Miele TWR 860 WP Operating instructions

Operating instructions
Heat pump dryer

To avoid the risk of accidents or damage to the appliance it is essen-
tial to read these instructions before it is installed and used for the
first time.

en-GB M.-Nr. 11 642 020

Contents

Caring for the environment ............................................................................. 6

Warning and Safety instructions ..................................................................... 7

Operating the tumble dryer .............................................................................. 19

Control panel....................................................................................................... 19

Touch display and sensors.................................................................................. 19

Main menu........................................................................................................... 20

Examples on how to operate the appliance........................................................ 21

Before using for the first time .......................................................................... 23

Downtime after installation.................................................................................. 23

Miele@home ........................................................................................................ 23

Setting the language ........................................................................................... 24

Energy saving tips ............................................................................................. 27

Energy saving tips ............................................................................................... 27

EcoFeedback....................................................................................................... 28

1. Notes on correct laundry care ..................................................................... 29

Points to note regarding washed laundry............................................................ 29

Preparing the laundry before drying.................................................................... 29

Drying .................................................................................................................. 30

Care label symbols......................................................................................... 30

Select the correct drying level........................................................................ 30

2. Load the tumble dryer................................................................................... 31

Loading the laundry............................................................................................. 31

3. Selecting a programme ................................................................................ 32

Switching on the tumble dryer ............................................................................ 32

4. Selecting programme settings..................................................................... 33

Programme settings ............................................................................................ 33

Selecting the drying level for a drying level programme ................................ 33

Other programmes and timed drying programmes........................................ 33

Selecting an extra option..................................................................................... 34

5. Starting a programme................................................................................... 35

Starting the programme ...................................................................................... 35

6. End of programme - unload the drum......................................................... 36

End of programme............................................................................................... 36

Unloading the drum............................................................................................. 36

Programme chart .............................................................................................. 37

2

Contents

Extras.................................................................................................................. 43

Gentle tumble...................................................................................................... 43

Freshen up........................................................................................................... 43

Drying programme overview - Extras.................................................................. 44

Wash2Dry....................................................................................................

Requirements for use .......................................................................................... 45

Selecting the Wash2Dry function ................................................................

Favourite programmes...................................................................................... 46

To create a Favourite programme........................................................................ 46

Option 1.......................................................................................................... 46

Option 2.......................................................................................................... 46

To enter a name.............................................................................................. 46

To change a Favourite programme................................................................. 46

Drying assistant................................................................................................. 47

Timer................................................................................................................... 48

Setting the timer.................................................................................................. 48

Changing the timer.............................................................................................. 48

Deleting the timer ................................................................................................ 48

Starting the timer................................................................................................. 48

SmartStart ........................................................................................................... 49

Setting the timeframe..................................................................................... 49

Changing the programme sequence .............................................................. 50

Adding or removing laundry ................................................................................ 50

Condensed water container ............................................................................. 51

Emptying the condensed water container .......................................................... 51

Preparing the condensed water container for the Steam Care programme ....... 52

45

45

Fragrance flacon................................................................................................ 53

FragranceDos ...................................................................................................... 53

Removing the protective seal from the fragrance flacon..................................... 53

Inserting the fragrance flacon.............................................................................. 54

Opening the fragrance flacon.............................................................................. 55

Closing the fragrance flacon ............................................................................... 55

Removing/replacing the fragrance flacon ........................................................... 56

3

Contents

Cleaning and care ............................................................................................. 57

Fluff filters............................................................................................................ 57

Removing the fragrance flacon ...................................................................... 57

Removing visible fluff ..................................................................................... 57

Cleaning the fluff filters and air flow openings thoroughly ............................. 58

Cleaning the fluff filters with water ................................................................. 59

Cleaning the plinth filter....................................................................................... 60

Removing the plinth filter ............................................................................... 60

Cleaning the plinth filter.................................................................................. 61

Cleaning the plinth filter access panel ........................................................... 62

Cleaning the dryer ............................................................................................... 62

Problem solving guide ...................................................................................... 63

The display indicates the following messages or faults...................................... 63

Unsatisfactory drying results............................................................................... 66

The drying cycle duration is very long................................................................. 67

General problems with the tumble dryer............................................................. 68

Replacing the plinth filter..................................................................................... 70

Reactivating the plinth filter................................................................................. 72

Checking the heat exchanger.............................................................................. 72

Cleaning the fluff filter in the condensed water container................................... 73

Replacing the blocked spray jet for the Steam care programme........................ 74

Service................................................................................................................ 75

Contact in the event of a fault ............................................................................. 75

Optional accessories........................................................................................... 75

Warranty .............................................................................................................. 75

Installation.......................................................................................................... 76

Front view............................................................................................................ 76

Rear view............................................................................................................. 77

Transporting the tumble dryer ............................................................................. 77

Transporting the tumble dryer to its installation site ...................................... 77

Installation ........................................................................................................... 78

Levelling the dryer .......................................................................................... 78

Downtime after installation............................................................................. 78

Ventilation....................................................................................................... 78

Before moving the tumble dryer again (e.g. when moving house)................. 78

Additional installation requirements .................................................................... 79

External condensed water outlet......................................................................... 80

Installation conditions requiring a non-return valve ....................................... 80

Arranging the drain hose ................................................................................ 81

Examples........................................................................................................ 81

4

Contents

Changing the door hinging.................................................................................. 83

Changing the hinging over ............................................................................. 83

Refitting .......................................................................................................... 88

Electrical connection .......................................................................................... 89

Technical data.................................................................................................... 90

Conformity declaration........................................................................................ 91

Data sheet for household tumble driers.............................................................. 92

Consumption data............................................................................................. 94

Settings .............................................................................................................. 95

Accessing the Settings menu.............................................................................. 95

Operation/display ............................................................................................. 96

Language  .................................................................................................... 96

Code............................................................................................................... 96

Clock display.................................................................................................. 96

Consumption.................................................................................................. 96

Memory .......................................................................................................... 97

Volume............................................................................................................ 97

Display brightness.......................................................................................... 97

Wash2Dry....................................................................................................... 97

“Display” off status......................................................................................... 98

Networking .......................................................................................................... 99

Miele@home ................................................................................................... 99

SmartGrid ....................................................................................................... 100

Remote control............................................................................................... 100

RemoteUpdate ............................................................................................... 101

Programme sequence ......................................................................................... 102

Anti-crease ..................................................................................................... 102

Cooling down temp........................................................................................ 102

Drying levels ................................................................................................... 102

Machine parameters............................................................................................ 103

Airways indicator............................................................................................ 103

Conductivity ................................................................................................... 103

Legal information............................................................................................ 104

5

Caring for the environment

Disposal of the packing mater­ial

The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.

Recycling the packaging reduces the
use of raw materials in the manufactur­ing process and also reduces the
amount of waste in landfill sites.

Disposing of your old appli­ance

Electrical and electronic appliances of­ten contain valuable materials. They
also contain specific materials, com­pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu­man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.

Please dispose of it at your local com­munity waste collection / recycling
centre for electrical and electronic ap­pliances, or contact your dealer or
Miele for advice. You are also respons­ible for deleting any personal data that
may be stored on the appliance being
disposed of. Please ensure that your
old appliance poses no risk to children
while being stored prior to disposal.

6

Warning and Safety instructions

 It is essential to read these instructions.

This tumble dryer complies with all current local and national
safety requirements. However, inappropriate use can lead to per­sonal injury and damage to property.

Read the operating instructions carefully before using the tumble
dryer. They contain important information on safety, installation,
use and maintenance. This prevents both personal injury and dam­age to the tumble dryer.

In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the tumble dryer as well as the safety instruc­tions and warnings.

Miele cannot be held liable for damage caused by non-compliance
with these instructions.

Keep these operating instructions in a safe place and pass them
on to any future owner.

Correct application

 This tumble dryer is intended for use in domestic households and

similar working and residential environments.

 This tumble dryer is not intended for outdoor use.
 It must be used only as a domestic appliance to dry items which

have been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. If us­ing dry cleaning kits, do so at your own risk, and follow the instruc­tions provided on the packaging.
Any other applications may be dangerous. Miele cannot be held li­able for damage resulting from incorrect or improper use or opera­tion.

7

Warning and Safety instructions

 This tumble dryer can only be used by people with reduced phys-

ical, sensory or mental capabilities, or lack of experience or know­ledge, if they are supervised whilst using it or have been shown how
to use it in a safe way and understand and recognise the con­sequences of incorrect operation.

Safety with children

 Children under 8 years of age must be kept away from the tumble

dryer unless they are constantly supervised.

 Children 8 years and older may only use the tumble dryer unsu-

pervised if they have been shown how to use it safely and recognise
and understand the consequences of incorrect operation.

 Children must not be allowed to clean or maintain the tumble

dryer unsupervised.

 Please supervise children in the vicinity of the tumble dryer and do

not let them play with it.

8

Warning and Safety instructions

Technical safety

 Please observe the instructions in “Installation” and the “Technical

data”.

 Before setting up the tumble dryer, check it for any externally vis-

ible damage.
Do not install or use a damaged tumble dryer.

 Before connecting the tumble dryer, ensure that the connection

data on the data plate (fuse rating, voltage and frequency) match the
mains electricity supply. If in any doubt, consult a qualified electri­cian.

 Reliable and safe operation of this tumble dryer can only be as-

sured if it has been connected to the mains electricity supply.

 The electrical safety of this tumble dryer can only be guaranteed

when correctly earthed. It is essential that this standard safety re­quirement is met. If in any doubt, please have the household wiring
system tested by a qualified electrician. Miele cannot be held liable
for the consequences of an inadequate earthing system (e.g. electric
shock).

 Do not connect the appliance to the mains electricity supply by an

extension lead, multi-socket adapter or similar. These can overheat
and are a fire hazard.

9

Warning and Safety instructions

 Faulty components must only be replaced by genuine Miele ori-

ginal spare parts. The manufacturer can only guarantee the safety of
the appliance when Miele replacement parts are used.

 Unauthorised repairs could result in unforeseen dangers for the

user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician, otherwise any
subsequent damage will not be covered by the warranty.

 The accessibility of the plug must always be ensured, in order to

disconnect the tumble dryer from the mains.

 If the electrical connection cable is faulty it must only be replaced

by a Miele authorised service technician to protect the user from
danger.

 The tumble dryer must be isolated from the electricity supply in

the event of a fault and during cleaning and maintenance.

10

Warning and Safety instructions

 Heat pump technology and refrigerant:

this tumble dryer uses a gaseous refrigerant which is condensed by
the compressor. The refrigerant, which is brought to a higher temper­ature level and liquefied by condensing, is led in a closed circuit
through the heat exchanger unit where heat exchange with the circu­lating drying air takes place.

 Damage to the tumble dryer by switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer wait for at least one hour before

switching it on.

- The humming noises caused by the heat pump during the drying
process are normal. They do not impair the efficient functioning of
the dryer.

- The refrigerant is not flammable or explosive.

- This tumble dryer contains fluorinated greenhouse gases. Her­metically sealed.

Designation of refrigerant R134a R134a R450A

Refrigerant quantity 0.48kg 0.30kg 0.31kg

Ozone-depletion potential of
refrigerant

Ozone-depletion potential of
appliance

The designation and quantity of refrigerant that apply to this tumble dryer, and
the ozone-depletion potential, can be found on the data plate (at the back of the
tumble dryer).

1430kg CO2 e 1430kg CO2 e 605kg CO2 e

686kg CO2 e 429kg CO2 e 188kg CO2 e

11

Warning and Safety instructions

 Do not block the gap between the bottom of the tumble dryer and

the floor with plinth facings, deep pile carpet etc. This would hinder a
sufficient flow of air to the dryer.

 Make sure the dryer door can be opened without hindrance after

installation.

 This tumble dryer must not be used in a non-stationary location

(e.g. on a ship).

 Do not make any alterations to the tumble dryer, unless authorised

to do so by Miele.

 This tumble dryer is supplied with a special lamp to cope with

particular conditions (e.g. temperature, moisture, chemical resist­ance, abrasion resistance and vibration). This special lamp must only
be used for the purpose it is intended for. It is not suitable for room
lighting. Replacement lamps may only be fitted by a Miele authorised
person or the Miele Service Department.

