USER MANUAL
BLENDER
MBL-25PK
MBL-25GN
A
B
C
D
E
Please read the manual carefully before operating your product.
Retain it for future reference.
F
技术要求(版本号: A, 2017-01）
1、颜色：双色（黑色+蓝色）
2、尺寸（mm）：145x210，采用钉装
3、此页为技术要求，印刷内容从下一页开始
D
E
F
G
H
处数 更改文件号 签 字 日 期
标记
1
邹兰
-----
-----
-----
审 核
标准化
审 定
日 期
制 图
设 计
校 对
会 签
徐明旭
古广君
古广君
20170327
2
榨汁机
MJ-BL2521H(MBL-25PK)
使用说明书
K
3
4
1:1
16164000A04101
马来西亚MIDEA-MJ-BL2521H
(MBL-25PK)-0501
材料:
100g双胶纸
广东美的电热电器制造有限公司
5
6
G
H
USER MANUAL
BLENDER
MBL-25PK
MBL-25GN
Please read the manual carefully before operating your product.
Retain it for future reference.
1.Read carefully and save all the instructions provided with this appliance.
2.Always use your appliance from a power outlet of the voltage (A.C. only)
marked on the appliance.
3.This appliance is designed for domestic use only.
4.Do not pull on the connection cord, but rather on the plug, to separate
the appliance from the mains.
5.Do not use outdoor.
6.Do not leave the appliance unattended when it is switched on, as this
may be a source of danger.
7.Stand the appliance on a table or flat surface.
8.If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
9.Do not operate for more than 2 minutes. Keep 1 minute rest between
each cycle.
10. Avoid touching the moving parts.
11.Do not blend hot ingredients.
12.Ensure the control dial is in the off '0' position before plugging-in.
13.Turn off the power and unplug when the appliance is not use and before
cleaning.
14.Do not use your appliance with an extension cord unless this cord has
been checked and tested by a qualified technician or service person.
15.Do not use an appliance for any purpose other than its intended use.
16.Do not place an appliance on or near a hot gas flame, electric element
or on a heated oven. Do not place on top of any other appliance.
17.Do not let the power cord of an appliance hang over the edge of a table
or bench top or touch any hot surface.
18.Do not operate any electrical appliance with a damaged cord or after
the appliance has been dropped or damaged in any manner.
19.Do not immerse the appliance in water or any other liquid.
20.Be careful when handing the sharp cutting blades, emptying the bowl
and during cleaning.
21.Cleaning and user maintenance shall not be made by children without
supervision.
1
22.This appliance shall not be used by children. Keep the appliance
and its cord out of reach of children.
23.This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
24.Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
25.This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
26.Children should be supervised to ensure that they do not play with
the appliance.
27.If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
28.Household use only.
29.Switch off the appliance and disconnect from supply before changing
accessories or approaching parts that move in use.
30.Be careful if hot liquid is poured into the food processor or blender as
it can be ejected out of the appliance due to a sudden steaming.
2
Package contents
•Blender (1 pc)
•Instruction manual (1 pc)
General Description
A
B
C
D
A. Lid stopper
B. Lid
C. Jar (1.2 Liters)
D. Rubber ring
E
F
G
H
E. Removable Blade Assembly
F. Motor Base
G. Power switch
H. Rubber Feet
3
Technical Data
Product
name
Blender
Model
MBL-25PK
MBL-25GN
Voltage
220-240V~
Frequen cy
50/60Hz
Power
250W
Installation and Maintenance
Before Using Your Blender
Important:
Always ensure your blender is unplugged
from the power outlet before fitting or
removing the blade assembly.
Always handle the blade assembly with caution,
as the blades are extremely sharp.
To assemble the blade system, operate as follows:
1.Place the silicone rubber seal over
assembly, as shown in Fig.1.
2.Place the blade assembly into the base of blender jar.
3.Ensure that the blade assembly is firmly in the place
by turning it counter clockwise as indicated by the
arrow.(as Fig.2).
the blade
Fig.2.
Capacit y
1.2L
Fig.1.
Using Your Blender
1.Place the blender jar on the motor base and rotate
clockwise (as Fig.3).
2.Remove the lid or the lid stopper from the blender jar,
put the ingredients into the jar.
3.Place the lid with the lid stopper back onto the jar.
Do not exceed the maximum indicated level1.5 liters.
4.Turn the speed control knob to the 'ON' position.
After you have completed blending, turn the speed
control knob to the 'OFF' position.
4
Fig.3
5.
a
b
a:Turn the inner lid off the lid in
the direction of anticlockwise.
6.After you have done you work, set the control knob to position ‘OFF’,
unplug the appliance, and pour out the drink.
b:Add the ingredients into the jar
through the opening in the lid.
Handy Blending Hints
1.A brief whirl in the blender will rescue a lumpy gravy, or an eggs-based
sauce that has separated.
2.Food items for blending should be cut into cubes (approximately 2-3cm),
this will assist in achieving an even result.
3.Never fill the blender jar above the maximum level indicated.
4.To ensure efficient mixing when blending dry mixtures, it may be
necessary to stop the blender and push ingredients down the sides of
the jar with a spatula ( not provided).
5.When blending a variety of ingredients together, blend the liquids first,
and then add dry ingredients.
6.Always ensure stones are removed from fruit and bones from meat as
these can damage the blades.
7.Do not process hot liquid in your blender. Allow to cool before processing.
8.Always ventilate the blender jar when pureeing warm ingredients, it can be
done by lifting the ingredient cup out of the lid, after starting the blender.
5
Cleaning and Storage
Quick cleaning method
1.Half fill the blender with warm and little detergent.
2.Press the 'ON' function and hold for 1-2 seconds and release.
Repeat 3-4 times.
3.Then remove the jar and rinse it under running water.
For thorough cleaning
1.Unscrew the blade assembly from the jar by turning
the bottom of the blade assembly in clockwise
direction. (as Fig.4).
2.Remove the rubber seal from the blade assembly.
3.Wash the blender lid, lid stopper, rubber seal, blade
assembly and blender jar in warm soapy water.
4.Only use a damp, soft sponge with detergent and wipe to clean the
motor base.
Caution: Take care when cleaning the blades as they are extremely sharp.
Note: Do not clean any part of the blender in the dishwasher.
Note: Never immerse the motor base in water.
Storage
1.Coil the power cord around the cord storage at the bottom of the
motor base.
2.Store in a cool and dry place.
Fig.4
