Midland Radio LXT314 Users manual

LXT314/317 Series

GMRS/FRS Radio

TRA

TALK

OWNER'S MANUAL

www.midlandradio.com

®®

MIC

LXT314

Model LXT314/317 Series

Page 2 www.midlandradio.com

TABLE OF CONTENTS 2

Introduction 3 Important Notice, FCC Licensing 4 LCD Display 5 Controls 5 Battery Installation 6 Installing the Belt Clip 6 Charging the Optional Battery Pack 7 Low Battery Level Indicator 7 Operating Your Radio 8 - 10 Troubleshooting Guide 11 Use and Care 11 Specifications and Frequency Charts 12 Warranty Information 13 MIDLAND Family Products 14 Accessories 14 Accessories Order Form 15

Page 3 www.midlandradio.com

Welcome to the world of Midland electronics

Congratulations on your purchase of a high quality MIDLAND product. Your 2-way radio represents the state-of-the-art in high-tech engineering. Designed for GMRS (General Mobile Radio Service) operation, this compact package is big in performance. It is a quality piece of electronic equipment, skillfully constructed with the finest components. The circuitry is all solid-state and mounted on a rugged printed circuit board. Your two-way radio is designed for reliable and trouble-free performance for years to come.

Features

- 22 GMRS/FRS Channel

- CALL Alert

- SCAN Function

- Roger Beep Tone

- Silent Operation

- Key Pad Lock

- Power High / Low Settings

- Auto Squelch

- Battery Life Extender

- Battery Low Indicator

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device does not cause harmful interference, and (2) this radio must accept any interference that may cause undesired operation.

To maintain compliance with FCC’s RF exposure guidelines, for body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Midland Radio Corp. accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.

Model LXT314/317 Series

Page 4 www.midlandradio.com

IMPORTANT NOTICE, FCC LICENSE REQUIRED FOR GMRS OPERATION

The LXT314/317 Series operates on GMRS (General Mobile Radio Service) frequencies which require an FCC (Federal Communications Commission) license. You must be licensed prior to operating on channels 1 - 7 or 15 - 22, which comprise the GMRS channels of the LXT314/317 Series. Serious penalties could result for unlicensed use of GMRS channels, in violation of FCC rules, as stipulated in the Communications Act's Sections 501 and 502 (amended).

You will be issued a call sign by the FCC which should be used for station identification when operating the radio on GMRS channels. You should also cooperate by engaging in permissible transmissions only, avoiding channel interference with other GMRS users, and being prudent with the length of their transmission time.

To obtain a license or ask questions about the license application, contact the FCC at 1-888-CALL FCC or go to the FCC's website: www

.fcc.gov/services/personal/generalmobile/licensing.html

Exposure To Radio Frequency Energy

Your Midland radio is designed to comply with the following national and international standards and guidelines regarding exposure of human being to radio frequency electromagnetic energy:

- United States Federal Communications Commission, Code of Federal Regulations: 47 CFR part 2 sub-part J

- American National Standards Institute (ANSI)/Institute of Electrical & Electronic Engineers (IEEE) C95. 1-1992

- Institute of Electrical and Electronic Engineer (IEEE) C95. 1-1999 Edition

- National Council on Radiation Protection and Measurements (NCRP) of the United States, Report 86, 1986

- International Commission on Non-lonizing Radiation Protection (ICNIRP) 1998

To control your exposure and ensure compliance with the general population or uncontrolled environment exposure limits, transmit no more than 50% of the time. The radio generates measurable RF energy exposure only when transmitting.

Model LXT314/317 Series

IMPORTANT: Changes or modifications to this unit not expressly approved by MIDLAND RADIO CORP. could void your right to operate this unit. Your radio is set

up to transmit a regulated signal on an assigned frequency. It is against the law to alter or adjust the settings inside the COMMUNICATOR to exceed those limitations. Any adjustment to your radio must be made by qualified technicians.

Page 5 www.midlandradio.com

CONTROLS

LCD DISPLA

1. LOW BATTERY ICON – Indicates the battery level is low.

2. TRANSMIT (TX) ICON – Indicates radio is transmitting a signal.

3. CHANNEL NUMBER – Changes from 1~22 on GMRS/FRS band (1~10 on WX band).

4. KEY LOCK ICON – Indicates KEY LOCK mode is on.

5. RECEIVE (RX) ICON – Indicates radio is receiving a transmission.

6. TRANSMIT POWER LEVEL ICON – Indicates TX Power setting (H/L)

7. PTT Button – Press and hold to transmit voice communication.

8. CALL/LOCK Button – Press to send a CALL Alert signal. Press and hold to turn KEY LOCK on/off.

9. MIC – Built-in microphone.

10. SPEAKER – Built-in speaker.

1 1. ANTENNA.

12. POWER / MENU Button – Press and

hold for at least 3 seconds to turn the radio on/off. Press momentarily to access Menu mode.

13. SCAN Button – Press to enter SCAN

mode.

14. UP and DOWN Button – Make

adjustments in MENU mode.

1 2

4 5 6

Model LXT314/317 Series

LXT314

-TRA ALK