12

Warning and Safety instructions

Correct use

 Do not install the tumble dryer in a room where there is a risk of

frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and hoses.

 The maximum load for this tumble dryer is 9.0 kg (dry weight).

The maximum recommended loads for individual programmes are
given in the Programme chart.

 To prevent the risk of fire, do not connect the tumble dryer via a

controllable socket (e.g. a timer or a peak-load switch-off device).
If the drying programme is interrupted before the end of the cooling
down phase, this could cause the laundry to self-ignite.

 Warning: Do not switch the dryer off before the drying pro-

gramme has finished. If this is done, the laundry must be hung up or
spread out to cool it down.

 In many programmes, the heating phase is followed by a cooling

down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry self-ig­niting). The programme is not finished until the cooling down phase
has been completed.
As soon as the programme has finished, remove all laundry from the
drum.

13

Warning and Safety instructions

 To prevent the risk of fire, the following textiles must not be dried

in this tumble dryer:

- Items which have not been washed.

- Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other depos­its (such as cosmetics, lotions etc). If items have not been thor­oughly cleaned there is a danger that these might ignite when
heated, even after they have been removed from the dryer at the
end of the programme.

- Items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of acet­one, alcohol, benzene, petrol, kerosene, stain remover, turpentine,
wax and wax remover or other chemicals.

- Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.

When washing such heavily soiled items ensure that you use suffi­cient detergent and select a high temperature. If in doubt, wash
the items several times.

 Remove all items from pockets (e.g. lighters, matches).

14

Warning and Safety instructions

 To prevent the risk of fire, the following textiles must not be dried

in this tumble dryer:

- Items which have been cleaned using chemicals (e.g. professional
dry-cleaning agents).

- Items which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.

- Damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of it
igniting in the dryer.

 Always close the door after use. This way you will avoid the

danger of:

- Children climbing onto or into the dryer or hiding things in it.

- Pets or other small animals climbing into it.

 Do not let anyone sit or lean on the door, as this can cause the

tumble dryer to tip up.

 The fluff filters must be cleaned after every drying cycle.
 The fluff filters or the plinth filter must be thoroughly dried after

cleaning. Wet fluff/plinth filters could cause operational faults while
drying.

15

Warning and Safety instructions

 The tumble dryer must not be used without fluff filters or

- with damaged fluff filters, or

- with a damaged plinth filter.

This would cause an excessive build-up of fluff which in turn would
cause a fault.

 If the water is drained externally through the drain hose instead of

being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.

 Condensed water is not drinking water.

It can cause health problems in both people and animals if con­sumed.

 Always keep the area around the tumble dryer free of dust and

fluff.
Dust drawn into the tumble dryer can cause blockages in the heat
exchanger over time.

 The tumble dryer must not be hosed down.
 Fabric conditioner and similar products must be used according

to the instructions on the manufacturer's packaging.

16

Warning and Safety instructions

Using a fragrance flacon (optional accessory)

 Only use genuine Miele original fragrance flacons.
 The fragrance flacon must be stored in its packaging so please

make sure you retain this.

 Caution. The fragrance can leak out of the flacon. Make sure that

you always keep the flacon, or the fluff filter with the flacon inserted
in it, in a horizontal position when carrying and do not tip or place
down on any surface.

 Use an absorbent cloth to wipe up any fragrance which has

leaked out of the flacon onto the floor, the dryer or any dryer com­ponents (e.g. the fluff filter) immediately.

 If fragrance which has leaked out of a flacon: comes into contact

with the skin - wash the skin thoroughly with soap and water; comes
in contact with the eyes - rinse the eyes with clean water for at least
15minutes; is swallowed - rinse out the mouth thoroughly with
clean water. Seek medical advice in the case of contact with the
eyes or if fragrance has been swallowed.

 If fragrance which has leaked out of a flacon comes in contact

with clothing, change the clothing immediately. Wash the clothing or
any cloths used for mopping up fragrance thoroughly with plenty of
water and detergent.

 There is the risk of fire or damage to the tumble dryer if the follow-

ing instructions are not observed:

- Never refill a flacon with fragrance.

- Never use a faulty fragrance flacon.

 Dispose of an empty fragrance flacon with the household waste

and never use it for any other purpose.

 Please also observe the information supplied with the fragrance

flacon.

17

Warning and Safety instructions

Accessories

 Only use genuine Miele original spare parts and accessories with

this appliance. If non-Miele parts are used, warranty, performance
and product liability claims will be invalidated.

 The tumble dryer can be combined with a Miele washing machine

in a washer-dryer stack. The appropriate “WTV” stacking kit (avail­able to order) to match your tumble dryer and washing machine is
required.

 If you order a plinth for this tumble dryer (available from Miele as

an optional accessory - depending on country), make sure it is the
correct one.

 Miele cannot be held liable for damage caused by non-compli­ance with these Warning and Safety instructions.

18

Operating the tumble dryer

Control panel

a

sensor
To go back a level in a menu.

b

Touch display

c

Start/Stop sensor
Touching the Start/Stop sensor starts the selected programme or cancels a
programme that has already been started. The sensor flashes slowly as soon as
it is possible for a programme to be started and then lights up constantly after
the programme has started.

d

Optical interface

For service technicians.

e

 button
For switching the tumble dryer on and off. The tumble dryer switches off auto­matically to save energy. This occurs 15minutes after the end of the pro­gramme/Anti-crease phase, or after being switched on if no further selection is
made.

Touch display and sensors

The  and Start/Stop sensors and the sensors in the display react to finger tip
contact.

The touch display can be scratched by pointed or sharp objects, e.g. pens.
Only touch the display with your fingers.

19

Operating the tumble dryer

 11:02

 





Programmes Favourites Wash2Dry

Help

 11:02







Drying

assistant

Settings

Help

MobileControl



Main menu

After switching on the tumble dryer, the
main menu will appear in the display.

You can access all the important sub­menus from the main menu.

Touch the sensor control at any
time to return to the main menu. Val­ues set previously are not saved.

Main menu page 1

You can scroll to the second page of
the main menu by swiping your finger
across the display.

 Programmes

For selecting drying programmes.

Favourites

You can save up to 12 of your own cus­tomised drying programmes (see “Fa­vourites”).

Wash2Dry

A drying programme tailored to the
laundry is set in conjunction with the
connected washing machine.

Tip: To make the Wash2Dry function
visible, you have to enable it once. See
“Settings”, “Wash2Dry”.

MobileStart

With MobileStart you can operate your tumble dryer remotely with the Miele@mobile app.

The Remote control setting must be
switched on.

Touch the MobileStart sensor control and
follow the instructions in the display.

Main menu page 2

20

 Drying assistant

The Drying assistant guides you step by
step so that you can select the op­timum drying programme for your laun­dry (see “Drying assistant”).

 Settings

You can alter the tumble dryer's elec­tronics to suit changing requirements in
the Settings menu (see “Settings”).

Operating the tumble dryer

 11:02



0:00

0:00

0:00 0:00

h

h

h

h

Programmes

Cottons

DelicatesCottons

Minimum iron









Help

 11:02





OK



Extras

Gentle tumble

Freshen up

Examples on how to operate the appliance

Option lists

Programmes menu

You can scroll to the right or the left by
swiping your finger across the screen.
To do this place your finger on the
touch display and swipe it in the direc­tion you want.

The orange bar under the pictures
shows that there are further options to
choose from.

Touch a programme name to select the
drying programme.

Extras menu

Touch an Extra to select it.

The Extra will be highlighted in orange.

To deselect an Extra simply touch the
Extra again.

Activate the Extra with OK.

The display will change to the standard
display for that programme.

21

Operating the tumble dryer

OK

12 00

11 59
10 58

13 01

14 02

Clock display

11:02

2:35

 Overview



Cottons

h

 Timer  Save

Drying level

Normal

Extras

not selected











Setting numerical values

You can set numerical values in some
menus.

Enter the numbers by swiping upwards
or downwards. Place your finger on the
number that you want to change and
move your finger in the direction you
want. Use the OK sensor to accept all
set figures.

Tip: Briefly touching the orange num­bers between the two lines
the numerical keypad. Once a valid
number has been entered, the OK
sensor will be highlighted green.

will bring up

Pull-down menu

The pull-down menu can be used to
display information, e.g. about a drying
programme.

Touch the top edge of the screen in the
middle and drag down with your finger.

Help display

With some menus Help appears along
the bottom line of the display.

 Touch theHelp sensor to display the

text.

 Touch the Closesensor to return to

the previous screen.

22

Exiting a menu

 Touch the sensor to return to the

previous screen.

Entries made before this which have not
been confirmed withOK will not be
saved.

Before using for the first time

Downtime after installation

 Damage to the tumble dryer by

switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer wait

for at least one hour before switching
it on.

Protective foil and stickers re­moval

 Remove:

- The protective foil from the door

- Any stickers from the front and the lid

Please do not remove any labels
(e.g. the data plate) which are visible
when you open the door.

Miele@home

Your tumble dryer is equipped with an
integrated WiFi module.

In order to use it you need:

- a WiFi network

- the Miele@mobile app

- a Miele user account. The user ac­count can be created via the
Miele@mobile app.

The Miele@mobile app will guide you as
you connect your tumble dryer to your
home WiFi network.

- Calling up information on the operat­ing status of your tumble dryer

- Calling up information on the pro­gramme sequence of your tumble
dryer

Connecting your tumble dryer to your
WiFi network will increase energy con­sumption, even when the tumble dryer
is switched off.

Before installing the tumble dryer in
its final location, ensure the signal
strength is sufficient for your WiFi
network.

Availability of the WiFi connection

The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This can give rise to sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot be guaranteed.

Miele@home availability

The ability to use the Miele@mobile app
depends on the availability of the
Miele@home service in your country.

The Miele@home service is not avail­able in every country.

For information about availability,
please visit www.miele.com.

Once your tumble dryer is connected to
your WiFi network you can use the app,
for example, to carry the following
activities:

- Controlling your tumble dryer re­motely

23

Before using for the first time

english (AU)

english (CA)

english (GB)

english (US)

Language

deutsch

dansk



Skip

Continue

Set up “Miele@home”?



Miele@mobile App

The Miele@mobile App is available to
download free of charge from the Apple

App Store® or from the Google Play
Store™.

Switching on the tumble dryer

 Press the button.

The welcome screen will light up.

The display will guide you step by step
through the initial commissioning pro­cess.

Setting the language

You will be asked to select the language
you require for the display. It is possible
to change the language at any time via
the Settings menu.

 Scroll to the left or the right until the

language you want appears.

24

 Touch the sensor for the language

you want.

The selected language will be high­lighted in orange and the display will
change to the next setting.

Setting up Miele@home

Before using for the first time

Via WPS Via App

Which connection method do you
want to use?



OK

12 00

11 59

10 58

13 01

14 02

Clock display

 To set up Miele@home now: Touch

the Continue sensor.

Tip: To postpone setup until later:
Touch the Skip sensor. The following
message will then appear in the display:
It is possible to set up later in “Settings” /

“Miele@home”.

Confirm with OK.

 Select the connection method you

wish to use.

You will then be guided by the display
and the Miele@home app.

You will require a WPS-compatible
router for the Via WPSconnection type.

Setting the clock format

The time of day can be displayed as a
24 hour or 12 hour clock.

 Select the clock format you want and

confirm this with the OK sensor.

The display will change to the next set­ting.

Setting the time of day

This message only appears if the
tumble dryer has not yet been con­nected to a WiFi network.

The time of day is set automatically if
connection is established with a WiFi
network.

 Activate the WPS function on your

router within 2minutes.

 Place your finger on the number that

you want to change and move your
finger in the direction you want.

 Confirm with the OK sensor.

The display shows further information.

25

Before using for the first time

Continuing with commission­ing

 Please see “1. Notes on correct laun-

dry care”.

 You can then select a programme

and load the tumble dryer as de­scribed in “2. Loading the tumble
dryer” and “3. Selecting a pro­gramme”.

The procedure for using for the first
time is completed when a programme
lasting longer than one hour has been
carried out in full.

26

Energy saving tips

Energy saving tips

This dryer with heat-pump technology
is designed for energy-saving drying
cycles. However, you can save a little
more energy with the following meas­ures as the drying time is not exten­ded unnecessarily.

