MVS 52X
Call: +1 (714) 283-4200 · Fax: +1 (714) 283-4268
info@minipack.us · www.minipack.us
MVS 52X
Chamber & Seal Bars
Downloads
Product Sheet (pdf)
Contact Us
Performance
Display & Controls
Request a Quote
Operational Features
Service
Housing & Dimensions
Optional Seal Bars
Wide Flat Seal (6mm + 1mm Cut-Off Seal)
Optional Features
*Depends on type of product, film and operator ability.
Specifications may chan ge without notice.
Chamber Width x Length 20.00" x 21.00"
Height (Chamber + Dome/Lid = Total) 3.50" + 3.00" = 6.50"
Number of Seal Bars (removable) 2
Position of Seal Bars Left & Right
Seal Bar Length 2 x 21.00"
Distance between Seal Bars 16.00"
4 mm Seal + 1 mm Cut-Off Seal
Independent Power to each Seal Bar
Programmable Vacuum Time (%)
Programmable Service Reminder
Shipping Wt. (Pallet not included) 345lbs
Unique Waffle-Pattern Se aling
Pop-Out Seal Bars
Pump Type Busch KB Oil Rotary
Cycles per Minute* up to 3
Free Air Displacement @ 50Hz 20 m³/h
Free Air Displacement @ 60Hz 24 m³/h
Pump Power Rating 1 hp
Power Supply 120V / 1ph / 18A
Water Resistant Digital Display
LED Full Description Display
Electronic Millibar Sensor
Customizable Programs 9
Programmable Sealing Time
Moisture Quick Stop
Excess Bag Cut-Off
High Volume Density Plates
Indicating Display
1 Year Limited Warranty
Material Stainless 304
Lid Type
Width x Length 25.00" x 31.00"
Height (Lid open/closed) 52.50" / 38.75"
Working Height 35.00"
Locking Casters
Dual Flat Seal (2 x 4 mm )
Dual Convex Seal (2 x 3.5 mm)
Top & Bottom Seal
Inert Gas Flush Kit
Evacuation Filter Kit
Tray for Liquids
Taller Dome -
230V Single Phase @ 50/60Hz
208V Three Phase @ 50/60Hz 48 m³/h
Transparent with
Dome
