Miele G 7361, G 7366 Operating instructions

Operating Instructions Dishwasher
To prevent accidents and machine damage, read these instructions before installation or use.
en-US M.-Nr. 11 838 230HG07-W
Contents
IMPORTANT SAFETY INSTRUCTIONS ............................................................ 7
Guide to the appliance...................................................................................... 17
Machine overview................................................................................................ 17
Control panel....................................................................................................... 18
Display functions................................................................................................. 19
Caring for the environment .............................................................................. 20
Before using for the first time .......................................................................... 21
Opening the door ................................................................................................ 21
Closing the door.................................................................................................. 21
Miele@home ........................................................................................................ 22
Basic settings...................................................................................................... 23
Reactivation salt.................................................................................................. 26
Rinse aid.............................................................................................................. 29
Settings .............................................................................................................. 31
Opening the settings menu ................................................................................. 31
Changing settings ............................................................................................... 31
Closing the settings menu................................................................................... 31
Language......................................................................................................... 32
Time of day.......................................................................................................... 32
Water hardness ................................................................................................... 33
AutoDos (AutoDos).............................................................................................. 34
Rinse Aid ............................................................................................................. 35
Miele@home ........................................................................................................ 35
Remote control.................................................................................................... 38
RemoteUpdate .................................................................................................... 39
SmartStart ........................................................................................................... 40
EcoStart............................................................................................................... 40
Display brightness............................................................................................... 42
Volume................................................................................................................. 43
Refill reminders.................................................................................................... 43
AutoOpen ............................................................................................................ 43
3
Contents
Extra Clean.......................................................................................................... 44
Extra Dry.............................................................................................................. 44
2nd interim rinse.................................................................................................. 44
Hygiene cycle ...................................................................................................... 44
Software version.................................................................................................. 45
Showroom program............................................................................................. 45
Factory default..................................................................................................... 45
Copyrights and licenses for the communication module.................................... 45
Caring for the environment .............................................................................. 46
Energy-saving dishwashing................................................................................. 46
Loading the dishwasher.................................................................................... 47
General information............................................................................................. 47
Loading examples ............................................................................................... 49
Upper basket....................................................................................................... 51
Adjusting the upper basket ................................................................................. 54
Lower basket....................................................................................................... 55
Filters................................................................................................................... 57
Cutlery tray .......................................................................................................... 58
Detergents ......................................................................................................... 59
Active ingredients ............................................................................................... 59
Detergent dispensing .......................................................................................... 60
Automatic dispensing/AutoDos........................................................................... 61
Manual detergent dispensing.............................................................................. 64
Operation............................................................................................................ 66
Turning on the dishwasher .................................................................................. 66
Selecting a program ............................................................................................ 66
Display of program duration................................................................................ 67
Starting a program .............................................................................................. 67
End of program.................................................................................................... 68
Energy management ........................................................................................... 68
Turning off the dishwasher .................................................................................. 69
Unloading the dishwasher................................................................................... 69
Interrupting a program......................................................................................... 70
Canceling or changing a program....................................................................... 70
4
Contents
Options ............................................................................................................... 71
Timer .............................................................................................................. 71
Activating Remote start....................................................................................... 75
Program overview ............................................................................................. 76
Program options................................................................................................ 80
Selecting program options .................................................................................. 80
Cleaning and care ............................................................................................. 81
Cleaning the wash cabinet .................................................................................. 81
Cleaning the door and the door seal................................................................... 82
Cleaning the control panel .................................................................................. 83
Cleaning the reflector panel ................................................................................ 83
Cleaning the front of the machine ....................................................................... 83
Cleaning the AutoDos assembly ......................................................................... 84
Cleaning the spray arms...................................................................................... 86
Checking the filters in the wash cabinet ............................................................. 89
Cleaning the filters............................................................................................... 89
Cleaning the drain pump..................................................................................... 91
Frequently Asked Questions ............................................................................ 93
Technical faults.................................................................................................... 93
Fault messages ................................................................................................... 94
Door release ........................................................................................................ 95
Water intake fault................................................................................................. 96
Water drainage fault ............................................................................................ 97
Fault in the AutoDos (automatic dispensing)....................................................... 98
Spray arm fault .................................................................................................... 100
General dishwasher problems............................................................................. 101
Noises.................................................................................................................. 103
Poor cleaning results........................................................................................... 104
Customer Service.............................................................................................. 108
Contact in the event of a fault ............................................................................. 108
Appliance warranty and product registration ...................................................... 108
Optional accessories ........................................................................................ 109
Installation.......................................................................................................... 111
Water intake ........................................................................................................ 111
Water drainage .................................................................................................... 113
Electrical connection ........................................................................................... 115
5
Contents
Sound emission testing .................................................................................... 117
6

IMPORTANT SAFETY INSTRUCTIONS

This dishwasher complies with all current local and national safety requirements. Inappropriate use can, however, lead to personal in­jury and material damage.
Please observe the installation sheet and read the operating in­structions carefully before setting up the dishwasher and using it for the first time. They both contain important information on the installation, safety, use, and maintenance of the machine. This pre­vents both personal injury and damage to the dishwasher.
Miele expressly and strongly advises that you read and follow the instructions in the section on installing the dishwasher as well as the IMPORTANT SAFETY INSTRUCTIONS. Miele cannot be held liable for injury or damage caused by non­compliance with these instructions.
Keep the installation sheet and the operating instructions in a safe place and pass them on to any future owner.
7
IMPORTANT SAFETY INSTRUCTIONS

Appropriate use

This dishwasher is intended for use in domestic households and
similar residential environments.
This dishwasher is not suitable for outdoor use.This dishwasher is intended for use at altitudes of up to 13,000ft
(4,000m) above sea level.
This dishwasher must only be used for cleaning domestic dishes
and cutlery. All other types of use are not permitted.
This appliance is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge.
8
IMPORTANT SAFETY INSTRUCTIONS

Safety with children

Children must be kept away from the dishwasher unless they are
constantly supervised.
Children must not be allowed to clean or maintain the appliance.Children should be supervised in the vicinity of the dishwasher.
Never allow children to play with the dishwasher. There is a danger that children might shut themselves in the dishwasher.
If the automatic door opening mechanism is active (depending on
the model), keep young children away from the area in which the door opens.
Danger of suffocation. While playing, children may become entan-
gled in packaging material (such as plastic wrapping) or pull it over their head with the risk of suffocation. Keep packaging material away from children.
Keep children away from detergents. Detergents cause severe
skin burns and severe eye damage. They can cause burning in the mouth and throat, or inhibit breathing. It is therefore important to keep children away from the dishwasher when the door is open. De­tergent residues could still be present in the machine. Seek medical advice immediately if a child has swallowed or inhaled any deter­gents.
9
IMPORTANT SAFETY INSTRUCTIONS

Technical safety

Unauthorized installation, maintenance, and repairs can cause
considerable danger for the user. Installation, maintenance, and re­pairs should only be carried out by a Miele authorized technician.
Damage to the dishwasher can compromise your safety. Before
using the dishwasher and in particular following transport, check it for any visible damage. Never use a damaged dishwasher.
The electrical safety of the dishwasher can only be guaranteed
when correctly grounded. It is most important that this basic safety requirement is fulfilled. If in doubt, the electrical installation should be checked by a qualified service technician. Miele cannot be held liable for the consequences of an inadequate or lack of grounding system (e.g., electric shock).
Reliable and safe operation of this dishwasher can only be as-
sured if it has been connected to the power supply.
Where the dishwasher is plugged into the electricity supply using
a 3-pin plug with a grounding contact, the electrical socket must be easily accessible after the dishwasher is installed so that it can be disconnected from the electricity supply at any time.
There must be no electrical sockets behind the dishwasher be-
cause the building-in niche may be too small. Danger of overheating and fire risk if the dishwasher were to be pushed up against a plug.
The dishwasher must not be installed underneath a cooktop. The
high temperatures radiated by cooktops could damage the dish­washer below. For the same reason, the dishwasher must not be in­stalled next to open fires or other appliances that give off heat, such as heaters etc., not normally found in a kitchen.
10
IMPORTANT SAFETY INSTRUCTIONS
Ensure that the connection data on the dishwasher’s data plate
(fuse rating, frequency, and voltage) match the electricity supply. This data must correspond in order to avoid the risk of damage to the dishwasher. Compare these before connecting the appliance to the electricity supply. If in any doubt, consult a qualified service technician.
Do not connect the dishwasher to the electricity supply until it has
been fully installed and any adjustment has been made to the door springs.
The dishwasher may only be operated if the door opening mecha-
nism is working correctly. Otherwise there could be a risk of danger while the automatic door opening mechanism (depending on the model) is active. To check that the door opening mechanism is working correctly:
- The door springs must be evenly adjusted on both sides. They are correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). It is also important that the door cannot fall open.
- The door locking pins automatically retract when the door opens at the end of the drying phase.
Power bars and extension cords do not guarantee the required
safety of the appliance (risk of fire). Do not connect the dishwasher to the electricity supply using a power bar or an extension cord.
The dishwasher must not be used in a non-stationary location
(e.g., on a ship).
Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses are at risk of tearing or bursting. The reliability of the electronic control unit may be impaired at temperatures below freezing point.
To avoid any damage to the appliance, the dishwasher must only
be operated when it is connected to a fully vented plumbing system.
11
IMPORTANT SAFETY INSTRUCTIONS
The water-connection pressure needs to be between 7.25 and
145 psi (50 and 1,000kPa).
A damaged dishwasher could be dangerous. If the dishwasher
gets damaged, turn it off at the electricity supply immediately and contact your Miele dealer or Miele Customer Service.
The manufacturer’s warranty may be invalidated if the appliance is
not repaired to Miele authorized service standards.
We recommend replacing defective components with original
parts. If original Miele parts are installed correctly, Miele ensures full compliance with safety requirements and the warranty remains valid.
During installation, maintenance, and repair work, the dishwasher
must be disconnected from the electricity supply (turn it off and with­draw the plug from the socket).
If the power cord is damaged, it must only be replaced with a spe-
cific cord of the same type (available from Miele Customer Service). For safety reasons, this must only be done by Miele Customer Ser­vice or a service technician authorized by Miele.
Do not sit the dishwasher on the hose. The hose needs to be free
of kinks and able to move freely after installation. Do not place hose or power cord next to a heat source e.g. hot water pipes. Do not ex­pose hose or power cord to corrosive substances or their vapors (e.g. chloride). Damage of hose or power cord could cause electrical shock or water damage.
This dishwasher is supplied with a special bulb (depending on the
model) to cope with particular conditions (e.g., in terms of tempera­ture, moisture, chemical resistance, abrasion resistance, and vibra­tion). This lamp must only be used for the purpose for which it is in­tended. The lamp is not suitable for room lighting. Replacement bulbs may only be installed by a Miele authorized technician or by Miele Customer Service.
12
IMPORTANT SAFETY INSTRUCTIONS

Correct installation

The dishwasher must be installed and connected in compliance
with the supplied installation sheet.
Be careful before and while installing the dishwasher.
Some metal parts pose a risk of injury/being cut. Wear pro­tective gloves.
The dishwasher must be correctly aligned horizontally to ensure
problem-free operation.
In order to ensure stability, built-under and integrated dishwashers
must only be installed under a continuous countertop which is se­cured to adjacent cabinetry.
The dishwasher must only be built into a tall cabinet if additional
safety precautions are taken. In order to safely install the appliance in a tall cabinet, please use the tall cabinet installation kit and ob­serve the installation sheet provided. Otherwise there is the danger of the cabinet tipping over.
The door springs must be evenly adjusted on both sides. They are
correctly adjusted when the door remains stationary when left half open (approx. 45° opening angle). It is also important that the door cannot fall open. The appliance must only be operated with properly adjusted door springs. If the door cannot be adjusted properly, contact the Miele Customer Service.
The maximum weight of the front panel that can be aligned with the factory-installed door springs is 22-26.5 lb (10–12kg) depending on model.