- Make sure your laundry is spun at the
maximum spin speed before drying.
The higher the spin speed, the
greater the savings that can be made
in energy and time during drying, e.g.
approx. 20% energy can be saved if
spun at 1600rpm instead of
1000rpm.

- Load according to the optimum
amount of laundry recommended for
the programme being used. This will
mean that the energy consumption
for the amount of laundry is at its
most economical.

- Make sure that the room temperature
is not too high. If there are other heat
producing appliances in the room in
which the dryer is located, make sure
the room is well ventilated and switch
the other appliances off, if possible.

- If possible, make use of time-vari­able, low-cost electricity tariffs. Ask
your energy supplier for information.
Your tumble dryer's delay start func­tion will be useful as you can select
when during the next 24 hours you
want drying to start automatically.

- Clean the fluff filters in the door open­ing after every drying cycle.

Please refer to “Cleaning and care” for
information on cleaning the fluff filters
and the plinth filter.

27

Energy saving tips

11:02

2:35

 Overview



Cottons

h

 Timer  Save

Drying level

Normal

Extras

not selected











Energy consumption

–– ––––––––

EcoFeedback

You can view information about the en­ergy consumption of your tumble dryer
in the pull-down menu.

The following information will appear in
the display:

- An estimate of the energy consump­tion before the programme begins.

- The actual energy consumption dur­ing the programme or at the end of
the programme.

 Open the pull-down menu.

1. Estimate

The estimated energy consumption
level will be displayed as a bar chart
before the programme starts.

2. Actual consumption

The actual energy consumption can
be viewed during the programme or at
the end of the programme.

If the energy consumption is too low, <

0.1 kWh will be displayed.

The consumption will alter as the pro­gramme progresses.

At the end of the programme, before
opening the door, you can also call up
the filter soiling level in % in the display.

Filter soiling
0% = light
50% = medium
100% = heavy
Increased soiling will cause the pro­gramme duration to increase which in
turn will increase energy consumption.

If the door is opened or the machine
has switched off automatically at the
end of the programme, the data will
revert to the estimated consumption.

Tip: You can view the consumption
data for the last drying programme and
for total consumption (see “Settings –
Consumption”).

The more bars visible, the higher the
energy consumption.

The estimate will vary depending on the
drying programme, temperature and
any extra options selected.

28

1. Notes on correct laundry care

Points to note regarding washed laundry

- When washing very heavily soiled
items ensure that you use sufficient
detergent and select a high temperat­ure. If in doubt, wash the items sev­eral times.

- Do not put soaking wet items into the
tumble dryer. Make sure your laundry
is thoroughly spun before drying. The
higher the spin speed, the greater the
savings that can be made in energy
and time during drying.

- New dark coloured garments should
be washed and dried separately from
light coloured garments to avoid the
danger of colours running and discol­ouring other garments or even plastic
components in the dryer. Dark col­oured fibres can also settle on light
coloured garments and vice versa.

- Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.

 Risk of fire due to incorrect use

and operation.
The laundry can burn and destroy

the dryer and the surroundings.
See “Warning and Safety” instruc-

tions for further information.

- Sort the laundry according to the type
of fibre and weave, size, garment
care label symbol and the drying level
required.

- Check seams and stitching to ensure
that padding and linings are intact.
This way you will avoid the danger of
fillings coming out. These could catch
fire when being dried.

- Disentangle the laundry.

- Tie together textile belts and ties.

- Fasten duvet covers and pillow cases
to prevent small items from being
rolled up inside them.

- Fasten hooks and eyes.

- Leave jackets open and undo any
long zips so that textiles dry evenly.

Preparing the laundry before drying

 Damage due to foreign objects

which were not removed from the
laundry.

Foreign objects can melt, burn, or
explode.

Ensure that any foreign objects, e.g.
detergent dispensing balls, lighters,
etc. have been removed from the
laundry.

- Sew in or remove underwiring from
bras.

- If necessary, reduce the size of the
load for these types of fabric. Easy
care fabric tends to crease more, the
larger the load. This is particularly the
case for garments made from very
fine weave fabric, such as shirts or
blouses.

29

1. Notes on correct laundry care

Drying

Tip: See the “Programme chart”.

It lists all programmes and their max­imum load.

- Always observe the maximum recom­mended load for each programme.
This will mean that the energy con­sumption for the amount of laundry is
at its most economical.

- Down-filled garments have linings
which have a tendency to shrink, de­pending on the quality of the item.
Only use the Pre-ironing programme
for these textiles.

- Pure linen should only be tumble
dried if it is specified as suitable on
the care label. The surface of the fab­ric may otherwise become rough.
Only use the Pre-ironing programme
for these textiles.

- Woollens and wool blends are sus­ceptible to becoming matted or
shrinking. Only use the Woollens
handcare programme for these tex­tiles.

- Jersey fabrics (e.g. T-shirts, under­wear) tend to shrink when they are
washed for the first time. Do not
overdry these fabrics to prevent fur­ther shrinking. Buy jersey garments
that are one or two sizes bigger.

Care label symbols

Drying



Normal/higher temperature

Low temperature*



* Select Gentle tumble

Do not tumble dry



Ironing

Hot iron

Cool iron

Select the correct drying level

- Extra dry for hard wearing and very
thick fabrics.

- Normal + if you want to fold the laun­dry after drying and put it away.

- Normal for textiles that can shrink. Or
for light cotton or jersey textiles.

- Slightly dry for particularly delicate
garments that you wish to line dry af­terwards.

- Hand iron/ or Machine iron if you
want to iron the laundry after drying.

Warm iron

Do not iron

- With fabrics that are particularly heat­sensitive or susceptible to creasing,
reduce the drying load and select
Gentle tumble.

30

2. Load the tumble dryer

Loading the laundry

Preventing textile damage.
Before loading, read chapter “1.

Notes on correct laundry care”.

 Check that the drum is empty. Re-

move any items that might be block­ing the drum.

 Unfold the laundry and load loosely

into the drum.

2 positions for inserting fragrance flacons

The “Fragrance flacon” chapter de­scribes how to use the fragrance
flacon.

If you are not using a fragrance flacon:
push the tab down completely (see ar­row) so that the socket is closed. Oth­erwise, lint will accumulate here.

Close the door

Do not overload the drum. Overload­ing can cause unnecessary wear and
tear to the laundry and give a disap­pointing drying result. It can also
cause more creasing.

This can result in damage to the
laundry.

When closing the door, make sure
that laundry does not get trapped in
the door opening.

 Shut the door with a gentle swing.

31

3. Selecting a programme

 11:02



0:00

0:00

0:00 0:00

h

h

h

h

Programmes

Cottons

DelicatesCottons

Minimum iron









Help

11:02

2:35

 Overview



Cottons

h

 Timer  Save

Drying level

Normal

Extras

not selected



Switching on the tumble dryer

 Touch the  sensor to switch the

tumble dryer on.

Selecting a programme

There are various ways to select a pro­gramme.

 Touch the Programmes sensor.

 Scroll to the right of the display until

the programme you want appears.

 Touch the sensor for that programme.

The display will then change to show
the Overview menu.

There are 4 further ways of selecting a
programme.

1. The Wash2Dry function

2. Favourites

3. The Drying assistant

4. MobileStart

Tip: In the pull-down menu, you can
menu the maximum recommended load
for the selected programme.

32

4. Selecting programme settings

11:02

2:35

 Overview



Cottons

h

 Timer  Save

Drying level

Normal

Extras

not selected



 11:02



Drying level

Machine iron Hand iron 

Normal

Hand iron  Slightly dry Normal plus

11:02

0:20

 Overview



Timed drying Warm air

h

 Timer  Save

Extras

not selected



h

Duration

0:20

Programme settings

Selecting the drying level for a drying level programme

Cottons, Minimum iron, Delicates, Bed
linen, Automatic, Express, Shirts,
Denim, Steam care, Sportswear, Outer­wear, Pre-ironing

The pre-set drying level for the pro­gramme can be changed if required.

 Touch the Drying level sensor.

Any drying level can be selected for the
Cottons, Express, and Bed linen pro­grammes. A more limited range is avail­able when using the other programmes.

When selecting the Steam care pro­gramme, you must make sure that the
condensed water container has been
filled as described in these operating
instructions (see “Condensed water
container”).

Other programmes and timed drying programmes

Cottons , Woollens handcare, Silks
handcare, Proofing, Standard pillows,
Large pillows, Cottons hygiene

The drying result is preset by the dryer
and cannot be altered.

Warm air, Cool air, Basket programme,
DryFresh

You can change the duration in 10­minute increments.

 Scroll in the display until the drying

level you want appears.

 Touch the sensor for the drying level.

Cool air: 20min–1:00h
Warm air: 20min–2:00h
Basket programme: 40min–2:30h
DryFresh: 1:00 – 2:00h

 Touch the Durationsensor control

(only in Warm air programme).

33

4. Selecting programme settings

OK

00 20

02

Reset



Duration

40

01 30

02 40

5001

11:02



h

11:02

2:35

 Overview



Cottons

h

 Timer  Save

Drying level

Normal

Extras

not selected



 11:02





OK



Extras

Gentle tumble

Freshen up

Selecting an extra option

 Place your finger on the number that

you want to change and move your
finger in the direction you want.

- Warm air

 Confirm with the OKsensor control.

- Cool air, Basket programme, Dry­Fresh

 Touch the Start/Stopsensor control.

The programme starts.

 Touch the Extras sensor.

 Touch the sensor for the extra option

you want.

34

Tip: Touching the sensor for an extra
option again allows you to deselect it.

You can only select one extra, as they
cannot be combined with one another.
See “Extras” for descriptions.

 Confirm with the OK sensor.

The symbol for the selected extra is dis­played.

5. Starting a programme

11:02 Status



Cottons

Time left

Machine iron

 Perfect Dry



h1:42

Add laundry

Starting the programme

The programme can be started when
the Start/Stop sensor control is flashing
on and off.

 Touch the Start/Stop sensor control.

The Start/Stop sensor control lights up
constantly.

Drying and the programme duration re-

maining will light up in the display.

The laundry will be cooled down shortly
before the end of the programme.

Tip: In the pull-down menu you can
view the selected drying level or dura­tion and the energy consumption.

With programmes with a selectable dry­ing level, PerfectDry calculates the resid­ual moisture present in the laundry to
ensure precise drying results. If a small
load or dry laundry is placed in the
dryer, it is dried/aired for a preset dura­tion.

- Solid point  when the drying level is

reached

The time left for the drying level pro­grammes can vary or “jump”. It de­pends on the load quantity, type of
laundry, residual moisture in the laundry
or water hardness. PerfectDry continu­ally adapts, constantly increasing the
accuracy of the time left.

To prevent laundry wearing out
avoid overdrying it.

Energy savings

After 10minutes, the indicators dim and
the Start/Stop sensor starts flashing.

 Touch the Start/Stop sensor to switch

the indicators on again (this does not
have any effect on a running pro­gramme).

The drum lighting switches off once the
programme has started.

Adding laundry

You can add laundry items after the
programme has started.

 Follow the description in “Changing

the programme sequence – Adding or
removing laundry”.

The PerfectDry display will only light up
with programmes with selectable drying
levels:

- Hollow point  after a programme
has started

The drying level reached will still be
shown later on.

35

6. End of programme - unload the drum

End of programme

The programme is finished when Finish/

Anti-crease appears in the display. The

Start/Stop sensor will no longer light up.

The dryer will switch off automatically
15minutes after the end of the Anti­crease phase (with programmes without
an Anti-crease phase it will switch off
15minutes after the end of the pro­gramme).

Unloading the drum

Only open the door when the drying
process has finished. Otherwise, the
laundry will not be properly dried
through and cooled down.

 Pull the door open at the side with

the orange marker.

 Remove the fluff from the 2 fluff filters

in the door opening: see “Cleaning
and care – Fluff filters”.

 Shut the door with a gentle swing.
 Empty the condensed water con-

tainer.

Tip: The condensed water can be used
for the Steam care programme. See
“Cleaning and care - Preparing the con­densed water container for the Steam
care programme”.

We recommend that you drain the con­densed water externally through the
drain hose when drying a full load using
the Cottons and Cottons  pro­grammes. This will avoid having to
empty the condensed water container
during the programme.

