MVS 50X

1832 North Glassell Street · Orange, CA 92865, USA

Call: [phone] · Fax: [phone]

[e-mail] · www.minipack.us

MVS 50X

Chamber & Seal Bars

Performance

Downloads

Product Sheet (pdf)

Freestanding Vacuum Chamber Sheet (pdf)

Display & Controls

Contact Us

Request a Quote

Operational Features

Service

Housing & Dimensions

Optional Seal Bars

Wide Flat Seal (6mm + 1mm Cut-Off Seal)

Optional Features

*Depends on type of product, film and operator ability.
Specifications may chan ge without notice.

Chamber Width x Length 26.00" x 20.50"

Height (Chamber + Dome/Lid = Total) 5.00" + 4.00" = 9.00"

Number of Seal Bars (removable) 2

Position of Seal Bars Left & Right

Seal Bar Length 2 x 20.25"

Distance between Seal Bars 22.00"

4 mm Seal + 1 mm Cut-Off Seal

Independent Power to each Seal Bar

Programmable Vacuum Time (%)

Programmable Service Reminder

Shipping Wt. (Pallet not included) 439lbs

Unique Waffle-Pattern Se aling

Pop-Out Seal Bars

Pump Type Busch R5 Oil Rotary

Cycles per Minute* up to 3

Free Air Displacement @ 50Hz 40 m³/h

Free Air Displacement @ 60Hz 48 m³/h

Pump Power Rating 2 hp

Power Supply 208V / 3ph / 14A

Water Resistant Digital Display

LED Full Description Display

Electronic Millibar Sensor

Customizable Programs 9

Programmable Sealing Time

Moisture Quick Stop

Excess Bag Cut-Off

High Volume Density Plates

Indicating Display

1 Year Limited Warranty

Material Stainless 304

Lid Type

Width x Length 31.00" x 29.00"

Height (Lid open/closed) 51.75" / 40.50"

Working Height 35.00"

Locking Casters

Dual Flat Seal (2 x 4 mm )

Dual Convex Seal (2 x 3.5 mm)

Top & Bottom Seal

Inert Gas Flush Kit

Evacuation Filter Kit

Tray for Liquids

Taller Dome -

220V / 1ph / 16.5A @ 50/60H z 40 m³/h / 48 m³/h

Transparent with

Dome
