cable. The cable coming from the telephone
service or networked system is connected to the port marked “IN”.
The equipment to be protected is connected to the port marked "OUT".

NOTE:

Connecting to the telephone/network surge protection connection is
optional. The UPS works properly without a connection.

8

English

TURNING THE UNIT ON/OFF

ON / OFF / Test Button

Press and release the ON/OFF/Test Button after one beep to turn the UPS ON
and supply power to the load. The load is immediately powered while the UPS
runs a five-second self test. Press and release the ON/OFF/Test Button after
one beep to turn the UPS OFF. The UPS will continue to charge the batteries
whenever it is plugged into an AC outlet and there is AC present.

SELF TEST

The self test feature is useful to verify the correct operation of the UPS and the
condition of the batteries. With the UPS in the normal On-Line mode, press
and hold the ON/OFF/Test Button for approximately 4 seconds (four beeps),
then release the button. The UPS will perform a five second self test. During
the self test, the UPS will switch to battery power and the On-Line LED will
blink and the audible alarm will sound. The length of the test that is
automatically performed every two weeks is longer than the start-up or user
invoked test. This test will run for approximately fifteen seconds to measure
the battery’s capability to provide an acceptable amount of runtime. If the UPS
fails a self test, one of the LEDs will remain illuminated indicating the type of
problem. (see section 5 Troubleshooting)
Note: The UPS will automatically perform a self test on start-up and every two

weeks.

DIP SWITCH SETTINGS

The DIP Switch setting may be changed by the user to set the desired inverter
(on battery) output voltage. The DIP Switch must be set to the desired output
voltage and then the UPS must be turned OFF and restarted to reconfigure the
microprocessor and save the changes. The setting for the 120VAC units may
be 110VAC, 120VAC, or 127VAC. The 110/120VAC settings will adjust the
inverter (on battery) output voltage only. The 127VAC setting will adjust the
inverter (on battery) output voltage and the Buck set points.

Switch #1 Switch #2 Output Voltage (battery mode)
OFF OFF 110VAC
OFF ON 110VAC
ON OFF 120VAC
ON ON 127VAC

English

9

ALARMS

ON BATTERY

English

When the UPS is operating on the batteries, the On-Line LED will blink and the
audible alarm will sound once every 10 seconds. The alarm will stop once the
UPS returns to the On-Line operation.

UPS FAULT

When the UPS detects a hardware fault, the Fault LED will illuminate and the
UPS will emit a sustained tone. The fault condition, in some instances, may be
reset by turning the UPS OFF and then ON. (see section 5 Troubleshooting)

OVERLOAD

When the amount of load attached to the UPS exceeds its power rating, the
Overload LED will illuminate and the UPS will emit a sustained tone. This alarm
will remain on until the excess load is removed or the UPS’s self protection
circuit shuts the UPS down.

REPLACE BATTERY

The UPS automatically tests the battery’s condition and will illuminate the Weak/
Bad Battery LED and emit a short beep. This tone will be repeated every hour
until the batteries pass a self test. It is recommended that the UPS be allowed
to charge overnight before performing a battery test to confirm a Weak/Bad
Battery condition.

LOW BATTERY WARNING

The UPS will emit two consecutive beeps every five seconds when the battery
reserve runs low. This condition will continue until AC returns or the UPS shuts
down from battery exhaustion.

COMMUNICATIONS PORT

The communications port is a standard DB9 female with both RS232 and
simulated contact closure capability. The SmartSine UPS will poll the port and
activate the port for RS232 or contact closure in accordance with the type of
cable it finds connected to the port. To change the port configuration requires
the UPS be turned off and restarted with the desired cable connected. The
pinout for the port is depicted below:
Pin 1: EPO Emergency Power Off (pull and hold this pin low to turn off the UPS)
Pin 2: /TXD
Pin 3: /RXD and receive UPS shutdown command
Pin 4: Simulated contact closure AC fail, NO
Pin 5: Ground
Pin 6: Simulated contact closure low battery warning, NO
Pin 7: Simulated contact closure AC fail, NC
Pin 8: AC fail signal (high to low signal)
Pin 9: Not Used

