MVS 35X

Call: [phone] · Fax: [phone]

[e-mail] · www.minipack.us

MVS 35X

Chamber & Seal Bars

Downloads

Performance

Product Sheet (pdf)

Table Top Vacuum Chamber Sheet (pdf)

Contact Us

Display & Controls

Request a Quote

Operational Features

Service

Housing & Dimensions

Optional Seal Bars

Wide Flat Seal (6mm + 1mm Cut-Off Seal)

Optional Features

*Depends on type of product, film and operator ability.
**Shipping weight to East Coast: 136 lbs (double-palleted)
Specifications may chan ge without notice.

Chamber Width x Length 13.00" x 11.75"

Height (Chamber + Dome/Lid = Total) 4.50" + 3.00" = 7.50"

Number of Seal Bars (removable) 1

Position of Seal Bars Front

Seal Bar Length 12.25"

Distance between Seal Bars -

4 mm Seal + 1 mm Cut-Off Seal

Unique Waffle-Pattern Se aling

Hygienic Seamless Cham ber

Independent Power to each Seal Bar

Programmable Vacuum Time (%)

External Channel Bag Evacuation

Programmable Service Reminder

Pop-Out Seal Bars

Pump Type Busch R5 Oil Rotary

Cycles per Minute* up to 3

Free Air Displacement @ 50Hz 10 m³/h

Free Air Displacement @ 60Hz 12 m³/h

Pump Power Rating 0.75 hp

Power Supply 120V / 10A

Water Resistant Digital Display

Electronic Millibar Sensor

Programmable Sealing Time

High Volume Density Plates

Dual Flat Seal (2 x 4 mm )

Dual Convex Seal (2 x 3,5 mm)

230V Single Phase @ 50/60Hz

LED Display

Customizable Programs 9

Extra Vacuum (30 sec)

Excess Bag Cut-Off

Indicating Display

1 Year Limited Warranty

Material Stainless 304

Lid Type

Width x Length 15.50" x 25.00"

Height (Lid open/closed) 23.00" / 13.00"

Recessed Lifting Cups -

Leveling Legs

Shipping Wt.** 120 lbs

Top & Bottom Seal -

Inert Gas Flush Kit

Evacuation Filter Kit

Tray for Liquids

NSF 4" Legs -

Transparent with

Dome