Drum lighting

The inside of the drum lights up so that
you don't forget any items of laundry
when you empty it.
The drum lighting switches off automat­ically (energy saving).

 Remove the laundry.

Items left in the dryer could be dam­aged by overdrying when the dryer is
used the next time.

Always remove all items from the
drum.

 Touch the  sensor to switch the

tumble dryer off.

36

Tip: To switch the lighting on again,
open the pull-down menu from the
overview menu and then touch the 
sensor.

Programme chart

All weights marked with * are based on the weight of dry laundry.

Cottons max.9kg*

Extra dry, Normal plus, Normal, Slightly dry

Use for Single and multi-layered cotton items. For example, T-shirts, under-

wear, baby clothes, workwear, jackets, covers, aprons, overalls,
hand towels, bath towels, bathrobes and flannelette/bed linen.

Tip - Select Extra dry for multi-layered and very thick fabrics.

- Do not use Extra dry for jersey fabrics (e.g. T-shirts, underwear,
baby clothes) because they can shrink.

Hand iron, Hand iron, Machine iron

Use for All cotton or linen fabrics requiring further processing. For example,

table linen, bed linen or starched laundry.

Tip To prevent laundry from drying out, it should be rolled up until you

are ready for ironing.

Cottons  max.9kg*

Use for Cotton items such as those described under Cottons Normal with

normal residual moisture.

Note - Items are dried to a Normal level only in this programme.

- The Cottons  programme is the most energy-efficient for dry­ing cotton items with normal residual moisture levels.

Note for
test insti­tutes

Minimum iron max.4kg*

Normal plus, Normal, Slightly dry, Hand iron, Hand iron

Use for Minimum iron fabrics made of synthetic, cotton or mixed fibre. For

- The Cottons programme is the test programme in accord­ance with Regulation 392/2012/EU for energy labelling, measured
in accordance with EN61121.

- With the Cottons and Cottons  programme settings, drain the
condensed water externally through the drain hose.

example, workwear, overalls, pullovers, dresses, trousers and table
linen.

37

Programme chart

Delicates max.2.5kg*

Normal plus, Normal, Slightly dry, Hand iron, Hand iron

Use for Delicate items with the  symbol on the care label made of syn-

thetic fibre, mixed fibre, rayon and easy care cotton. For example,
shirts, blouses, lingerie and appliquéd garments.

Tip The load should be reduced further for a particularly crease-free dry-

ing process.

Bed linen max.4kg*

Extra dry, Normal plus, Normal, Slightly dry, Hand iron, Hand iron, Ma­chine iron

Use for Bed linen, pillowcases

Automatic max.5kg*

Normal plus, Normal, Slightly dry, Hand iron, Hand iron

Use for Mixed loads of garments suitable for the Cottons and Minimum iron

programmes.

Woollens handcare max.2kg*

Use for Woollen garments and fabric containing wool blends, e.g. pullovers,

cardigans, tights.

Note - Wool and wool blend items are only fluffed up; they are not dried

completely.

- Remove the garments as soon as the programme has finished.

Silks handcare max.1kg*

Use for Silk garments which are suitable for drying in the tumble dryer, e.g.

blouses and shirts

Note - This programme reduces creasing. Items are not dried completely

by this programme.

- Remove the garments as soon as the programme has finished.

Express max.4kg*

Extra dry, Normal plus, Normal, Slightly dry, Hand iron, Hand iron, Ma­chine iron

Use for Garments that can be dried in the Cottons programme.

Note The programme duration is shorter.

38

Programme chart

Shirts max.2kg*

Normal plus, Normal, Slightly dry, Hand iron, Hand iron

Use for All shirts and blouses.

Denim max.3kg*

Normal plus, Normal, Slightly dry, Hand iron, Hand iron

Use for All denim garments, e.g. jackets, jeans, shirts and skirts.

Steam care max.1kg*

Normal, Hand iron

Use for - All items made of cotton or linen.

- For minimum iron items made of cotton, mixed or synthetic fibre.
For example, cotton trousers, anoraks and shirts.

Tip - For dampening items before ironing.

- For smoothing items that are creased.

- Select Hand iron if the items are to be ironed after drying.

Note - At the beginning of the programme, the condensed water collec-

ted in the condensed water container is sprayed into the drum via
a spray jet. The condensed water container must therefore be
filled with water to at least the –min– marker.

- You may just be able to hear the water as it is being sprayed into
the drum.

Sportswear max.3kg*

Normal plus, Normal, Slightly dry, Hand iron, Hand iron

Use for Sportswear which is suitable for drying in a tumble dryer.

39

Programme chart

Basket programme max. load for basket 3.5kg

Note - This programme may only be used with the Miele tumble dryer

basket TRK 555 (optional accessory) fitted.

- You must follow the operating instructions for the tumble dryer
basket.

- Make sure that the item (bag, boot, etc.) does not touch the drum:
the tumble dryer drum will rotate, causing damage to the tumble
dryer basket and drum if it is incorrectly loaded.

Fabric
type/Items

Outerwear max.2.5kg*

Normal, Hand iron

Use for Outerwear which is suitable for tumble drying.

Proofing max.2.5kg*

Use for Microfibre fabrics, skiwear, outdoor wear, fine, close-weave cotton

Note - Items are dried to a Normal level only in this programme.

Use this programme to dry or air items which are suitable for drying
in a tumble dryer but which are not suitable for drying using mech­anical action.

garments (poplin), and table linen which are suitable for drying in a
tumble dryer.

- This programme includes a proofing agent fixing phase.

- Only use proofing agents which are stated by the manufacturer as
being “suitable for use on membrane textiles”. These agents con­tain fluorochemical compounds.

- Do not dry items which have been treated with proofing agents
containing paraffin. Fire hazard.

40

Programme chart

Warm air max.9kg*

Use for - Multi-layered fabric whose layers have different drying character-

istics, e.g. jackets, pillows, sleeping bags and other voluminous
items.

- For drying individual items, e.g. bath towels, bathing costumes
and tea towels.

Tip Do not select the longest drying time to start with. Check the items

as you are drying them to find the optimum time.

Cool air max.9kg*

Use for Any item which only needs airing.

Standard pillows

Large pillows

Use for Pillows suitable for drying in a tumble dryer, with feather, down or

synthetic fillings.

Tip Items are dried to a Normal level only in this programme.

Note - Feathers have the property of developing a significant odour when

they are warm. Allow bedding to air outside the dryer after tumble
drying.

- Pillows can still feel damp after being dried. You can use this pro­gramme several times until the pillow feels dry.

Cottons hygiene max.4kg*

Use for Cottons and linen fabric which will be in direct contact with the skin,

e.g. underwear, baby clothes, bed linen, towelling.

Note In this programme, the items will be dried to Normal level with a

temperature that is constant over an extended period. This temper­ature holding time kills off micro-organisms such as germs or dust
mites and reduces allergens in the laundry. Therefore, this pro­gramme should not be interrupted as this would prevent the micro­organisms from being killed off.

1–2 pillows 40x80cm or

1 pillow 80x80cm

41

Programme chart

Pre-ironing max.1kg*

Normal, Hand iron

Use for - Cotton and linen fabric.

- For minimum iron items made of cotton, mixed or synthetic fibre.
For example, cotton trousers, anoraks and shirts.

Tip - This programme smoothes out creasing caused during the spin

cycle in the washing machine.

- This programme is also suitable for dry fabrics.

- Please remove the garments as soon as the programme has fin­ished.

DryFresh max.9kg*

Use for Any item which only needs airing.

Note You can reduce or eliminate unwanted odours in clean, dry textiles.

Use this programme in conjunction with the DryFresh fragrance
flacon (optional accessory1).

1

Insert fragrance flacon and set the intensity: see “Fragrance flacon”

42

Extras

The drying programmes can be aug­mented with various extra options.
The table lists the selection options.

Gentle tumble

Delicate fabric (with the  symbol on
the care label, e.g. acrylic garments) is
dried at a lower temperature. The pro­gramme duration is longer.

Freshen up

You can use the Freshen up option to
help remove or reduce odours in clean
(dry or damp) clothing.

The drying air is heated for a specific
length of time. After this, the garments
are aired to the Normal drying level
without any more heat being added.
The drying level cannot be altered.

The option will be more effective if you
dampen the garments a little before­hand, use a fragrance flacon and re­duce the load. Please note that odours
will not be removed as effectively from
parts of garments made of synthetic
fibres.

43

Extras

Drying programme overview - Extras

Freshen up

Cottons  – –

Cottons X X

Minimum iron X X

Delicates – 

Bed linen – –

Automatic – X

Woollens handcare – –

Silks handcare – –

Express – –

Shirts X X

Denim X X

Steam care – –

Sportswear – X

Basket programme – –

Outerwear – 

Proofing – –

Timed drying Warm air – X

Timed drying Cool air – –

Standard pillows
Large pillows

Cottons hygiene – –

Pre-ironing – 

DryFresh – –

1

– –

Gentle tumble

1

1

= these Extras cannot be combined

X = can be selected
– = cannot be selected

 = automatically selected

44

Wash2Dry

Function

Once the programme has come to a
proper end, the Miele washing ma­chine transfers the programme data
via the router to which the networked
tumble dryer is also connected, as
well as transferring it to the Miele
Cloud.
The tumble dryer automatically sets a
drying programme tailored to the laun­dry based on the transferred pro­gramme data.

All you need to do is start the drying
programme once you have loaded the
tumble dryer. No further programme
settings are required on the tumble
dryer.

The drying programme must be star­ted within 24 hours of the end of the
wash programme. The data will be
kept available for the tumble dryer
during this period, but will be overwrit­ten when a new wash programme
ends.

Tip: Do not disconnect the tumble dryer
from the network. The programme data
transferred by the washing machine will
be received by the tumble dryer as
soon as you select Wash2Dry.
If you have disconnected the appliance
from the network beforehand, this will
cause a delay in receiving the data.

Requirements for use

In order to use the Wash2Dry function, the Miele washing machine and tumble dryer must be networked using Miele@home services.

Tip: Set up Miele@home as described
in “Before using for the first time”.

Tip: You can select the Wash2Dry func-
tion in the main menu.
To make the Wash2Dry function visible,
you have to enable it once. See “Set­tings”, “Wash2Dry”.

Selecting the
Wash2Dry function

Please wait lights up in the display of

the tumble dryer while the wash pro­gramme is running.

Once the washing machine programme
has come to a proper end, the drying
programme tailored to the laundry will
be displayed.

 Once the wash cycle has ended,

place the clean laundry in the tumble
dryer.

 To start the programme, all you need

to do is press the Start/Stopsensor
control on the tumble dryer.

The programme will not start on this
tumble dryer after washing delicate
textiles (e.g. curtains) in special wash
programmes.

45

Favourite programmes

To create a Favourite pro­gramme

You can save your own customised
programmes under names of your
choice.

There are 2 ways to create a Favourite
programme.

Option 1

 The main menu must be visible in the

display. Touch the Favourites sensor
control.

The display will change to show the Fa­vourites menu.

 Touch the Create sensor control.
The display will change to the Create Fa-

vouritesmenu.

 Select the programme you want to

use.

 Select all the programme settings you

want.

To enter a name

It is best to select short, memorable
names.

 Touch the letters or characters you

want.

 Confirm with the Save sensor.

The programme will then be saved to
the Favourites programme list.

To change a Favourite programme

You can rename, delete or move a Fa­vourite programme.

 Select the Favourites sensor control

from the main menu.

 Touch the Favourite programme that

you wish to change until the context
menu opens.

 Select Rename, Delete or Move.

 Then select Save.
 Enter a name.

Option 2

You can save a programme which has
been selected as a Favourite pro­gramme before you start it.

 Before the programme starts, touch

the  Save sensor.

 Enter a name.

If 12 Favourites have already been
saved, the Create or  Save sensor
will not be visible. Delete an existing
Favourite if you wish to create a new
one.

46

Drying assistant

OK

Purpose

Drying

Proofing/

Reactivation

Smooth damp

items

Smooth dry

items



11:02



OK

Textiles



Shirts





Denim



T-shirts

Blouses



11:02

The Drying assistant helps you when
drying a wide variety of items. The
tumble dryer will use the list of items to
put together a suitable drying pro­gramme.

 Scroll to the second page in the main

menu.

