Operating instructions
Heat pump tumble dryer
It is essential to read these operating instructions before installing and
using the appliance. This prevents both personal injury and damage to
the appliance.
en-AU, NZ M.-Nr. 11 015 671
Contents
Caring for the environment ................................................................................. 6
Warning and Safety instructions .........................................................................7
Operating the tumble dryer ................................................................................ 18
Control panel......................................................................................................... 18
Touch display and sensor controls........................................................................ 18
Main menu............................................................................................................. 19
Examples on how to operate the appliance.......................................................... 20
Before using for the first time ............................................................................ 22
Downtime after installation.................................................................................... 22
Removing the protective foil and stickers ............................................................ 22
Miele@home .......................................................................................................... 22
Setting the language ............................................................................................. 23
Energy saving tips ............................................................................................... 25
Energy saving tips ................................................................................................. 25
EcoFeedback......................................................................................................... 26
1. Notes on correct laundry care .......................................................................27
Points to note regarding washed laundry.............................................................. 27
Preparing the laundry before drying...................................................................... 27
Drying .................................................................................................................... 28
Care label symbols...........................................................................................28
Selecting the correct drying level.....................................................................28
2. Loading the tumble dryer ............................................................................... 29
Loading the laundry............................................................................................... 29
3. Selecting a programme .................................................................................. 30
Switching on the tumble dryer .............................................................................. 30
4. Selecting programme settings.......................................................................31
Programme settings .............................................................................................. 31
Selecting a drying level with a drying programme ........................................... 31
Selecting timed drying programmes and other programmes .......................... 31
Selecting Extras..................................................................................................... 32
5. Starting the programme ................................................................................. 33
Starting a programme ........................................................................................... 33
6. End of programme - unloading the drum...................................................... 34
At the end of the programme ................................................................................ 34
Removing the laundry ........................................................................................... 34
2
Contents
Programme chart ................................................................................................35
Extras.................................................................................................................... 41
Gentle tumble........................................................................................................ 41
Freshen up............................................................................................................. 41
Drying programme overview - Extras.................................................................... 42
Favourite programmes........................................................................................43
Creating a Favourite programme........................................................................... 43
Option 1............................................................................................................ 43
Option 2............................................................................................................ 43
Entering a name ...............................................................................................43
Changing a Favourite programme....................................................................43
Drying assistant...................................................................................................44
Timer..................................................................................................................... 45
Setting the Timer ................................................................................................... 45
Changing the Timer............................................................................................... 45
Deleting the Timer ................................................................................................. 45
Starting the Timer.................................................................................................. 45
SmartStart ............................................................................................................. 46
Setting the timeframe.......................................................................................46
Changing the programme sequence................................................................. 47
Condensed water container ............................................................................... 48
Emptying the condensed water container ............................................................ 48
Preparing the condensed water container for Steam care.................................... 49
Fragrance flacon.................................................................................................. 50
FragranceDos – 2 positions for inserting a fragrance flacon................................. 50
Using a fragrance flacon ....................................................................................... 50
Removing the protective seal from the fragrance flacon.................................. 50
Inserting the fragrance flacon........................................................................... 51
Opening the fragrance flacon................................................................................ 52
Closing the fragrance flacon ................................................................................. 52
Removing/replacing the fragrance flacon ............................................................. 53
Cleaning and care ............................................................................................... 54
Fluff filters.............................................................................................................. 54
Removing the fragrance flacon ........................................................................ 54
Removing visible fluff ....................................................................................... 54
Cleaning the fluff filters and air flow openings thoroughly ............................... 55
Cleaning the fluff filters with water ................................................................... 56
3
Contents
Cleaning the plinth filter......................................................................................... 57
Removing the plinth filter .................................................................................57
Cleaning the plinth filter.................................................................................... 58
Cleaning the plinth filter panel.......................................................................... 58
Checking the heat exchanger unit....................................................................59
Inserting the plinth filter....................................................................................59
Cleaning the dryer ................................................................................................. 60
Problem solving guide ........................................................................................61
The display indicates the following messages or faults........................................ 61
Unsatisfactory drying results................................................................................. 63
The drying process takes a long time. .................................................................. 64
General problems with the tumble dryer............................................................... 65
Cleaning the fluff filter in the condensed water container..................................... 67
Replacing the blocked spray jet for the Steam care programme.......................... 68
Service..................................................................................................................69
Contact in case of fault ......................................................................................... 69
Optional accessories............................................................................................. 69
Warranty ................................................................................................................ 69
Installation and connection ................................................................................ 70
Front view.............................................................................................................. 70
Rear view............................................................................................................... 71
Transporting the tumble dryer ............................................................................... 72
Transporting the tumble dryer to its installation site ........................................72
Installation ............................................................................................................. 72
Levelling the dryer ............................................................................................ 72
Downtime after installation...............................................................................73
Ventilation......................................................................................................... 73
Before moving the tumble dryer again (e.g. when moving house)...................73
Additional installation requirements ...................................................................... 74
Externally draining condensed water .................................................................... 75
Installation conditions requiring a non-return valve ......................................... 75
Arranging the drain hose .................................................................................. 76
Examples: Draining condensed water.............................................................. 76
Electrical connection ............................................................................................. 79
Technical data...................................................................................................... 80
Consumption data............................................................................................... 81
Settings ................................................................................................................ 82
Calling up settings................................................................................................. 82
4
Contents
Operation/Display .............................................................................................. 83
Language ...................................................................................................... 83
Consumption....................................................................................................83
Code.................................................................................................................83
Memory ............................................................................................................84
Clock display....................................................................................................84
Volume..............................................................................................................84
Display brightness............................................................................................84
Display switch-off status .................................................................................. 85
Programme sequence ........................................................................................... 86
Anti-crease ....................................................................................................... 86
Drying levels ..................................................................................................... 86
Cooling down temperature............................................................................... 86
Network ................................................................................................................. 87
RemoteUpdate ................................................................................................. 87
Miele@home ..................................................................................................... 88
SmartGrid ......................................................................................................... 89
Remote control................................................................................................. 89
Appliance parameters ........................................................................................... 90
Airways indicator .............................................................................................. 90
Conductivity setting .........................................................................................90
5
Caring for the environment
Disposal of the packing material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances. You are also responsible for
deleting any personal data that may be
stored on the appliance prior to
disposal. Please ensure that your old
appliance poses no risk to children
while being stored prior to disposal.
6
Warning and Safety instructions
It is essential to read these instructions.
This tumble dryer complies with current local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
This tumble dryer is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
This tumble dryer is not suitable for outdoor use.
It must only be used to dry items which have been washed in a
water solution and which are marked on the manufacturer's care
label as being suitable for tumble drying. If using dry cleaning kits,
do so at your own risk, and follow the instructions provided on the
packaging.
Any other applications may be dangerous. Miele cannot be held
liable for damage resulting from incorrect or improper use or
operation.
7
Warning and Safety instructions
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it by a person responsible
for their safety.
Safety with children
Young children must not be allowed to use this appliance.
Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely,
recognising the dangers of misuse.
Children must not be allowed to clean or maintain the tumble
dryer unsupervised.
Please supervise children in the vicinity of the tumble dryer and do
not let them play with it.
8
Warning and Safety instructions
Technical safety
Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
Before connecting the tumble dryer, ensure that the connection
data on the data plate (fuse rating, voltage and frequency) matches
the mains electricity supply. If in any doubt, consult a qualified
electrician.
The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the household wiring
system tested by a qualified electrician. Miele cannot be held liable
for the consequences of an inadequate earthing system (e.g. electric
shock).
Reliable and safe operation of this tumble dryer can only be
assured if it has been connected to the mains electricity supply.
Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the appliance (e.g. danger of overheating).
If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele authorised service technician, otherwise any
subsequent damage will not be covered by the warranty.
Faulty components must only be replaced by genuine Miele spare
parts. Miele can only guarantee the safety of the appliance when
Miele replacement parts are used.
9
Warning and Safety instructions
In the event of a fault or for cleaning purposes, the tumble dryer is
only completely isolated from the electricity supply when:
– it is switched off at the wall socket and the plug is withdrawn, or
– it is switched off at the mains circuit breaker.
This tumble dryer must not be installed and operated in mobile
installations (e.g. on a ship).
Do not make any alterations to the tumble dryer, unless authorised
to do so by Miele.
Heat pump technology and refrigerant:
The heat pump in this tumble dryer uses a refrigerant which is
condensed by the compressor and led in a closed circuit through the
heat exchanger unit where heat exchange with the circulating drying
air takes place.
– The humming noises caused by the heat pump are normal and do
not impair the efficient functioning of the dryer.
– The refrigerant is not flammable or explosive.
– In general it is not necessary to leave the dryer standing for any
length of time before it is connected to the mains provided it has
been transported and installed correctly.
10
Warning and Safety instructions
Please observe the instructions in “Installation and connection”
and “Technical data”.
The accessibility of the plug must be always ensured in order to
separate the tumble dryer from the mains.
Do not block the gap between the bottom of the tumble dryer and
the floor with plinth facings, deep pile carpet etc. This would hinder a
sufficient flow of air to the tumble dryer.
Make sure the dryer door can be opened without hindrance after
installation.
11
Warning and Safety instructions
Correct use
Warning: Risk of fire / Flammable materials.
To avoid the possible danger of fire, please read these warnings
carefully.
A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
The maximum load for this tumble dryer is 9.0 kg (dry weight). See
the “Programme chart” for the maximum recommended loads for
individual programmes.
To prevent the risk of fire, do not connect the tumble dryer via a
controllable socket (e.g. a timer or a peak-load switch-off device).
If the drying programme is interrupted before the end of the cooling
down phase, this could cause the laundry to self-ignite.
12
Warning and Safety instructions
To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have not been washed.
– Items which have been cleaned using chemicals (e.g. professional
dry-cleaning agents).
– Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
desposits (such as cosmetics, lotions etc). If items have not been
thoroughly cleaned, there is a danger that these might ignite when
heated, even after they have been removed from the dryer at the
end of the programme.
– Items that have been soiled with substances such as cooking oil,
acetone, petrol, kerosene, spot removers, turpentine, waxes, wax
removers and other chemicals (e.g. mops and floor cloths).
– Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
– Fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– Damaged fabrics which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of it
igniting in the dryer.
When washing such heavily soiled items ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.
13
Warning and Safety instructions
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
Remove all items from pockets (e.g. lighters, matches).
Warning: Ensure that you always wait until the end of the
programme before removing the laundry. If the drying programme is
stopped prematurely, remove the laundry immediately and hang it up
or spread it out to cool it down.
Fabric softener and similar products must be used according to
the instructions on the manufacturer's packaging.
In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry selfigniting). The programme is not finished until the cooling down phase
has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
Always close the door after use. This way you will avoid the
danger of:
– children climbing onto or into the dryer or hiding things in it.
