MVS 41XP

1832 N. Glassell Street · Orange, CA 92865, USA

Call: +1.714.283.4200 · Fax: [phone]

[e-mail] · www.minipack.us

MVS 41XP

Downloads

Product Sheet (pdf)

Table Top Vacuum Chamber with Printer Sheet (pdf)

Contact Us

Request a Quote

Chamber & Seal Bars

Height (Chamber + Do me/Lid = Total) 3.00" + 1.00" = 4.00"

Chamber Width x Length 29.00" x 13.50"

Number of Seal Bars (removable) 3

Position of Seal Bars Front, Left & Right

Seal Bar Length

Distance between Seal Bars 25.00" (Left to Right)

4 mm Seal + 1 mm Cut-Off Seal

Unique Waffle-Pattern Seal ing

Hygienic Seamless Chamber

Pop-Out Seal Bars

Independent Power to each Seal Bar

Performance

Pump Type Busch KB Oil Rotary

Cycles per Minute* up to 3

Free Air Displacement @ 50Hz 20 m³/h

Free Air Displacement @ 60Hz 24 m³/h

Pump Power Rating 1.25 hp

Power Supply 120V / 19A

Display & Controls

Water Resistant Digital Display

LCD Full Description Display

Selectable Control (mbar or %)

Electronic Millibar Sensor

Customizable Programs 100

Operational Features

Programmable Direct Thermal Printer

Printing Features: Item Name, Date Coding,

Ingredients, Operator Code, Unit Pricing

Programmable Vacuum Time (mbar or %)

Programmable Sealing Time

Moisture Quick Stop

Programmable Hot Food Cycle

Programmable Infusion Cycle

External Channel Bag Evacuation -

Soft Air (slow return of air)

Extra Vacuum (30 sec)

Excess Bag Cut-Off

High Volume Density Plates

Service

Pump Conditioning

Self Diagnostic

Programmable Service Reminder

Indicating Display

1 Year Limited Warranty

Housing & Dimensions

Material Stainless 304

Lid Type

Width x Length 34.00" x 20.50"

Height (Lid open/closed) 28.00" / 17.00"

Recessed Lifting Cups

Shipping Wt. (Pallet not inclu ded) 245.9lbs

Leveling Legs

Optional Seal Bars

Wide Flat Seal (6mm + 1mm Cut-Off Seal)

Dual Flat Seal (2 x 4 mm)

Dual Convex Seal (2 x 3,5 mm)

Top & Bottom Seal -

Optional Features

Inert Gas Flush Kit

Evacuation Filter Kit

Tray for Liquids

220V Single Phase @ 50/60Hz

NSF 4" Legs

Accessories

*Depends on type of product, film and operator ability.
Specifications may change without notice.

Thermal Paper

24.75" (F) / 2 x

12.25" (L & R)

Transparent with

Dome
