Page 1
HL-SF
Original instructions
Page 2
7
6
ON
OFF
Text section with Technical Data, important Safety
and Working Hints and description of Symbols
12
4
5
2 3
Page 3
1
2
+
-
+
-
+
-
Type AAA
3
click
4 5
Page 4
ON
OFF
MODE memory: the selected
operating mode is available again
when switching on again.
6 7
Page 5
TECHNICAL DATA BATTERY LAMP
Rated Power input ..................................................................
Lighting time
Spot Mode High ...................................................................
Flood Mode High .................................................................
Flood Mode Med ..................................................................
Flood Mode Low ..................................................................
Hybrid Mode ........................................................................
Luminus fl ux
Spot Mode High ...................................................................
Flood Mode High .................................................................
Flood Mode Med ..................................................................
Flood Mode Low ..................................................................
Hybrid Mode ........................................................................
Colour rendering index (CRI)..................................................
Colour temperature.................................................................
Battery voltage........................................................................
Battery type ............................................................................
Weight according EPTA-Procedure 01/2014 ..........................
Protection class ......................................................................
WARNING Read all safety warnings, instructions,
illustrations and specifi cations provided with this power
tool. Failure to follow all instructions listed below may result
in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS BATTERY LAMP
Warning: Do not direct the light beam at persons or animals
and do not stare into the light beam yourself (not even from
a distance). Staring into the light beam may result in serious
injury or vision loss.
Don‘t use this tool in wet areas .
The light source of this luminaire is not replaceable; when
the light source reaches its end of life the whole luminaire
shall be replaced.
SAFETY INSTRUCTIONS BATTERY
This tool is designed to be powered by 3 LR03 / AAA
batteries properly inserted into the instrument. Do not
attempt to use with any other voltage or power supply.
Do not leave batteries within the reach of children.
Do not mix new and used batteries. Do not mix brands (or
types within brands) of batteries.
Do not mix rechargeable and non-rechargeable batteries.
Install batteries according to polarity (+ / –) diagrams.
Properly dispose of used batteries immediately.
Battery acid may leak from damaged batteries under
extreme load or extreme temperatures. In case of contact
with battery acid wash it off immediately with soap and
water. In case of eye contact rinse thoroughly for at least 10
minutes and immediately seek medical attention.
Warning! To reduce the risk of fi re, personal injury, and
product damage due to a short circuit, never immerse your
tool, battery pack or charger in fl uid or allow a fl uid to fl ow
inside them. Corrosive or conductive fl uids, such as
seawater, certain industrial chemicals, and bleach or bleach
containing products, etc., can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The headlight is intended to be used light independent use
away from mains supply. The headlight is especially
designed for head mounting.
Do not use this product in any other way as stated for
normal use.
MAINTENANCE
The light source of this luminaire is not replaceable; when
the light source reaches its end of life the whole luminaire
shall be replaced.
Use only Milwaukee accessories and spare parts. Should
components need to be replaced which have not been
described, please contact one of our Milwaukee service
agents (see our list of guarantee/service addresses).
HL-SF
..........................5,5 W
.............................4 h
.............................4 h
...........................10 h
...........................26 h
.............................2 h
.........................350 lm
.........................350 lm
.........................150 lm
...........................25 lm
.........................450 lm
...........................80
.......................4000 K
..........................4,5 V (3x1,5V)
............ LR03 / AAA
..........................0,1 kg
........................... IP 52
If needed, an exploded view of the tool can be ordered.
Please state the machine type printed as well as the six-digit
No. on the label and order the drawing at your local service
agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany.
SYMBOLS
CAUTION! WARNING! DANGER!
Please read the instructions carefully before
starting the machine.
Do not stare at the operating light source.
Class III electrical protection.
This tool is only suitable for indoor use. Never
expose tool to rain.
Do not dispose electric tools, batteries/
rechargeable batteries together with household
waste material.
Electric tools and batteries that have reached the
end of their life must be collected separately and
returned to an environmentally compatible
recycling facility.
Check with your local authority or retailer for
recycling advice and collection point.
European Conformity Mark
British Confomity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
ENGLISH
98
Page 6
10 11
Page 7
Copyright 2020
Techtronic Industries GmbH
Max-Eyth-Str. 10
71364 Winnenden
Germany
+49 (0) 7195-12-0
www.milwaukeetool.eu
Techtronic Industries (UK) Ltd
Fieldhouse Lane
Marlow Bucks SL7 1HZ
UK
(10.20)
4100 4702 83