Correct use

Do not use solvents in the dishwasher. There is a danger of explo-
sion.
13
IMPORTANT SAFETY INSTRUCTIONS
Dishwasher detergents can cause burning on the skin and in the
eyes, nose, mouth, and throat. Avoid contact with detergents. Do not inhale powder detergents. Do not swallow dishwasher detergents. Seek medical attention immediately if detergent has been swallowed or inhaled.
Avoid leaving the dishwasher door open unnecessarily. You could
injure yourself on the opened door or trip over it.
Do not sit, stand, or lean on the opened door. The dishwasher
could tip over. This could injure you or damage the dishwasher.
Dishes may be very hot at the end of the program. Allow the
dishes to cool until they are comfortable enough to handle before unloading them.
Only use detergent and rinse aid formulated for domestic dish-
washers. Do not use liquid dish soap.
Do not use any commercial or industrial detergents. These may
cause material damage, and there is a risk of a severe explosive chemical reaction (such as an explosive oxyhydrogen gas reaction).
Do not fill the rinse aid reservoir with powder or liquid detergent.
This will cause damage to the rinse aid reservoir.
Do not fill the AutoDos (depending on model) with powder or liq-
uid detergent. Loose detergent will damage the AutoDos.
Do not fill the salt reservoir with powder or liquid detergent. Dish-
washer detergent will damage the softener assembly.
Use only special, coarse-grained reactivation salt. Other types of
salt may contain insoluble components which can cause the water softener to malfunction.
14
IMPORTANT SAFETY INSTRUCTIONS
In dishwashers with a cutlery basket (depending on model), knives
and forks should be placed with the handles upwards in the basket for safety reasons. Knives and forks placed with the handles down­wards pose a danger of injury. However, cutlery placed handle down in the cutlery basket will come out cleaner and drier.
Plastic items which cannot withstand being washed in hot water,
such as disposable plastic containers or plastic cutlery, should not be cleaned in the dishwasher. The high temperatures in the dish­washer may cause them to melt or lose shape.
If you use the timer option (depending on model), the detergent
compartment must be dry. Wipe dry with a cloth first if necessary. The detergent will clump together if the detergent compartment is not dry, and this may mean that it is not fully rinsed out.

Accessories and parts

Only use original Miele accessories. If other parts are used, war-
ranty, performance, and, if applicable, product liability claims will be invalidated.
Miele will guarantee to supply functional spare parts for a mini-
mum of 10years and up to 15years following the discontinuation of your dishwasher.

Transport

Damage to the dishwasher can compromise your safety. Before
using the dishwasher, check it for any visible transport damage. Never use a damaged dishwasher.
Only transport the dishwasher in an upright position so that no
water flows into the electrical controls, as this would cause faults.
If you wish to transport the dishwasher, empty it and securely fas-
ten all loose parts such as baskets, hoses, and power cords.
15
IMPORTANT SAFETY INSTRUCTIONS

Disposal of your old dishwasher

Remove the door of the dishwasher so that children cannot be-
come trapped inside.

FCC Declaration of Conformity

These devices comply with FCC Rules Part15. This equipment
has been tested and found to be in compliance with the limits for a ClassB digital device, pursuant to Part15 of the FCC Rules of Oper­ation and is subject to the following conditions: These devices may not cause harmful interference. These devices must accept any interference received, including in­terference that may cause undesired operation.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be in­stalled and operated with minimum distance 8" (20cm) between the radiator and your body.

Industry Canada Statement

This digital apparatus does not exceed the ClassB limits for Ra-
dio Noise Emissions from digital apparatus set out in the Radio Inter­ference Regulations of the Canadian Department of Communica­tions.
Complies with Canadian ICES-003 ClassB specifications.
16

Machine overview

Guide to the appliance

a
Door locking pins
b
Top spray arm
c
3D MultiFlex Cutlery Tray (depending on model)
d
Upper basket (depending on model)
e
Middle spray arm
f
Aeration valve
g
Bottom spray arm
h
Filter combination
i
Salt reservoir
j
Data plate
k
Rinse aid reservoir
l
Detergent compartment
m
AutoDos detergent outlet
n
AutoDos (automatic dispensing)
17
Guide to the appliance

Control panel

a
On/Offsensor button For turning the dishwasher on and off.
b
In-operation indicator light For indicating an ongoing wash pro­gram when the door is closed.
c
Remote startsensor button For activating/deactivating the Re­mote start option.
d
Program selection
Normal = NormalPots = Pots & PansCrystal = China & CrystalQuick = QuickIntenseWashSani = SaniWashMore = Additional programs/
settings
e
IntenseZonesensor button Increases cleaning performance in the lower basket.
f
Expresssensor button For reducing the program cycle time.
g
AutoDos sensor button For activating/deactivating AutoDos.
h
Timer sensor button For selecting a later program start.
i
Display For further information, see “Display functions” under “Guide to the appli­ance”.
j
Back sensor button For navigating back to the previous menu or deleting values which have been set previously.
k
Sensor buttons For program selection. For changing the values displayed. For scrolling to other menu pages.
l
OK sensor button To select menu options and values displayed. To confirm messages.
18
Guide to the appliance

Display functions

The display is used to select or set the following:
- the program
- the Timer
- the Settings 
The display can show the following:
- the program stage
- The estimated time left for the pro­gram to run
- Any relevant fault messages and in­formation
To save energy, the dishwasher turns off after a few minutes if you do not press any sensor buttons during this time. Touch the sensor button to turn the dishwasher back on.
The OKsensor button is used to con­firm a message or setting and also to move to the next menu or another level.
Under More, a scroll bar will ap-
pear in the right of the display. This of­fers further options. These options can be shown using the sensor but­tons.
You can alter the dishwasher’s controls to suit changing requirements in the “Settings” menu (see “Settings”).
The option which is selected will have a check next to it.
To exit a sub-menu again, use the Back sensor button.
If you do not press any sensor buttons for several seconds, the display will re­vert to the previous menu. You will then have to enter your settings again.
These operating instructions apply to several different dishwasher models of different heights. The specific dishwasher models are referred to as follows: Standard = 31 11/16" (80.5cm) high dishwashers (integrated) and 33 1/4" (84.5cm) high dishwash­ers (freestanding) XXL = 33 1/4" (84.5cm) high dish­washers (integrated).
19

Caring for the environment

Disposal of the packing mate­rial
The cardboard box and packing materi­als protect the appliance during ship­ping. They have been designed to be biodegradable and recyclable.
Ensure that any plastic wrappings, bags, etc. are disposed of safely and kept out of the reach of children. Dan­ger of suffocation!

Disposal of your old appliance

Electrical and electronic appliances contain valuable materials. They also contain certain substances, compounds and components which were essential for the proper functioning and safe use of the equipment. Handling these mate­rials improperly by disposing of them in your household waste can be harmful to your health and the environment. There­fore, please do not dispose of your old appliance with regular household waste and follow local regulations on proper disposal.
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. Please en­sure that your old appliance is kept away from children until removal. Ob­serve safety requirements for appli­ances that may tip over or pose an en­trapment hazard.
20

Before using for the first time

Every dishwasher is tested at the fac­tory. There will be residual water in the machine from this test. It is not an in­dication that the dishwasher has been used previously.

Opening the door

In some programs the door automati­cally opens slightly to assist the drying process. This function can be deactivated, if pre­ferred (see “AutoOpen” under “Set­tings”).
Pull the handle to open the door.
Risk of scalding due to hot wa-
ter. During operation, water in the dish-
washer may be very hot. During operation, only open the door
with extreme caution.
Risk of injury due to door open-
ing automatically. The door may open automatically at
the end of a program. Keep the area around the door free
of obstructions.

Closing the door

Insert the baskets.Raise the door upwards until the
catch engages.
Risk of crushing due to the door
closing. When closing the door, you are at
risk of shutting your fingers in it. Do not put your hand inside the door
as it is closing.
Open the door fully to disengage the
locking mechanism.
At the end of the program, if the Au­toOpen function is on, the door locking pins automatically retract.
To prevent a technical fault, do not hold the door locking pins firmly when they are retracting.
If the door is opened during operation, all functions are automatically inter­rupted.
21
Before using for the first time

Miele@home

Your dishwasher is equipped with an integrated WiFi module.
To use this feature, you will need:
- A WiFi network
- The Miele app
- A Miele user account. The user ac­count can be created via the Miele app
The Miele app will guide you as you connect your dishwasher to your home WiFi network.
Once your dishwasher is connected to your WiFi network, you can use the app, for example, to carry out the fol­lowing activities:
- Control your dishwasher remotely
- Call up information on the operating status of your dishwasher
- Call up information on the program sequence of your dishwasher

Availability of the WiFi connection

The WiFi connection shares a frequency range with other appliances (including microwave ovens and remote control toys). This can cause sporadic or even complete connection failures. There­fore, the availability of featured func­tions cannot be guaranteed.

Miele@home availability

The ability to use the Miele app de­pends on the availability of the Miele@home service in your country.
The Miele@home service is not avail­able in every country.
For information about availability, please visit www.miele.com.

Miele App

The Miele App is available to download free of charge from the Apple App
Store® or from the Google Play Store™.
Connecting your dishwasher to your WiFi network will increase energy con­sumption, even when the dishwasher is turned off.
Make sure that your WiFi network signal strength is strong enough at the installation site of your dish­washer.
22
Before using for the first time

Basic settings

Turning on the dishwasher

Open the door.Turn the dishwasher on using the
sensor button.
The welcome screen will appear when the dishwasher is turned on and the welcome melody will sound.
For further information about the dis­play functionality, see “Display func­tions” under “Guide to the appliance”.

Setting the language

The display will change automatically to the screen for setting the language.
Select the language you want as well
as the country, if appropriate, using the sensor button and confirm with OK.
For further information on setting the language, see “Language” under “Set­tings”.

Setting up Miele@home

The message Set up Miele@home will ap­pear on the display.
To set up Miele@home now, confirm
by touching OK.
Tip: To postpone setup until later, select the optionSkip and confirm with OK.
There are 2 ways of connecting your dishwasher to your WiFi network:
Select the connection method you
want and confirm your choice with OK.
1. Connect using App
2. Connect using WPS
You will then be guided by the display and the Miele app.
For further information on Miele@home, see “Miele@home” un­der “Settings”.
A check will appear next to the lan­guage that has been set.
23
Before using for the first time

Setting the time

The time is updated automatically if a connection is established with the WiFi network.
The display will then change to the screen for setting the time.
The current time of day must be set be­fore you can use the timer option.
Use the sensor buttons to enter
the hour and confirm your entry with OK.
Then set the minutes and confirm
with OK.
Keeping the relevant or sensor button pressed will increase or de­crease the time automatically.

