Midland ER310 User Manual

Model ER310

Table of Contents - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2

Features - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3

Controls and Functions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4

ER310 Power Sources - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6

Using the USB Output Port to Charge a Device - - - - - - - - - - 8

Operating the Radio - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8

Using the Weather Radio - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9

ER310 Settings Menu- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11

LED Flashlight - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

SOS Morse Code Flashlight Beacon - - - - - - - - - - - - - - - - - - - - - 12

Ultrasonic Dog Whistle - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

Using the Headphone Jack - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

Limited Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 13

Service - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15

Other Products - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17

FCC Notice - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18

Page 2

midlandusa.com

Model ER310

Welcome to the World of Midland Electronics

The Midland ER310 is skillfully constructed from the finest
components. Built with emergency situations in mind, the hand
crank digital weather alert radio and flashlight are perfect for
severe weather situations or daily use.

Features

• Charge battery 3 ways: hand crank, USB or solar panel

• 7 NOAA/NWS weather alert channels and 1 hour alert memory

• Rechargeable Lithium-ion battery

• Powerful flashlight uses Cree®* LEDs

• SOS Morse code flashlight beacon

• Ultrasonic dog whistle

• Charge external electronic devices

• AM/FM radio

• AA battery power option

• Digital clock

• Headphone jack

• Rotatable telescopic antenna

• Large, bright, backlit LCD

*Cree® is a registered trademark of Cree, Inc. or one of its subsidiaries.

midlandusa.com

Page 3

Controls and Functions

Model ER310

Flashlight/

SOS/Dog

Whistle

Button

Ultrasonic

Dog

Whistle

Page 4

LCD

Display

LED

Flashlight

Solar

Panel

Charge/
Weather
Memory

Indicator

Antenna

Speaker

Tuning

Adjust

Buttons

Volume

Adjust

Buttons

Weather

Alert/Menu

Button

Power/

Band

Button

midlandusa.com

Model ER310

Controls and Functions Continued...

Headphone

Jack

USB Output

Port

USB Input

Port

AA/Li-ion

Power Switch

midlandusa.com

Dynamo

Crank

Page 5

Model ER310

Powering Your ER310
USB Charge Cable: Before the ER310 is used, the internal

rechargeable battery pack should be charged with the USB charge
cable until the battery indicator icon indicates a full charge. To
charge the ER310 with the USB cable, switch the power source
switch to the “Li” position. Then, insert the USB charge cable into
a USB power source and plug the micro USB connector into
the port labeled “USB In” on the side of the radio. The CHARGE
indicator light will be lit when the USB charge cable is plugged
in. The battery icon on the LCD will flash as the battery charges.
When the Li-ion battery has reached full charge, the battery icon
will stop flashing and will have 3 bars. It will take approximately

5.5 hours to recharge a completely depleted battery pack using the
USB charge cable.

Rechargeable Battery: The included rechargeable battery

is located in the battery compartment and is charged by turning
the hand crank, exposing the solar panel to sunlight, or by using
the USB cable to attach to a USB power source. The battery is
specified as 3.7 VDC, 2600 mAh, lithium ion (Li-ion).

Warning:

• Only use Midland’s Li-ion battery pack.

• Do not attempt to charge alkaline batteries or any battery packs

other than the ones indicated in this manual. This could cause
leakage and damage to the radio.

Page 6

midlandusa.com