– pets or other small animals climbing into it.
14
Warning and Safety instructions
The tumble dryer must not be used without or
– with damaged fluff filters.
– with a damaged plinth filter.
This would cause an excessive build-up of fluff which in turn would
cause a fault.
The fluff filters must be cleaned after every drying cycle.
Fluff must not be allowed to accumulate around the tumble dryer.
The fluff filters and the plinth filter must be thoroughly dried after
cleaning. Do no replace them if they are damp or wet. Damp or wet
filters could cause operational faults.
Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and hoses.
If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
Condensed water is not drinking water.
It can cause health problems in both people and animals.
Always keep the area around the tumble dryer free of dust and
fluff.
Dust drawn into the tumble dryer can cause blockages in the heat
exchanger over time.
The tumble dryer must not be hosed down.
15
Warning and Safety instructions
Using a fragrance flacon (optional accessory)
Only use genuine Miele original fragrance flacons.
The fragrance flacon must be stored in its packaging so please
make sure you retain this.
Caution. The fragrance can run out of the flacon. Make sure that
you always keep the flacon, or the fluff filter with the flacon inserted
in it, in a horizontal position when carrying and do not tip it or place
it down on any surface.
Use an absorbent cloth immediately to wipe up any fragrance
which has run out of the flacon onto the floor, the dryer or any dryer
components (e.g. the fluff filter).
If fragrance which has run out of a flacon should come in contact
with the skin - wash the skin thoroughly with soap and water; come
in contact with the eyes - rinse the eyes with clean water for at least
15minutes; be swallowed - rinse out the mouth thoroughly with
clean water. Seek medical advice in the case of contact with the
eyes or if fragrance has been swallowed.
If fragrance which has run out of a flacon comes in contact with
clothing, change the clothing immediately. Wash the clothing or any
cloths used for mopping up fragrance thoroughly with plenty of
water and detergent.
There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
– Never refill a flacon with fragrance.
– Never use a faulty fragrance flacon.
Dispose of an empty fragrance flacon with the household waste
and never use it for any other purpose.
Please also observe the information supplied with the fragrance
flacon.
16
Warning and Safety instructions
Accessories
Only use genuine Miele spare parts and accessories with this
appliance. If spare parts or accessories from other manufacturers
are used, this will invalidate the warranty, and Miele cannot accept
liability.
A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the Miele
washing machine and Miele tumble dryer.
Miele cannot be held liable for damage caused by noncompliance with these Warning and Safety instructions.
17
Operating the tumble dryer
Control panel
a
Sensor
Takes you back a level in a menu.
b
Touch display
c
Start/Stop sensor
Touching the Start/Stop sensor starts the selected programme or cancels a
programme that has already started. The sensor flashes slowly as soon as it is
possible for a programme to be started and then lights up constantly after the
programme has started.
d
Optical interface
For service technicians.
e
button
For switching the tumble dryer on and off. To save energy, the tumble dryer will
switch off automatically. This occurs 15 minutes after the end of the
programme/Anti-crease phase, or after being switched on if no further selection
is made.
Touch display and sensor controls
The and Start/Stop sensors and the sensors in the display react to fingertip
contact.
The touch display can be scratched by pointed or sharp objects, e.g. pens.
Only touch the display with your fingertips.
18
Operating the tumble dryer
11:02
Programmes Favourites MobileControl
Help
11:02
Drying
assistant
Settings
Help
Main menu
After switching on the tumble dryer, the
main menu will appear in the display.
You access all the important submenus from the main menu.
Touch the sensor at any time to
return to the main menu. Please note
any programmes or Extras selected
that have not yet been confirmed with
the OK sensor will not be saved when
you return to the main menu.
Main menu page 1
You can scroll to the second page of
the main menu by swiping your finger
across the display.
Programmes
For selecting drying programmes.
Favourites
You can save up to 12 of your own
customised drying programmes (see
“Favourite programmes”).
MobileControl
With MobileControl you can operate your tumble dryer remotely with the Miele@mobile App.
TheRemote control setting must be
switched on.
Touch the MobileControl sensor control
and follow the instructions in the
display.
Drying assistant
The Drying assistant guides you step by
step so that you can select the
optimum drying programme for your
laundry (see “Drying assistant”).
Settings
You can alter the tumble dryer's
electronics to suit changing
requirements in the Settings menu (see
“Settings”).
Main menu page 2
19
Operating the tumble dryer
11:02
0:00
0:00
0:00 0:00
h
h
h
h
Programmes
Cottons
DelicatesCottons
Minimum iron
Help
11:02
OK
Extras
Gentle tumble
Freshen up
Examples on how to operate the appliance
Option lists
Programme menu
You can scroll to the right or the left by
swiping your finger across the screen.
To do this, place your finger on the
touch display and swipe it in the
direction you want.
The orange bar under the pictures
shows that there are further options to
choose from.
Touch a programme name to select the
drying programme.
Extras menu
Touch an Extra to select it.
The Extra will be highlighted in orange.
To deselect an Extra simply touch the
Extra again.
Activate the Extra with OK.
The display will change to the standard
display for that programme.
20
Operating the tumble dryer
OK
12 00
11 59
10 58
13 01
14 02
Clock display
11:02
2:35
Overview
Cottons
h
Timer Save
Drying level
Normal
Extras
not selected
Setting numerical values
You can set numerical values in some
menus.
Enter the numbers by swiping upwards
or downwards. Place your finger on the
number that you want to change and
move your finger in the direction you
want. Use the OK sensor to accept all
set numerical values.
Useful tip: Briefly touching an orange
number between the two lines will bring
up the numerical keypad. Once a valid
number has been entered, the OK
sensor will be highlighted green.
Pull-down menu
The pull-down menu can be used to
display information, e.g. about a drying
programme.
Touch the top edge of the screen in the
middle and drag down with your finger.
Help display
With some menus Help appears along
the bottom line of the display.
Touch the Helpsensor to display the
text.
Touch the Closesensor to return to
the previous screen.
Exiting a menu
Touch the sensor to return to the
previous screen.
Entries made before this which have not
been confirmed withOK will not be
saved.
21
Before using for the first time
Downtime after installation
Damage to the tumble dryer by
switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer,
wait for at least one hour before
switching it on.
Removing the protective foil and stickers
Remove:
– the protective foil from the door
– any stickers from the front and the lid
Please do not remove any labels
(e.g. the data plate) which are visible
when you open the door.
Miele@home
Your tumble dryer is equipped with an
integrated Wi-Fi module.
In order to use it you need:
– a Wi-Fi network
– the Miele@mobile App
– a Miele user account. The user
account can be created via the
Miele@mobile App.
The Miele@mobile App will guide you
as you connect your tumble dryer to
your home Wi-Fi network.
Once your tumble dryer is connected to
your Wi-Fi network, you can use the
App, for example, to carry out the
following activities:
– Operate the tumble dryer remotely
– Call up information on the operating
status of your appliance
– Call up information on the
programme sequence of your tumble
dryer
22
Connecting your tumble dryer to your
Wi-Fi network will increase energy
consumption, even when the tumble
dryer is switched off.
Before installing the tumble dryer in
its final location, ensure the signal
strength of your Wi-Fi network is
sufficient.
Miele@mobile App
You can download the Miele@mobile
App from the Apple App Store® or the
Google Play Store™ free of charge (only
functional in selected countries).
Switching on the tumble dryer
english (AU)
english (CA)
english (GB)
english (US)
Language
deutsch
dansk
Skip
Continue
Set up "Miele@home"?
Press the control.
The welcome screen will light up.
The display will guide you step by step
through the initial commissioning
process.
Before using for the first time
Setting the language
You will be asked to select the language
you require for the display. It is possible
to change the language at any time via
the Settings menu.
Scroll to the left or the right until the
language you want appears.
Touch the sensor for the language
you want.
The selected language will be
highlighted in orange and the display
will change to the next setting.
Setting up Miele@home
To set up Miele@home now: touch
the Continue sensor.
23
Before using for the first time
via WPS via App
Which connection method do you
want to use?
OK
12 00
11 59
10 58
13 01
14 02
Clock display
Useful tip: To postpone set-up until
later: touch the Skip sensor. The
following message will then appear in
the display:
It is possible to set up later in "Settings" /
"Miele@home".
Confirm with OK.
Select the connection method (either
via WPS or via App) you wish to use.
You will then be guided by the display
and the Miele@home App.
Setting the clock format
The time of day can be displayed as a
24-hour or 12-hour clock.
Select the clock format you want and
confirm this with the OK sensor.
The display will change to the next
setting.
Place your finger on the number that
you want to change and move your
finger in the direction you want.
Confirm with the OK sensor.
Further information will appear in the
display.
Continuing set-up
Refer to “1. Notes on correct laundry
care”.
You can then select a programme
and load the tumble dryer as
described in 2. Loading the tumble
dryer and 3. Selecting a programme.
The procedure for using for the first
time is completed when a programme
lasting longer than one hour has been
carried out in full.
Setting the time of day
This message only appears if the
tumble dryer has not yet been
connected to a Wi-Fi network.
The time of day is set automatically if
connection is established with a Wi-Fi
network.
24
Energy saving tips
Energy saving tips
This dryer with heat-pump technology
is designed for energy-saving drying
cycles. You can save even more
energy with the following measures,
because the drying time is not
extended unnecessarily.
– Make sure your laundry is spun at the
maximum spin speed before drying.
The higher the spin speed, the
greater the savings that can be made
in energy and time during drying, e.g.
approx. 20% energy can be saved if
spinning laundry at 1600rpm instead
of 1000rpm.
– Use the maximum load quantity for
the drying programme being used.
This will mean that the energy
consumption for the amount of
laundry is the most economical.
– Make sure that the room temperature
is not too high. If there are other heat
producing appliances in the room in
which the dryer is located, make sure
the room is well ventilated and switch
the other appliances off, if possible.
– If possible, make use of time-
variable, low-cost electricity tariffs.
Ask your energy supplier for
information. Your tumble dryer's
Delay start function will be useful as
you can select when during the next
24hours you want drying to start
automatically.
– Clean the fluff filters in the door
opening after every drying cycle.
Please refer to “Cleaning and care” for
information on cleaning the fluff filters
and the plinth filter.
25
Energy saving tips
11:02
2:35
Overview
Cottons
h
Timer Save
Drying level
Normal
Extras
not selected
Energy consumption
–– ––––––––
EcoFeedback
You can view information about the
energy consumption of your tumble
dryer in the pull-down menu.
The following information will appear in
the display:
– An estimate of the energy
consumption before the programme
ends.
– The actual energy consumption
during the programme or at the end
of the programme.
Open the pull-down menu.
1. Estimate
The estimated energy consumption
will be displayed as a bar chart before
the start of the programme.