Setting the water hardness

The display changes to the screen for setting the water hardness.
- The dishwasher must be pro­grammed to the correct water hard­ness for your area.
- Your local water authority will be able to advise you of the water hardness level in your area.
- Where the water hardness fluctuates, e.g., between 10-16 gpg (10–15°dH), always program the dishwasher to the higher value (16 gpg (15°dH) in this example).
It is useful to know your water hardness so that you can provide the service technician with this information in the event of any service calls.
Enter the water hardness below:
____________gpg (°dH)
The dishwasher is programmed at the factory for a water hardness level 1 gpg (1°dH).
24
Set the water hardness level in your
area and confirm with OK.
See “Water hardness” under “Set­tings” for more information.
Before using for the first time

Activating AutoDos

The display changes to the settings screen for AutoDos (see “Automatic dis­pensing/AutoDos” under “Detergent”).
Even if you do not wish to use Auto­Dos, you must remove the transport locking device from the PowerDisk compartment before running the first program (see “Activating AutoDos” under “Detergent”).
You can activate AutoDos. If you do not wish to use AutoDos, you can manually dispense the detergent via the detergent compartment (see “Manual detergent dispensing” under “Detergent”).
Select the setting you want and con-
firm with OK.
This setting applies to all programs and you can change it at any time using the AutoDossensor button.
Finally, prompts will appear in the dis­play.
After confirming these prompts with
OK, the messages Refill salt andAdd rinse aid may appear.
Add salt and rinse aid if necessary
(see “Reactivation salt” and “Rinse aid” under “Before using for the first time”).
Select OK to confirm the messages.
The program selected will appear briefly in the display and the appropriate sen­sor button will be illuminated. The display will then show the esti­mated program duration for the pro­gram selected.
25
Before using for the first time

Reactivation salt

In order to achieve good cleaning re­sults, the dishwasher needs to operate with soft water. Hard water results in the build-up of calcium deposits on dishes and on the inner surfaces of the machine. Domestic water with a hardness level higher than 5 gpg (5°dH – German scale) must be softened. This occurs automatically in the integrated water softener. The water softener is suitable for a water hardness level of up to 73 gpg (70°dH – German scale).
In order to be reactivated, the water softener requires reactivation salt. Depending on the water hardness level (<22 gpg, or <21°dH – German scale), reactivation salt may not be required if combination detergents are being used (see “Active ingredients” under “Deter­gents”).
If the water in your area is very soft and constantly lower than 5 gpg (5°dH – German scale), you do not need to add reactivation salt. The salt refill indicator will automatically turn off after the water hardness has been set accordingly (see “Water hardness” under “Settings”).
Damage to the water softener
from detergent. Dishwasher detergent will damage
the softener assembly. Do not fill the salt reservoir with pow-
der or liquid detergent.
Damage caused by using unsuit-
able salts. Some types of salt may contain in-
soluble components which can cause the water softener to malfunc­tion.
Use only special, coarse-grained re­activation salt.
26
If you only ever use combination de­tergent products in your dishwasher, you can turn off both refill reminders if you wish (see “Refill reminders” under “Settings”).
Please make sure that if you stop us­ing combination detergents, you refill the reactivation salt and rinse aid. Turn the refill reminders back on if re­quired.

Filling the salt reservoir

Before filling the salt reservoir for the first time, you must fill it with approx. 1/2gallon (2l) of water to enable the salt to dissolve.
Once the dishwasher has been used once, there is always sufficient water in the salt reservoir.
Remove the lower basket from the
wash cabinet and unscrew the salt reservoir cap.
Before using for the first time
Danger of corrosion due to saline
solution. Water or saline solution will run out
of the reservoir when the cap is opened. Salt solution that runs out can cause corrosion in the wash cabinet and to the wash items.
The cap should therefore only be re­moved in order to refill the salt reser­voir.
Fill the salt reservoir with approx.
1/2gallon (2l) of water (first use only).
Place the funnel provided over the
salt reservoir and carefully fill with re­activation salt until the reservoir is full. The salt reservoir holds up to
4.4lb (2kg) of salt, depending on the type of salt used.
Clean off salt residues from around
the salt reservoir opening. Next, screw the salt reservoir cap on again firmly.
Immediately after filling the salt reser-
voir and each time you remove the salt reservoir cap, run the Quick-
IntenseWash program with the Ex­press program option selected with-
out wash items in the dishwasher to dissolve and remove any traces of salt from the wash cabinet.
27
Before using for the first time

Refilling the salt

Fill the salt reservoir with reactivation
salt when Refill salt appears in the display.
Confirm with OK.
The salt refill indicator will go out.
Danger of corrosion due to saline
solution. Salt solution that runs out can cause
corrosion in the wash cabinet and to the wash items.
Each time you remove the salt reser­voir cap, you must run the QuickIntenseWash program with the Express program option se­lected without wash items in the dishwasher. This will dissolve and re­move any traces of salt from the wash cabinet.
After the salt reservoir has been filled, the refill indicator may still appear in the display if the salt concentration has not yet reached the correct level. In this case, still confirm the message with OK.
The salt refill indicator will be turned off if you have programmed the dishwasher for a water hardness below 5 gpg (5°dH – German scale).
28
Before using for the first time

Rinse aid

Rinse aid is necessary to ensure that water does not cling and leave marks on dishes during the drying phase, and helps dishes dry faster after they have been washed. Rinse aid is poured into the container and the amount set is dispensed auto­matically.
Liquid dish soap or detergent
can cause damage. Liquid dish soap and detergent can
damage the rinse aid reservoir. Only fill it with rinse aid formulated
for domestic dishwashers.
Risk of acid damage.
The dishwasher can be damaged by high concentrations of acid.
Under no circumstances should you use citric acid with a higher acid content.
If you only ever wish to use combina­tion detergent products in your dish­washer, you do not need to add rinse aid. However, for optimum rinsing and drying results, use dishwasher deter­gent and add reactivation salt and rinse aid separately.
If you only ever use combination de­tergent products containing salt and rinse aid in your dishwasher, you can turn off both refill reminders if you wish (see “Refill reminders” under “Settings”).
Please make sure that if you stop us­ing combination detergents, you refill the reactivation salt and rinse aid. Turn the refill reminders back on if re­quired.
29
Before using for the first time

Adding rinse aid

Press the yellow button on the lid
of the rinse aid reservoir.
The lid will spring open.
Close the lid firmly until you hear it
click into place. Otherwise, water can enter the rinse aid reservoir during a program.
Wipe up any spilled rinse aid. This
prevents excess foam developing during the next program.
You can adjust the rinse aid dosage for best wash results (see “Rinse aid” under “Settings”).

Filling the rinse-aid reservoir

When Add rinse aid appears in the display, the reservoir contains sufficient rinse aid for 2–3 programs only.
Add rinse aid in plenty of time.Confirm with OK.
The rinse-aid refill indicator will go out.
Fill with rinse aid until the filling level
indicator (arrow) changes to a dark color while the door is horizontally open.
The rinse aid reservoir holds approxi­mately 110ml.
30

Settings

You can alter the dishwasher’s con­trols to suit changing requirements by adjusting the settings.
The settings can be altered at any time.

Opening the settings menu

Turn the dishwasher on with the
sensor button if it is turned off.
Touch the “Additional programs/
Settings” sensor button.
The first of the additional programs will appear in the display.
Use the sensor button to select
the Settings menu option and con­firm with OK.
The first option in the Settings menu will appear in the display.
For further information about the dis­play functionality, see “Display func­tions” under “Guide to the appliance”.

Changing settings

Use the sensor buttons to select
the menu option you want to change and confirm your selection with OK.
Sub-menu options that have already been selected will have a check be­side them.
Select the setting you want using the
sensor buttons and confirm with OK.
To exit a sub-menu again, use the
Back sensor button.
The display will revert to the menu above.

Closing the settings menu

Touch the Back sensor button. The display will change to the More
menu.
31
Settings
Language
The display can be set to appear in one of several different languages.
You can change the language used in the display and also the country via the
Language sub-menu.
The flag after the word Language  serves as a guide if a language that you do not understand has been set. In this case keep selecting the menu option that has a flag after it until you reach the Language sub-menu.

Time of day

The current time of day must be set be­fore you can use the timer option.

Setting the clock format

You can select either a 24-hour or 12­hour clock.
Select the Clock format menu option.Select the setting you want and con-
firm with OK.

Setting the time

You can set the current time of day.
Select the Set menu option.Use the sensor buttons to enter
the hour and confirm your entry by touching OK. Then set the minutes and confirm with OK.
The time of day has now been saved.
32
Settings

Water hardness

Your dishwasher is fitted with a water softener.
- The dishwasher must be pro­grammed to the correct water hard­ness for your area.
- Your local water authority will be able to advise you of the water hardness level in your area.
- Where the water hardness fluctuates, e.g., between 10-16gpg (10–15°dH), always program the dishwasher to the higher value (16gpg (15°dH) in this example).
If the water hardness in your area is available in a unit other than °dH, you can convert the values as follows: 1°dH = 1.04gpg = 0.18mmol/l =
1.78°fH
°d gr/gal °fH Display
1 1 2 1
2 2 4 2
3 3 5 3
4 4 7 4
5 5 9 5
6 6 11 6
7 7 13 7
8 8 14 8
9 9 16 9
10 10 18 10
°d gr/gal °fH Display
11 11 20 11
12 13 22 12
13 14 23 13
14 15 25 14
15 16 27 15
16 17 29 16
17 18 31 17
18 19 32 18
19 20 34 19
20 21 36 20
21 22 38 21
22 23 40 22
23 24 41 23
24 25 43 24
25 26 45 25
26 27 47 26
27 28 49 27
28 29 50 28
29 30 52 29
30 31 54 30
31 32 56 31
32 33 58 32
33 34 59 33
34 35 61 34
35 36 63 35
36 38 65 36
37-45 39-47 66-80 37-45
46-59 48-62 82-105 46-59
60 63 107 60
61-70 64-73 109-125 61-70
33
Settings

Setting the water hardness

Select the water hardness level in
your area and confirm with OK.

AutoDos (AutoDos)

AutoDos automatically adjusts the amount of detergent to the selected program. In the Auto program, the quantity is adjusted depending on the degree of soiling of the dishware.
If you want to extend the service life of the PowerDisk, you can reduce the dis­pensing quantity. The program’s clean­ing performance may decrease as a re­sult. If you want to improve the cleaning per­formance, you can increase the dis­pensing quantity. This reduces the ser­vice life of the PowerDisk.
Setting theDosage amount
For best results, you can adjust the dis­pensing quantity of the PowerDisk.
Select the Dosage amount menu op-
tion and confirm with OK.
Select the setting you want and con-
firm with OK.
34
Settings

Rinse Aid

You can adjust the rinse aid dosage for best results. The rinse aid dosage can be set from 0 to 6ml. 3ml is the factory default setting.
The rinse aid dosage can turn out to be higher than the set value due to the au­tomatic adjustment of the program.
If spots appear on dishes and glass­ware:
- Increase the rinse aid dosage.
If clouding or smearing appears on dishes and glassware:
- Decrease the rinse aid dosage.

Miele@home

Your dishwasher is equipped with an in­tegrated WiFi module.
You can connect your dishwasher to your WiFi network. This will increase the energy consump­tion, even when the dishwasher is turned off.
The “Settings” and “Miele@home set­tings” menus will be added as addi­tional menu options.
Make sure that your WiFi network signal strength is strong enough at the installation site of your dish­washer.
There are a number of ways of connect­ing your dishwasher to your WiFi net­work:
35
Settings

Connect using App

The Miele app is available to download free of charge from the Apple App
Store® or from the Google Play Store™.
Select the Connect using App menu
option and confirm with OK.
Follow the instructions in the app.
Once your dishwasher is connected to your WiFi network, you can use the app to carry out the following tasks:
- Control your dishwasher remotely
- Call up information on the operating status of your dishwasher
- Call up information on the program sequence of your dishwasher

Connect using WPS

As an alternative to networking via the Miele app, you can connect your dish­washer to your WiFi network using WPS (Wireless Protected Setup).
Your WiFi router must support WPS.
Confirm the message Press WPS but-
ton with OK.
Activate the WPS function on your
router within 2minutes.
Once the connection has been estab-
lished, confirm the message with OK.
If the connection fails, you have proba­bly not activated WPS on your router quickly enough. Repeat the steps above.
- Set up a Miele@home network with other WiFi-enabled Miele appliances
36
Settings

Deactivate

If you do not wish to use the WiFi mod­ule of your dishwasher, you can turn it off.
Select the Deactivate menu option
and confirm with OK.
In the Miele@home menu, the menu op­tion Activate will now be displayed in­stead of Deactivate.

