Miele G 5285, G 5280 User Manual
Operating Instructions
Dishwasher
G 5280
G 5285
To prevent accidents
and appliance damage
read these instructions
before
installation or use.
en - US, CA
M.-Nr. 09 510 220
Contents
IMPORTANT SAFETY INSTRUCTIONS.................................4
Guide to the dishwasher ............................................7
Control panel ......................................................8
Caring for the environment..........................................9
Before using for the first time.......................................10
To open the door ..................................................10
To close the door ..................................................10
Displaying and setting the water hardness ...........................12
Filling the salt container .............................................13
Salt indicator .....................................................14
Deactivating refill indicators .......................................15
Rinse aid ........................................................16
Adding rinse aid ..................................................16
Rinse aid indicator .................................................17
Setting the rinse aid dosage .........................................18
Loading the dishwasher ...........................................19
Items not recommended for dishwashing ...............................20
Typical load for 10 place settings with cutlery tray ........................21
Typical load for 16 place settings with cutlery tray ........................22
Upper basket .....................................................23
Lower basket .....................................................25
MultiComfort zone...............................................26
Foldable spikes (depending on the model) ...........................26
Optional accessories..............................................29
Use ............................................................30
Detergent ........................................................30
Adding detergent..................................................31
Turning the dishwasher on ..........................................32
Selecting a program ...............................................32
Starting a program.................................................32
Time display......................................................34
Standby .........................................................34
At the end of a program.............................................35
Preparing your appliance for an extended vacation .......................35
Interrupting a program..............................................36
Changing a program ...............................................36
2
Contents
Additional options ................................................37
Turbo ...........................................................37
Delay start .......................................................38
Buzzer ..........................................................39
Optimize Standby .................................................40
Factory defaults ...................................................41
Frequently Asked Questions .......................................42
Technical faults ...................................................42
Faults in the water intake or water drain ................................43
General problems with the dishwasher .................................44
Sounds..........................................................45
Poor cleaning results ...............................................46
After sales service ................................................49
User Maintenance Instructions......................................51
Cleaning and Care ................................................52
Triple filter system .................................................53
Cleaning the drain pump and non-return valve...........................56
Installation instructions ...........................................57
Electrical connection..............................................58
Plumbing........................................................60
Connection to the water supply .......................................60
Drainage ........................................................61
3
IMPORTANT SAFETY INSTRUCTIONS
WARNING –
When using your dishwasher, follow
basic precautions, including the
following:
Read the operating instructions and
installation diagram carefully before
installation or use of the dishwasher
to prevent injury and machine
damage.
Use the dishwasher only for its
intended purpose. This appliance is
intended for residential use only.
Keep these operating instructions in
a safe place and pass them on to
any future user.
Correct usage
The dishwasher is not designed for
~
commercial use. It is intended for use in
domestic households and in similar
working and residential environments
such as, shops, offices and showrooms
or guest houses.
The dishwasher is not intended for
~
outdoor use.
It must only be used as a domestic
~
appliance as specified in these
operating instructions, for cleaning
domestic cookware and cutlery. Any
other usage is not supported by the
manufacturer and could be dangerous.
Persons who lack physical, sensory
~
or mental abilities, or experience with
the appliance should not use the
dishwasher without supervision or
instruction by a responsible person.
Electrical Safety
Before installation, make sure that
~
the voltage and frequency listed on the
data plate correspond with the
household electrical supply. This data
must correspond to prevent injury and
machine damage. Consult a qualified
electrician if in doubt.
Before installation or service,
~
disconnect the power supply to the
work area by unplugging the unit,
"tripping" the circuit breaker or
removing the fuse.
Do not use an extension cord to
~
connect this appliance to electricity.
Extension cords do not guarantee the
required safety of the appliance (e.g.
danger of overheating).
Be certain your appliance is
~
properly installed and grounded by a
qualified technician. To guarantee the
electrical safety of this appliance
continuity must exist between the
appliance and an effective grounding
system. It is imperative that this basic
safety requirement be met. If there is
any doubt, have the electrical system of
the house checked by a qualified
electrician.