2. Actual consumption
You can view the actual energy
consumption during the programme or
at the end of the programme.
If the energy consumption is too low to
be measured, < 0.1 kWh will be
displayed.
The consumption will alter as the
programme progresses.
At the end of the programme, before
opening the door, you can also call up
the filter soiling level as a %.
Filter soiling
0% = Light
50% = Normal
100% = Heavy
With increased soiling, the programme
duration is extended, which increases
energy consumption.
If the door is opened or the appliance
has switched off automatically at the
end of the programme, the data will
revert to the estimated consumption.
Useful tip: You can view the
consumption data for the last drying
programme and for total consumption
(see “Settings - Consumption”).
The more bars visible, the higher the
energy consumption.
The estimate will vary depending on the
drying programme, the drying level and
any Extras selected.
26
1. Notes on correct laundry care
Points to note regarding washed laundry
– When washing very heavily soiled
items, ensure that you use sufficient
detergent and select a high
temperature. If in doubt, wash the
items several times.
– Do not put soaking wet items into the
tumble dryer. Make sure your laundry
is thoroughly spun before drying. The
higher the spin speed, the greater the
savings that can be made in energy
and time during drying.
– New dark coloured garments should
be washed and dried separately from
light coloured garments to avoid the
risk of colours running and
discolouring other garments or even
plastic components in the dryer. Dark
coloured fibres can also settle on
light coloured garments and vice
versa.
– Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
Risk of fire due to incorrect use
and operation.
The laundry can burn and destroy
the dryer and the surroundings.
See “Warning and Safety
instructions” for further information.
– Sort the laundry according to the type
of fibre and weave, size, garment
care label symbol and the drying level
required.
– Check seams and stitching to ensure
that padding and linings are intact.
This way you will avoid the danger of
fillings coming out. These could catch
fire when being dried.
– Untangle the laundry.
– Tie together textile belts and apron
ties.
– Fasten duvet covers and pillow cases
to prevent small items from being
rolled up inside them.
– Fasten hooks and eyes.
– Leave jackets open and undo any
long zips so that textiles dry evenly.
Preparing the laundry before drying
Damage due to foreign objects
which were not removed from the
laundry.
Foreign objects can melt, burn, or
explode.
Ensure that any foreign objects, e.g.
detergent dispensing balls, lighters,
etc. have been removed from the
laundry.
– Sew in or remove loosened
underwiring from bras.
– Reduce the size of the load. Minimum
iron fabric tends to crease more the
larger the load. This is particularly the
case for garments made from very
fine weave fabric, such as shirts or
blouses.
27
1. Notes on correct laundry care
Drying
Useful tip: See the “Programme chart”.
It lists all programmes and their
maximum load.
– Always observe the maximum
recommended load for each
programme. This will mean that the
energy consumption for the amount
of laundry is the most economical.
– Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
Only use the Pre-ironing programme
for these textiles.
– Pure linen should only be tumble
dried if it is specified as suitable on
the care label. The surface of the
fabric may otherwise become rough.
Only use the Pre-ironing programme
for these textiles.
– Woollens and wool blends are
susceptible to becoming matted or
shrinking. Only use the Woollens
handcare programme for these
textiles.
– Loopknit garments (e.g. T-Shirts,
underwear) have a tendency to shrink
after the first wash. Do not overdry
these fabrics to prevent further
shrinking. When buying loopknit
garments, it is advisable to take their
shrinkage potential into account.
Care label symbols
Drying
Normal/higher temperature
Reduced temperature*
* Select Gentle tumble
Do not tumble dry
Ironing
Very hot
Warm
Selecting the correct drying level
– Extra dry for hard wearing and thicker
fabrics.
– Normal plus if you want to fold the
laundry after drying and put it away.
– Normal for textiles that can shrink,
such as light cotton or jersey textiles.
– Slightly dry for particularly delicate
garments that you wish to line dry
afterwards.
– Hand iron/ or Machine iron if you
want to iron the laundry after drying.
Hot
Do not iron
– With fabrics that are particularly heat-
sensitive or susceptible to creasing,
reduce the drying load and select
Gentle tumble.
28
2. Loading the tumble dryer
Loading the laundry
Textiles may be damaged.
Before loading the dryer, read “1.
Notes on correct laundry care.”
Unfold the laundry and load loosely
into the drum.
Do not overload the drum.
Overloading can cause unnecessary
wear and tear to the laundry and give
a disappointing drying result. It can
also cause more creasing.
Two positions for inserting a fragrance flacon
See the section “Fragrance flacon” for
information on how to use fragrance
flacons.
If you are not using a fragrance flacon:
push the tab down completely (see
arrow) so that the socket is closed.
Otherwise, lint will accumulate here.
Closing the door
When closing the door, make sure
that laundry does not get trapped in
the door opening.
This can result in damage to the
laundry.
Shut the door with a gentle swing.
29
3. Selecting a programme
11:02
0:00
0:00
0:00 0:00
h
h
h
h
Programmes
Cottons
DelicatesCottons
Minimum iron
Help
11:02
2:35
Overview
Cottons
h
Timer Save
Drying level
Normal
Extras
not selected
Switching on the tumble dryer
To switch on, press the button.
Selecting a programme
There are different ways to select a
programme:
Touch the Programmes sensor.
Scroll to the right of the display until
the programme you want appears.
Touch the sensor for that programme.
The display will change to show the
Overview menu.
There are 3 further ways of selecting a
programme.
1. Favourites
2. Drying assistant
3. MobileControl
Useful tip: In the pull-down menu, you
can display the maximum
recommended load for the selected
programme.
30
4. Selecting programme settings
11:02
2:35
Overview
Cottons
h
Timer Save
Drying level
Normal
Extras
not selected
11:02
Drying level
Machine iron Hand iron
Normal
Hand iron Slightly dry Normal plus
11:02
0:20
Overview
Warm air
h
Timer Save
Extras
not selected
h
Duration
0:20
Programme settings
Selecting a drying level with a drying programme
Cottons, Minimum iron, Delicates, Bed
linen, Automatic, Express, Shirts,
Denim, Steam care, Sportswear,
Outerwear, Pre-ironing
The preset drying level for the
programme can be changed if
required.
Touch the Drying level sensor.
Any drying level can be selected for the
Cottons, Express, and Bed linen
programmes. A limited range is
available with the other programmes.
When selecting the Steam care
programme, you must make sure that
the condensed water container has
been filled as described in these
operating instructions (see
“Condensed water container”).
Selecting timed drying programmes and other programmes
Cottons , Woollens handcare, Silks
handcare, Proofing, Standard pillows,
Large pillows, Cottons hygiene
The drying level is preset by the dryer
and cannot be altered.
Warm air, Cool air, Basket programme
You can change the duration in 10minute increments.
Scroll in the display until the drying
level you want appears.
Touch the sensor for the drying level.
Cool air: 20min – 1:00h
Warm air: 20min – 2:00h
Basket programme: 40min – 2:30h
Touch the Duration sensor (only in
Cool air, Warm air and Basket
programmes).
31
4. Selecting programme settings
OK
00 20
02
Reset
Duration
40
01 30
02 40
5001
11:02
h
11:02
2:35
Overview
Cottons
h
Timer Save
Drying level
Normal
Extras
not selected
11:02
OK
Extras
Gentle tumble
Freshen up
Selecting Extras
Place your finger on the number that
you want to change and move your
finger in the direction you want.
– Warm air
Confirm with the OK sensor.
– Cool air, Basket programme
Touch the Start/Stop sensor.
The programme will start.
Touch the Extras sensor.
Touch the sensor for the Extra you
want.
32
Useful tip: Touching the sensor for an
Extra again allows you to deselect it.
You can only select one Extra as they
cannot be combined with one another.
See “Extras” for descriptions.
Confirm with the OK sensor.
The symbol for the selected Extra is
displayed.
5. Starting the programme
11:02 Status
Cottons
Time left
Machine iron
Perfect Dry
h1:42
Starting a programme
The programme can be started when
the Start/Stop sensor is flashing on and
off.
Touch the Start/Stop sensor.
The Start/Stop sensor lights up
constantly.
Drying and the programme duration
remaining will light up in the display.
The laundry will be cooled down shortly
before the end of the programme.
Useful tip: In the pull-down menu you
can view the selected drying level or
duration and the energy consumption.
With programmes with a selectable
drying level, PerfectDry calculates the
residual moisture present in the laundry
to ensure precise drying results. If a
small load or dry laundry is placed in
the dryer, it is dried/aired for a preset
duration.
– Solid dot when the drying level is
reached
The time left for the drying level
programmes can vary or “jump”. It
depends on the load quantity, type of
laundry, residual moisture in the laundry
or water hardness. PerfectDry
continually adapts, constantly
increasing the accuracy of the time left.
Laundry items and fabrics can wear
out unnecessarily.
Avoid over-drying laundry and
garments.
Energy savings
After 10minutes, the indicators dim and
the Start/Stop sensor starts flashing.
Touch the Start/Stop sensor to switch
the indicators on again (this does not
have any effect on a running
programme).
The drum lighting switches off once the
programme has started.
The PerfectDry display will only light up
with programmes with selectable drying
levels:
– Hollow dot after a programme has
started
The drying level reached will still be
shown later on.
33
6. End of programme - unloading the drum
At the end of the programme
The programme is finished when Finish/
Anti-crease appears in the display. The
Start/Stop sensor will no longer light up.
The dryer will switch off automatically
15minutes after the end of the Anticrease phase (or 15minutes after the
programme with programmes without
an Anti-crease phase).
Removing the laundry
Only open the door when the drying
process has finished. Otherwise, the
laundry will not be properly dried and
cooled down.
Reach under the door grip and pull
the door open.
Remove the fluff from the two fluff
filters in the door opening (see
“Cleaning and care - Fluff filters”).
Shut the door with a gentle swing.
Empty the condensed water
container.
Useful tip: The condensed water can
be used for the Steam care programme.
See “Condensed water container Preparing the condensed water
container for Steam care”.
We recommend that you drain the
condensed water externally through the
drain hose when drying a full load using
the Cottons and Cottons
programmes. This will avoid having to
empty the condensed water container
during the programme.
Drum lighting
The lighting helps to ensure that all
items are removed from the drum.
The drum lighting will go out
automatically to save energy.
Remove the laundry.
Always remove all items from the
drum.
Items left in the dryer could be
damaged by overdrying when the
dryer is used the next time.
Press the button to switch the
tumble dryer off.
34
Useful tip: To switch the lighting on
again, open the pull-down menu from
the overview menu and then touch the
sensor.
Programme chart
All weights marked with * are based on the weight of dry laundry.
Cottons Max. load 9.0 kg*
Items Cotton items such as those described under Cottons Normal with
normal residual moisture.
Notes Items are dried to a Normal level only.