Activate

If you wish to connect your dishwasher to your WiFi network, you can turn on the WiFi module.
Select the Activate menu option and
confirm with OK.
In the Miele@home menu, the menu op­tion Deactivate will now be displayed in­stead of Activate.
Displaying theConnection status
You can call up the current connection status of your dishwasher.
Select the Connection status menu op-
tion and confirm with OK.
Use the sensor buttons to con-
secutively call up the WiFi signal strength, the name of your router, and the associated IP address.
Select OK to confirm the messages.

Set up again

This menu option only appears if you have already connected your dish­washer to your WiFi network.

Connect using App

Select the Connect using App menu
option and confirm with OK.
Follow the instructions in the app.

Connect using WPS

Select the Connect using WPS menu
option and confirm with OK.
Follow the instructions on the display.
37
Settings

Reset

This menu option only appears if you have already connected your dish­washer to your WiFi network.
You can use this menu option to reset all WiFi module settings to the factory default settings.
The network configuration should be re­set whenever a dishwasher is being dis­posed of or sold, or if a used dish­washer is being put into operation. This is the only way to ensure that all per­sonal data has been removed and the previous owner will no longer be able to access the dishwasher.
Select the Reset menu option and
confirm with OK.

Remote control

This menu option will only be dis­played if you have connected your dishwasher to your WiFi network (see “Miele@home” under “Settings”).
If you wish to permanently turn off the
Remote control option, you can do this
under this menu option. The sensor button will then no longer be available to select until you change this setting again.
Even if the Remote control option is turned off, you can use Miele to call up information about your appliance. How­ever, you cannot start any programs or change any settings from it.
38
Settings

RemoteUpdate

The RemoteUpdate menu option is only displayed and can only be se­lected if the requirements for using Miele@home have been met (see “Miele@home” under “Before using for the first time”).
The RemoteUpdate function is used for updating the software in your dish­washer. If an update is available for your dishwasher, it will automatically download it. Updates will not be in­stalled automatically. They must be initi­ated manually.
If you do not install an update, you can continue to use your dishwasher as usual. However, Miele recommends in­stalling updates.

Activating/deactivating

The RemoteUpdate function is acti­vated as standard. Available updates will be downloaded automatically but will only be installed if you initiate instal­lation manually.
Deactivate RemoteUpdate if you do not want any updates to be downloaded automatically.

Running RemoteUpdate

Information about the content and scope of a RemoteUpdate will be pro­vided in the Miele app.
A message will appear in your dish­washer display if a software update is available.
You can install the update immediately or postpone this until later. When the appliance is turned on again, you will be reminded about the update.
Deactivate RemoteUpdate if you do not want to install the update.
The update may take several minutes.
Please note the following information about the RemoteUpdate function:
- You will only receive a message when an update is available.
- Once an update has been installed, it cannot be undone.
- Do not turn the dishwasher off during the update. Otherwise, the update will be aborted and will not be in­stalled.
- Some software updates can only be carried out by Miele Customer Ser­vice.
39
Settings

SmartStart

This menu option will only be dis­played if you have connected your dishwasher to your WiFi network (see “Miele@home” under “Settings”).
The SmartStart function is used for start­ing your dishwasher automatically at a time when your energy costs are most economical.
To use this function you may need fur­ther technical accessories.
If you have activated SmartStart Permit-
ted, the Timer menu of the selected
program will no longer show EcoStart but will instead show SmartStart. The dishwasher will then start within the timeframe specified when it receives a signal from the energy supplier. If it has not received a signal from the energy supplier by the latest possible start time, the dishwasher will start au­tomatically.

EcoStart

This option is not available in all areas.
In order to run your dishwasher in the most economical way, you can use the
EcoStart option to take advantage of
your electricity supplier’s cheaper en­ergy tariffs (see “Timer” under “Op­tions”). With this option selected, your dish­washer will start automatically at your electricity supplier’s cheapest rate times.
To use this option, you must first set up to 3 electricity rate time zones in which the dishwasher can start. You can allo­cate different priorities to these time zones. The time with the cheapest elec­tricity rate will be given Priority 1.
Contact your electric supplier to find out the times of the cheapest electricity rates.
Once the electricity rate times have been set, you can use the EcoStart op­tion to set the latest finish time required for each program. The dishwasher will then start automati­cally during the cheapest energy rate time period. The program will end at the set finish time at the latest.
40
Settings

Setting the electricity rate times

Before you can use the EcoStart option, you must set at least one electricity rate time.
Use the sensor buttons to select
an electricity rate time T1–T3 and confirm with OK.
The start of the electricity rate time se­lected will appear in the display and the hour number block will be highlighted.
Use the sensor buttons to set
the hours and minutes for the start time and confirm both with OK.
The end of the electricity rate time se­lected will appear in the display and the hour number block will be highlighted.
Use the sensor buttons to set
the hours and minutes for the end time and confirm both with OK.
The electricity rate time will be saved and its priority will appear in the display.

Changing the electricity rate times

You can change the start, finish, or pri­ority of an electricity rate time.
Use the sensor buttons to select
an electricity tariff time T1–T3 that you wish to change and confirm with OK.
Select the setting you want to change
and confirm with OK.
Use the sensor buttons to
change the setting and confirm with OK.
Confirm the message with OK.
The change will be saved.
Use the sensor buttons to set
the priority you want and confirm with OK.
Confirm the message with OK.
The electricity rate time will be acti­vated.
41
Settings

Deleting the electricity rate times

You can delete the settings for an en­ergy rate time and in doing so deacti­vate the EcoStart option for this time zone.
Use the sensor buttons to select
an electricity rate time T1–T3 that you wish to delete and confirm with OK.
For example, select Delete R1 and
confirm with OK.
For example, select Delete R1? and
confirm with OK.
The settings for the electricity rate time selected will be reset.
Confirm the message with OK.
The energy tariff time will be deleted.

Display brightness

You can set the display brightness to one of 7 different levels.
42
Settings

Volume

A sequence of audible signals will sound at the end of the program or if there is a fault, provided that the audi­ble signals have been activated.
Audible signals in the event of a fault
In the event of a fault, the alarm tone will sound 4times at intervals with a short pause between each set of tones.
The alarm tone that sounds when there is a fault cannot be deacti­vated.
Audible signals
The audible signals at the end of a pro­gram will sound 4times at intervals with a short pause between each signal.
The volume of the audible signals at the end of the program can be set to one of 7 different settings. If no volume is se­lected, the audible signals are turned off.
Keypad tone
An audible tone sounds each time a sensor button is pressed.
The volume for the keypad tone can be set to one of 7 different settings. If no volume is selected, the keypad tone is turned off (except the On/Offsensor button).

Refill reminders

If you only ever use combination deter­gent products or automatic dispensing using Miele PowerDisks (if available), you can turn off the refill reminders for reactivation salt and rinse aid if you wish.
Please make sure that if you stop us­ing combination detergents, you refill the reactivation salt and rinse aid. Turn the refill reminders back on.

AutoOpen

In some programs the door automati­cally opens slightly to assist the drying process.
This function can be deactivated if you wish.
Risk of damage due to steam.
Steam from the dishwasher could damage the edges of delicate coun­tertops when you open the door at the end of the program if the fan is no longer running.
If you have deactivated the auto­matic door opening function but would still like to open the door at the end of the program, then make sure that you open the door fully.
Welcome melody
If you turn the dishwasher on or off, a brief melody will sound.
You can turn the melody off.
43
Settings

Extra Clean

You can choose this function to in­crease the cleaning performance of the programs.
If you activate this function, the pro­gram cycle times and the main wash temperatures will increase. The water and energy consumption may increase.
If this function is turned on, it will be ap­plied to all programs until it is turned off again.

Extra Dry

You can select this function in order to increase the program drying perfor­mance.
If you activate this function, the pro­gram cycle times and final rinse temper­atures will increase. The energy con­sumption may increase.
If this function is turned on, it will be ap­plied to all programs until it is turned off again.

2nd interim rinse

You can choose this function to in­crease the cleaning performance of the programs with a second interim rinse.
When this function is activated, water consumption may increase.
If this function is switched on, it will be applied to all programs until it is switched off again.

Hygiene cycle

If you mainly use low-temperature pro­grams , there is a risk of bacteria and unpleasant odors building up in the wash cabinet (see “Hygiene cycle” un­der “Cleaning and care”).
If this function is switched on, a mes­sage will be displayed recommending the use of a high-temperature program after several low-temperature programs have been run.
44
Settings

Software version

You can display the electronic software version of your dishwasher for technical support purposes.

Showroom program

For demonstration purposes only.
The dishwasher is equipped with a demo mode for showroom use.

Factory default

You can reset all dishwasher settings to the factory default settings.
WiFi module settings (where applicable) have to be reset separately (see “Miele@home” under “Settings”).
Select Reset and confirm with OK.

Copyrights and licenses for the communication module

For the purpose of operating and con­trolling the communication module, Miele uses proprietary or third-party software that is not covered by open source licensing terms. This software/ these software components are pro­tected by copyright. The copyrights held by Miele and third parties must be respected.
This communication module contains software components which are distrib­uted under open source license condi­tions. The open source components contained in the appliance along with the corresponding copyright notices, copies of the licensing terms valid at the time, and any additional information can be accessed locally via http://<IP address>/Licenses. The liability and warranty arrangements for the open source licenses displayed in this loca­tion only apply in relation to the respec­tive rights holders.
45

Caring for the environment

Energy-saving dishwashing

This dishwasher is exceptionally eco­nomical in its use of water and electric­ity. You can make the most of your ma­chine by following these tips:
- Washing in a dishwasher generally uses less water and energy than washing by hand.
- There is no need to pre-rinse items under running water, and this unnec­essarily increases water and energy consumption.
- Make full use of the basket capacity without overloading the dishwasher. This results in the most economical dishwashing in terms of energy and water consumption.
- Choose a program that best suits the degree of soiling and the type of dishes being washed (see “Program overview”).
- If you are manually dosing the deter­gent, reduce the amount of detergent
by 1/3 when using powder or liquid detergent if the baskets are only half full.
- Select the Normal program for en­ergy-saving dishwashing. This pro­gram is the most efficient in terms of its combined energy and water con­sumption for cleaning dishes with a normal level of soiling.
- If you have a hot water connection, choose the Energy Saver program (see “Water intake” under “Installa­tion”). The wash water will not be heated up during this program.
- Follow the detergent manufacturer’s recommendations on detergent dosage.
46

Loading the dishwasher

General information

Remove coarse food residues from dishes.
There is no need to pre-rinse items un­der running water.
Damage can be caused by ash,
sand, wax, lubricating grease, or paint.
These substances will contaminate the dishwasher and can then no longer be removed.
Do not wash items soiled with these substances in the dishwasher.
Dishes can be loaded anywhere in the baskets, but the following notes should be observed:
- Do not place dishes and utensils in­side other items where they will cover one another.
- Load the dishes so that water can access all surfaces. This ensures that they get properly cleaned.
- The spray arms must not be blocked by items which are too tall or hang through the baskets. Test for free movement by manually rotating the spray arms.
- Make sure that small items cannot fall through the holders in the bas­kets. Small items such as lids should therefore be placed in the 3D Multi­Flex Tray or cutlery basket (depend­ing on model).
Some foods such as carrots, toma­toes, or ketchup may contain natural dyes. These dyes can discolor plastic items in the dishwasher if large quanti­ties of these foods are in contact with the dishes inside the machine. The stability of plastic items is not affected by this discoloration. Washing silverware can also cause plastic items to discolor.
- Make sure that all items are securely positioned.
- Hollow items such as cups, glasses, pans, etc., must be inverted in the baskets.
- Tall, narrow, hollow items such as champagne glasses should be placed in the center of the basket rather than in the corners. This en­sures the hollow items are more eas­ily accessed by the water jets.
- Concave items such as mugs or bowls should be placed at an angle so that the water can run off.
47
Loading the dishwasher
Wash items not suitable for dish­washers:
- Wooden cutlery and dishes or items with wooden parts. These may dis­color and fade. The glue used in these items is not dishwasher-proof and wooden handles may come loose after being washed in a dish­washer.
- Craft items, antiques, valuable vases, and decorative glassware. Such items are not suitable for dishwash­ers.
- Plastic items that are not heat resis­tant. The high temperatures in the dishwasher may cause them to melt or lose shape.
- Copper, brass, tin and aluminum items. These may discolor or become dull.
- Colors painted over a glaze. These may fade after a number of washes.
- Delicate glassware and glassware containing lead crystal. Clouding may occur over time.
Silver
Silver that has been in contact with foods containing sulphur can discolor. These include egg yolk, onions, mayon­naise, mustard, fish, and marinades.
Silverware previously cleaned with a silver polish may still be damp or spot-
ted at the end of a program, where wa­ter has not run off smoothly.
Damage due to caustic alkaline
detergents. Aluminum parts (e.g., the grease fil-
ters of ventilation hoods) can be damaged by caustic alkaline deter­gents. In extreme cases, there is a risk of an explosive chemical reac­tion (such as an explosive oxyhydro­gen gas reaction).
Aluminum components must not be cleaned in the dishwasher with caus­tic alkaline commercial or industrial detergents.
Tip: When purchasing new dishes and cutlery, make sure they are dishwasher­proof if you want to wash them in the dishwasher.

