Page 1
YOUR WI-FI HAS AN AUDIENCE
Who said you should hide your router in the closet? Bring it
out in the open and enjoy faster and smoother signal in your
whole home. A router for those who value both beauty and
functionality.
Page 2
STRONG CONNECTION
EVERYWHERE
Wi-Fi has to be fast, reliable, easy to manage, it
must reach every room and every corner. That
is exactly what Audience devices can deliver in
grand style – even in the biggest houses!
Audience is a tri-band (one 2.4 GHz & two 5 GHz )
home access point with LTE support and meshing
technology. If you need Wi-Fi in a huge building
with all kinds of obstacles, simply add more
Audience devices to your network – with a press
of a button they will sync seamlessly and create a
single Wi-Fi network to cover the whole premises.
The initial setup is also very simple – download
the iOS or Android MikroTik app, it will connect to
the router and guide you through a quick setup
process.
In some cases a single Audience unit might be
able to replace several other routers – in our tests
it covered 1858 m² (20000 square feet) easily. It
depends on the amount of obstacles, Wi-Fi clients
and interference, so results may vary.
Page 3
ENJOY THE FREEDOM OF LTE
Cables can no longer limit you. CAT6 LTE delivers speed
up to 300 Mbps with low latency, so having a traditional
Ethernet connection is not a must-have for streaming high-
quality videos or gaming. Alternatively, you can use the two
Gigabit Ethernet ports and keep the LTE option for backup.
One of the Ethernet ports supports PoE for powering the
device.
Dual-chain 2.4 GHz and 5 GHz wireless coverage will solve
most interference issues in a crowded environment. For
example, you can simultaneously use the 2.4 GHz channel
for all your household mobile devices and reserve
the 5 GHz channel for your PC or TV.
Order your Audience today and start living in the future.
The future of easy and elegant networking.
Page 4
Audience series
General specifications
Product code RBD25G-5HPacQD2HPnD, RBD25GR-5HPacQD2HPnD&R11e-LTE6
CPU 4 core IPQ-4019 716 MHz
Size of RAM 256 MB
Storage 128 MB NAND, 2 MB flash
10/100/1000 Ethernet ports 2
Wireless* 2.4 GHz 5.18 - 5.3 GHz 5.5 - 5.85 GHz
Protocols 802.11b/g/n 802.11a/n/ac 802.11a/n/ac
Number of chains 2 4
Wireless antenna max gain 3.5 dBi 4.5 dBi
Wireless regulations Specific frequency range will be limited by country regulations
Antenna beam width 360°
Supported input voltage DC jack 12 - 57 V
PoE in 802.3af/at 24 - 57 V
Dimensions 251 x 129 x 39 mm
Operating temperature -40°C .. +60°C
Operating system RouterOS, License level 4
Max power consumption 27 W
*Audience’s 5 GHz coverage is limited to 5180 – 5320 MHz, as it uses 5500 – 5825 MHz spectrum to communicate
with other Audience devices.
LTE model specifications
Product code RBD25GR-5HPacQD2HPnD&R11e-LTE6
Micro SIM slots 1
MiniPCIe slots 1
LTE category 6 (300 Mbps Downlink, 50 Mbps Uplink)
LTE antenna max gain 4 dBi (with u.FL connector)
LTE (FDD) bands
LTE (TDD) bands 38(2600)/39(1900)/40(2300)/41n(2500)
3G bands 1(2100)/2(1900)/5(850)/8(900)
2G bands 2(1900)/3(1800)/5(850)/8(900)
Audience series
1(2100)/2(1900)/3(1800)/5(850)/7(2600)/8(900)/12(700)/17(700)/20(800)/25(1900)/
26(850)
4
Page 5
Audience series
Supported 2xCA LTE bands
1+1/5/8/20 2+2/5/12/17 3+3/5/7/8/20 7+7/8/12/20 8+8
12+12 38+38 39+39/41 40+40 41+41
Wireless specifications
Rate (2.4 GHz) Tx (dBm) Rx (dBm)
1MBit/s 26 -100
11MBit/s 26 -94
6MBit/s 29 -96
54MBit/s 26 -80
MCS0 29 -96
MCS7 25 -75
Rate (5 GHz
5500 – 5825)
6MBit/s 32 -96
54MBit/s 28 -80
MCS0 32 -96
MCS7 27 -77
MCS9 25 -72
Tx (dBm) Rx (dBm)
Rate (5 GHz
5180 – 5320)
6MBit/s 28 -95
54MBit/s 25 -78
MCS0 28 -95
MCS7 24 -75
MCS9 22 -70
Tx (dBm) Rx (dBm)
Included parts
24 V 1.5 A
power adapter
Audience series
Ethernet cable
5