Cottons Max. load 9.0 kg*
Extra dry, Normal plus, Normal, Slightly dry
Items Single and multi-layered cotton fabrics. For example: towelling,
jerseywear, T-shirts, underwear, baby clothes, workwear, covers,
aprons, jackets, bathrobes, and flannelette bed linen.
Notes – Select Extra dry for multi-layered and very thick fabrics.
– Do not use Extra dry for jersey fabrics (e.g. T-shirts, underwear), as
they have a tendency to shrink.
Hand iron , Hand iron , Machine iron
Items Cotton or linen fabric requiring further processing.
For example: table linen, bed linen, or starched laundry.
Notes Roll up laundry that you want to iron to prevent it from drying out,
until you are ready for ironing.
Minimum iron Max. load 4.0 kg*
Normal plus, Normal, Slightly dry, Hand iron, Hand iron
Items Minimum iron items made of cotton, synthetic, or mixed fibre. For
example: workwear, overalls, pullovers, dresses, trousers, table linen
and leggings.
Delicates Max. load 2.5 kg*
Normal plus, Normal, Slightly dry, Hand iron, Hand iron
Items Delicate items with the symbol on the care label made of
synthetic fibre, mixed fibre, rayon, and easy care cotton. For
example: shirts, blouses, lingerie, and appliquéd garments.
Notes The load should be reduced further for a particularly crease-free
drying result.
35
Programme chart
Bed linen Max. load 4.0 kg*
Extra dry, Normal plus, Normal, Slightly dry, Hand iron, Hand iron,
Machine iron
Items Bed linen, pillow cases.
Automatic Max. load5.0kg*
Normal plus, Normal, Slightly dry, Hand iron, Hand iron
Items Mixed loads of garments suitable for the Cottons and Minimum iron
programmes.
Woollens handcare Max. load2.0kg*
Items Woollen garments and fabric containing wool blends, e.g. pullovers,
cardigans, stockings.
Notes – Wool and wool blend items are only fluffed up; they are not dried
completely.
– Remove garments as soon as the programme has finished.
Silks handcare Max. load1.0kg*
Items Silk garments which are suitable for drying in a tumble dryer, e.g.
blouses and shirts.
Notes – This programme reduces creasing. Items are not dried completely.
– Remove garments as soon as the programme has finished.
Express Max. load 4.0 kg*
Extra dry, Normal plus, Normal, Slightly dry, Hand iron, Hand iron,
Machine iron
Items Hard-wearing garments suitable for the Cottons programme.
Notes The programme duration is shorter.
Shirts Max. load 2.0 kg*
Normal plus, Normal, Slightly dry, Hand iron, Hand iron
Items Shirts and blouses.
Denim Max. load 3.0 kg*
Normal plus, Normal, Slightly damp, Hand iron, Hand iron
Items Denim garments, e.g. jackets, jeans, shirts, and skirts.
36
Programme chart
Steam care Max. load 1.0 kg*
Normal, Hand iron
Items – Cotton and linen fabric.
– Minimum iron items made of cotton, synthetic or mixed fibre. For
example: cotton trousers, jackets, anoraks, and shirts.
Notes – For dampening items before ironing.
– For smoothing items that are creased.
– Select Hand iron if the items are to be ironed after drying.
Notes – At the beginning of the programme, the condensed water
collected in the condensed water container is sprayed into the
drum via a spray jet. The condensed water container must
therefore be filled with water to at least the –min– marker.
– You may hear a humming noise when the water is sprayed into the
drum.
Sportswear Max. load 3.0 kg*
Normal plus, Normal, Slightly dry, Hand iron, Hand iron
Items Sportswear which is suitable for drying in a tumble dryer.
37
Programme chart
Basket programme Max. load for basket 3.5 kg
Notes – This programme must only be used with the Miele drying basket
TRK 555 (optional accessory) fitted.
– It is essential to observe the operating instructions for the drying
basket.
– Make sure that the load (bag, boots ...) does not touch the drum:
The dryer drum rotates, which can damage the basket and the
drum if loaded incorrectly.
Fabric
type/Items
Outerwear Max. load 2.5 kg*
Normal, Hand iron
Items Outerwear which is suitable for drying in a tumble dryer.
Proofing Max. load 2.5 kg*
Items Microfibre fabric, skiwear, outerwear, fine close weave cotton
Notes – Items are dried to a Normal level only.
Use this programme to dry or air items which are suitable for drying
in a tumble dryer but which are not suitable for drying using
mechanical action.
garments (poplin), or tablecloths which are suitable for drying in a
tumble dryer and have been treated to provide a water and dirtresistant finish.
– This programme includes a proofing fixing phase.
– Only use proofing agents which are stated by the manufacturer as
being “suitable for use on membrane textiles”. These agents
contain fluorochemical compounds.
– Do not dry items which have been treated with proofing agents
containing paraffin. Fire hazard!
38
Programme chart
Warm air Max. load 9.0 kg*
Items – For completely drying multi-layered fabrics whose layers have
different drying characteristics, e.g. jackets, pillows, sleeping bags
and other voluminous items.
– For drying individual items, e.g. bath towels, bathing suits, tea
towels and small loads.
Notes Do not select the longest drying time to start with. Check the items
as you are drying them to find the optimum time.
Cool air Max. load 9.0 kg*
Items Any item which only needs airing.
Standard pillows
Large pillows
Items Pillows suitable for drying in a tumble dryer, with feather, down, or
synthetic fillings.
Notes Items are dried to a Normal level only.
Notes – Feathers are a natural product and may develop odours when
exposed to heat. Allow bedding to air outside the dryer after
drying.
– Pillows can still feel damp after being dried. You can use this
programme several times until the pillow feels dry.
Cottons hygiene Max. load 4.0 kg*
Items Cottons and linen fabric which will be in direct contact with the skin,
e.g. underwear, baby clothes, bed linen, towelling.
Notes In this programme, the items will be dried to Normal level with a
temperature that is constant over an extended period. This
temperature holding time kills off micro-organisms such as germs or
dust mites and reduces allergens in the laundry. Therefore, this
programme should not be interrupted as this would prevent the
micro-organisms from being killed off.
1-2 pillows 40x80cm or
1 pillow 80 x 80 cm
39
Programme chart
Pre-ironing Max. load 1.0 kg*
Normal, Hand iron
Items – Cotton and linen fabrics.
– Minimum iron items made of cotton, synthetic or mixed fibre. For
example: cotton trousers, jackets, anoraks, and shirts.
Notes – This programme smoothes out creasing caused during the spin
cycle in the washing machine.
– This programme is also suitable for dry fabrics.
– Please remove the garments as soon as the programme has
finished.
40
The drying programmes can be
supplemented with various Extras. The
table lists the selection options.
Gentle tumble
Delicate fabric (with the symbol on
the care label, e.g. acrylic garments) is
dried at a lower temperature. The
programme duration is longer.
Freshen up
You can use the Freshen up Extra to
help remove or reduce odours in clean
(dry or damp) clothing.
The drying air is heated for a specific
length of time. After this, the garments
are aired to the Normal drying level
without any more heat being added.
The drying level cannot be altered.
This Extra will be more effective if you
dampen the garments a little
beforehand, use a fragrance flacon and
reduce the load. Please note that
odours will not be removed as
effectively from parts of garments made
of synthetic fibres.
Extras
41
Extras
Drying programme overview - Extras
Freshen up
Cottons – –
Cottons X X
Minimum iron X X
Delicates –
Bed linen – –
Automatic – X
Woollens handcare – –
Silks handcare – –
Express – –
Shirts X X
Denim X X
Steam care – –
Sportswear – X
Basket programme – –
Outerwear –
Proofing – –
Warm air – X
Cool air – –
Standard pillows
Large pillows
Cottons hygiene – –
Pre-ironing –
1
– –
Gentle tumble
1
1
= these Extras cannot be combined
X = can be selected
– = cannot be selected
= automatically selected
42
Favourite programmes
Creating a Favourite programme
You can save your own customised
programmes under names of your
choice.
There are two ways to create a
Favourite programme.
Option 1
The main menu must be visible in the
display. Touch the Favourites sensor.
The display will change to show the
Favourites menu.
Touch the Create sensor.
The display will change to show the
Create Favourites menu.
Select the required programme.
Select all the programme settings you
want.
Then select Save.
Entering a name
It is best to select short, memorable
names.
Touch the letters or characters you
want.
Confirm with the Save sensor.
The programme will then be saved to
the Favourites programme list.
Changing a Favourite programme
You can rename, delete or move a
Favourite programme.
Select Favourites from the main menu.
Touch the Favourite programme that
you wish to change until the context
menu opens.
Select Rename, Delete or Move.
Enter a name.
Option 2
You can save a programme which has
been selected as a Favourite
programme before you start it.
Before the programme starts, touch
the Save sensor.
Enter a name.
If 12 Favourites have already been
saved, the Create or Save sensor
will not be visible. Delete an existing
Favourite if you wish to create a new
one.
43
Drying assistant
OK
Purpose
Drying
Proofing /
Reactivation
Smooth damp
items
Smooth dry
items
11:02
OK
Fabrics
Shirts
Denim
T-shirts
Blouses
11:02
The Drying assistant helps you when
drying a wide variety of items. The
tumble dryer will use the list of items to
put together a suitable drying
programme.
Scroll to the second page in the main
menu.
Touch the Drying assistant sensor.
A list will open. The drying purpose is
grouped into different areas.
Useful tip: Touch the sensor to find
out more about each purpose.
Touch the sensor for the Purpose
which matches your drying
requirement.
A list of items will appear.
Touch the appropriate sensor for your
item of laundry.
The item selected will be highlighted
orange. You can select several items.
With some items, helpful information
will also appear in the display when
they are selected.
Confirm with the OK sensor.
Follow the instructions in the display.
A summary of the selected parameters
will then appear in the display.
Confirm with the OK sensor or select
Change if you would like to make any
changes.
44
The programme which has been
tailored to your laundry is ready to start.
Useful tip: You can add individual
programme settings, e.g. Extras before
you start the programme.
Timer
The Timer can be used to set the time
at which a programme starts or finishes.
The programme start can be delayed by
up to 24hours.
Setting the Timer
Touch the sensor.
Select the Finish at or Start at option.
Set the hours and the minutes and
confirm your entry with the OK
sensor.
Changing the Timer
The selected Timer can be changed
before the programme starts.
Touch the or sensor.
Change the time set and confirm with
the OK sensor.
Deleting the Timer
The selected Timer can be deleted
before the programme starts.
Touch the or sensor.
The selected time will appear in the
display.
Touch the Delete sensor.
Confirm with the OK sensor.
The time set for the Timer is deleted.
Starting the Timer
Touch the Start/Stop sensor.
The time until the programme starts will
appear in the display.
After the programme has started, the
selected finish time can only be
changed or cancelled by interrupting
the programme.