If the supplied power cord is
~
damaged it must only be replaced by a
Miele Service technician with a genuine
Miele power cord.
The outlet must be accessible at all
~
times after installation to disconnect the
dishwasher.
4
IMPORTANT SAFETY INSTRUCTIONS
Installation
The dishwasher must be installed
~
and connected in accordance with the
installation instructions.
Installation and repair work should
~
be performed by a Miele authorized
service technician. Work by unqualified
persons could be dangerous and may
void the warranty.
Do not install or use a damaged
~
dishwasher. A damaged appliance is
dangerous. Unplug the machine and
contact Miele Technical Service
Department.
Ensure that any plastic wrappings,
~
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
This appliance must not be used in
~
a non-stationary location (e.g. on a
boat).
, WARNING - Fire hazard!
~
Do not cover or crush the plug of the
appliance. Ensure that the cabinet
opening for the dishwasher provides
ample space for the plug and cord.
Installing the dishwasher in a tight
space may crimp the power cord or put
pressure on the plug which could
cause overheating.
This dishwasher should only be
~
installed under a continuous counter
top secured to adjacent cabinetry.
Do not install this dishwasher
~
beneath a cooking surface, oven or any
appliance that radiates heat.
High temperatures from these units
may damage the dishwasher.
A toe-kick must be used with the
~
dishwasher. If the supplied toe-kick is
not used, a cabinet matching toe-kick
must be installed.
Do not install the dishwasher in an
~
area where it will be exposed to
temperatures below freezing.
Do not cut the intake hose or
~
submerge it in liquid. This hose
contains electrical components that
could cause injury or property damage
if cut or submerged.
Only power up the dishwasher when
~
all installation and plumbing work is
complete.
Do not place hose or power cord
~
next to a heat source e.g. hot water
pipes.
Do not expose hose or power cord to
corrosive substances.
Damage of hose or power cord could
cause electrical shock or water
damage!
5
IMPORTANT SAFETY INSTRUCTIONS
Use
To reduce the risk of injury, do not
~
allow children to play in, on or near the
dishwasher. It is possible for small
fingers may be pinched in the door.
Only use the dishwasher if all panels
~
are properly in place.
Do not tamper with the controls.
~
Do not sit or stand on the door or
~
baskets of the dishwasher. Close the
door when not in use.
Under certain conditions, hydrogen
~
gas may be produced in a hot water
system that has not been used for two
weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has
not been used for such a period, turn
on all hot water faucets and let water
flow from each for several minutes
before using the dishwasher. This will
release any accumulated hydrogen
gas. Do not smoke or use an open
flame during this time.
Be sure that all items placed in the
~
dishwasher are "dishwasher safe". For
items not labeled, check the
manufacturer’s recommendations.
When loading tableware, place
~
sharp items away from the door to
prevent damage to the seal. Load
sharp items pointing downwards to
prevent injuries.
Only use detergents and rinse aids
~
recommended for residential
dishwashers. Keep all detergents and
rinse aids out of the reach of children.
Do not inhale or swallow detergents.
~
Dishwasher detergents contain irritant
and corrosive ingredients. They can
cause burning in the mouth and throat if
swallowed, or inhibit breathing. Consult
a doctor immediately if detergent has
been swallowed or inhaled.
Do not drink water from the
~
dishwasher! Harmful residues could be
present.
Do not fill the rinse aid reservoir or
~
salt container with detergent. It will
destroy the rinse aid compartment and
water softener.
Dishes can be very hot at the end of
~
a program. Allow the dishes to cool
until they are cool enough to handle
before unloading them.
The water supply must be turned off
~
when the appliance is not used for a
longer period of time (e.g. during
vacations).
Disposal of an appliance
If the appliance is removed from its
~
installation site and will not be used,
remove the doorlock to the wash
cabinet to prevent children from locking
themselves in the machine.
SAVE THESE
INSTRUCTIONS
6
Guide to the dishwasher
a Upper spray arm (not visible)
b Cutlery tray (depending on model)
c Upper basket
d Middle spray arm
e Air inlet for drying
(depending on model)
f Lower spray arm
g Triple filter system
h Data plate
i Rinse aid reservoir
j Dual compartment detergent
dispenser
k Salt container
7
Guide to the dishwasher
Control panel
a Check / Refill indicators
b Time display
c , button with indicator light
(Delay start)
d Turbo button with indicator light
e Program selection
f Program button
g K button (On/Off) with indicator light
This operating instruction manual describes several dishwasher models with
different indicated settings.
