Operating and installation instructions
Built-in system drawer
ESS 3060-10
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time
en-GB
M.-Nr. 07 241 620
Contents
Guide to the appliance .............................................3
Warning and Safety instructions .....................................4
Caring for the environment..........................................5
Operation ........................................................6
How the appliance works ............................................6
To open and close the drawer ......................................6
Capacity..........................................................7
Cleaning and care .................................................8
Appliance front and interior ...........................................8
Anti-slip mat .......................................................9
Optional accessories..............................................10
Building-in combinations ..........................................11
Installation ......................................................12
After sales service, data plate ......................................13
2
a Anti-slip mat
Guide to the appliance
3
Warning and Safety instructions
In countries where there are areas
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before using it for the first time. They
contain important notes on its
installation, safety, use and
maintenance.
Keep these instructions in a safe
place for reference, and pass them
on to any future user.
This appliance is intended for
~
domestic use only, and must only be
used as described in these instructions.
Any other usage is at the owner's risk
and could be dangerous. The
manufacturer cannot be held liable for
damage resulting from incorrect or
improper use or operation.
The drawer may only be built in in
~
combination with the following Miele
appliances:
–
DG 3450 / 3460 steam ovens
–
CVA 3650 / 3660 coffee machines
For safety reasons, this machine
~
may only be used when it has been
fully installed.
This appliance is intended for
~
domestic use only and is not to be used
for commercial purposes.
Do not store cooked food in the
~
drawer. The moisture in the food can
lead to corrosion in the appliance.
~
which may be subject to infestation by
cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the guarantee.
Do not sit or lean on the opened
~
drawer. This can damage the
telescopic runners. The drawer has a
maximum load bearing capacity of
15 kg.
Repairs may only be carried out by
~
a service technician authorised by the
manufacturer. Repairs and other work
by unqualified persons could be very
dangerous and invalidate the
guarantee.
The appliance is only intended for
~
use by adults who have read these
instructions.
This appliance is not a toy! To avoid
~
the risk of injury, keep children well
away and do not let them play with it.
They should be supervised whenever
you are working in the kitchen.
Packaging, e.g. cling film,
~
polystyrene and plastic wrappings,
must be kept out of the reach of babies
and young children. Danger of
suffocation. Dispose of or recycle all
packaging safely as soon as possible.
4
Caring for the environment
Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and can normally be
recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Dispose of or recycle all packaging
materials safely as soon as possible.
Rather than just throwing these
materials away, please ensure that they
are recycled.
Disposal of your old appliance
Appliances often contain materials
which can be recycled. Please do not
therefore dispose of it with your
household waste.
Please dispose of it at your local
community waste collection/recycling
centre, and ensure that it presents no
danger to children while being stored
for disposal.
5
Operation
Please stick the extra data plate for the appliance supplied
with this documentation in the space provided in the "After
sales service" section of this booklet.
How the appliance works
The drawer is designed for storing crockery in only.
Do not store food or drinks in it, as moisture in the food or
drinks could cause corrosion damage to the drawer.
The base of the drawer is fitted with a non-slip mat which
stops crockery sliding about when the drawer is opened and
closed.
To open and close the drawer
The drawer can be opened and closed by pressing lightly in
the middle of the drawer front.
6
Operation
Capacity
The quantity that can be loaded will depend to a great extent
on the type and size of your crockery.
The layouts shown here are suggestions only.
The maximum load bearing capacity of the drawer is
15 kg.
Combining the drawer with a CVA 3650 or CVA 3660 coffee machine
– 24 espresso cups C 6 cm, plus saucers and spoons
or
– 15 cappuccino cups C 8 cm, plus saucers and spoons
Combining the drawer with a DG 3450 or DG 3460 steam oven
–
1 condensate tray (GN 1/2)
–
2 cooking containers (GN 1/3)
–
1 rack
7
Cleaning and care
Under no circumstances use a steam cleaning appliance
to clean this appliance. The steam could cause lasting
damage to the surface material and other components for
which the manufacturer cannot be held liable.
Only use domestic washing up liquid to clean this
appliance; commercial cleaning products are not suitable,
and may damage the appliance.
Appliance front and interior
Remove any soiling immediately.
If not, it might become impossible to remove and could
cause the outer surface to alter or discolour.
Clean the front using a Miele microfibre E-cloth or with a
clean sponge and a solution of hot water and washing-up
liquid. Then dry with a soft cloth.
The external surfaces of this appliance are all susceptible
to scratching. Scratches on glass surfaces could even
cause a breakage.
Contact with unsuitable cleaning agents can alter or
discolour the outer surfaces.
8
Anti-slip mat
Cleaning and care
To avoid damaging the surface of your appliance, do not
use:
cleaning agents containing soda, ammonia, acids or
–
chlorides,
cleaning agents containing descaling agents,
–
abrasive cleaning agents, e.g. powder cleaners and cream
–
cleaners,
solvent-based cleaning agents,
–
stainless steel cleaning agents,
–
dishwasher cleaner,
–
oven sprays,
–
– glass cleaning agents,
– hard, abrasive sponges and brushes, e.g. pot scourers,
– sharp metal scrapers.
The anti-slip mat can be removed for cleaning.
^ Clean the anti-slip mat by hand using warm water and a
little washing up liquid, and then dry with a cloth.
Do not put the anti-slip mat back into the drawer until it is
completely dry.
Do not wash the anti-slip mat in a dishwasher or washing
machine.
Never place the anti-slip mat in the oven to dry.
9
Optional accessories
These can be ordered via the internet at
www.miele-shop.com, or from the Miele Customer Contact
Centre (see back cover for contact details) or from your Miele
dealer.
Anti-slip mat
Anti-slip mat to keep crockery secure
E-Cloth (microfibre cloth)
Removes finger marks and light soiling.
10
The drawer may only be built in in combination with the
following Miele appliances:
DG 3450 and DG 3460 steam ovens
* Appliances with glass front / **Appliances with metal front
Building-in combinations
CVA 3650 and 3660 coffee machines
11
Installation
It is essential to read the operating and installation
instructions for any other appliance fitted in combination
with the drawer.
The niche dimension required will depend on which
appliance the drawer is combined with.
The combination appliance is placed directly on top of the
built-in drawer. An interim shelf is not required.
A fixed shelf in the housing which can take the weight of
both appliances is necessary.
12
^
Push the appliance into the housing unit as far as it will go,
and align it.
^
Open the drawer, and use the 2 screws supplied to secure
the appliance to the side walls of the housing unit.
^
Build in the combination appliance in accordance with its
own specific operating and installation instructions.
After sales service, data plate
In the event of any faults which you cannot remedy yourself, or if the appliance is
under guarantee, please contact:
your Miele Dealer
–
or
the Miele Customer Contact Centre (see back cover for address).
–
Please note that telephone calls may be monitored and recorded to improve
our service.
When contacting Miele, please quote the model and serial number of your
appliance, which are given on the data plate.
Space in which to stick the extra data plate supplied with the appliance. Ensure
that the model number is the same as the one on the front of these instructions.
131415