 Touch the Drying assistant sensor.

A list will open. The drying purpose is
grouped into different areas.

Tip: Touch the  sensor to find out
more about each purpose.

 Touch the sensor for the Purpose

which matches your drying require­ment.

A list of items will appear.

 Touch the appropriate sensor for your

item of laundry.

The item selected will be highlighted or­ange. You can select several items.

With some items, helpful information
will also appear in the display when
they are selected.

 Confirm with the OK sensor.
 Follow the instructions in the display.

A summary of the selected parameters
will then appear in the display.

 Confirm with the OK sensor or select

change if you would like to make any
changes.

The programme which has been
tailored to your laundry is ready to start.

Tip: You can add individual programme
settings, e.g. Extras before you start the
programme.

47

Timer

The timer can be used to set the time
you wish a programme to finish or start
at. The programme start can be delayed
by up to 24 hours.

Setting the timer

 Touch the  Timer sensor.
 Select the Finish at or Start at option.
 Set the hours and the minutes with

the OK sensor.

Changing the timer

The selected timer can be changed be­fore the programme starts.

 Touch the or  sensor.
 Change the specified time and con-

firm with the OK sensor.

Deleting the timer

The selected timer can be deleted be­fore the programme starts.

 Touch the or  sensor.

Starting the timer

 Touch the Start/Stop sensor.

The time until the programme starts will
appear in the display.

After the programme has started, the
selected delay start time can only be
changed or cancelled by interrupting
the programme.

The programme can now be started.
 Touch the Start immediately sensor.

Adding laundry during ongoing delay start period

 Follow the description in “Changing

the programme sequence – Adding or
removing laundry”.

With a longer delay start time, the drum
will rotate occasionally to untangle the
laundry. This is not a fault.

The selected delay start time will ap­pear in the display.

 Touch the delete sensor.
 Confirm with the OK sensor.

The selected delay start time is can­celled.

48

Timer

SmartStart

The SmartStart function lets you
define a time period during which your
tumble dryer will start automatically.
The appliance will start on receipt of a
signal, e.g. from your energy supplier,
that indicates that the electricity tariff
is particularly economical.

This function is active when the
SmartGrid setting is switched on.

The timeframe can be defined between
1minute and 24 hours. During this
period, the tumble dryer waits for the
signal from the energy supplier. If no
signal is sent during the defined period,
the tumble dryer starts the drying pro­gramme.

Setting the timeframe

If you have activated the SmartGrid
function in Settings, SmartStart or
SmartFinish will appear in the display
instead of Start at or Finish at when
you touch the  Timer sensor (see
“Settings – SmartGrid”).

The procedure for setting this is the
same as for setting the time for Delay
start.

 Now set the time you want and con-

firm with the OK sensor.

 Touch the Start/Stop sensor to start

the programme with SmartStart.

The selected programme will start auto­matically, as soon as the energy pro­vider has sent the signal, or the latest
calculated start time has been reached.

The procedure for changing or delet­ing the SmartStart function is the
same as described for the Delay start
function.

49

Changing the programme sequence

Changing a programme once it has started

You cannot change to another pro­gramme once a programme has started
(this prevents unintentional alterations).

You will need to cancel the current pro­gramme before you can select a new
one.

Cancelling a programme

 Touch the Start/Stop sensor.

The following will appear in the display:
Cancel the programme?

 Select Yes.

The following appears in the display:

Programme cancelled.

 Open the door.

Selecting another programme

 Close the door.
 Select the programme you want.
 Touch the Start/Stop sensor.

Adding or removing laundry

You have forgotten something but the
programme is already running.

 Touch the Add laundrysensor control.

Add laundry and The door can be opened.

appears in the display. The Start/Stop
sensor control flashes slowly.

 Open the door.
 Add or remove laundry items.
 Close the door.
 Touch the Start/Stopsensor control.

The programme continues.

Exceptions when adding laundry

In some cases, for example, during
the cooling phase or the Proofing pro­gramme, it is not possible to add laun­dry items.

In exceptional cases, the door can be
opened while the programme is run­ning.

50

Condensed water container

Emptying the condensed water container

The condensed water is collected in
the condensed water container.
Empty the condensed water container
after every drying programme.

When the maximum level in the con­densed water container is reached, the
following message will light up in the
display: Empty the container or check the

drain outlet

To delete the message:
 Open and close the door, with the

tumble dryer switched on.

 Damage to the door and the fas-

cia panel when removing the con­densed water container.

The door and the fascia panel can
sustain damage.

Always close the door completely.

* This does not apply to right-hand
hinged models.

 To prevent water from running out,

keep it in a horizontal position when
carrying it. Hold the condensed water
container by the front panel and at
the back.

 Empty the condensed water con-

tainer.

 Replace the condensed water con-

tainer in the dryer.

Condensed water can cause health
problems in people and animals.

Do not drink condensed water.

 Remove the condensed water con-

tainer.

The condensed water can be used for
the Steam care programme. The con­densed water container must be filled
to use this programme. See the follow­ing section.

51

Condensed water container

Preparing the condensed wa­ter container for the Steam
Care programme

During the Steam Care programme,
the condensed water collected in the
condensed water container is sprayed
into the drum via a spray jet. The con­densed water container must therefore
be filled with water to at least the
–min– marker. Otherwise, this could
cause a fault.

The –min– marker is at the front left­hand side of the container.

1 spout, 2 rubber seal

 Pour the water in through the rings on

the spout 1.

The spray jet in the door opening can
suffer a blockage.

It should only be filled with clean wa­ter. The water must not contain any
fragrance, detergent, or other sub­stances.

Make use of the condensed water
which collects during the drying pro­cess.

Filling the empty condensed water container

 You can fill the condensed water con-

tainer with commercially available
condensed water (ironing water).

You should only use tap water in excep­tional circumstances. If tap water is
used frequently, the spray jet in the
door opening can become calcified.

52

Check the rubber seal from time to time.

If tap water is used frequently, white
limescale deposits can build up on the
rubber seal 2.

 Use a damp cloth to carefully remove

any limescale deposits from the rub­ber seal 2.

Fragrance flacon

FragranceDos

Fragrance flacons (optional accessor­ies) can be used to give your laundry a
pleasant scent.

This dryer has 2 places for inserting
fragrance flacons. This gives you a
choice of how to use them.

- You can use both positions if you
wish to change from one scent to an­other. You can close the fragrance
flacon that you are not using.

- Use both positions if you want a more
intense scent of the same fragrance.
Or if you wish to conveniently switch
between a scent for normal laundry
and DryFresh to freshen up your laun­dry.

- Use one socket only if you only want
to use the one fragrance.

 Risk of fire and damage to health

if fragrance flacons are used incor­rectly.

The leaked fragrance can damage
your health if it comes into contact
with your body. Leaked fragrance
can cause fire.

Before using a fragrance flacon,
please read “Warnings and safety
notes”, “Using the fragrance flacon
(optional accessory)”.

Removing the protective seal from the fragrance flacon

Only hold the fragrance flacon as il­lustrated. Do not hold it at an angle
or tip it as the fragrance will leak out
of it.

 Hold the fragrance flacon securely so

that you do not open it by mistake.

 Pull off the protective seal.

53

Fragrance flacon

Inserting the fragrance flacon

 Open the door of the tumble dryer.

The fragrance flacon is inserted in the
upper fluff filter. They can be fitted on
the left and the right hand side next
the opener.

 Insert the fragrance flacon into the

socket as far as it will go.

 Open the cover using the tab until the

tab is right at the top as shown.

To prevent the accumulation of fluff,
the cover of the unused socket must
remain closed.

Push the tab of the cover to the bot­tom (see arrow), until you hear it click
into position.

54

Markers  and  must line up with
one another.

 Turn the outer ring  clockwise a

little.

The fragrance flacon can slip out.
Turn the outer ring in such a way that

markers  and  line up.

Opening the fragrance flacon

Before drying, you can select the in­tensity of the fragrance.

Fragrance flacon

grance will also be noticeable in the
room air during the process. The Cool
Air programme will not generally apply
fragrance.

Closing the fragrance flacon

After drying, the fragrance flacon should
be closed to prevent the fragrance from
escaping needlessly.

 Turn the outer ring counter-clockwise

until marker b is in position _.

 Turn the outer ring clockwise: the fur-

ther you open the fragrance flacon,
the more intense the fragrance.

Damp laundry and longer drying dura­tions with sufficient heat transfer are
needed for the fragrance to be released
into the laundry effectively. The fra-

If you wish to dry without the fra­grance occasionally: remove the fra­grance flacon and store it in its original
packaging.

Replace the fragrance flacon with a
new one when the intensity of the fra­grance is no longer sufficient.

55

Fragrance flacon

Removing/replacing the fra­grance flacon

 Turn the outer ring counter-clockwise

until markers a and b line up.

Fragrance can leak.
Do not lay the fragrance flacon

down.

 Replace the fragrance flacon with a

new one.

When not in use, you can store the fra­grance flacon in its original packaging.

Fragrance flacons are available to or­der from Miele or online at www.miele­shop.com.

56

- If you are keeping the fragrance
flacon in its original packaging, do
not store the packaging upright on its
edge or upside down. Otherwise, the
fragrance will leak out.

- Always store in a cool, dry place
away from direct sunlight.

- When purchasing new fragrance flac­ons, only remove the protective seal
just before use.

Cleaning and care

Fluff filters

This tumble dryer has 2 fluff filters in
the door opening: the upper and lower
fluff filters trap fluff produced during
the drying process.

Clean the fluff filters after each drying
programme. This prevents an exten­sion of the programme duration.

Also clean the fluff filters when the fol­lowing message lights up in the dis­play: Clean the fluff and plinth filters. See

the operating instruction manual for more
information.

To delete the message:
 Confirm with OK.

Removing the fragrance flacon

The intensity of the fragrance will be di­minished if the fluff filters and the plinth
filter are not cleaned.

 Remove the fragrance flacon. See

“Fragrance flacon”, “Removing/repla­cing the fragrance flacon”.

Removing visible fluff

Tip: You can also use a vacuum cleaner

so that you can remove the fluff without
touching it.

 Open the door.

 Pull the upper fluff filter forwards to

remove it.

 Remove the fluff (see arrows).

57

Cleaning and care

 Remove the fluff from the filter sur-

face of all the fluff filters and the per­forated laundry deflector.

 Push the upper fluff filter back into

position until it clicks.

 Close the door.

Cleaning the fluff filters and air flow openings thoroughly

If the drying duration has become
longer or the surface of the filters is
visibly compacted with fluff, you
should carry out the following cleaning
procedure.

 Remove the fragrance flacon. See

“Fragrance flacon”.

 Pull the upper fluff filter forwards to

remove it.

 Turn the yellow dial on the lower fluff

filter in the direction of the arrow (until
it reaches the stop position).

 Hold the dial and pull the fluff filter

forwards to remove it.

58

 Use a vacuum cleaner with a long

crevice nozzle attached to remove
any visible fluff from the upper air
flow openings.

Finally, clean the fluff filters with water.

Cleaning and care

Cleaning the fluff filters with water
 Wipe the smooth plastic surfaces of

the fluff filters with a damp cloth to
clean them.

 Flush the filters through under warm

running water.

 Shake the fluff filters thoroughly and

then dry them carefully.

Ensure the filters are dry before re­placing them. Wet filters could cause
operational faults.

 Push the lower fluff filter in com-

pletely and lock it with the yellow dial.

 Push the upper fluff filter in com-

pletely.

 Close the door.

59

Cleaning and care

Cleaning the plinth filter

Clean the plinth filter when the pro­gramme duration is longer than usual
or if the following message lights up in
the display: Clean the fluff and plinth fil-

ters. See the operating instruction manual
for more information.

To delete the message:
 Confirm with OK.

Removing the plinth filter

 Pull the plinth filter out by the handle.

The right-hand guide pin comes out
when the plinth filter is removed. The
guide pin prevents the access panel
from closing without the plinth filter.

 Press the round, indented area on the

heat exchanger access panel to open
it.

The panel will spring open.

60

Cleaning the plinth filter

 Pull the handle out of the plinth filter.
 Clean the plinth filter thoroughly un-

der running water.

 Squeeze the plinth filter very carefully

several times as you rinse it.

 Rinse the plinth filter until all visible

residues have been removed.