Glass care

- Clouding may occur on glasses after frequent washing in the dishwasher. When washing delicate glassware in the dishwasher, ensure that only a special glass-care program with very low temperatures is selected (see “Program overview”). This will reduce the risk of clouding.
- Purchase glassware that is dish­washer-safe (e.g., Riedel glassware).
- Use detergents with glass protective additives.
Tip: Rub the silver dry with a cloth.
48
Loading the dishwasher

Loading examples

Loading for 10 standard place settings with cutlery tray

Upper basket
Cutlery tray
Lower basket
49
Loading the dishwasher

Loading for 16 standard place settings with cutlery tray

Upper basket
Cutlery tray
Lower basket
50
Loading the dishwasher

Upper basket

Loading the upper basket

Risk of damage due to water
leakage. If you run the dishwasher without the
upper basket, water can leak out of the dishwasher.
Only run the dishwasher with the up­per basket in place (except during the Tall Items program, if available).
Use the upper basket for small, light-
weight, and delicate items such as cups, saucers, glasses, dessert bowls, etc. Shallow pans or casserole dishes can also be placed in the upper basket.
Long items such as soup ladles and
mixing spoons should be placed lying down across the front of the upper basket.

Loading the FlexCare cup rack

You can put cups, small bowls, and flat dishes on the FlexCare cup rack. Glasses can be arranged along the cup rack so they sit securely during the pro­gram.
Lower the cup rack to do so.Raise the cup rack upwards to make
room for tall items.
51
Loading the dishwasher

Adjusting the FlexCare cup rack

You can set the height and depth of the cup rack at 2 different levels so that it can accommodate larger cups and so that taller items can be placed under­neath it.
Pull the cup rack upwards and click it
into the desired position (see arrow).

Loading the silicone elements of the FlexCare cup rack

The silicone elements in the cup rack are specially designed to hold tall glasses with long stems securely.
Lower the cup rack and lean the
glasses against the openings.
If you wish you can adjust the left in-
sert of the 3D MultiFlex Tray to make space for taller glasses (see “3D Mul­tiFlex Tray” under “Cutlery”).
52

Lowering the spikes

On both right-hand rows of spikes, you can lower every other spike to make it easier to arrange larger dishes, like ce­real bowls.
Press the yellow lever downward,
and then lower the dark gray
spikes.
Loading the dishwasher
Place the bowls vertically in the row
of spikes.
53
Loading the dishwasher

Adjusting the upper basket

In order to gain more space for taller items in the lower basket or upper bas­ket, the upper basket can be adjusted on 3 levels with 3/4" (2cm) between each level.
The upper basket can also be set at an angle so that water can run off freely from recesses. Make sure, however, that the basket can slide smoothly in and out of the wash cabinet.
Pull out the upper basket.

To raise the upper basket:

Lift the basket until it clicks into
place.

To lower the upper basket:

Pull upwards on the levers at either
side of the upper basket.
Adjust the basket to the desired
height and then push the levers se­curely back down into position.
When adjusting the upper basket, make sure that tall plates in the lower basket do not block the middle spray arm.
54
Loading the dishwasher

Lower basket

Loading the lower basket

Place larger and heavier items such
as plates, serving platters, saucepans, bowls, etc., in the lower basket. Glasses, cups, and small plates and saucers can also be placed in the lower basket.

Loading the MultiComfort area

The rear section of the lower basket is used for washing cups, glasses, plates, and pots.
Place very large plates in the center
of the lower basket.
Tip: When tilted, plates up to 133/4" (35cm) in diameter can be ac­commodated.
55
Loading the dishwasher

Lowering the spikes

The rows of spikes at the front are used for loading plates, soup bowls, platters, dessert bowls, and saucers.
Both right-hand rows of spikes can be lowered to make more room for large items such as pots, pans, and serving dishes.
Press the yellow lever downward,
and then lower the spikes.

Loading the FlexCare glass holder

The silicone elements in the glass holder provide a stable and secure hold for delicate stemware.
Stemware such as wine glasses,
champagne flutes, and beer glasses can be leaned against the glass holder or suspended from it.
The glass holder can be raised to
make more room for tall items.
You can set the glass holder at two dif­ferent heights.
56
Slide the glass holder to the desired
height until the catches click into place at the top or the bottom.
Loading the dishwasher

Filters

You can also wash Miele Ventilation­Hood Filters.
Select the Filters program for optimum dishwashing results.
Damage caused by protruding
parts. Protruding parts can damage the
dishwasher. Load the filters in such a way that no
corners protrude over the side of the basket.
Damage caused by wash items
with sharp edges. Heavy and sharp wash items can
damage the coating of the basket struts.
Load the filters carefully.
Risk of scalding due to hot wa-
ter. At the end of the program, the filters
may still contain hot water. Be careful when unloading the filters.

Loading the filters

You can wash 2ventilation hood filters in the upper basket and 2filters in the lower basket at once.
If you only want to wash 2filters, put
them in the upper basket.
Upper basket
Set the upper basket into the top or
middle position if you load filters in the lower basket.
Lower basket
57
Loading the dishwasher

Cutlery tray

Load the cutlery into the 3D MultiFlex
Tray.

Loading the 3D MultiFlex Tray

To make unloading easier, utensils should be grouped in zones, one for knives, one for forks, one for spoons, etc.
Spoon heads should be placed in con­tact with at least one of the serrated re­tainers on the base of the cutlery tray to ensure that water runs off them freely.
You can push the left insert to the mid­dle in order to accommodate tall items and long stemmed glasses in the upper basket (see “Loading the silicone ele­ments of the FlexCare cup rack” under “Upper basket”).
You can put large and long utensils in the recessed center part of the tray.
Arrange tall items (such as cake plat­ters) so that they do not block the upper spray arm.
You can adjust the height of the right­hand insert to create more space in the right-hand part of the tray for larger utensil items or smaller dishes.
If spoon handles do not fit between
the holders, then lay them the other way round.
58
Pull the insert inward by the yellow
handle and click it into place in one of the two positions.

Detergents

Active ingredients

Damage caused by using unsuit-
able detergents. Detergents that are not suitable for
domestic dishwashers can cause damage to the dishwasher or to the wash items.
Only use detergents formulated for domestic dishwashers.
Modern detergents contain various ac­tive ingredients, the most important of which are:
- Water softening complexing agents to prevent calcification.
- Alkalis to aid removal of dried-on soiling.
- Enzymes to break down starch and loosen protein.
- Oxygen-based bleaching agents to remove colored stains (e.g., tea, cof­fee, tomato sauce).
Most dishwasher detergents are mildly alkaline and contain enzymes and oxy­gen-based bleaching agents.
There are different types of detergent:
- Powder and liquid gel detergents. These detergents allow you to adjust the amount dispensed according to the amount of wash items and the level of soiling.
- Tab detergents. These are suitable for most levels of soiling.
As well as the usual detergents, combi­nation products are also available. These contain rinse aid and water soft­ener (reactivation salt). Only use these combination detergents for the water hardness levels recom­mended by the manufacturer on the packaging. The cleaning and drying performance of these combination detergents can vary greatly.
For optimum cleaning and drying re­sults, use dishwasher detergent and add salt and rinse aid separately (de­pending on model).
59
Detergents
Risk of chemical burns from de-
tergent. Dishwasher detergents can cause
burning on the skin and in the eyes, nose, mouth, and throat.
Avoid contact with detergents. Do not inhale or ingest powder de­tergents. Do not swallow dishwasher detergents. Seek medical attention immediately if detergent has been swallowed or inhaled.
Keep children away from detergents. Detergent residues could still be present in the machine. Keep chil­dren away from the dishwasher when the door is open. Do not fill the de­tergent dispenser until just before starting the program and activate the door safety lock (depending on model).

Detergent dispensing

There are 2 ways of dispensing the de­tergent.
During automatic dispensing, the Auto­Dos function will automatically dispense the required amount of detergent for each program sequence once a Pow­erDisk has been inserted (see “Auto­matic dispensing/AutoDos” under “De­tergent”).
If you do not wish to use AutoDos, you can manually dispense the detergent into the detergent compartment. This means you will have to fill the required amount of detergent into the detergent compartment before each program (see “Manual detergent dispensing” under “Detergent”).
60
Detergents

Automatic dispensing/AutoDos

Before you can use AutoDos, you must insert a PowerDisk containing powder detergent into the PowerDisk compart­ment.
One PowerDisk contains enough deter­gent for approx. 20rinse cycles, de­pending on the chosen program.
PowerDisks are available to order di­rectly from Miele’s online store, Miele Customer Service, or from your Miele dealer.
Risk of chemical burns from
residual detergent. Detergents have a caustic effect.
This can cause health problems and damage to surfaces. If the AutoDos is used incorrectly or leaks, residual detergent may drip onto the floor area in front of the dishwasher.
Always remove residual detergent from in front of the dishwasher im­mediately.

Activating AutoDos

Turn the dishwasher on using the
sensor button.
Before you first use AutoDos, remove
the transport lock from the PowerDisk compartment and dispose of it ap­propriately.
Insert a PowerDisk (see “Inserting a
PowerDisk” under “Automatic dis­pensing/AutoDos”).
The AutoDos function will be acti­vated automatically. The message AutoDos activated will ap­pear on the display.
This setting applies to all programs and you can change it at any time using the AutoDossensor button.
If no program is started for 48hours, the PowerDisk will automatically be ro­tated so that the detergent does not clump together. If this happens, the messagePowder refreshing will be shown in the display when the dish­washer is turned on. No detergent will be dispensed.
61
Detergents

Inserting a PowerDisk

Turn on the dishwasher before you re­place the PowerDisk so that the dish­washer recognizes it.
Only replace the PowerDisk when the messagePowerDisk empty. Deactivate
AutoDos with OK. appears.
Turn the AutoDos lid to and open
it.
The message AutoDos lid open will ap­pear on the display.
Remove the empty PowerDisk.
If the arrows in the PowerDisk holder
and in the viewing window are not pointing towards each other, remove the PowerDisk holder (see “Cleaning the AutoDos” under “Cleaning and care”).
Put the holder back into place so that
the arrows point towards each other and the holder lies flat. When doing this, only touch the Pow­erDisk holder by the yellow tab in the middle. Do not touch the side tab.
Insert the new PowerDisk and press it
evenly downwards until it sits flush.
62
Close the AutoDos lid and turn it until
the lid handle is directly below the symbol.
If the PowerDisk is not in the correct starting position, it will be rotated auto­matically and the AutoDos function will be activated. Wait until this procedure ends before you start a program.
Detergents
The detergent powder must be dry so that it does not clump together.
Do not fill the AutoDos with any type of fluid.
In order to ensure that the AutoDos works at its best, check it each time you replace the PowerDisk and clean it if needed (see “Cleaning the Auto­Dos” under “Cleaning and care”).
The AutoDos lid must be closed to prevent damage to the AutoDos.
Always close the AutoDos lid before you close the dishwasher door. Oth­erwise, the AutoDos may become damaged.
Programs cannot start when the Auto­Dos lid is open.
63
Detergents

Manual detergent dispensing

Detergent must be manually dispensed if you have deactivated automatic dis­pensing using the AutoDossensor button.