The programme can now be started.
Touch the Start immediately sensor.
With a longer delayed start time, the
drum will rotate occasionally to
untangle the laundry. This is not a fault.
45
Timer
SmartStart
The SmartStart function (only available
in selected countries) lets you define a
time period during which your tumble
dryer will start automatically. The
appliance will start on receipt of a
signal, e.g. from your energy supplier,
that indicates that the electricity rate is
particularly economical.
This function is active when the
SmartGrid setting is switched on.
The timeframe can be defined between
1minute and 24hours. During this
period, the tumble dryer waits for the
signal from the energy supplier. If no
signal is sent during the defined period,
the tumble dryer starts the drying
programme.
Setting the timeframe
If you have activated the SmartGrid
function in Settings, SmartStart by or
SmartFinish by will appear in the
display instead of Start at or Finish at
when you touch the sensor (see
“Settings – SmartGrid”).
The procedure for setting this is the
same as for setting the Timer.
Set the time you want and confirm
with the OK sensor.
Touch the Start/Stop sensor to start
the drying programme with
SmartStart.
The selected programme will start
automatically, as soon as the energy
provider has sent the signal, or the
latest calculated start time has been
reached.
The procedure for changing or
deleting the SmartStart function is the
same as described for the Timer
function.
46
Changing the programme sequence
Changing a programme after it has started
You cannot change to another
programme once a programme has
started (this prevents unintentional
alterations).
You will need to cancel the current
programme before you can select a
new one.
Risk of fire due to incorrect use
and operation.
The laundry can burn and destroy
the dryer and the surroundings.
See “Warning and Safety
instructions” for further information.
Cancelling a programme
Touch the Start/Stop sensor.
The following appears in the display:
Cancel the programme?
Select yes.
The following appears in the display:
Programme cancelled
Adding or removing laundry
Risk of burning when touching
hot laundry in the drum!
You could burn yourself.
Let the laundry cool down and
remove it carefully.
Pull open the door.
Add or remove items.
Close the door.
Touch the Start/Stop sensor.
The programme will start.
Adding laundry during the Delay start period
You can open the door to add or
remove laundry.
– All programme settings will be saved.
– You can change the drying level, if
required.
Open the door.
Add or remove laundry.
Open the door.
Selecting another programme
Close the door.
Select the required programme.
Touch the Start/Stop sensor.
Close the door.
Touch the Start/Stop sensor so that
the Delay start period continues.
Programme duration
Altering the programme sequence can
cause the programme duration shown
in the display to be adjusted.
47
Condensed water container
Emptying the condensed water container
The condensed water is collected in
the condensed water container.
Empty the condensed water container
after every drying programme.
When the maximum level in the
condensed water container is reached,
Empty the container or check the drain
outlet. will light up.
To delete the message:
Open and close the door (with the
dryer switched on).
Empty the container.
Replace the container in the dryer.
Damage to the door and the
fascia panel when removing the
condensed water container.
The door and the fascia panel can
get damaged.
Always close the door completely.
Pull out the condensed water
container.
To prevent water running out, keep it
in a horizontal position when carrying
it. Hold the condensed water
container by the front panel and at
the back.
Condensed water can cause health
problems in people and animals.
Do not drink condensed water.
The condensed water can be used for
the Steam care programme (see the
following section).
48
Preparing the condensed water container for Steam care
During Steam care, the condensed
water collected in the condensed
water container is sprayed into the
drum via a spray jet. The condensed
water container must therefore be
filled with water to at least the –min–
marker. Otherwise, this could cause a
fault.
Condensed water container
The –min– marker is at the front lefthand side of the container.
Make use of the condensed water
which collects during the drying
process.
Filling the empty condensed water container
You can fill the condensed water
container with commercially available
condensed water (ironing water).
1 spout, 2 rubber seal
Pour the water in through the rings on
the spout 1.
The spray jet in the door opening
may clog.
Only fill with clean water. Do not add
fragrances, detergents or other
substances.
Checking the rubber seal periodically
If tap water is used frequently, white
limescale deposits can build up on the
rubber seal 2.
Use a damp cloth to carefully remove
any limescale deposits from the
rubber seal 2.
You should only use tap water in
exceptional cases. If tap water is used
frequently, the spray jet in the door
opening can become calcified.
49
Fragrance flacon
FragranceDos – 2 positions for inserting a fragrance flacon
Fragrance flacons (optional
accessories) can be used to give your
laundry a pleasant scent.
This dryer has 2 places for inserting
fragrance flacons. This gives you a
choice of how to use them.
– Use both positions if you wish to
change from one scent to another.
You can close the fragrance flacon
that you are not using.
– Both positions can be used for a
more intense scent of the same
fragrance.
– Use one socket only if you only want
to use the one fragrance.
Risk of fire and harm to health if
fragrance flacons are used
incorrectly.
Leaked fragrance can be harmful to
your health if it comes into contact
with your body. Leaked fragrance
can cause a fire.
Before using a fragrance flacon,
please read the section "Using a
fragrance flacon (optional
accessory)” in the Warning and
Safety instructions.
Using a fragrance flacon
Removing the protective seal from the fragrance flacon
Only hold the fragrance flacon as
illustrated. Do not hold it at an angle
or tip it as the fragrance will leak out.
Hold the fragrance flacon securely so
that you do not open it by mistake.
Pull off the protective seal.
50
Inserting the fragrance flacon
Open the door of the tumble dryer.
The fragrance flacon is inserted in the
upper fluff filter. It can be inserted on
the left or the right-hand side beside
the grip.
Fragrance flacon
Insert the fragrance flacon in the
opening as far as it will go.
Open the cover using the tab until the
tab is right at the top as shown
To prevent the accumulation of fluff,
the cover of the unused socket must
remain closed.
Push the tab of the cover to the
bottom (see arrow), until you hear it
click into position.
Markers and must line up with
each other.
51
Fragrance flacon
Turn the outer ring clockwise a
little.
The fragrance flacon can slip out.
Turn the outer ring so that markers
and line up.
Opening the fragrance flacon
Before drying, you can select the
intensity of the fragrance.
The fragrance will also be noticeable in
the room air during the process. The
Cool Air programme will not generally
apply fragrance.
Closing the fragrance flacon
After drying, the fragrance flacon should
be closed to prevent the fragrance from
escaping needlessly.
Turn the outer ring anti-clockwise
until marker b is in position _.
Turn the outer ring clockwise: the
further you open the fragrance flacon,
the more intense the fragrance.
Damp laundry and longer drying
durations with sufficient heat transfer
are needed for the fragrance to be
released into the laundry effectively.
52
If you wish to dry laundry without
adding fragrance: remove the
fragrance flacon and store it in its
original packaging.
When the intensity of the fragrance is
no longer sufficient, replace the
fragrance flacon with a new one.
Removing/replacing the fragrance flacon
Turn the outer ring anti-clockwise
until markers a and b line up.
Fragrance flacon
Fragrance can leak.
Do not lay the fragrance flacon
down.
Replace the fragrance flacon with a
new one.
When not in use, you can store the
fragrance flacon in its original
packaging.
Fragrance flacons are available to
order from Miele or online at
www.miele-shop.com.
– If you are keeping the fragrance
flacon in its original packaging, do
not store the packaging upright on its
edge or upside down. Otherwise, the
fragrance will leak out.
– Always store in a cool, dry place
away from direct sunlight.
– When purchasing new fragrance
flacons, only remove the protective
seal just before use.
53
Cleaning and care
Fluff filters
This tumble dryer has 2 fluff filters in
the door opening: the upper and lower
fluff filters trap fluff produced during
the drying process.
Clean the fluff filters after each drying
programme. This prevents an
extension of the programme duration.
Also clean the fluff filters when Clean
the fluff and plinth filters. See the operating
instruction manual. lights up.
To delete the message:
Confirm with OK.
Removing the fragrance flacon
The intensity of the fragrance will be
diminished if the fluff filters and the
plinth filter are not cleaned.
Remove the fragrance flacon. See
“Fragrance flacon - Removing/
replacing the fragrance flacon”.
Removing visible fluff
Useful tip: You can use a vacuum
cleaner so that you can remove the fluff
without touching it.
Open the door.
Pull the upper fluff filter forwards to
remove it.
54
Remove the fluff (see arrows).
Cleaning and care
Remove the fluff from the filter
surface of all the fluff filters and the
perforated laundry deflector (see
arrows).
Push the upper fluff filter back until it
clicks into position.
Close the door.
Cleaning the fluff filters and air flow openings thoroughly
If the drying duration has become
longer or the surface of the filters is
visibly compacted with fluff, you
should clean them thoroughly.
Remove the fragrance flacon. See
“Fragrance flacon-Removing/
replacing the fragrance flacon”.
Pull the upper fluff filter forwards to
remove it.
Turn the yellow dial on the lower fluff
filter in the direction of the arrow (until
you hear it click).
Hold the dial and pull the fluff filter
forwards to remove it.
55
Cleaning and care
Use a vacuum cleaner with a long
crevice nozzle attached to remove
any visible fluff from the upper air
flow openings.
Finally, clean the fluff filters with water.
Cleaning the fluff filters with water
Wipe the smooth plastic surfaces of
the fluff filters with a damp cloth to
clean them.
Rinse the filters with warm running
water.
Shake the fluff filters thoroughly and
then dry them carefully.
Ensure the filters are dry before
replacing them. Wet filters could
cause operational faults.
Push the lower fluff filter in
completely and lock it with the yellow
dial.
Push the upper fluff filter in
completely.
Close the door.
56
Cleaning and care
Cleaning the plinth filter
Clean the plinth filter when Clean the
fluff and plinth filters. See the operating
instruction manual. lights up or when the
programme duration has been
extended.
To delete the message:
Confirm with OK.
Removing the plinth filter
Press the round, indented area on the
heat exchanger access panel to open
it.
The panel will spring open.
Pull the plinth filter out by the handle.
Removing the plinth filter will cause the
right-hand guide pin in the dryer to
come out. This pin ensures that the
heat exchanger access panel can only
be closed if the plinth filter is inserted
the right way round.
57
Cleaning and care
Cleaning the plinth filter
Pull the handle out of the plinth filter.
Clean the filter thoroughly under
running water.
Squeeze the water out of the plinth
filter thoroughly.
The plinth filter must not be replaced
dripping wet. This can cause a fault.
Use a damp cloth to remove any fluff
from the handle.
Cleaning the plinth filter panel
Use a damp cloth to remove any fluff.
Make sure that you do not damage
the rubber seal when doing this.
Check whether the cooling fins are
blocked with fluff (as follows).
58
Cleaning and care
Checking the heat exchanger unit
Risk of injury from sharp cooling
fins.
You could cut yourself.
Do not touch the cooling fins.
Look to see if fluff has accumulated.