 Use a damp cloth to remove any fluff

from the handle.

Cleaning and care

 Fit the plinth filter back on the handle.

Make sure it is the correct way round.

 Damage caused by a damaged

or worn plinth filter.
The heat exchanger will clog up if the

plinth filter is not in good working or­der. This can cause a fault.

Check the plinth filter following the
instructions provided in “Problem
solving guide – Replacing the plinth
filter”. Replace the plinth filter if ne­cessary.

 Push the plinth filter in completely.

This will push in the right-hand guide
pin at the same time.

61

Cleaning and care

Cleaning the plinth filter access panel

 Use a damp cloth to remove any fluff.

Make sure that you do not damage
the rubber seal when doing this.

 Close the heat exchanger access

panel.

 Damage or ineffective drying if

drying takes place without a plinth
filter or when the heat exchanger ac­cess panel is open.

An excessive accumulation of fluff
can damage the tumble dryer. If the
system is not leak-tight, this can
make drying ineffective.

Only operate the tumble dryer with
the plinth filter fitted and the heat ex­changer access panel closed.

Cleaning the dryer

Disconnect the tumble dryer from the
electrical supply.

 Damage due to the use of un-

suitable care products.
Unsuitable care products could dam-

age plastic surfaces and other parts.
Do not use any solvents, abrasive

cleaners, glass cleaners, or all-pur­pose cleaners.

 Clean the tumble dryer and the seal

on the inside of the door with a
slightly damp soft cloth and a mild
solution of washing-up liquid and wa­ter.

 Dry all parts with a soft cloth.

62

Problem solving guide

Many malfunctions and faults that can occur in daily operation can be easily
remedied. Time and money will be saved because a service call will not be
needed.

The following guide may help you to find the reason for a malfunction or a fault,
and to correct it.

The display indicates the following messages or faults

Message Cause and remedy

000 lights up after

switching on.

Finish/Cooling down The laundry will be cooled down at the end of the

 Fault F. If restart

fails, call Service.

lights up after a
programme has
been cancelled.

 Fill the condensate

container with water

 Please open and

close the door

Access via a code has been activated.
 Enter the code and confirm the entry. Deactivate

the code if you do not wish this message to ap­pear in the display the next time the machine is
switched on.

programme.
 Either remove the laundry and spread it out to cool

down or leave it in the tumble dryer to cool down
during the cooling phase.

There is no obvious cause.

 Switch the tumble dryer off and then on again.
 Start a programme.

If the programme terminates again with the same er­ror message, then there is a fault. Contact Miele Ser­vice.

This is to remind you that water is taken from the
condensed water container when the Steam care pro­gramme is being used. The condensed water con­tainer must be filled with water to at least the –min–
marker.

 Fill the condensed water container as described

under “Condensed water container”.

To switch off the message:
 Confirm with OK.

This is to remind you to load the laundry when the

Steam care programme is selected.

 Load the laundry in the drum.

63

Problem solving guide

Message Cause and remedy

 Clean the fluff and

plinth filters. See the
operating instruction
manual for more in­formation. lights up

at the end of a
programme.

 Clean the fluff filter.

Check the airways.

lights up after a
programme has
been cancelled.

The tumble dryer is not working correctly or econom­ically. Possible causes could be clogging caused by
fluff or detergent residue.

 Please see “Cleaning and care” for notes on clean-

ing.

 Clean the fluff filters.
 Also check the plinth filter and clean it if neces-

sary.

 To switch off the message: confirm OK.
You can influence when the Clean the fluff and plinth fil-

ters. See the operating instruction manual for more inform­ation. message lights up.

 To do this, follow the instructions in “Airways indic-

ator – Settings”.

The system has been clogged by fluff or detergent
residue.

 To switch off the message: confirm OK.
 Clean all fluff filters and the plinth filter.

Please see “Cleaning and care” for notes on clean­ing.

 Check that the fluff filters and the plinth filter are

free from damage and in good working order.

If all of the fluff filters are damaged, out of shape or
can no longer be cleaned, they must be replaced.
“Problem solving guide – Replacing the plinth filter”
contains information about when a plinth filter that is
no longer in good working order has to be replaced.

64

Message Cause and remedy

 Clean the fluff filter.

Check the air­ways.continues

to light up after a
programme has
been cancelled,
despite thorough
cleaning.

The plinth filter looks clean after thorough cleaning.
However, the programme terminates and the error
message appears again. It is likely that there is still
underlying residue that could not be removed.

 To switch off the message: confirm OK.
 Check for the possible causes described below.

The heat exchanger is clogged.
 Check the heat exchanger. Follow the instructions

in “Problem solving guide – Checking the heat ex­changer”.

The plinth filter is clogged further down.
 Check the plinth filter. Follow the instructions de-

scribed in “Problem solving guide – Replacing the
plinth filter”.

 If the plinth filter is not out of shape or damaged,

you can reactivate it in a washing machine. Follow
the instructions described in “Problem solving
guide – Reactivating the plinth filter”.

 Empty the container

or check the drain
outlet lights up

after a pro­gramme has
been cancelled.

The condensed water container is full or there is kink
in the drain hose.

 Empty the condensed water container.
 Check the drain hose.

To switch the fault message off:
 Open and close the door while the dryer is

switched on or switch the dryer off and back on
again.

 Obstruction detec-

ted. Untangle laun­dry and restart.

lights up after a
programme has

The laundry is unevenly distributed or has rolled up.
 Open the door and loosen the laundry. Remove a

few items if necessary.

 Switch the tumble dryer off and then on again.
 Start a programme.

been cancelled.

Problem solving guide

65

Problem solving guide

Unsatisfactory drying results

Problem Cause and remedy

The laundry is not suffi­ciently dry.

Laundry or feather filled
pillows smell after dry­ing

Items made of synthetic
fibres are charged with
static electricity after
drying

There is a build-up of
fluff

The load consisted of different types of fabric.

 Finish drying using the Warm air programme.
 Select a more suitable programme next time.

Tip: You can alter the residual moisture level for some
programmes. See “Settings”.

The laundry was washed with insufficient detergent
Feathers are a natural product and this is quite nor­mal.

 Laundry: use sufficient detergent next time.
 Pillows: take out of the tumble dryer and air them.
 Use a fragrance flacon (available as an optional

accessory) for your favourite fragrance.

Synthetic fibres tend to attract static charge.
 Static charge can be reduced by adding a fabric

conditioner to the final rinse in the washing pro­gramme.

Fluff is principally the result of friction when garments
are being worn and to some extent when they are be­ing washed. Machine drying hardly causes any fluff
to form.
Fluff is collected by the fluff filters and the plinth filter
and can be removed easily.

 See “Cleaning and care”.

66

The drying cycle duration is very long

Problem Cause and remedy

The drying process
goes on too long or
even switches off.*

The room where the tumble dryer is located is too
warm.

 Ventilate the room thoroughly.

Detergent residues, hair and fine fluff can clog the fil­ters.

 Clean the fluff filters and the plinth filter.
 Remove visible fluff from the heat exchanger.

The laundry is unevenly distributed or has rolled up.
The drum is too full.

 Disentangle the laundry and remove a few items.
 Start a programme.

The bottom right grille is blocked.
 Move any objects, such as a laundry basket, away

from the dryer.

The laundry is too damp.
 Spin using a higher spin speed in the washing ma-

chine.

Metallic components, e.g. zips, have prevented the
tumble dryer from registering the correct laundry
moisture level.

 Open any zips next time.
 If the problem recurs, dry these items using the

Warm air timed drying programme.

Problem solving guide

* Switch the tumble dryer off and on again before starting a new programme.

67

Problem solving guide

General problems with the tumble dryer

Problem Cause and remedy

You can hear operating
noises (buzzing/hum­ming).

A programme does not
start

The display is dark and
the Start/Stop control is
flashing slowly.

The dryer is switched
off at the end of the
programme.

The display is in a dif­ferent language.

The interior drum light­ing does not come on.

This is not a fault.
The compressor (heat pump) is operating or you have
selected the Steam Care programme.

 No action required. These noises are quite normal

and can be heard when the compressor or the
condensed water pump is operating.

No obvious cause.

 Connect the tumble dryer to the mains
 Turn on the tumble dryer
 Close the door
 Check whether the mains fuse has tripped

Has there been a power cut? When power is re­stored any previously running programme will re­start automatically.

The display has switched off automatically to save
energy (Standby mode).
The drum will turn at intervals in the anti-crease
phase.

 Press any control. This switches Standby off.

The tumble dryer switches off automatically. This is
not a fault, but a normal function.

A different language has been selected in “Settings,
Language ”.

 Set the language you want. The flag symbol serves

as a guide.

Not a fault. The drum lighting switches off automat­ically in the following cases:
If the door is closed.
If the door remains open for an extended period of
time.

68

Problem Cause and remedy

Insufficient spray for
the Steam care pro­gramme.

The fluff filter in the condensed water container
clogged.

 Clean the fluff filter in the condensed water con-

tainer. See “Fluff filter in the condensed water con­tainer”.

The spray jet in the door opening is heavily calcified.
 Replace the spray jet. See “Spray jet for the Steam

care programme”.

 Only use condensed water. Do not use tap water.

The frequent use of tap water leads to limescale de­posits.

Problem solving guide

69

Problem solving guide

Replacing the plinth filter

The heat exchanger can clog up.
Replace the plinth filter immediately

if you see the following signs of wear
before or after cleaning (optional ac­cessory).

Poor fit

The edges of the plinth filter do not sit
properly and the plinth filter is out of
shape. Fluff will blow into the heat ex­changer unfiltered through edges that
do not sit properly. This will, in time,
cause a blockage in the heat ex­changer.

Deformations

Deformations indicate that the filter has
become blocked and worn by continu­ous use.

70

Problem solving guide

Cracks, tears, indentations

Fluff will blow into the heat exchanger
through cracks and tears. This will, in
time, cause a blockage in the heat ex­changer.

White residues or residues of other col­ours

These residues arise from laundry fibres
and traces of detergent components.
They can be found on the front and side
edges of the plinth filter. In extreme
cases, they can form stubborn crust.
Residues are a sign that the plinth filter
no is longer a snug fit at the sides, even
if it appears to be perfect:
fluff is getting in unfiltered at the edges.

Reactivate the plinth filter. If these
residues appear on the plinth filter again
soon after cleaning, the plinth filter must
be replaced.

71

Problem solving guide

Reactivating the plinth filter

You can reactivate one or more soiled
plinth filters in a washing machine. You
will then be able to use the plinth filter
again.

Prior to reactivation, check that the
plinth filter is in good order. Check the
plinth filter following the instructions
provided in “Problem solving guide –
Replacing the plinth filter”. Replace the
plinth filter if it has worn out.

 Wash the plinth filter(s) separately,

not with any laundry items. Do not
add any detergent.

 Select a short wash programme with

a maximum temperature of 40°C and
a maximum spin speed of 600rpm.

You can re-insert the plinth filter once
the wash and spin cycles are complete.

Checking the heat exchanger

 Risk of injury from sharp cooling

fins.
You could cut yourself.
Do not touch the cooling fins with

your hands.

 Look to see if fluff has accumulated.

Remove any fluff you can see.

 Damage due to incorrect clean-

ing of the heat exchanger.
The tumble dryer will not dry if the

cooling fins are damaged or bent.
Clean using a vacuum cleaner with a

suction brush attached. Only pass
the vacuum cleaner brush over the
heat exchanger cooling fins lightly,
without applying any pressure.

72

 Use a vacuum cleaner to remove fluff

and residues.

Cleaning the fluff filter in the condensed water container

In some circumstances, there can be
problems running the Steam care pro­gramme. The fluff filter at the end of
the hose which is connected to the
rubber seal in the condensed water
container could be blocked.

Problem solving guide

Do not pull on the hose with force.
Otherwise it will come loose.

 Guide the end of the hose through

the opening.

 Hold it securely with one hand
 Use your other hand to pull the fluff

filter off the hose.

 Remove the condensed water con-

tainer.

 Reach under the side lug on the

spout with your finger.

 Pull out the spout.

 Rinse the fluff filter with a jet of water

until all the fluff has been removed.

 Refit the cleaned fluff filter onto the

end of the hose.

 Now feed the hose with its fluff filter

attached into the condensed water
container.