Detergent dispensing

The detergent compartment holds a maximum of 31/2" tablespoons.
There are marks in the detergent com­partment to aid with dispensing: 11/4, 2 tablespoons (20, 30ml). When the door is opened to a horizontal position, they show the approximate fill level in ml and the maximum fill height.
Follow the detergent dosage recom-
mended by the manufacturer on the packaging.
Unless directed otherwise, use one
detergent tab or add 11/4 to 2 table­spoons (20 to 30ml) of detergent to the detergent compartment, depend­ing on the level of soiling of the dish­ware.

Adding detergent

Press the yellow button on the lid
of the detergent compartment.
The lid will spring open. The lid will also open at the end of a program.
If you use less than the recommended amount of detergent, the dishware may not get properly clean.
Some tabs may not dissolve completely when the program QuickIntenseWash is used.
64
Add the detergent to the detergent
compartment.
Push the lid shut until you hear it click
into place.
The detergent must not cause the detergent-compartment lid to get stuck. This can prevent the lid from opening during the program.
Do not overfill the detergent com­partment.
If you wish, deactivate automatic dis-
pensing/AutoDos.
Ensure that the detergent packaging
is properly closed after use. This pre­vents the detergent from getting damp and clumping together.
Detergents
You can also apply a small amount of
detergent to the inner panel of the door in programs that have a pre­rinse stage (see “Program overview”).
65

Operation

Turning on the dishwasher

Turn on the water supply if it is turned
off.
Open the door.Make sure the spray arms can rotate
freely.
Touch the sensor button.
If the dishwasher has been turned off for longer than 1minute, you will need to hold the sensor button for a bit longer (wipe protection).
The program selected will appear in the display briefly and the indicator light for the program selected will come on. Then the display will show the esti­mated duration for the selected pro­gram.

Selecting a program

Choose your program according to the type of load and the degree of soiling.
The different programs and their uses are described under Program over- view.
Touch the sensor button for the re-
quired program.
The sensor button for the selected pro­gram will light up.
Additional programs can be selected under More.
To do so, touch the More sensor
button.
The first of the additional programs will appear in the display.
Use the sensor buttons in the
display to select the program you want.
You can now select program options (see “Options”).
66
If any program options are selected, the appropriate sensor buttons will also light up.
If you want to control the dishwasher remotely using the Miele app, you will first need to activate the Remote start option (see “Activate Remote start” un­der “Options”).
Close the door within 4seconds.
Operation

Display of program duration

The estimated duration of the selected program appears on the display before the program begins. If the door is opened during the program, the time left until the end of the program is dis­played.
Each program phase is indicated by a symbol:
Pre-rinse/Soak Main wash Interim rinse Final rinse Drying Finish
The displayed duration may vary for the same program. It is influenced by, for example, the temperature of the incom­ing water, the reactivation cycle of the water softener, the detergent type, and the amount of dishes and how soiled they are.
When a program is selected for the first time, the display will show the average program duration for a cold water con­nection.

Starting a program

Start the program by closing the door
within 4seconds of the last press of a button. If necessary, confirm the previously displayed message with OK.
The in-operation indicator comes on to show that a program has been started.
If you do not close the door within 4seconds, the message Continue with
OK will appear in the display.
The program cannot be started until you confirm the message by press­ing the OK button and close the door within 4seconds.
During a program sequence, you can use OK to display the name of the program that is currently running when the door is open.
Risk of scalding due to hot wa-
ter. During operation, water in the dish-
washer may be very hot. During operation, only open the door
with extreme caution.
The program durations shown under “Program overview” refer to standard test loads and temperatures.
Each time a program is run, the control module calculates the program duration required depending on the temperature of the water taken into the dishwasher and the amount of dishes.
67
Operation

End of program

At the end of a program, the in-opera­tion indicator light will be flashing slowly with the door shut. The audible signal may also be sounding.
The in-operation indicator light will go out 10minutes after the end of the pro­gram if the door is closed.
The program has ended when the dis­play shows the messageReady.
In some programs, if the AutoOpen function is activated, the door will auto­matically open slightly (see “AutoOpen” under “Settings”). This improves the drying process.
The drying fan may continue to run for a few minutes at the end of the pro­gram.
Risk of damage due to steam.
Steam from the dishwasher could damage the edges of delicate coun­tertops when you open the door at the end of the program if the fan is no longer running.
If you have deactivated the auto­matic door opening function (see “AutoOpen” under “Settings”), but would still like to open the door at the end of the program, then make sure that you open the door fully.

Energy management

To save energy, the dishwasher will turn off automatically 10minutes after the last time a sensor button is pressed or after the end of a program.
You can turn the dishwasher back on again with the sensor button.
If the dishwasher has been turned off for longer than 1minute, you will need to hold the sensor button for a bit longer (wipe protection).
The dishwasher will not turn itself off while a program is running or if there is a fault.
68
Operation

Turning off the dishwasher

Open the door.The dishwasher can be turned off at
any time using the sensor button.
Confirm the query Turn appliance off
with OK.
Turning the dishwasher off during a pro­gram stops the program.
You can also do this to stop an ongoing timer.
Risk of damage from leaking wa-
ter. Leaking water can cause damage. If the dishwasher is not going to be
used for a longer period of time, e.g., during vacations, the water supply faucet should be turned off.

Unloading the dishwasher

Dishes tend to break and chip more easily when they are hot. Allow the dishes to cool until they are comfortable enough to handle before unloading them.
The dishes will cool much faster if you open the door when the program has ended.
First unload the lower basket, then
the upper basket, and finally the 3D MultiFlex Tray (if present). This will prevent water drops from the upper basket and 3D MultiFlex Tray from falling onto the dishes in the lower basket.
69
Operation

Interrupting a program

A program will be interrupted as soon as the door is opened. After 4seconds, the indicator light of the selected program will flash and the message Continue with OK will appear in the display.
Confirm with OK and close the door
within 4seconds.
The program will continue from the point at which it was interrupted.
Risk of scalding due to hot wa-
ter. During operation, water in the dish-
washer may be very hot. During operation, only open the door
with extreme caution.
Canceling or changing a pro­gram
If a program is canceled, important program stages may be missed.
A program should only be canceled in the first few minutes.
If a program has already started and you wish to cancel it, proceed as fol­lows:
Open the door.Turn the dishwasher off using the
sensor button.
Confirm the query Turn appliance off
with OK.
If you would like to select another pro­gram:
Turn the dishwasher back on using
the sensor button.
If you have dispensed detergent
manually, check whether the deter­gent compartment is still closed. If the lid is already open, fill it with de­tergent again and close the lid.
70
Select the program you want, and
then start it by shutting the door.
The in-operation indicator light comes on to show that a program has been started.

Options

Timer
The timer gives you several options for starting a program at a later time. The start or finish time of a program can be delayed. You can also use the
EcoStart or SmartStartfunctions to bene-
fit from cheaper energy rates at night.
During manual detergent dispensing the detergent will clump together if the detergent compartment is not dry, and this may mean it is not fully rinsed out.
When using the timer function, make sure that the detergent compartment is dry before adding detergent. Wipe dry with a cloth first, if necessary. Do not use any liquid detergents. These can leak out.
Danger to health due to deter-
gent. To prevent children coming into con-
tact with dishwasher detergent: Do not fill the detergent dispenser
until just before starting the pro­gram, i.e., before you activate the
timer.

Activating the timer

Open the door.Turn the dishwasher on using the
sensor button.
Select the desired program.Tap the sensor button.
The sensor button lights up. You can use the sensor buttons to
choose between the Start at, Finish at, or
EcoStart functions, or SmartStart if appli-
cable.
Confirm selection of the function you
want with OK.
The last time set for the timer will be displayed and the hour number block will be highlighted.
Enter the time you want for the timer
using the sensor buttons and confirm with OK.
If, while you are setting the time, you do not apply any settings for several sec­onds, the display will revert to the previ­ous menu. You will then have to enter your settings again.
After you have activated the timer, all the displays will turn off after a few minutes to save energy.
You can also activate a timer via the Miele app.
71
Options

Setting “Start at”

With the Start at function, you set the exact time at which you want the pro­gram to start.
Use the sensor buttons to enter
the hour and confirm your entry with OK.
The hour will be saved and the minute number block will be highlighted.
Use the sensor buttons to enter
the minutes and confirm your entry with OK.
The saved start time for the selected program will appear in the display for several minutes.
Close the door.
When the set time is reached, the pro­gram selected will begin automatically.

Setting “Finish at”

Use the Finish atfunction to set the lat­est time by which the program selected has to be finished.
Use the sensor buttons to enter
the hour and confirm your entry with OK.
The hour will be saved and the minute number block will be highlighted.
Use the sensor buttons to enter
the minutes and confirm your entry with OK.
The estimated start time for the se­lected program will appear in the dis­play for several minutes.
A message will appear in the display if the program cannot be completed by the set finish time because it has too long a running time.
If it appears, confirm the message
with OK.
72
Close the door.
The program will start automatically when the estimated start time is reached.
Options

Setting EcoStart

The EcoStart function enables you to benefit from cheaper electricity rates at night. Before you can use this option, you need to set up to 3 electricity rate time zones (see “EcoStart” under “Set­tings”). Then set the time by which the selected program has to be finished. The dishwasher will then start automati­cally in the most economical rate zone within the time set.
Use the sensor buttons to enter
the hour and confirm your entry with OK.
The hour will be saved and the minute number block will be highlighted.
Use the sensor buttons to enter
the minutes and confirm your entry with OK.
The estimated start time for the se­lected program will appear in the dis­play for several minutes.
Close the door.

Setting SmartStart

The SmartStart function is used for start­ing your dishwasher automatically at a time when your energy costs are most economical.
To use this function you may need fur­ther technical accessories.
If you have activated the SmartStart function in the Settings  menu, the Timer menu will no longer show the
EcoStart function but will instead show SmartStart (see “Miele@home” under
“Settings”).
If your energy provider offers this ser­vice, they will send a signal to your dishwasher when energy costs are at their most economical. This signal will start the dishwasher.
You can set the time by which the pro­gram selected has to be finished. The dishwasher will then calculate the latest possible start time for the program se­lected and will wait until this start time for the signal from the energy provider.
The program will start automatically when the estimated start time is reached.
73
Options
Set the time by which the selected pro­gram has to be finished.
Use the sensor buttons to enter
the hour and confirm your entry with OK.
The hour will be saved and the minute number block will be highlighted.
Use the sensor buttons to enter
the minutes and confirm your entry with OK.
Waiting for SmartStart will appear in the
display.
Close the door.
The selected program will start auto­matically as soon as the energy provider has sent the signal or the latest possible calculated start time has been reached.

