Minox MD 62 ED BROCHURE
MINOX MD 62 ED SILVER
S
POTTING SCOPE IN
MINOX
FORMAT
P
RODUCT INFORMATION
The ability to draw in distant objects close
enough to touch! This is also something
many nature observers and birdwatchers desire. With the new spotting scopes, MINOX
MD 62 and MD 62 ED,MINOX has now supplemented its sport optics program to meet
particular importance to an extremely short
focusing distance and it is therefore possible with the MD62 to observe everything
which grows, blossoms and moves in the
area in the closest detail, yet remaining at a
safe distance. Even just 5 meters away!
this requirement. Here again the MINOX
values of compact design, quality and precision are consistently applied, as with all
products from MINOX in the field of sport
optics.The new spotting scope weights just
930 grams and with its dimensions of
328x99x89 mm it is one of the most compact models available.
The MD 62ED version uses a new type of ED
fluoride glass which guarantees absolutely
neutral colour rendition even in critical light
conditions. The optical designers attached
Technical data
MD 62 / MD 62 ED MD 62 / MD 62 ED MD 62 / MD 62 ED
Magnification 20 - 45x 40x 22xWW
Front lens diameter 62 mm 62 mm 62 mm
Exit pupil 3.1 - 1.38 mm 1.55 mm 2.81 mm
Field of view 1.7° - 1.1° 1.2° 3°
Close distance 5 m / 16.4 ft 5 m / 16.4 ft 5 m / 16.4 ft
Over run (∞) ± 4 dpt. ± 4 dpt. ± 4 dpt.
Twilight number 35.2 - 52.8 49.8 36.9
Geom. twilight no. 9.6 - 1.9 2.4 7.9
Operating temp. -10°C up to +45°C -10°C up to +45°C -10°C up to +45°C
14° up to 113° F 14° up to 113° F 14° up to 113° F
Water proof yes, up to 5 m / 16,4 ft yes, up to 5 m / 16,4 ft yes, up to 5 m / 16,4 ft
Height, width, depth 328 x 99 x 89 mm 328 x 99 x 89 mm 328 x 99 x 89 mm
Weight 930 g 930 g 930 g
The sturdy metal housing protects the precision mechanical parts and precision optics
against harmful influence from the outside
and the nitrogen filling prevents misting up
of the optical system on the inside, even under extreme temperature fluctuations. The
three eyepieces, 20-45x, 22xww and 40x,
complete the new MD range of spotting scopes.These ensure a universal application and
with the bayonet mount system it is instantly ready for use.
Being a legendary camera manufacturer, MINOX has, of course,also provided an appropriate photo adapter for use with all camera
systems via T2 mount.
A nylon ever-ready case with a unique design perfectly complements this new MINOX
product and can be optimally used with a
tripod, whenever required.
Accessories
• Eyepiece with variable
magnification 20 - 45x
• Eyepiece 22 x WW
• Eyepiece 40 x
• Photo adapter
• Delivery includes a
nylon ever-ready case
MINOX GmbH
Walter-Zapp-Str. 4
D-35578 Wetzlar, Germany
Tel.: +49 (0) 6441 / 917-0
Fax: +49 (0) 6441 / 917-612
e-mail: info@minox.com
http:// www.minox.com
Design, features, supply and price are subject to change. Product information order number:99213 (e)
