Minolta X 20, 20 Specifications

www.minolta.co.uk The essentials of imaging

Technical Specifications

Number of effective pixels: 2.0 million

CCD: 1/3.2-type interline primary-colour CCD

Total pixels: 2.1 million

Camera
sensitivity: Auto (between ISO 64 –200 equivalent), ISO

64,100, 200, 400 equivalents

Focal length: 4.8 – 14.4mm (35mm equivalent: 37 – 111mm)

Lens construction: 10 elements in 9 groups (includes two double-

sided aspheric elements)

Maximum aperture: f/2.8 – f/3.7

Minimum focus distance: 0.10m from front of camera

Maximum magnification: 0.111x (1:9.01)

Equivalent to 0.857x (1: 1.17) in 35mm format

Area covered at
maximum magnification: 40 x 30mm

Monitor LCD: 4.0cm digital-interface TFT colour

monitor with anti-reflection coating
Total pixels: 84,960
Automatic monitor amplification

Shutter: CCD electronic shutter and mechanical shutter

Shutter speed range: 4 - 1/1000 s

Autofocus system: Video AF

Autofocus areas: Wide focus area (five point AF)

Metering: Multi-segment

Multi-segment metering: 256 segments

www.minolta.co.uk The essentials of imaging

Exposure control: Programmed AE

Exposure compensation: ±2 Ev in 1/3 increments

Flash range: Wide: 0.1 – 3.6m (approx.)

Telephoto: 0.1 – 2.7m (approx.)
(Camera sensitivity: auto)

Flash modes: Autoflash, Autoflash with red-eye reduction,

Fill-flash, Flash cancel, Night portrait

Continuous advance: Available

Self timer: 10 s (approx.)

Self portrait: Subject program used with the mirror on the

front of the camera.

Multi frame: To capture 9 sequential images at 3fps

displayed in a 3x3 grid in a single frame.

Image pasting: Embeds an image within another image.

Movie recording: Recording time dependent on memory card

capacity and image size.
Frame rate: 15fps
Mono only.

Audio: Voice memo: 15s (max)

Audio caption: 15s (max.)
Mono only.

White balance control: Automatic, Preset (Daylight, Cloudy, Tungsten,

Fluorescent)

Toning: Neutral black and white, Sepia, Red tone, Blue

tone, Green tone

Portrait mode: Optimises camera settings to enhance skin

tones.

Noise reduction: Auto