Changing or deleting set times

You can change the time set for the timer or delete it.
Open the door.Touch the sensor button.Use the sensor buttons in the
display to select the previously acti­vated timer function and confirm your entry with OK.
Use the sensor buttons to select
the Change or Deletefunction and confirm with OK.
After confirming the Change function with OK, you can change the time set for the timer.
After confirming the Delete function with OK, the cycle time of the selected pro­gram will appear in the display. The sensor button goes out and the sensor button for the selected program will light up.
74
You can now start a program or turn the dishwasher off.
Turning the dishwasher off while a timer is running stops the timer.
You can also change the time set for the timer or delete it using the Miele app.
Options

Activating Remote start

You can start your dishwasher remotely using the Miele app. To do this, you first need to install the app on your mobile device, connect the dishwasher to your WiFi network (see “Miele@home” under “Settings”), and, if applicable, activate the Remote control option (see “Remote control” under “Settings”).
Open the door.Touch the Remote sensor button.
The Remote sensor button lights up. Turn the dishwasher off with the
button, if it is turned on.
Close the door within 4seconds.
If the dishwasher is turned off and you do not close the door within 4seconds, the message Continue with OK will ap­pear in the display and the Remote start option will be automatically deactivated. The Remote start option cannot be re­activated until you confirm the message by pressing the OK button.
The Remote start option will also re­main active if you turn the dishwasher off and back on again in the meantime.
Even if the Remote start option is not active, you can check the status of your dishwasher and apply settings using the Miele app.
If you start a program by closing the dishwasher door, the Remote start op­tion will automatically be activated for the duration of the program.
The remote control function for the dishwasher using the Miele app must be reactivated each time the door is opened before a program is started if you do not close the door within 4sec­onds.
The dishwasher can now be operated remotely using the Miele app.
75

Program overview

Program When to use Program sequence
1
Normal
Pots & Pans
China &Crystal
Quick Intense­Wash
SaniWash To sanitize dishes, e.g. baby bottles,
Program for regular use to completely wash a full load of normally soiled dishes with the ability to adjust energy and water consumption based on the soil load of the dishes.
For heavily soiled dishes and normally soiled pots,pans and utensils with dried on residue; use 20% more detergent than recommended.
For temperature sensitive glassware and lightly soiled dishes, use 50% detergent recommended. GlassCare program for temperature-sensitive glasses and dishes with light soiling.
“Quick program” for standard dishes soiling that has not dried on.
cutting boards and preparation dish­ware.
Pre-
wash
140– 158/60 –70
75
113/45
- 149/65
- 118– 149/48
Main
Interim
wash
°F/°C °F/°C
rinse
Final rinse
133–
149/56
–65
131–
158/55
–70
131–
158/55
–70
140/60
131–
158/55
–65
–70
Drying
1)
This program is used for energy labeling purposes.
76
Program overview
Consumption
Energy Water
Cold water Hot water Gallons/Liters Cold water Hot water
50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C
kWh kWh h:min h:min
2
Duration
2
1.06 1.20 3.2/12.1 3:04 2:43
1.40 1.55 3.4/13.0 3:29 3:11
0.90 1.05 3.3/12.5 2:45 2:25
1.10 1.15 2.9/11.0 1:13 0:58
0.85–1.25 0.90–1.40 1.7–3.2/6.5–12.0 2:28–3:45 2:16–3:27
2
Values were calculated under standardized testing conditions. In practice there may be variations to these figures due to variable conditions and data recorded by the sensors. Durations shown will reflect your household conditions. Selecting program options will also affect consumption levels and program durations (see “program options”). The energy consumption with a hot water supply includes the energy used to heat the water (exception: EnergySaver, if available).
77
Program overview
Program When to use Program sequence
Rinse& Hold
Extra Quiet Extra quiet program for mixed loads
Filters Wash program for cleaning Miele ven-
Clean Machine
To rinse dishes when a complete pro­gram is not needed.
with standard, slightly dried-on food residue with a longer program dura­tion.
tilation hood filters.
Special cleaning program to remove grease deposits from the dishwasher.
Pre-
wash
- 131/55
167/75
- 167/75
Main
Interim
wash
°F/°C °F/°C
rinse
Final rinse
- - - -
131–
158/55
–70
131–
158/55
–70

158/70
Drying
78
Program overview
Consumption
Energy Water
Cold water Hot water Gallons/Liters Cold water Hot water
50°F/10°C 120°F/49°C 50°F/10°C 120°F/49°C
kWh kWh h:min h:min
2
Duration
2
0.01 0.15 1.1/4.0 0:21 0:21
1.00 1.15 2.5/9.5 4:10 3:56
1.55 1.70 3.3/12.5 3:51 3:35
1.75 2.00 5.0/19.0 2:37 2:07
2
Values were calculated under standardized testing conditions. In practice there may be variations to these figures due to variable conditions and data recorded by the sensors. Durations shown will reflect your household conditions. Selecting program options will also affect consumption levels and program durations (see “program options”). The energy consumption with a hot water supply includes the energy used to heat the water (exception: EnergySaver, if available).
79

Program options

Selecting program options

You can use program options to adjust the programs.
To do this, you can select or deselect the program options before running the program.
Open the door.Turn the dishwasher on using the
sensor button.
The sensor button for the selected pro­gram will light up.
Select a different program as re-
quired.
Touch the sensor button for the pro-
gram option you want.
The appropriate sensor button will light up when the program options are avail­able for the selected program.
If the program option is not compatible with the selected program, a message to this effect will appear in the display.
In this instance, confirm the message
with OK.
Start the program by closing the
door.
The selected program option will remain active for that particular program until the setting is changed.
IntenseZone

The IntenseZone program option in­creases cleaning performance in the lower basket.

Energy consumption increases due to the extended wash duration in the lower basket and increased temperature.
Express

The Expressoption reduces the pro­gram cycle time.

In order to achieve optimum cleaning results, the temperature, and therefore the energy consumption, will increase with this option.
The time by which the program cycle time is shortened varies according to the selected program.
Selecting the Expressoption may take precedence over other selected options.
When used in combination with the QuickIntenseWash program, the Express option results in a rinse designed solely for the purpose of flushing out the wash cabinet to re­move salt solution that leaked out af­ter refilling the salt reservoir.
80

Cleaning and care

Check the condition of your dish­washer regularly (approx. every 4– 6months). This helps to avoid faults and problems.
Damage due to unsuitable clean-
ing agents. All surfaces are susceptible to
scratching. Contact with unsuitable cleaning agents can alter or discolor all surfaces.
Only use cleaning agents formulated for use on the relevant surfaces.

Cleaning the wash cabinet

The wash cabinet is largely self-clean­ing, provided that the correct amount of detergent is always used.
The frequent use of low-temperature wash programs increases the risk of contamination and odors inside the wash cabinet. Run the Pots & Pans pro­gram once per month to clean the wash cabinet and prevent odors from devel­oping.
However, if residues such as limescale or grease have been deposited, use the
Clean Machine program to clean the
dishwasher (see “Additional pro­grams” under “Program overview”) with dishwasher cleaner (see “Clean Machine” under “Optional acces­sories”). Follow the dosage recom­mended by the manufacturer on the packaging.
Miele cleaning and care products are available to order from Miele Customer Service or from Miele’s online store.
Clean the filters in the wash cabinet
regularly.
81
Cleaning and care

Hygiene cycle

The frequent use of low-temperature wash programs increases the risk of contamination and odors inside the wash cabinet. If you repeatedly use low-temperature programs, you should regularly run a high-temperature pro­gram. This is to prevent contamination and odors.
You can activate or deactivate a Hy­giene info message (see “Settings – Hy­giene cycle”). If you deactivate this message, run the Intensiveprogram once per month to clean the wash cabinet and prevent odors from developing.

Cleaning the door and the door seal

The door seal and the sides of the dish­washer door are not accessed and cleaned by the spray arm jets. As a re­sult, mold can develop here.
Wipe the door seals regularly with a
damp cloth to remove food deposits.
Wipe off any food or drink residues
which may have dripped onto the sides of the dishwasher door before closing it.
82
Cleaning and care

Cleaning the control panel

The control panel should only be
wiped with a damp cloth.

Cleaning the reflector panel

The reflector panel for the in-operation indicator light is situated on the cover sheeting underneath the countertop.
The reflector panel should only be
cleaned with a damp cloth if neces­sary.
Cleaning the front of the ma­chine
Damage due to soiling.
Soiling that is left too long might be­come impossible to remove and could cause the external surfaces to alter or discolor.
It is therefore best to remove any soiling immediately.
Clean the appliance front with a clean
soft sponge and a solution of warm water and liquid dish soap. After cleaning, wipe the surfaces dry using a soft cloth. A clean, damp microfiber cloth with­out detergent can also be used.
To avoid damaging the external sur­faces, do not use the following:
- cleaning agents containing soda, am­monia, acids, or chloride
- cleaning agents containing lime scale remover
- abrasive cleaning agents, such as scouring powder, scouring liquid, or pumice stones
- cleaning agents containing solvents
- stainless-steel cleaning agents
- dishwasher cleaner
- oven cleaner
- glass cleaner
- hard, abrasive brushes or sponges, e.g., pot scourers, brushes, or sponges which have been previously used with abrasive cleaning agents
- eraser sponges
- sharp metal scrapers
- steel wool
- steam cleaners
83
Cleaning and care
Cleaning the AutoDos assem­bly
If the Clean AutoDos message is dis­played, check that the fill channel is clean, and clean it if necessary, e.g., powder residues. This helps keep the AutoDos working properly.
In order to ensure that the AutoDos works at its best, check it each time you replace the PowerDisk and clean it if needed.
Turn the AutoDos lid to and open
it.
Remove the PowerDisk if appropriate.
Pull the PowerDisk holder upward by
the yellow tabs and remove it. When doing so, do not pull on the side tab.
1 PowerDisk holder
2 Fill channel for dispensing the deter-
gent from the PowerDisk into the wash cabinet
84
Use the tab (see the arrow) to re-
lease the fill channel and pull it out
.
Cleaning and care
Clean the fill channel using water and
a soft brush if necessary.
It is very important that no moisture is able to access the inside of the AutoDos system during cleaning.
Dry the fill channel well so that the
detergent powder does not clump to­gether.
Insert the fill channel again until the
tab clicks into place.
The AutoDos lid must close tightly so that the detergent powder does not get wet and clump together.
Make sure that all seals are clean.
Insert a PowerDisk.Close the AutoDos lid and turn it until
the lid handle is directly below the symbol (see “Inserting a Pow­erDisk” under “Detergent”).
Regularly check the lower spray arm for any blockages to ensure that the detergent outlet of the AutoDos can be fully flushed out (see “Cleaning the spray arms” under “Cleaning and care”).
Put the holder back into place so that
the arrows in the PowerDisk holder and in the viewing window point to­ward each other. The holder must lie flat.
85
Cleaning and care

Cleaning the spray arms

Particles of food can get stuck in the spray-arm jets and bearings. The spray arms should therefore be inspected reg­ularly (approx. every 2–4months).
Never run a wash program without using the spray arms.
Damage due to soiling entering
the circulation system. Without filters, soiling can enter the
circulation system and cause a blockage.
Do not run a wash program without the lower spray arm or without the fil­ters.
When cleaning the filters and spray arms, make sure that coarse soiling cannot get into the circulation sys­tem.
Turn off the dishwasher.

Removing the cutlery tray (if present)

In order to be able to remove the upper spray arm, you first have to remove the cutlery tray (if present).
Pull out the cutlery tray.
Press the rail safety clips on both
sides of the cutlery tray together and remove the safety clips.
Take out the cutlery tray completely.
86
Cleaning and care

Removing the upper spray arm

Push the upper spray arm upward
to engage the inner ratchet. Then un­screw the spray arm by rotating the
screw thread counterclockwise.

Removing the middle spray arm

Removing the lower spray arm

Remove the lower basket.
Rotate the screw thread of the lower
spray arm counterclockwise and
pull the spray arm upward to re-
move.

Cleaning the spray arms

Rotate the screw thread of the middle
spray arm clockwise and remove the spray arm.
Use a pointed object to push food
particles that are stuck in the spray­arm jets into the spray arm.
Rinse the spray arm thoroughly under
running water.
87
Cleaning and care

Reinstalling the spray arms

Reinstall the upper spray arm and
tighten it by hand.
Reinstall the middle spray arm.Reinstall the lower spray arm and en-
sure that the filter combination lies flat in the base of the wash cabinet.
Rotate the screw thread of the lower
spray arm clockwise until the arrow in the viewing window points to the lock symbol.