10

English

Symptom

UPS will not turn on

UPS operates in
battery mode only,
even though there is
normal AC present

Fault LED is
illuminated

Site Wiring Fault
LED is illuminated

The On-line/On­Battery LED is
illuminated, but
there is no output

UPS does not
provide expected
runtime

Weak/Bad Battery
LED is illuminated

Possible Cause

On/Off/Test button not
pushed

Input AC circuit breaker is
tripped

UPS has detected an
internal fault
Incorrect service wiring

The UPS is being
controlled via its
communications port

The batteries may be weak
or at the end of useful
service life

Weak/bad batteries or bad
connections at the battery

What To Do

Press and release the On/Off/
Test button to start UPS

Reset circuit breaker by
pressing the plunger back in.
If the AC circuit breaker trips
after UPS starts up, reduce
the load on the UPS

Call for service

Have a Qualified Electrician
correct the service wiring

Disconnect the computer
cable from the UPS and press
the On button. If UPS works
normally, the software has

control of the UPS
Charge the batteries for 8
hours and retest. If the runtime
is still less than expected, the
batteries may need to be
replaced, even though the
Weak/Bad Battery LED is not
illuminated

Check battery connections,

charge the batteries for 8

hours, replace the batteries

UPS occasionally
emits a beep

Overload LED is
illuminated and a
constant alarm
The On-Line LED is
blinking and the au­dible alarm is silent

Normal operation

The load has exceeded the
UPS's capacity

The UPS is in either the
Boost mode or the Buck
mode

The UPS is performing its
intended function

Check the specifications (see

section 8). Remove part of the

load

The UPS is performing its

intended function

11

English

REPLACING THE BATTERY

(AUTHORIZED SERVICE PERSONNEL ONLY)
The SmartSine UPS has an easy to replace hot-swappable batteries. Please
read all of the Warnings and Cautions before attempting to service the
batteries.
NOTE: If there is a power interruption while replacing the hot-swappable

batteries, with the UPS on, the load will not be backed up.

WARNING!

CAUTION:

This Uninterruptible Power Supply contains potentially hazardous
voltages. Do not attempt to disassemble the UPS beyond battery
replacement procedures below. This UPS contains no
user serviceable parts. Battery replacement must be performed
by AUTHORIZED SERVICE PERSONNEL ONLY.

Do not open or mutilate batteries. Released electrolyte is harmful
to the skin and eyes and may be toxic.

CAUTION:

CAUTION:

12

Do not dispose of batteries in a fire. The batteries May explode.
The batteries in this UPS are recyclable. Dispose of the batteries
properly. The batteries contain lead and pose a hazard to the
environment and human health if not disposed of properly. Refer
to local codes for proper disposal requirements or return the
battery to MINUTEMAN.

Although battery system voltages are only 24VDC, the battery
system can still present a risk of electrical shock. The current
capability of a battery is sufficent to burn wire or tools very rapidly,
producing molten metal. Observe these precautions when
replacing the batteries:

1. Remove watches, rings, or other metal objects.

2. Use hand tools with insulated handles.

3. Wear protective eye gear (goggles), rubber gloves and boots.

4. Do not lay tools or other metal parts on top of batteries.

5. Disconnect the charging source prior to connecting or
disconnecting the battery terminals.

6. Determine if the battery is inadvertently grounded. If the
battery is, remove the source of the grounding. Contact with
any part of a grounded battery can result in an electrical shock.
The likehood of such shock will be reduced, if such grounds
are removed during installation and maintenance.

CAUTION:

Replace batteries with the same number and type as originally
installed in the UPS. These batteries have pressure operated vents.
These UPSs contain sealed non-spillable lead acid batteries.

SmartSine
Model #

Battery

Model #

B.B. Part #

CSB Part #

S 700

2-12V7Ah

BP7-12

GP1272 F2 GP12120 F2

Yuasa Part # NP 7-12 NP 12-12 NP 17-12

S 1000

2-12V12Ah

S 1400

2-12V17Ah

BP12-12 BP12-17

GP12170 B1

S 2000

2-12V17Ah

BP12-17

GP12170 B1

NP 17-12

BATTERY REPLACEMENT PROCEDURE

PLEASE READ THE CAUTIONS BEFORE ATTEMPTING TO REPLACE THE
BATTERIES

Hot-swappable batteries mean that the batteries can be replaced without
powering down the whole UPS system.
NOTE: If there is a power interruption while replacing the hot-swappable

batteries, with the UPS on, the load will not be backed up. To
hot-swap the batteries start with step number 5.

