Midea MB-FZ4086 Operating Instructions Manual
Operating Instructions
for IH Intelligent Electric Cooker
MB-FZ4086
Please read the Operating Instruc
NOTE：The Midea Warranty Certificate attached in the Chinese Version.
tions carefully before operation!
The Operating Instructions contain the warranty card, and shall be kept properly.
It’s your Idea
Quick Start/001
Panel Operation Process-001
Product Features/002
Instructions of the Usage/008
Maintenance/018
Points to Use
Tips of Usage-006
-002
Part Description-008
Product Operation Guide-018
Care Instructions-016
Abnormality Analysis
and Troubleshooting-018
Note：Midea Warranty Certificate
attached in the Chinese Version.
Function
Rice Selectes
Quick Start
Panel Operation Process
Sliding
The Electric Cooker is only applicable to the
household use. Please refer to the Operating
Instructions for the specific using methods.
Quick Start
Press “Function” button
and choose the
cooking feature.
Select the cooking functions such
as cereal rice by slipping the
slider or by pressing the left /right
arrow.
Casserole Rice
Brown Rice
Keep Warm
Mew Rice
Rice
Pearl Rice
Rice Select
Press the "Rice Select" to
choose the fragrant cooking,
ultra-fast cooking, rice
porridge, porridge cooking and
soup rice cooking functions.
Select the “Rice Select”
will be saved and for
the next use.
Quick Start
Product Features
Operating Instructions
Maintenance
Press the START
button after finishing
the cooking settings.
START
Mew Rice
Rice
Pearl Rice
Quick Start
Product Features
Operating Instructions
Maintenance
Product Features
Points to Use
Follow the safety notes to ensure the operation safety as well as avoid the people
injured and property damaged.
Improper use due to the failure of observing the safety warning may lead to the
accidents.
Do not modify the product
People who are not the maintenance
technician are not allowed to decompose
and repair the product, in order to avoiding the
fire, electric shock or injury.
Use of voltage other than 220V AC
is prohibited, to avoid the fire
and electric shock. Power cord which
is damaged cannot be used.
Do not cover the steam outlet
with cloth during operation.
Do not put the product near
the flammable materials and
keep away from curtains,
cloths, curtain walls or similar
items articles when using, or
otherwise it may cause fires or
damage to the electric cooker.
Do not move or shake the
electric cooker during
cooking.
Keep your hands or face
away from the steam outlet
when it starts, to avoid being
burned.
Food which may block the vent
hole should not be cook in the
electric cooker, such as flake food
(i.e. seaweed, cabbage) or strip food
(i.e. kelp) and fragmented food (i.e.
corn residue), so as not to cause an
accident or damage to the cooker.
Get
acquainted for our
first meeting!
Quick Start
Product Features
Operating Instructions
Maintenance
Situations will not be considered by the product are as follows:
- Use of the product by the uncared children and the disabled.
- Children play the appliance as toys.
Do not insert a pin, wire or
other items to the vent hole
located at bottom of the
cooker, to avoid electric
shock and injury.
Do not put the cooker on a place which is
unstable, humid or near other sources of
ignition and heat (such as stoves), and the
distance between which shall be at least
30cm, or otherwise it will be damaged.
Children are not
allowed to operate it
individually. Place
the cooker in a place
which children
cannot touch, to
avoid the electric
shock or being burned
as well as other
accidents.
Following ways are prohibited, or
otherwise the power cord will be
damaged and thus lead to the fire
and electric shock.
The power cord is bent forcibly, or
placed in close to the high-temperature place, or in bundle and bearing
heavy weight.
Do not pull and insert the plug
with wet hand, as it may lead
to the electric shock and injury.
Once the plug of power cord is
damaged, it will be no longer
used, as it may cause fire,
electric shock or short circuit.
Meanings of Icons
Represent the [prohibited] content
Warning: indicate the matters which will
lead to the casualties.
Represent the [compulsory] content
Note: it denotes the matters which may
cause minor injury or damage to property.
Quick Start
Product Features
Operating Instructions
Maintenance
Socket with earthing wire and rated
current of 13
A and above shall be
separately used.
When using together with other electric
appliances, the socket may have
exception occurred, causing fires and
other accident.
The appliance cannot be immersed
into water or be sprayed.
Clear the dirt or water stains appeared on
the plug and tail of power cord as well as
on the socket in a timely manner, so as not
to cause a fire, electric shock or short circuit.
If the power cord is too short, users must use
the extension socket, and low-quality
extension socket shall not be used.
Clean the water deposited
on the outside of the inner
pot before cooking.
The product maintenance
or part replacement should
be done by midea customer
service center,
to avoid the
hidden troubles caused due
to the improper
maintenance or improper
selection of accessories.
Plug should be completely
inserted into the socket,
to prevent fire, electric shock and short
circuit. If the flexible cord is damaged, it must
be replaced with a special cord or the special
components purchased from the
customer service center.
The product should only be used indoor.
Quick Start
Product Features
Operating Instructions
Maintenance
Do not touch the inner pot directly
with your hands when the cooker
works or after turning off, to protect
from being burned by such high
temperature.
Do not knock against the
inner pot with hard
object to avoid
deformation.
Please clear the water drop, rice
kernel left between the inner pot and
coil panel before the cooker starts, to
avoid the overheat or short circuit.
The inner pot should not be
fell, or otherwise it may be
deformed.
The rice cooker
should only use the
original inner pot, so
as to avoid overheat
and abnormality.
Persons equipped with pacemakers or users
with hearing aids and cochlear implanted
shall consult with the authorized medical
personnel and refer to the instructions from
medical device provider when using the
product.
Some important elements like fuse and other critical
elements, with the improper maintenance or
connected by yourselves, may lead to the failure of
product, thereby causing the overheating or fire.