The different dishwasher models are named :
Standard = Dishwasher with 31 11/16" (80.5 cm) height (built-in)
or 33 1/4" (84.5 cm) height (stand-alone)
XXL = Dishwasher with 33 1/4" (84.5 cm) height.
8
Caring for the environment
Energy saving washing
This dishwasher is economical in the
use of water and electricity. For best
results follow these tips:
For lowest energy consumption you
^
may connect the dishwasher to a
cold water source.
For fastest possible wash times, with
^
slightly higher energy consumption,
connect the dishwasher to a hot
water source.
Make full use of the baskets without
^
overloading for the most economical
washing.
^ Use the correct amount of detergent
and rinse aid. Detergent dosage is
dependent upon the amount of
soiling and type of dishware being
washed. See the "Program Guide" for
more information.
^ When using powder or liquid
detergent, reduce the amount to
of the normal amount when washing
a small load.
2
/
3
Disposal of the packing
material
The cardboard box and packaging
protect the appliance during shipping.
These materials are biodegradable and
recyclable. Please recycle.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of an old machine
Old appliances may contain materials
that can be recycled. Please contact
your local recycling authority about the
possibility of recycling these materials.
Ensure that the appliance presents no
danger to children while being stored
for disposal. Before discarding an old
appliance, unplug it from the outlet, cut
off its power cord and remove any
doors to prevent hazards.
^
Choose a program that best suits the
degree of soiling and the type of
dishes being washed.
9
Before using for the first time
To open the door
^ Pull the handle to open the door.
If the door is opened during operation,
the dishwasher will stop running. Once
the door is closed the program will
continue.
To close the door
Push the baskets in.
^
Lift the door and push until it clicks
^
into position.
10
Before using for the first time
Water hardness
To achieve good cleaning results, the
dishwasher needs soft water. Hard
water results in calcium deposits on
dishware and in the dishwasher.
If your tap water hardness is above 4 °d
(4 gr/gal [US]), the water should be
softened.
Your local water authority will be able
–
to advise you of the water hardness
level in your area.
The dishwasher must be
–
programmed to correspond to the
water hardness in your area.
– In areas where the water hardness
fluctuates (e. g. 37 - 50 °d
[39 -52 gr/gal]) always program the
machine to the higher value (in this
example 50 °d [52 gr/gal]).
It is useful to know your water hardness
so that you can provide the service
technician with this information in the
event of any service calls.
The water hardness factory setting is
15°d (16 gr/gal).
If this setting matches your water
hardness you need not read any
further.
However, if you have a different water
hardness you must adjust the water
softener to match your water hardness.
If there is a fault, it will help the service
technician to know the hardness of your
local water supply.
Please note your water hardness
below:
°d (gr/gal)
11
Before using for the first time
Displaying and setting the water
hardness
If the dishwasher is on, press the K
^
button to turn it off.
Hold down the Program button.
^
Press the K button to turn the
^
dishwasher on, and hold the Program
button down for at least 4 more
seconds until the lower right program
indicator lights up.
If it does not come on, start over.
Press the Turbo button twice.
^
The Turbo indicator light flashes 2 times
at a short interval.
The time display shows the flashing
sequence p15.
A water hardness of 15°d (16 gr/gal) is
set (default setting).
^ Using the Program button, select the
value that matches your water
hardness.
With each press of the button the value
will go up one level. Once the highest
value is reached the setting will start
again from the beginning.
^
Press the K button to turn the
dishwasher off.
°d gr/gal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37-50
51-60
61-70
39-52
53-63
64-73
10
11
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
38
Value to
set
in the display
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
50
60
70
12
Every dishwasher is tested before
leaving the factory. Any water
remaining in the machine is from the
final factory test and does not
indicate that the machine has been
used.