1. Turn off the equipment that is plugged into the output receptacles of the
UPS.

2. Press and release the ON/OFF button on the front panel to turn the UPS
OFF.

3. Unplug the UPS's AC power cord from the AC outlet.

4. Unplug the equipment from the output receptacles of the UPS.

5. Remove the front panel of the UPS.

6. Lay the front panel on top of the UPS.

7. Remove the two retaining screws and the battery retaining bracket.

English

13

English

8. Disconnect the positive (red) wire from the battery positve terminal.

9. Using the pull tab, pull the batteries out far enough to get to the battery
negative (black) wire. DO NOT pull the batteries out by pulling the battery
jumper wires.

10. Disconnect the battery negative (black) wire from the battery negative
terminal.

11. Using the pull tab, pull the batteries out completely. DO NOT pull the
batteries out by pulling the battery jumper wires.

12. Remove the battery jumper wire.

13. Verify proper polarity. Re-install the battery jumper wire on the new
batteries.

14. Slide the new batteries into the battery compartment far enough to connect
the battery negative wire.

15. Verify proper polarity. Reconnect the battery negative (black) wire to the
battery negative terminal.

16. Slide the batteries the rest of the way into the battery compartment.

17. Verify proper polarity. Reconnect the battery positive (red) wire to the
battery positive terminal. Some sparking may occur, this is normal.

18. Reinstall the battery retaining bracket and the retaining screws.

19. Reinstall the front panel of the UPS.

20. Dispose of the batteries properly at an appropriate recycling facility or
return them to the supplier in the packing material for the new batteries.

21. The UPS is now ready for the normal start-up procedure.

14

IF THE UPS REQUIRES SERVICE

1.Use the TROUBLESHOOTING section to eliminate obvious causes.

2.Verify there are no circuit breakers tripped. A tripped circuit breaker is the
most common problem.

3.Call your dealer for assistance. If you cannot reach your dealer, or if they
cannot resolve the problem call or fax MINUTEMAN Technical Support at the
following numbers; Voice phone [phone], FAX line [phone] or
visit our Web site at www.minutemanups.com the "Discussion Board". Please
have the following information available BEFORE calling the Technical
Support Department.
A. Your name and address.
B. Where and when the unit was purchased.
C. All of the model information on the rear panel of your UPS.
D. Any information on the failure, including LEDs that may be illuminated.
E. A description of the protected equipment, including model numbers if

possible.

F. A technician will ask you for the above information and, if possible, help

solve your problem over the phone. In the event that the unit requires
factory service, the technician will issue you a Return Material
Authorization Number (RMA #).

G. If the UPS is under warranty, the repairs will be done at no charge. If not,

there will be a charge for repair.

4. Pack the UPS in its original packaging. If the original packaging is no longer

available, ask the Technical Support Technician about obtaining a new set. It
is important to pack the UPS properly in order to avoid damage in transit.
Never use Styrofoam beads for a packing material.
A. Include a letter with your name, address, day time phone number, RMA

number, a copy of your original sales receipt, and a brief description of the
problem.

5. Mark the RMA # on the outside of all packages. The factory cannot accept

any package without the RMA # marked on the outside.

6. Return the UPS by insured, prepaid carrier to:

English

Para Systems Inc.
MINUTEMAN UPS

1455 LeMay Drive

Carrollton, TX 75007

ATTN: RMA # _______

15

English

MODEL NUMBER

Acceptable input voltage
Input voltage (on-line
operation)

Output voltage (AC Mode)

Nominal input frequency

Input protection

Frequency limits (AC Mode)
Transfer time
Maximum load

On-battery output voltage
On-battery frequency
On-battery waveshape
Protection
Surge energy rating (one time,