Inserting the cutlery tray (if present)

Slide the cutlery tray back onto the
rails from the front.
Replace the safety clips in the rails on
both sides of the cutlery tray.
Make sure the spray arms can rotate
freely.
Damage due to soiling entering
the circulation system. The lower spray arm is used to se-
cure the filter combination. Without filters, coarse soiling can enter the circulation system and cause a blockage.
Do not run a wash program without the lower spray arm or without the fil­ters.
88
Cleaning and care

Checking the filters in the wash cabinet

The filter combination in the base of the wash cabinet retains coarse soil from the suds solution. This prevents soiling getting into the circulation system and re-entering the wash cabinet through the spray arms.
Damage due to soiling entering
the circulation system. Without filters, soiling can enter the
circulation system and cause a blockage.
Do not run a wash program without the lower spray arm or without the fil­ters.
When cleaning the filters and spray arms, make sure that coarse soiling cannot get into the circulation sys­tem.
The filters can become blocked by soil­ing that collects over time. The level of soiling and time it takes before the fil­ters need cleaning will vary depending on use.

Cleaning the filters

Turn off the dishwasher.Remove the lower spray arm (see
“Cleaning the spray arms” under “Cleaning and care”).
Before removing the filter combina-
tion, remove any coarse soiling to prevent it from entering the circulation system.
Remove the filter combination.
The message Check filters will appear in the display after every 50 program se­quences.
Check the filter combination.Clean if necessary.Then confirm the message with OK.
89
Cleaning and care
In order to clean the inside of the fil-
ter, pull the microfilter on the plastic ring downwards and away from the filter combination.
Rinse all of the filters under running
water. If necessary, use a soft cleaning brush to remove soiling.
Insert the microfilter back into the fil-
ter combination.
Reinstall the filter combination so that
it lies flat in the base of the wash cab­inet.
Refit the lower spray arm to the filter
combination using the screw thread.
Rotate the screw thread clockwise
until the arrow in the viewing window points to the lock symbol.
Damage due to soiling entering
the circulation system. The lower spray arm is used to se-
cure the filter combination. Without filters, coarse soiling can enter the circulation system and cause a blockage.
Do not run a wash program without the lower spray arm or without the fil­ters.
90

Cleaning the drain pump

If water remains in the wash cabinet af­ter the end of a program, the water has not been pumped away. The drain pump may be blocked by foreign ob­jects. These foreign objects are easy to remove.
Disconnect the dishwasher from the
power supply. To do this, turn off at the electrical socket and withdraw the plug.
Take the filter combination out of the
wash cabinet (see “Cleaning the fil­ters” under “Cleaning and care”).
Cleaning and care
Press the catch of the drain pump
cover inwards.
Scoop the water out of the wash cab-
inet using a suitable small container or utensil.
Tip the cover inwards until it is re-
leased.
Rinse the cover thoroughly under run-
ning water and remove all foreign ob­jects.
91
Cleaning and care
The drain pump (see arrow) is under­neath the cover.
Risk of injury from glass splin-
ters. It is especially difficult to see glass
splinters in the drain pump. Take care when cleaning the drain
pump.
Damage due to incorrect clean-
ing. The components are delicate and
can be damaged during cleaning. Take care when cleaning the drain
pump.
Carefully remove all foreign objects
from the drain pump. Check the drain pump impeller by manually turning it. You will feel a little resistance when you turn the impeller.
Refit the cover by placing it down
vertically from above.
Ensure that the catch engages cor­rectly.
92

Frequently Asked Questions

With the help of the following guide minor faults in the performance of the ma­chine, some of which may result from incorrect operation, can be remedied with­out contacting the Service Department.
This guide may help you to find the reason for the fault, and how to correct it.
This section only lists faults that you can remedy yourself. All other faults are shown in Fault FXX.

Technical faults

Problem Possible cause and solution
The dishwasher does not start.
The dishwasher stops during a program.
After the program has started, the in-operation indicator light is not vis­ible.
The door is not properly closed.
Raise the door upward until the catch engages.
The dishwasher is not plugged in.
Insert the plug.
The circuit breaker has tripped.
Reset the breaker (see data tag for the correct fuse
rating).
If the breaker trips again, contact Miele Customer
Service.
The dishwasher is not turned on.
Turn the dishwasher on using the sensor button.
The circuit breaker has tripped.
Reset the circuit breaker (see data plate for the
correct fuse rating).
If the circuit breaker trips again, contact Miele
Customer Service.
The reflector panel was not correctly fitted.
Re-fit the reflector panel correctly (see installation
sheet).
93
Frequently Asked Questions

Fault messages

Problem Possible cause and solution
The in-operation indica­tor light is flashing quickly. The alarm tone is sounding. One of the following faults appears in the display:
Fault FXX There may be a technical fault.
Waterproof The Waterproof system has reacted.
Fault F78 Circulation pump fault.
Before remedying the fault:
Turn off the dishwasher.
Turn the dishwasher back on after a few seconds.Select the desired program.Close the door.
If the fault message appears again, there is a techni­cal fault.
Turn off the dishwasher.Turn off the water supply.Contact Miele Customer Service.
Turn off the dishwasher.Turn off the water supply.Contact Miele Customer Service.
Turn off the dishwasher.Turn the dishwasher back on.Select the desired program.Close the door.
If the fault message appears again, there is a techni­cal fault.
Turn off the dishwasher.Turn off the water supply.Contact Miele Customer Service.
94
Frequently Asked Questions

Door release

Problem Possible cause and solution
The in-operation indica­tor light is flashing quickly. The alarm tone is sounding. The following fault is in­dicated via the display:
Door fault The door does not open automatically.
Before remedying the fault:
Turn off the dishwasher.
There may be a technical fault.
Open the door manually (see “Opening the door”
under “Before using for the first time”) and turn the dishwasher back on again.
If the same fault message appears again, contact
Miele Customer Service.
The door locking pins do not retract after the door is opened. There may be a technical fault.
Turn the dishwasher back on.If the same fault message appears again, contact
Miele Customer Service.
95
Frequently Asked Questions

Water intake fault

Problem Possible cause and solution
The in-operation indica­tor light is flashing quickly. The alarm tone is sounding. One of the following messages appears in the display:
Open water supply The water supply is turned off.
Open the water supply valve all the way.
Intake Before remedying the fault:
Turn off the dishwasher.
Water-intake fault.
Open the water-supply faucet all the way and start
the program again.
Clean the water-intake filter (see “Cleaning the wa-
ter-intake filter” under “Cleaning and care”).
The water-connection pressure is lower than 7.25
psi (50kPa). Seek professional advice.
The on-site connection for the water drainage may
be too low and you will need to vent the water drainage (see “Water drainage” under “Installa­tion”).
Fault F18 A technical fault has occurred.
Turn off the dishwasher.Close the faucet.Contact Miele Customer Service.
The following fault mes­sage appears during the
EnergySaver program: Intake temperture low
The intake water has not reached the required tem­perature of 115°F (45°C) (see “Water intake” under “Installation”).
Start the program again.If the fault message appears again, select a differ-
ent program.
96
Frequently Asked Questions

Water drainage fault

Problem Possible cause and solution
The in-operation indica­tor light is flashing quickly. The alarm tone is sounding. The following message appears on the display: Drain
Before remedying the fault:
Turn off the dishwasher.
Water drainage fault. There might be water in the wash cabinet.
Clean the filter combination (see “Cleaning the fil-
ters” under “Cleaning and care”).
Clean the drain pump (see “Cleaning the drain
pump” under “Cleaning and care”).
Remove any kink or loop in the drain hose.
97
Frequently Asked Questions

Fault in the AutoDos (automatic dispensing)

Problem Possible cause and solution
The following message appears on the display:
Insert PowerDisk or deacti­vate AutoDos with OK
The in-operation indica­tor light is flashing quickly. The alarm tone is sounding. The program does not start or a program that has already started stops. The following message appears on the display:
AutoDos lid open
The following message appears on the display:
PowerDisk empty. Deacti­vate AutoDos with OK.
The message
PowerDisk empty. Deacti­vate AutoDos with OK. ap-
pears in the display even though you have inserted a new Pow­erDisk.
The AutoDosfunction is active but no PowerDisk has been inserted.
Insert a PowerDisk (see “Automatic dispensing/
AutoDos” under “Detergent”).
If you do not wish to use AutoDos, deactivate the
function using OK or the AutoDossensor but­ton.
The AutoDos lid has not been closed properly.
Close the AutoDos lid and lock it fully (see “Auto-
matic dispensing/AutoDos” under “Detergent”).
If the lid cannot be fully closed, check whether the
PowerDisk holder is lying flat (see “Inserting a PowerDisk” under “Detergent”).
If the same fault message appears again, contact
Miele Technical Service.
The AutoDosfunction is active and the PowerDisk is empty.
Replace the PowerDisk (see “Automatic dispens-
ing/AutoDos” under “Detergent”). If you do not wish to use AutoDos, deactivate the function using OK or the AutoDossensor but­ton.
The dishwasher was turned off when the PowerDisk was replaced and it has therefore not recognized the new PowerDisk.
Turn the dishwasher on before replacing the Pow-
erDisk (see “Automatic dispensing/AutoDos” and “Inserting a PowerDisk” under “Detergent”).
98
Frequently Asked Questions
Problem Possible cause and solution
The in-operation indica­tor light is flashing quickly. At the end of the pro­gram, the alarm tone sounds and the display shows the following message: Fault F601
The in-operation indica­tor light is flashing quickly. At the end of the pro­gram, the alarm tone sounds and the display shows the following message:
AutoDos maintenance re­quired
The dishwasher does not turn off at the end of the program. The dishes may not be clean because an insuf­ficient amount of deter­gent was dispensed. The AutoDos func­tion is automatically de­activated during the program sequence.
There is a fault in the AutoDos.
Turn the dishwasher off and back on again.Check whether the PowerDisk holder and the
PowerDisk have been fitted correctly (see “Auto­matic dispensing/AutoDos” under “Detergent”).
Activate the AutoDos function and start the pro-
gram again.
If the fault message appears again, there is a techni­cal fault. You can continue to use your dishwasher by deactivating automatic dispensing using the Auto- Dossensor button and manually dispensing the de­tergent via the detergent compartment.
If you wish to use automatic dispensing again,
contact Miele Customer Service.
An empty PowerDisk has been inserted or the Auto­Dos is blocked by residual detergent. Detergent dosage is insufficient. The AutoDos function was automatically deacti­vated.
Turn the dishwasher off and back on again.
Multiple messages appear in the display.
Clean the pouring channel of the AutoDos (see
“Cleaning the AutoDos” under “Detergent”).
Clean the lower spray arm (see “Cleaning the
spray arms” under “Cleaning and care”).
Select OK to confirm each message.Activate the AutoDos function by confirming the
message AutoDos available with OK.
Start the program again.
The program duration will be extended by up to
2.5hours to flush out the AutoDos detergent outlet.
99
Frequently Asked Questions

Spray arm fault

Problem Possible cause and solution
During the program and at the end of the pro­gram, the display shows the following message:
Check spray arms
The dishwasher does not turn off at the end of the program. The dishes may not be clean because no deter­gent was dispensed. The AutoDos func­tion is automatically de­activated during the program sequence.
The lower spray arm is blocked or the nozzles of the lower spray arm are clogged. The AutoDos func­tion is automatically deactivated during the program because the AutoDos detergent outlet cannot be completely flushed out.
Turn the dishwasher off and back on again.
Messages appear in the display.
Perform a rotation check of the lower spray arm
and rearrange the wash items if they are blocking the spray arm.
Clean the lower spray arm (see “Cleaning the
spray arms” under “Cleaning and care”).
Select OK to confirm each message.Start the program again.
100
Loading...