If there is visible soiling:
Damage due to incorrect
cleaning of the heat exchanger.
The dryer will not dry if the cooling
fins are damaged or bent.
Clean using a vacuum cleaner with a
dusting brush attached. Only pass
the vacuum cleaner dusting brush
over the fins lightly, without applying
any pressure.
Inserting the plinth filter
Fit the plinth filter back on the handle
the right way round.
To ensure that the filter is positioned
correctly in the front of the heat
exchanger unit:
Carefully vacuum up any visible fluff
or dirt.
Insert the handle with the plinth filter
facing the right way onto the two
guide pins.
– The word Miele on the handle must
be the correct way up.
Push the plinth filter in completely.
Insert the right guide pin at the same
time.
Close the heat exchanger access
panel.
59
Cleaning and care
Damage or ineffective drying
when drying without a plinth filter or
with the heat exchanger flap open.
An excessive accumulation of fluff
can damage the dryer in the long
term. If the system is not leak-proof,
this can lead to ineffective drying.
You may only operate the dryer with
the plinth filter fitted correctly and the
heat exchanger access panel closed.
Cleaning the dryer
Disconnect the dryer from the
electricity supply.
Damage due to the use of
unsuitable care products.
Unsuitable care products could
damage plastic surfaces and other
parts.
Do not use solvents, abrasive
cleaners, glass cleaners or allpurpose cleaners.
60
Clean the dryer and the seal on the
inside of the door only with a slightly
damp, soft cloth and mild detergent
or soapy water.
Dry all parts with a soft cloth.
Problem solving guide
With the help of the following guide, minor faults in the performance of the
appliance, some of which may result from incorrect operation, can be remedied
without contacting Miele. This will save you time and money because you won't
need a service call.
Please note that a call-out charge will be applied to unnecessary service visits
where the problem could have been rectified as described in these operating
instructions.
The display indicates the following messages or faults
Message Possible cause and remedy
Fill the condensate
container with water
Please open and
close the door
Clean the fluff and
plinth filters. See the
operating instruction
manual. lights up
at the end of a
programme.
000 lights up after
switching on.
This is to remind you that water is taken from the
condensed water container when the Steam care
programme is being used. The condensed water
container must be filled with water to at least the
–min– marker.
Fill the condensed water container as described
under “Condensed water container”.
To switch off the message:
Confirm with OK.
After selecting the Steam care programme, you are
alerted to load laundry.
Load the laundry in the drum.
There is a build-up of fluff.
Clean the fluff filters.
Clean the plinth filter.
See “Cleaning and care”.
To switch off the message:
Confirm with OK.
You can influence when the indicator lights up: see
“Settings – Airways indicator”.
Access via a code has been activated.
Enter the code and confirm the entry. Deactivate
the code if you do not wish this message to
appear in the display the next time the machine is
switched on (see “Operation/display - Code”).
61
Problem solving guide
Message Possible cause and remedy
Finish/Cooling down The laundry is cooled down at the end of the
programme.
Either remove the laundry and spread it out to cool
down or leave it in the tumble dryer to cool down
during the cooling phase.
Clean the fluff filter.
Check the airways.
lights up after a
programme has
been cancelled.
Empty the container
or check the drain
outlet. lights up
after a
programme has
been cancelled.
Obstruction
detected. Untangle
laundry and restart.
lights up after a
programme has
been cancelled.
An excessive amount of fluff has built up.
Clean the fluff filters.
Clean the plinth filter.
Clean the air duct area below the fluff filters.
Clean the heat exchanger.
To delete the fault:
Switch the dryer off and then on again.
The condensed water container is full or there is a
kink in the drain hose.
Empty the condensed water container.
Check the drain hose.
To delete the fault:
Open and close the door while the dryer is
switched on or switch the dryer off and back on.
The laundry is unevenly distributed or has rolled up.
Open the door and loosen the laundry. Remove a
few items, if necessary.
Switch the dryer off and then back on.
Start a programme.
Fault F. If restart
fails, call Miele.
lights up after a
programme has
been cancelled.
62
There is no obvious cause.
Switch the dryer off and then on again.
Start a programme.
If the programme terminates again with the same
error message, then there is a fault. Contact Miele.
Problem solving guide
Unsatisfactory drying results
Problem Possible cause and remedy
The laundry is not
sufficiently dry.
Laundry or feather filled
pillows smell after
drying.
Items made of synthetic
fibres are charged with
static electricity after
drying.
There is a build-up of
fluff.
The load consisted of different types of fabric.
Finish drying using the Warm air programme.
Select a more suitable programme next time.
Tip: You can alter the residual moisture level for some
programmes. See “Settings - Drying levels”.
The laundry was washed with insufficient detergent.
Feathers are a natural product and this is quite
normal.
Laundry: use sufficient detergent next time.
Pillows: take out of the tumble dryer and aerate.
Use a fragrance flacon (available as an optional
accessory).
Synthetic fibres tend to attract static charge.
Static charge can be reduced by adding a fabric
softener to the final rinse in the washing
programme.
Fluff is principally the result of friction when garments
are being worn and to some extent when they are
being washed. Machine drying hardly causes any fluff
to form.
Fluff is collected by the fluff filters and the plinth filter
and can be removed easily.
See “Cleaning and care”.
63
Problem solving guide
The drying process takes a long time.
Problem Possible cause and remedy
The drying process
goes on too long or
even switches off.*
The room in which the tumble dryer is located is too
warm.
Ventilate the room thoroughly.
Detergent residues, hair and fine fluff can clog the
filters.
Clean the fluff filters and the plinth filter (see
“Cleaning and care - Fluff filters and Cleaning the
plinth filter”).
Remove any visible fluff from the heat exchanger
(see “Cleaning and care - Cleaning the plinth
filter”).
The laundry is unevenly distributed or has rolled up.
The tumble dryer has been overloaded.
Untangle the laundry and remove a few items, if
necessary.
Start a programme.
The cool air intake (bottom right grille) is blocked.
Move any objects, such as a laundry basket, away
from the dryer.
The fluff filters and the plinth filter were wet when
replaced.
The fluff filters and the plinth filter must be dry.
The laundry is too damp.
Spin using a higher spin speed in the washing
machine.
Metallic components, e.g. zippers, have prevented
the dryer from registering the correct moisture level.
Open the zippers next time.
If the problem recurs, dry these items using the
Warm air timed drying programme.
* Switch the tumble dryer off and on again before starting a new programme.
64
Problem solving guide
General problems with the tumble dryer
Problem Possible cause and remedy
There are operating
noises (whirring/
humming).
A programme cannot be
started.
The display is dark and
the Start/Stop sensor is
flashing slowly.
The dryer is switched
off at the end of the
programme.
The display is in a
different language.
The interior drum
lighting does not come
on.
This is not a fault.
The compressor (heat pump) is operating or you have
selected the Steam care programme.
No action is required. These are normal noises
caused by the operation of the compressor or
condensate pump.
There is no obvious cause.
Connect the tumble dryer to the mains electricity
supply.
Turn on the tumble dryer.
Close the door.
Check whether the mains fuse has tripped.
Has there been a power cut? When power is
restored, any previously running programme will
restart automatically.
The display has switched off automatically to save
energy (Standby mode).
The drum will rotate from time to time when the dryer
is in the Anti-crease phase.
Touch any sensor. This switches Standby off.
The tumble dryer switches off automatically. This is
not a fault, but a normal function.
See “Settings - Appliance switch-off status”.
A different language has been selected in “Settings Language ”.
Set the language you want. The flag symbol serves
as a guide.
This is not a fault. The drum lighting switches off
automatically in the following cases:
If the door is closed.
If the door remains open for an extended period of
time.
65
Problem solving guide
Problem Possible cause and remedy
Insufficient jet spray for
the Steam care
programme.
The fluff filter in the condensed water container is
clogged.
Clean the fluff filter in the condensed water
container. See the section “Cleaning the fluff filter
in the condensed water container” in this chapter.
The spray jet in the door opening is heavily calcified.
Replace the spray jet. See the section “Replacing
the blocked spray jet for the Steam care
programme” in this chapter.
Only use condensed water. Do not use tap water.
Tap water leads to limescale deposits in the long run.
66
Cleaning the fluff filter in the condensed water container
If you are experiencing problems
running the Steam care programme,
the fluff filter at the end of the hose
which is connected to the rubber seal
in the condensed water container
could be blocked.
Problem solving guide
Do not pull on the hose with force.
Otherwise it will come loose.
Guide the end of the hose through
the opening.
Hold it securely with one hand.
Use your other hand to pull the fluff
filter off the hose.
Pull out the condensed water
container.
Reach under the side lug on the
spout with your finger.
Pull out the spout.
Rinse the fluff filter with a jet of water
until all the fluff has been removed.
Reattach the cleaned fluff filter onto
the end of the hose.
Now feed the hose with its fluff filter
attached into the condensed water
container.
Refit the spout in the condensed
water container ensuring that it is
positioned correctly. Please refer to
the image.
67
Problem solving guide
Replacing the blocked spray jet for the Steam care programme
Limescale deposits will impair the
water jet of the spray jet.
In this case, the spray jet must be
removed and replaced with a new one
(optional accessory).
You can only replace the spray jet
using a special tool. The special tool is
supplied with the new spray jet.
Using the wrong tool can cause
damage.
It can damage the spray jet or the
tumble dryer.
Only use the tool supplied. Do not
use any other tool.
The Steam care programme must not
be used without the spray jet fitted
and screwed in correctly.
Open the door of the tumble dryer.
The spray jet is located in the top left of
the door opening.
Attach the tool to the spray jet.
Turn the tool anti-clockwise to
unscrew the spray jet.
Insert the new spray jet in the tool.
Turn the tool clockwise to screw the
spray jet securely in position.
68
Service
Contact in case of fault
In the event of any faults which you
cannot remedy yourself, please contact
Miele.
Contact information for Miele can be
found at the end of this booklet.
Please quote the model and serial
number of your appliance when
contacting Miele. This information can
be found on the data plate.
The data plate is visible when the door
is open.
Optional accessories
Optional accessories for this tumble
dryer are available from Miele (see
contact details at the back of these
instructions).
You also can order these and other
useful products from the Miele online
shop.
Drying basket
The drying basket is suspended in the
drum and does not rotate with the
drum. This enables items which must
not be subjected to mechanical action
to be dried or aired.
Fragrance flacon
Fragrance flacons can be used in your
tumble dryer to add a pleasant
fragrance to your laundry.
Warranty
The manufacturer's warranty for this
appliance is 2years.
For further information, please refer to
your warranty booklet.