10/1000 uS waveform)
Surge current capability

(one time, 8/20 uS waveform)
Surge response time
Surge voltage let-through (as

a percentage of an applied
ANSI C62.41 Cat. A +/-6 kV)

Noise filter

Battery type: Sealed, non­spillable, maintenance free,
lead-acid

Typical battery life
Typical recharge time
10 Base-T surge protection let-

through (as a percentage of
an applied +/-6 kV 1.2/50 us,

500 a 8/20 uS test)
Telephone line surge protec­tion let-through (as a percent­age of an applied +/-6 kV 1.2/
50 us, 500a 8/20 uS test)

Operating temperature

Storage temperature

Operating elevation

Storage elevation
Electromagnetic immunity

Audible noise at 1 m (3 ft.)

Size - Net (Shipping)

H x W x D

Weight - Net (Shipping)

Safety and approvals
EMC Verification

16

S 700

110/120V Settings: 104-130 VAC, 127V Setting: 104-134 VAC

700VA
500W

Default 120VAC / User selectable at 110, 120, 127VAC

50/60 Hz, +/-.5 Hz, unless synchronized to utility

Over current, short circuit protected and latching shutdown

0 ns (instantaneous) normal mode; <5 ns common mode

Normal and common mode EMI/RFI suppression

2-12V7Ah

3-6 years, depending on discharge cycles and ambient temp

0 to 40 degrees C (+32 to 104 degrees F)

-15 to +45 degrees C (+5 to +113 degrees F)

IEC 801-2 level IV, 801-4 level IV, 801 -5 level III

8.9 x 6.5 x 17.8" / 226.1 x 165.1 x 452.1 mm

(12.8 x 10.8 x 21.7" / 325.1 x 274.3 x 551.2 mm)

38.6 (42)lb

17.5 (19)Kg
UL1778, UL497A, UL497B, cUL (CSA 22.1)

FCC Class B, CE certified

S 1000

0 - 165 VAC

80 - 150 VAC

50 or 60 Hz, autosensing

Resettable circuit breaker

50 or 60 Hz, +/-6Hz

2-6 mS typical
1000VA
700W

True Sine Wave

6500 Amps total

2-12V12Ah

8 hours from total discharge

0 to +3,000 m (0 to + 10,000 ft)

0 to +15,000 m (0 to +50,000 ft)

<45 dBA

46.3 (50)lb
21 (22.5)Kg

S 1400

1400VA
1000W

500 J

<5%

2-12V17Ah

<5%

<1%

61.7 (65)lb
28 (29.5)Kg

FCC Class A, CE certified

S 2000

2000VA
1400W

2-12V17Ah

67.2 (71)lb

30.5 (32)Kg

English

English

(These items may require optional software or hardware)

Function

UPS ID

Battery
install
date

Battery
life in
days

Enable/
Disable
auto
restart

Set
audible
alarm
state

Shut­down
Type

Factory
Default

SmartSine

Date of
manufacture

1826

Enabled

Enabled

UPS output

User Choices

Up to 64
characters
to define
the UPS

Date of battery
replacement ­day/month/year
XX/XX/XXXX

Up to 5
characters

Enable
or
Disable

Enabled, at
low battery,
disabled

UPS output
or UPS

Description

Use this function to uniquely
identify the UPS in your network
configuration

Enter the current date when
replacing batteries

At first battery replacement, reset
to reflect actual number of days
experience in your environment or
leave factory default

When enabled, the UPS will
automatically restart from a low
battery shutdown when normal AC
returns

Enabled - the UPS will emit a
short beep when in the battery
mode. At Low Battery the UPS
will emit two beeps from low
battery warning until shutdown.
Disabled - Use only when software
is controlling the UPS or to
silence the alarm

UPS Output - When the UPS is
told to shut down, it turns off the
UPS output only. UPS - Turns off
the UPS which requires the UPS
to be turned on manually

Set
inverter
output
voltage

Enable/
Disable
EPO

120VAC

Disabled

110, 120,
127VAC

Enable
or
Disable

Changes output voltage during
battery mode operations

Enabled - the UPS will be
completely powered OFF and
remain OFF until EPO is disabled

17

Customized Output Receptacle Panels

English

The SmartSine UPS has a removable receptacle panel. The receptacle panel
can be configured with one locking receptacle and two duplex receptacles.
This will allow the user to customize the output receptacles for their specific
applications. MINUTEMAN will only use UL or CE approved receptacles. Here
is one example that could be used: one L5-20R, two 5-15/20R duplexes. To
customize your MINUTEMAN UPS for your specific application, contact your
local distributor or contact MINUTEMAN at 1-972-446-7363, 1-800-238-7272 or
fax [phone]to find out which output receptacle options are available.
Come visit our web site at www.minutemanups.com to find out about all the
Power Protection products available from MINUTEMAN.