Before using for the first time
Filling the salt container
To achieve good cleaning results, the
dishwasher needs soft water (water that
is low in minerals). Hard water results in
calcium deposits on dishware and in
the dishwasher.
Therefore, if your tap water hardness is
above 4 °d (4 gr/gal) the water should
be softened.
Inadvertently filling the salt
,
container with dishwashing
detergent (including liquid
detergent) will damage the water
softener.
Only use water softener salt
,
specially formulated for
dishwashers. Other salts may
contain insoluble additives which
can impair the water softener.
If using "Tab" products which
include salt, still add salt to the
machine to achieve optimal cleaning
results and ensure long-term
functioning of the water softener.
13
Before using for the first time
Remove the lower basket from the
^
wash cabinet and unscrew the salt
container lid.
When opening the salt container,
water will run out. Open the
container only to refill salt.
Important: The salt container must
be filled with 2 quarts (2 l) of water
before adding salt for the first time
so the salt can dissolve
properly. Water does not have to be
added with subsequent refills.First
fill the container with approx. 2 liters
of water.
Immediately run the Express program
^
without a load (no Turbo function) to
remove any traces of salt or brine
from the wash cabinet.
Salt indicator
When the Salt indicator comes on,
^
refill the salt container.
The refill salt message may continue to
be displayed for a short time after salt
has been added. It will go out as soon
as a sufficiently high concentration of
salt has formed.
The Insufficient salt message is turned
off if you have programmed the
dishwasher to a water hardness below
4 °d (4 gr/gal).
,Immediately run the Express
program without a load (no Turbo
function) to remove any traces of
salt or brine from the wash cabinet.
^
Place the provided funnel over the
salt container and carefully fill it with
salt. The salt container holds
approx. 4.4 lbs (2 kg) of salt,
depending on the type of salt.
^
Clean any excess salt from the
threads of the container opening.
Screw the lid on firmly.
14
Before using for the first time
Deactivating refill indicators
If you consistently use Tab detergents,
you can deactivate the refill indicators if
you wish.
Press the K button to turn the
^
dishwasher off.
Hold down the Program button and
^
simultaneously turn the dishwasher
on using the K button.
Keep the Program button pressed for
at least four seconds until the lower
right program indicator lights up.
If it does not come on, start over.
^ Press the Turbo button nine times.
The Turbo indicator light flashes 9 times
at a short interval.
The flashing in the time display
indicates whether the refill indicators
are activated or not.
"p1": refill indicators are activated
–
"p0": refill indicators are deactivated
–
Press the Program button if you wish
^
to change the setting.
The setting is immediately saved.
Press the K button to turn the
^
dishwasher off.
If you switch to a single-function
detergent, it is important to
remember to add salt and rinse aid
and to activate the indicators.
15
Before using for the first time
Rinse aid
Rinse aid helps to prevent spotting on
dishes and glassware.
The rinse aid is filled in the reservoir
and the set amount will be
automatically dosed.
Filling the rinse aid reservoir with
,
detergent (liquid or powder) will
damage the reservoir. Only pour
rinse aid formulated for residential
dishwashers into the reservoir.
When using "Tab" detergents rinse
aid is not needed.
Adding rinse aid
Pour rinse aid into the reservoir until it
^
is visible in the opening.
The rinse aid reservoir holds
approximately 3.7 fl. oz. (110 ml).
^ Close the flap until you hear it click
shut, otherwise water might enter the
reservoir during the wash program.
^
Press the button on top of the rinse
aid reservoir in the direction of the
arrow. The flap will pop open.
16
^ Wipe up any spilled rinse aid to
prevent over-foaming during the next
wash program.
Rinse aid indicator
When the Rinse aid indicator comes on,
the reservoir only contains enough rinse
aidfor2-3wash programs.
Add rinse aid soon.
^
If you consistently use a detergent
that contains salt and rinse aid, you
can deactivate the refill indicators if
you wish (see Before using for the
first time - Deactivating refill
indicators).
If you switch to a single-function
detergent, it is important to
remember to add salt and rinse aid
and to activate the indicators.
Before using for the first time
17
Before using for the first time
Setting the rinse aid dosage
The rinse aid dosage can be set at
levels between 0 and 6 ml. The factory
setting is 3 ml of rinse aid. This is just a
recommendation.