69
Installation and connection
Front view
a
Mains connection cable
b
Control panel
c
Condensed water container
– empty after every drying cycle
d
Door
– do not open during drying
70
e
Heat exchanger access panel
– do not open during drying
f
Four height adjustable screw feet
g
Cool air intake grille
– do not obstruct with a laundry
basket or other objects
h
Hose for external drainage of
condensed water
Installation and connection
Rear view
Depending on the model of your
tumble dryer, the guide path for the
condensed water drain hose on the
rear of the dryer will be different.
Version 1
The drain hose c for condensed water
is wound up at the top left. The
accessories b for external drainage of
condensed water are attached to the
tumble dryer.
a
Protruding lid for holding when
moving the tumble dryer (see
arrows)
b
Accessories for external drainage of
condensed water: hose clip, adapter
and hose holder
c
Drain hose for condensed water
d
Mains connection cable
Version 2
The drain hose b for condensed water
is wound up in the middle of the rear
panel. The accessories for external
drainage of condensed water are
supplied separately with the tumble
dryer.
a
Protruding lid for holding when
moving the tumble dryer (see
arrows)
b
Drain hose for condensed water
c
Hook for winding the mains cable
around during transport
d
Mains connection cable
71
Installation and connection
Transporting the tumble dryer
Danger of injury to people and
damage to property caused by
moving the appliance incorrectly.
If the tumble dryer tips over, there is
a danger of injury to people and
damage to property.
Ensure that the tumble dryer is stable
during transportation.
If the tumble dryer is being
transported horizontally, it must only
be tipped onto its left or right side.
If the tumble dryer is being
transported upright and you are using
a handcart or trolley, you must only
transport it with its left or right side
resting on the handcart or trolley.
Transporting the tumble dryer to its installation site
Make sure the fixings at the back
of the lid are secure.
Otherwise there is a danger of the lid
being pulled off when carrying the
appliance.
Before carrying the appliance, check
that the lid is secure where it
protrudes at the back of the
appliance.
Carry the tumble dryer by the front
feet and by the lid where it protrudes
at the back of the appliance.
Installation
Levelling the dryer
The appliance must not be
installed behind a lockable door, a
sliding door or a door with a hinge on
the opposite side to that of the
tumble dryer, in such a way that a full
opening of the tumble dryer door is
resticted.
Make sure the dryer door can be
opened without hindrance after
installation.
72
The appliance must stand perfectly
level to ensure safe and proper
operation.
Installation and connection
Ventilation
The cool air intake at the front of the
tumble dryer must not be blocked or
covered. This would hinder a
sufficient intake of cool air for the
heat exchanger.
Do not block the gap between the
bottom of the tumble dryer and the
floor with plinth facings, deep pile
carpet etc. This would hinder a
sufficient flow of air to the tumble
dryer.
Adequate ventilation has to be
provided to avoid the backflow of
gases into the room from appliances
burning other fuels, including open
fires.
Air which is taken in to cool the heat
exchanger is then blown back out of the
dryer and warms up the air in the room.
Ensure sufficient ventilation of the
room, e.g. by opening a window. The
drying time will otherwise take longer
(higher energy requirement).
The screw feet can be adjusted to
compensate for any unevenness in the
floor.
Downtime after installation
Damage to the tumble dryer by
switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer,
wait for at least one hour before
switching it on.
Before moving the tumble dryer again (e.g. when moving house)
After each use a small quantity of
condensed water will collect in the area
of the pump. This water can run out if
the tumble dryer is tipped up when it is
being moved. Recommendation: Run
the Warm air programme for
approximately 1minute without a load
before moving the tumble dryer. Any
remaining condensed water will then be
fed into the condensed water container,
which can then be emptied, or out
through the drain hose.
73
Installation and connection
Additional installation requirements
Suitable for pushing under a worktop
This tumble dryer is suitable for pushing
under a worktop.
Appliance defect due to a build-up of
heat.
Make sure there is adequate room
for warm air from the dryer to be
directed away.
– The appliance lid cannot be removed.
– The electrical socket must be located
in an accessible position near the
appliance.
– Drying durations may increase
slightly.
Optional accessories
– Washer-dryer stack
The tumble dryer can also be combined
with a Miele washing machine in a
washer-dryer stack. The appropriate
Miele washer-dryer stacking kit is
required.
74
Installation and connection
Externally draining condensed water
Notes
When drying is in progress,
condensed water is pumped into the
condensed water container through
the drain hose which is located at the
back of the dryer.
The condensed water can also be
drained away via the drain hose. The
condensed water container will then not
need to be emptied.
Hose length: 1.49m
Maximum delivery head: 1.50m
Maximum drain hose length: 4.00m
Drainage accessories
Installation conditions requiring a non-return valve
Danger of condensed water
backflow.
Water could flow back into the
tumble dryer or be drawn into it.
Backflow water could damage the
tumble dryer and also the room in
which it is located.
The non-return valve should be used
if the end of the hose is immersed in
water, or if other water connections
are installed.
Maximum delivery head with non-return
valve fitted: 1.00m
Installation conditions requiring the
fitting of a non-return valve:
– Drainage into a sink or floor gully
where the end of the hose is
immersed in water.
– Connection to a sink drain outlet.
– Supplied: adapter (b), hose clip (c),
hose holder (e);
– Available to purchase: “Non-return
valve” kit for connection to an
external water connection. Nonreturn valve (d), hose extension (a)
and hose clips (c) are supplied with
the kit.
– Connection to a drainage system
already in use by another appliance,
e.g. a dishwasher or washing
machine.
If the non-return valve is incorrectly
fitted the appliance will not drain.
The non-return valve has to be fitted
with the arrow on it pointing in the
direction of flow.
75
Installation and connection
Arranging the drain hose
Risk of damage to the drain hose
due to improper use.
A damaged drain hose can cause
damage due to leaking water.
Do not pull on the drain hose
excessively and do not stretch it or
allow it to become kinked.
There will be a small amount of residual
water left in the drain hose. Have a
container ready to collect this.
Version 1
Pull the drain hose off its connection.
Unwind the hose and pull it carefully
out of the holders.
Allow any residual water to run into
the container.
Guide the hose to the right or left side
of the dryer as required.
– If you are guiding it to the right, you
can fit the hose into the groove.
– Leave the hose in the lower holder to
prevent it from being kinked
inadvertently.
Examples: Draining condensed water
Version 2
76
The illustrations show the process of
removing the accessories for the
external condensed water connection
in version 1. In version 2, the
accessories for the external
condensed water connection are
supplied separately.
– Drainage into a sink or floor gully
Use the hose holder to prevent the
drain hose from becoming kinked.
Press the small catches on the left
and right of the hose holder with your
thumbs (black arrows) and ...
... pull the hose holder forwards to
remove it (white arrows).*
If you want to drain the water off
into a sink or basin, you will need to
secure the hose carefully, e.g. by
tying it to a tap, to make sure it
cannot slip during use (see the
drawing under “Installation and
connection - Front view”).
Overflowing water can cause
damage.
Installation and connection
Direct connection to a sink drain outlet
Remove the following from the back
of the dryer at the top: Adapter 1 and
hose clip 3 behind it.
Connect the drain hose as described
below.
The non-return valve can be fitted in
the end of the hose.
* You can refit the hose holder at a
later stage if you decide that you no
longer want to drain the condensed
water externally.
77
Installation and connection
1. Adapter
2. Nut
3. Hose clip
4. End of the hose (secured with the
hose holder)
5. Non-return valve
Fit the adapter 1 to the sink drain
outlet using the nut 2.
The nut is usually fitted with a washer
which must be removed.
Attach the end of the hose 4 to the
adapter 1.
Use the hose holder.
Use a screwdriver to tighten the hose
clip 3 up close to the nut.
Fit the non-return valve 5 to the
tumble dryer drain hose 6.
The non-return valve 5 has to be
fitted so that the arrow points in the
direction of flow (i.e. towards the
sink).
Secure the non-return valve using
hose clips.
6. Tumble dryer drain hose
78
Installation and connection
Electrical connection
This tumble dryer is supplied with a
mains cable with moulded plug.
The accessibility of the plug must be
always ensured in order to separate the
tumble dryer from the mains.
Connection of this appliance must
comply with national and local safety
regulations.
Do not connect the appliance via an
extension lead. Extension leads do not
guarantee the required safety of the
appliance (e.g. danger of overheating).
The appliance must be connected only
by a qualified and competent electrician
in accordance with national and local
safety regulations. For extra safety, it is
advisable to install a residual current
device (RCD) with a trip current of 30
mA.
The voltage, rated load and plug rating
are given on the data plate. Please
ensure that these match the household
mains supply.
Important
The wires in the mains lead are
coloured in accordance with the
following code:
Green/yellow = earth
Blue = neutral
Brown = live
As the colours of the wires in the mains
lead of this appliance may not
correspond with the coloured markings
identifying the terminals in your plug,
proceed as follows: The wire which is
coloured green and yellow must be
connected to the terminal in the plug
which is marked with the letter E or by
the earth symbol or coloured green or
green and yellow. The wire which is
coloured blue must be connected to the
terminal which is marked with the letter
N or coloured black. The wire which is
coloured brown must be connected to
the terminal which is marked with the
letter A or coloured red.
WARNING THIS APPLIANCE MUST BE EARTHED
79
Technical data
Height 850mm
Width 596mm
Depth 636mm
Depth with door open 1054mm
Height for building under 850mm (+5/-5mm)
Width for building under 600mm
Depth for building under 600mm
Suitable for pushing under a worktop Yes
Suitable for stacking Yes
Weight Approx. 62 kg
Drum volume 120l
Maximum capacity 9.0 kg (weight of dry laundry)
Capacity of condensed water container 4.8l
Drain hose length 1.49m
Maximum delivery head 1.50m
Maximum drain hose length 4.00m
Length of connection cable 2.00m
Voltage See data plate
Rated load See data plate
Fuse rating See data plate
Test certificates awarded See data plate
Energy consumption See “Consumption data”
LEDs Class 1
Frequency band 2.412GHz – 2.472GHz
Maximum transmission power <100mW
80
Consumption data
1
Load
Cottons 9.0
Cottons Normal 9.0
Cottons Normal
incl. Gentle tumble
Cottons Hand iron 9.0
Minimum iron Normal 4.0 1,200 40 0.50 70
Minimum iron Normal
incl. Gentle tumble
Delicates Normal 2.5 800 50 0.55 75
Woollens handcare 2.0 1,000 50 0.02 5
Shirts Normal 2.0 600 60 0.45 65
Express Normal 4.0 1,000 60 0.85 110
Denim Normal 3.0 900 60 1.05 130
Proofing Normal 2.5 800 50 0.90 120
1
Weight of dry laundry
All data was calculated using EN 61121 unless otherwise stated.
Final spin speed in a
domestic washing
machine
kg rpm % kWh min.