MINUTEMAN reserves the right to make changes without notice.

18

English

LIMITED PRODUCT WARRANTY

Para Systems Inc. (Para Systems) warrants this equipment, when
properly applied and operated within specified conditions, against faulty
materials or workmanship for a period of three years from the date of purchase.
For equipment sites within the United States and Canada, this warranty covers
repair or replacement of defective equipment at the discretion of Para Systems.
Repair will be from the nearest authorized service center. Replacement parts
and warranty labor will be borne by Para Systems. For equipment located
outside of the United States and Canada, Para Systems only covers faulty
parts. Para Systems products repaired or replaced pursuant to this warranty
shall be warranted for the unexpired portion of the warranty applying to the
original product. This warranty applies only to the original purchaser who must
have properly registered the product within 10 days of purchase.

The warranty shall be void if (a) the equipment is damaged by the
customer, is improperly used, is subjected to an adverse operating
environment, or is operated outside the limits of its electrical specifications; (b)
the equipment is repaired or modified by anyone other than Para Systems or
Para Systems-approved personnel; or (c) has been used in a manner contrary
to the product’s User's Manual or other written instructions.

English

Any technical advice furnished before or after delivery in regard to use or
application of Para Systems’s equipment is furnished without charge and on
the basis that it represents Para Systems’s best judgment under the
circumstances, but it is used at the recipient’s sole risk.

EXCEPT AS PROVIDED HEREIN, PARA SYSTEMS MAKES NO
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some
states do not permit limitation of implied warranties; therefore, the aforesaid
limitation(s) may not apply to the purchaser.

19

LIMITED PRODUCT WARRANTY

English

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL PARA SYSTEMS
BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Specifically, Para Systems is not liable for any costs, such as lost profits or
revenue, loss of equipment, loss of use of equipment, loss of software, loss of
data, cost of substitutes, claims by third parties, or otherwise. The sole and
exclusive remedy for breach of any warranty, expressed or implied, concerning
Para Systems’s products and the only obligation of Para Systems hereunder,
shall be the repair or replacement of defective equipment, components, or parts;
or, at Para Systems’s option, refund of the purchase price or substitution with
an equivalent replacement product. This warranty gives you specific legal rights
and you may also have other rights which vary from state to state.

Longer term and F.O.B. job site warranties are available at extra cost.
Contact Para Systems (1-972-446-7363) for details.

(Continued)

20

DECLARATION OF CONFORMITY

Application of Council Directive(s): 89/336/EEC, 7/23/EEC

Standard(s) to which Conformity is declared: EN50091-2, EN60555-2,
EN61000-3, EN50091-1

Manufacturer’s Name: Para Systems, Inc. (Minuteman UPS)
Manufacturer’s Address: 1455 LeMay Drive

Carrollton, Texas 75007 USA

Type of Equipment: Uninterruptible Power Supplies (UPS)
Model No: S 700 (Y), S 1000 (Y), S 1400 (Y), S 2000 (Y)

Year of Manufacture: Beginning June 3, 2002

I, the undersigned, hereby declare that the equipment specified above
conforms to the above Directive(s).

Robert Calhoun
(Name)

Robert Calhoun

(Signature)

English

Manager Engineering
(Position)

Place: Carrollton, Texas, USA

Date: June 3, 2002

21

English

Notes:

22

24

Para Systems, Inc.

1455 Lemay Dr.

Carrollton, TX 75007

Phone: [phone]

Fax: [phone]
Internet: minutemanups.com
UPS Sizing: sizemyups.com

PN - 34000196 Rev. 0
