Thank you for purchasing a Minuteman power protection product. It has been designed
and manufactured to provide many years of trouble free service.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS !
Please read the manual before installing your Pro Series UPS as it provides
the information that should be followed during installation and maintenance of
the UPS and batteries allowing you to correctly set up your system for the
maximum safety and performance.
Included is information on customer support and factory service if it is required. If you
experience a problem with the UPS please refer to the Troubleshooting guide in this
manual to correct the problem or collect enough information so that the Minuteman
technical support department can rapidly assist you.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B computing device in accordance with the specifications in Subpart J
of Part 15 of FCC Rules and the Class B limits for radio noise emissions from digital
apparatus
set out in the Radio Interference of the Canadian Department of Communications. These limits
are designed to provide reasonable protection against such interference in a residential instal-
lation. This equipment generates and uses radio frequency and if not installed and used
properly, that is, in strict accordance with the manufacturer's instructions, this equipment may
cause interference to radio and television reception. If this equipment does cause interference
to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
n Re-orient the receiving antenna
n Relocate the computer with respect to the receiver
n Move the computer away from the receiver
n Plug the computer into a different outlet so that the computer and receiver are on
different branch circuits.
n Shielded communications interface cables must be used with this product
INTRODUCTION
WARNING: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
Receiving Inspection
After removing your Minuteman UPS from its carton, it should be inspected for damage that
may have occurred in shipping. Immediately notify the carrier and place of purchase if any
damage is found. Warranty claims for damage caused by the carrier will not be honored.
2
The packing materials that your UPS was shipped in are carefully designed to minimize any
shipping damage. In the unlikely case that the UPS needs to be returned to Minuteman,
please use the original packing material. Since Minuteman is not responsible for shipping
damage incurred when the system is returned, the original packing material is inexpensive
insurance.
PLEASE SAVE THE PACKING MATERIALS!
WARNING: RISK OF ELECTRICAL SHOCK. HAZARDOUS LIVE PARTS
INSIDE THIS POWER SUPPLY ARE ENERGIZED FROM THE BATTERY EVEN
WHEN THE AC INPUT POWER IS DISCONNECTED.
TO DE-ENERGIZE THE OUTPUTS OF THE UPS:
1. IF THE UPS IS ON PRESS THE ON/OFF BUTTON FOR 1 SECOND
2. DISCONNECT THE UPS FROM THE AC POWER OUTLET
3. TO DEENERGIZE THE UPS COMPLETELY, DISCONNECT THE BATTERY.
(SEE SECTION 6 FOR INSTRUCTIONS)
CAUTION! TO REDUCE THE RISK OF ELECTRICAL SHOCK IN CONDI-
TIONS WHERE LOAD EQUIPMENT GROUNDING CANNOT BE VERIFIED, DISCON-
NECT THE UPS FROM THE AC POWER OUTLET BEFORE INSTALLING A COM-
PUTER INTERFACE CABLE. RECONNECT THE POWER CORD ONLY AFTER ALL
SIGNALING CONNECTIONS ARE MADE.
CAUTION! CONNECT THE UPS TO A TWO POLE, THREE WIRE GROUND-
ING AC POWER OUTLET. THE RECEPTACLE MUST BE CONNECTED TO APPROPRI-
ATE BRANCH PROTECTION (CIRCUIT BREAKER OR FUSE). CONNECTION TO ANY
OTHER TYPE OF RECEPTACLE MAY RESULT IN A SHOCK HAZARD AND VIOLATE
LOCAL ELECTRICAL CODES
English
Para Systems Life Support Policy
As a general policy, Para Systems Inc. (Para Systems) does not recommend the use of any
of its products in life support applications where failure or malfunction of the Para Systems
product can be reasonably expected to cause failure of the life support device or to
significantly affect its safety or effectiveness. Para Systems does not recommend the use
of any of its products in direct patient care. Para Systems will not knowingly sell its
products for use in such applications unless it receives in writing assurances satisfactory
to Para Systems that (a) the risks of injury or damage have been minimized, (b) the
customer assumes all such risks, and (c) the liability of Para Systems Inc. is adequately
protected under the circumstances.
Examples of devices considered to be life support devices are neonatal oxygen analyzers,
nerve stimulators (whether used for anesthesia, pain relief, or other purposes), auto
transfusion devices, blood pumps, defibrillators, arrhythmia detectors and alarms, pacemak-
ers, hemodialysis systems, peritoneal dialysis systems, neonatal ventilator incubators,
ventilators for both adults and infants, anesthesia ventilators, and infusion pumps as well as
any other devices designated as critical by the United States FDA.
Hospital grade wiring devices and leakage current may be ordered as options on many
PARA SYSTEMS UPS systems. PARA SYSTEMS does not claim that units with this
modification are certified or listed as Hospital Grade by PARA SYSTEMS or any other
organization. Therefore, these units do not meet the requirements for use in direct patient
care.
3
English
CONTROLS AND
INDICATORS
2
FRONT PANEL
Press and release the on/off/test button after one beep to turn the unit on or off
(see section 4)
online
on-battery
boost/buck
fault
overload
Pro 1400
Pro 1400 front panel
replace
battery
online on-battery boost and buck
The online/on battery/boost and buck LED illuminates in a steady state when the
UPS is on and supplying AC power to the load, blinks and sounds the audible
alarm when supplying battery power to the load, blinks with no audible alarm
when the automatic voltage regulator is in operation.
The fault LED illuminates when the UPS has detected an internal fault (contact
Minuteman technical support)
The overload LED illuminates when the loads connected to the Ups exceed the
UPS power rating (see section 4)
The replace battery LED illuminates when the UPS has detected that battery
replacement is required (see section 6)
4
Interface Port
In
Out
Pro 1400 rear panel
SWF
Circuit
Breaker
REAR PANEL (120 vac models shown)
The RJ-45/RJ-11 modular connectors are used for 10 Base-T network/single line telephone
surge protection (see section 3).
The computer interface port is for UPS monitoring and control (see section 3).
The site wiring fault LED illuminates when the UPS detects an improperly wired AC power
outlet (120 vac MODELS ONLY) see section 3.
The output power receptacles are NEMA 5-15R type. (IEC output sockets on 230 VAC
models)
English
The input power cord has a NEMA 5-15P connector. (IEC input socket on 230 VAC models)
The input circuit breaker will trip in the event the load exceeds the UPSs power rating.
INSTALLATION
3
INSTALLATION PLACEMENT
Install the UPS in a temperature controlled environment that is free of conductive contami-
nants. Select a location which will provide good air circulation for the UPS at all times. Avoid
locations near heating devices, water or excessive humidity, or where the UPS is exposed
to direct sunlight. Route power cords so they cannot be walked on or damaged.