 Refit the spout in the condensed wa-

ter container ensuring that it is posi­tioned correctly. Please refer to the
image.

73

Problem solving guide

Replacing the blocked spray
jet for the Steam care pro­gramme

Limescale deposits will impair the
spray jet.
If this happens, the spray jet must be
removed and replaced with a new one
(see “Optional accessories”).

You can only replace the spray jet us­ing a special tool. The special tool is
supplied with the new spray jet.

 Using the wrong tool can cause

damage.
Doing so can damage the spray jet

or the tumble dryer.
Only use the tool supplied. Do not

use any other tool.

The Steam care programme must
never be used without the spray jet
fitted and screwed in correctly.

 Open the door of the tumble dryer.

The spray jet is located in the top left of
the door opening.

 Attach the tool to the spray jet.
 Turn the tool anti-clockwise to un-

screw the spray jet.

 Insert the new spray jet in the tool.
 Turn the tool clockwise to screw the

spray jet securely in position.

74

Service

Contact in the event of a fault

In the event of any faults which you
cannot remedy yourself, please contact
your Miele dealer or the Miele Customer
Service Department.

You can book a Miele Customer Ser­vice Department call-out online at
www.miele.com/service.

Contact information for the Miele Cus­tomer Service Department can be
found at the end of this document.

Please quote the model identifier and
serial number of your appliance (Fabr./
SN/Nr.) when contacting the Miele Cus­tomer Service Department. This inform­ation can be found on the data plate.

Please note that telephone calls may be
monitored and recorded for training
purposes and that a call-out charge will
be applied to service visits where the
problem could have been resolved as
described in this booklet.

The data plate is visible when the door
is open.

Optional accessories

Optional accessories for this tumble
dryer are available from Miele or from
your Miele dealer.

You also can order these and many
other useful products from the Miele
online shop.

Dryer basket

The dryer basket is enables items which
must not be subjected to mechanical
action to be dried or aired.

Fragrance flacon

A fragrance flacon can be used in your
tumble dryer to add a pleasant fra­grance to your laundry.

Warranty

For information on the appliance war­ranty specific to your country please
contact Miele. See back cover for ad­dress.

In the UK, your appliance warranty is
valid for 2 years from the date of pur­chase. However, you must activate your
cover by calling 0330 160 6640 or re­gistering online at www.miele.co.uk.

75

*INSTALLATION*

Installation

Front view

a

Mains connection cable

b

Control panel

c

Condensed water container
– empty after every drying cycle

d

Door
– do not open during drying

76

e

Heat exchanger access panel
– do not open during drying

f

Four height adjustable screw feet

g

Cool air intake grille
– do not obstruct with a laundry bas-

ket or other objects

h

Hose for external drainage of con­densed water

*INSTALLATION*

Rear view

a

Protruding lid for holding when mov­ing the tumble dryer (see arrows)

b

Drain hose for condensed water

c

Hook for winding the mains cable
around during transport

d

Mains connection cable

Installation

 If the tumble dryer is being transpor-

ted on its side, it must be tipped onto
its left or right side.

 If the tumble dryer is being transpor-

ted upright and you are using a hand
truck, you must transport it with its
left or right side resting on the truck.

Transporting the tumble dryer to its installation site

Transporting the tumble dryer

 Danger of injury to people and

damage to property caused by mov­ing the appliance incorrectly.

If the tumble dryer tips up there is a
danger of injury to people and dam­age to property.

Ensure that the tumble dryer is stable
during transportation.

 Make sure the fixings at the back

of the lid are secure.
Otherwise there is a danger of the lid

being pulled off when carrying the
appliance.

Before carrying the appliance check
that the lid is secure where it pro­trudes at the back of the appliance.

 Carry the tumble dryer by the front

feet and by the lid where it protrudes
at the back of the appliance.

77

*INSTALLATION*

Installation

Installation

Levelling the dryer

Ensure that no closeable door, slid­ing door, or an oppositely hinged
door is installed that would hinder
the door of the dryer being opened in
any way.

The dryer must stand perfectly level to
ensure safe and proper operation.

Downtime after installation

 Damage to the tumble dryer by

switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer wait

for at least one hour before switching
it on.

Ventilation

The cool air intake at the front of the
tumble dryer must not be blocked or
covered. This would hinder a suffi­cient intake of cool air for the heat
exchanger.

Do not block the gap between the
bottom of the tumble dryer and the
floor with plinth facings, deep pile
carpet etc. This would hinder a suffi­cient flow of air to the tumble dryer.

The hot air that is blown out from the
heat exchanger warms the room air. En­sure sufficient ventilation of the room:
e.g., open the window. The drying time
will otherwise take longer (higher energy
requirement).

The screw feet can be adjusted to com­pensate for unevenness in the floor.

78

Before moving the tumble dryer again (e.g. when moving house)

After each use a small quantity of con­densed water will collect in the area of
the pump. This water can run out if the
tumble dryer is tipped up when it is be­ing moved. Recommendation: run the
Warm air programme for approximately
1minute before moving the tumble
dryer. Any remaining condensed water
will then be fed into the condensed wa­ter container or out through the drain
hose.

*INSTALLATION*

Additional installation require­ments

Slot-in

This tumble dryer is suitable for pushing
under a worktop.

Appliance defect due to a build-up of
heat.

Make sure there is adequate room
for warm air from the dryer to be dir­ected away.

- The appliance lid cannot be removed.

- The electrical socket must be located
in an accessible position near the
tumble dryer.

- Drying durations may increase
slightly.

Installation

Optional accessories

– Washer-dryer stack

The tumble dryer can be combined with
a Miele washing machine in a washer­dryer stack. The appropriate Miele
washer-dryer stacking kit is required.

– Plinth

The tumble dryer can be fitted on a
plinth with drawer (please note the
plinth may not be available in all coun­tries).

79

*INSTALLATION*

Installation

External condensed water out­let

Note

When drying is in progress, con­densed water is pumped into the con­densed water container through the
drain hose which is located at the
back of the dryer.

The condensed water can also be ex­ternally drained away via the drain hose
at the back of the dryer. This means
that the condensed water container no
longer has to be emptied.

Drain hose length: 1.49m
Max. delivery head: 1.00m
Max. drain hose length: 4.00m

Drainage accessories

Installation conditions requiring a non-return valve

 Danger of condensed water

back-flow.
Water could flow back into the

tumble dryer or be drawn into it.
Back-flow water could damage the
tumble dryer and also the room in
which it is located.

The non-return valve should be used
if the end of the hose is immersed in
water, or if other water connections
are installed.

Maximum delivery head with non-return
valve fitted: 1.00m

Installation conditions requiring the fit­ting of a non-return valve:

- Drainage into a sink or floor gully
where the end of the hose is im­mersed in water.

- Connection to a sink drain outlet.

- Supplied: Adapter (b), Hose clip (c),
Hose holder (e);

- Available to purchase: “Non-return
valve” kit for connection to an ex­ternal water connection. Non-return
valve (d), Hose extension (a) and
Hose clips (c) are supplied.

80

- Connection to a drainage system
already in use by another appliance,
e.g. a dishwasher or washing ma­chine.

If the non-return valve is incorrectly
fitted the appliance will not drain.

The non-return valve has to be fitted
with the arrow on it pointing in the
direction of flow.

*INSTALLATION*

Installation

Arranging the drain hose

 Damage to the drain hose

through incorrect handling.
The drain hose can suffer damage

and leak.
Do not pull on the drain hose and do

not stretch it or allow it to become
kinked.

There will be a small amount of residual
water left in the drain hose. Have a con­tainer ready to collect this.

Examples

Drainage into a sink or floor gully

Use the hose holder to secure the drain
hose.

 Water damage.

Should the end of the hose come
loose, overflowing water can cause
damage.

Secure the drain hose carefully (e.g.,
by tying it) to make sure it cannot
slip.

 Pull the drain hose off its connection

(light arrow).

 Pull the hose out of the holders (dark

arrow) and unwind it.

 Allow any residual water to run into a

container.

The non-return valve can be fitted in the
end of the hose.

81

*INSTALLATION*

Installation

Direct connection to a sink drain outlet

Use the hose holder, the adapter, the
hose clips and the non-return valve
(available to purchase).

1. Adapter

2. Nut

3. Hose clip

 Fit adapter 1 to the sink drain outlet

using nut 2.
The nut is usually fitted with a washer
which must be removed.

 Attach the end of the hose 4 to ad-

apter 1.

 Use the hose holder.
 Use a screwdriver to tighten hose clip

3 up close to the nut.

 Fit non-return valve 5 to tumble dryer

drain hose 6.

Non-return valve 5 has to be fitted so
that the arrow points in the direction
of flow (i.e. towards the sink).

 Secure the non-return valve using

hose clips.

4. End of the hose (secured with the
hose holder)

5. Non-return valve

6. Tumble dryer drain hose

82

*INSTALLATION*

Installation

Changing the door hinging

You can change the door hinging on
this tumble dryer yourself.

For safety reasons the tumble dryer
must be disconnected from the elec­tricity supply before changing the
door hinging.

You will need:

- a Torx T20 and T30 screwdriver

- a flat head screwdriver or pointed pli­ers

- the lock catch cover supplied

- the door hinge cover supplied

- a soft surface (e.g. a tablecloth)

Changing the hinging over

1. Remove the door from the dryer

 Open the door.

 Hold the door securely and pull it for-

wards: to remove the door you will
need to pull the base plate of the
hinge with its 2 pins out of the dryer.

To avoid scratching the door, place it
outer side downwards on a soft sur­face (e.g. a tablecloth).

2. Change over the door lock on the dryer

 Use a Torx T30 screwdriver to un-

screw the two screws on the door
lock .

 Use a T30 Torx screwdriver to un-

screw the two screws on the base
plate of the door hinge .

The door cannot fall off as it is held in
place by 2 pins.

 Use the screwdriver to press the door

lock upwards.

The door lock will spring out of its posi­tion and can then be removed.

83

*INSTALLATION*

Installation

 Turn the door lock through 180°.

 Press the door lock into openings 

on the opposite side of the door
opening.

 Adjust the position of the door lock

so that the screw holes line up with
those in the front panel of the dryer

.

 Use a T20 Torx screwdriver to remove

screw  on the lock catch.

 Pull off the lock catch together with

lock catch cover .

 Secure the door lock with the two

Torx screws.

3. Remove the lock catch from the door

 First take the rubber seal off the door

and place this to one side.

84

 Remove the lock catch from the

cover.

This lock catch cover is no longer
needed, however, please keep it in a
safe place.

*INSTALLATION*

 Insert the lock catch into the new

cover supplied with the dryer.

 Place this new cover to one side for

now.

Installation

4. Dismantle the door hinge from the door

The door hinge cover must be un­clipped from position  and then re­moved.

 Use a screwdriver to press down

gently on position  on the door
hinge cover.

 Using a little force, pull out door

hinge cover .

This door hinge cover is no longer
needed, however, please keep it in a
safe place.

85

*INSTALLATION*

Installation

5. Change over the door hinge on the door

The door hinge is secured to the door
with 2 angled rods. These rods need
to be removed with a screwdriver or
pointed pliers.

 Insert the end of the screwdriver

blade under rod  and rotate it so it
is in an upright position. Do the same
to the other rod.

Tip: In some circumstances, the rods
can be difficult to dislodge. Moving the
screwdriver with a levering action while
pulling at the same time may help to
work the rods free.

 Remove the door hinge and turn it

through 180°.

 Fit the door hinge on the opposite

side of the door.

 Secure the door hinge with the two

rods .

 Use the screwdriver or pointed pliers

to guide first one then the other rod
 to the middle until each can be re­moved.

86

 Position the tip of the screwdriver un-

der the end of the rod and then push
it into its resting position .

*INSTALLATION*

You now need the new door hinge
cover supplied with the tumble dryer.

 Fit new door hinge cover  and clip

it into position.

6. Change the lock catch on the door

Installation

 You now need the new lock

catch cover supplied with the dryer
which you have already fitted with
the lock catch.

 Push lock catch cover  with its lock

catch into position.

 Tighten screw .

87

*INSTALLATION*

Installation

Refitting

7. Refit the door

 Press the rubber seal back into the

grove on the door.