If the dishes appear spotty:
Use a higher setting.
^
If the dishes appear cloudy or streaky:
Use a lower setting.
^
Press the K button to turn the
^
dishwasher off.
Hold down the Program button and
^
simultaneously turn the dishwasher
on using the K button.
Keep the Program button pressed for
at least four seconds until the lower
right program indicator lights up.
If it does not come on, start over.
Press the Turbo button three times.
^
The Turbo indicator light flashes 3 times
at short intervals.
The time display shows the flashing
sequence p3.
The set value is shown in the time
display after the P.
^ Select the desired dosage with the
Program button.
Every touch of the button increases
the level.
The setting is saved immediately.
18
^
Press the K button to turn the
dishwasher off.
Do not wash items soiled with
,
ash, sand, wax, grease or paint in
the dishwasher.
Ash and sand do not dissolve and
will be distributed throughout the
inside of the dishwasher.
Wax, grease and paint will cause
permanent discoloration and
damage to the dishwasher.
Scrape food from dishes before
^
placing them in the dishwasher,
rinsing is not necessary.
^ Some foods contain natural dyes,
e.g. carrots or tomatoes. Plastic items
may discolor permanently if they
come in contact with food dyes.
^ All items can be placed anywhere in
the baskets.
^ Load dishes so that water can reach
all surfaces. Do not place dishes or
cutlery inside other pieces.
Loading the dishwasher
The spray arms must not be blocked
^
by items that are too tall or hang
through the baskets. Check
clearance by manually rotating the
spray arms.
Place very small items in the cutlery
^
tray or basket so they do not fall to
the bottom of the wash cabinet.
Food residue and spilled liquids
^
should be cleaned from the sides of
the dishwasher door. These are
outside of the wash cabinet and are
not cleaned by water from the spray
arms.
^
Make sure that all items are securely
positioned.
^
Hollow items such as cups and
glasses should be placed upside
down in the baskets.
^
To ensure good water coverage, tall,
narrow and hollow items, i.e. vases
or champagne glasses, should be
placed in the center of the basket
rather than in the corners.
^
Concave based items such as mugs
or bowls, should be placed at an
angle so that water does not pool.
19
Loading the dishwasher
Items not recommended for
dishwashing
Cutlery with wooden handles
–
Wooden cutting boards
–
Glued items such as old knives with
–
handles glued together around the
shank of the blade
Handmade craft items, antique,
–
metal trimmed or decorative
glassware
Plastic items that are not heat
–
resistant
– Copper, brass, tin or aluminum
– Dishes with color painted over the
glaze. These dishes may fade over
time
– Fine glassware and crystal items
should only be washed using the
"China & Crystal" program*.
Otherwise clouding or etching may
occur after frequent washing.
–
Cast iron pots and pans
* depending on model
Glassware:
There are no standard guidelines for
–
washing glassware, when in doubt
wash by hand.
When purchasing new dishes,
–
glasses and cutlery, make sure they
are dishwasher safe. Only wash
items marked "dishwasher safe" in
the dishwasher.
If fine glassware is washed in the
–
dishwasher select the "China &
Crystal" program*. This will reduce
the risk of clouding.
Silver and aluminum:
– Silver or aluminum items may tarnish.
– Silverware previously cleaned with a
silver polish may be damp or spotted
at the end of a program where water
has adhered to the polish. This can
be rubbed off with a soft, dry cloth.
Silver that has been cleaned in an
immersion dip is usually dry at the
end of a program, but may tarnish.
–
If left to dry, foods containing sulfur
can discolor silver. These include
egg yolk, onions, mayonnaise,
mustard, fish and marinades.
If unsure whether your china and
crystal are dishwasher safe, please
check with the manufacturer. The
China & Crystal program*, although
extremely gentle and thorough can
cause the china and crystal to "wear"
if they are not dishwasher safe.
20
–
Silverware may tarnish or pit if
washed next to stainless steel.
Leave space between these metals.
–
Clean aluminum items, e.g. grease
filters, with domestic dishwasher
detergent only.
Loading...