4.5
9.0
9.0
9.0 1,000 60 1.70 200
9.0
9.0
9.0
4.0 1,200 40 0.50 72
1,000
1,000
1,200
1,400
1,600
1,000
1,200
1,400
1,600
Residual
moisture
60
60
53
50
44
60
53
50
44
Energy Duration
1.63
0.86
1.45
1.40
1.25
1.25
1.10
1.00
0.85
208
124
189
179
160
147
129
120
102
Consumption data can vary from the nominal values given above depending on the size of the
load, types of textiles, residual moisture levels after spinning and fluctuations in the electricity
supply, or when water hardness levels differ from specified values.
Using the Cottons Extra dry programme is recommended for a mixed cotton load and is the programme
used in energy consumption tests according to AS/NZS 2442 (Refer to http://www.energyrating.gov.au
website for consumption data).
The consumption data shown in the EcoFeedback display can vary from the consumption data quoted
here. The variations arise from the way the data is measured in the dryer. For example, the programme
duration may vary depending on the residual moisture present in the laundry and the type of fabric
which will affect the energy requirement.
81
Settings
Settings can be altered to adapt the
electronics of the dryer to different
requirements.
Settings can be altered at any time.
Calling up settings
Switch the tumble dryer on.
Scroll to the second page in the main
menu.
Touch the Settings sensor.
Selecting settings
The settings are grouped into different
areas.
Select the required area.
Scroll through the list until the setting
you want appears.
Touch the sensor to edit the setting.
Editing settings
Change the value displayed and
confirm with OK.
The display will change to show the
main menu.
or
Touch an option to select it.
An option which is selected will be
highlighted orange.
The option is saved. The display will
then switch to the Settings menu, or go
back to the previous menu level.
Exiting Settings
Touch the sensor.
The display will then go back to the
previous menu level.
Touch the sensor.
82
Settings
Operation/Display
Language
The display can be set to appear in
one of several different languages.
The flag after the word Language
(Sprache in German) acts as a guide in
case a language which is not
understood has been set.
The language selected is saved.
Consumption
You can display the total
consumption.
Options
– Previous programme
Energy consumption in the last
programme run
– Total consumption
Previous total consumption
Code
The code prevents your machine
being used without your knowledge.
Options
– Activate
When the code has been activated,
you have to enter the code after
switching the dryer on. Otherwise the
dryer cannot be operated.
The factory default code is 250.
– Change
You can enter a code of your own.
If you forget the code, only a Miele
technician can unlock the tumble
dryer.
Make a note of your new code.
– Deactivate
For using the dryer without entering
the code. This only appears if the
code has been activated previously.
83
Settings
Memory
The dryer saves the settings that were
last selected for a drying programme
(drying level and/or Extras, or the
duration for some programmes).
The next time the programme is chosen
the saved settings will appear in the
display.
Options
– Off (factory setting)
– On
The activation of the Timer, the buzzer,
or ECO feedback data are not saved.
Clock display
After selecting the clock format, you
can set the time of day.
Options
– Clock format
The clock format is set.
– 24 h (factory setting)
– 12 h
– Time
The current time is set.
Volume
The volume can be changed for the
buzzer that sounds when the dryer is
switched on and at the end of the
programme. The volume of the tone
that sounds when a sensor is touched
can also be changed.
Options
– Finish tone
– Keypad tone
– Welcome tone
The tones can be set to one of 7
different settings or switched off
altogether.
Display brightness
The brightness of the display can be
altered.
It can be set to one of 7 different
settings.
Factory setting: medium
84
Display switch-off status
To save energy the display and sensor
controls will go out after 10 minutes
and the Start/Stop sensor will flash
slowly. You can change this automatic
switch-off function.
Options
– Off
The display will remain on (i.e. never
go out).
– On
The display will go out (after
10minutes):
– if no programme selection is made
after switching the dryer on
– during the current programme
– after the end of a programme.
– On, not in current prog.
(factory setting)
The display will go out (as described
above), but will remain on while the
programme is running.
Settings
You can switch the display back on by
touching any sensor.
85
Settings
Programme sequence
Anti-crease
The Anti-crease function reduces
creasing after the end of the
programme.
The drum will continue to rotate for up
to 2hours after the drying cycle has
finished. This helps to reduce creasing.
Options
– Off
– 1 h
– 2 h (factory setting)
Drying levels
You can alter the drying levels for the
Cottons, Minimum iron and Automatic
programmes. The Cottons
programme will remain unchanged.
It can be set to one of 7 different
settings.
Cooling down temperature
The laundry will be cooled down
automatically before the end of the
programme. The automatic cooling
phase at the end of a programme can
be set to a cooler level for all drying
programmes. This extends the cooling
phase.
Options
The level is set in increments of 1°C.
– 55°C (factory setting)
– ...
– 40 °C
Factory setting: medium
86
Settings
Network
RemoteUpdate
The RemoteUpdate function is used for
updating the software of your dryer.
The RemoteUpdate function is
deactivated as standard.
If you do not install a RemoteUpdate,
you can continue to use your dryer in
the usual way. However, Miele
recommends installing RemoteUpdates.
Activation
The RemoteUpdate menu option is
only displayed and can only be
selected if you have added your dryer
to your Wi-Fi network (see “Settings Miele@home”).
Miele’s RemoteUpdate function can
only be used if the tumble dryer is
connected to a Wi-Fi network and you
have an account in the Miele@mobile
App. The dryer must be registered in
the app.
Running a RemoteUpdate
If a RemoteUpdate is available for your
dryer, it will be displayed automatically
for you.
You can choose to start the
RemoteUpdate immediately or wait until
later. If you select “Start later”, the
prompt to run the RemoteUpdate will
be displayed again the next time you
switch on the dryer.
The RemoteUpdate can take several
minutes.
Please note the following information
about the RemoteUpdate function:
– You will only receive a message when
a RemoteUpdate is available.
– Once a RemoteUpdate has been
installed, it cannot be undone.
– Do not switch off the dryer during a
RemoteUpdate. Otherwise, the
RemoteUpdate will be aborted and
will not be installed.
See the Miele@mobile App for terms
and conditions of use.
Some software updates can only be
carried out by Miele Service.
87
Settings
Miele@home
Control the networking of your dryer
with your home Wi-Fi network.
The following points may appear in the
sub-menu:
Set up
This message only appears if the dryer
has not yet been connected to a Wi-Fi
network.
Please refer to “Before using for the first
time” for instructions on how to set up
the connection.
Activate
(visible if Miele@home is deactivated)
The Wi-Fi function is reactivated.
Deactivate
(visible if Miele@home is activated)
Miele@home remains set up, and the
Wi-Fi function is switched off.
Connection status
(visible if Miele@home is activated)
The following values are displayed:
– the quality of Wi-Fi reception
– the network name
– the IP address
Set up again
(visible if set up)
Resets the Wi-Fi login (network) to
immediately re-establish a new
connection.
Reset
(visible if set up)
– The Wi-Fi is switched off.
– The Wi-Fi connection will be reset to
the factory setting.
Miele@home is no longer set up. In
order to use Miele@home again, a new
connection must be established.
88
Settings
SmartGrid
The SmartGrid setting (available
depending on country) is only visible if
the Miele@home setting is set up and
activated.
This function can be used for starting
your dryer automatically at a time
when energy rates are more
economical.
Activating SmartGrid gives the Timer
sensor a new function. You can set the
SmartGrid via the Timer sensor. The
tumble dryer will then start within the
timeframe specified when it receives a
signal from the energy supplier.
If it has not received a signal from the
energy supplier by the latest start time
set, the tumble dryer will start
automatically (see “Timer”).
SmartGrid is deactivated as standard.
Remote control
The Remote control setting (available
depending on country) is only visible if
the Miele@home setting is set up and
activated.
Once the Miele@mobile App has been
installed on your mobile device, you
can check the status of your tumble
dryer from anywhere and start it
remotely. You can also control it
remotely via the MobileControl
function.
You can switch off the Remote control
setting if you do not want to operate the
dryer with your mobile device.
If Remote control is not switched on the
App can cause the programme to be
cancelled.
Use the Timer sensor to set a time by
when you want to start the tumble dryer
(see “Timer”).
The tumble dryer will then start within
the specified timeframe when it receives
your signal.
If it has not received a start signal by
the latest start time set, the tumble
dryer will start automatically.
Remote control is activated as
standard.
89
Settings
Appliance parameters
Airways indicator
Fluff must be removed after every
drying programme. In addition, this
indicator will remind you to clean the
filters when a certain amount of fluff
has collected in them:
Clean the fluff and plinth filters. See the
operating instruction manual.
You can decide at what level of fluff
this reminder should be given.
Options
You will have an idea of how often this
should be done after a few drying
programmes.
– Off
The reminder does not appear.
However, if there is a very severe
blockage in the ducting, the
programme will be cancelled and the
error message
Clean the fluff filter. Check the
airways. will appear in the display
regardless of this option.
Conductivity setting
This setting is only relevant for regions
with very soft water.
Very soft water can result in
unsatisfactory drying results.
You should only select this setting if
the water used for washing the
laundry is extremely soft with a
conductivity reading (electrical
conductivity) of less than 150μS/cm.
Contact your local water authority for
the conductivity level of your mains
water supply.
Options
– Normal (factory setting)
– Low <150mS (only for regions with
very soft water)
– Heavy
The reminder only appears when
there is a heavy build-up of fluff.
– Normal (factory setting)
– Light
The reminder appears whenever
there is a small build-up of fluff.
90
www.miele.com.au
Miele Experience Centre and
Head Office Melbourne:
1 Gilbert Park Drive
Knoxfield, VIC 3180
Miele Experience Centre South Melbourne:
206-210 Coventry Street
South Melbourne, VIC 3205
Miele Experience Centre and Office Sydney:
3 Skyline Place
Frenchs Forest, NSW 2086
Miele Experience Centre and Office Brisbane:
Tenancy 4C, 63 Skyring Terrace
Newstead, QLD 4006
Miele Experience Centre and Office Perth:
83-85 Sir Donald Bradman Drive
Hilton, SA 5033
205-207 Stirling Highway
Claremont, WA 6010
Miele Experience Centre and Office Adelaide:
Miele Australia Pty. Ltd.
Miele New Zealand Limited
Level 2, 10 College Hill
Freemans Bay, Auckland 1011
Miele Experience Centre
Auckland:
8 College Hill
Freemans Bay, Auckland 1011
Telephone:
0800 464 353 (0800 4 MIELE)
www.miele.co.nz
Miele Global Headquarters
Germany
Miele & Cie. KG
Carl-Miele-Straße 29
33332 Gütersloh
Federal Republic of Germany
Head Office:
IRD 98 463 631
ACN 005 635 398
ABN 96 005 635 398
Miele Experience Centre Gold Coast:
131 Ferry Road
Southport, QLD 4215
TCR 870 WP
M.-Nr. 11 015 671 / 00en-AU, NZ
Loading...