 Position the door in front of the dryer.
 Fit the base of the door hinge with its

2 pins into the openings on the dryer.

The base of the door hinge must be
flush with the front panel of the dryer.
The door cannot fall off in this position.

 Now that you have changed the

door hinging the door will open from
the opposite side.

 Push the orange marker round to the

other side so that you will see at
which side to pull the door open.

Important

 Please keep the lock catch and

door hinge covers which were no
longer needed in a safe place. These
will be required if, for example, you
move house and need to change the
door hinging back to its original posi­tion.

 Screw the door securely to the dryer

at the base of door hinge .

88

*INSTALLATION*

Installation

Electrical connection

The tumble dryer is supplied with a
mains cable with moulded plug ready
for connection to a suitable switched
socket.

The socket must be easily accessible
after the tumble dryer has been in­stalled. If that is not possible, ensure
that a suitable means of disconnection
is provided on the installation side for
each pole.

 Risk of fire from overheating.

Connecting the tumble dryer to a
multi-socket plug adapter or to an
extension lead can overload the
cable.

For safety reasons, do not use an ex­tension lead or multi-socket plug ad­apter.

The electrical system must comply with
local and national safety regulations
(BS7671 in the UK). We recommend
the use of a suitable RCD .

Do not connect the tumble dryer to a
stand-alone inverter such as those used
with an autonomous energy source, e.g.
solar power. When the tumble dryer is
switched on, power surges could result
in a safety switch-off. This could dam­age the electronic module.

If the connection cable is damaged, it
must only be replaced with a specific
connection cable of the same type
(available from the Miele Customer Ser­vice Department). For safety reasons,
such replacement may only be carried
out by a qualified technician or the
Miele Customer Service Department.

The data plate indicates the nominal
power consumption and the appropri­ate fuse rating. Compare the specifica­tions on the data plate with those of the
electricity supply and make sure that
they match.

If in any doubt, consult a qualified elec­trician.

89

Technical data

Height 850mm

Width 596mm

Depth 643mm

Depth with door open 1077mm

Suitable for pushing under a worktop Yes

Suitable for stacking Yes

Weight approx. 61.5 kg

Drum volume 120litres

Load size 9.0 kg (weight of dry laundry)

Capacity of condensed water container 4.8l

Hose length 1.49m

Maximum delivery head 1.00m

Maximum drain hose length 4.00m

Length of connection cable 2.00m

Voltage See data plate

Connected load See data plate

Fuse rating See data plate

Test certificates awarded See data plate

Energy consumption See “Consumption data”

LEDs Class 1

Frequency band 2.4000GHz–2.4835GHz

Maximum transmission power <100mW

90

Technical data

Conformity declaration

Miele hereby declares that this heat-pump tumble dryer complies with Directive
2014/53/EU.

The complete text of the EU declaration of conformity is available from one of the
following internet addresses:

- Products, Download from www.miele.co.uk

- For service, information, operating instructions etc: go to www.miele.co.uk/do­mestic/customer-information-385.htm and enter the name of the product or the
serial number

91

Technical data

Data sheet for household tumble driers

In acc. with delegated regulation (EU) No. 392/2012

MIELE

Model name/identifier TWR860WP

Rated capacity

Type of tumble drier (Air-vented / condenser) - / ●

Energy efficiency class

A+++ (most efficient) to D (least efficient) A+++

Weighted annual energy consumption (AEc)

Tumble drier (Automatic / non-automatic) ● / -

Energy consumption of the standard cotton programme

Energy consumption at full load 1,63 kWh

Energy consumption at partial load 0,86 kWh

Weighted power consumption in off-mode (Po) 0,20 W

Weighted power consumption in the left-on mode (Pl) 0,20 W

Duration of the 'left-on' mode (Tl)

Standard programme to which the information in the label and the fiche

4

relates

Programme time of the 'standard cotton programme'

Weighted programme time 160 min

Programme time at full load 208 min

Programme time at partial load 124 min

Condensation efficiency class

A (most efficient) to G (least efficient) A

Weighted condensation efficiency for the 'standard cotton programme' at
full and partial load

Average condensation efficiency of the 'standard cotton programme' at full
load

Average condensation efficiency of the 'standard cotton programme' at par­tial load

Sound power level (LWA)

Built-in -

1

2

3

5

6

9,0 kg

193 kWh/year

15 min

Cottons with arrow

94 %

94 %

94 %

62 dB(A) re 1 pW

● Yes, standard feature

1

In kg of cotton laundry for the standard cotton programme at full load.

2

based on 160 drying cycles of the standard cotton programme at full and partial load, and the con­sumption of the low-power modes. Actual energy consumption per cycle will depend on how the ap­pliance is used.

92

Technical data

3

If the household tumble drier is equipped with a power management system.

4

This programme is suitable for drying normal wet cotton laundry and is the most efficient programme
in terms of energy consumption for cotton.

5

If the household tumble drier is a condenser tumble drier.

6

For the standard cotton programme at full load.

93

Consumption data

1

Load size

kg rpm % kWh Min

Cottons 

Cottons Normal 9.0

Cottons Normal
incl. Gentle tumble

Cottons Hand iron 9.0

Minimum iron Normal 4.0 1200 40 0.50 70

Minimum iron Normal
incl. Gentle tumble

Delicates Normal 2.5 800 50 0.55 75

Woollens handcare 2.0 1000 50 0.02 5

Shirts Normal 2.0 600 60 0.45 65

Express Normal 4.0 1000 60 0.85 110

Denim Normal 3.0 900 60 1.05 130

Proofing Normal 2.5 800 50 0.90 120

1

Weight of dry laundry

2

Test programme in accordance with Regulation 392/2012/EU for energy labelling, measured in ac-

cordance with EN61121

All data was calculated using EN61121 unless otherwise stated.

Consumption data can vary from the nominal values given above depending on the size of the
load, types of textiles, residual moisture levels after spinning and fluctuations in the electricity
supply, or when water hardness levels differ from specified values.

The consumption data shown in the EcoFeedback display can vary from the consumption data quoted
here. The variations arise from the way the data is measured in the dryer. For example, the programme
duration may vary depending on the residual moisture present in the laundry and the type of fabric
which will affect the energy requirement.

2

9.0

4.5

9.0

9.0

9.0 1000 60 1.70 200

9.0

9.0

9.0

4.0 1200 40 0.50 72

Final spin speed in

washing machine

1000

1000

1200

1400

1600

1000

1200

1400

1600

Residual

mois-

ture

60

60

53

50

44

60

53

50

44

Energy Duration

1.63

0.86

1.45

1.40

1.25

1.25

1.10

1.00

0.85

208

124

189

179

160

147

129

120

102

94

Settings

You can alter the tumble dryer's elec­tronics to suit changing requirements
with the settings.
The settings can be altered at any
time.

Accessing the Settings menu

 Switch the tumble dryer on.
 Scroll to the second page in the main

menu.

 Touch the Settings sensor.

Selecting settings

The settings are grouped into different
areas.

 Select the required area.
 Scroll through the list until the setting

you want appears.

 Touch the sensor to select the setting

you require.

Changing a setting

 Change the value displayed and con-

firm with OK.

or
 Touch an option to select it.

An option which is selected will be
highlighted orange.

The option is saved. The display will
then switch to the Settings menu, or go
back to the previous menu level.

Closing the Settings menu

 Touch the  sensor.

The display will then go back to the pre­vious menu level.

 Touch the  sensor.

The display will change to show the
main menu.

95

Settings

Operation/display 

Language 

The display can be set to appear in
one of several different languages.

The flag  after the word Language
(Sprache in German) acts as a guide in
case a language which is not under­stood has been set.

The language selected is saved.

Code

The code prevents your dryer being
used without your knowledge.

Options

- Activate
If the PIN code has been activated,
you have to enter the PIN code after
switching the dryer on. Otherwise the
dryer cannot be operated.
The factory default PIN code is 250.

- Clock format

The clock format is set.

– 24 h (factory default)
– 12 h

- Set

The current time is set.

Consumption

You can display the total consump­tion.

Options

- Previous programme

Energy consumption in the last pro­gramme run

- Total consumption

Previous total consumption

- Change
You can enter a PIN code of your
own.

If you forget the PIN code, only Miele
Service can unlock the tumble dryer.

Make a note of your new PIN code.

- Deactivate
For using the dryer without entering
the code. This only appears if the
code had been activated previously.

Clock display

After selecting the clock format you
can set the time of day.

Options

96

Settings

Memory

The dryer saves the settings that were
selected last for a drying programme
(drying stage and/or extra option, or
the duration for some programmes).

When the programme is chosen again,
the saved settings will appear in the
display.

Options

- Off (factory default)

- On

The activation of delay start, the buzzer
or ECO feedback data are not saved.

Volume

The volume can be changed for the
buzzer that sounds when the dryer is
switched on and at the end of the pro­gramme. The volume of the tone that
sounds when a sensor is touched can
also be changed.

Display brightness

The brightness of the display can be
altered.

It can be set to one of 7 different set­tings.

Factory default: a medium setting

Wash2Dry

You can select the Wash2Dry function
in the main menu. You will have to en­able the function first.

Options

- On

Wash2Dry is enabled and lights
up in the main menu.

- Off(factory default)

Wash2Dry does not light up.

Options

- Finish tone

- Keypad tone

- Welcome tone

It can be set to one of 7 different set­tings or switched off altogether.

97

Settings

“Display” off status

To save energy the display and sensor
controls will go out after 10minutes
and the Start/Stop button will flash
slowly. You can change this setting.

Options

- Off
The display will remain on (i.e. it will
never go out).

- On
The display will go out (after
10minutes):

– if a programme is not selected

after the dryer has been switched
on

– during the current programme

– after the end of a programme

- On. Not in current prog.
(Factory default)
The display will go out (as described
above) but will remain on while the
programme is running.

You can switch the display back on by
touching any sensor.

98

Settings

Networking

Miele@home

Control the networking of your tumble
dryer with your home WiFi network.

The following points may appear in the
submenu:

Set up

This message only appears if the
tumble dryer has not yet been connec­ted to a WiFi network.

Please refer to “Before using for the first
time” for instructions on how to set up
the connection.

Activate

(visible if Miele@home is deactivated)

The WiFi function is reactivated.

Deactivate

(visible if Miele@home is activated)

Miele@home remains set up, the WiFi
function is switched off.

Connection status

(visible if Miele@home is activated)

The following values are displayed:

- The quality of WiFi reception

- The network name

- The IP address

Set up again

(visible if set up)

Resets the WiFi login (network) to im­mediately re-establish a new connec­tion.

Reset

(visible if set up)

- The WiFi is switched off.

- The WiFi connection will be reset to
the factory default setting.

The network configuration should be re­set whenever a tumble dryer is being
disposed of or sold, or if a used tumble
dryer is being put into operation. This is
the only way to ensure that all personal
data has been removed and the previ­ous owner will no longer be able to ac­cess the tumble dryer.

A new connection setup has to be car­ried out in order to use the Miele@home
setting again.

99

Settings

SmartGrid

The SmartGrid setting is only visible if
the Miele@home setting is set up and
activated.

This function can be used for starting
your tumble dryer automatically at a
time when your energy costs are most
economical.

Activating SmartGrid gives the Delay
start button a new function. Use the
“Delay start” control to set the

SmartGrid. The tumble dryer will then

start within the timeframe specified
when it receives a signal from the en­ergy supplier.
If it has not received a signal from the
energy supplier by the latest start time
set, the tumble dryer will start automat­ically (see “Delay start”).

SmartGrid is deactivated as standard.

Remote control

The Remote control setting is only vis­ible if the Miele@home setting is set up
and activated.

Once the Miele@mobile app has been
installed on your mobile device, you
can check the status of your tumble
dryer from anywhere and start it re­motely. You can also control it re­motely via the MobileStart pro­gramme.

You can switch off the Remote control
setting if you do not want to operate the
tumble dryer with your mobile device.

If Remote control is not switched on, the
app can cause the programme to be
cancelled.

Use the “Delay start” button to set a
time at which you wish to start the
tumble dryer and start the delay start
(see “Delay start/SmartStart”).
The tumble dryer will then start within
the timeframe specified when it receives
your signal.
If it has not received a start signal by
the latest start time set, the tumble
dryer will start automatically.

100

Remote control is activated by default.
