Midea MC-ID351 User Manual

Induction Hob

Instruction Manual / Installation Manual

MODEL: MC-ID351

2

Congratulations on the purchase of your new Induction Hob.

We recommend that you spend some time to read this Instruction / Installation
Manual in order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Mnual for future reference.

Product Overview

Top View

Control Panel

1. max. 2000 W zone

2. max. 1500 W zone

3. Glass plate

4. ON/OFF control

5. Control panel

1. ON/OFF control

2. Power / Timer regulating controls

3. Heating zone selection controls

4. Timer control

5. keylock control

3

A Word on Induction Cooking

Induction cooking is a safe, advanced, efficient, and economical cooking
technology. It works by electromagnetic vibrations generating heat directly in
the pan, rather than indirectly through heating the glass surface. The glass
becomes hot only because the pan eventually warms it up.

Before using your New Induction Hob

• Read this guide, taking special note of the ‘Safety Warnings’ section.

• Remove any protective film that may still be on your Induction hob.

Using the Touch Controls

• The controls respond to touch, so you don’t need to apply any pressure.

• Use the ball of your finger, not its tip.

• You will hear a beep each time a touch is registered.

• Make sure the controls are always clean, dry, and that there is no object (e.g.
a utensil or a cloth) covering them. Even a thin film of water may make the
controls difficult to operate.

iron pot

magnetic circuit
ceramic glass plate
induction coil
induced currents

4

Choosing the right Cookware

• Only use cookware with a base suitable for induction
cooking. Look for the induction symbol on the

packaging or on the bottom of the pan.

• You can check whether your cookware is suitable by carrying out
a magnet test. Move a magnet towards the base of the pan. If it
is attracted, the pan is suitable for induction.

• If you do not have a magnet:

1. Put some water in the pan you want to check.

2. Follow the steps under ‘To start cooking’ on page 5.

3. If does not flash in the display and the water is heating, the pan is suitable.

• Cookware made from the following materials is not suitable: pure stainless steel, aluminium or

copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

Do not use cookware with jagged edges or a curved base.

Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size as the cooking zone. Use pans whose diameter is as large as the
graphic of the zone selected.Using a pot a slightly wider energy will be used at
its maximum efficiency.If you use smaller pot efficiency could be less than
expected.Pot less than 140 mm could be undetected by the hob. Always centre
your pan on the cooking zone.

Always lift pans off the Induction hob – do not slide, or they may scratch the
glass.

5

Using your Induction Hob

To start cooking

1. Touch the ON/OFF control.

After power on, the buzzer beeps once, all displays

show “ – “ or “ – – “, indicating that the induction
hob has entered the state of standby mode.

2. Place a suitable pan on the cooking zone that

you wish to use.

• Make sure the bottom of the pan and the surface

Of the cooking zone are clean and dry.

3. Touching the heating zone selection control

(e.g. zone 1#),and a indicator next to the
key will flash

4. Select a heat setting by touching the ”-“ or “+”

control.

• If you don’t choose a heat setting within 1
minute, the Induction hob will automatically
switch off. You will need to start again at
step 1.

• You can modify the heat setting at any time

during cooking.

6

If the display flashes alternately with the heat
setting

This means that:

• you have not placed a pan on the correct cooking zone or,

• the pan you’re using is not suitable for induction cooking or,

• the pan is too small or not properly centered on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.
The display will automatically turn off after 2 minutes if no suitable pan is
placed on it.

When you have finished cooking

1. Touching the heating zone selection
control that you wish to switch off
(e.g. zone 1#),

2. Turn the cooking zone off by scrolling down to” 0” or touching”-“ and”+”
control together. Make sure the display shows”0”

3. Turn the whole cooktop off by touching the ON/OFF control.

7

4. Beware of hot surfaces

H will show which cooking zone is hot to touch. It will disappear when the

surface has cooled down to a safe temperature. It can also be used as an
energy saving function if you want to heat further pans, use the hotplate

that is still hot.

Locking the Controls

• You can lock the controls to prevent unintended use (for example children

accidentally turning the cooking zones on).

• When the controls are locked, all the controls except the ON/OFF control are

disabled.

To lock the controls

Touch the keylock control. The timer indicator will show “ Lo “

To unlock the controls

1. Make sure the Induction hob is turned on.

2. Touch and hold the keylock contro for a while.

3. You can now start using your Induction hob.

When the hob is in the lock mode,all the controls are disable except the
ON/OFF , you can always turn the ceramic hob off with the ON/OFF

control in an emergency,but you shall unlock the hob first in the next

operation

Over-Temperature Protection

A temperature sensor equipped can monitor the temperature inside the
Induction hob. When an excessive temperature is monitored, the Induction hob
will stop operation automatically.

Detection of Small Articles

When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other
small item (e.g. knife, fork, key) has been left on the hob, the hob automatically
go on to standby in 1 minute. The fan will keep cooking down the induction hob
for a further 1 minute.
